FANUC Series 30i-MODEL B, 31i-MODEL B, 32i-MODEL B. MAINTENANCE MANUAL - page 15
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
PMC → CNC
Address
Bit number
7
6
5
4
3
2
1
0
Gn000
ED7#P
ED6#P
ED5#P
ED4#P
ED3#P
ED2#P
ED1#P
ED0#P
Gn001
ED15#P
ED14#P
ED13#P
ED12#P
ED11#P
ED10#P
ED9#P
ED8#P
Gn002
ESTB#P
EA6#P
EA5#P
EA4#P
EA3#P
EA2#P
EA1#P
EA0#P
Gn003
Gn004
MFIN3#P
MFIN2#P
FIN#P
Gn005
BFIN#P
AFL#P
TFIN#P
SFIN#P
MFIN#P
Gn006
SKIPP#P
OVC#P
*ABSM#P
SRN#P
Gn007
RLSOT#P
EXLM#P
*FLWU#P
RLSOT3#P
ST#P
STLK#P
RVS#P
Gn008
ERS#P
RRW#P
*SP#P
*ESP#P
*BSL#P
*CSL#P
*IT#P
Gn009
PN16#P
PN8#P
PN4#P
PN2#P
PN1#P
Gn010
*JV7#P
*JV6#P
*JV5#P
*JV4#P
*JV3#P
*JV2#P
*JV1#P
*JV0#P
Gn011
*JV15#P
*JV14#P
*JV13#P
*JV12#P
*JV11#P
*JV10#P
*JV9#P
*JV8#P
Gn012
*FV7#P
*FV6#P
*FV5#P
*FV4#P
*FV3#P
*FV2#P
*FV1#P
*FV0#P
Gn013
*AFV7#P
*AFV6#P
*AFV5#P
*AFV4#P
*AFV3#P
*AFV2#P
*AFV1#P
*AFV0#P
Gn014
ROV2#P
ROV1#P
Gn015
Gn016
F1D#P
Gn017
Gn018
HS2D#P
HS2C#P
HS2B#P
HS2A#P
HS1D#P
HS1C#P
HS1B#P
HS1A#P
Gn019
RT#P
MP4#P
MP2#P
MP1#P
HS3D#P
HS3C#P
HS3B#P
HS3A#P
Gn020
HS4D#P
HS4C#P
HS4B#P
HS4A#P
SVR08I#P
SVR07I#P
SVR06I#P
SVR05I#P
SVR04I#P
SVR03I#P
SVR02I#P
SVR01I#P
Gn021
SVSP#P
SVGN#P
DFSYC#P
SVR12I#P
SVR11I#P
SVR10I#P
SVR09I#P
Gn022
- 402 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Gn023
ALNGH#P
RGHTH#P
NOINPS#P
HREV#P
HNDLF#P
Gn024
EPN7#P
EPN6#P
EPN5#P
EPN4#P
EPN3#P
EPN2#P
EPN1#P
EPN0#P
Gn025
EPNS#P
EPN13#P
EPN12#P
EPN11#P
EPN10#P
EPN9#P
EPN8#P
Gn026
*SSTP4#SP
SWS4#P
PC4SLC#P
PC3SLC#P
Gn027
CON#P
*SSTP3#SP
*SSTP2#SP
*SSTP1#SP
SWS3#P
SWS2#P
SWS1#P
Gn028
PC2SLC#P
SPSTPA#SP
*SCPFA#SP
*SUCPFA#SP
GR2#SP
GR1#SP
Gn029
*SSTP#P
SOR#P
SAR#P
GR32#SP
GR31#SP
GR22#SP
GR21#SP
Gn030
SOV7#P
SOV6#P
SOV5#P
SOV4#P
SOV3#P
SOV2#P
SOV1#P
SOV0#P
Gn031
PKESS2#P
PKESS1#P
GR42#SP
GR41#SP
M3R#P
Gn032
R08I#SP
R07I#SP
R06I#SP
R05I#SP
R04I#SP
R03I#SP
R02I#SP
R01I#SP
Gn033
SIND#SP
SSIN#SP
SGN#SP
R12I#SP
R11I#SP
R10I#SP
R09I#SP
Gn034
R08I2#SP
R07I2#SP
R06I2#SP
R05I2#SP
R04I2#SP
R03I2#SP
R02I2#SP
R01I2#SP
Gn035
SIND2#SP
SSIN2#SP
SGN2#SP
R12I2#SP
R11I2#SP
R10I2#SP
R09I2#SP
Gn036
R08I3#SP
R07I3#SP
R06I3#SP
R05I3#SP
R04I3#SP
R03I3#SP
R02I3#SP
R01I3#SP
Gn037
SIND3#SP
SSIN3#SP
SGN3#SP
R12I3#SP
R11I3#SP
R10I3#SP
R09I3#SP
Gn038
SDPC#P
SPPHS#P
SPSYC#P
SBRT#P
*PLSST#P
*BECLP#P
*BEUCP#P
GOQSM #P
WOQSM #P
OFN5#P
OFN4#P
OFN3#P
OFN2#P
OFN1#P
OFN0#P
Gn039
GOQSM #P
WOQSM #P
OFN5#P
OFN4#P
OFN3#P
OFN2#P
OFN1#P
OFN0#P
WOSET#P
PRC#P
S2TLS#P
OFN9#P
OFN8#P
OFN7#P
OFN6#P
Gn040
OFN9#P
OFN8#P
OFN7#P
OFN6#P
Gn041
HS2ID#P
HS2IC#P
HS2IB#P
HS2IA#P
HS1ID#P
HS1IC#P
HS1IB#P
HS1IA#P
Gn042
DMMC#P
HS3ID#P
HS3IC#P
HS3IB#P
HS3IA#P
Gn043
ZRN#P
DNCI#P
MD4#P
MD2#P
MD1#P
Gn044
MLK#P
BDT1#P
Gn045
BDT9#P
BDT8#P
BDT7#P
BDT6#P
BDT5#P
BDT4#P
BDT3#P
BDT2#P
Gn046
DRN#P
KEY4
KEY3
KEY2
KEY1
SBK#P
KEYP
- 403 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Gn047
TL128#P
TL64#P
TL32#P
TL16#P
TL08#P
TL04#P
TL02#P
TL01#P
Gn048
TLRST#P
TLRSTI#P
TLSKP#P
LFCIV#P
TL512#P
TL256#P
Gn049
*TLV7#P
*TLV6#P
*TLV5#P
*TLV4#P
*TLV3#P
*TLV2#P
*TLV1#P
*TLV0#P
Gn050
*TLV9#P
*TLV8#P
Gn051
*CHLD#P
CHPST#P
*CHP8#P
*CHP4#P
*CHP2#P
*CHP1#P
Gn052
*CDZ#P
Gn053
SMZ#P
ROVLP#P
UINT#P
TMRON#P
Gn054
UI007#P
UI006#P
UI005#P
UI004#P
UI003#P
UI002#P
UI001#P
UI000#P
Gn055
UI015#P
UI014#P
UI013#P
UI012#P
UI011#P
UI010#P
UI009#P
UI008#P
Gn056
UI023#P
UI022#P
UI021#P
UI020#P
UI019#P
UI018#P
UI017#P
UI016#P
Gn057
UI031#P
UI030#P
UI029#P
UI028#P
UI027#P
UI026#P
UI025#P
UI024#P
Gn058
EXWT
EXSTP
EXRD
Gn059
NSYNCA#P
TRRTN#P
TRESC#P
*TSB#P
Gn060
RGTSP4#SP
RGTSP3#SP
RGTSP2#SP
RGTSP1#SP
SYSS#P
Gn061
RGTAP#P
Gn062
HEAD2
RTNT#P
Gn063
NMWT#P
NOZAGC#P
SLSPB#P
SLSPA#P
NOWT
HEAD
INFD#P
Gn064
ESRSYC#P
SLPCB#P
SLSPA#P
Gn065
HCSK4#P
HCSK3#P
HCSK2#P
HCSK1#P
HSRT#P
Gn066
EKSET
RTRCT#P
ENBKY
IGNVRY#P
MLTC#P
Gn067
HCREQ
HCABT
MCHK#P
MMOD#P
CGREN#P
MTL07#P
MTL06#P
MTL05#P
MTL04#P
MTL03#P
MTL02#P
MTL01#P
MTL00#P
Gn068
MTL15#P
MTL14#P
