A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

101

PLEASE CLEAR MEMORY

The power turned off while rewriting the memory by program edit opera-

tion. If this alarm has occurred, press <RESET> while pressing

<PROG>, and only the program being edited will be deleted.

109

FORMAT ERROR IN G08

A value other than 0 or 1 was specified after P in the G08 code, or no

value was specified.

110

DATA OVERFLOW

The absolute value of fixed decimal point display data exceeds the al-

lowable range. Modify the program.

111

CALCULATED DATA OVERFLOW

The result of calculation turns out to be invalid, an alarm No.111 is is-

sued.

-10⁴⁷ to -10^-29, 0, 10^-29 to 10⁴⁷

Modify the program.

112

DIVIDED BY ZERO

Division by zero was specified. (including tan 90°)

Modify the program.

113

IMPROPER COMMAND

A function which cannot be used in custom macro is commanded.

Modify the program.

114

FORMAT ERROR IN MACRO

There is an error in other formats than <Formula>.

Modify the program.

115

ILLEGAL VARIABLE NUMBER

A value not defined as a variable number is designated in the custom

macro or in high-speed cycle machining.

The header contents are improper. This alarm is given in the following

cases:

High speed cycle machining

1. The header corresponding to the specified machining cycle number

called is not found.

2. The cycle connection data value is out of the allowable range

(0 - 999).

3. The number of data in the header is out of the allowable range

(0 - 32767).

4. The start data variable number of executable format data is out of

the allowable range (#20000 - #85535).

5. The last storing data variable number of executable format data is

out of the allowable range (#85535).

6. The storing start data variable number of executable format data is

overlapped with the variable number used in the header.

Modify the program.

116

WRITE PROTECTED VARIABLE

The left side of substitution statement is a variable whose substitution

is inhibited. Modify the program.

118

PARENTHESIS NESTING ERROR

The nesting of bracket exceeds the upper limit (quintuple).

Modify the program.

119

ILLEGAL ARGUMENT

The SQRT argument is negative. Or BCD argument is negative, and

other values than 0 to 9 are present on each line of BIN argument.

Modify the program.

122

FOUR FOLD MACRO MODAL-CALL

The macro modal call is specified four fold.

Modify the program.

123

CAN NOT USE MACRO COMMAND

Macro control command is used during DNC operation.

IN DNC

Modify the program.

124

MISSING END STATEMENT

DO - END does not correspond to 1 : 1. Modify the program.

125

FORMAT ERROR IN MACRO

<Formula> format is erroneous. Modify the program.

126

ILLEGAL LOOP NUMBER

In DOn, 1x n x3 is not established. Modify the program.

842

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

127

NC, MACRO STATEMENT IN SAME

NC and custom macro commands coexist.

BLOCK

Modify the program.

128

ILLEGAL MACRO SEQUENCE

The sequence number specified in the branch command was not 0 to

NUMBER

9999. Or, it cannot be searched. Modify the program.

129

ILLEGAL ARGUMENT ADDRESS

An address which is not allowed in <Argument Designation > is used.

Modify the program.

130

ILLEGAL AXIS OPERATION

An axis control command was given by PMC to an axis controlled by

CNC. Or an axis control command was given by CNC to an axis con-

trolled by PMC. Modify the program.

131

TOO MANY EXTERNAL ALARM

Five or more alarms have generated in external alarm message.

MESSAGES

Consult the PMC ladder diagram to find the cause.

132

ALARM NUMBER NOT FOUND

No alarm No. concerned exists in external alarm message clear.

Check the PMC ladder diagram.

133

ILLEGAL DATA IN EXT. ALARM MSG

Small section data is erroneous in external alarm message or external

operator message. Check the PMC ladder diagram.

ILLEGAL ANGLE COMMAND

The index table indexing positioning angle was instructed in other than

(M series)

an integral multiple of the value of the minimum angle.

135

Modify the program.

SPINDLE ORIENTATION PLEASE

Without any spindle orientation , an attept was made for spindle index-

(T series)

ing. Perform spindle orientation.

ILLEGAL AXIS COMMAND

In index table indexing.Another control axis was instructed together with

(M series)

the B axis.

Modify the program.

136

C/H-CODE & MOVE CMD IN SAME

A move command of other axes was specified to the same block as

BLK. (T series)

spindle indexing addresses C, H. Modify the program.

137

M-CODE & MOVE CMD IN SAME

A move command of other axes was specified to the same block as M-

BLK.

code related to spindle indexing. Modify the program.

138

SUPERIMPOSED DATA OVER-

The total distribution amount of the CNC and PMC is too large during

FLOW

superimposed control of the extended functions for PMC axis control.

139

CAN NOT CHANGE PMC CONTROL

An axis is selected in commanding by PMC axis control.

AXIS

Modify the program.

141

CAN NOT COMMAND G51 IN CRC

G51 (Scaling ON) is commanded in the tool offset mode.

(M series)

Modify the program.

142

ILLEGAL SCALE RATE

Scaling magnification is commanded in other than 1 - 999999.

(M series)

Correct the scaling magnification setting (G51 P_p

or parameter 5411 or 5421).

143

SCALED MOTION DATA OVER-

The scaling results, move distance, coordinate value and circular radius

FLOW

exceed the maximum command value. Correct the program or scaling

(M series)

mangification.

144

ILLEGAL PLANE SELECTED

The coordinate rotation plane and arc or cutter compensation C plane

(M series)

must be the same. Modify the program.

145

ILLEGAL CONDITIONS IN POLAR

The conditions are incorrect when the polar coordinate interpolation

COORDINATE INTERPOLATION

starts or it is canceled.

1) In modes other than G40, G12.1/G13.1 was specified.

2) An error is found in the plane selection. Parameters No. 5460 and

No. 5461 are incorrectly specified.

Modify the value of program or parameter.

146

IMPROPER G CODE

G codes which cannot be specified in the polar coordinate interpolation

mode was specified. See section II-4.4 and modify the program.

148

ILLEGAL SETTING DATA

Automatic corner override deceleration rate is out of the settable range

(M series)

of judgement angle. Modify the parameters (No.1710 to No.1714)

843

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

149

FORMAT ERROR IN G10L3

A code other than Q1,Q2,P1 or P2 was specified as the life count type

in the extended tool life management.

150

ILLEGAL TOOL GROUP NUMBER

Tool Group No. exceeds the maximum allowable value.

Modify the program.

151

TOOL GROUP NUMBER NOT

The tool group commanded in the machining program is not set.

FOUND

Modify the value of program or parameter.

152

NO SPACE FOR TOOL ENTRY

The number of tools within one group exceeds the maximum value re-

gisterable. Modify the number of tools.

153

T-CODE NOT FOUND

In tool life data registration, a T code was not specified where one should

be. Correct the program.

154

NOT USING TOOL IN LIFE GROUP

When the group is not commanded, H99 or D99 was commanded.

(M series)

Correct the program.

155

ILLEGAL T-CODE IN M06

In the machining program, M06 and T code in the same block do not cor-

(M series)

respond to the group in use. Correct the program.

ILLEGAL T-CODE IN M06

Group No.∆∆ which is specified with T∆∆ 88 of the machining program

(T series)

do not included in the tool group in use. Correct the program.

156

P/L COMMAND NOT FOUND

P and L commands are missing at the head of program in which the tool

group is set. Correct the program.

157

TOO MANY TOOL GROUPS

The number of tool groups to be set exceeds the maximum allowable

value. (See parameter No. 6800 bit 0 and 1) Modify the program.

158

ILLEGAL TOOL LIFE DATA

The tool life to be set is too excessive. Modify the setting value.

159

TOOL DATA SETTING

During executing a life data setting program, power was turned off.

INCOMPLETE

Set again.

MISMATCH WAITING M-CODE

Diffrent M code is commanded in heads 1 and 2 as waiting M code.

(T series (At two-path))

Modify the program.

MISMATCH WAITING M-CODE

1) Although the same P command is specified, the waiting M codes do

(T series (At three-path))

not match.

160

2) Although the waiting M codes match, the P commands do not match.

3) Two-path wait and three-path wait are specified simultaneously.

Modify the program.

G72.1 NESTING ERROR

A subprogram which performs rotational copy with G72.1 contains

(M series)

another G72.1 command.

161

ILLEGAL P OF WAITING M-CODE

1) The value of address P is a negative value, 1, 2, 4, or a value not

(T series (three-path control)

smaller than 8.

2) The value specified in P is not consistent with the system configura-

tion.

Modify the program.

G72.1 NESTING ERROR

A subprogram which performs parallel copy with G72.2 contains anoth-

(M series)

er G72.2 command.

COMMAND G68/G69 INDEPEN-

G68 and G69 are not independently commanded in balance cut.

163

DENTLY (T series (At two-path))

Modify the program.

169

ILLEGAL TOOL GEOMETRY DATA

Incorrect tool figure data in interference check.

(At two-path)

Set correct data, or select correct tool figure data.

175

ILLEGAL G107 COMMAND

Conditions when performing circular interpolation start or cancel not

correct. To change the mode to the cylindrical interpolation mode, spec-

ify the command in a format of “G07.1 rotation-axis name radius of cylin-

der.”

844

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

IMPROPER G-CODE IN G107

Any of the following G codes which cannot be specified in the cylindrical

(M series)

interpolation mode was specified.

1) G codes for positioning: G28,, G73, G74, G76, G81 - G89,

including the codes specifying the rapid traverse cycle

2) G codes for setting a coordinate system: G52,G92,

3) G code for selecting coordinate system: G53 G54-G59

Modify the program.

176

IMPROPER G-CODE IN G107

Any of the following G codes which cannot be specified in the cylindrical

(T series)

interpolation mode was specified.

1) G codes for positioning: G28, G76, G81 - G89, including the

codes specifying the rapid traverse cycle

2) G codes for setting a coordinate system: G50, G52

3) G code for selecting coordinate system: G53 G54-G59

Modify the program.

177

CHECK SUM ERROR

Check sum error

(G05 MODE)

Modify the program.

178

G05 COMMANDED IN G41/G42

G05 was commanded in the G41/G42 mode.

MODE

Correct the program.

179

PARAM. (NO. 7510) SETTING

The number of controlled axes set by the parameter 7510 exceeds the

ERROR

maximum number. Modify the parameter setting value.

180

COMMUNICATION ERROR

Remote buffer connection alarm has generated. Confirm the number of

(REMOTE BUF)

cables, parameters and I/O device.

181

FORMAT ERROR IN G81 BLOCK

G81 block format error (hobbing machine)

(Hobbing machine, EGB) (M series)

1) T (number of teeth) has not been instructed.

2) Data outside the command range was instructed by either T, L, Q or

3) An overflow occurred in synchronization coefficient calculation.

Modify the program.

