G. ALARM LIST

Number

Message

Contents

131

TOO MANY EXTERNAL ALARM

Five or more alarms have generated in external alarm message.

MESSAGES

Consult the PMC ladder diagram to find the cause.

132

ALARM NUMBER NOT FOUND

No alarm No. concerned exists in external alarm message clear.

Check the PMC ladder diagram.

133

ILLEGAL DATA IN EXT. ALARM

Small section data is erroneous in external alarm message or exter-

MSG

nal operator message. Check the PMC ladder diagram.

135

ILLEGAL ANGLE COMMAND

The index table indexing positioning angle was instructed in other

than an integral multiple of the value of the minimum angle.

Modify the program.

136

ILLEGAL AXIS COMMAND

In index table indexing, another control axis was instructed together

with the B axis.

Modify the program.

138

SUPERIMPOSED DATA

In PMC-based axis control, the increment for pulse distribution on

OVERFLOW

the CNC and PMC side are too large when the superimposed control

extended function is used.

139

CAN NOT CHANGE PMC CON-

An axis is selected in commanding by PMC axis control.

TROL AXIS

Modify the program.

141

CAN NOT COMMAND G51 IN CRC

G51 (Scaling ON) is commanded in the tool offset mode.

Modify the program.

142

ILLEGAL SCALE RATE

Scaling magnification is commanded in other than 1 - 999999.

Correct the scaling magnification setting (G51 Pp . . or parameter

5411 or 5421).

143

SCALED MOTION DATA OVER-

The scaling results, move distance, coordinate value and circular

FLOW

radius exceed the maximum command value. Correct the program or

scaling mangification.

144

ILLEGAL PLANE SELECTED

The coordinate rotation plane and arc or cutter compensation C

plane must be the same. Modify the program.

145

ILLEGAL CONDITIONS IN POLAR

The conditions are incorrect when the polar coordinate interpolation

COORDINATE INTERPOLATION

starts or it is canceled.

1) In modes other than G40, G12.1/G13.1 was specified.

2) An error is found in the plane selection. Parameters No. 5460 and

No. 5461 are incorrectly specified.

Modify the value of program or parameter.

146

IMPROPER G CODE

G codes which cannot be specified in the polar coordinate interpola-

tion mode was specified. See section polar coordinate interpolation

and modify the program.

148

ILLEGAL SETTING DATA

Automatic corner override deceleration rate is out of the settable

range of judgement angle. Modify the parameters (No.1710 to

No.1714)

149

FORMAT ERROR IN G10L3

A code other than Q1,Q2,P1 or P2 was specified as the life count

type in the extended tool life management.

150

ILLEGAL TOOL GROUP NUMBER

Tool Group No. exceeds the maximum allowable value.

Modify the program.

151

TOOL GROUP NUMBER NOT

The tool group commanded in the machining program is not set.

FOUND

Modify the value of program or parameter.

152

NO SPACE FOR TOOL ENTRY

The number of tools within one group exceeds the maximum value

registerable. Modify the number of tools.

153

T-CODE NOT FOUND

In the registration of tool life data, a T code was not specified in a

block where it is required. Alternatively, only M06 was specified in a

block for tool change type D. Correct the program.

154

NOT USING TOOL IN LIFE GROUP

When the group is not commanded, H99 or D99 was commanded.

Correct the program.

155

ILLEGAL T-CODE IN M06

In the machining program, M06 and T code in the same block do not

correspond to the group in use. Correct the program.

1183

G. ALARM LIST

APPENDIX

B-63534EN/02

Number

Message

Contents

156

P/L COMMAND NOT FOUND

P and L commands are missing at the head of program in which the

tool group is set. Correct the program.

157

TOO MANY TOOL GROUPS

The number of tool groups to be set exceeds the maximum allowable

value. See parameter GS1, GS2 (No. 6800 bit 0 and 1). Modify the

program.

158

ILLEGAL TOOL LIFE DATA

The tool life to be set is too excessive. Modify the setting value.

159

TOOL DATA SETTING INCOM-

During executing a life data setting program, power was turned off.

PLETE

Set again.

160

G72.1 NESTING ERROR

Code G72.1 was specified in a sub-program after the same code

had already been specified for copying with rotation.

161

ILLEGAL P OF WAITING M-CODE

Code G72.2 was specified in a sub-program after the same code

(T series) (three-path control)

had already been specified for parallel copying.

169

ILLEGAL TOOL GEOMETRY DATA

Incorrect tool figure data in interference check.

(At two-path)

Set correct data, or select correct tool figure data.

175

ILLEGAL G107 COMMAND

Conditions when performing cylindrical interpolation start or cancel

not correct. To change the mode to the cylindrical interpolation

mode, specify the command in a format of “G07.1 rotation-axis name

radius of cylinder.”

176

IMPROPER G-CODE IN G107

Any of the following G codes which cannot be specified in the cylin-

drical interpolation mode was specified.

1) G codes for positioning, such as G28,, G73, G74, G76, G81 - G89,

including the codes specifying the rapid traverse cycle

2) G codes for setting a coordinate system: G52,G92,

3) G code for selecting coordinate system: G53 G54-G59

Modify the program.

177

CHECK SUM ERROR

Check sum error

(G05 MODE)

Modify the program.

178

G05 COMMANDED IN G41/G42

G05 was commanded in the G41/G42 mode.

MODE

Correct the program.

179

PARAM. (PRM NO. 7510) SETTING

The number of controlled axes set by the parameter 7510 exceeds

ERROR

the maximum number. Modify the parameter setting value.

180

COMMUNICATION ERROR

Remote buffer connection alarm has generated. Confirm the number

(REMOTE BUF)

of cables, parameters and I/O device.

181

FORMAT ERROR IN G81 BLOCK

G81 block format error (hobbing machine)

1) T (number of teeth) has not been instructed.

2) Data outside the command range was instructed by either T, L, Q or

3) Calculation of the synchronization coefficient has overflowed.

(gear hobbing machine, EGB)

Modify the program.

182

G81 NOT COMMANDED

G83 (C axis servo lag quantity offset) was instructed though synchro-

nization by G81 has not been instructed. Correct the program. (hob-

(gear hobbing machine)

bing machine)

183

DUPLICATE G83 (COMMANDS)

G83 was instructed before canceled by G82 after compensating for

(gear hobbing machine)

the C axis servo lag quantity by G83. (hobbing machine)

184

ILLEGAL COMMAND IN G81

A command not to be instructed during synchronization by G81 was

instructed. (hobbing machine)

1) A C axis command by G00, G27, G28, G29, G30, etc. was

instructed.

(gear hobbing machine, EGB)

2) Inch/Metric switching by G20, G21 was instructed.

1184

B-63534EN/02

APPENDIX

G. ALARM LIST

Number

Message

Contents

185

RETURN TO REFERENCE POINT

G81 was instructed without performing reference position return after

power on or emergency stop. (hobbing machine) Perform reference

(gear hobbing machine)

position return.

186

PARAMETER SETTING ERROR

Parameter error regarding G81 (hobbing machine)

1) The C axis has not been set to be a rotary axis.

(gear hobbing machine, EGB)

2) A hob axis and position coder gear ratio setting error

190

ILLEGAL AXIS SELECT

In the constant surface speed control, the axis specification is wrong.

(See parameter No. 3770.) The specified axis command (P) contains

an illegal value.

Correct the program.

194

SPINDLE COMMAND IN SYN-

A contour control mode, spindle positioning (Cs-axis control) mode,

CHRO-MODE

or rigid tapping mode was specified during the serial spindle

synchronous control mode. Correct the program so that the serial

spindle synchronous control mode is released in advance.

197

C-AXIS COMMANDED IN SPINDLE

The program specified a movement along the Cs-axis when the sig-

MODE

nal CON(DGN=G027#7) was off. Correct the program, or consult the

PMC ladder diagram to find the reason the signal is not turned on.