MTL13#P
MTL12#P
MTL11#P
MTL10#P
MTL09#P
MTL08#P
Gn069
Gn070
MRDYA#SP
ORCMA#SP
SFRA#SP
SRVA#SP
CTH1A#SP
CTH2A#SP
TLMHA#SP
TLMLA#SP
- 404 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Gn071
RCHA#SP
RSLA#SP
INTGA#SP
SOCNA#SP
MCFNA#SP
SPSLA#SP
*ESPA#SP
ARSTA#SP
Gn072
RCHHGA#SP
MFNHGA#SP
INCMDA#SP
OVRIDA#SP
DEFMDA#SP
NRROA#SP
ROTAA#SP
INDXA#SP
Gn073
MPOFA#SP
SLVA#SP
MORCMA#SP
Gn074
MRDYB#SP
ORCMB#SP
SFRB#SP
SRVB#SP
CTH1B#SP
CTH2B#SP
TLMHB#SP
TLMLB#SP
Gn075
RCHB#SP
RSLB#SP
INTGB#SP
SOCNB#SP
MCFNB#SP
SPSLB#SP
*ESPB#SP
ARSTB#SP
Gn076
RCHHGB#SP
MFNHGB#SP
INCMDB#SP
OVRIDB#SP
DEFMDB#SP
NRROB#SP
ROTAB#SP
INDXB#SP
Gn077
MPOFB#SP
SLVB#SP
MORCMB#SP
Gn078
SH07A#SP
SH06A#SP
SH05A#SP
SH04A#SP
SH03A#SP
SH02A#SP
SH01A#SP
SH00A#SP
Gn079
SH11A#SP
SH10A#SP
SH09A#SP
SH08A#SP
Gn080
SH07B#SP
SH06B#SP
SH05B#SP
SH04B#SP
SH03B#SP
SH02B#SP
SH01B#SP
SH00B#SP
Gn081
SH11B#SP
SH10B#SP
SH09B#SP
SH08B#SP
Gn082
EUI07#P
EUI06#P
EUI05#P
EUI04#P
EUI03#P
EUI02#P
EUI01#P
EUI00#P
Gn083
EUI15#P
EUI14#P
EUI13#P
EUI12#P
EUI11#P
EUI10#P
EUI09#P
EUI08#P
Gn084
Gn085
Gn086
-Ja#P
+Ja#P
-Jg#P
+Jg#P
Gn087
MP42#P
MP41#P
MP32#P
MP31#P
MP22#P
MP21#P
Gn088
HS4ID#P
HS4IC#P
HS4IB#P
HS4IA#P
Gn089
G2SLC#P
G2Y#P
G2Z#P
G2X#P
G2RVY#P
G2RVZ#P
G2RVX#P
Gn090
Gn091
Gn092
Gn093
Gn094
- 405 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Gn095
Gn096
HROV#P
*HROV6#P
*HROV5#P
*HROV4#P
*HROV3#P
*HROV2#P
*HROV1#P
*HROV0#P
Gn097
Gn098
EKC7
EKC6
EKC5
EKC4
EKC3
EKC2
EKC1
EKC0
Gn099
Gn100
+J8#SV
+J7#SV
+J6#SV
+J5#SV
+J4#SV
+J3#SV
+J2#SV
+J1#SV
Gn101
*+ED28#SV
*+ED27#SV
*+ED26#SV
*+ED25#SV
*+ED24#SV
*+ED23#SV
*+ED22#SV
*+ED21#SV
Gn102
-J8#SV
-J7#SV
-J6#SV
-J5#SV
-J4#SV
-J3#SV
-J2#SV
-J1#SV
Gn103
*-ED28#SV
*-ED27#SV
*-ED26#SV
*-ED25#SV
*-ED24#SV
*-ED23#SV
*-ED22#SV
*-ED21#SV
Gn104
+EXL8#SV
+EXL7#SV
+EXL6#SV
+EXL5#SV
+EXL4#SV
+EXL3#SV
+EXL2#SV
+EXL1#SV
Gn105
-EXL8#SV
-EXL7#SV
-EXL6#SV
-EXL5#SV
-EXL4#SV
-EXL3#SV
-EXL2#SV
-EXL1#SV
Gn106
MI8#SV
MI7#SV
MI6#SV
MI5#SV
MI4#SV
MI3#SV
MI2#SV
MI1#SV
Gn107
*+ED38#SV
*+ED37#SV
*+ED36#SV
*+ED35#SV
*+ED34#SV
*+ED33#SV
*+ED32#SV
*+ED31#SV
Gn108
MLK8#SV
MLK7#SV
MLK6#SV
MLK5#SV
MLK4#SV
MLK3#SV
MLK2#SV
MLK1#SV
Gn109
*-ED38#SV
*-ED37#SV
*-ED36#SV
*-ED35#SV
*-ED34#SV
*-ED33#SV
*-ED32#SV
*-ED31#SV
Gn110
+LM8#SV
+LM7#SV
+LM6#SV
+LM5#SV
+LM4#SV
+LM3#SV
+LM2#SV
+LM1#SV
Gn111
Gn112
-LM8#SV
-LM7#SV
-LM6#SV
-LM5#SV
-LM4#SV
-LM3#SV
-LM2#SV
-LM1#SV
Gn113
Gn114
*+L8#SV
*+L7#SV
*+L6#SV
*+L5#SV
*+L4#SV
*+L3#SV
*+L2#SV
*+L1#SV
Gn115
Gn116
*-L8#SV
*-L7#SV
*-L6#SV
*-L5#SV
*-L4#SV
*-L3#SV
*-L2#SV
*-L1#SV
Gn117
Gn118
*+ED8#SV
*+ED7#SV
*+ED6#SV
*+ED5#SV
*+ED4#SV
*+ED3#SV
*+ED2#SV
*+ED1#SV
- 406 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Gn119
Gn120
*-ED8#SV
*-ED7#SV
*-ED6#SV
*-ED5#SV
*-ED4#SV
*-ED3#SV
*-ED2#SV
*-ED1#SV
Gn121
Gn122
PK8#SV
PK7#SV
PK6#SV
PK5#SV
PK4#SV
PK3#SV
PK2#SV
PK1#SV
PKESS2#P
PKESS1#P
Gn123
Gn124
DTCH8#SV
DTCH7#SV
DTCH6#SV
DTCH5#SV
DTCH4#SV
DTCH3#SV
DTCH2#SV
DTCH1#SV
Gn125
IUDD8#SV
IUDD7#SV
IUDD6#SV
IUDD5#SV
IUDD4#SV
IUDD3#SV
IUDD2#SV
IUDD1#SV
Gn126
SVF8#SV
SVF7#SV
SVF6#SV
SVF5#SV
SVF4#SV
SVF3#SV
SVF2#SV
SVF1#SV
Gn127
Gn128
MIX8#SV
MIX7#SV
MIX6#SV
MIX5#SV
MIX4#SV
MIX3#SV
MIX2#SV
MIX1#SV
Gn129
Gn130
*IT8#SV
*IT7#SV
*IT6#SV
*IT5#SV
*IT4#SV
*IT3#SV
*IT2#SV
*IT1#SV
Gn131
Gn132
+MIT2#P
+MIT1#P
+MIT8#P
+MIT7#P
+MIT6#P
+MIT5#P
+MIT4#P
+MIT3#P
Gn133
Gn134
-MIT2#P
-MIT1#P
-MIT8#P
-MIT7#P
-MIT6#P
-MIT5#P
-MIT4#P
-MIT3#P
Gn135
Gn136
EAX8#SV
EAX7#SV
EAX6#SV
EAX5#SV
EAX4#SV
EAX3#SV
EAX2#SV
EAX1#SV
Gn137
Gn138
SYNC8#SV
SYNC7#SV
SYNC6#SV
SYNC5#SV
SYNC4#SV
SYNC3#SV
SYNC2#SV
SYNC1#SV
Gn139
Gn140
SYNCJ8#SV
SYNCJ7#SV
SYNCJ6#SV
SYNCJ5#SV
SYNCJ4#SV
SYNCJ3#SV
SYNCJ2#SV
SYNCJ1#SV
Gn141
Gn142
EBUFA#PX
ECLRA#PX
ESTPA#PX
ESOFA#PX
ESBKA#PX
EMBUFA#PX
ELCKZA#PX
EFINA#PX
- 407 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Gn143
EMSBKA#PX
EC6A#PX
EC5A#PX
EC4A#PX
EC3A#PX
EC2A#PX
EC1A#PX
EC0A#PX
Gn144