182

G81 NOT COMMANDED

G83 (C axis servo lag quantity offset) was instructed though synchro-

(Hobbing machine) (M series)

nization by G81 has not been instructed. Correct the program. (hobbing

machine)

183

DUPLICATE G83 (COMMANDS)

G83 was instructed before canceled by G82 after compensating for the

(Hobbing machine) (M series)

C axis servo lag quantity by G83. (hobbing machine)

184

ILLEGAL COMMAND IN G81

A command not to be instructed during synchronization by G81 was

(Hobbing machine, EGB) (M series)

instructed. (hobbing machine)

1) A C axis command by G00, G27, G28, G29, G30, etc. was

instructed.

2) Inch/Metric switching by G20, G21 was instructed.

185

RETURN TO REFERENCE POINT

G81 was instructed without performing reference position return after

(Hobbing machine) (M series)

power on or emergency stop. (hobbing machine) Perform reference

position return.

186

PARAMETER SETTING ERROR

Parameter error regarding G81 (hobbing machine)

(Hobbing machine, EGB) (M series)

1) The C axis has not been set to be a rotary axis.

2) A hob axis and position coder gear ratio setting error

Modify the parameter.

187

HOB COMMAND IS NOT ALLOWED

Error in the modal state when G81.4 or G81 is specified

1. The canned cycle mode (G81 to G89) is set.

2. The thread cutting mode is set.

3. The C-axis is under synchronous, composite, or superimposed

control.

845

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

190

ILLEGAL AXIS SELECT

In the constant surface speed control, the axis specification is wrong.

(See parameter No. 3770.) The specified axis command (P) contains an

illegal value.

Correct the program.

194

SPINDLE COMMAND IN

A contour control mode, spindle positioning (Cs-axis control) mode, or

SYNCHRO-MODE

rigid tapping mode was specified during the serial spindle synchronous

control mode. Correct the program so that the serial spindle synchro-

nous control mode is released in advance.

197

C-AXIS COMMANDED IN SPINDLE

The program specified a movement along the Cs-axis when the signal

MODE

CON(DGN=G027#7) was off. Correct the program, or consult the PMC

ladder diagram to find the reason the signal is not turned on.

199

MACRO WORD UNDEFINED

Undefined macro word was used. Modify the custom macro.

200

ILLEGAL S CODE COMMAND

In the rigid tap, an S value is out of the range or is not specified.

Modify the program.

201

FEEDRATE NOT FOUND IN RIGID

In the rigid tap, no F value is specified.

TAP

Correct the program.

202

POSITION LSI OVERFLOW

In the rigid tap, spindle distribution value is too large. (System error)

203

PROGRAM MISS AT RIGID TAPPING

In the rigid tap, position for a rigid M code (M29) or an S command is in-

correct. Modify the program.

204

ILLEGAL AXIS OPERATION

In the rigid tap, an axis movement is specified between the rigid M code

(M29) block and G84 or G74 for M series (G84 or G88 for T series) block.

Modify the program.

205

RIGID MODE DI SIGNAL OFF

1. Although a rigid M code (M29) is specified in rigid tapping, the rigid

mode DI signal (DGN G061.0) is not ON during execution of the G84

(G88) block.

2. In a system with the multi-spindle option, the spindle used for rigid

tapping is not selected (by DI signal G27#0 and #1, or G61#4 and #5).

Check the PMC ladder diagram to find the reason why the DI signal

is not turned on.

206

CAN NOT CHANGE PLANE

Plane changeover was instructed in the rigid mode.

(M series)

Correct the program.

207

RIGID DATA MISMATCH

The specified distance was too short or too long in rigid tapping.

210

CAN NOT COMAND M198/M199

M98 and M99 are executed in the schedule operation. M198 is

executed in the DNC operation. Modify the program.

1) The execution of an M198 or M99 command was attempted during

scheduled operation. Alternatively, the execution of an M198 com-

mand was attempted during DNC operation. Correct the program.

The execution of an M99 command was attempted by an interrupt

macro during pocket machining in a multiple repetitive canned

cycle.

211

G31 (HIGH) NOT ALLOWED IN G99

G31 is commanded in the per revolution command when the high-

(T series)

speed skip option is provided. Modify the program.

ILLEGAL PLANE SELECT

The arbitrary angle chamfering or a corner R is commanded or the plane

(M series)

including an additional axis. Correct the program.

212

ILLEGAL PLANE SELECT

The direct drawing dimensions programming is commanded for the

(T series)

plane other than the Z-X plane. Correct the program.

846

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

213

ILLEGAL COMMAND IN

Movement is commanded for the axis to be synchronously controlled.

SYNCHRO-MODE

Any of the following alarms occurred in the operation with the simple

(M series)

synchronization control.

1) The program issued the move command to the slave axis.

2) The program issued the manual continuous feed/manual handle

feed/incremental feed command to the slave axis.

3) The program issued the automatic reference position return com-

mand without specifying the manual reference position return after

the power was turned on.

4) The difference between the position error amount of the master and

slave axes exceeded the value specified in parameter NO.8313.

ILLEGAL COMMAND IN

A move command has been specified for an axis subject to synchro-

SYNCHRO-MODE (T series)

nous control.

214

ILLEGAL COMMAND IN

Coordinate system is set or tool compensation of the shift type is

SYNCHRO-MODE

executed in the synchronous control. Correct the program.

217

DUPLICATE G51.2 (COMMANDS)

G51.2/G251 is further commanded in the G51.2/G251 mode. Modify

(T series)

the program.

218

NOT FOUND P/Q COMMAND IN

P or Q is not commanded in the G251 block, or the command value is

G251 (T series)

out of the range. Modify the program.

219

COMMAND G250/G251

G251 and G250 are not independent blocks.

INDEPENDENTLY (T series)

220

ILLEGAL COMMAND IN

In the synchronous operation, movement is commanded by the NC pro-

SYNCHR-MODE (T series)

gram or PMC axis control interface for the synchronous axis.

221

ILLEGAL COMMAND IN

Polygon machining synchronous operation and axis control or balance

SYNCHR-MODE (T series)

cutting are executed at a time. Modify the program.

222

DNC OP. NOT ALLOWED IN

Input and output are executed at a time in the background edition.

BG.-EDIT (M series)

Execute a correct operation.

224

RETURN TO REFERENCE POINT

Reference position return has not been performed before the automatic

(M series)

operation starts. Perform reference position return only when bit 0 of pa-

rameter 1005 is 0.

TURN TO REFERENCE POINT

Reference position return is necessary before cycle start.

(T series)

225

SYNCHRONOUS/MIXED CONTROL

This alarm is generated in the following circumstances. (Searched for

ERROR

during synchronous and mixed control command.

(T series (At two-path))

When there is a mistake in axis number parameter (No. 1023) set-

ting.

When there is a mistake in control commanded.

During hobbing synchronization, a command to bring the C-axis under

synchronous, composite, or superimposed control is made.

Modify the program or the parameter.

226

ILLEGAL COMMAND IN SYNCHRO-

A travel command has been sent to the axis being synchronized in syn-

MODE (T series (At two-path))

chronous mode. Modify the program or the parameter.

229

CAN NOT KEEP SYNCHRO-STATE

This alarm is generated in the following circumstances.

(T series)

When the synchro/mixed state could not be kept due to system over-

load.

The above condition occurred in CMC devices (hardware) and syn-

chro-state could not be kept.

(This alarm is not generated in normal use conditions.)

230

R CODE NOT FOUND

The infeed quantity R has not been instructed for the G161 block. Or

(Grinding machine) (M series)

the R command value is negative. Correct the program.

847

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

231

ILLEGAL FORMAT IN G10 OR L50

Any of the following errors occurred in the specified format at the pro-

grammable-parameter input.

Address N or R was not entered.

A number not specified for a parameter was entered.

The axis number was too large.

An axis number was not specified in the axis-type parameter.

An axis number was specified in the parameter which is not an axis

type. Correct the program.

In the locked state set by the password function, an attempt was

made to set bit 4 (NE9) of parameter No. 3204 to 0 or change the con-

tents of parameter No. 3210.

An attempt was made to change a program encryption parameter

(parameter No. 3220 to 3223).

232

TOO MANY HELICAL AXIS

Three or more axes (in the normal direction control mode (M series) two

COMMANDS

or more axes) were specified as helical axes in the helical interpolation

mode.

233

DEVICE BUSY

When an attempt was made to use a unit such as that connected via the

RS-232-C interface, other users were using it.

239

BP/S ALARM

While punching was being performed with the function for controlling ex-

ternal I/O units ,background editing was performed.

240

BP/S ALARM

Background editing was performed during MDI operation.

241

ILLEGAL FORMAT IN G02.2/G03.2

The end point, I, J, K, or R is missing from a command for involute inter-

(M series)

polation.

242

ILLEGAL COMMAND IN

An invalid value has been specified for involute interpolation.

G02.2/G03.2

S The start or end point is within the basic circle.

(M series)

S I, J, K, or R is set to 0.

S The number of rotations between the start of the involute curve and

the start or end point exceeds 100.

243

OVER TOLERANCE OF END POINT

The end point is not on the involute curve which includes the start point

(M series)

and thus falls outside the range specified with parameter No. 5610.

244

P/S ALARM

In the skip function activated by the torque limit signal, the number of ac-

(T series)

cumulated erroneous pulses exceed 32767 before the signal was input.

Therefore, the pulses cannot be corrected with one distribution.

Change the conditions, such as feed rates along axes and torque limit,

and try again.

245

T-CODE NOT ALOWEE IN THIS

One of the G codes, G50, G10, and G04, which cannot be specified in

BLOCK (T series)

the same block as a T code, was specified with a T code.

246

ENCODE PROGRAM

During read of an encrypted program, an attempt was made to store the

NUMBER ERROR

program with a number exceeding the protection range.

(See parameter Nos. 3222 and 223.)

247

ILLEGAL CODE USED

When an encrypted program is output, EIA is set for the punch code.

FOR OUTPUT

Specify ISO.

250

Z AXIS WRONG COMMAND (ATC)

Movement along the Z-axis is specified in a block specifying a tool

(M series)

change command (M06T_). (Only for ROBODRILL)

848

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

251

ATC ERROR

This alarm is issued in the following cases:

(M series)

S An M06T_ command contains an unusable T code.

S An M06 command has been specified when the Z machine coordi

nate is positive.

S The parameter for the current tool number (No. 7810) is set to 0.

S An M06 command has been specified in canned cycle mode.

S A reference position return command (G27 to G44) and M06 com-

mand have been specified in the same block.

S An M06 command has been specified in tool compensation mode

(G41 to G44).

S An M06 command has been specified without performing reference

position return after power-on or the release of emergency stop.

S The machine lock signal or Z-axis ignore signal has been turned on

during tool exchange.

S A pry alarm has been detected during tool exchange.

