FANUC Series 16i/160i/160is-MODEL B, Series 18i/180i/180is-MODEL B, Series 21i/210i/210is-MODEL B. MAINTENANCE MANAUL - page 15

5. MATTERS COMMON TO BOTH LCD-MOUNTED TYPE

AND STAND-ALONE TYPE i SERIES (HARDWARE)

B-63525EN/02

Fan retaining

metal sheet

Perform wiring as shown below.

Be sure to install

the fan in the cor-

rect direction.

Note the

cabling

Air Flow

direction.

Two screws (B)

A08B-0082-B031 to -B038, -B041 to -B048, -B051 to -B057

A13B-0193-B031 to -B034, -B041 to -B044, -B051 to -B054

392

5. MATTERS COMMON TO BOTH LCD-MOUNTED TYPE

B-63525EN/02

AND STAND-ALONE TYPE i SERIES (HARDWARE)

D Replacing the fan for

(1) Make sure the CNC display unit with PC functions or the PANEL i is

HDD

powered off.

(2) Remove the fan connector (CN7) on the main board. Since the

connector is fixed with a latch, pull out the connector while lifting the

connector lightly to open the latch.

(3) Loosen the two screws that retain the fan, then remove it.

(4) Retain a new fan with the two screws, then connect the cable to the

connector (CN7).

CN7

Fan

Two screws

Fig 5.10.3 Replacing the FAN for HDD

5.10.4

LCD back-light can not be replaced for CNC display unit with PC

functions or PANEL i.

Replacing the LCD

Back-Light

393

5. MATTERS COMMON TO BOTH LCD-MOUNTED TYPE

AND STAND-ALONE TYPE i SERIES (HARDWARE)

B-63525EN/02

5.10.5

For the CNC display unit with PC functions or the PANEL i, the surface

of the touch panel is covered with the protection sheet to protect it. When

Replacing the Touch

there are flaws and contamination on this protection sheet that make the

Panel Protection Sheet

screen hard to read, replace the protection sheet. Prepare the following

items.

D Ordering number

Item

Ordering number

Touch panel

For 10.4” LCD (with touch panel and

A02B-0236-K110

protection sheet

soft keys)

For 10.4” LCD (with touch panel, with-

A02B-0236-K130

out soft keys)

For 12.1” LCD

A02B-0236-K118

For 15.0” LCD

A08B-0082-K020

D Replacing method

See Section 5.4, for replacing the protection sheet.

394

5. MATTERS COMMON TO BOTH LCD-MOUNTED TYPE

B-63525EN/02

AND STAND-ALONE TYPE i SERIES (HARDWARE)

5.11

REPLACING THE

MAINTENANCE

PARTS OF CNC

DISPLAY UNIT FOR is

SERIES CNC

5.11.1

Replacing Procedure

WARNING

of Mother Board

Only those personnel who were well trained for

maintenance and safety can perform the replacement.

When removing the board with the cabinet open, be careful

not to touch the part containing high-voltage circuits

(

indicated by the electric shock mark and covered with

the electric shock prevention sheet). If you touch the part

when the sheet comes off, you receive an electric shock.

<1> Loosen the four screws that retain the case, then remove the case.

At this time, do not disconnect the cables for the fan and battery.

395

5. MATTERS COMMON TO BOTH LCD-MOUNTED TYPE

AND STAND-ALONE TYPE i SERIES (HARDWARE)

B-63525EN/02

<2> Disconnect the cables from PCMCIA2

(PCMCIA interface

connector), CN8 (video signal interface connector), and CN2 (soft

key connector) located on the mother board. When the touch panel

is attached, also disconnect TP1 (touch panel connector). Remove the

screws that retain the mother board. Since connector CN3 (inverter

connection connector) directly engages the mother board and the

inverter printed circuit board, remove the mother board while sliding

it downward.

: Location of screw hole

CN3

CN8

PCMCIA2

Mother board

CN2

<3> To install the mother board, reverse steps <1> and <2>.

5.11.2

Replacing the Fuse

WARNING

Before replacing the fuse, eliminate the cause by which the

fuse blew.

Therefore, only those personnel who were well trained for

maintenance and safety can perform the replacement.

When replacing the fuse with the cabinet open, be careful

not to touch the part containing high-voltage circuits

(

indicated by the electric shock mark and covered with

the electric shock prevention sheet). If you touch the part

when the sheet comes off, you receive an electric shock.