EIF7A#PX
EIF6A#PX
EIF5A#PX
EIF4A#PX
EIF3A#PX
EIF2A#PX
EIF1A#PX
EIF0A#PX
Gn145
EIF15A#PX
EIF14A#PX
EIF13A#PX
EIF12A#PX
EIF11A#PX
EIF10A#PX
EIF9A#PX
EIF8A#PX
Gn146
EID7A#PX
EID6A#PX
EID5A#PX
EID4A#PX
EID3A#PX
EID2A#PX
EID1A#PX
EID0A#PX
Gn147
EID15A#PX
EID14A#PX
EID13A#PX
EID12A#PX
EID11A#PX
EID10A#PX
EID9A#PX
EID8A#PX
Gn148
EID23A#PX
EID22A#PX
EID21A#PX
EID20A#PX
EID19A#PX
EID18A#PX
EID17A#PX
EID16A#PX
Gn149
EID31A#PX
EID30A#PX
EID29A#PX
EID28A#PX
EID27A#PX
EID26A#PX
EID25A#PX
EID24A#PX
Gn150
EDRN#P
ERT#P
EOVC#P
EROV2#P
EROV1#P
#P
*EFOV7
*EFOV6#P
*EFOV5#P
*EFOV4#P
*EFOV3#P
*EFOV2#P
*EFOV1#P
*EFOV0#P
Gn151
*EROV7#P
*EROV6#P
*EROV5#P
*EROV4#P
*EROV3#P
*EROV2#P
*EROV1#P
*EROV0#P
Gn152
Gn153
Gn154
EBUFB#PX
ECLRB#PX
ESTPB#PX
ESOFB#PX
ESBKB#PX
EMBUFB#PX
ELCKZB#PX
EFINB#PX
Gn155
EMSBKB#PX
EC6B#PX
EC5B#PX
EC4B#PX
EC3B#PX
EC2B#PX
EC1B#PX
EC0B#PX
Gn156
EIF7B#PX
EIF6B#PX
EIF5B#PX
EIF4B#PX
EIF3B#PX
EIF2B#PX
EIF1B#PX
EIF0B#PX
Gn157
EIF15B#PX
EIF14B#PX
EIF13B#PX
EIF12B#PX
EIF11B#PX
EIF10B#PX
EIF9B#PX
EIF8B#PX
Gn158
EID7B#PX
EID6B#PX
EID5B#PX
EID4B#PX
EID3B#PX
EID2B#PX
EID1B#PX
EID0B#PX
Gn159
EID15B#PX
EID14B#PX
EID13B#PX
EID12B#PX
EID11B#PX
EID10B#PX
EID9B#PX
EID8B#PX
Gn160
EID23B#PX
EID22B#PX
EID21B#PX
EID20B#PX
EID19B#PX
EID18B#PX
EID17B#PX
EID16B#PX
Gn161
EID31B#PX
EID30B#PX
EID29B#PX
EID28B#PX
EID27B#PX
EID26B#PX
EID25B#PX
EID24B#PX
Gn162
EOVCB#PX
#PX
*EFOV7B
*EFOV6B#PX
*EFOV5B#PX
*EFOV4B#PX
*EFOV3B#PX
*EFOV2B#PX
*EFOV1B#PX
*EFOV0B#PX
Gn163
*EROV7B#PX
*EFOV6B#PX
*EROV5B#PX
*EROV4B#PX
*EROV3B#PX
*EROV2B#PX
*EROV1B#PX
*EROV0B#PX
Gn164
Gn165
Gn166
EBUFC#PX
ECLRC#PX
ESTPC#PX
ESOFC#PX
ESBKC#PX
EMBUFC#PX
ELCKZC#PX
EFINC#PX
- 408 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Gn167
EMSBKC#PX
EC6C#PX
EC5C#PX
EC4C#PX
EC3C#PX
EC2C#PX
EC1C#PX
EC0C#PX
Gn168
EIF7C#PX
EIF6C#PX
EIF5C#PX
EIF4C#PX
EIF3C#PX
EIF2C#PX
EIF1C#PX
EIF0C#PX
Gn169
EIF15C#PX
EIF14C#PX
EIF13C#PX
EIF12C#PX
EIF11C#PX
EIF10C#PX
EIF9C#PX
EIF8C#PX
Gn170
EID7C#PX
EID6C#PX
EID5C#PX
EID4C#PX
EID3C#PX
EID2C#PX
EID1C#PX
EID0C#PX
Gn171
EID15C#PX
EID14C#PX
EID13C#PX
EID12C#PX
EID11C#PX
EID10C#PX
EID9C#PX
EID8C#PX
Gn172
EID23C#PX
EID22C#PX
EID21C#PX
EID20C#PX
EID19C#PX
EID18C#PX
EID17C#PX
EID16C#PX
Gn173
EID31C#PX
EID30C#PX
EID29C#PX
EID28C#PX
EID27C#PX
EID26C#PX
EID25C#PX
EID24C#PX
Gn174
EOVCC#PX
#PX
*EFOV7C
*EFOV6C#PX
*EFOV5C#PX
*EFOV4C#PX
*EFOV3C#PX
*EFOV2C#PX
*EFOV1C#PX
*EFOV0C#PX
Gn175
*EROV7C#PX
*EROV6C#PX
*EROV5C#PX
*EROV4C#PX
*EROV3C#PX
*EROV2C#PX
*EROV1C#PX
*EROV0C#PX
Gn176
Gn177
Gn178
EBUFD#PX
ECLRD#PX
ESTPD#PX
ESOFD#PX
ESBKD#PX
EMBUFD#PX
ELCKZD#PX
EFIND#PX
Gn179
EMSBKD#PX
EC6D#PX
EC5D#PX
EC4D#PX
EC3D#PX
EC2D#PX
EC1D#PX
EC0D#PX
Gn180
EIF7D#PX
EIF6D#PX
EIF5D#PX
EIF4D#PX
EIF3D#PX
EIF2D#PX
EIF1D#PX
EIF0D#PX
Gn181
EIF15D#PX
EIF14D#PX
EIF13D#PX
EIF12D#PX
EIF11D#PX
EIF10D#PX
EIF9D#PX
EIF8D#PX
Gn182
EID7D#PX
EID6D#PX
EID5D#PX
EID4D#PX
EID3D#PX
EID2D#PX
EID1D#PX
EID0D#PX
Gn183
EID15D#PX
EID14D#PX
EID13D#PX
EID12D#PX
EID11D#PX
EID10D#PX
EID9D#PX
EID8D#PX
Gn184
EID23D#PX
EID22D#PX
EID21D#PX
EID20D#PX
EID19D#PX
EID18D#PX
EID17D#PX
EID16D#PX
Gn185
EID31D#PX
EID30D#PX
EID29D#PX
EID28D#PX
EID27D#PX
EID26D#PX
EID25D#PX
EID24D#PX
Gn186
EOVCD#PX
#PX
*EFOV7D
*EFOV6D#PX
*EFOV5D#PX
*EFOV4D#PX
*EFOV3D#PX
*EFOV2D#PX
*EFOV1D#PX
*EFOV0D#PX
Gn187
*EROV7D#PX
*EROV6D#PX
*EROV5D#PX
*EROV4D#PX
*EROV3D#PX
*EROV2D#PX
*EROV1D#PX
*EROV0D#PX
Gn188
Gn189
Gn190
OVLS8#SV
OVLS7#SV
OVLS6#SV
OVLS5#SV
OVLS4#SV
OVLS3#SV
OVLS2#SV
OVLS1#SV
- 409 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Gn191
Gn192
IGVRY8#SV
IGVRY7#SV
IGVRY6#SV
IGVRY5#SV
IGVRY4#SV
IGVRY3#SV
IGVRY2#SV
IGVRY1#SV
Gn193
HDSR#P
Gn194
Gn195
Gn196
*DEC8#SV
*DEC7#SV
*DEC6#SV
*DEC5#SV
*DEC4#SV
*DEC3#SV
*DEC2#SV
*DEC1#SV
Gn197
MTD
MTC
MTB
MTA
Gn198
Gn199
IOLBH2
IOLBH1
Gn200
EASIP8#SV
EASIP7#SV
EASIP6#SV
EASIP5#SV
EASIP4#SV
EASIP3#SV
EASIP2#SV
EASIP1#SV
Gn201
Gn202
NDCAL8#SV
NDCAL7#SV
