Driving your vehicle

Vehicle weight

Vehicle weight
This section will guide you in the
proper loading of your vehicle, to
keep your loaded vehicle weight
within its rating capability. Prop

erly loading your vehicle will pro

vide maximum return of vehicle
performance. Before loading your
vehicle, familiarize yourself with
the following terms to deter

mine

your vehicle's weight rat

ings,

from the vehicle's specifications
and the certifica

tion label:

Base curb weight
This is the weight of the vehicle
including a full tank of fuel and all
standard equipment. It does not
include passengers, cargo, or
optional equipment.

Vehicle curb weight
This is the weight of your new
vehicle when you took delivery
from your dealer plus any after

market equipment.

Cargo weight
This figure includes all weight
added to the Base Curb Weight,
including cargo and optional
equipment.

G AW (Gross axle weight)
This is the total weight placed on
each axle (front and rear) -
including vehicle curb weight,
passenger weight and cargo
weight.

GAW R (Gross axle weight rat

ing)
This is the maximum allowable
weight that can be carried by a
single axle (front or rear). These
numbers are shown on the certi

fication label.
The total load on each axle must
never exceed its GAWR.

G V W (Gross vehicle weight)
This is the Base Curb Weight plus
actual cargo weight plus passen

gers.

GVW R (Gross vehicle weight
rating)
This is the maximum allowable
weight of a fully loaded vehicle
(including all options, equipment,
passengers and cargo). The
GVWR is shown on the certifica

tion label located on the

driver’s

(or front

passenger’s) door sill.

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view

camera only)...................................................................................6-4

•

Forward Collision-Avoidance Assist setting ......................................... 6-
5

•

Forward Collision-Avoidance Assist operation ................................... 6-6

僅

Forward Collision-Avoidance Assist malfunction and

limitations.............................................................................................................

Forward Collision-Avoidance Assist (FCA) (Sensor fusion) .. 6-15

•

Detecting sensor............................................................................................. 6-
15

•

Forward Collision-Avoidance Assist setting ....................................... 6-
16

•

Forward Collision-Avoidance Assist operation ................................. 6-18

僅

Forward Collision-Avoidance Assist malfunction and

limitations..........................................................................................................

Lane Keeping Assist (LKA)......................................................... 6-27

•

Detecting

sensor............................................................................................. 6-

•

Lane Keeping Assist setting ...................................................................... 6-
27

•

Lane Keeping Assist operation.................................................................6-
28

•

Lane Keeping Assist malfunction and limitations........................... 6-30

Blind-Spot Collision Warning (BCW ) ........................................6-32

•

Detecting

sensor.............................................................................................6-

•

Blind-Spot Collision Warning setting.................................................... 6-34

•

Blind-Spot Collision Warning ....................................................................6-
36

•

Blind-Spot Collision Warning malfunction and limitations ..........6-37

Blind-Spot Collision-Avoidance Assist (BCA) .......................... 6-41

•

Detecting

sensor.............................................................................................6-

•

Blind-Spot Collision-Avoidance Assist setting.................................. 6-43

•

Blind-Spot Collision-Avoidance Assist operation ............................ 6-45

僅

Blind-Spot Collision-Avoidance Assist malfunction and

limitations..........................................................................................................

Driving assistance system

Driver Attention Warning (DAW ) ............................................. 6-55

•

Driver Attention Warning setting ............................................................6-55

•

Driver Attention Warning operation ......................................................6-56

僅

Driver Attention Warning malfunction and limitations .................6-59

Cruise Control (CC)......................................................................6-61

•

Cruise Control operation ............................................................................ 6-
61

Smart Cruise Control (SCC) ....................................................... 6-64

•

Overtaking Acceleration Assist ................................................................6-64

僅

Detecting sensor ............................................................................................6-64

•

Smart Cruise Control setting ....................................................................6-
64

•

Smart Cruise Control operation...............................................................6-67

•

Smart Cruise Control malfunction and limitations.......................... 6-72

Navigation-based Smart Cruise Control (NSCC) .....................6-77

•

Navigation-based Smart Cruise Control setting ..............................6-78

•

Navigation-based Smart Cruise Control operation ........................6-78

Lane Following Assist (LFA) ...................................................... 6-83

•

Detecting sensor ............................................................................................6-
83

•

Lane Following Assist setting .................................................................. 6-
84

•

Lane Following Assist operation............................................................. 6-
84

•

Lane Following Assist malfunction and limitations.........................6-86

僅

Limitations of Lane Following Assist .....................................................6-86

Highway Driving Assist (HDA).................................................. 6-87

•

Highway Driving Assist setting ............................................................... 6-
88

•

Highway Driving Assist operation ......................................................... 6-
88

•

Highway Driving Assist operating ..........................................................6-
89

•

Highway Driving Assist malfunction and limitations..................... 6-90

Rear View Monitor (RVM).......................................................... 6-92

•

Detecting sensor ............................................................................................ 6-
92

•

Rear View Monitor setting..........................................................................6-
93

Driving assistance system

Rear Cross-Traffic Collision Warning (RCCW ) ....................... 6-95

•

Rear Cross-Traffic Collision Warning setting.....................................6-95

•

Rear Cross-Traffic Collision Warning ....................................................6-97

僅

Rear Cross-Traffic Collision Warning malfunction and

limitations...........................................................................................................6-97

Rear Cross-Traffic Collision-Avoidance Assist (RCCA)........ 6-101

僅

Rear Cross-Traffic Collision-Avoidance Assist setting................ 6-102

僅

Rear Cross-Traffic Collision-Avoidance Assist operation.......... 6-103

•

Rear Cross-Traffic Collision-Avoidance Assist malfunction

and

limitations...............................................................................................

107

Reverse Parking Distance Warning (PDW ) ............................. 6-111

•

Reverse Parking Distance Warning setting .......................................6-
112

•

Reverse Parking Distance Warning operation .................................6-

112

僅

Reverse Parking Distance Warning malfunction and

precautions......................................................................................................

113

Declaration of conformity ........................................................ 6-114

•

The radio frequency components (Front Radar) complies: ...... 6-114

僅

The radio frequency components (Rear Corner Radar)

complies:...........................................................................................................

115

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

Driving assistance system

INFORMATION

The information displayed on the info

tainment system may not have some
menu or may appear different from this
user manual depending on the specifica

tions of your vehicle. The infotainment
system may change after software
updates. For more details, access the
manual using the QR code in the info

tainment system quick reference guide.