199

MACRO WORD UNDEFINED

Undefined macro word was used. Modify the custom macro.

200

ILLEGAL S CODE COMMAND

In the rigid tap, an S value is out of the range or is not specified.

The maximum value for S which can be specified in rigid tapping is

set in parameter (No.5241 to 5243). Change the setting in the

parameter or modify the program.

201

FEEDRATE NOT FOUND IN RIGID

In the rigid tapping, no F value is specified.

TAP

Correct the program.

202

POSITION LSI OVERFLOW

In the rigid tapping, spindle distribution value is too large.

203

PROGRAM MISS AT RIGID

In the rigid tapping, position for a rigid M code (M29) or an S

TAPPING

command is incorrect. Modify the program.

204

ILLEGAL AXIS OPERATION

In the rigid tapping, an axis movement is specified between the rigid

M code (M29) block and G84 (G74) block. Modify the program.

205

RIGID MODE DI SIGNAL OFF

Rigid tapping signal (DGNG 061#1) is not 1 when G84 (G74) is

executed though the rigid M code (M29) is specified.Consult the PMC

ladder diagram to find the reason the DI signal is not turned on.

Modify the program.

206

CAN NOT CHANGE PLANE (RIGID

Plane changeover was instructed in the rigid mode.

TAP)

Correct the program.

207

RIGID DATA MISMATCH

The specified distance was too short or too long in rigid tapping.

210

CAN NOT COMAND M198/M99

1) M198 and M99 are executed in the schedule operation. Or M198

is executed in the DNC operation.

2) In a multiple repetitive pocketing canned cycle, an interrupt macro

was specified, and M99 was executed.

212

ILLEGAL PLANE SELECT

The arbitrary angle chamfering or a corner R is commanded or the

plane including an additional axis. Correct the program.

213

ILLEGAL COMMAND IN SYN-

Any of the following alarms occurred in the operation with the simple

CHRO-MODE

synchronization control.

1) The program issued the move command to the slave axis.

2) The program issued the manual continuous feed/manual handle

feed/incremental feed command to the slave axis.

3) The program issued the automatic reference position return com-

mand without executing the manual reference position return after

the power was turned on.

4) The difference between the position error amount of the master and

slave axes exceeded the value specified in parameter No. 8313.

1185

G. ALARM LIST

APPENDIX

B-63534EN/02

Number

Message

Contents

214

ILLEGAL COMMAND IN SYN-

Coordinate system is set or tool compensation of the shift type is

CHRO-MODE

executed in the synchronous control. Correct the program.

222

DNC OP. NOT ALLOWED IN BG.-

Input and output are executed at a time in the background edition.

EDIT

Execute a correct operation.

224

RETURN TO REFERENCE POINT

Reference position return has not been performed before the auto-

matic operation starts. Perform reference position return only when

parameter ZRN_X (No.1005#0) is 0.

230

R CODE NOT FOUND

The infeed quantity R has not been instructed for the G161 block. Or

(for grinding machine)

the R command value is negative. Correct the program.

231

ILLEGAL FORMAT IN G10 OR L50

Any of the following errors occurred in the specified format at the

programmable-parameter input.

1) Address N or R was not entered.

2) A number not specified for a parameter was entered.

3) The axis number was too large.

4) An axis number was not specified in the axis-type parameter.

5) An axis number was specified in the parameter which is not an axis

type.

6) An attempt was made to reset bit 4 of parameter 3202 (NE9) or

change parameter 3210 (PSSWD) when they are protected by a

password. Correct the program.

232

TOO MANY HELICAL AXIS COM-

Three or more axes (in the normal direction control mode two or more

MANDS

axes) were specified as helical axes in the helical interpolation mode.

233

DEVICE BUSY

When an attempt was made to use a unit such as that connected via

the RS-232-C interface, other users were using it.

239

BP/S ALARM

While punching was being performed with the function for controlling

external I/O units ,background editing was performed.

240

BP/S ALARM

Background editing was performed during MDI operation.

241

ILLEGAL FORMAT IN G02.2/G03.2

The end point, I , J , K , or R was not specified for involute

interpolation.

242

ILLEGAL COMMAND IN

An erroneous value was specified for involute interpolation.

G02.2/G03.2

The start or end point was specified within the base circle.

The value 0 was specified for I , J, K , or R,.

The start or end point exceeds 100 revolutions from the involute

curve start point.

243

OVER TOLERNCE OF END POINT

The end point was not positioned on the involute curve which started

at the start point, and the end point was out of the range specified by

parameter No.5610.

246

During read of an encrypted program, an attempt was made to store the

program with a number exceeding the protection range.

(See parameter Nos. 3222 and 223.)

247

When an encrypted program is output, EIA is set for the punch code.

Specify ISO.

250

Z AXIS WRONG COMMAND (ATC)

Movement alogn the Z-axis was specified in a block in which a com-

mand for changing tools (M06 T_)was specified. (Only for the ROBO-

DRILL)

1186

B-63534EN/02

APPENDIX

G. ALARM LIST

Number

Message

Contents

251

ATC ERROR

An error occurs in the following cases (Only for the ROBODRILL) :

When unusable T code is specified in M06 T_

When the M06 code is specified when the Z coordinate is positive

in the machine coordinate system.

When parameter No. 7810,which specifies the current tool number,

is 0.

When the M06 code is specified in the canned-cycle mode.

When the M06 code is specified in a block in which a reference posi-

tion return code, G27,G28, G29, or G30 is specified.

When the M06 code is specified in the tool compensation mode

(G41 to G44).

When the M06 code is specified without any reference position re-

turn after the power is turned on or after the emergency stop is re-

leased.

When the machine lock signal or the signal for ignoring the Z-axis

is turned on while the tool is being changed.

When a “prying” condition is detected while the tool is changed.

Refer to diagnosis parameter No. 530 for identifying the situations

above.

252

ATC SPINDLE ALARM

An error due to excessive deviation occurs in spindle positioning

during ATC operation. For details, see diagnosis parameter No.531.

(Only for the ROBODRILL)

253

G05 IS NOT AVAIRABLE

Binary-input operation with a high-speed remote buffer (G05) or

high-speed cycle machining (G05) has been specified in look-ahead

control mode (G08P1). Before attempting to specify these

commands, first specify G08P0; to cancel look-ahead control mode.

5000

ILLEGAL COMMAND CODE

The specified code was incorrect in the high-precision contour con-

trol (HPCC) mode.

5003

ILLEGAL PARAMETER (HPCC)

The parameter setting is incorrect.

5004

HPCC NOT READY

High-precision contour control is not ready.

5006

TOO MANY WORD IN ONE BLOCK

The number of words specified in a block exceeded 26 in the HPCC

mode.

5007

TOO LARGE DISTANCE

In the HPCC mode, the machine moved beyond the limit.

5009

PARAMETER ZERO (DRY RUN)

The maximum feedrate (parameter No. 1422) or the feedrate in dry

run (parameter No. 1410) is 0 in the HPCC model.

5010

END OF RECORD

The end of record (%) was specified.

5011

PARAMETER ZERO(CUT MAX)

The maximum cutting feedrate (parameter No. 1422) is 0 in the

HPCC mode.

5012

G05 P10000 ILLEGAL START UP

G05 P10000 has been specified in a mode from which HPCC mode

(HPCC)

cannot be entered.

5013

HPCC:CRC OFS REMAIN AT

G05P0 has been specified in G41/G42 mode or before cancellation

CANCEL

axis is not found.

5014

TRACE DATA NOT FOUND

Trace data is not available, preventing transfer from being performed.

5015

NO ROTATION AXIS

During tool axis direction handle feed or tool axis normal direction

handle feed, the specified rotation axis cannot be found.

5016

ILLEGAL COMBINATION OF M

M codes which belonged to the same group were specified in a

CODE

block. Alternatively,an M code which must be specified without other

M codes in the block was specified in a block with other M codes.