NDCAL6#SV
NDCAL5#SV
NDCAL4#SV
NDCAL3#SV
NDCAL2#SV
NDCAL1#SV
Gn203
RWFL
AOFS2#P
AOFS1#P
CHGAO#P
ESTPR#P
Gn204
MRDYC#SP
ORCMC#SP
SFRC#SP
SRVC#SP
CTH1C#SP
CTH2C#SP
TLMHC#SP
TLMLC#SP
Gn205
RCHC#SP
RSLC#SP
INTGC#SP
SOCNC#SP
MCFNC#SP
SPSLC#SP
*ESPC#SP
ARSTC#SP
#S
OVRIDC
Gn206
RCHHGC#SP
MFNHGC#SP
INCMDC#SP
DEFMDC#SP
NRROC#SP
ROTAC#SP
INDXC#SP
P
Gn207
MPOFC#SP
SLVC#SP
MORCMC#SP
Gn208
SH07C#SP
SH06C#SP
SH05C#SP
SH04C#SP
SH03C#SP
SH02C#SP
SH01C#SP
SH00C#SP
Gn209
SH11C#SP
SH10C#SP
SH09C#SP
SH08C#SP
Gn210
ED23#P
ED22#P
ED21#P
ED20#P
ED19#P
ED18#P
ED17#P
ED16#P
Gn211
ED31#P
ED30#P
ED29#P
ED28#P
ED27#P
ED26#P
ED25#P
ED24#P
Gn212
Gn213
Gn214
- 410 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Gn215
Gn216
Gn217
Gn220
*CGROV7#P
*CGROV6#P
*CGROV5#P
*CGROV4#P
*CGROV3#P
*CGROV2#P
*CGROV1#P
*CGROV0#P
Gn251
LCBS
Gn263
Gn264
ESSYC4#SP
ESSYC3#SP
ESSYC2#SP
ESSYC1#SP
Gn265
PKESE4#SP
PKESE3#SP
PKESE2#SP
PKESE1#SP
Gn266
MRDYD#SP
ORCMD#SP
SFRD#SP
SRVD#SP
CTH1D#SP
CTH2D#SP
TLMHD#SP
TLMLD#SP
Gn267
RCHD#SP
RSLD#SP
INTGD#SP
SOCND#SP
MCFND#SP
SPSLD#SP
*ESPD#SP
ARSTD#SP
#S
OVRIDD
Gn268
RCHHGD#SP
MFNHGD#SP
INCMDD#SP
DEFMDD#SP
NRROD#SP
ROTAD#SP
INDXD#SP
P
MORC
Gn269
MPOFD#SP
SLVD#SP
MD#SP
Gn270
SH07D#SP
SH06D#SP
SH05D#SP
SH04D#SP
SH03D#SP
SH02D#SP
SH01D#SP
SH00D#SP
Gn271
SH11D#SP
SH10D#SP
SH09D#SP
SH08D#SP
Gn272
R08I4#SP
R07I4#SP
R06I4#SP
R05I4#SP
R04I4#SP
R03I4#SP
R02I4#SP
R01I4#SP
Gn273
SIND4#SP
SSIN4#SP
SGN4#SP
R12I4#SP
R11I4#SP
R10I4#SP
R09I4#SP
Gn274
CSFI4#SP
CSFI3#SP
CSFI2#SP
CSFI1#SP
CONS4#SP
CONS3#SP
CONS2#SP
CONS1#SP
Gn275
Gn276
UI107#P
UI106#P
UI105#P
UI104#P
UI103#P
UI102#P
UI101#P
UI100#P
Gn277
UI115#P
UI114#P
UI113#P
UI112#P
UI111#P
UI110#P
UI109#P
UI108#P
Gn278
UI123#P
UI122#P
UI121#P
UI120#P
UI119#P
UI118#P
UI117#P
UI116#P
Gn279
UI131#P
UI130#P
UI129#P
UI128#P
UI127#P
UI126#P
UI125#P
UI124#P
Gn280
UI207#P
UI206#P
UI205#P
UI204#P
UI203#P
UI202#P
UI201#P
UI200#P
Gn281
UI215#P
UI214#P
UI213#P
UI212#P
UI211#P
UI210#P
UI209#P
UI208#P
- 411 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Gn282
UI223#P
UI222#P
UI221#P
UI220#P
UI219#P
UI218#P
UI217#P
UI216#P
Gn283
UI231#P
UI230#P
UI229#P
UI228#P
UI227#P
UI226#P
UI225#P
UI224#P
Gn284
UI307#P
UI306#P
UI305#P
UI304#P
UI303#P
UI302#P
UI301#P
UI300#P
Gn285
UI315#P
UI314#P
UI313#P
UI312#P
UI311#P
UI310#P
UI309#P
UI308#P
Gn286
UI323#P
UI322#P
UI321#P
UI320#P
UI319#P
UI318#P
UI317#P
UI316#P
Gn287
UI331#P
UI330#P
UI329#P
UI328#P
UI327#P
UI326#P
UI325#P
UI324#P
Gn288
SPSYC4#SP
SPSYC3#SP
SPSYC2#SP
SPSYC1#SP
Gn289
SPPHS4#SP
SPPHS3#SP
SPPHS2#SP
SPPHS1#SP
Gn290
PGCK#P
Gn291
Gn292
ITCD
ITCD3
ITCD2
ITCD1
ITRC
Gn293
Gn294
Gn295
CNCKY
C2SEND
Gn296
DI8#SV
DI7#SV
DI6#SV
DI5#SV
DI4#SV
DI3#SV
DI2#SV
DI1#SV
Gn297
AOFS2#P
AOFS1#P
CHGAO#P
BCAN#P
Gn298
RNDH#P
TB_BASE#P
Gn299
Gn300
Gn301
Gn302
Gn303
Gn304
CSYCA#SP
Gn305
- 412 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Gn306
Gn307
Gn308
CSYCB#SP
Gn309
Gn310
Gn311
Gn312
CSYCC#SP
Gn313
Gn314
Gn315
Gn316
CSYCD#SP
Gn317
Gn318
Gn319
Gn320
Gn321
Gn322
Gn323
Gn324
Gn325
Gn326
Gn327
#P
#P
#P
#P
Gn328
TLRSTI4
#P
TLRSTI3
#P
TLRSTI2
TLRSTI1
TLRST4#P
TLRST3
TLRST2
#P
TLRST1
Gn329
TLNCT4#P
TLNCT3#P
TLNCT2#P
TLNCT1#P
TLSKP4#P
TLSKP3#P
TLSKP2#P
TLSKP1#P
- 413 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Gn330
TKEY5
TKEY4
TKEY3
TKEY2
TKEY1
TKEY0
Gn331
Gn332
Gn333
Gn334
Gn335
Gn336
Gn337
Gn338
Gn339
Gn340
Gn341
*+ED48#SV
*+ED47#SV
*+ED46#SV
*+ED45#SV
*+ED44#SV
*+ED43#SV
*+ED42#SV
*+ED41#SV
Gn342
*-ED48#SV
*-ED47#SV
*-ED46#SV
*-ED45#SV
*-ED44#SV
*-ED43#SV
*-ED42#SV
*-ED41#SV
Gn343
*+ED58#SV
*+ED57#SV
*+ED56#SV
*+ED55#SV
*+ED54#SV
*+ED53#SV
*+ED52#SV
*+ED51#SV
Gn344
*-ED58#SV
*-ED57#SV
*-ED56#SV
*-ED55#SV
*-ED54#SV
*-ED53#SV
*-ED52#SV
*-ED51#SV
Gn345
Gn346
Gn347
NOT3DM#P
HDN#P
Gn348
Gn349
Gn350
Gn351
Gn352
*FHRO7#P
*FHRO6#P
*FHRO5#P
*FHRO4#P
*FHRO3#P
*FHRO2#P
*FHRO1#P
*FHRO0#P
Gn353
FHROV#P
*FHRO9#P