Refer to diagnosis No. 530 to determine the cause. (Only for ROBO-

DRILL)

252

ATC SPINDLE ALARM

An excessive error arose during spindle positioning for ATC. For details,

(M series)

refer to diagnosis No. 531. (Only for ROBODRILL)

253

G05 IS NOT AVAILABLE

Alarm details

(M series)

Binary input operation using high-speed remote buffer (G05) or high-

speed cycle machining (G05) has been specified in advance control

mode (G08P1). Execute G08P0; to cancel advance control mode, be-

fore executing these G05 commands.

4500

REPOSITIONING INHIBITED

A repositioning command was specified in the circular interpolation

(G02, G03) mode.

4502

ILLEGAL COMMAND IN BOLT

In a bolt hole circle (G26) command, the radius (I) was set to zero or a

negative value, or the number of holes (K) was set to zero. Alternatively,

HOLE

I, J, or K was not specified.

4503

ILLEGAL COMMAND IN LINE AT

In a line-at-angle (G76) command, the number of holes (K) was set to

ANGLE

zero or a negative value. Alternatively, I, J, or K was not specified.

4504

ILLEGAL COMMAND IN ARC

In an arc (G77) command, the radius (I) or the number of holes (K) was

set to zero or a negative value. Alternatively, I, J, K, or P was not speci-

fied.

4505

ILLEGAL COMMAND IN GRID

In a grid (G78, G79) command, the number of holes (P, K) was set to

zero or a negative value. Alternatively, I, J, K, or P was not specified.

4506

ILLEGAL COMMAND IN SHARE

In a shear proof (G86) command, the tool size (P) was set to zero, or the

blanking length (I) was 1.5 times larger than the tool size (P) or less. Al-

PROOFS

ternatively, I, J, or P was not specified.

4507

ILLEGAL COMMAND IN SQUARE

In a square (G87) command, the tool size (P,Q) was set to zero or a neg-

ative value, or the blanking length (I, J) was three times larger than the

tool size (P, Q) or less. Alternatively, I, J, P, or Q was not specified.

4508

ILLEGAL COMMAND IN RADIUS

In a radius (G88) command, the traveling pitch (Q) or radius (I) was set

to zero or a negative value, or the traveling pitch (Q) was greater than

or equal to the arc length. Alternatively, I, J, K, P, or Q was not specified.

4509

ILLEGAL COMMAND IN CUT AT

In a cut-at-angle (G89) command, the traveling pitch (Q) was set to zero,

ANGLE

negative value, or another value larger than or equal to the length (I).

Alternatively, I, J, P, or Q was not specified.

4510

ILLEGAL COMMAND IN

In a linear punching (G45) command, the traveling distance was set to

zero or a value 1.5 times larger than the tool size (P) or less. Alternative-

LINE-PUNCH

ly, P was not specified.

849

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

4511

ILLEGAL COMMAND IN

In a circular punching (G46, G47) command, the same position was

CIRCLE-PUNCH

specified for both start and end points of the arc, radius (R) of the arc was

set to zero, or the pitch (Q) was set to a value exceeding the arc length.

Alternatively, R or Q was not specified.

4520

T, M INHIBITED IN

T code, M code, G04, G70 or G75 was specified in the nibbling mode.

NIBBLING-MODE

4521

EXCESS NIBBLING MOVEMENT

In the nibbling mode, the X-axis or Y-axis traveling distance was larger

(X, Y)

than or equal to the limit (No. 16188 to 16193).

4522

EXCESS NIBBLING MOVEMENT

In the circular nibbling (G68) or usual nibbling mode, the C-axis traveling

(C)

distance was larger than or equal to the limit (No. 16194).

4523

ILLEGAL COMMAND IN

In a circular nibbling (G68) command, the traveling pitch (Q) was set to

zero, a negative value, or a value larger than or equal to the limit (No.

CIRCLE-NIBBL

16186, 16187), or the radius (I) was set to zero or a negative value. Al-

ternatively, I, J, K, P, or Q was not specified.

4524

ILLEGAL COMMAND IN

In a linear nibbling (G69) command, the traveling pitch (Q) was set to

zero, negative value, or a value larger than or equal to the limit (No.

LINE-NIBBL

16186, 16187). Alternatively, I, J, P, or Q was not specified.

4530

A/B MACRO NUMBER ERROR

The number for storing and calling by an A or B macro was set to a value

beyond the range from 1 to 5.

4531

U/V MACRO FORMAT ERROR

An attempt was made to store a macro while storing another macro us-

ing a U or V macro.

A V macro was specified although the processing to store a macro was

not in progress.

A U macro number and V macro number do not correspond with each

other.

4532

IMPROPER U/V MACRO NUMBER

The number of an inhibited macro (number beyond the range from 01

to 99) was specified in a U or V macro command.

4533

U/V MACRO MEMORY OVERFLOW

An attempt was made to store too many macros with a U or V macro

command.

4534

W MACRO NUMBER NOT FOUND

Macro number W specified in a U or V macro command is not stored.

4535

U/V MACRO NESTING ERROR

An attempt was made to call a macro which is defined three times or

more using a U or V macro command.

An attempt was made to store 15 or more macros in the storage area

for macros of number 90 to 99.

4536

NO W, Q COMMAND IN

W or Q was not specified in the command for taking multiple workpieces

(G73, G74).

MULTI-PIECE

4537

ILLEGAL Q VALUE IN MULTI-PIECE

In the command for taking multiple workpieces (G73, G74), Q is set to

a value beyond the range from 1 to 4.

4538

W NO. NOT FOUND IN

Macro number W specified in the command for taking multiple work-

MULTI-PIECE

pieces (G73, G74) is not stored.

4539

MULTI-PIECE SETTING IS ZERO

The command for taking multiple workpieces (G73, G74) was specified

although zero is specified for the function to take multiple workpieces

(No. 16206 or signals MLP1 and MLP2 (PMC address G231, #0 and

#1)).

4540

MULTI-PIECE COMMAND WITHIN

The command for taking multiple workpieces (G73, G74) was specified

MACRO

when a U or V macro was being stored.

4542

MULTI-PIECE COMMAND ERROR

Although G98P0 was specified, the G73 command was issued.

Although G98K0 was specified, the G74 command was issued.

850

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

4543

MULTI-PIECE Q COMMAND

Although G98P0 was specified, the Q value for the G74 command was

ERROR

not 1 or 3.

Although G98K0 was specified, the Q value for the G73 command was

not 1 or 2.

4544

MULTI-PIECE RESTART ERROR

In the command for resuming taking multiple workpieces, the resume

position (P) is set to a value beyond the range from 1 to total number of

workpieces to be machined.

4549

ILLEGAL TOOL DATA FORMAT

The quantity of tool data patterns to be saved is too large to fit the usable

area (16 KB).

4600

T, C COMMAND IN

In the linear interpolation (G01) mode or circular interpolation (G02,

G03) mode, a T command or C-axis command was specified.

INTERPOLATION

4601

INHIBITED T, M COMMAND

In the block of G52, G72, G73, or G74, a T or M command was specified.

4602

ILLEGAL T-CODE

The specified T command is not cataloged on the tool register screen.

4603

C AXIS SYNCHRONOUS ERROR

The difference between the position deviation value of C1 axis and C2

axis exceeds the parameter value (No. 16364, 16365) with the C-axis

synchronous control function.

4604

ILLEGAL AXIS OPERATION

A C-axis command was specified in the block containing a T command

for multiple tools.

4605

NEED ZRN

C-axis synchronization failed.

4630

ILLEGAL COMMAND IN LASER

In the laser mode, a nibbling command or pattern command was speci-

MODE

fied.

In the tracing mode, an attempt was made to make a switch to the

punching mode.

4650

IMPROPER G-CODE IN OFFSET

In the cutter compensation mode, an inhibited G code (pattern com-

MODE

mand, G73, G74, G75, etc.) was specified.

4700

PROGRAM ERROR (OT +)

The value specified in the X-axis move command exceeded the positive

value of stored stroke limit 1. (Advance check)

4701

PROGRAM ERROR (OT -)

The value specified in the X-axis move command exceeded the nega-

tive value of stored stroke limit 1. (Advance check)

4702

PROGRAM ERROR (OT +)

The value specified in the Y-axis move command exceeded the positive

value of stored stroke limit 1. (Advance check)

4703

PROGRAM ERROR (OT -)

The value specified in the Y-axis move command exceeded the nega-

tive value of stored stroke limit 1. (Advance check)

4704

PROGRAM ERROR (OT +)

The value specified in the Z-axis move command exceeded the positive

value of stored stroke limit 1. (Advance check)

4705

PROGRAM ERROR (OT -)

The value specified in the Z-axis move command exceeded the nega-

tive value of stored stroke limit 1. (Advance check)

5000

ILLEGAL COMMAND CODE

The specified code was incorrect in the high-precision contour control

(M series)

(HPCC) mode.

5003

ILLEGAL PARAMETER (HPCC)

There is an invalid parameter.

(M series)

5004

HPCC NOT READY (M series)

High-precision contour control is not ready.

5006

TOO MANY WORD IN ONE BLOCK

The number of words specified in a block exceeded 26 in the HPCC

(M series)

mode.

5007

TOO LARGE DISTANCE (M series)

In the HPCC mode, the machine moved beyond the limit.

5009

PARAMETER ZERO (DRY RUN)

The maximum feedrate (parameter No. 1422) or the feedrate in dry run

(M series)

(parameter No. 1410) is 0 in the HPCC model.

5010

END OF RECORD

The end of record (%) was specified.

I/O is incorrect. modify the program.

851

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

5011

PARAMETER ZERO(CUT MAX)

The maximum cutting feedrate (parameter No. 1422, No. 1430, No.

(M series)

1431, No. 1432) is 0 in the HPCC mode.

5012

G05 P10000 ILLEGAL START UP

Function category:

(HPCC)

High-precision contour control

(M series)

Alarm details:

G05 P10000 has been specified in a mode from which the system can-

not enter HPCC mode.

5013

HPCC: CRC OFS REMAIN AT CAN-

G05P0 has been specified in G41/G42 mode or with offset remaining.

CEL (M series)

5014

TRACE DATA NOT FOUND

Transfer cannot be performed because no trace data exists.

5015

NO ROTATION AXIS

The specified rotation axis does not exist for tool axis direction handle

(M series)

feed.

5016

ILLEGAL COMBINATION OF M

M codes which belonged to the same group were specified in a block.

CODE

Alternatively,an M code which must be specified without other M codes

in the block was specified in a block with other M codes.

5018

POLYGON SPINDLE SPEED ER-

Function category:

ROR

Polygon turning

(T series)

Alarm details:

In G51.2 mode, the speed of the spindle or polygon synchronous axis

either exceeds the clamp value or is too small. The specified rotation

speed ratio thus cannot be maintained.

5020

PARAMETER OF RESTART ERROR

An erroneous parameter was specified for restarting a program.

A parameter for program restart is invalid.