Forward

Collision

–Avoidance

Assist (FCA) (Front view cam

era only) (if equipped)

Forward Collision-Avoidance Assist is
designed to help detect and monitor the
vehicle ahead or help detect a pedes

trian in the roadway and warn the driver
that a collision is imminent with a warn

ing message, audible warning and apply
emergency braking.

Detecting sensor

[1]: Front view camera
Refer to the picture above for the
detailed location of the detecting sen

sors.

CAUTION

Take the following precautions to main

tain optimal performance of the detect

ing sensor:
• Never disassemble the detecting sen

sor or sensor assembly, or cause any
damage to it.

• If the detecting sensor has been

replaced or repaired, have your vehi

cle inspected by an authorized Kia
dealer.

• Never install any accessories or stick

ers on the front windshield, or tint the
front windshield.

• Pay extreme caution to keep the front

view camera dry.

• Never place any reflective objects (for

example, white paper, mirror) over the
dashboard.

OBDM052357N

OBDM052015N

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

Forward Collision-Avoidance
Assist setting

Forward Safety

With the ignition switch or ENGINE
START/STOP button in the ON
position, select 'Driver Assistance

→

Forward Safety' from the 'User Settings
(LCD dis

play) or Setup

→ Vehicle

(Infotainment System screen)' menu to
set whether to use each function.
• If 'Active Assist' is selected, Forward

Collision-Avoidance Assist will warn
the driver with a warning message
and an audible warning depending on
the collision risk levels. Braking assist
may be applied depending on the col

lision risk levels. Braking assist will be
applied depending on the collision risk.

• If 'Warning Only' is selected, Forward

Collision-Avoidance Assist will warn
the driver with a warning message
and an audible warning depending on
the collision risk levels. Braking will not
be assisted. The driver must apply the
brake pedal if necessary.

• If 'Off' is selected, Forward Collision-

Avoidance Assist will be turned off.

The

warning light will illuminate

on the cluster.

The driver can monitor Forward Colli

sion-Avoidance Assist On/Off status

from the settings menu. If the

warning light remains on when Forward
Collision-Avoidance Assist is on, have
the vehicle inspected by an authorized
Kia dealer.

W ARNING

• When the engine is restarted, Forward

Collision-Avoidance Assist will always
turn on.

• If 'Off' is selected from the settings

menu, Forward Collision-Avoidance
Assist will not operate so the driver
should always be aware of the sur

roundings and drive safely.

CAUTION

If 'Warning Only' is selected, braking is
not assisted.

NOTICE

Forward Collision-Avoidance Assist will
turn off when ESC is turned off by press

ing and holding the ESC OFF button and

the

warning light will illuminate on

the cluster.

OMQ4AH050344

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

Warning Timing

With the ignition switch or ENGINE
START/STOP button in the ON position,
select 'Driver Assistance

→ Warning

Timing' from the 'User Settings (LCD dis

play) or Setup

→ Vehicle (Infotainment

System screen)' menu to change the ini

tial warning activation time for Forward
Collision-Avoidance Assist.

When the vehicle is first delivered, Warn

ing Timing is set to 'Normal'.
If you change the Warning Timing, the
Warning Timing of other Driver Assis

tance systems may change.

Warning Volume

With the ignition switch or ENGINE
START/STOP button in the ON position,
select 'Driver Assistance

→ Warning Vol

ume' from the 'User Settings (LCD dis

play) or Setup

→ Vehicle (Infotainment

System screen)' menu to change the
Warning Volume to 'High', 'Medium' or
'Low' for Forward Collision-Avoidance
Assist.

If you change the Warning Volume, the
Warning Volume of other Driver Assis

tance systems may change.

CAUTION

• The setting of the Warning Timing

and Warning Volume applies to all
functions of Forward Collision-Avoid

ance Assist.

• Even though 'Normal' is selected for

Warning Timing, if the front vehicle
suddenly stops, the warning may
seem late.

• Select 'Late' for Warning Timing when

traffic is light and when driving speed
is slow.

NOTICE

If the engine is restarted, Warning Tim

ing and Warning Volume will maintain
the last setting.

Forward Collision-Avoidance
Assist operation

Warning and control

The basic function for Forward Collision-
Avoidance Assist is to warn and help
control the vehicle depending on the col

lision risk level: 'Collision Warning',
'Emergency Braking' and 'Stopping vehi

cle and ending brake control'.

OMQ4AH050334

OBD041619L

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

Collision Warning

• To warn the driver of a collision, the

'Collision Warning' warning message
will appear on the cluster, and an
audible warning will sound.

• If a vehicle is detected in front, the

function will operate when your vehi

cle speed is between approximately
6~112 mph (10~180 km/h).

• If a pedestrian is detected in front, the

function will operate when your vehi

cle speed is between approximately
6~37 mph (10~60 km/h).

• If 'Active Assist' is selected, braking

may be assisted.

Emergency Braking

• To warn the driver that Emergency

Braking will be assisted, the 'Emer

gency Braking' warning message will
appear on the cluster, and an audible
warning will sound.

• If a vehicle is detected in front, the

function will operate when your vehi

cle speed is between approximately
6~37 mph (10~60 km/h).

• If a pedestrian is detected in front, the

function will operate when your vehi

cle speed is between approximately
6~37 mph (10~60 km/h).

• In emergency braking situation, brak

ing is assisted with strong braking
power by the function to help prevent
collision with the vehicle or pedestrian
ahead.

Stopping vehicle and ending
brake control

• When the vehicle is stopped due to

Emergency Braking, the 'Drive care

fully' warning message will appear on
the cluster.

• For your safety, the driver should

depress the brake pedal immediately
and check the surroundings.

• Brake control will end after the vehicle

is stopped by emergency braking for
approximately 2 seconds.

OBD041231L

OBD041232L

OBD041233L

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

W ARNING

• For your safety, only change the set

tings after parking the vehicle at a
safe location.

• With 'Active Assist' or 'Warning Only'

selected, when ESC is turned off by
pressing and holding the ESC OFF
button, Forward Collision-Avoidance
Assist will turn off automatically. In this
case, Forward Collision-Avoid

ance

Assist cannot be set from the settings
menu and the warning light will
illuminate on the cluster which is
normal. If ESC is turned on by press

ing the ESC OFF button, Forward
Col

lision-Avoidance Assist will

maintain the last setting.