*FHRO8#P
- 414 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Gn354
THD07#P
THD06#P
THD05#P
THD04#P
THD03#P
THD02#P
THD01#P
THD00#P
Gn355
THD15#P
THD14#P
THD13#P
THD12#P
THD11#P
THD10#P
THD09#P
THD08#P
Gn356
THSTB#P
THML#P
Gn357
Gn358
WPRST8
WPRST7
WPRST6
WPRST5
WPRST4
WPRST3
WPRST2
WPRST1
~
Gn375
SOV27
SOV26
SOV25
SOV24
SOV23
SOV22
SOV21
SOV20
Gn376
SOV37
SOV36
SOV35
SOV34
SOV33
SOV32
SOV31
SOV30
Gn377
SOV47
SOV46
SOV45
SOV44
SOV43
SOV42
SOV41
SOV40
Gn378
Gn379
HS5ID#P
HS5IC#P
HS5IB#P
HS5IA#P
HS5D#P
HS5C#P
HS5B#P
HS5A#P
Gn380
MP52#P
MP51#P
Gn381
Gn382
Gn383
Gn384
Gn385
Gn386
Gn387
Gn388
Gn389
Gn390
Gn391
Gn392
- 415 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Gn393
Gn394
Gn395
Gn396
Gn397
Gn398
Gn399
Gn400
*SUCPFD#SP
*SUCPFC#SP
*SUCPFB#SP
Gn401
*SCPFD#SP
*SCPFC#SP
*SCPFB#SP
Gn402
SPSTPD#SP
SPSTPC#SP
SPSTPB#SP
Gn403
SLPCD#P
SLPCC#P
SLSPD#P
SLSPC#P
Gn404
Gn405
ITF08#P
ITF07#P
ITF06#P
ITF05#P
ITF04#P
ITF03#P
ITF02#P
ITF01#P
Gn406
ITF10#P
ITF09#P
Gn407
ITCD6
ITCD5
ITCD4
Gn408
MDISL
HEAD4
HEAD3
STCHK#P
Gn409
Gn410
Gn411
HS4IE#P
HS3IE#P
HS2IE#P
HS1IE#P
HS4E#P
HS3E#S
HS2E#P
HS1E#P
Gn412
HS5IE#P
HS1E#P
~
Gn512
MCST8#P
MCST7#P
MCST6#P
MCST5#P
MCST4#P
MCST3#P
MCST2#P
MCST1#P
Gn513
MCST16#P
MCST15#P
MCST14#P
MCST13#P
MCST12#P
MCST11#P
MCST10#P
MCST9#P
- 416 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Gn514
MCFIN#P
Gn515
PPK8#SV
PPK7#SV
PPK6#SV
PPK5#SV
PPK4#SV
PPK3#SV
PPK2#SV
PPK1#SV
Gn516
SEMI8 #SV
SEMI7#SV
SEMI6#SV
SEMI5#SV
SEMI4#SV
SEMI3#SV
SEMI2#SV
SEMI1#SV
Gn517
GAE2#P
GAE1#P
GAE3#P
Gn518
TDISD
BOV#P
Gn519
TSE#P
TDICHG
TDID
PTREQ#P
Gn520
PTOV7
PTOV6
PTOV5
PTOV4
PTOV3
PTOV2
PTOV1
SRVON8
SRVON7
SRVON6
SRVON5
SRVON4
SRVON3
SRVON2
SRVON1
Gn521
Gn522
PTSK8#P
PTSK7#P
PTSK6#P
PTSK5#P
PTSK4#P
PTSK3#P
PTSK2#P
PTSK1#P
SVRVS8
SVRVS7
SVRVS6
SVRVS5
SVRVS4
SVRVS3
SVRVS2
SVRVS1
Gn523
Gn524
MT8N07#P
MT8N06#P
MT8N05#P
MT8N04#P
MT8N03#P
MT8N02#P
MT8N01#P
MT8N00#P
Gn525
MT8N15#P
MT8N14#P
MT8N13#P
MT8N12#P
MT8N11#P
MT8N10#P
MT8N09#P
MT8N08#P
Gn526
MT8N23#P
MT8N22#P
MT8N21#P
MT8N20#P
MT8N19#P
MT8N18#P
MT8N17#P
MT8N16#P
Gn527
MT8N31#P
MT8N30#P
MT8N29#P
MT8N28#P
MT8N27#P
MT8N26#P
MT8N25#P
MT8N24#P
Gn528
~
Gn530
EGBS8#SV
EGBS7#SV
EGBS6#SV
EGBS5#SV
EGBS4#SV
EGBS3#SV
EGBS2#SV
EGBS1#SV
Gn531
OVLN#P
HBTRN#P
MRVM#P
FWSTP#P
Gn532
Gn533
SSRS#P
SSR4#SP
SSR3#SP
SSR2#SP
SSR1#SP
Gn534
TDISAW
AXC4#P
AXC2#P
AXC1#P
Gn535
Gn536
SPSP#P
~
Gn544
MHLC5#P
MHLC4#P
MHLC3#P
MHLC2#P
MHLC1#P
- 417 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Gn545
MHUS5#P
MHUS4#P
MHUS3#P
MHUS2#P
MHUS1#P
Gn546
GQSMC#P
OFNC5#P
OFNC4#P
OFNC3#P
OFNC2#P
OFNC1#P
OFNC0#P
ONSC#P
Gn547
OFNC9#P
OFNC8#P
OFNC7#P
OFNC6#P
Gn548
*CL8#SV
*CL7#SV
*CL6#SV
*CL5#SV
*CL4#SV
*CL3#SV
*CL2#SV
*CL1#SV
Gn549
CONH4#SP
CONH3#SP
CONH2#SP
CONH1#SP
~
Gn767
- 418 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
CNC → PMC
Address
Bit number
7
6
5
4
3
2
1
0
Fn000
OP#P
SA#P
STL#P
SPL#P
RWD#P
Fn001
MA#P
TAP#P
ENB#SP
DEN#P
BAL#P
RST#P
AL#P
Fn002
MDRN#P
CUT#P
SRNMV#P
THRD#P
CSS#P
RPDO#P
INCH#P
#
MMEM
Fn003
MEDT#P
MRMT#P
MMDI#P
MJ#P
MH#P
MINC#P
P
Fn004
MREF#P
MAFL#P
MSBK#P
MABSM#P
MMLK#P
MBDT1#P
Fn005
MBDT9#P
MBDT8#P
MBDT7#P
MBDT6#P
MBDT5#P
MBDT4#P
MBDT3#P
MBDT2#P
Fn006
ERTVA#P
MDIRST#P
TPPRS
Fn007
BF#P
TF#P
SF#P
MF#P
Fn008
MF3#P
MF2#P
Fn009
DM00#P
DM01#P
DM02#P
DM30#P
Fn010
M07#P
M06#P
M05#P
M04#P
M03#P
M02#P
M01#P
M00#P
Fn011
M15#P
M14#P
M13#P
M12#P
M11#P
M10#P
M09#P
M08#P
Fn012
M23#P
M22#P
M21#P
M20#P
M19#P
M18#P
M17#P
M16#P
Fn013
M31#P
M30#P
M29#P
M28#P
M27#P
M26#P
M25#P
M24#P
Fn014
M207#P
M206#P
M205#P
M204#P
M203#P
M202#P
M201#P
M200#P
Fn015
M215#P
M214#P
M213#P
M212#P
M211#P
M210#P
M209#P
M208#P
Fn016
M307#P
M306#P
M305#P
M304#P
M303#P
M302#P
M301#P
M300#P
Fn017
M315#P
M314#P
M313#P
M312#P
M311#P
M310#P
M309#P
M308#P
Fn018
Fn019
Fn020
Fn021
Fn022
S07#P
S06#P
S05#P
S04#P
S03#P
S02#P
S01#P
S00#P