5030

ILLEGAL COMMAND (G100)

The end command (G110) was specified before the registratioin start

(T series)

command (G101, G102, or G103) was specified for the B-axis.

5031

ILLEGAL COMMAND (G100, G102,

While a registration start command (G101, G102, or G103) was being

G103) (T series)

executed, another registration start command was specified for the B-

axis.

5032

NEW PRG REGISTERED IN B-AXS

While the machine was moving about the B-axis, at attempt was made

MOVE (T series)

to register another move command.

5033

NO PROG SPACE IN MEMORY B-

Commands for movement about the B-axis were not registered be-

AXS (T series)

cause of insufficient program memory.

5034

PLURAL COMMAND IN G110

Multiple movements were specified with the G110 code for the B-axis.

(T series)

5035

NO FEEDRATE COMMANDED B-

A feedrate was not specified for cutting feed about the B-axis.

AXS (T series)

5036

ADDRESS R NOT DEFINED IN

Point R was not specified for the canned cycle for the B-axis.

G81-G86 (T series)

5037

ADDRESS Q NOT DEFINED IN G83

Depth of cut Q was not specified for the G83 code (peck drilling cycle).

(T series)

Alternatively, 0 was specified in Q for the B-axis.

5038

TOO MANY START M-CODE COM-

More than six M codes for starting movement about the B-axis were

MAND (T series)

specified.

5039

START UNREGISTERED B-AXS

An attempt was made to execute a program for the B-axis which had

PROG (T series)

not been registered.

5040

CAN NOT COMMANDED B-AXS

The machine could not move about the B-axis because parameter

MOVE (T series)

No.8250 was incorrectly specified, or because the PMC axis system

could not be used.

5041

CAN NOT COMMANDED G110

Blocks containing the G110 codes were successively specified in tool-

BLOCK (T series)

tip radius compensation for the B-axis.

852

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

5043

TOO MANY G68 NESTING

Three-dimensional coordinate conversion G68 has been specified

(M series)

three or more times.

TOO MANY G68 NESTING

Three-dimensional coordinate conversion G68.1 has been specified

(T series)

three or more times.

5044

G68 FORMAT ERROR

A G68 command block contains a format error. This alarm is issued in

(M series)

the following cases:

1. I, J, or K is missing from a G68 command block (missing coordinate

rotation option).

2. I, J, and K are 0 in a G68 command block.

3. R is missing from a G68 command block.

G68 FORMAT ERROR

A G68.1 command block contains a format error. This alarm is issued

(T series)

in the following cases:

1. I, J, or K is missing from a G68.1 command block (missing coordi-

nate rotation option).

2. I, J, and K are 0 in a G68.1 command block.

3. R is missing from a G68.1 command block.

5046

ILLEGAL PARAMETER (ST.COMP)

The parameter settings for straightness compensation contain an error.

Possible causes are as follows:

1. A parameter for a movement axis or compensation axis contains an

axis number which is not used.

2. More than 128 pitch error compensation points exist between the

negative and positive end points.

3. Compensation point numbers for straightness compensation are

not assigned in the correct order.

4. No straightness compensation point exists between the pitch error

compensation points at the negative and positive ends.

5. The compensation value for each compensation point is too large

or too small.

The settings of parameters Nos. 13881 to 13886 are illegal (in the

interpolation type straightness compensation).

5050

ILL-COMMAND IN CHOPPING

A command for switching the major axis has been specified for circular

MODE

threading. Alternatively, a command for setting the length of the major

(M series)

axis to 0 has been specified for circular threading.

5051

M-NET CODE ERROR

Abnormal character received (other than code used for transmission)

5052

M-NET ETX ERROR

Abnormal ETX code

5053

M-NET CONNECT ERROR

Connection time monitoring error (parameter No. 175)

5054

M-NET RECEIVE ERROR

Polling time monitoring error (parameter No. 176)

5055

M-NET PRT/FRT ERROR

Vertical parity or framing error

5057

M-NET BOARD SYSTEM DOWN

Transmission timeout error (parameter No. 177)

ROM parity error

CPU interrupt other than the above

5058

G35/G36 FORMAT ERROR

A command for switching the major axis has been specified for circular

(T series)

threading. Alternatively, a command for setting the length of the major

axis to 0 has been specified for circular threading.

5059

RADIUS IS OUT OF RANGE

A radius exceeding nine digits has been specified for circular interpola-

tion with the center of the arc specified with I, J, and K.

853

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

5060

ILLEGAL

PARAMETER

There is a parameter setting error.

G02.3/G03.3

Parameter No. 5641 (setting of the linear axis) is not set.

(M series)

The axis set in parameter No. 5641 is not a linear axis.

Parameter No. 5642 (setting of a rotation axis) is not set.

The axis set in parameter No. 5642 is not a rotation axis.

The linear and rotation axes cannot be controlled by the CNC. (The val-

ue set in parameter No. 1010 is exceeded.)

5061

ILLEGAL FORMAT IN G02.3/G03.3

The exponential interpolation command (G02.3/G03.3) has a format er-

(M series)

ror.

Address I, J, or K is not specified.

The value of address I, J, or K is 0.

5062

ILLEGAL

COMMAND

The value specified in an exponential interpolation command

G02.3/G03.3

(G02.3/03.3) is illegal. A value that does not allow exponential interpola-

(M series)

tion is specified.

(For example, a negative value is specified in In.)

5063

IS NOT PRESET AFTER REF.

Function category:

(M series)

Workpiece thickness measurement

Alarm details

The position counter was not preset before the start of workpiece thick-

ness measurement. This alarm is issued in the following cases:

(1) An attempt has been made to start measurement without first estab-

lishing the origin.

(2) An attempt has been made to start measurement without first pre-

setting the position counter after manual return to the origin.

5064

DIFFERRENT AXIS UNIT

(IS-B,

Circular interpolation has been specified on a plane consisting of axes

IS-C)

having different increment systems.

(M series)

5065

DIFFERENT AXIS UNIT (PMC AXIS)

Axes having different increment systems have been specified in the

(M series)

same DI/DO group for PMC axis control. Modify the setting of parameter

No. 8010.

5067

G05 PO COMMANDED IN G68/G51

HPCC mode cannot be canceled during G51 (scaling) or G68 (coordi-

MODE

nate system rotation).

(HPCC) (M series)

Correct the program.

5068

G31 FORMAT ERROR

The continuous high-speed skip command (G31 P90) has one of the

(M series)

following errors:

1. The axis along which the tool is moved is not specified.

2. More than one axis is specified as the axis along which the tool is

moved.

Alternatively, the EGB skip command (G31.8) or continuous high-

speed skip command (G31.9) has one of the following errors:

1. A move command is specified for the EGB axis (workpiece axis).

2. More than one axis is specified.

3. P is not specified.

4. The specified Q value exceeds the allowable range.

Correct the program.

5069

WHL-C:ILLEGA

The P data in selection of the grinding-wheel wear compensation cen-

P-DATA

ter is illegal.

(M series)

5073

NO DECIMAL POINT

No decimal point has been specified for an address requiring a decimal

point.

5074

ADDRESS DUPLICATION ERROR

The same address has been specified two or more times in a single

block. Alternatively, two or more G codes in the same group have been

specified in a single block.

5082

DATA SERVER ERROR

This alarm is detailed on the data server message screen.

854

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

5085

SMOOTH IPL ERROR 1

A block for specifying smooth interpolation contains a syntax error.

5096

MISMATCH WAITING M-CODE

Different wait codes (M codes) were specified in HEAD1 and HEAD2.

(M series)

Correct the program.

5110

NOT STOP POSITION

An illegal G code was specified in AI contour control mode.

(G05.1 G1)

A command was specified for the index table indexing axis in AI control

(M series)

mode.

NOT STOP POSITION

An illegal G code was specified in AI look-ahead control mode.

(G05.1 G1)

A command was specified for the index table indexing axis in AI look-

(21i-M)

ahead control mode.

5111

IMPROPER MODEL G-CODE

An illegal G code is left modal when AI contour control mode was speci-

(G05.1 G1)

fied.

(M series)

IMPROPER MODEL G-CODE

An illegal G code is left modal when AI look-ahead control mode was

(G05.1 G1)

specified.

(21i-M)

5112

G08 CAN NOT BE COMMANDED

Look-ahead control (G08) was specified in AI contour control mode.

(G05.1 G1)

(M series)

G08 CAN NOT BE COMMANDED

Look-ahead control (G08) was specified in AI look-ahead control

(G05.1 G1)

mode.

(21i-M)

5114

NOT STOP POSITION

At the time of restart after manual intervention, the coordinates at which

(G05.1 Q1)

the manual intervention occurred have not been restored.

(M series)

CAN NOT ERROR IN MDI MODE

AI contour control (G05.1) was specified in MDI mode.

(G05.1)

(21i-M)

5115

SPL : ERROR

There is an error in the specification of the rank.

(M series)

No knot is specified.

The knot specification has an error.

The number of axes exceeds the limits.

Other program errors

5116

SPL : ERROR

There is a program error in a block under look-ahead control.

(M series)

Monotone increasing of knots is not observed.

In NURBS interpolation mode, a mode that cannot be used together is

specified.

5117

SPL : ERROR

The first control point of NURBS is incorrect.

(M series)

5118

SPL : ERROR

After manual intervention with manual absolute mode set to on, NURBS

(M series)

interpolation was restarted.

855

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

5122

ILLEGAL COMMAND IN SPIRAL

A spiral interpolation or conical interpolation command has an error.

(M series)

Specifically, this error is caused by one of the following:

1) L = 0 is specified.

2) Q = 0 is specified.

3) R/, R/, C is specified.

4) Zero is specified as height increment.

5) Three or more axes are specified as the height axes.

6) A height increment is specified when there are two height axes.

7) Conical interpolation is specified when the helical interpolation

function is not selected.

8) Q < 0 is specified when radius difference > 0.

9) Q > 0 is specified when radius difference < 0.

10) A height increment is specified when no height axis is specified.

5123

OVER TOLERANCE OF END POINT

The difference between a specified end point and the calculated end

(M series)

point exceeds the allowable range (parameter 3471).

5124

CAN NOT COMMAND SPIRAL

A spiral interpolation or conical interpolation was specified in any of the

(M series)

following modes:

1) Scaling

2) Programmable mirror image

3) Polar coordinate interpolation

In cutter compensation C mode, the center is set as the start point or

end point.

5134

FSSB : OPEN READY TIME OUT

Initialization did not place FSSB in the open ready state.

5135

FSSB : ERROR MODE

FSSB has entered error mode.

5136

FSSB : NUMBER OF AMPS IS SMALL

In comparison with the number of controlled axes, the number of amplifi-

ers recognized by FSSB is not enough.

5137

FSSB : CONFIGURATION ERROR

FSSB detected a configuration error.