• Forward Collision-Avoidance Assist

does not operate in all situations or
cannot avoid all collisions.

• The driver should hold the responsi

bility to control the vehicle. Do not
solely depend on Forward Collision-
Avoidance Assist. Rather, maintain a
safe braking distance, and if neces

sary, depress the brake pedal to
reduce driving speed or to stop the
vehicle.

• Never deliberately test Forward Colli

sion-Avoidance Assist on people,
objects, etc. It may cause serious
injury or death.

• Forward Collision-Avoidance Assist

may not operate if the driver
depresses the brake pedal to avoid
collision.

• Depending on the road and driving

conditions, Forward Collision-Avoid

ance Assist may warn the driver late
or may not warn the driver.

• During Forward Collision-Avoidance

Assist operation, the vehicle may stop
suddenly injuring passengers and

shifting loose objects. Always have the
seat belt on and keep loose objects
secured.

• If any other function's warning mes

sage is displayed or audible warning
is generated, Forward Collision-Avoid

ance Assist warning message may not
be displayed and audible warning
may not be generated.

• You may not hear the warning sound

of Forward Collision-Avoidance Assist
if the surrounding is noisy.

• Forward Collision-Avoidance Assist

may turn off or may not operate prop

erly or may operate unnecessarily
depending on the road conditions and
the surroundings.

W ARNING

• Even if there is a problem with For

ward Collision-Avoidance Assist, the
vehicle's basic braking performance
will operate properly.

• During emergency braking, braking

control by Forward Collision-Avoid

ance Assist will automatically cancel
when the driver excessively depresses
the accelerator pedal or sharply steers
the vehicle.

CAUTION

Depending on the condition of the vehi

cle, pedestrian in front and the sur

roundings, the speed range to operate
Forward Collision-Avoidance Assist may
reduce. The function may only warn the
driver, or the function may not operate.

NOTICE

When a collision is imminent, the For

ward Collision-Avoidance Assist may

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

assist the driver with braking if the driver
fails to brake enough.

Forward Collision-Avoidance Assist
malfunction and limitations

Forward Collision-Avoidance
Assist malfunction

When Forward Collision-Avoidance
Assist is not working properly, the
'Check Forward Safety system' warning
message will appear (turns off after a

certain time), and the

and

warning lights will illuminate on the clus

ter. In this case, have the vehicle
inspected by an authorized Kia dealer.

Forward Collision-Avoidance
Assist disabled

When the front windshield where the
front view camera is located, is covered
with foreign material, such as snow or
rain, it can reduce the detecting perfor

mance and temporarily limit or disable
Forward Collision-Avoidance Assist.

If this occurs, the 'Forward Safety system
disabled. Camera obscured' warning
message will appear (turns off after a

certain time), and the

and

warning lights will illuminate on the clus

ter.

Forward Collision-Avoidance Assist will
operate properly when snow, rain or for

eign matter is removed. Always keep it
clean.

If Forward Collision-Avoidance Assist
does not operate properly after obstruc

tion (snow, rain, or foreign material) is
removed, have the vehicle inspected by
an authorized Kia dealer.

W ARNING

• Even though the warning message or

warning light does not appear on the
cluster, Forward Collision-Avoidance
Assist may not properly operate.

OMQ4050074L

OMQ4050073L

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

• Forward Collision-Avoidance Assist

may not properly operate in an area
(for example, open terrain), where any
objects are not detected after turning
ON the engine.

Limitations of Forward Collision-
Avoidance Assist

Forward Collision-Avoidance Assist may
not operate properly or it may operate
unexpectedly under the following cir

cumstances:
• The detecting sensor or the surround

ings are contaminated or damaged

• The temperature around the front view

camera is abnormally high or low due.

• The camera lens is contaminated due

to tinted, filmed or coated windshield,
damaged glass, or sticky foreign
material (sticker, bug, etc.) on the
glass

• Moisture is not removed or frozen on

the windshield

• Washer fluid is continuously sprayed,

or the wiper is on

• Driving in heavy rain or snow, or in

thick fog

• The field of view of the front view

camera is obstructed by sun glare

• The camera is affected by reflected

light or glare, including light reflected
off the road

• The camera is affected by light

reflected from an object on the dash

board

• The surrounding is very bright
• The surrounding is very dark, such as

in a tunnel, etc.

• The brightness changes suddenly, for

example when entering or exiting a
tunnel

• The brightness outside is low, and the

headlamps are not on or are not bright

• Driving through steam, smoke or

shadow

• Only part of the vehicle, pedestrian is

detected

• The vehicle in front is a bus, heavy

truck, truck with an unusually shaped
cargo, trailer, etc.

• The vehicle in front has no tail lights,

tail lights are located unusually, etc.

• Your vehicle is being towed
• The brightness outside is low, and the

tail lamps are not on or are not bright

• The rear of the front vehicle is small or

the vehicle does not look normal, such
as when the vehicle is tilted, over

turned, or the side of the vehicle is vis

ible, etc.

• The front vehicle's ground clearance

is low or high

• A vehicle or pedestrian suddenly cuts

in front

• The vehicle in front is detected late

僅

The vehicle in front is suddenly
blocked by an obstacle

• The vehicle in front suddenly changes

lanes or suddenly reduces speed

• The vehicle in front is bent out of

shape

• The front vehicle's speed is fast or

slow

• The vehicle in front steers in the

opposite direction of your vehicle to
avoid a collision

• With a vehicle in front, your vehicle

changes lanes at low speed

• The vehicle in front is covered with

snow

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

• You are departing or returning to the

lane

• You are driving unstably
• You are on a roundabout and the

vehicle in front is not detected

• You are continuously driving in a cir

cle

• The vehicle in front has an unusual

shape

• The vehicle in front is driving uphill or

downhill.