- 419 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Fn023
S15#P
S14#P
S13#P
S12#P
S11#P
S10#P
S09#P
S08#P
Fn024
S23#P
S22#P
S21#P
S20#P
S19#P
S18#P
S17#P
S16#P
Fn025
S31#P
S30#P
S29#P
S28#P
S27#P
S26#P
S25#P
S24#P
Fn026
T07#P
T06#P
T05#P
T04#P
T03#P
T02#P
T01#P
T00#P
Fn027
T15#P
T14#P
T13#P
T12#P
T11#P
T10#P
T09#P
T08#P
Fn028
T23#P
T22#P
T21#P
T20#P
T19#P
T18#P
T17#P
T16#P
Fn029
T31#P
T30#P
T29#P
T28#P
T27#P
T26#P
T25#P
T24#P
Fn030
B07#P
B06#P
B05#P
B04#P
B03#P
B02#P
B01#P
B00#P
Fn031
B15#P
B14#P
B13#P
B12#P
B11#P
B10#P
B09#P
B08#P
Fn032
B23#P
B22#P
B21#P
B20#P
B19#P
B18#P
B17#P
B16#P
Fn033
B31#P
B30#P
B29#P
B28#P
B27#P
B26#P
B25#P
B24#P
Fn034
SRSRDY#P
SRSP1R#SP
SRSP2R#SP
SRSP3R#SP
SRSP4R#SP
GR3O#P
GR2O#P
GR1O#P
Fn035
SPAL#P
Fn036
R08O#SP
R07O#SP
R06O#SP
R05O#SP
R04O#SP
R03O#SP
R02O#SP
R01O#SP
Fn037
R12O#SP
R11O#SP
R10O#SP
R09O#SP
Fn038
ENB3#SP
ENB2#SP
SUCLPA#SP
SCLPA#SP
Fn039
ENB4#SP
MSPOSA#SP
CHPCYL#P
CHPMD#P
Fn040
AR07#SP
AR06#SP
AR05#SP
AR04#SP
AR03#SP
AR02#SP
AR01#SP
AR00#SP
Fn041
AR15#SP
AR14#SP
AR13#SP
AR12#SP
AR11#SP
AR10#SP
AR09#SP
AR08#SP
Fn042
Fn043
SYCAL4#SP
SYCAL3#SP
SYCAL2#SP
SYCAL1#SP
Fn044
SYCAL#P
FSPPH#P
FSPSY#P
FSCSL#P
Fn045
ORARA#SP
TLMA#SP
LDT2A#SP
LDT1A#SP
SARA#SP
SDTA#SP
SSTA#SP
ALMA#SP
Fn046
MORA2A#SP
MORA1A#SP
PORA2A#SP
SLVSA#SP
RCFNA#SP
RCHPA#SP
CFINA#SP
CHIPA#SP
- 420 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Fn047
CSYFNA#SP
CS1DTA#SP
INCSTA#SP
PC1DEA#SP
Fn048
CSPENA#SP
Fn049
ORARB#SP
TLMB#SP
LDT2B#SP
LDT1B#SP
SARB#SP
SDTB#SP
SSTB#SP
ALMB#SP
Fn050
MORA2B#SP
MORA1B#SP
PORA2B#SP
SLVSB#SP
RCFNB#SP
RCHPB#SP
CFINB#SP
CHIPB#SP
Fn051
CSYFNB#SP
CS1DTB#SP
INCSTB#SP
PC1DEB#SP
Fn052
CSPENB#SP
Fn053
EKENB
RPALM#P
RPBSY#P
PRGDPL
INHKY
Fn054
UO007#P
UO006#P
UO005#P
UO004#P
UO003#P
UO002#P
UO001#P
UO000#P
Fn055
UO015#P
UO014#P
UO013#P
UO012#P
UO011#P
UO010#P
UO009#P
UO008#P
Fn056
UO107#P
UO106#P
UO105#P
UO104#P
UO103#P
UO102#P
UO101#P
UO100#P
Fn057
UO115#P
UO114#P
UO113#P
UO112#P
UO111#P
UO110#P
UO109#P
UO108#P
Fn058
UO123#P
UO122#P
UO121#P
UO120#P
UO119#P
UO118#P
UO117#P
UO116#P
Fn059
UO131#P
UO130#P
UO129#P
UO128#P
UO127#P
UO126#P
UO125#P
UO124#P
Fn060
ESCAN#SP
ESEND#P
EREND#P
MTLA#P
MTLANG#P
Fn061
HCEXE
HCAB2
BCLP#P
BUCLP#P
S2MES#P
S1MES#P
Fn062
PRTSF#P
D3ROT#P
HSRA#P
AICC#P
Fn063
PSYN#P
WATO#P
COSP2#P
COSP1#P
PSAR#P
PSE2#P
PSE1#P
TIALM#P
TICHK#P
Fn064
COSP#P
TLCHB#P
TLCHI#P
TLNW#P
TLCH#P
#
SYNMOD
Fn065
RTRCTF#P
RSMAX#P
RGSPM#P
RGSPP#P
P
Fn066
FEED0#P
RTPT#P
PECK2#P
Fn067
Fn068
Fn069
Fn070
PSW08#P
PSW07#P
PSW06#P
PSW05#P
PSW04#P
PSW03#P
PSW02#P
PSW01#P
- 421 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Fn071
PSW16#P
PSW15#P
PSW14#P
PSW13#P
PSW12#P
PSW11#P
PSW10#P
PSW09#P
Fn072
OUT7#P
OUT6#P
OUT5#P
OUT4#P
OUT3#P
OUT2#P
OUT1#P
OUT0#P
Fn073
ZRNO#P
MD4O#P
MD2O#P
MD1O#P
Fn074
OUT15#P
OUT14#P
OUT13#P
OUT12#P
OUT11#P
OUT10#P
OUT9#P
OUT8#P
Fn075
SPO#P
KEYO
DRNO#P
MLKO#P
SBKO#P
BDTO#P
Fn076
ROV2O#P
ROV1O#P
RTAP#P
MP2O#P
MP1O#P
Fn077
RTO#P
HS1DO#P
HS1CO#P
HS1BO#P
HS1AO#P
Fn078
*FV7O#P
*FV6O#P
*FV5O#P
*FV4O#P
*FV3O#P
*FV2O#P
*FV1O#P
*FV0O#P
Fn079
*JV7O#P
*JV6O#P
*JV5O#P
*JV4O#P
*JV3O#P
*JV2O#P
*JV1O#P
*JV0O#P
Fn080
*JV15O#P
*JV14O#P
*JV13O#P
*JV12O#P
*JV11O#P
*JV10O#P
*JV9O#P
*JV8O#P
Fn081
-J4O#P
+J4O#P
-J3O#P
+J3O#P
-J2O#P
+J2O#P
-J1O#P
+J1O#P
Fn082
RVSL#P
CGRMD#P
Fn083
Fn084
EUO07#P
EUO06#P
EUO05#P
EUO04#P
EUO03#P
EUO02#P
EUO01#P
EUO00#P
Fn085
EUO15#P
EUO14#P
EUO13#P
EUO12#P
EUO11#P
EUO10#P
EUO09#P
EUO08#P
Fn086
Fn087
Fn088
Fn089
SVSPM#P
SVAR#P
SYSSM#P
SYAR#P
Fn090
ABTSP3＃SP
ABTSP2＃SP
ABTSP1＃SP
ABTQSV#P
Fn091
ABTSP4＃SP
MMMOD#P
MRVSP#P
MNCHG#P
MRVMD#P
Fn092
HSBIN#P
TRSPS#P
TRMTN#P
TRACT#P
Fn093
SVWRN4#P
SVWRN3#P
SVWRN2#P
SVWRN1#P
WFAN#P
LFCIF#P
SFAN#P
Fn094
ZP8#SV
ZP7#SV
ZP6#SV
ZP5#SV
ZP4#SV
ZP3#SV
ZP2#SV
ZP1#SV
- 422 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Fn095
Fn096
ZP28#SV
ZP27#SV
ZP26#SV
ZP25#SV
ZP24#SV
ZP23#SV
ZP22#SV
ZP21#SV
Fn097
Fn098