5138

FSSB : AXIS SETTING NOT COM-

In automatic setting mode, axis setting has not been made yet.

PLETE

Perform axis setting on the FSSB setting screen.

5139

FSSB : ERROR

Servo initialization did not terminate normally.

The optical cable may be defective, or there may be an error in connec-

tion to the amplifier or another module.

Check the optical cable and the connection status.

5155

NOT RESTART PROGRAM BY G05

During servo leaning control by G05, an attempt was made to perform

restart operation after feed hold or interlock. This restart operation can-

not be performed. (G05 leaning control terminates at the same time.)

5156

ILLEGAL AXIS OPERATION

In AI contour control mode, the controlled axis selection signal (PMC

(AICC)

axis control) changes.

(M series)

In AI contour control mode, the simple synchonous axis selection signal

changes.

ILLEGAL AXIS OPERATION

In AI look-ahead control mode, the controlled axis selection signal

(AICC)

(PMC axis control) changes.

(21i-M)

In AI look-ahead control mode, the simple synchonous axis selection

signal changes.

5157

PARAMETER ZERO (AICC)

Zero is set in the parameter for the maximum cutting feedrate (parame-

(M series)

ter No. 1422 or 1432).

Zero is set in the parameter for the acceleration/deceleration before in-

terpolation (parameter No. 1770 or 1771).

Set the parameter correctly.

856

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

5195

DIRECTION CAN NOT BE JUDGED

When the touch sensor with a single contact signal input is used in the

(T series)

direct input B function for tool offset measurement values, the stored

pulse direction is not constant. One of the following conditions exists:

· The stop state exists in offset write mode.

· Servo off state

· The direction varies.

· Movement takes place simultaneously along two axes.

5196

ILLEGAL OPERATION (HPCC)

Detach operation was performed in HPCC mode. (If detach operation

(M series)

is performed in HPCC mode, this alarm is issued after the currently

executed block terminates.)

5197

FSSB : OPEN TIME OUT

The CNC permitted FSSB to open, but FSSB was not opened.

5198

FSSB : ID DATA NOT READ

Temporary assignment failed, so amplifier initial ID information could not

be read.

5199

FINE TORQUE SENSING PARAME-

A parameter related to the fine torque sensing function is illegal.

TER

· The storage interval is invalid.

· An invalid axis number is set as the target axis.

Correct the parameter.

5212

SCREEN COPY : PARAMETER ER-

There is a parameter setting error. Check that 4 is set as the I/O channel.

ROR

5213

SCREEN COPY : COMMUNICATION

The memory card cannot be used. Check the memory card. (Check

ERROR

whether the memory card is write-protected or defective.)

5214

SCREEN COPY : DATA TRANSFER

Data transfer to the memory card failed.

ERROR

Check whether the memory card space is insufficient and whether the

memory card was removed during data transfer.

5218

ILLEGAL PARAMETER

(INCL.

There is an inclination compensation parameter setting error.

COMP)

Cause:

1. The number of pitch error compensation points between the nega-

tive (-) end and positive (+) end exceeds 128.

2. The relationship in magnitude among the inclination compensation

point numbers is incorrect.

3. An inclination compensation point is not located between the nega-

tive (-) end and positive (+) end of the pitch error compensation

points.

4. The amount of compensation per compensation point is too large or

too small.

Correct the parameter.

5219

CAN NOT RETURN

Manual intervention or return is not allowed during three-dimensional

coordinate conversion.

5220

REFERENCE POINT ADJUSTMENT

A parameter for automatically set a reference position is set. (Bit 2 of

MODE

parameter No. 1819 = 1)

Perform automatic setting.

(Position the machine at the reference position manually, then perform

manual reference position return.)

Supplementary: Automatic setting sets bit 2 of parameter No. 1819 to

5222

SRAM CORRECTABLE ERROR

The SRAM correctable error cannot be corrected.

Cause:

A memory problem occurred during memory initialization.

Action:

Replace the master printed circuit board (SRAM module).

857

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

5227

FILE NOT FOUND

A specified file is not found during communication with the built-in

Handy File.

5228

SAME NAME USED

There are duplicate file names in the built-in Handy File.

5229

WRITE PROTECTED

A floppy disk in the built-in Handy File is write protected.

5231

TOO MANY FILES

The number of files exceeds the limit during communication with the

built-in Handy File.

5232

DATA OVER-FLOW

There is not enough floppy disk space in the built-in Handy File.

5235

COMMUNICATION ERROR

A communication error occurred during communication with the built-in

Handy File.

5237

READ ERROR

A floppy disk in the built-in Handy File cannot be read from. The floppy

disk may be defective, or the head may be dirty. Alternatively, the Handy

File is defective.

5238

WRITE ERROR

A floppy disk in the built-in Handy File cannot be written to. The floppy

disk may be defective, or the head may be dirty. Alternatively, the Handy

File is defective.

5242

ILLEGAL AXIS NUMBER

The axis number of the synchronous master axis or slave axis is incor-

(M series)

rect. (This alarm is issued when flexible synchronization is turned on.)

Alternatively, the axis number of the slave axis is smaller than that of the

master axis.

5243

DATA OUT OF RANGE

The gear ratio is not set correctly.

(This alarm is issued when flexible

(M series)

synchronization is turned on.)

5244

TOO MANY DI ON

Even when an M code was encountered in automatic operation mode,

(M series)

the flexible synchronization mode signal was not driven on or off.

Check the ladder and M codes.

5245

OTHER AXIS ARE COMMANDED

One of the following command conditions was present during flexible

(M series)

synchronization or when flexible synchronization was turned on:

1. The synchronous master axis or slave axis is the EGB axis.

2. The synchronous master axis or slave axis is the chopping axis.

3. In reference position return mode

5251

ILLEGAL PARAMETER IN G54.2

A fixture offset parameter (No. 7580 to 7588) is illegal. Correct the pa-

(M series)

rameter.

5252

ILLEGAL P COMMAND IN G54.2

The P value specifying the offset number of a fixture offset is too large.

(M series)

Correct the program.

5257

G41/G42 NOT ALLOWED IN MDI

G41/G42 (cutter compensation C: M series) was specified in MDI

MODE

mode. (Depending on the setting of bit 4 of parameter No. 5008)

(M series)

G41/G42 NOT ALLOWED IN MDI

G41/G42 (tool-nose radius compensation: T series) was specified in

MODE

MDI mode. (Depending on the setting of bit 4 of parameter No. 5008)

(T series)

5300

SET ALL OFFSET DATAS AGAIN

After the inch/metric automatic conversion function (OIM: Bit 0 of pa-

rameter No. 5006) for tool offset data is enabled or disabled, all the tool

offset data must be reset. This message reminds the operator to reset

the data.

If this alarm is issued, reset all the tool offset data. Operating the ma-

chine without resetting the data will result in a malfunction.

5302

ILLEGAL COMMAND IN G68 MODE

A command to set the coordinate system is specified in the coordinate

system rotation mode.

858

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

5303

TOUCH PANEL ERROR

A touch panel error occurred.

Cause:

1. The touch panel is kept pressed.

2. The touch panel was pressed when power was turned on.

Remove the above causes, and turn on the power again.

5306

MODE CHANGE ERROR

In a one-touch macro call, mode switching at the time of activation is not

performed correctly.

5307

INTERNAL DATA OVER FLOW

In the following function, internal data exceeds the allowable range.

(M series)

1) Improvement of the rotation axis feedrate

5311

FSSB:ILLEGAL CONNECTION

A connection related to FSSB is illegal.

This alarm is issued when either of the following is found:

1. Two axes having adjacent servo axis numbers (parameter No.

1023), odd number and even number, are assigned to amplifiers to

which different FSSB systems are connected.

2. The system does not satisfy the requirements for performing HRV

control, and use of two pulse modules connected to different FSSB

systems having different FSSB current control cycles is specified.

5321

S-COMP. VALUE OVERFLOW

The straightness compensation value has exceeded the maximum val-

ue of 32767.After this alarm is issued, make a manual reference position

return.

5400

SPL:ILLEGAL AXIS COMMAND

An axis specified for spline interpolation or smooth interpolation is incor-

(M series)

rect.

If an axis that is not the spline axis is specified in spline interpolation

mode, this alarm is issued. The spline axis is the axis specified in a block

containing G06.1 or the next block. For smooth interpolation, the axis

specified in G5.1Q2 is incorrect.

5401

SPL:ILLEGAL COMMAND (M series)

In a G code mode in which specification of G06.1 is not permitted, G06.1

is specified.

5402

SPL:ILLEGAL AXIS MOVING

A movement is made along an axis that is not the spline interpolation

(M series)

axis.

For example, in three-dimensional tool compensation mode using an

offset vector of which components are the X-, Y-, and Z-axes, when

two-axis spline interpolation is performed with the two spline axes set

to the X- and Y-axes, a movement along the Z-axis occurs, resulting

in this alarm.

5403

SPL:CAN NOT MAKE VECTOR

Three-dimensional tool compensation vectors cannot be generated.

(M series)

· When a three-dimensional tool compensation vector is created for

the second or subsequent point, that point, previous point, and next

point are on the same straight line, and that straight line and the three-

dimensional tool compensation vector for the previous point are in

parallel.

· When a three-dimensional tool compensation vector is created at the

end point of smooth interpolation or spline interpolation, the end point

and the point two points before are the same.

5405

ILLEGAL PARAMETER IN G41.2/

The parameter setting that determines the relationship between the

G42.2 (M series)

rotation axis and rotation plane is incorrect.

5406

G41.3/G40 FORMAT ERROR

1) A G41.3 or G40 block contains a move command.

(M series)

2) A G1.3 block contains a G code or M code for which buffering is sup-

pressed.

859

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

5407

ILLEGAL COMMAND IN G41.3

1) A G code that belongs to group 01 except G00 and G01 is specified

(M series)

in G41.3 mode.

2) An offset command (a G code belonging to group 07) is specified in

G41.3 mode.

3) The block next to G41.3 (startup) contains no movement.

5408

G41.3 ILLEGAL START_UP

1) In a mode of group 01 except G00 and G01, G41.3 (startup) is speci-

(M series)

fied.

2) At startup, the included angle of the tool direction vector and move

direction vector is 0 or 180 degrees.

5409

ILLEGAL PARAMETER IN G41.3

The parameter setting (No. xxxx to xxxx) that determines the relation-

(M series)

ship between the rotation axis and rotation plane is incorrect.

5411

NURBS:ILLEGAL ORDER (M series)

The number of steps is specified incorrectly.

5412

NURBS:NO KNOT COMMAND

No knot is specified. Alternatively, in NURBS interpolation mode, a

(M series)

block not relating to NURBS interpolation is specified.

5413

NURBS:ILLEGAL AXIS COMMAND

An axis not specified with controlled points is specified in the first block.

(M series)

5414

NURBS:ILLEGAL KNOT (M series)

The number of blocks containing knots only is insufficient.