• The pedestrian is not fully detected, for

example, if the pedestrian is lean

ing

over or is not fully walking upright

• The pedestrian is wearing clothing or

equipment that makes it difficult to
detect

The following images illustrate the

images that the sensor recognizes as a

vehicle and a pedestrian

• The pedestrian in front is moving very

quickly

• The pedestrian in front is short or is

posing a low posture

• The pedestrian in front has impaired

mobility

• The pedestrian in front is moving

intersected with the driving direction

• There is a group of pedestrians or a

large crowd in front

• The pedestrian is wearing clothing

that easily blends into the back

ground, making it difficult to detect

• The pedestrian is difficult to distin

guish from similarly shaped objects in
the backgrounds

• You encounter a pedestrian, traffic

signs, structures, etc. near an inter

section

• Driving in a parking lot
• Driving through a tollgate
• Driving through a, construction area

僅

Driving on, unpaved, partially paved,
and uneven roads

• Driving over speed bumps
• Driving on an inclined or curved road

that limits the

sensors’ range

• Driving through a roadside with trees

or streetlights

• Driving on rough roads that cause

excessive vehicle vibrations that inter

fere with the sensors

• Your vehicle height is abnormally low

or high due to heavy loads, abnormal
tire pressure, etc.

• Driving on a narrow road with nearby

trees, overgrown grass

• There is interference by extraordi

nary electromagnetic waves, such as
driving in an area with strong radio
waves or electrical noise

OJA040544

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

W ARNING

• Driving on a curved road

Forward Collision-Avoidance Assist
may not detect other vehicle, pedes

trian in front of you when driving on
curved roads adversely affecting the
performance of the sensors. This may
result in no warning or no braking
assist when necessary.

When driving on a curve, you must
maintain a safe braking distance, and
if necessary, steer the vehicle and
depress the brake pedal to reduce
your driving speed in order to main

tain a safe distance.

Forward Collision-Avoidance Assist
may detect a vehicle or pedestrian in
the next lane or outside the lane when
driving on a curved road.

If this occurs, Forward Collision-Avoid

ance Assist may unnecessarily warn
the driver and control the brake or
steering wheel. Always check the traf

fic conditions around the vehicle.

OSP2N052267

OSP2N052268

OCD059191

OSP2N052269

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

• Driving on an inclined road

Forward Collision-Avoidance Assist
may not detect other vehicles, pedes

trians in front of you while driving uphill
or downhill adversely affecting the
performance of the sensors.

This may result in unnecessary warn

ing, braking assist or no warning or no
braking assist.

Also, vehicle speed may rapidly
decrease when a vehicle or pedestrian
ahead is suddenly detected.

Always have your eyes on the road
while driving uphill or downhill and if
necessary, steer your vehicle and
depress the brake pedal to reduce
your driving speed in order to main

tain a safe distance.

• Changing lanes

: Your vehicle

: Lane changing vehicle

When a vehicle [B] moves into your
lane from an adjacent lane, it cannot
be detected by the sensor until it is in
the sensor's detection range. Forward
Collision-Avoidance Assist may not
immediately detect the vehicle when
the vehicle changes lanes abruptly.
You must maintain a safe braking dis

tance, and if necessary, steer your
vehicle and depress the brake pedal to
reduce your driving speed in order to
maintain a safe distance.

OSP2N052270

OSP2N052271

OHM051518

Driving assistance system

Forward Collision

–Avoidance Assist (FCA) (Front view camera

only)

: Your vehicle

: Lane changing

vehicle, [C]: Same lane

vehicle

When a vehicle [B] in front of you
merges out of the lane, Forward Colli

sion-Avoidance Assist may not imme

diately detect the vehicle [C] that is
now in front of you. In this case, a safe
braking distance, and if necessary,
steer your vehicle and depress the
brake pedal to reduce your driving
speed in order to maintain a safe dis

tance.

• Detecting vehicle

If the vehicle in front of you has cargo
that extends rearward from the cab,

or when the vehicle in front of you has
higher ground clearance, additional
special attention is required. Forward
Collision-Avoidance Assist may not be
able to detect the cargo extending
from the vehicle. In these instances,
you must maintain a safe braking dis

tance from the rearmost object, and if
necessary, steer your vehicle and
depress the brake pedal to reduce
your driving speed in order to main

tain distance.

W ARNING

• When you are towing a trailer or

another vehicle, we recommend that
Forward Collision-Avoidance Assist is
turned off due to safety reasons.

• Forward Collision-Avoidance Assist

may operate if objects that are similar
in shape or characteristics to vehicles
and pedestrians are detected.

• Forward Collision-Avoidance Assist

does not operate on bicycles, motor

cycles, or smaller wheeled objects,
such as luggage bags, shopping
carts, or strollers that are dragged by a
pedestrian.

• Forward Collision-Avoidance Assist

may not operate properly if interfered
with by strong electromagnetic
waves.

• Forward Collision-Avoidance Assist

may not operate for approximately 15
seconds after the vehicle is started, or
the front view camera is initialized.

OHM051519

OBDM052364N

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

Forward Collision-Avoidance
Assist (FCA) (Sensor fusion) (if
equipped)

Forward Collision-Avoidance Assist is
designed to help detect and monitor the
vehicle ahead or help detect a pedes

trian or cyclist in the roadway and warn
the driver that a collision is imminent with
a warning message, audible warn

ing

and apply emergency braking.

Detecting sensor

[1]: Front view camera, [2]: Front radar

Refer to the picture above for the
detailed location of the detecting sen

sors.

CAUTION

Take the following precautions to main

tain optimal performance of the detect

ing sensor:
• Never disassemble the detecting sen

sor or sensor assembly, or cause any
damage to it.

• If the detecting sensor has been

replaced or repaired, have your vehi

cle inspected by an authorized Kia
dealer.

• Never install any accessories or stick

ers on the front windshield, or tint the
front windshield.

• Pay extreme caution to keep the front

view camera dry.

• Never place any reflective objects (for

example, white paper, mirror) over the
dashboard.

• Do not apply license plate frame or

objects, such as a bumper sticker, film
or a bumper guard, near the front
radar cover.

• Always keep the front radar and cover

clean and free of dirt and debris. Use
only a soft cloth to wash the vehicle.

OBDM052362N

OBDM052015N

OBDM052014N

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

Do not spray pressurized water directly
on the sensor or sensor cover.

• If the radar or around the radar has

been damaged or impacted in any
way, Forward Collision-Avoidance
Assist may not properly operate even
though a warning message does not
appear on the cluster. In this case,
have your vehicle inspected by an
authorized Kia dealer.

• The genuine Kia front radar sensor

covers are parts with quality and per

formance ensured. If arbitrarily apply

ing paint on or changing the cover,
Forward Collision-Avoidance Assist
may not function properly. Use only Kia
Genuine Parts or those of an
equivalent standard with proven qual

ity and performance to repair or
replace the radar sensor covers.