D Ordering number of fuse

A02B-0236-K100

396

5. MATTERS COMMON TO BOTH LCD-MOUNTED TYPE

B-63525EN/02

AND STAND-ALONE TYPE i SERIES (HARDWARE)

D Location of Fuse

Rear of units

Fuse

Since the display unit for the is series CNC has no battery, replacement

5.11.3

is not required.

Replacing the Battery

5.11.4

Replacing the Fan

Motor

D Ordering number of fan

motor

Unit

Ordering number

Required number

CNC display unit for is series CNC

A02B-0236-K120

2

D Replacing method

See Section 2.9, ”REPLACING FAN MOTORS” for replacing the fan

motor.

397

5. MATTERS COMMON TO BOTH LCD-MOUNTED TYPE

AND STAND-ALONE TYPE i SERIES (HARDWARE)

B-63525EN/02

5.11.5

LCD back-light can not be replaced for CNC display unit for is series

CNC.

Replacing the LCD

Back-Light

5.11.6

For the LCD display unit with a touch panel, the surface of the touch panel

is covered with the protection sheet to protect it. When there are flaws and

Replacing the Touch

contamination on this protection sheet that make the screen hard to read,

Panel Protection Sheet

replace the protection sheet. Prepare the following items.

Item

Ordering number

Touch panel

For 10.4” LCD (with touch panel and

A02B-0236-K110

protection sheet

soft keys)

For 10.4” LCD (with touch panel)

A02B-0236-K130

D See Section 5.4, ”LIQUID CRYSTAL DISPLAY (LCD)” for the

replacement procedure.

5.11.7

See Section 3.13, ”BACKUP UNIT” for details on the backup unit.

When the LED (LEDP) on the main printed circuit board lights, do not

Backup Unit

touch any parts in the display unit for the is series CNC and the backup

unit. The display unit for the is series CNC operates for about 12 seconds

after the main power is turned off.

398

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

6.1

SETTING

PARAMETERS

FOR INPUT/OUTPUT

D Setting procedure of

Parameter writing is enabled with following steps 1 to 3.

parameters

1.

Set to MDI mode or emergency stop state.

OFFSET

2.

Press

SETTING

key several times or press soft key [SETING] to display

SETTING (HANDY) screen.

3.

Set the cursor to PARAMETER WRITE and, press

1

and

INPUT

keys in this order. Here alarm 100 will be displayed.

4.

Press

SYSTEM

key several times to display the following screen.

PARAMETER (SETTING)

O1234N12345

0000

SEQ

INI ISO TVC

0

0

0

0

0

0

0

0

0001

FCV

0

0

0

0

0

0

0

0

0012

RMV

MIR

X

0

0

0

0

0

0

0

0

Y

0

0

0

0

0

0

0

0

Z

0

0

0

0

0

0

0

0

B

0

0

0

0

0

0

0

0

0020 I/O CHANNEL

S

0 T0000

REF **** *** ***

10:15:30

[ F SRH ][ READ

][ PUNCH ][DELETE ][

]

To make the cursor display in bit unit,

press the cursor key

or

5.

Press soft key[(OPRT)] and the following operation menu

is

displayed.

1) Soft key [NO. SRH] : Searched by number.

Examination) Parameter number → [NO. SRH].

2) Soft key [ON : 1] : Item with cursor position is set to 1

(bit parameter)

3) Soft key [OFF : 0] : Item with cursor position is set to 0

(bit parameter)

4) Soft key [+INPUT] : Input value is added to the value at cursor

(word type)

5) Soft key [INPUT] : Input value is replaced with the value at

cursor (word type)

6) Soft key [READ] : Parameters are input from reader/puncher

interface.

7) Soft key [PUNCH] : Parameters are output to reader/puncher

interface.

400

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

6.

After the parameters have been input, set PARAMETER WRITE on

the SETTING screen to 0. Press

RESET

to release alram 100.

7.

Convenient method

1)

To change parameters in bit unit, press cursor key

or

,

then the cursor becomes bit length and you can set parameters bit

by bit (Bit parameter only).

2)

To set data consecutively, use

EOB

key.

(Ex.1)

1

2

3

4

EOB

4

5

6

7

EOB

9

9

9

9

INPUT

This key sequence sets data as follows:

0

1234

0

⇒

4567

0

9999

0

0

(Ex.2)

1

2

3

4

EOB

EOB

9

9

9

9

INPUT

This key sequence sets data as follows:

0

1234

0

⇒

0

0

9999

0

0

3)

To set the same data sequentially, press

=

(Ex.)

1

2

3

4

EOB

a

EOB

a

INPUT

This key sequence sets data as follows:

0

1234

0

⇒

1234

0

1234

0

0

4)

Bit parameters can be set as follows:

(Ex.)