5415

NURBS:ILLEGAL CANCEL

Although NURBS interpolation is not completed yet, the NURBS inter-

(M series)

polation mode is turned off.

5416

NURBS:ILLEGAL MODE (M series)

A mode that cannot be used with NURBS interpolation mode is speci-

fied in NURBS interpolation mode.

5417

NURBS:ILLEGAL MULTI-KNOT

As many knots as the number of steps are not specified at the start and

(M series)

end points.

5418

NURBS:ILLEGAL KNOT VALUE

Knots do not increase in monotone.

(M series)

5420

ILLEGAL PARAMETER IN G43.4/

A parameter related to pivot tool length compensation is incorrect.

G43.5 (M series)

5421

ILLEGAL COMMAND IN G43.4/

In pivot tool length compensation (type 2) mode, a rotation axis is speci-

G43.5 (M series)

fied.

5422

EXCESS VELOCITY IN G43.4/G43.5

As a result of pivot tool length compensation, an attempt was made to

(M series)

move the tool along an axis at a feedrate exceeding the maximum cut-

ting feedrate.

5425

ILLEGAL OFFSET VALUE (M series)

The offset number is incorrect.

5430

ILLEGAL COMMAND IN 3-D CIR

In a modal state in which three-dimensional circular interpolation can-

(M series)

not be specified, a three-dimensional circular interpolation

(G02.4/G03.4) is specified. Alternatively, in three-dimensional circular

interpolation mode, a code that cannot be specified is specified.

5432

G02.4/G03.4 FORMAT ERROR

A three-dimensional circular interpolation command (G02.4/G03.4) is

(M series)

incorrect.

5433

MANUAL INTERVENTION IN 3-D

In three-dimensional circular interpolation mode (G02.4/G03.4), manu-

CIR (M series)

al intervention was made when the manual absolute switch was on.

5435

PARAMETER OUT OF RANGE

Incorrect parameter setting (set value range)

(TLAC) (M series)

5436

PARAMETER SETTING ERROR 1

Incorrect parameter setting (setting of the rotation axis)

(TLAC) (M series)

5437

PARAMETER SETTING ERROR 2

Incorrect parameter setting (setting of the tool axis)

(TLAC) (M series)

5440

ILLEGAL DRILLING AXIS

The drilling axis specified for the drilling canned cycle is incorrect.

SELECTED (M series)

The G code command block of the canned cycle does not specify the

Z point of the drilling axis. When there is a parallel axis with the drilling

axis, the parallel axis is also specified at the same time.

860

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

5445

CRC:MOTION IN G39 (M series)

Corner circular interpolation (G39) of cutter compensation is not speci-

fied alone but is specified with a move command.

5446

CRC:NO AVOIDANCE (M series)

Because there is no interference evade vector, the interference check

evade function of cutter compensation cannot evade interference.

5447

CRC:DANGEROUS AVOIDANCE

The interference check evade function of cutter compensation deter-

(M series)

mines that an evade operation will lead to danger.

5448

CRC:INTERFERENCE TO AVD.

In the interference check evade function of cutter compensation, a fur-

(M series)

ther interference occurs for an already created interference evade vec-

tor.

5452

IMPROPER G-CODE (5AXIS MODE)

A G code that cannot be specified is found. (5-axis mode)

(M series)

This alarm is issued when:

1) Three-dimensional cutter compensation (side-face offset and lead-

ing-edge offset) is applied during cutter compensation, or cutter

compensation is applied during three-dimensional cutter com-

pensation (side-face offset and leading-edge offset).

2) A leading-edge offset of three-dimensional cutter compensation is

applied during side-face offsetting of three-dimensional cutter com-

pensation, or a side-face offset of three-dimensional cutter com-

pensation is applied during leading-edge offsetting of three-dimen-

sional cutter compensation.

3) Tool axis direction tool length compensation is applied during tool

length compensation, or tool length compensation is applied during

tool axis direction tool length compensation.

4) Tool center point control is provided during tool length compensa-

tion, or tool length compensation is applied during tool center point

control.

5) Tool center point control is provided during tool axis direction tool

length compensation, or tool axis direction tool length compensation

is applied during tool center point control.

If this alarm is issued, cancel the relevant mode, then specify a differ-

ent mode.

5453

NOTE: G68 IS CANCELED (HPCC)

When bit 2 of parameter No. 5400 is set to 1, and a reset does not cancel

(M series)

G68, this alarm is issued at the time of program restart.

To release this alarm, press <RESET> and <CAN>. Once this operation

is performed, the alarm will not be issued at the next restart.

5455

ILLEGAL ACC. PARAMETER

A permissible acceleration parameter for optimum torque acceleration/

(M series)

deceleration is incorrect. The cause is one of the following:

1) The ratio of the deceleration rate to the acceleration rate is below the

limit.

2) The time required for deceleration to a speed of 0 exceeds the maxi-

mum value.

NOTE

HPCC designates High Precision Contour Control.

AICC designates AI Contour Control.

861

A. ALARM LIST

APPENDIX

B-63525EN/02

(2) Background edit alarm

Number

Message

Contents

???

BP/S alarm

BP/S alarm occurs in the same number as the P/S alarm that occurs in

ordinary program edit. (070, 071, 072, 073, 074 085,086,087 etc.)

140

BP/S alarm

It was attempted to select or delete in the background a program being

selected in the foreground. (Note)

Use background editing correctly.

NOTE

Alarm in background edit is displayed in the key input line of the background edit screen instead

of the ordinary alarm screen and is resettable by any of the MDI key operation.

(3) Absolute pulse coder (APC) alarm

Number

Message

Contents

300

APC alarm: nth-axis origin return

Manual reference position return is required for the nth-axis (n=1 - 8).

301

APC alarm: nth-axis communication

nth-axis (n=1 - 8) APC communication error. Failure in data transmis-

sion

Possible causes include a faulty APC, cable, or servo interface module.

302

APC alarm: nth-axis over time

nth-axis (n=1 - 8) APC overtime error.

Failure in data transmission.

Possible causes include a faulty APC, cable, or servo interface module.

303

APC alarm: nth-axis framing

nth-axis (n=1 - 8) APC framing error. Failure in data transmission.

Possible causes include a faulty APC, cable, or servo interface module.

304

APC alarm: nth-axis parity

nth-axis (n=1 - 8) APC parity error.

Failure in data transmission.

Possible causes include a faulty APC, cable, or servo interface module.

305

APC alarm: nth-axis pulse error

nth-axis (n=1 - 8) APC pulse error alarm.

APC alarm.APC or cable may be faulty.

306

APC alarm: nth-axis battery

nth-axis (n=1 - 8) APC battery voltage has decreased to a low level so

voltage 0

that the data cannot be held.

APC alarm. Battery or cable may be faulty.

307

APC alarm: nth-axis battery low 1

nth-axis (n=1 - 8) axis APC battery voltage reaches a level where the

battery must be renewed.

APC alarm. Replace the battery.

308

APC alarm: nth-axis battery low 2

nth-axis (n=1 - 8) APC battery voltage has reached a level where the

battery must be renewed (including when power is OFF).

APC alarm .Replace battery.

309

APC ALARM:

Return to the origin has been attempted without first rotating the motor

n AXIS ZRN IMPOSSIBL

one or more times. Before returning to the origin, rotate the motor one

or more times then turn off the power.

(4) Inductsyn alarms

Number

Message

Description

330

INDUCTOSYN:DATA ALARM

The absolute-position data (offset data) from Inductosyn cannot be

detected.

331

INDUCTOSYN:ILLEGAL PRM

Parameter No. 1874, 1875, or 1876 is set to 0.

862

B-63525EN/02

APPENDIX

A. ALARM LIST

(5) Serial pulse coder

(SPC) alarms

No.

Message

Description

360

n AXIS : ABNORMAL CHECKSUM

A checksum error occurred in the built-in pulse coder.

(INT)

361

n AXIS : ABNORMAL PHASE DATA

A phase data error occurred in the built-in pulse coder.

(INT)

362

n AXIS : ABNORMAL REV.DATA

A rotation speed count error occurred in the built-in pulse coder.

(INT)

363

n AXIS : ABNORMAL CLOCK (INT)

A clock error occurred in the built-in pulse coder.

364

n AXIS : SOFT PHASE ALARM (INT)

The digital servo software detected invalid data in the built-in pulse

coder.

365

n AXIS : BROKEN LED (INT)

An LED error occurred in the built-in pulse coder.

366

n AXIS : PULSE MISS (INT)

A pulse error occurred in the built-in pulse coder.

367

n AXIS : COUNT MISS (INT)

A count error occurred in the built-in pulse coder.

368

n AXIS : SERIAL DATA ERROR

Communication data from the built-in pulse coder cannot be re-

(INT)

ceived.

369

n AXIS : DATA TRANS. ERROR

A CRC or stop bit error occurred in the communication data being

(INT)

received from the built-in pulse coder.

380

n AXIS : BROKEN LED (EXT)

The LED of separate detector is erroneous.

381

n AXIS : ABNORMAL PHASE

A phase data error occurred in the separate linear scale.

(EXT LIN)

382

n AXIS : COUNT MISS (EXT)

A pulse error occurred in the separate detector.

383

n AXIS : PULSE MISS (EXT)

A count error occurred in the separate detector.

384

n AXIS : SOFT PHASE ALARM

The digital servo software detected invalid data in the separate de-

(EXT)

tector.

385

n AXIS : SERIAL DATA ERROR

Communication data from the separate detector cannot be received.

(EXT)

386

n AXIS : DATA TRANS. ERROR

A CRC or stop bit error occurred in the communication data being

(EXT)

received from the separate detector.

387

n AXIS : ABNORMAL ENCODER

An error occurs in the separate detector. For details, contact the

(EXT)

manufacturer of the scale.

D The details of serial

The details of serial pulse coder alarm are displayed in the diagnosis

pulse coder alarm

display (No. 202 and No.203) as shown below.

202

CSA

BLA

PHA

PCA

BZA

CKA

SPH

#6 (CSA) : The serial pulse coder is defective. Replace it.

#5 (BLA) : The battery voltage is low. Replace the batteries.

#4 (PHA) : The serial pulse coder or feedback cable is defective. Replace the serial

pulse coder or cable.

#3 (PCA) : The serial pulse coder is defective. Replace it.

#2 (BZA) : The pulse coder was supplied with power for the first time.

Make sure that the batteries are connected.

Turn the power off, then turn it on again and perform a reference position

return.

#1 (CKA) : The serial pulse coder is defective. Replace it.

#0 (SPH) : The serial pulse coder or feedback cable is defective. Replace the serial

pulse coder or cable.

863

A. ALARM LIST

APPENDIX

B-63525EN/02

203

DTE

CRC

STB

PRM

#7 (DTE) : The serial pulse coder encountered a communication error.