Forward Collision-Avoidance
Assist setting

Forward Safety

With the ignition switch or ENGINE
START/STOP button in the ON
position, select 'Driver Assistance

→

Forward Safety' from the 'User Settings
(LCD dis

play) or Setup

→ Vehicle

(Infotainment

System screen)' menu to set whether to
use each function.
• If ‘Active Assist’ is selected, Forward

Collision-Avoidance Assist will warn
the driver with a warning message, an
audible warning depending on the
collision risk levels. Braking assist will
be applied depending on the collision
risk.

• If ‘Warning Only’ is selected, Forward

Collision-Avoidance Assist will warn
the driver with a warning message, an
audible warning depending on the
collision risk levels. Braking will not be
assisted. The driver must apply the
brake pedal if necessary.

• If ‘Off’ is selected, Forward Collision-

Avoidance Assist will be off. The

warning light will illuminate on the
cluster.

The driver can monitor Forward Colli

sion-Avoidance Assist On/Off status

from the settings menu. If the

warning light remains on when Forward
Collision-Avoidance Assist is on, have
the vehicle inspected by an authorized
Kia dealer.

W ARNING

• When the engine is restarted, Forward

Collision-Avoidance Assist will always
turn on.

• If 'Off' is selected from the settings

menu, Forward Collision-Avoidance
Assist will not operate so the driver
should always be aware of the sur

roundings and drive safely.

CAUTION

If 'Warning Only' is selected, braking is
not assisted.

OMQ4AH050344

With the ignition switch or ENGINE
START/STOP button in the ON position,
select 'Driver Assistance

→ Warning Vol

ume' from the 'User Settings (LCD dis

play) or Setup

→ Vehicle (Infotainment

System screen)' menu to change the
Warning Volume to 'High', 'Medium' or
'Low' for Forward Collision- Avoidance
Assist.

If you change the Warning Volume, the

Warning Volume of other Driver Assis

tance systems may change.

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

NOTICE

Forward Collision-Avoidance Assist will
turn off when ESC is turned off by press

ing and holding the ESC OFF button and

the

warning light will illuminate.

Warning Timing

With the ignition switch or ENGINE
START/STOP button in the ON position,
select 'Driver Assistance

→ Warning

Timing' from the 'User Settings (LCD dis

play) or Setup

→ Vehicle (Infotainment

System screen)' menu to change the ini

tial warning activation time for Forward
Collision-Avoidance Assist.

When the vehicle is first delivered, Warn

ing Timing is set to

‘Normal’. If you

change the Warning Timing, the Warn

ing Timing of other Driver Assistance
systems may change.

Warning Volume

CAUTION

• The setting of the Warning Timing

and Warning Volume applies to all
functions of Forward Collision-Avoid

ance Assist.

• Even though ‘Normal’ is selected for

Warning Timing, if the front vehicle
suddenly stops, the warning may
seem late.

• Select ‘Late’ for Warning Timing when

traffic is light and when driving speed
is slow.

OMQ4AH050334

OBD041619L

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

NOTICE

If the engine is restarted, Warning Tim

ing and Warning Volume will maintain
the last setting.

Forward Collision-Avoidance
Assist operation

Warning and control

The basic function for Forward Collision-
Avoidance Assist is to warn and help
control the vehicle depending on the col

lision risk level:

‘Collision Warning’,

‘Emergency Braking’ and ‘Stopping vehi

cle and ending brake

control’.

Collision Warning

• To warn the driver of a collision, the

‘Collision Warning’ warning message
will appear on the cluster, an audible
warning will sound.

• If a vehicle is detected in front, the

function will operate when your vehi

cle speed is between approximately
6~112 mph (10~180 km/h).

• If a pedestrian or cyclist is detected in

front, the function will operate when
your vehicle speed is between
approximately 6~53 mph (10~85 km/
h).

• If ‘Active Assist’ is selected, braking

may be assisted.

Emergency Braking

• To warn the driver that emergency

braking will be assisted, the

‘Emer

gency

Braking’ warning message will

appear on the cluster, an audible
warning will sound.

• If a vehicle is detected in front, the

function will operate when your vehi

cle speed is between approximately
6~53 mph (10~85 km/h).

• If a pedestrian or cyclist is detected in

front, the function will operate when
your vehicle speed is between
approximately 6~40 mph (10~65 km/
h).

• In emergency braking situation, brak

ing is assisted with strong braking
power by the function to help prevent
collision with the vehicle, pedestrian or
cyclist ahead.

OBD041231L

OBD041232L

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

Stopping vehicle and ending
brake control

• When the vehicle is stopped due to

emergency braking, the

‘Drive care

fully’ warning message will appear on
the cluster.

• For your safety, the driver should

depress the brake pedal immediately
and check the surroundings.

• Brake control will end after the vehicle

is stopped by emergency braking for
approximately 2 seconds.

W ARNING

• For your safety, change the settings

after parking the vehicle at a safe
location.

• With ‘Active Assist’ or ‘Warning Only’

selected, when ESC is turned off by
pressing and holding the ESC OFF
button, Forward Collision-Avoidance
Assist will turn off automatically. In this
case, Forward Collision-Avoid

ance

Assist cannot be set from the settings
menu and the warning light will
illuminate on the cluster which is
normal. If ESC is turned on by press

ing the ESC OFF button, Forward
Col

lision-Avoidance Assist will

maintain the last setting.

• Forward Collision-Avoidance Assist

does not operate in all situations or
cannot avoid all collisions.

• The driver should hold the responsi

bility to control the vehicle. Do not
solely depend on Forward Collision-
Avoidance Assist. Rather, maintain a
safe braking distance, and if neces

sary, depress the brake pedal to
reduce driving speed or to stop the
vehicle.

• Never deliberately operate Forward

Collision-Avoidance Assist on people,
objects, etc. It may cause serious
injury or death.

• Forward Collision-Avoidance Assist

may not operate if the driver
depresses the brake pedal to avoid
collision.

• Depending on the road and driving

conditions, Forward Collision-Avoid

ance Assist may warn the driver late
or may not warn the driver.

• During Forward Collision-Avoidance

Assist operation, the vehicle may stop
suddenly injuring passengers and
shifting loose objects. Always have the
seat belt on and keep loose objects
secured.

• If any other function’s warning mes

sage is displayed or audible warning
is generated, Forward Collision-Avoid

ance Assist warning message may not
be displayed and audible warning
may not be generated.