5020

PARAMETER OF RESTART

The parameter for specifying program restart is not set correctly.

ERROR

5043

TOO MANY G68 NESTING

The G68 command for three-dimensional coordinate conversion has

been specified three or more times.

1187

G. ALARM LIST

APPENDIX

B-63534EN/02

Number

Message

Contents

5044

G68 FORMAT ERROR

The G68 block contains a format error. This alarm occurs in the fol-

lowing cases:

One of I, J, and K is not specified in the G68 block (missing option

for coordinate conversion).

I, J, and K are 0 in the G68 block.

R is not specified in the G68 block.

5046

ILLEGAL PARAMETER (ST.COMP)

An illegal parameter has been specified for straightness compensa-

tion.

Possible reasons are as follows:

There is no axis corresponding to the axis number specified in the

move axis or compensation axis parameter.

More than 128 pitch error compensation points are not sequentially

numbered.

The straightness compensation points are not sequentially num-

bered.

A specified straightness compensation point is outside the range

between the pitch error compensation points having the maximum

positive and negative coordinates.

The compensation value specified for each compensation point is

too large or too small.

The settings of parameters Nos. 13881 to 13886 are illegal.

5050

ILL-COMMAND IN CHOPPING

When the chopping function is used, a move command was specified

MODE

for a chopping axis in chopping mode (during reciprocation between

a top dead point and bottom dead point).

5051

M-NET CODE ERROR

When the chopping function is used, a move command was specified

for a chopping axis in chopping mode (during reciprocation between

a top dead point and bottom dead point).

5052

M-NET ETX ERROR

“ETX” code is abnormal.

5053

M-NET CONNECT ERROR

Connection time supervision error (parameter No.175)

5054

M-NET RECEIVE ERROR

Boring time supervision error (parameter No.176)

5055

M-NET PRT/FRM ERROR

Vertical parity or framing error detection

5057

M-NET BOARD SYSTEM DOWN

Transmit time-out error (parameter No. 177)

ROM parity error

CPU interruption detection of not listed above

5060

ILLEGAL PARAMETER IN

Parameter setting is illegal.

G02.3/G03.3

No. 5641 (setting of the linear axis) is not specified.

No. 5641 specifies an axis other than a linear axis.

No. 5642 (setting of the rotation axis) is not specified.

No. 5642 specifies an axis other than a rotation axis.

The CNC cannot control the linear or rotation axis (the value of No.

1010 is exceeded).

5061

ILLEGAL FORMAT IN G02.3/G03.3

The command for exponential interpolation (G02.3/G03.3) contains a

format error.

Address I, J, or K is not specified.

Addresses I, J, and K are 0.

5062

ILLEGAL COMMAND IN

The command for exponential interpolation (G02.3/G03.3) contains

G02.3/G03.3

an illegal value.

The specified value is not suitable for exponential interpolation (for

example, a negative value is subject to ln).

1188

B-63534EN/02

APPENDIX

G. ALARM LIST

Number

Message

Contents

5063

IS NOT PRESET AFTER REF.

This message is output when the position counter has not been

preset before the start of plate thickness measurement. This alarm is

issued in one of the cases below.

1) When an attempt was made to perform measurement before a refer-

ence position had been established.

2) When, after manual reference position return, an attempt was made

to start measurement without first setting the position counter.

5064

DIFFERRENT AXIS UNIT

Circular interpolation was specified for a plane formed by axes using

(IS-B, IS-C)

different increment systems.

5065

DIFFERRENT AXIS UNIT

In PMC-based axis control, axes using different increment systems

(PMC AXIS)

are specified for the same DI/DO group. Modify parameter No. 8010.

5067

G05 PO COMMANDED IN G68/G51

HPCC mode cannot be canceled during G51 (scaling) or G68 (coordi-

MODE (HPCC)

nate system rotation).

Correct the program.

5068

G31 P90 FORMAT ERROR

The continuous high-speed skip command (G31 P90) has one of the

following errors:

1. The axis along which the tool is moved is not specified.

2. More than one axis is specified as the axis along which the tool is

moved.

Alternatively, the EGB skip command (G31.8) or continuous high-

speed skip command (G31.9) has one of the following errors:

1. A move command is specified for the EGB axis (workpiece axis).

2. More than one axis is specified.

3. P is not specified.

4. The specified Q value exceeds the allowable range.

Correct the program.

5069

WHL-C; ILLEGAL P-DATA

The P data, specified for selecting the compensation center for grind-

ing wheel wear compensation, is invalid.

5073

NO DECIMAL POINT

A decimal point is not specified for a command for which a decimal

point must be specified.

5074

ADDRESS DUPLICATION ERROR

The same address appears more than once in a block. Alternatively,

a block contains two or more G codes belonging to the same group.

5082

DATA SERVER ERROR

Details are displayed on the data server message screen.

5085

SMOOTH IPL ERROR 1

A block for specifying smooth interpolation contains a syntax error.

5096

MISMATCH WAITING M-CODE

Different wait codes (M codes) were specified in HEAD1 and HEAD2.

Correct the program.

5110

IMPROPER G-CODE

An illegal G code was specified in simple high-precision contour control

(G05.1 G1 MODE)

mode.

A command was specified for the index table indexing axis in simple

high-precision contour control mode.

5111

IMPROPER MODAL G-CODE

An illegal G code is left modal when simple high-precision contour con-

(G05.1 G1)

trol mode was specified.

5112

G08 CAN NOT BE COMMANDED

Look-ahead control (G08) was specified in simple high-precision con-

(G05.1 G1)

tour control mode.

5114

NOT STOP POSITION

At the time of restart after manual intervention, the coordinates at which

(G05.1 Q1)

the manual intervention occurred have not been restored.

1189

G. ALARM LIST

APPENDIX

B-63534EN/02

Number

Message

Contents

5115

SPL : ERROR

There is an error in the specification of the rank.

No knot is specified.

The knot specification has an error.

The number of axes exceeds the limits.

Other program errors

5116

SPL : ERROR

There is a program error in a block under look-ahead control.

Monotone increasing of knots is not observed.

In NURBS interpolation mode, a mode that cannot be used together is

specified.

5117

SPL : ERROR

The first control point of NURBS is incorrect.

5118

SPL : ERROR

After manual intervention with manual absolute mode set to on, NURBS

interpolation was restarted.

5122

ILLEGAL COMMAND IN SPIRAL

A spiral interpolation or conical interpolation command has an error.

Specifically, this error is caused by one of the following:

1) L = 0 is specified.

2) Q = 0 is specified.

3) R/, R/, C is specified.

4) Zero is specified as height increment.

5) Three or more axes are specified as the height axes.

6) A height increment is specified when there are two height axes.

7) Conical interpolation is specified when the helical interpolation

function is not selected.

8) Q < 0 is specified when radius difference > 0.

9) Q > 0 is specified when radius difference < 0.

10) A height increment is specified when no height axis is specified.

5123

OVER TOLERANCE OF END

The difference between a specified end point and the calculated end

POINT

point exceeds the allowable range (parameter 3471).

5124

CAN NOT COMMAND SPIRAL

A spiral interpolation or conical interpolation was specified in any of the

following modes:

1) Scaling

2) Programmable mirror image

3) Polar coordinate interpolation

In cutter compensation C mode, the center is set as the start point or

end point.

5134

FSSB : OPEN READY TIME OUT

Initialization did not place FSSB in the open ready state.

5135

FSSB : ERROR MODE

FSSB has entered error mode.

5136

FSSB : NUMBER OF AMPS IS

In comparison with the number of controlled axes, the number of amplifi-

SMALL

ers recognized by FSSB is not enough.

5137

FSSB : CONFIGURATION ERROR

FSSB detected a configuration error.

5138

FSSB : AXIS SETTING NOT COM-

In automatic setting mode, axis setting has not been made yet.

PLETE

Perform axis setting on the FSSB setting screen.