1

1

EOB

a

EOB

a

INPUT

This key sequence sets data as follows:

0 0 0 0 0 0 0 0

0 0 0 1 1 0 0 0

0 0 0 0 0 0 0 0 ⇒

0 0 0 1 1 0 0 0

0 0 0 0 0 0 0 0

0 0 0 11 0 0 0

0 0 0 0 0 0 0 0

0 0 0 0 0 0 0 0

8.

After the required parameters are set, set PARAMETER WRITE to

0.

401

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

The main CPU memorized the following data.

6.2

Outputting the data 1/O device while the CNC is rurnning normally

INPUTTING/

(1) CNC paramter

OUTPUTTING

(2) PMC parameter

DATA

(3) Pitch error compensation amount

(4) Custom macro variable values

(5) Tool compensation amount

(6) Part program (machining program, custom macro program)

Be sure that data output cannot be done in an alarm status.

6.2.1

Parameters required for output are as follows :

Confirming the

In addition, l indicates the standard setting for input/output devices

Parameters Required for

made by FANUC. Change these settings according to the unit you

Data Output

actually use.

(Parameter can be changed in MDI mode or emergency stop status.)

#7

#6

#5

#4

#3

#2

#1

#0

0000

ISO

#1 (ISO)

0 : Output with EIA code

1 : Output with ISO code (FANUC cassette)

0020

Selection of I/O channel

l 0 : Channel 1 (JD36A of mother board)

1 : Channel 1 (JD36A of mother board)

2 : Channel 2 (JD36B of mother board)

3 : Channel 3 (JD38A of serial communication board)

4 : Memory card interface

NOTE

An operation example shown here assumes that data input/

output is performed with an input/output unit connected to

the JD36A. (I/O channel = 0)

#7

#6

#5

#4

#3

#2

#1

#0

0101

NFD

ASI

SB2

#7 (NFD)

0 : Feed is output when data is output.

1 : Feed is not output when data is output.

#3 (ASI)l

0 : EIA or ISO code is used for input/output data.

1 : ASCII code is used.

#0 (SB2)

0 : No. of stop bits is 1.

l 1 : No. of stop bits is 2.

402

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

0102

pecification number of input/output device

Set value

Input/output device

0

RS-232-C (Used control codes DC1 to DC4)

1

FANUC CASSETTE ADAPTOR 1 (FANUC CASSETTE B1/ B2)

2

FANUC CASSETTE ADAPTOR 3 (FANUC CASSETTE F1)

3

FANUC PROGRAM FILE Mate, FANUC FA Card Adaptor

FANUC FLOPPY CASSETTE ADAPTOR, FANUC Handy File

FANUC SYSTEM P-MODEL H

4

RS-232-C (Not used control codes DC1 to DC4)

5

Portable tape reader

6

FANUC PPR

FANUC SYSTEM P-MODEL G, FANUC SYSTEM P-MODEL H

0103

Baud Rate

1:

50

5:

200

9:

2400

2:

100

6:

300

l10:

4800

3:

110

7:

600

11:

9600

4:

150

8:

1200

12:

19200 [BPS]

In case of PPR, steps 2 and 3 are not required.

6.2.2

Outputting CNC

1. Enter EDIT mode or the emergency stop condition.

Parameters

2.

PROG

Press PROG key and soft key PRGRM to select a program text.

3. Press soft key [(OPRT)] and soft key

And then, put out the head of file by pressing [FSRH]

0

[EXEC].

4. Press

SYSTEM

key and soft key [PARAM] to display parameter screen.

5. Press soft key [(OPRT)] ,and soft key

6. Press soft key [PUNCH] and [EXEC],and the parameters are started

to be output.

403

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

6.2.3

1. Select MDI mode.

Outputting PMC

OFFSET

2. Press

SETTING

key then soft key [SETTING] to select a setting screen.

Parameters

3. Set the cursor to PARAMETER WRITE and input

1

and

INPUT

At this time, alarm 100 will be generated.

4. Press

SYSTEM

key and soft key [PMC].

5. Press soft key [PMCPRM] and soft key [KEEPRL]

6. Set the cursor to K17 and set the first bit to 1.

X

X

X

X

X

X

1

X

INPUT

Where, mark x is a former value

Thus, data input/output screen has been selected.

7. Select EDIT mode.

8. Press soft key

then key

9. Press soft key [I/O] and set the parameters on I/O.

Item selection cursor moves to the following item after data of an item

is set.