• You may not hear the warning sound

of Forward Collision-Avoidance Assist
if the surrounding is noisy.

• Forward Collision-Avoidance Assist

may turn off or may not operate prop

erly or may operate unnecessarily

OBD041233L

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

depending on the road conditions and
the surroundings.

W ARNING

• Even if there is a problem with For

ward Collision-Avoidance Assist, the
vehicle’s basic braking performance
will operate properly.

• During emergency braking, braking

control by Forward Collision-Avoid

ance Assist will automatically cancel
when the driver excessively depresses
the accelerator pedal or sharply steers
the vehicle.

W ARNING

• Depending on the condition of the

vehicle, pedestrian and cyclist in front
and the surroundings, the speed
range to operate Forward Collision-
Avoidance Assist may reduce. The
function may only warn the driver, or
the function may not operate.

• It operates only under certain condi

tions by judging the danger according
to a condition of the oncoming vehi

cle, driving direction, speed and the
surrounding environment.

NOTICE

When a collision is imminent, the For

ward Collision-Avoidance Assist may
assist the driver with braking if the driver
fails to brake enough.

Forward Collision-Avoidance Assist
malfunction and limitations

Forward Collision-Avoidance
Assist malfunction

When Forward Collision-Avoidance
Assist is not working properly, the
‘Check Forward Safety system’ warning
message will appear (turns off after a

certain time), and the

and

warning lights will illuminate on the clus

ter. In this case, have the vehicle
inspected by an authorized Kia dealer.

Forward Collision-Avoidance
Assist disabled

OMQ4050074L

OMQ4050073L

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

When the front windshield where the front
view camera is located, front radar cover
or sensor is covered with foreign material
such as snow or rain, it can reduce the
detecting performance and temporarily
limit or disable Forward Col

lision-

Avoidance Assist. If this occurs the
‘Forward Safety system disabled. Radar
blocked’ warning message will appear
(turns off after a certain time), and the

and

warning lights will illumi

nate on the cluster.

Forward Collision-Avoidance Assist will
operate properly when snow, rain or for

eign matter is removed. If Forward Colli

sion-Avoidance Assist does not operate
properly after it is removed, have the
vehicle inspected by an authorized Kia
dealer.

W ARNING

• Even though the warning message or

warning light does not appear on the
cluster, Forward Collision-Avoidance
Assist may not properly operate.

• Forward Collision-Avoidance Assist

may not properly operate in an area
(for example, open terrain), where any
objects are not detected after turning
ON the engine.

Limitations of Forward Collision-
Avoidance Assist

Forward Collision-Avoidance Assist may
not operate properly or it may operate
unexpectedly under the following cir

cumstances:
• The detecting sensor or the surround

ings are contaminated or damaged

• The temperature around the front view

camera is high or low due to the
external environment

• The camera lens is contaminated due

to tinted, filmed or coated windshield,
damaged glass, or sticky foreign mat

ters (sticker, bug, etc.) on the glass

• Moisture is not removed or frozen on

the windshield

• Washer fluid is continuously sprayed,

or the wiper is on

• Driving in heavy rain or snow, or thick

fog

• The field of view of the front view

camera is obstructed by sun glare

• Street light or light from an oncoming

traffic is reflected on the wet road sur

face, such as a puddle on the road

• An object is placed on the dashboard

僅

Your vehicle is being towed

• The surrounding is very bright
• The surrounding is very dark, such as

in a tunnel, etc.

• The brightness changes suddenly, for

example when entering or exiting a
tunnel

• The brightness outside is low, and the

headlamps are not on or are not bright

• Driving through steam, smoke or

shadow

• Only part of the vehicle, pedestrian or

cyclist is detected

OMQ4050079L

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

• The vehicle in front is a bus, heavy

truck, truck with an unusually shaped
cargo, trailer, etc.

• The vehicle in front has no tail lights,

tail lights are located unusually, etc.

• The brightness outside is low, and the

tail lamps are not on or are not bright

• The rear of the front vehicle is small or

the vehicle does not look normal, such
as when the vehicle is tilted, over

turned, or the side of the vehicle is vis

ible, etc.

• The front vehicle’s ground clearance

is low or high

• A vehicle, pedestrian or cyclist sud

denly cuts in front

• The bumper around the front radar is

impacted, damaged or the front radar
is out of position

• The temperature around the front

radar is high or low

• Driving through a tunnel or iron

bridge

• Driving in large areas where there are

few vehicles or structures (for exam

ple, desert, meadow, suburb, etc.)

• Driving near areas containing metal

substances, such as a construction
zone, railroad, etc.

• A material is near that reflects very

well on the front radar, such as a
guardrail, nearby vehicle, etc.

• The cyclist in front is on a bicycle

made of material that does not reflect
on the front radar

• The vehicle in front is detected late

僅

The vehicle in front is suddenly
blocked by an obstacle

• The vehicle in front suddenly changes

lane or suddenly reduces speed

• The vehicle in front is bent out of

shape

• The front vehicle’s speed is fast or

slow

• The vehicle in front steers in the

opposite direction of your vehicle to
avoid a collision

• With a vehicle in front, your vehicle

changes lane at low speed

• The vehicle in front is covered with

snow

• You are departing or returning to the

lane

• You are driving unstably
• You are on a roundabout and the

vehicle in front is not detected

• You are continuously driving in a cir

cle

• The vehicle in front has an unusual

shape

• The vehicle in front is driving uphill or

downhill

• The pedestrian or cyclist is not fully

detected, for example, if the pedes

trian is leaning over or is not fully
walking upright

• The pedestrian or cyclist is wearing

clothing or equipment that makes it
difficult to detect as a pedestrian or
cyclist

Following image shows the image the

sensor recognizes as vehicle, pedes

trian, and cyclist.

OADAS044

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

• The pedestrian or cyclist in front is

moving very quickly

• The pedestrian or cyclist in front is

short or is posing a low posture

• The pedestrian or cyclist in front has

impaired mobility

• The pedestrian or cyclist in front is

moving intersected with the driving
direction

• There is a group of pedestrians,

cyclists or a large crowd in front

• The pedestrian or cyclist is wearing

clothing that easily blends into the
background, making it difficult to
detect

• The pedestrian or cyclist is difficult to

distinguish from the similarly shaped
structure in the surroundings

• You are driving by a pedestrian,

cyclist traffic signs, structures, etc.
near the intersection

• Driving in a parking lot
• Driving through a tollgate, construc

tion area, unpaved road, partial paved
road, uneven road, speed bumps, etc.