5139

FSSB : ERROR

Servo initialization did not terminate normally.

The optical cable may be defective, or there may be an error in connec-

tion to the amplifier or another module.

Check the optical cable and the connection status.

5155

NOT RESTART PROGRAM BY G05

During servo leaning control by G05, an attempt was made to perform

restart operation after feed hold or interlock. This restart operation can-

not be performed. (G05 leaning control terminates at the same time.)

1190

B-63534EN/02

APPENDIX

G. ALARM LIST

Number

Message

Contents

5156

ILLEGAL AXIS OPERATION

In simple high-precision contour control (SHPCC) mode, the controlled

(SHPCC)

axis selection signal (PMC axis control) changes.

In SHPCC mode, the simple synchronous axis selection signal

changes.

5157

PARAMETER ZERO (AICC)

Zero is set in the parameter for the maximum cutting feedrate (parame-

ter No. 1422 or 1432).

Zero is set in the parameter for the acceleration/deceleration before in-

terpolation (parameter No. 1770 or 1771).

Set the parameter correctly.

5196

ILLEGAL OPERATION (HPCC)

Detach operation was performed in HPCC mode. (If detach operation

is performed in HPCC mode, this alarm is issued after the currently

executed block terminates.)

5197

FSSB : OPEN TIME OUT

The CNC permitted FSSB to open, but FSSB was not opened.

5198

FSSB : ID DATA NOT READ

Temporary assignment failed, so amplifier initial ID information could not

be read.

5199

FINE TORQUE SENSING PARAME-

A parameter related to the fine torque sensing function is illegal.

TER

· The storage interval is invalid.

· An invalid axis number is set as the target axis.

Correct the parameter.

5212

SCREEN COPY : PARAMETER ER-

There is a parameter setting error. Check that 4 is set as the I/O channel.

ROR

5213

SCREEN COPY : COMMUNICA-

The memory card cannot be used. Check the memory card. (Check

TION ERROR

whether the memory card is write-protected or defective.)

5214

SCREEN COPY : DATA TRANSFER

Data transfer to the memory card failed.

ERROR

Check whether the memory card space is insufficient and whether the

memory card was removed during data transfer.

5218

ILLEGAL PARAMETER (INCL.

There is an inclination compensation parameter setting error.

COMP)

Cause:

1. The number of pitch error compensation points between the nega-

tive (-) end and positive (+) end exceeds 128.

2. The relationship in magnitude among the inclination compensation

point numbers is incorrect.

3. An inclination compensation point is not located between the nega-

tive (-) end and positive (+) end of the pitch error compensation

points.

4. The amount of compensation per compensation point is too large or

too small.

Correct the parameter.

5219

CAN NOT RETURN

Manual intervention or return is not allowed during three-dimensional

coordinate conversion.

5220

REFERENCE POINT ADJUST-

A parameter for automatically set a reference position is set. (Bit 2 of

MENT MODE

parameter No. 1819 = 1)

Perform automatic setting.

(Position the machine at the reference position manually, then perform

manual reference position return.)

Supplementary: Automatic setting sets bit 2 of parameter No. 1819 to

5222

SRAM CORRECTABLE ERROR

The SRAM correctable error cannot be corrected.

Cause:

A memory problem occurred during memory initialization.

Action:

Replace the master printed circuit board (SRAM module).

1191

G. ALARM LIST

APPENDIX

B-63534EN/02

Number

Message

Contents

5227

FILE NOT FOUND

A specified file is not found during communication with the built-in

Handy File.

5228

SAME NAME USED

There are duplicate file names in the built-in Handy File.

5229

WRITE PROTECTED

A floppy disk in the built-in Handy File is write protected.

5231

TOO MANY FILES

The number of files exceeds the limit during communication with the

built-in Handy File.

5232

DATA OVER-FLOW

There is not enough floppy disk space in the built-in Handy File.

5235

COMMUNICATION ERROR

A communication error occurred during communication with the built-in

Handy File.

5237

READ ERROR

A floppy disk in the built-in Handy File cannot be read from. The floppy

disk may be defective, or the head may be dirty. Alternatively, the Handy

File is defective.

5238

WRITE ERROR

A floppy disk in the built-in Handy File cannot be written to. The floppy

disk may be defective, or the head may be dirty. Alternatively, the Handy

File is defective.

5242

ILLEGAL AXIS NUMBER

The axis number of the synchronous master axis or slave axis is incor-

(M series)

rect. (This alarm is issued when flexible synchronization is turned on.)

Alternatively, the axis number of the slave axis is smaller than that of the

master axis.

5243

DATA OUT OF RANGE

The gear ratio is not set correctly.

(This alarm is issued when flexible

(M series)

synchronization is turned on.)

5244

TOO MANY DI ON

Even when an M code was encountered in automatic operation mode,

(M series)

the flexible synchronization mode signal was not driven on or off.

Check the ladder and M codes.

5245

OTHER AXIS ARE COMMANDED

One of the following command conditions was present during flexible

(M series)

synchronization or when flexible synchronization was turned on:

1. The synchronous master axis or slave axis is the EGB axis.

2. The synchronous master axis or slave axis is the chopping axis.

3. In reference position return mode

5251

ILLEGAL PARAMETER IN G54.2

A fixture offset parameter (No. 7580 to 7588) is illegal. Correct the pa-

rameter.

5252

ILLEGAL P COMMAND IN G54.2

The P value specifying the offset number of a fixture offset is too large.

Correct the program.

5257

G41/G42 NOT ALLOWED IN MDI

G41/G42 (cutter compensation C: M series, tool-nose radius com-

MODE

pensation: T series) was specified in MDI mode. (Depending on the set-

ting of bit 4 of parameter No. 5008)

5300

SET ALL OFFSET DATAS AGAIN

After the inch/metric automatic conversion function (OIM: Bit 0 of pa-

rameter No. 5006) for tool offset data is enabled or disabled, all the tool

offset data must be reset. This message reminds the operator to reset

the data.

If this alarm is issued, reset all the tool offset data. Operating the ma-

chine without resetting the data will result in a malfunction.

5302

ILLEGAL COMMAND IN G68 MODE

A command to set the coordinate system is specified in the coordinate

system rotation mode.

5303

TOUCH PANEL ERROR

A touch panel error occurred.

Cause:

1. The touch panel is kept pressed.

2. The touch panel was pressed when power was turned on.

Remove the above causes, and turn on the power again.

5306

MODE CHANGE ERROR

In a one-touch macro call, mode switching at the time of activation is not

performed correctly.

1192

B-63534EN/02

APPENDIX

G. ALARM LIST

Number

Message

Contents

5307

INTERNAL DATA OVER FLOW

In the following function, internal data exceeds the allowable range.

1) Improvement of the rotation axis feedrate

5311

FSSB:ILLEGAL CONNECTION

A connection related to FSSB is illegal.

This alarm is issued when either of the following is found:

1. Two axes having adjacent servo axis numbers (parameter No.

1023), odd number and even number, are assigned to amplifiers to

which different FSSB systems are connected.

2. The system does not satisfy the requirements for performing HRV

control, and use of two pulse modules connected to different FSSB

systems having different FSSB current control cycles is specified.

5321

S-COMP. VALUE OVERFLOW

The straightness compensation value has exceeded the maximum val-

ue of 32767.

After this alarm is issued, make a manual reference position return.

5400

SPL:ILLEGAL AXIS COMMAND

An axis specified for spline interpolation or smooth interpolation is incorrect.

If an axis that is not the spline axis is specified in spline interpolation

mode, this alarm is issued. The spline axis is the axis specified in a block

containing G06.1 or the next block. For smooth interpolation, the axis

specified in G5.1Q2 is incorrect.

5401

SPL:ILLEGAL COMMAND

In a G code mode in which specification of G06.1 is not permitted, G06.1

is specified.