ZP38#SV
ZP37#SV
ZP36#SV
ZP35#SV
ZP34#SV
ZP33#SV
ZP32#SV
ZP31#SV
Fn099
Fn100
ZP48#SV
ZP47#SV
ZP46#SV
ZP45#SV
ZP44#SV
ZP43#SV
ZP42#SV
ZP41#SV
Fn101
Fn102
MV8#SV
MV7#SV
MV6#SV
MV5#SV
MV4#SV
MV3#SV
MV2#SV
MV1#SV
Fn103
Fn104
INP8#SV
INP7#SV
INP6#SV
INP5#SV
INP4#SV
INP3#SV
INP2#SV
INP1#SV
Fn105
Fn106
MVD8#SV
MVD7#SV
MVD6#SV
MVD5#SV
MVD4#SV
MVD3#SV
MVD2#SV
MVD1#SV
Fn107
Fn108
MMI8#SV
MMI7#SV
MMI6#SV
MMI5#SV
MMI4#SV
MMI3#SV
MMI2#SV
MMI1#SV
Fn109
Fn110
MDTCH8#SV
MDTCH7#SV
MDTCH6#SV
MDTCH5#SV
MDTCH4#SV
MDTCH3#SV
MDTCH2#SV
MDTCH1#SV
Fn111
Fn112
EADEN8#SV
EADEN7#SV
EADEN6#SV
EADEN5#SV
EADEN4#SV
EADEN3#SV
EADEN2#SV
EADEN1#SV
Fn113
Fn114
TRQL8#SV
TRQL7#SV
TRQL6#SV
TRQL5#SV
TRQL4#SV
TRQL3#SV
TRQL2#SV
TRQL1#SV
Fn115
Fn116
FRP8#SV
FRP7#SV
FRP6#SV
FRP5#SV
FRP4#SV
FRP3#SV
FRP2#SV
FRP1#SV
Fn117
Fn118
SYN80#SV
SYN70#SV
SYN60#SV
SYN50#SV
SYN40#SV
SYN30#SV
SYN20#SV
SYN10#SV
- 423 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Fn119
Fn120
ZRF8#SV
ZRF7#SV
ZRF6#SV
ZRF5#SV
ZRF4#SV
ZRF3#SV
ZRF2#SV
ZRF1#SV
Fn121
Fn122
HDO7#P
HDO6#P
HDO5#P
HDO4#P
HDO3#P
HDO2#P
HDO1#P
HDO0#P
Fn123
Fn124
+OT8#SV
+OT7#SV
+OT6#SV
+OT5#SV
+OT4#SV
+OT3#SV
+OT2#SV
+OT1#SV
Fn125
Fn126
-OT8#SV
-OT7#SV
-OT6#SV
-OT5#SV
-OT4#SV
-OT3#SV
-OT2#SV
-OT1#SV
Fn127
Fn128
Fn129
*EAXSL#P
EOV0#P
Fn130
EBSYA#PX
EOTNA#PX
EOTPA#PX
EGENA#PX
EDENA#PX
EIALA#PX
ECKZA#PX
EINPA#PX
Fn131
EMF3A#PX
EMF2A#PX
EABUFA#PX
EMFA#PX
Fn132
EM28A#PX
EM24A#PX
EM22A#PX
EM21A#PX
EM18A#PX
EM14A#PX
EM12A#PX
EM11A#PX
Fn133
EBSYB#PX
EOTNB#PX
EOTPB#PX
EGENB#PX
EDENB#PX
EIALB#PX
ECKZB#PX
EINPB#PX
Fn134
EMF3B#PX
EMF2B#PX
EABUFB#PX
EMFB#PX
Fn135
EM28B#PX
EM24B#PX
EM22B#PX
EM21B#PX
EM18B#PX
EM14B#PX
EM12B#PX
EM11B#PX
Fn136
EBSYC#PX
EOTNC#PX
EOTPC#PX
EGENC#PX
EDENC#PX
EIALC#PX
ECKZC#PX
EINPC#PX
Fn137
EMF3C#PX
EMF2C#PX
EABUFC#PX
EMFC#PX
Fn138
EM28C#PX
EM24C#PX
EM22C#PX
EM21C#PX
EM18C#PX
EM14C#PX
EM12C#PX
EM11C#PX
Fn139
EBSYD#PX
EOTND#PX
EOTPD#PX
EGEND#PX
EDEND#PX
EIALD#PX
ECKZD#PX
EINPD#PX
Fn140
EMF3D#PX
EMF2D#PX
EABUFD#PX
EMFD#PX
Fn141
EM28D#PX
EM24D#PX
EM22D#PX
EM21D#PX
EM18D#PX
EM14D#PX
EM12D#PX
EM11D#PX
Fn142
EM48A#PX
EM44A#PX
EM42A#PX
EM41A#PX
EM38A#PX
EM34A#PX
EM32A#PX
EM31A#PX
- 424 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Fn143
Fn144
Fn145
EM48B#PX
EM44B#PX
EM42B#PX
EM41B#PX
EM38B#PX
EM34B#PX
EM32B#PX
EM31B#PX
Fn146
Fn147
Fn148
EM48C#PX
EM44C#PX
EM42C#PX
EM41C#PX
EM38C#PX
EM34C#PX
EM32C#PX
EM31C#PX
Fn149
Fn150
Fn151
EM48D#PX
EM44D#PX
EM42D#PX
EM41D#PX
EM38D#PX
EM34D#PX
EM32D#PX
EM31D#PX
Fn152
Fn153
Fn154
TLAL#P
Fn155
Fn156
Fn157
Fn158
Fn159
Fn160
MSP07#P
MSP06#P
MSP05#P
MSP04#P
MSP03#P
MSP02#P
MSP01#P
MSP00#P
Fn161
MSP15#P
MSP14#P
MSP13#P
MSP12#P
MSP11#P
MSP10#P
MSP09#P
MSP08#P
Fn162
Fn163
Fn164
Fn165
Fn166
- 425 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Fn167
Fn168
ORARC#SP
TLMC#SP
LDT2C#SP
LDT1C#SP
SARC#SP
SDTC#SP
SSTC#SP
ALMC#SP
Fn169
MORA2C#SP
MORA1C#SP
PORA2C#SP
SLVSC#SP
RCFNC#SP
RCHPC#SP
CFINC#SP
CHIPC#SP
Fn170
CSYFNC#SP
CS1DTC#SP
INCSTC#SP
PC1DEC#SP
Fn171
CSPENC#SP
Fn172
PBATL#P
PBATZ#P
Fn173
Fn174
Fn175
Fn176
Fn177
Fn178
Fn179
Fn180
CLRCH8#SV
CLRCH7#SV
CLRCH6#SV
CLRCH5#SV
CLRCH4#SV
CLRCH3#SV
CLRCH2#SV
CLRCH1#SV
Fn181
Fn182
EACNT8#SV
EACNT7#SV
EACNT6#SV
EACNT5#SV
EACNT4#SV
EACNT3#SV
EACNT2#SV
EACNT1#SV
Fn183
Fn184
ABDT8#SV
ABDT7#SV
ABDT6#SV
ABDT5#SV
ABDT4#SV
ABDT3#SV
ABDT2#SV
ABDT1#SV
Fn185
Fn186
Fn187
Fn188
AMRST8#SV
AMRST7#SV
AMRST6#SV
AMRST5#SV
AMRST4#SV
AMRST3#SV
AMRST2#SV
AMRST1#SV
Fn189
Fn190
TRQM8#SV
TRQM7#SV
TRQM6#SV
TRQM5#SV
TRQM4#SV
TRQM3#SV
TRQM2#SV
TRQM1#SV
- 426 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Fn191
Fn192
Fn193
Fn194
Fn195
Fn196
Fn197
MFSYND
MFSYNC
MFSYNB
MFSYNA
Fn198
Fn199
MCHAO#P
Fn200
R08O2#SP
R07O2#SP
R06O2#SP
R05O2#SP
R04O2#SP
R03O2#SP
R02O2#SP
R01O2#SP
Fn201
R12O2#SP
R11O2#SP
R10O2#SP
R09O2#SP
Fn202
AR072#SP
AR062#SP
AR052#SP
AR042#SP
AR032#SP
AR022#SP
AR012#SP
AR002#SP
Fn203