• Driving on an incline road, curved

road, etc.

• Driving through a roadside with trees

or streetlights

• The adverse road conditions cause

excessive vehicle vibrations while
driving

• Your vehicle height is abnormally low

or high due to heavy loads, abnormal
tire pressure, etc.

• Driving through a narrow road where

trees or grass are overgrown

• There is interference by electromag

netic waves, such as driving in an area
with strong radio waves or electrical
noise

W ARNING

• Driving on a curved road

The front view camera or radar sensor
recognition function may not detect
the vehicle, pedestrian or cyclist trav

eling in front on a curved road.

OHM051527

OHM051528

OHM051529

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

Always pay attention to road and driv

ing conditions, and if necessary,
depress the brake pedal to reduce
your driving speed in order to main

tain a safe distance.

Forward Collision-Avoidance Assist
may detect a vehicle or pedestrian in
the next lane or outside the lane when

driving on a curved road. If this
occurs, the unnecessarily alarm the
driver and apply the brake. Always
check the traffic conditions around
the vehicle.

• Driving on an inclined road

Forward Collision-Avoidance Assist
may not detect a vehicle, pedestrian

OHM051530

OHM051531

OHM051532

OHM051533

OHM051534

OHM051535

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

or cyclist in front while driving uphill
or downhill and this may result in no
warning, or braking assist.

When the function suddenly recog

nizes the vehicle, pedestrian or cyclist
in front while passing over a slope,
you may experience sharp decelera

tion.

Always keep your eyes forward while
driving upward or downward on a
slope, and, if necessary, depress the
brake pedal to reduce your driving
speed in order to maintain distance.

• Changing lanes

: Your vehicle

: Lane changing vehicle

When a vehicle changes lanes in front
of you, Forward Collision-Avoidance
Assist may not immediately detect the
vehicle, especially if the vehicle
changes lanes abruptly. You must
maintain a safe braking distance, and
if necessary, depress the brake pedal
to reduce your driving speed in order
to maintain a safe distance.

: Your vehicle

: Lane changing vehicle

[C]: Same lane vehicle

When driving in stop-and-go traffic,
and a stopped vehicle in front of you
merges out of the lane, Forward Colli

sion-Avoidance Assist may not imme

diately detect the new vehicle that is
now in front of you. You must main

tain a safe braking distance, and if
necessary, depress the brake pedal to
reduce your driving speed in order to
maintain a safe distance.

• Detecting vehicle

When the vehicle in front has heavy
loading extended rearward, or when

OHM051518

OHM051519

OBDM052365N

Driving assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor fusion)

the vehicle in front has higher ground
clearance, it may induce a hazardous
situation. Always pay attention to road
and driving conditions, while driving
and, if necessary, depress the brake
pedal to reduce your driving speed in
order to maintain distance.

W ARNING

• When you are towing a trailer or

another vehicle, we recommend that
Forward Collision-Avoidance Assist is
turned off due to safety reasons.

• Forward Collision-Avoidance Assist

may operate if objects that are similar
in shape or characteristics to vehicles,
pedestrians or cyclists are detected.

• Forward Collision-Avoidance Assist

does not operate on bicycles, motor

cycles, or smaller wheeled objects,
such as luggage bags, shopping
carts, or strollers that are dragged by a
pedestrian or a cyclist.

• Forward Collision-Avoidance Assist

may not operate properly if interfered
with by strong electromagnetic
waves.

• Forward Collision-Avoidance Assist

may not operate for 15 seconds after
the vehicle is started, or the front view
camera is initialized.

This device complies with Part 15
of the FCC rules.

Operation is subject to the following
three conditions:

1. This device may not cause harmful

interference, and

2. This device must accept any interfer

ence received, including interference
that may cause undesired operation.

3. Changes or modifications not

expressly approved by the party
responsible for compliance could void
the user's authority to operate the
device.

Radio frequency radiation expo

sure information:

This equipment complies with FCC radi

ation exposure limits set forth for an
uncontrolled environment. This equip

ment should be installed and operated
with minimum distance of 8 in (20 cm)
between the radiator and your body.This
transmitter must not be collocated with or
operating in conjunction with any other
antenna or transmitter.

Driving assistance system

Lane Keeping Assist (LKA)

Lane Keeping Assist (LKA) (if
equipped)

Lane Keeping Assist is designed to help
detect the lane markers while driving
over a certain speed. Lane Keeping
Assist will warn the driver if the vehicle
leaves the lane without using the turn
signal, or will automatically assist the
driver’s steering to help prevent the
vehicle from departing the lane.

Detecting sensor

[1]: Front view camera
The front view camera is used as a
detecting sensor to detect lane mark

ings.

Refer to the picture above for the detailed
location of the detecting sensor.

CAUTION

For more details on the precautions of
the front view camera, refer to "Forward
Collision-Avoidance Assist (FCA) (Sen

sor fusion) (if equipped)" on page 6-15.

Lane Keeping Assist setting

Lane Safety

With the ignition switch or ENGINE
START/STOP button in the ON
position, select 'Driver Assistance

→

Lane Safety' from the 'User Settings
(LCD display) or Setup

→ Vehicle

(Infotainment System screen)' menu to
set whether to use each function.
• If ‘Assist’ is selected, Lane Keeping

Assist will automatically assist the
driver’s steering when lane departure
is detected to help prevent the vehicle
from moving out of its lane.

• If ‘Warning Only’ is selected, Lane

Keeping Assist will warn the driver
with an audible warning when lane
departure is detected. In this mode,
Lane Keeping Assist will not assist
with steering the vehicle.

• If ‘Off’ is selected, Lane Keeping Assist

will turn off. The indicator light

(

) will turn off on the cluster.

OSP2N052278

OBDM052015N

OBD041251L

Driving assistance system

Lane Keeping Assist (LKA)

W ARNING

• If ‘Warning Only’ is selected, steering

is not assisted.

• Lane Keeping Assist does not control

the steering wheel when the vehicle is
driven in the middle of the lane.

• The driver should always be aware of

the surroundings and steer the vehi

cle if

‘Off’ is selected.