5402

SPL:ILLEGAL AXIS MOVING

A movement is made along an axis that is not the spline interpolation axis.

For example, in three-dimensional tool compensation mode using an

offset vector of which components are the X-, Y-, and Z-axes, when

two-axis spline interpolation is performed with the two spline axes set

to the X- and Y-axes, a movement along the Z-axis occurs, resulting

in this alarm.

5403

SPL:CAN NOT MAKE VECTOR

Three-dimensional tool compensation vectors cannot be generated.

· When a three-dimensional tool compensation vector is created for the

second or subsequent point, that point, previous point, and next point are

on the same straight line, and that straight line and the three-dimensional

tool compensation vector for the previous point are in parallel.

· When a three-dimensional tool compensation vector is created at the

end point of smooth interpolation or spline interpolation, the end point

and the point two points before are the same.

5405

ILLEGAL PARAMETER IN G41.2/

The parameter setting that determines the relationship between the

rotation axis and rotation plane is incorrect.

5406

G41.3/G40 FORMAT ERROR

1) A G41.3 or G40 block contains a move command.

2) A G1.3 block contains a G code or M code for which buffering is sup-

pressed.

5407

ILLEGAL COMMAND IN G41.3

1) A G code that belongs to group 01 except G00 and G01 is specified

in G41.3 mode.

2) An offset command (a G code belonging to group 07) is specified in

G41.3 mode.

3) The block next to G41.3 (startup) contains no movement.

5408

G41.3 ILLEGAL START_UP

1) In a mode of group 01 except G00 and G01, G41.3 (startup) is speci-

fied.

2) At startup, the included angle of the tool direction vector and move

direction vector is 0 or 180 degrees.

5409

ILLEGAL PARAMETER IN G41.3

The parameter setting (No. xxxx to xxxx) that determines the relation-

ship between the rotation axis and rotation plane is incorrect.

5411

NURBS:ILLEGAL ORDER

The number of steps is specified incorrectly.

5412

NURBS:NO KNOT COMMAND

No knot is specified. Alternatively, in NURBS interpolation mode, a

block not relating to NURBS interpolation is specified.

1193

G. ALARM LIST

APPENDIX

B-63534EN/02

Number

Message

Contents

5413

NURBS:ILLEGAL AXIS COMMAND

An axis not specified with controlled points is specified in the first block.

5414

NURBS:ILLEGAL KNOT

The number of blocks containing knots only is insufficient.

5415

NURBS:ILLEGAL CANCEL

Although NURBS interpolation is not completed yet, the NURBS inter-

polation mode is turned off.

5416

NURBS:ILLEGAL MODE

A mode that cannot be used with NURBS interpolation mode is speci-

fied in NURBS interpolation mode.

5417

NURBS:ILLEGAL MULTI-KNOT

As many knots as the number of steps are not specified at the start and

end points.

5418

NURBS:ILLEGAL KNOT VALUE

Knots do not increase in monotone.

5420

ILLEGAL PARAMETER IN

A parameter related to pivot tool length compensation is incorrect.

G43.4/G43.5

5421

ILLEGAL COMMAND IN G43.4/G43.5

In pivot tool length compensation (type 2) mode, a rotation axis is specified.

5422

EXCESS VELOCITY IN

As a result of pivot tool length compensation, an attempt was made to

G43.4/G43.5

move the tool along an axis at a feedrate exceeding the maximum cut-

ting feedrate.

5425

ILLEGAL OFFSET VALUE

The offset number is incorrect.

5430

ILLEGAL COMMAND IN 3-D CIR

In a modal state in which three-dimensional circular interpolation can-

not be specified, a three-dimensional circular interpolation

(G02.4/G03.4) is specified. Alternatively, in three-dimensional circular

interpolation mode, a code that cannot be specified is specified.

5432

G02.4/G03.4 FORMAT ERROR

A three-dimensional circular interpolation command (G02.4/G03.4) is

incorrect.

5433

MANUAL INTERVENTION IN 3-D

In three-dimensional circular interpolation mode (G02.4/G03.4), manu-

CIR

al intervention was made when the manual absolute switch was on.

5435

PARAMETER OUT OF RANGE

Incorrect parameter setting (set value range)

(TLAC)

5436

PARAMETER SETTING ERROR 1

Incorrect parameter setting (setting of the rotation axis)

(TLAC)

5437

PARAMETER SETTING ERROR 2

Incorrect parameter setting (setting of the tool axis)

(TLAC)

5440

ILLEGAL DRILLING AXIS

The drilling axis specified for the drilling canned cycle is incorrect.

SELECTED

The G code command block of the canned cycle does not specify the

Z point of the drilling axis. When there is a parallel axis with the drilling

axis, the parallel axis is also specified at the same time.

5445

CRC:MOTION IN G39

Corner circular interpolation (G39) of cutter compensation is not speci-

fied alone but is specified with a move command.

5446

CRC:NO AVOIDANCE

Because there is no interference evade vector, the interference check

evade function of cutter compensation cannot evade interference.

5447

CRC:DANGEROUS AVOIDANCE

The interference check evade function of cutter compensation deter-

mines that an evade operation will lead to danger.

5448

CRC:INTERFERENCE TO AVD.

In the interference check evade function of cutter compensation, a further

interference occurs for an already created interference evade vector.

1194

B-63534EN/02

APPENDIX

G. ALARM LIST

Number

Message

Contents

5452

IMPROPER G-CODE (5AXIS

A G code that cannot be specified is found. (5-axis mode)

MODE)

This alarm is issued when:

1) Three-dimensional cutter compensation (side-face offset and lead-

ing-edge offset) is applied during cutter compensation, or cutter

compensation is applied during three-dimensional cutter com-

pensation (side-face offset and leading-edge offset).

2) A leading-edge offset of three-dimensional cutter compensation is

applied during side-face offsetting of three-dimensional cutter com-

pensation, or a side-face offset of three-dimensional cutter com-

pensation is applied during leading-edge offsetting of three-dimen-

sional cutter compensation.

3) Tool axis direction tool length compensation is applied during tool

length compensation, or tool length compensation is applied during

tool axis direction tool length compensation.

4) Tool center point control is provided during tool length compensa-

tion, or tool length compensation is applied during tool center point

control.

5) Tool center point control is provided during tool axis direction tool

length compensation, or tool axis direction tool length compensation

is applied during tool center point control.

If this alarm is issued, cancel the relevant mode, then specify a differ-

ent mode.

5453

NOTE: G68 IS CANCELED (HPCC)

When bit 2 of parameter No. 5400 is set to 1, and a reset does not cancel

G68, this alarm is issued at the time of program restart.

To release this alarm, press <RESET> and <CAN>. Once this operation

is performed, the alarm will not be issued at the next restart.

5455

ILLEGAL ACC. PARAMETER

A permissible acceleration parameter for optimum torque acceleration/

deceleration is incorrect. The cause is one of the following:

1) The ratio of the deceleration rate to the acceleration rate is below the

limit.

2) The time required for deceleration to a speed of 0 exceeds the maxi-

mum value.

NOTE

AICC designates AI contour control.

2) Background edit alarm

Number

Message

Contents

???

BP/S alarm

BP/S alarm occurs in the same number as the P/S alarm that occurs in

ordinary program edit.

(P/S alarm No. 070, 071, 072, 073, 074, 085 to 087)

Modify the program.

140

BP/S alarm

It was attempted to select or delete in the background a program being

selected in the foreground. (NOTE)

Use background editing correctly.

NOTE

Alarm in background edit is displayed in the key input line of the background edit screen instead

of the ordinary alarm screen and is resettable by any of the MDI key operation.

1195

G. ALARM LIST

APPENDIX

B-63534EN/02

3) Absolute pulse coder (APC) alarm

Number

Message

Contents

300

nth-axis origin return

Manual reference position return is required for the nth-axis (n=1 to 8).