The pulse coder, feedbak cable, or feedback receiver circuit is defective.

Replace the pulse coder, feedback cable, or NC-axis board

#6 (CRC) : The serial pulse coder encountered a communication error.

The pulse coder, feedback cable, or feedback receiver circuit is defective.

Replace the pulse coder, feedback cable, or NC-axis board.

#5 (STB) : The serial pulse coder encountered a communication error.

The pulse coder, feedback cable, or feedback receiver circuit is defective.

Replace the pulse coder, feedback cable, or NC-axis board.

#4 (PRM) : An invalid parameter was found. Alarm No.

417

(invalid servo

parameter) is also issued.

(6) Servo alarms(1/2)

Number

Message

Contents

401

SERVO ALARM: n-TH AXIS VRDY

The n-th axis (axis 1-8) servo amplifier READY signal (DRDY) went off.

OFF

Refer to procedure of trouble shooting.

402

SERVO ALARM: SV CARD NOT EX-

The axis control card is not provided.

IST

403

SERVO ALARM: CARD/SOFT MIS-

The combination of the axis control card and servo software is illegal.

MATCH

The possible causes are as follows:

· A correct axis control card is not provided.

· Correct servo software is not installed on flash memory.

404

SERVO ALARM: n-TH AXIS VRDY

Even though the n-th axis (axis 1-8) READY signal (MCON) went off,

the servo amplifier READY signal (DRDY) is still on. Or, when the power

was turned on, DRDY went on even though MCON was off.

Check that the servo interface module and servo amp are connected.

405

SERVO ALARM: (ZERO POINT RE-

Position control system fault. Due to an NC or servo system fault in the

TURN FAULT)

reference position return, there is the possibility that reference position

return could not be executed correctly. Try again from the manual refer-

ence position return.

407

SERVO ALARM: EXCESS ERROR

The following error occurred during simple synchronous control:

The difference in machine coordinates between the synchronized axes

exceeds the value set in parameter No. 8314.

409

SERVO ALARM: n AXIS TORQUE

Abnormal servo motor load has been detected. Alternatively, abnormal

ALM

spindle motor load has been detected in Cs mode.

410

SERVO ALARM: n-TH AXIS - EX-

One of the following errors occurred:

CESS ERROR

1) The positional deviation value when the n-th axis stops exceeds the

value set in parameter No. 1829.

2) In simple synchronous control, the compensation amount for syn-

chronization exceeds the value set in parameter No. 8325.

This alarm is issued only for the slave axis.

411

SERVO ALARM: n-TH AXIS - EX-

The position deviation value when the n-th axis (axis 1-8) moves is

CESS ERROR

larger than the set value.

Refer to procedure of trouble shooting.

413

SERVO ALARM: n-th AXIS - LSI

The contents of the error register for the n-th axis (axis 1-8) exceeded

OVERFLOW

"2³¹ power. This error usually occurs as the result of an improperly set

parameters.

864

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

415

SERVO ALARM: n-TH AXIS - EX-

A speed higher than 524288000 units/s was attempted to be set in the

CESS SHIFT

n-th axis (axis 1-8). This error occurs as the result of improperly set

CMR.

417

SERVO ALARM: n-TH AXIS - PA-

This alarm occurs when the n-th axis (axis 1-8) is in one of the condi-

RAMETER INCORRECT

tions listed below. (Digital servo system alarm)

1) The value set in Parameter No. 2020 (motor form) is out of the speci-

fied limit.

2) A proper value (111 or -111) is not set in parameter No.2022 (motor

revolution direction).

3) Illegal data (a value below 0, etc.) was set in parameter No. 2023

(number of speed feedback pulses per motor revolution).

4) Illegal data (a value below 0, etc.) was set in parameter No. 2024

(number of position feedback pulses per motor revolution).

5) Parameters No. 2084 and No. 2085 (flexible field gear rate) have not

been set.

6) A value outside the limit of {1 to the number of control axes} or a non-

continuous value (Parameter 1023 (servo axis number) contains a

value out of the range from 1 to the number of axes, or an isolated

value (for example, 4 not prceded by 3).was set in parameter No.

1023 (servo axisnumber).

7) A torque control parameter is set incorrectly in PMC axis control.

(The torque constant parameter is set to 0.)

420

SERVO ALARM: n AXIS SYNC

During simple synchronous control, the difference between the torque

TORQUE

commands for the master and slave axes exceeded the value set in pa-

(M series)

rameter No. 2031.

421

SERVO ALARM: n AXIS EXCESS

The difference between the errors in the semi-closed loop and closed

ER (D)

loop has become excessive during dual position feedback. Check the

values of the dual position conversion coefficients in parameters No.

2078 and 2079.

422

SERVO ALARM: n AXIS

In torque control of PMC axis control, a specified allowable speed

has been exceeded.

423

SERVO ALARM: n AXIS

In torque control of PMC axis control, the parameter-set allowable

cumulative travel distance has been exceeded.

430

n AXIS : SV. MOTOR OVERHEAT

A servo motor overheat occurred.

431

n AXIS : CNV. OVERLOAD

1) PSM: Overheat occurred.

2) β series SVU: Overheat occurred.

432

n AXIS : CNV. LOW VOLT CON-

1) PSM: Control power voltage has dropped.

TROL

2) PSMR: The control power supply voltage has dropped.

3) β series SVU: The control power supply voltage has dropped.

433

n AXIS : CNV. LOW VOLT DC LINK

1) PSM: The DC link voltage has dropped.

2) PSMR: The DC link voltage has dropped.

3) α series SVU: The DC link voltage has dropped.

4) β series SVU: The DC link voltage has dropped.

434

n AXIS : INV. LOW VOLT CONTROL

SVM: The control power supply voltage has dropped.

435

n AXIS : INV. LOW VOLT DC LINK

SVM: The DC link voltage has dropped.

436

n AXIS : SOFTTHERMAL (OVC)

The digital servo software detected the soft thermal state (OVC).

437

n AXIS : CNV. OVERCURRENT

PSM: Overcurrent flowed into the input circuit.

POWER

865

A. ALARM LIST

APPENDIX

B-63525EN/02

Number

Message

Contents

438

n AXIS : INV. ABNORMAL CUR-

1) SVM: The motor current is too high.

RENT

2) α series SVU: The motor current is too high.

3) β series SVU: The motor current is too high.

439

n AXIS : CNV. OVERVOLT POWER

1) PSM: The DC link voltage is too high.

2) PSMR: The DC link voltage is too high.

3) α series SVU: The C link voltage is too high.

4) β series SVU: The link voltage is too high.

440

n AXIS : CNV. EX DECELERATION

1) PSMR: The regenerative discharge amount is too large.

POW.

2) α series SVU: The regenerative discharge amount is too large. Al-

ternatively, the regenerative discharge circuit is abnormal.

441

n AXIS : ABNORMAL CURRENT

The digital servo software detected an abnormality in the motor cur-

OFFSET

rent detection circuit.

442

n AXIS : CNV. CHARGE FAILURE

1) PSM: The spare discharge circuit of the DC link is abnormal.

2) PSMR: The spare discharge circuit of the DC link is abnormal.

443

n AXIS : CNV. COOLING FAN FAIL-

1) PSM: The internal stirring fan failed.

URE

2) PSMR: The internal stirring fan failed.

3) β series SVU: The internal stirring fan failed.

444

n AXIS : INV. COOLING FAN FAIL-

SVM: The internal stirring fan failed.

URE

445

n AXIS : SOFT DISCONNECT

The digital servo software detected a broken wire in the pulse coder.

ALARM

446

n AXIS : HARD DISCONNECT

A broken wire in the built-in pulse coder was detected by hardware.

ALARM

447

n AXIS : HARD DISCONNECT (EXT)

A broken wire in the separate detector was detected by hardware.

448

n AXIS : UNMATCHED FEEDBACK

The sign of feedback data from the built-in pulse coder differs from

ALARM

that of feedback data from the separate detector.

449

n AXIS : INV. IPM ALARM

1) SVM: IPM (intelligent power module) detected an alarm.

2) α series SVU: IPM (intelligent power module) detected an alarm.

453

n AXIS : SPC SOFT DISCONNECT

Software disconnection alarm of the α pulse coder.

ALARM

Turn off the power to the CNC, then remove and insert the pulse cod-

er cable. If this alarm is issued again, replace the pulse coder.

456

ILLEGAL CURRENT LOOP

The current control cycle settings (parameter No. 2004, bit 0 of pa-

rameter No. 2003, and bit 0 of parameter No. 2013) are incorrect.

Possible problems are as follows.

- For the two axes whose servo axis numbers (settings of parame-

ter No. 1023) are an odd number followed by an even number (a

pair of axes 1 and 2 or axes 5 and 6, for example), a different

current control cycle is set for each of the axes.

- The requirements for slaves needed for the set current control

cycle, including the number, type, and connection method of

them, are not satisfied.

457

ILLEGAL HI HRV (250US)

Use of high-speed HRV is specified although the current control

cycle is 200 µs.

458

CURRENT LOOP ERROR

The current control cycle setting does not match the actual current

control cycle.

459

HI HRV SETTING ERROR

Of two axes having adjacent servo axis numbers (parameter No.

1023), odd number and even number, high-speed HRV control can

be performed for one axis and not for the other.

866

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

460

n AXIS : FSSB DISCONNECT

FSSB communication was disconnected suddenly. The possible

causes are as follows:

1) The FSSB communication cable was disconnected or broken.

2) The power to the amplifier was turned off suddenly.

3) A low-voltage alarm was issued by the amplifier.

461

n AXIS : ILLEGAL AMP INTERFACE

The axes of the 2-axis amplifier were assigned to the fast type inter-

face.

462

n AXIS : SEND CNC DATA FAILED

Because of an FSSB communication error, a slave could not receive

correct data.

463

n AXIS : SEND SLAVE DATA

Because of an FSSB communication error, the servo system could

FAILED

not receive correct data.

464

n AXIS : WRITE ID DATA FAILED

An attempt was made to write maintenance information on the ampli-

fier maintenance screen, but it failed.

465

n AXIS : READ ID DATA FAILED

At power-up, amplifier initial ID information could not be read.

466

n AXIS : MOTOR/AMP COMBINA-

The maximum current rating for the amplifier does not match that for

TION

the motor.

467

n AXIS : ILLEGAL SETTING OF

The servo function for the following has not been enabled when an

AXIS

axis occupying a single DSP (corresponding to two ordinary axes) is

specified on the axis setting screen.

1. Learning control (bit 5 of parameter No. 2008 = 1)

2. High-speed current loop (bit 0 of parameter No. 2004 = 1)

3. High-speed interface axis (bit 4 of parameter No. 2005 = 1)

468

HI HRV SETTING ERROR(AMP)

Use of high-speed HRV is specified for a controlled axis of an ampli-

fier which does not support high-speed HRV.