10.In CHANNEL NO item, input

1

INPUT

to select I/O channel 1.

11.In DEVICE item, press soft key [FDCAS] to select the floppy cassette.

12.In KIND DATA item, press soft key [PARAM].

13.In FUNCTION item, press soft key [WRITE].

14.In FILE No item, specify a file name. In this example input as follows:

@

P

M

C

INPUT

15.Press soft key [EXEC]. Then PMC parameters are started to be output.

16.After the PMC parameters have been output, set PARAMETER

WRITE to 0.

17.Press

RESET

to release alarm 100.

6.2.4

1. Select EDIT mode.

Outputting Pitch Error

SYSTEM

2. Press

key several times, press soft key [PARAM],

and

Compensation Amount

[PITCH] to select the SETTING screen for pitch error amount.

3. Press soft key [(OPRT)] and

4. Press soft key [PUNCH] and [EXEC], then pitch error compensation

amount is started to be output.

404

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

6.2.5

When custom macro function is equipped, values of variable no. 500 and

later are output.

Outputting Custom

OFFSET

Macro Variable Values

1. Press

SETTING

key.

2. Press

key and soft key [MACRO] to select custom macro

variable screen.

3. Press soft key [(OPRT)] and then key

4. Press soft key [PUNCH] and [EXEC], then custom macro variable

values are output.

1. Select EDIT mode.

6.2.6

Outputting Tool

OFFSET

2. Press

SETTING

key and soft key

[OFFSET] to display the tool

Compensation Amount

compensation amount screen.

3. Press [(OPRT)] key and soft key

4. Press soft key [PUNCH] an [EXEC] key, and the tool compensation

amount is started to be output.

6.2.7

1. Confirm the following parameters. If this parameter is set to 1, rather

than the value indicated by l, change to MDI mode and then reset to 0.

Outputting Part Program

However, if you changed the parameter setting, restore the original

value after finishing this work.

#7

#6

#5

#4

#3

#2

#1

#0

3202

NE9

NE8

#4 (NE9) l

0 : Programs of 9000s are edited.

1 : Programs of 9000s can be protected.

#0 (NE8) l

0 : Programs of 8000s are edited.

1 : Programs of 8000s can be protected.

2. Select EDIT mode.

3. Press

PROG

key and press soft key [PRGRM] to display program text.

4. Press [(OPRT)] key and press soft key

5. Input a program number to be output. To output all programs input as:

O

-

9

9

9

9

6. Press [PUNCH] and [EXEC] key, then program output is started.

405

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

6.2.8

1.

Set to the emergency stop state.

Inputting CNC

2.

Confirm that the patameters required to input data is correct.

In addition, l indicates the standard setting for input/output devices

Parameters

made by FANUC. Change these settings according to the unit you

actually use.

OFFSET

1) Press

SETTING

key several times, and press [SETING] to display

SETTING screen.

2) Confirm that PARAMETER WRITE=1.

3) Press

SYSTEM

key to select the parameter screen.

4)

0020

Selectionof I/O channel

l

0 :

Channel 1 (JD36A of mother board)

1 :

Channel 1

(JD36A of mother board)

2 :

Channel 2

(JD36B of mother board)

3 :

Channel 3

(JD38A of serial communication board)

4 :

Memory card interface

5)

#7

#6

#5

#4

#3

#2

#1

#0

0101

NFD

ASI

SB2

#7 (NFD)

0 :

Feed is output when punching out.

1 :

Feed is not output when punching out.

#3 (ASI)

0 :

EIA or ISO code is used.

1 :

ASCII code is used.

#0 (SB2)

0 :

No. of stop bits is 1.

l 1 : No. of stop bits is 2.

6)

0102

Specification number of I/O device

Set value

Input/output device

0

RS-232-C (Used control codes DC1 to DC4)

1

FANUC CASSETTE ADAPTOR 1 (FANUC CASSETTE B1/ B2)

2

FANUC CASSETTE ADAPTOR 3 (FANUC CASSETTE F1)

3

FANUC PROGRAM FILE Mate, FANUC FA Card Adaptor

FANUC FLOPPY CASSETTE ADAPTOR, FANUC Handy File

FANUC SYSTEM P-MODEL H

4

RS-232-C (Not used control codes DC1 to DC4)

5

Portable tape reader

6

FANUC PPR

FANUC SYSTEM P-MODEL G, FANUC SYSTEM P-MODEL H

406

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

7)

0103

Baud rate

1:

50

5:

200

9:

2400

2:

100

6:

300

l10:

4800

3:

110

7:

600

11:

9600

4:

150

8:

1200

12:

19200 [BPS]

3. Press soft key [(OPRT)] and soft key

4. Press soft key [READ] and [EXEC]. Then input of parameters are

started.