301

APC alarm: nth-axis communication

nth-axis (n=1 to 8) APC communication error. Failure in data transmission

Possible causes include a faulty APC, cable, or servo interface module.

302

APC alarm: nth-axis over time

nth-axis (n=1 to 8) APC overtime error.

Failure in data transmission.

Possible causes include a faulty APC, cable, or servo interface module.

303

APC alarm: nth-axis framing

nth-axis (n=1 to 8) APC framing error. Failure in data transmission.

Possible causes include a faulty APC, cable, or servo interface module.

304

APC alarm: nth-axis parity

nth-axis (n=1 to 8) APC parity error.

Failure in data transmission.

Possible causes include a faulty APC, cable, or servo interface module.

305

APC alarm: nth-axis pulse error

nth-axis (n=1 to 8) APC pulse error alarm.

APC alarm.APC or cable may be faulty.

306

APC alarm: nth-axis battery voltage

nth-axis (n=1 to 8) APC battery voltage has decreased to a low level so

that the data cannot be held.

APC alarm. Battery or cable may be faulty.

307

APC alarm: nth-axis battery low 1

nth-axis (n=1 to 8) axis APC battery voltage reaches a level where the

battery must be renewed.

APC alarm. Replace the battery.

308

APC alarm: nth-axis battery low 2

nth-axis (n=1 to 8) APC battery voltage has reached a level where the

battery must be renewed (including when power is OFF).

APC alarm .Replace battery.

309

APC ALARM : n AXIS ZRN

An attempt was made to perform reference position return without rotat-

IMPOSSIBL

ing the motor through one or more turns. Rotate the motor through one

or more turns, turn off the power then on again, then perform reference

position return.

4) Industosyn alarms

No.

Message

Contents

330

INDUCTOSYN:DATA ALARM

The absolute-position data (offset data) from Inductosyn cannot be

detected.

331

INDUCTOSYN:ILLEGAL PRM

Parameter No. 1874, 1875, or 1876 is set to 0.

5) Serial pulse coder (SPC) alarms

When either of the following alarms is issued, a possible cause is a faulty serial pulse coder or cable.

No.

Message

Description

360

n AXIS : ABNORMAL CHECKSUM

A checksum error occurred in the built-in pulse coder.

(INT)

361

n AXIS : ABNORMAL PHASE DATA

A phase data error occurred in the built-in pulse coder.

(INT)

362

n AXIS : ABNORMAL REV.DATA

A rotation speed count error occurred in the built-in pulse coder.

(INT)

363

n AXIS : ABNORMAL CLOCK (INT)

A clock error occurred in the built-in pulse coder.

364

n AXIS : SOFT PHASE ALARM (INT)

The digital servo software detected invalid data in the built-in pulse

coder.

365

n AXIS : BROKEN LED (INT)

An LED error occurred in the built-in pulse coder.

366

n AXIS : PULSE MISS (INT)

A pulse error occurred in the built-in pulse coder.

367

n AXIS : COUNT MISS (INT)

A count error occurred in the built-in pulse coder.

1196

B-63534EN/02

APPENDIX

G. ALARM LIST

No.

Message

Description

368

n AXIS : SERIAL DATA ERROR

Communication data from the built-in pulse coder cannot be re-

(INT)

ceived.

369

n AXIS : DATA TRANS. ERROR

A CRC or stop bit error occurred in the communication data being

(INT)

received from the built-in pulse coder.

380

n AXIS : BROKEN LED (EXT)

The separate detector is erroneous.

381

n AXIS : ABNORMAL PHASE

A phase data error occurred in the separate linear scale.

(EXT LIN)

382

n AXIS : COUNT MISS (EXT)

A pulse error occurred in the separate detector.

383

n AXIS : PULSE MISS (EXT)

A count error occurred in the separate detector.

384

n AXIS : SOFT PHASE ALARM

The digital servo software detected invalid data in the separate de-

(EXT)

tector.

385

n AXIS : SERIAL DATA ERROR

Communication data from the separate detector cannot be received.

(EXT)

386

n AXIS : DATA TRANS. ERROR

A CRC or stop bit error occurred in the communication data being

(EXT)

received from the separate detector.

387

n AXIS : ABNORMAL ENCODER

An error occurs in the separate detector. For details, contact the

(EXT)

manufacturer of the scale.

D The details of serial

pulse coder alarm

202

CSA

BLA

PHA

PCA

BZA

CKA

SPH

#6 (CSA) : Check sum alarm has occurred.

#5 (BLA) : Battery low alarm has occurred.

#4 (PHA) : Phase data trouble alarm has occurred.

#3 (PCA) : Speed count trouble alarm has occurred.

#2 (BZA) : Battery zero alarm has occurred.

#1 (CKA) : Clock alarm has occurred.

#0 (SPH) : Soft phase data trouble alarm has occurred.

203

DTE

CRC

STB

PRM

#7 (DTE) : Data error has occurred.

#6 (CRC) : CRC error has occurred.

#5 (STB) : Stop bit error has occurred.

#4 (PRM) : Parameter error alarm has occurred. In this case, a servo parameter error

alarm (No. 417) is also output.

1197

G. ALARM LIST

APPENDIX

B-63534EN/02

6) Servo alarms (1/2)

Number

Message

Contents

401

SERVO ALARM: n-TH AXIS VRDY

The n-th axis (axis 1-8) servo amplifier READY signal (DRDY) went off.

OFF

Refer to procedure of trouble shooting.

402

SERVO ALARM: SV CARD NOT EX-

The axis control card is not provided.

IST

403

SERVO ALARM: CARD/SOFT MIS-

The combination of the axis control card and servo software is illegal.

MATCH

The possible causes are as follows:

· A correct axis control card is not provided.

· Correct servo software is not installed on flash memory.

404

SERVO ALARM: n-TH AXIS VRDY

Even though the n-th axis (axis 1-8) READY signal (MCON) went off,

the servo amplifier READY signal (DRDY) is still on. Or, when the power

was turned on, DRDY went on even though MCON was off.

Check that the servo interface module and servo amp are connected.

405

SERVO ALARM: (ZERO POINT RE-

Position control system fault. Due to an NC or servo system fault in the

TURN FAULT)

reference position return, there is the possibility that reference position

return could not be executed correctly. Try again from the manual refer-

ence position return.

407

SERVO ALARM: EXCESS ERROR

The difference in synchronous axis position deviation exceeded the set

value.

Position control system fault. Due to an NC or servo system fault in the

reference position return, there is the possibility that reference position

return could not be executed correctly. Try again from the manual refer-

ence position return.

409

SERVO ALARM: n AXIS TORQUE

Abnormal servo motor load has been detected. Alternatively, abnormal

ALM

spindle motor load has been detected in Cs mode.

410

SERVO ALARM: n-TH AXIS - EX-

The position deviation value when the n-th axis (axis 1-8) stops is larg-

CESS ERROR

er than the set value.

Refer to procedure of trouble shooting.

411

SERVO ALARM: n-TH AXIS - EX-

The position deviation value when the n-th axis (axis 1-8) moves is

CESS ERROR

larger than the set value.

Refer to procedure of trouble shooting.

413

SERVO ALARM: n-th AXIS - LSI

The contents of the error register for the n-th axis (axis 1-8) exceeded

OVERFLOW

"2³¹ power. This error usually occurs as the result of an improperly set

parameters.

415

SERVO ALARM: n-TH AXIS - EX-

A speed higher than 524288000 units/s was attempted to be set in the

CESS SHIFT

n-th axis (axis 1-8). This error occurs as the result of improperly set

CMR.

1198

B-63534EN/02

APPENDIX

G. ALARM LIST

Number

Message

Contents

417

SERVO ALARM: n-TH AXIS - PA-

This alarm occurs when the n-th axis (axis 1-8) is in one of the condi-

RAMETER INCORRECT

tions listed below. (Digital servo system alarm)

1) The value set in Parameter No. 2020 (motor form) is out of the speci-

fied limit.