AR152#SP
AR142#SP
AR132#SP
AR122#SP
AR112#SP
AR102#SP
AR092#SP
AR082#SP
Fn204
R08O3#SP
R07O3#SP
R06O3#SP
R05O3#SP
R04O3#SP
R03O3#SP
R02O3#SP
R01O3#SP
Fn205
R12O3#SP
R11O3#SP
R10O3#SP
R09O3#SP
Fn206
AR073#SP
AR063#SP
AR053#SP
AR043#SP
AR033#SP
AR023#SP
AR013#SP
AR003#SP
Fn207
AR153#SP
AR143#SP
AR133#SP
AR123#SP
AR113#SP
AR103#SP
AR093#SP
AR083#SP
Fn208
EGBM8#SV
EGBM7#SV
EGBM6#SV
EGBM5#SV
EGBM4#SV
EGBM3#SV
EGBM2#SV
EGBM1#SV
Fn209
Fn210
SYNMT8#P
SYNMT7#P
SYNMT6#P
SYNMT5#P
SYNMT4#P
SYNMT3#P
SYNMT2#P
SYNMT1#P
Fn211
SYNOF8#P
SYNOF7#P
SYNOF6#P
SYNOF5#P
SYNOF4#P
SYNOF3#P
SYNOF2#P
SYNOF1#P
Fn212
Fn213
Fn214
- 427 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Fn215
Fn216
Fn217
Fn218
Fn263
Fn264
SPWRN8#P
SPWRN7#P
SPWRN6#P
SPWRN5#P
SPWRN4#P
SPWRN3#P
SPWRN2#P
SPWRN1#P
Fn265
SPWRN9#P
Fn266
ORARD#SP
TLMD#SP
LDT2D#SP
LDT1D#SP
SARD#SP
SDTD#SP
SSTD#SP
ALMD#SP
Fn267
MORA2D#SP
MORA1D#SP
PORA2D#SP
SLVSD#SP
RCFND#SP
RCHPD#SP
CFIND#SP
CHIPD#SP
Fn268
CSYFND#SP
CS1DTD#SP
INCSTD#SP
PC1DED#SP
Fn269
CSPEND#SP
Fn270
R08O4#SP
R07O4#SP
R06O4#SP
R05O4#SP
R04O4#SP
R03O4#SP
R02O4#SP
R01O4#SP
Fn271
R12O4#SP
R11O4#SP
R10O4#SP
R09O4#SP
Fn272
AR074#SP
AR064#SP
AR054#SP
AR044#SP
AR034#SP
AR024#SP
AR014#SP
AR004#SP
Fn273
AR154#SP
AR144#SP
AR134#SP
AR124#SP
AR114#SP
AR104#SP
AR094#SP
AR084#SP
Fn274
CSFO4#SP
CSFO3#SP
CSFO2#SP
CSFO1#SP
FCSS4#SP
FCSS3#SP
FCSS2#SP
FCSS1#SP
Fn275
Fn276
UO023#P
UO022#P
UO021#P
UO020#P
UO019#P
UO018#P
UO017#P
UO016#P
Fn277
UO031#P
UO030#P
UO029#P
UO028#P
UO027#P
UO026#P
UO025#P
UO024#P
Fn278
Fn279
Fn280
UO207#P
UO206#P
UO205#P
UO204#P
UO203#P
UO202#P
UO201#P
UO200#P
Fn281
UO215#P
UO214#P
UO213#P
UO212#P
UO211#P
UO210#P
UO209#P
UO208#P
Fn282
UO223#P
UO222#P
UO221#P
UO220#P
UO219#P
UO218#P
UO217#P
UO216#P
- 428 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Fn283
UO231#P
UO230#P
UO229#P
UO228#P
UO227#P
UO226#P
UO225#P
UO224#P
Fn284
UO307#P
UO306#P
UO305#P
UO304#P
UO303#P
UO302#P
UO301#P
UO300#P
Fn285
UO315#P
UO314#P
UO313#P
UO312#P
UO311#P
UO310#P
UO309#P
UO308#P
Fn286
UO323#P
UO322#P
UO321#P
UO320#P
UO319#P
UO318#P
UO317#P
UO316#P
Fn287
UO331#P
UO330#P
UO329#P
UO328#P
UO327#P
UO326#P
UO325#P
UO324#P
Fn288
FSPSY4#SP
FSPSY3#SP
FSPSY2#SP
FSPSY1#SP
Fn289
FSPPH4#SP
FSPPH3#SP
FSPPH2#SP
FSPPH1#SP
Fn290
PRGMD#P
PCKSV#P
Fn291
Fn292
ITED
Fn293
HPS08#P
HPS07#P
HPS06#P
HPS05#P
HPS04#P
HPS03#P
HPS02#P
HPS01#P
Fn294
HPS16#P
HPS15#P
HPS14#P
HPS13#P
HPS12#P
HPS11#P
HPS10#P
HPS09#P
Fn295
CNCKYO
C2SEND
Fn296
DM8#SV
DM7#SV
DM6#SV
DM5#SV
DM4#SV
DM3#SV
DM2#SV
DM1#SV
Fn297
MCHAO#P
MBCAN#P
Fn298
Fn299
Fn300
Fn301
Fn302
Fn303
Fn304
Fn305
Fn306
- 429 -
6.INTERFACE BETWEEN CNC AND PMC
B-64485EN/01
Address
Bit number
7
6
5
4
3
2
1
0
Fn307
Fn308
Fn309
Fn310
Fn311
Fn312
Fn313
Fn314
Fn315
TLMEM#P
TMFNFD#P
TLMOT#P
TLMG10#P
TLMSRH#P
TLSKF#P
Fn316
SQMPE#P
SQMPR#P
Fn317
Fn318
Fn319
Fn320
Fn321
Fn322
Fn323
Fn324
Fn325
Fn326
Fn327
#P
#P
Fn328
TLCHI4#P
TLCHI3#P
TLCHI2
TLCHI1#P
TLCH4
TLCH3#P
TLCH2#P
TLCH1#P
Fn329
TLCHB4#P
TLCHB3#P
TLCHB2#P
TLCHB1#P
TLSKF4#P
TLSKF3#P
TLSKF2#P
TLSKF1#P
Fn330
- 430 -
B-64485EN/01
6.INTERFACE BETWEEN CNC AND PMC
Address
Bit number
7
6
5
4
3
2
1
0
Fn331
Fn332
Fn333
Fn334
Fn335
Fn336
Fn337
Fn338
Fn339
Fn340
Fn341
SYCM8#SV
SYCM7#SV
SYCM6#SV
SYCM5#SV
SYCM4#SV
SYCM3#SV
SYCM2#SV
SYCM1#SV
Fn342
SYCS8#SV
SYCS7#SV
SYCS6#SV
SYCS5#SV
SYCS4#SV
SYCS3#SV
SYCS2#SV
SYCS1#SV
Fn343
MIXO8#SV
MIXO7#SV
MIXO6#SV
MIXO5#SV
MIXO4#SV
MIXO3#SV
MIXO2#SV
MIXO1#SV
Fn344
OVMO8#SV
OVMO7#SV
OVMO6#SV
OVMO5#SV
OVMO4#SV
OVMO3#SV
OVMO2#SV
OVMO1#SV
Fn345
OVSO8#SV
OVSO7#SV
OVSO6#SV
OVSO5#SV
OVSO4#SV
OVSO3#SV
OVSO2#SV
OVSO1#SV
Fn346
SMPK8#SV
SMPK7#SV
SMPK6#SV
SMPK5#SV
SMPK4#SV
SMPK3#SV
SMPK2#SV
SMPK1#SV
Fn347
D3MI#P
Fn348
Fn349
Fn350
Fn356
THREND#P
MTHML#P
Fn358
WPSF8
WPSF7
WPSF6
WPSF5
WPSF4
WPSF3
WPSF2
WPSF1
~
Fn376
SVSST8#SV
SVSST7#SV
SVSST6#SV
SVSST5#SV
SVSST4#SV
SVSST3#SV
SVSST2#SV
SVSST1#SV
- 431 -