5. Because alarm 300 will generate for the system with absolute pulse

coder, set parameter 1815#5 to 0.

6. Alarm 300 is issued if the system employs an absolute pulse coder.

In such a case, perform reference position return again.

Set the emergency stop state.

6.2.9

Operation of 12 is not required when PPR is used.

Inputting PMC

1. Turn off (KEY4=1) the program protect key.

Parameters

OFFSET

2. Press

SETTING

key and soft key [SETTING] to select the SETTING

screen.

3. Confirm that PARAMETER WRITE=1.

4. Press

SYSTEM

key and soft key [PMC].

5. Press soft key [PMCPRM] and soft key [KEEPRL].

6. Set the cursor to K17 and set bit 1 to 1.

0

0

0

0

0

0

1

0

INPUT

7. Press

key and

key.

8. Press soft key [I/O] and set the parameters required for I/O.

Item selection cursor displays the next item after an item is set.

9. In CHANNEL item , press

1

INPUT

to select channel 1.

10.In DEVICE item, press [FDCAS] key to select the floppy cassette.

11.In FUNCTION item, press soft key [READ] to input data

12.In FILE NO item, press

2

INPUT

to select file no. 2.

13.Press soft key [EXECT] and the PMC parameters are started to be

input.

14.After data has been read, turn off power and turn it on.

407

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

6.2.10

1. Release the emergency stop and select EDIT mode.

Inputting Pitch Error

2. Confirm that PARAMETER WRITE=1 on the setting screen.

Compensation Amount

3. Press

PROG

key and soft key [PRGRM] to display program contents.

4. Press soft key [(OPRT)],

, [F SRH], and

3

[EXEC] to select

the pitch error compensation file.

5. Press

SYSTEM

key several times, soft key

[PARAM],

and

[PITCH] to select the screen for pitch error compensation amount.

6. Press soft key [(OPRT)] and

key.

7. Press soft key

[READ] and

[EXEC], then the pitch error

compensation amount is started to be input.

OFFSET

8. After data has been input, press

SETTING

key twice to display the

SETTING screen and return the PARAMETER WRITE to 0.

6.2.11

If the system is equipped with the custom macro fucntion, input the

variable values.

Inputting Custom Macro

For PPR, item 4 is not required.

Variable Values

1.

Confirm that EDIT mode is selected.

2.

Turn off the program protect key (KEY2=1).

3.

Press

PROG

key then soft key [PRGRM] to display program contents.

4.

Press soft key [(OPRT)],

, [F SRH], and

4

[EXEC] to select

a file.

5.

Press soft key [(OPRT)] and key

6.

Press address

O

, a program number (0001 for example), soft key

[READ] and [EXEC] key, then custom macro variable values are

started to be input.

Input a program number that is not used.

7.

Select MEMORY mode on the machine operator’s panel and press

cycle start button.

When the program is executed, macro variables are set.

OFFSET

8.

Press

SETTING

key,

key and soft key [MACRO] to select the custom

macro variable screen.

9.

Press 500 and soft key [NO SRH] to display variable number 500 and

confirm the custom macro variables are set correctly.

Of the data displayed, 0 and vacant differ in meaning.

Vacant is an undefined variable. To set vacant, press soft key

[INPUT].

10.Select EDIT mode again.

11.Press

PROG

key to select the program display screen.

408

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

12.Press address O and a program number (0001 for example) ,then press

DELETE

to delete the program.

6.2.12

Item 4 is not required for PPR.

Inputting Tool

1. Select the EDIT mode.

Compensation Amount

2. Turn off the program protect (KEY=1).

3. Press

PROG

key, and press soft key[PRGRM] to display the program

contents screen.

4. Press soft key [(OPRT)],

, [F SRH], and

5

[EXEC] to select

the tool compensation amount file.

OFFSET

5. Press

SETTING

key, and soft key

[OFFSET] to display the tool

compensation amount screen.

6. Press soft key [(OPRT)] and

key.

7. Press [READ] key and [EXEC] key and data input is started.

6.2.13

Confirm the following parameters. If the setting is different from the

value indicated by l, reset to the specified value only during this work.

Inputting Part Programs

(Change it in MDI mode).

#7

#6

#5

#4

#3

#2

#1

#0

3201

NPE

RAL

#6 (NPE)

When programs are registered in part program storage area, M02,M30

and M99 are:

0 : regarded as the end of program.

l

1 : not regarded as the end of porgram.