2) A proper value (111 or -111) is not set in parameter No.2022 (motor

revolution direction).

3) Illegal data (a value below 0, etc.) was set in parameter No. 2023

(number of speed feedback pulses per motor revolution).

4) Illegal data (a value below 0, etc.) was set in parameter No. 2024

(number of position feedback pulses per motor revolution).

5) Parameters No. 2084 and No. 2085 (flexible field gear rate) have not

been set.

6) A value outside the limit of {1 to the number of control axes} or a non-

continuous value (Parameter 1023 (servo axis number) contains a

value out of the range from 1 to the number of axes, or an isolated

value (for example, 4 not prceded by 3).was set in parameter No.

1023 (servo axisnumber).

420

SERVO ALARM: n AXIS SYNC

During simple synchronous control, the difference between the torque

TORQUE

commands for the master and slave axes exceeded the value set in pa-

rameter No. 2031.

421

SERVO ALARM: n AXIS EXCESS

The difference between the errors in the semi-closed loop and closed

ER (D)

loop has become excessive during dual position feedback. Check the

values of the dual position conversion coefficients in parameters No.

2078 and 2079.

422

SERVO ALARM: n AXIS

In torque control of PMC axis control, a specified allowable speed

has been exceeded.

423

SERVO ALARM: n AXIS

In torque control of PMC axis control, the parameter-set allowable

cumulative travel distance has been exceeded.

430

n AXIS : SV. MOTOR OVERHEAT

A servo motor overheat occurred.

431

n AXIS : CNV. OVERLOAD

1) PSM: Overheat occurred.

2) β series SVU: Overheat occurred.

432

n AXIS : CNV. LOWVOLT CON.

1) PSM: The control power supply voltage has dropped.

2) PSMR: The control power supply voltage has dropped.

3) β series SVU: The control power supply voltage has dropped.

433

n AXIS : CNV. LOWVOLT DC LINK

1) PSM: The DC link voltage has dropped.

2) PSMR: The DC link voltage has dropped.

3) α series SVU: The DC link voltage has dropped.

4) β series SVU: The DC link voltage has dropped.

434

n AXIS : INV. LOWVOLT CONTROL

SVM: The control power supply voltage has dropped.

435

n AXIS : INV. LOWVOLT DC LINK

SVM: The DC link voltage has dropped.

436

n AXIS : SOFTTHERMAL (OVC)

The digital servo software detected the soft thermal state (OVC).

437

n AXIS : CNV. OVERCURRENT

PSM: Overcurrent flowed into the input circuit.

POWER

438

n AXIS : INV. ABNORMAL CUR-

1) SVM: The motor current is too high.

RENT

2) α series SVU: The motor current is too high.

3) β series SVU: The motor current is too high.

1199

G. ALARM LIST

APPENDIX

B-63534EN/02

Number

Message

Contents

439

n AXIS : CNV. OVERVOLT POWER

1) PSM: The DC link voltage is too high.

2) PSMR: The DC link voltage is too high.

3) α series SVU: The C link voltage is too high.

4) β series SVU: The link voltage is too high.

440

n AXIS : CNV. EX DECELERATION

1) PSMR: The regenerative discharge amount is too large.

POW.

2) α series SVU: The regenerative discharge amount is too large. Al-

ternatively, the regenerative discharge circuit is abnormal.

441

n AXIS : ABNORMAL CURRENT

The digital servo software detected an abnormality in the motor cur-

OFFSET

rent detection circuit.

442

n AXIS : CNV. CHARGE FAULT

1) PSM: The spare discharge circuit of the DC link is abnormal.

2) PSMR: The spare discharge circuit of the DC link is abnormal.

443

n AXIS : CNV. COOLING FAN FAIL-

1) PSM: The internal stirring fan failed.

URE

2) PSMR: The internal stirring fan failed.

3) β series SVU: The internal stirring fan failed.

444

n AXIS : INV. COOLING FAN FAIL-

SVM: The internal stirring fan failed.

URE

445

n AXIS : SOFT DISCONNECT

The digital servo software detected a broken wire in the pulse coder.

ALARM

446

n AXIS : HARD DISCONNECT

A broken wire in the built-in pulse coder was detected by hardware.

ALARM

447

n AXIS : HARD DISCONNECT (EXT)

A broken wire in the separate detector was detected by hardware.

448

n AXIS : UNMATCHED FEEDBACK

The sign of feedback data from the built-in pulse coder differs from

ALARM

that of feedback data from the separate detector.

449

n AXIS : INV. IPM ALARM

1) SVM: IPM (intelligent power module) detected an alarm.

2) α series SVU: IPM (intelligent power module) detected an alarm.

453

n AXIS : SPC SOFT DISCONNECT

Software disconnection alarm of the α pulse coder.

ALARM

Turn off the power to the CNC, then remove and insert the pulse cod-

er cable. If this alarm is issued again, replace the pulse coder.

456

ILLEGAL CURRENT LOOP

The current control cycle settings (parameter No. 2004, bit 0 of pa-

rameter No. 2003, and bit 0 of parameter No. 2013) are incorrect.

Possible problems are as follows.

- For the two axes whose servo axis numbers (settings of parameter

No. 1023) are an odd number followed by an even number (a pair

of axes 1 and 2 or axes 5 and 6, for example), a different current con-

trol cycle is set for each of the axes.

- The requirements for slaves needed for the set current control cycle,

including the number, type, and connection method of them, are not

satisfied.

457

ILLEGAL HI HRV (250US)

Use of high-speed HRV is specified although the current control

cycle is 200 ms.

458

CURRENT LOOP ERROR

The current control cycle setting does not match the actual current

control cycle.

459

HI HRV SETTING ERROR

For the two axes whose servo axis numbers (settings of parameter

No. 1023) are an odd number followed by an even number (a pair of

axes 1 and 2 or axes 5 and 6, for example), the SVM for one of the

axes supports high-speed HRV control but the SVM for the other

does not. Refer to the SVM specification.

1200

B-63534EN/02

APPENDIX

G. ALARM LIST

Number

Message

Contents

460

n AXIS : FSSB DISCONNECT

FSSB communication was disconnected suddenly. The possible

causes are as follows:

1) The FSSB communication cable was disconnected or broken.

2) The power to the amplifier was turned off suddenly.

3) A low-voltage alarm was issued by the amplifier.

461

n AXIS : ILLEGAL AMP INTERFACE

The axes of the 2-axis amplifier were assigned to the fast type inter-

face.

462

n AXIS : SEND CNC DATA FAILED

Because of an FSSB communication error, a slave could not receive

correct data.

463

n AXIS : SEND SLAVE DATA

Because of an FSSB communication error, the servo system could

FAILED

not receive correct data.

464

n AXIS : WRITE ID DATA FAILED

An attempt was made to write maintenance information on the ampli-

fier maintenance screen, but it failed.

465

n AXIS : READ ID DATA FAILED

At power-up, amplifier initial ID information could not be read.

466

n AXIS : MOTOR/AMP COMBINA-

The maximum current rating for the amplifier does not match that for

TION

the motor.

467

n AXIS : ILLEGAL SETTING OF

The servo function for the following has not been enabled when an

AXIS

axis occupying a single DSP (corresponding to two ordinary axes) is

specified on the axis setting screen.

1. Learning control (bit 5 of parameter No. 2008 = 1)

2. High-speed current loop (bit 0 of parameter No. 2004 = 1)

3. High-speed interface axis (bit 4 of parameter No. 2005 = 1)

468

HI HRV SETTING ERROR (AMP)

Use of high-speed HRV is specified for a controlled axis of an ampli-

fier which does not support high-speed HRV.

D Details of servo alarm

The details of servo alarm are displayed in the diagnosis display (No. 200

and No.204) as shown below.

200

OVL

OVC

HCA

HVA

DCA

FBA

OFA

#7 (OVL) : An overload alarm is being generated.