Turning Lane Keeping Assist On/
Off

With the ignition switch or ENGINE
START/STOP button in the ON
position, press and hold the Lane
Driving Assist

button (

) located on the steering

wheel to turn off Lane Keeping Assist.
Press and hold the button again to turn
on the function.

The indicator (

) in the cluster

display will initially illuminate gray. If you
press and hold the Lane Driving Assist
button located on the steering wheel,
Lane Keeping Assist will be turned off
and the indicator on the cluster display
will go off.

INFORMATION

If the engine is restarted, Lane Keeping
Assist will maintain the last setting.

NOTICE

When Lane Keeping Assist is turned off
with the Lane Driving Assist button, Lane
Safety settings will turn off.

Warning Volume

With the ignition switch or ENGINE
START/STOP button in the ON position,
select 'Driver Assistance

→ Warning Vol

ume' from the 'User Settings (LCD dis

play) or Setup

→ Vehicle (Infotainment

System screen)' menu to change the
Warning Volume to 'High', 'Medium' or
'Low' for Lane Keeping Assist.

If you change the Warning Volume, the
Warning Volume of other Driver Assis

tance systems may be changed.

Lane Keeping Assist operation

Warning and control

Lane Keeping Assist will warn and con

trol the vehicle with Lane Departure
Warning and Lane Keeping Assist.

OBD051366

OBD041619L

Driving assistance system

Lane Keeping Assist (LKA)

Lane Departure Warning

Left

Right

• To warn the driver that the vehicle is

departing from the projected lane in
front, the green (

) indicator

light will blink on the cluster, the lane
line will blink on the cluster depending
on which direction the vehicle is veer

ing, and an audible warning will
sound.

• Lane Keeping Assist will operate when

your vehicle speed is between
approximately 40~120 mph (60~200
km/h).

Lane Keeping Assist

• To warn the driver that the vehicle is

departing from the projected lane in
front, the green (

)indicator

light will blink on the cluster, and the
steering wheel will make adjustments
to keep vehicle inside the lane.

• Lane Keeping Assist will operate when

your vehicle speed is between
approximately 40~120 mph (60~200
km/h).

Hands-off warning

If the driver takes their hands off the
steering wheel for several seconds, the
‘Keep hands on steering wheel’ warning
message will appear on the cluster, and
an audible warning will sound in stages.

W ARNING

• The steering wheel may not be

assisted if the steering wheel is held
very tight or the steering wheel is
steered over a certain degree.

• Lane Keeping Assist does not operate

at all times. It is the responsibility of the
driver to safely steer the vehicle and to
maintain the vehicle in its lane.

• The hands–off warning message may

appear late depending on road condi

OBD041263

OBD041266

OBD041236L

Driving assistance system

Lane Keeping Assist (LKA)

tions. Always have your hands on the
steering wheel while driving.

• If the steering wheel is held very lightly,

the hands-off warning mes

sage may

appear because Lane Keep

ing Assist

may not recognize that the driver has
their hands on the steering wheel.

• If you attach objects to the steering

wheel, the hands-off warning may not
work properly.

NOTICE

• For more details on setting the func

tions in the infotainment system, refer
to "LCD display modes" on page 4-58.

• When lane markings are detected, the

lane lines on the cluster will change
from gray to the green (

) indi

cator light will illuminate if Lane Keep

ing Assist is operable.

Lane undetected

Lane detected

• Even though the steering is assisted

by Lane Keeping Assist, the driver
may control the steering wheel.

• The steering wheel may feel heavier

or lighter when the steering wheel is
assisted by Lane Keeping Assist than
when it is not.

Lane Keeping Assist malfunction
and limitations

Lane Keeping Assist malfunction

When Lane Keeping Assist is not work

ing properly, the

‘Check Lane Keeping

Assist

(LKA)

system’,

warning

message
will appear and the yellow (

) indi

cator light will illuminate on the cluster.
In this case, have the function inspected
by an authorized Kia dealer.

OBDM041267L

OBD041268

OMQ4050214L

Driving assistance system

Lane Keeping Assist (LKA)

Limitations of Lane Keeping
Assist

Lane Keeping Assist may not operate
properly or may operate unexpectedly
under the following circumstances:
• The lane is ill-defined or difficult to

detect because,

- The lane markings are covered with

rain, snow, dirt, oil, etc.

- The color of the lane marking is not

distinguishable from the road

- There are markings on the road

near the lane or the markings on
the road look similar to the lane
markings

- The lane marking is indistinct or

damaged

- The shadow is on the lane marking

by a median strip, trees, guardrail,
noise barriers, etc.

• There are more than two lane mark

ings on the road

• The lane number increases or

decreases, or the lane markings are
crossing

• The lane markings are complicated or

a structure substitutes for the lines,
such as a construction area

• There are road markings, such as zig

zag lanes, crosswalk markings and
road signs

• The lane suddenly disappears, such

as at the intersection

• The lane is very wide or narrow
• There is a road edge without a lane

僅

There is a boundary structure in the

roadway, such as a tollgate, sidewalk,
curb, etc.

• The distance to the front vehicle is

extremely short or the vehicle in front
is covering the lane marking

For more details on the limitations of the
front view camera, refer to "Forward Col

lision-Avoidance Assist (FCA) (Sensor
fusion) (if equipped)" on page 6-15.

W ARNING

Take the following precautions when
using Lane Keeping Assist:
• The driver should hold the responsi

bility to safely drive and control the
vehicle. Do not solely rely on Lane
Keeping Assist and drive dangerously.

• The operation of Lane Keeping Assist

can be cancelled or not work properly
depending on road conditions and
surroundings. Always be cautious
while driving.

• Refer to "Limitations of Lane Keeping

Assist" on page 6-31, if the lane is not
detected properly.

• When you are towing a trailer or

another vehicle, we recommend that
Lane Keeping Assist is turned off due
to safety reasons.

• If the vehicle is driven at high speed,

the steering wheel will not be con

trolled. The driver must always follow
the speed limit when using Lane
Keeping Assist.

• If any other function’s warning mes

sage is displayed or audible warning
is generated, Lane Keeping Assist
warning message may not be dis

played and audible warning may not
be generated.

• You may not hear the warning sound

of Lane Keeping Assist if the sur

rounding is noisy.

• If you attach objects to the steering

wheel, steering may not be assisted
properly.

• Lane Keeping Assist may not operate

for 15 seconds after the vehicle is

Kia Forte (2024 year). Manual in english - page 9