#1 (RAL)

When programs are registered:

l

0 : All programs are registered.

1 : Only one program is registered.

#7

#6

#5

#4

#3

#2

#1

#0

3202

NE9

NE8

#4 (NE9)

l

0 : Programs of 9000s can be edited.

1 : Programs of 9000s are protected.

#0 (NE8)

l

0 : Programs of 8000s can be edited.

1 : Programs of 8000s are protected.

409

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

6.3

INPUT/OUTPUT

Super CAPi DATA

6.3.1

The following operation allows all the data used for Super CAPi M to be

input and output in a lump.

Input/Output of

1.

Confirm the parameters shown below:

Conversational Data in a

P0020: I/O CHANNEL (select I/O device)

:

0

Lump(Super CAPi M)

P0102: I/O device number

:

3

P0103: Baud rate

for 4800 bauds

:

10

for 9600 bauds

:

11

2.

Select EDIT mode.

3.

Press function key

PROG

and press soft key [CAP].

4.

Press soft key [8] (C.A.P DATA) on the basic menu screen.Serial 16i

Conversational Data Screen

C.A.P. DATA

SET DATA OF PRE-

DATA

PRE-

INPUT OR OUTPUT OF DATA

TOOLS BEFORE C.A.P.

I/O

TOOL

PROGRAMMING

TOOL

DISPLAY AND SET

FILE

VARIOUS DATA OF

TOOLS REGISTERED

TOOL

DISPLAY THE DIREC-

DRCTRY

TORY OF TOOLS IN

TOOL FILE

DEF.

DIVIDE

DISPLAY THE DIREC-

DISPLAY DEFAULT DATA

FILE

TOLDIR

TORY OF DIVIDE

TOOLS IN TOOL FILE

DISPLAY A LIST OF TOOL

TOOL

F.S.

DISPLAY AND SET

USED

USED

FILE

DATA OF CUTTING

SET T-ORDER FOR T-OR-

DER CHANGE

CONDITION

SELECT FROM SOFT KEY

<

DATA

DEF.

TOOL

PRE-

TOOL

TOOL

DIVIDE

F.S.

I/O

FILE

USED

TOOL

FILE

DRCTRY

TOLDIR

FILE

5. Press soft key [DATA I/O].

411

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

Series16i Conversational Data Screen

DATA I/O

@ READ

DATA I/O PARA GUIDE

READ

I/O CHANNEL

=0

EXEC

@ PUNCH

I/O DEVICE NO.

=3

OR

@ ALL CAP DATA

PUNCH

@ DEFAULT DATA

EXEC

@ PRE-TOOL LIST

@ TOOL FILE

@ CUT COND FILE

SELECT FROM SOFT-KEY

<

FLOPPY

READ

PUNCH

ALL

DEF.

PRE-

TOOL

F.S.

DIR

DATA

FILE

TOOL

FILE

FILE

6. Press soft key [READ] or [PUNCH].

7. Press soft key [ALL DATA].

8. For read, input a file no. and press soft key [READ EXEC].(Specify

a file no. for all data).

READ FILE NO. =

>

<

FLOPPY

PUNCH

READ

ALL

DEF.

PRE-

TOOL

F.S.

DIR

DATA

FILE

TOOL

FILE

EXEC

FILE

⋅For punch, press soft key [PUNCH EXEC].

SELECT FROM SOFT KEYS

<

FLOPPY

ALL

DEF.

PRE-

F.S.

READ

TOOL

PUNCH

DIR

EXEC

DATA

FILE

TOOL

FILE

FILE

The above operation reads and punches default data, pre-tool list, tool file

and F.S. file in a lump.

412

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

PROGRAM NO.

=

1234

³SFTKY

INITAL SET FC25

BAR

PROC(01)

BAR

OUTER END

HEAD-L

ROUGH

T0505

PROC(02)

BAR

OUTER END

HEAD-L

FIN

T0505

PROC(03)

TRANS

PROC(04)

BAR

OUTER END

HEAD-R

ROUGH

T0505

PROC(05)

BAR

OUTER END

HEAD-R

FIN

T0505

<

CAN-

EXE

CEL

C

When [EXEC] is pressed, punch-out of the specified program starts.

When [CANCEL] is pressed, punch-out operation is canceled and the

previous state is restored.

To output all the machining programs, specify -9999 for the program

number.

When the output device is the FANUC cassette adapter, a new file is

created immediately after the existing files.