D Details of servo alarm

The details of servo alarm are displayed in the diagnosis display (No. 200

and No.204) as shown below.

200

OVL

OVC

HCA

HVA

DCA

FBA

OFA

#7 (OVL) : An overload alarm is being generated.

(The details are indicated in diagnostic data No.201).

#6 (LV) : A low voltage alarm is being generated in servo amp.

Check LED.

#5 (OVC) : A overcurrent alarm is being generated inside of digital servo.

#4 (HCA) : An abnormal current alarm is being generated in servo amp.

Check LED.

#3 (HVA) : An overvoltage alarm is being generated in servo amp.

Check LED.

#2 (DCA) : A regenerative discharge circuit alarm is being generated in servo amp.

Check LED.

#1 (FBA) : A disconnection alarm is being generated.

(The details are indicated in diagnostic data No. 201)

#0 (OFA) : An overflow alarm is being generated inside of digital servo.

867

A. ALARM LIST

APPENDIX

B-63525EN/02

201

ALD

EXP

When OVL equal 1 in diagnostic data No.200 (servo alarm No. 400 is

being generated):

#7 (ALD)

1 : Motor overheating

0 : Amplifier overheating

When FBAL equal 1 in diagnostic data No.200 (servo alarm No. 416 is

being generated):

ALD

EXP

Alarm details

Built-in pulse coder disconnection (hardware)

Separately installed pulse coder disconnection

(hardware)

Pulse coder is not connected due to software.

204

OFS

MCC

LDA

PMS

#6 (OFS) : A current conversion error has occured in the digital servo.

#5 (MCC) : A magnetic contactor contact in the servo amplifier has welded.

#4 (LDA) : The LED indicates that serial pulse coder C is defective

#3 (PMS) : A feedback pulse error has occured because the feedback cable is

defective.

(7)

Over travel alarms

Number

Message

Contents

500

OVER TRAVEL : +n

Exceeded the n-th axis (axis 1-8) + side stored stroke check I.

(Parameter No.1320 or 1326 NOTE)

501

OVER TRAVEL : -n

Exceeded the n-th axis (axis 1-8) - side stored stroke check I.

(Parameter No.1321 or 1327 NOTE)

502

OVER TRAVEL : +n

Exceeded the n-th axis (axis 1-8) + side stored stroke check II.

(Parameter No.1322 )

503

OVER TRAVEL : -n

Exceeded the n-th axis (axis 1-8) - side stored stroke check II.

(Parameter No.1323)

504

OVER TRAVEL : +n

Exceeded the n-th axis (axis 1-8) + side stored stroke check III.

(Parameter No.1324 )

505

OVER TRAVEL : -n

Exceeded the n-th axis (axis 1-8) - side stored stroke check III.

(Parameter No.1325 )

506

OVER TRAVEL : +n

Exceeded the n-th axis (axis 1-8) + side hardware OT.

507

OVER TRAVEL : -n

Exceeded the n-th axis (axis 1-8) - side hardware OT.

508

INTERFERENCE: +n

A tool moving in the positive direction along the n axis has fouled anoth-

(T series (two-path control))

er tool post.

509

INTERFERENCE: -n

A tool moving in the negative direction along the n axis has fouled anoth-

(T series (two-path control))

er tool post.

510

OVER TRAVEL: +n

Alarm for stroke check prior to movement. The end point specified in a

block falls within the forbidden area defined with the stroke check in the

positive direction along the N axis. Correct the program.

511

OVER TRAVEL: -n

Alarm for stroke check prior to movement. The end point specified in a

block falls within the forbidden area defined with the stroke check in the

negative direction along the N axis. Correct the program.

868

B-63525EN/02

APPENDIX

A. ALARM LIST

Number

Message

Contents

514

INTERFERENCE : +n

The rotation area interference check function found interference on the

plus side of the n axis.

515

INTERFERENCE : -n

The rotation area interference check function found interference on the

minus side of the n axis.

NOTE

Parameters 1326 and 1327 are effective when EXLM(stroke check switch signal) is on.

(8) Servo alarms

Number

Message

Contents

600

n AXIS: INV. DC LINK OVER CUR-

DC link current is too large.

RENT

601

n AXIS: INV. RADIATOR FAN FAIL-

The external dissipator stirring fan failed.

URE

602

n AXIS: INV. OVERHEAT

The servo amplifier was overheated.

603

n AXIS: INV. IPM ALARM(OH)

The IPM (intelligent power module) detected an overheat alarm.

604

n AXIS: AMP. COMMUNICATION

Communication between the SVM and the PSM failed.

ERROR

605

n AXIS: CNV. EX. DISCHARGE

PSMR: Regenerative power is too large.

POW.

606

n AXIS: CNV. RADIATOR FAN FAIL-

PSM: The external dissipator stirring fan failed.

URE

PSMR: The external dissipator stirring fan failed.

607

n AXIS: CNV. SINGLE PHASE FAIL-

PSM: Input voltage is in the open-phase condition.

URE

PSMR: Input voltage is in the open-phase condition.

(9) Overheat alarms

Number

Message

Contents

700

OVERHEAT: CONTROL UNIT

Control unit overheat

Check that the fan motor operates normally, and clean the air filter.

701

OVERHEAT: FAN MOTOR

The fan motor on the top of the cabinet for the contorl unit is overheated.

Check the operation of the fan motor and replace the motor if necessary.

704

OVERHEAT: SPINDLE

Spindle overheat in the spindle fluctuation detection

(1) If the cutting load is heavy, relieve the cutting condition.

(2) Check whether the cutting tool is share.

(3) Another possible cause is a faulty spindle amp.

(10)Rigid tapping alarms

Number

Message

Contents

740

RIGID TAP ALARM: EXCESS ER-

The positional deviation of the stopped spindle has exceeded the set

ROR

value during rigid tapping.

741

RIGID TAP ALARM: EXCESS ER-

The positional deviation of the moving spindle has exceeded the set val-

ROR

ue during rigid tapping.

742

RIGID TAP ALARM: LSI OVER-

An LSI overflow has occurred for the spindle during rigid tapping.

FLOW

869

A. ALARM LIST

APPENDIX

B-63525EN/02

(11) Serial spindle alarms

Number

Message

Contents

749

S-SPINDLE LSI ERROR

It is serial communication error while system is executing after power

supply on. Following reasons can be considered.

1) Optical cable connection is fault or cable is not connected or cable

is cut.

2) MAIN CPU board or option 2 board is fault.

3) Spindle amp. printed board is fault.

4) The spindle amplifier is under an abnormal condition. (The SPM in-

dication is A, A1, A2, or the like, depending on the type of the ab-

normality.)

If this alarm occurs when CNC power supply is turned on or when this

alarm can not be cleared even if CNC is reset, turn off the power supply

also turn off the power supply in spindle side.

If the spindle amplifier is under an abnormal condition, check the SPM

indication (A, A1, A2, or the like). Then, refer to the FANUC SERVO MO-

TOR ai series MAINTENANCE MANUAL (B-65285EN) or FANUC

SERVO MOTOR a series MAINTENANCE MANUAL (B-65165E) to

solve the problem.

750

SPINDLE SERIAL LINK START

This alarm is generated when the spindle control unit is not ready for

FAULT

starting correctly when the power is turned on in the system with the

serial spindle.

The four reasons can be considered as follows:

1) An improperly connected optic cable, or the spindle control unit’s

power is OFF.

2) When the NC power was turned on under alarm conditions other

than SU-01 or AL-24 which are shown on the LED display of the

spindle control unit.

In this case, turn the spindle amplifier power off once and perform

startup again.

3) Other reasons (improper combination of hardware)

This alarm does not occur after the system including the spindle con-

trol unit is activated.

4) The second spindle (when SP2, bit 4 of parameter No. 3701, is 1)

is in one of the above conditions 1) to 3).

See diagnostic display No. 409 for details.

752

FIRST SPINDLE MODE CHANGE

This alarm is generated if the system does not properly terminate a

FAULT

mode change. The modes include the Cs contouring, spindle position-

ing, rigid tapping, and spindle control modes. The alarm is activated if

the spindle control unit does not respond correctly to the mode change

command issued by the NC.

754

SPINDLE-1 ABNORMAL TORQUE

Abnormal first spindle motor load has been detected.

ALM

762

SECOND SPINDLE MODE

Refer to alarm No. 752.(For 2nd axis)

CHANGE FAULT

764

SPINDLE-2 ABNORMAL TORQUE

Same as alarm No. 754 (for the second spindle)

ALM

772

SPINDLE-3 MODE CHANGE ER-

Same as alarm No. 752 (for the third spindle)

ROR

774

SPINDLE-3 ABNORMAL TORQUE

Same as alarm No. 754 (for the third spindle)

ALM

782

SPINDLE-4 MODE CHANGE ER-

Same as alarm number 752 (for the fourth spindle)

ROR

784

SPINDLE-4 ABNORMAL TORQUE

Same as alarm number 754 (for the fourth spindle)

ALM

870

B-63525EN/02

APPENDIX

A. ALARM LIST

D The details of spindle

alarm No.750

1st and 2nd spindles

409

SPE

S2E

S1E

SHE

#3 (SPE)

0 :

In the spindle serial control, the serial spindle parameters fulfill the

spindle unit startup conditions.

1 :

In the spindle serial control, the serial spindle parameters do not fulfill

the spindle unit startup conditions.

#2 (S2E)

0 :

The second spindle is normal during the spindle serial control startup.

1 :

The second spindle was detected to have a fault during the spindle

serial control startup.

#1 (S1E)

0 :

The first spindle is normal during the spindle serial control startup.

1 :

The first spindle was detected to have a fault during the spindle axis

serial control startup.

#0 (SHE)

0 :

The serial communications module in the CNC is normal.

1 :

The serial communications module in the CNC was detected to have a

fault.

3rd and 4th spindles

The details of spindle alarm No. 750 are displayed in the diagnosis display

(No. 409) as shown below.

409

SPE

S4E

S3E

SHE

#3 (SPE)

0 : In the spindle serial control, the serial spindle parameters fulfill the

spindle unit startup conditions.

1 : In the spindle serial control, the serial spindle parameters do not fulfill

the spindle unit startup conditions.

#2 (S2E)

0 : The fourth spindle is normal during the spindle serial control startup.

1 : The fourth spindle was detected to have a fault during the spindle

serial control startup.

#1 (S1E)

0 : The third spindle is normal during the spindle serial control startup.

1 : The third spindle was detected to have a fault during the spindle axis

serial control startup.

#0 (SHE)

0 : The serial communications module in the CNC is normal.

1 : The serial communications module in the CNC was detected to have a

fault.

871

FANUC Series 16i/160i/160is-MODEL B, Series 18i/180i/180is-MODEL B, Series 21i/210i/210is-MODEL B. MAINTENANCE MANAUL - page 30