Upon the start of outputting machining programs, “OUTPUTTING”

blinks at the bottom of the screen, until the output operation ends.

NOTE

1

Only a machining program created with the conversational

input function can be output by applying the above

procedure.

A machining program created using the NC program screen

cannot be output by applying the above procedure.

2

When a machining program is output to a memory card, the

file name is CAPO****.DAT

(with

**** representing a

specified program number). If the program number -9999

is specified, the file name is CAPALLPR.DAT.

3

When an attempt is made to output a machining program to

a memory card, and a file with the same name is already

present, the machining program is overwritten to the file.

4

When an attempt is made to output a machining program to

a flash ROM card, and a file with the same name is already

present, the machining program cannot be written to the card.

414

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

Input of conversational

The machining program punched out by applying the procedure described

machining programs

on the previous page can be read into the NC via a reader/punch interface.

A machining program can also be read from the memory card by setting

bit 7 (IO4) of parameter No. 27000. (Note, however, that only those files

that are output to the memory card according to the procedure described

above can be read.)

At this time, be sure to release the memory protect switch on the machine

operator’s panel.

Before attempting to read a program, release the memory protect switch

on the machine operator’s panel.

After switching to EDIT mode, display the registered program list screen

for editing, then press [READ]. The following message prompting the

user to input the file number is displayed, as well as the soft keys used to

confirm operation.

PROGRAM NO.

=

³SFTKY

INITAL SET FC25

BAR

PROC(01)

BAR

OUTER END

HEAD-L

ROUGH

T0505

PROC(02)

BAR

OUTER END

HEAD-L

FIN

T0505

PROC(03)

TRANS

PROC(04)

BAR

OUTER END

HEAD-R

ROUGH

T0505

PROC(05)

BAR

OUTER END

HEAD-R

FIN

T0505

<

CAN-

EXE

CEL

C

Enter the number of the file containing the machining program to be input,

using numeric keys, then press [EXEC]. Reading of the machining

program starts. When the input device is FANUC PPR, press [EXEC]

without inputting a file number.

When [CANCEL] is pressed, read operation is canceled and the previous

state is restored.

Upon the start of inputting machining programs, “INPUTTING” blinks

at the bottom of the screen, until the input operation ends.

NOTE

Only a machining program created with the conversational

input function can be input by applying the above

procedure.

A machining program created using the NC program screen

cannot be input by applying the above procedure.

Output of conversational

The tool data file, cutting condition data, surface roughness data, pre-tool

tool setting data

list, and chuck/tailstock figure data can be punched out to an external I/O

device.

(1) Connect an external I/O device and set necessary parameters, such as

device selection.

(2) Select EDIT mode.

415

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

(3) Display the tool data menu screen, then press [+]. The following soft

keys appear. Press [PUNCH].

<

10

11

READ

PUN

CLEA

\

CH

R

NOTE

1

When data is output to a memory card, the file name is

CAPTOOL.DAT.

2

When an attempt is made to output data to a memory card,

and a file with the same name is already present, the data

is overwritten to the file.

3

When an attempt is made to output data to a flash ROM

card, and a file with the same name is already present, the

data cannot be written to the card.

Input of conversational

The setting data punched out in the previous section can be read.

tool setting data

(1) Connect an external I/O device and set necessary parameters, such as

device selection.

(2) Set “PARAMETER WRITE” in the setting data to 1.

(3) When the FANUC cassette adapter is used, set the file number for

parameter No. 9887 (TLFLNO).

(4) Display the tool data menu screen and place the system in the

emergency stop state.

(5) Press [READ].

Clearing of

The tool data file, cutting condition data, surface roughness data, pre-tool

conversational tool

list, and chuck/tailstock figure data can be cleared.

setting data

(1) Set “PARAMETER WRITE” in the setting data to 1.

(2) Display the tool data menu screen. After switching to EDIT mode,

place the system in the emergency stop state.

(3) Press [CLEAR].

416

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

INITIAL SCREEN

6.4

Symbolic

INPUTTING/

OUTPUTTING Symbol

FAPT TURN

CAPi T

PRESS [DATA

PRESS [FAMILY

SET] KEY

PROGRAM]

**FAMILY PROGRAM**

**PARAMETER & DATA SET**

1. FAMILY PROGRAM OUTPUT

1. SYSTEM DATA SETTING

2. FAMILY PROGRAM INPUT

2. SETTING DATA CORRECTION

:

3. MATERIAL DATA CORRECTION

:

:

:

:

:

4 or 5

INPUT

1

INPUT

(REFER TO TABLE 1) (REFER TO TABLE 2)

**SYSTEM DATA SETTING &

OUTPUT/INPUT**

1. SYSTEM PARAMETER SETTING

2. SYSTEM PARAMETER OUTPUT

3. SYSTEM PARAMETER INPUT

:

:

:

(REFER TO TABLE 3)

417

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

[TABLE 1] Input/Output of Family Program

I/O

Item

Operation on I/O

Remarks

device

Input

Family program

2, n

[INPUT]

n=P⇒FANUC PPR

n=B⇒FANUC Cassette

Sub cycle

5, n

[INPUT]

n=C⇒Sub Memory

Output

Family program

1, n

[INPUT]

*When n is omitted, parameter

Sub cycle

4, n

[INPUT]

no. 15 becomes valid.

[TABLE 2] Input/Output of Material Data

I/O

Item

Operation on I/O

Remarks

device

Input

Material data

5, n

[INPUT]

n=P⇒FANUC PPR

n=B⇒FANUC Cassette

Toolinginformation

8, n

[INPUT]

n=C⇒Sub Memory

Output

Material data

4, n

[INPUT]

*When n is omitted, parameter

no. 15 becomes valid.

Toolinginformation

7, n

[INPUT]

[Table 3] Input/Output of system parameters and other data.

Item

Operation on I/O

Remarks

I/O

device

System parameter

3, n

[INPUT]

1[INPUT]⇒[SAVE END]

MTF

7, n

[INPUT]

5[INPUT]⇒[SAVE END]

Input/

Tool data

11, n

[INPUT]

9[INPUT]⇒[SAVE END]

Read

Setting

14, n

[INPUT]

Graphic data

16, n

[INPUT]

n=P⇒FANUC PPR

System parameter

2, n

[INPUT]

n=B⇒FANUC Cassette

Out-

MTF

6, n

[INPUT]

put/

Regis-

Tool data

10, n

[INPUT]

tera-

Setting

13, n

[INPUT]

tion

Graphic data

15, n

[INPUT]

System parameter

4, n

[INPUT]

Colla-

MTF

8, n

[INPUT]

tion

Tool data

12, n

[INPUT]

418

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

Symbol CAPi T data is stored in the sub-memory (SRAM) on the symbol

6.5

CAPi T board. When replacing the symbol CAPi T board, perform data

DUMP/RESTORE OF

input/output operation according to this section.

Symbol CAPi T DATA

6.5.1

1. System parameter (FAPT-SYS. PARAM.)

Kind of Data in Sub

2. MTF (FAPT-MTF)

Memory

3. Setting data

(FAPT-SETTING)

4. Tool data

(FAPT-TOOL)

5. Graphic data (FAPT-GRAPHIC)

6. Files

Family program

(FAPT-FAMILY)

Material file

(FAPT-MATERIAL)

Tooling information

(FAPT-TOOL)

Sub cycle file

(FAPT-SUB. CYCLE)

6.5.2

Operation

D Outputting data (Dump)

1. Display the screen of Symbolic FAPT TURN.

2. To output data on FANUC Cassette, press keys as follows:

[AUXILIARY]⇒

,

INPUT

D

U

M

P

B

Be careful that data is memorized from top of the file.

To output data on FANUC PPR, press keys as follows:

[AUXILIARY]⇒

D

U

M

P

,

P

INPUT

D Inputting data (Restore)

1. Hold

SP

key and turn on power.

2. To input data from FANUC Cassette, press keys as follows :

[AUXILIARY]⇒

R

S

T

R

,

B

INPUT

To input data from FANUC PPR, press keys as follows :

[AUXILIARY]⇒

R

S

T

R

,

P

INPUT

3. Turn off the power once.

419

6. INPUT AND OUTPUT OF DATA

B-63525EN/02

6.6

CLEARING Symbol

CAPi T DATA

6.6.1

Deleting File Name and

Symbolic FAPT TURN

Files

(Initial screen)

Press [Family program]

Press [DATA SET] key

key

“Family program” menu

“PARAMETER & DATASET”

screen

menu key

Press [FILE NAME] key

Not only file names of family

programs, but also file names

File name list stored in

and sub cycle files are dis-

submemory

played.

No

Delete a file ?

Yes

Meet the cursor to a no. to be

Press [END]

deleted using [CURSOR⇓] or

[CURSOR⇑] key

DEL

INPUT

EOB

,

YES(Delete)

NO(Not delete)

Delete really ?

1

INPUT

0

INPUT

,

,

420

Content      ..     13      14      15      16     ..