#6 (LV) : A low voltage alarm is being generated in servo amp.

#5 (OVC) : A overcurrent alarm is being generated inside of digital servo.

#4 (HCA) : An abnormal current alarm is being generated in servo amp.

#3 (HVA) : An overvoltage alarm is being generated in servo amp.

#2 (DCA) : A regenerative discharge circuit alarm is being generated in servo amp.

#1 (FBA) : A disconnection alarm is being generated.

#0 (OFA) : An overflow alarm is being generated inside of digital servo.

201

ALD

EXP

When OVL equal 1 in diagnostic data No.200 (servo alarm No. 400 is

being generated):

#7 (ALD)

0 : Motor overheating

1 : Amplifier overheating

When FBAL equal 1 in diagnostic data No.200 (servo alarm No. 416 is

being generated):

1201

G. ALARM LIST

APPENDIX

B-63534EN/02

ALD

EXP

Alarm details

Built-in pulse coder disconnection (hardware)

Separately installed pulse coder disconnection

(hardware)

Pulse coder is not connected due to software.

204

OFS

MCC

LDA

PMS

#6 (OFS)

A current conversion error has occured in the digital servo.

#5 (MCC) : A magnetic contactor contact in the servo amplifier has welded.

#4 (LDA) : The LED indicates that serial pulse coder C is defective

#3 (PMS) : A feedback pulse error has occured because the feedback cable is

defective.

7) Over travel alarms

Number

Message

Contents

500

OVER TRAVEL : +n

Exceeded the n-th axis (axis 1 to 8) + side stored stroke limit I.

(Parameter No.1320 or 1326 NOTE)

501

OVER TRAVEL : -n

Exceeded the n-th axis (axis 1 to 8) - side stored stroke limit I.

(Parameter No.1321 or 1327 NOTE)

502

OVER TRAVEL : +n

Exceeded the n-th axis (axis 1 to 8) + side stored stroke limit II.

(Parameter No.1322 )

503

OVER TRAVEL : -n

Exceeded the n-th axis (axis 1 to 8) - side stored stroke limit II.

(Parameter No.1323)

504

OVER TRAVEL : +n

Exceeded the n-th axis (axis 1 to 8) - side stored stroke limit III.

(Parameter No.1324)

505

OVER TRAVEL : -n

Exceeded the n-th axis (axis 1 to 8) - side stored stroke limit III.

(Parameter No.1325)

506

OVER TRAVEL : +n

Exceeded the n-th axis (axis 1 to 8) + side hardware OT.

507

OVER TRAVEL : -n

Exceeded the n-th axis (axis 1 to 8) - side hardware OT.

510

OVER TRAVEL : +n

A stroke limit check, made before starting movement, found that the end

point of a block falls within the plus (+) side inhibited area along the n-

axis defined by a stroke limit. Correct the program.

511

OVER TRAVEL : -n

A stroke limit check, made before starting movement, found that the end

point of a block falls within the minus (-) side inhibited area along the

N-axis defined by a stroke limit. Correct the program.

514

INTERFERENCE : +n

The rotation area interference check function found interference on the

plus side of the n axis.

515

INTERFERENCE : -n

The rotation area interference check function found interference on the

minus side of the n axis.

NOTE

Parameters 1326 and 1327 are effective when EXLM (stroke limit switch signal) is on.

1202

B-63534EN/02

APPENDIX

G. ALARM LIST

8) Servo alarms (2/2)

Number

Message

Contents

600

n AXIS : INV. DC LINK OVER CUR-

DC link current is too large.

RENT

601

n AXIS : INV. RADIATOR FAN FAIL-

The external dissipator stirring fan failed.

URE

602

n AXIS : INV. OVERHEAT

The servo amplifier was overheated.

603

n AXIS : INV. IPM ALARM (OH)

The IPM (intelligent power module) detected an overheat alarm.

604

n AXIS : AMP. COMMUNICATION

Communication between the SVM and the PSM failed.

ERROR

605

n AXIS : CNV. EX. DISCHARGE

PSMR: Regenerative power is too large.

POW.

606

n AXIS : CNV. RADIATOR FAN FAIL-

PSM: The external dissipator stirring fan failed.

URE

PSMR: The external dissipator stirring fan failed.

607

n AXIS : CNV. SINGLE PHASE FAIL-

PSM: Input voltage is in the open-phase condition.

URE

PSMR: Input voltage is in the open-phase condition.

9) Overheat alarms

Number

Message

Contents

700

OVERHEAT: CONTROL UNIT

Control unit overheat

Check that the fan motor operates normally, and clean the air filter.

701

OVERHEAT: FAN MOTOR

The fan motor on the top of the cabinet for the contorl unit is overheated.

Check the operation of the fan motor and replace the motor if necessary.

704

OVERHEAT: SPINDLE

Spindle overheat in the spindle fluctuation detection

1) If the cutting load is heavy, relieve the cutting condition.

2) Check whether the cutting tool is share.

3) Another posible cause is a faulty spindle amp.

10) Rigid tapping alarm

Number

Message

Contents

740

RIGID TAP ALARM : EXCESS

During rigid tapping, the position deviation of the spindle in the stop

ERROR

state exceeded the setting.

741

RIGID TAP ALARM : EXCESS

During rigid tapping, the position deviation of the spindle in the stop

ERROR

state exceeded the setting.

742

RIGID TAP ALARM : LSI OVER

During rigid tapping, an LSI overflow occurred on the spindle side.

FLOW

1203

G. ALARM LIST

APPENDIX

B-63534EN/02

11) Serial spindle alarms

Number

Message

Contents

749

S-SPINDLE LSI ERROR

It is serial communication error while system is executing after power

supply on. Following reasons can be considered.

1) Optical cable connection is fault or cable is not connected or cable

is cut.

2) MAIN CPU board or option 2 board is fault.

3) Spindle amp. printed board is fault.

4) The spindle amplifier is under an abnormal condition. (The SPM in-

dication is A, A1, A2, or the like, depending on the type of the ab-

normality.)

If this alarm occurs when CNC power supply is turned on or when

this alarm can not be cleared even if CNC is reset, turn off the power

supply also turn off the power supply in spindle side.

If the spindle amplifier is under an abnormal condition, check the

SPM indication (A, A1, A2, or the like). Then, refer to the FANUC

SERVO MOTOR ai series MAINTENANCE MANUAL (B-65285EN)

or FANUC SERVO MOTOR a series MAINTENANCE MANUAL

(B-65165E) to solve the problem.

750

SPINDLE SERIAL LINK START

This alarm is generated when the spindle control unit is not ready for

FAULT

starting correctly when the power is turned on in the system with the

serial spindle.

The four reasons can be considered as follows:

1) An improperly connected optic cable, or the spindle control unit’s

power is OFF.

2) When the NC power was turned on under alarm conditions other

than SU-01 or AL-24 which are shown on the LED display of the

spindle control unit.

In this case, turn the spindle amplifier power off once and perform

startup again.

3) Other reasons (improper combination of hardware)

This alarm does not occur after the system including the spindle con-

trol unit is activated.

4) The second spindle (when SP2, bit 4 of parameter No. 3701, is 1)

is in one of the above conditions 1) to 3).

See diagnostic display No. 409 for details.

752

FIRST SPINDLE MODE CHANGE

This alarm is generated if the system does not properly terminate a

FAULT

mode change. The modes include the Cs contouring, spindle position-

ing, rigid tapping, and spindle control modes. The alarm is activated if

the spindle control unit does not respond correctly to the mode change

command issued by the NC.

754

SPINDLE-1 ABNORMAL TORQUE

Abnormal first spindle motor load has been detected.

ALM

762

SECOND SPINDLE MODE

Refer to alarm No. 752.(For 2nd axis)

CHANGE FAULT

764

SPINDLE-2 ABNORMAL TORQUE

Same as alarm No. 754 (for the second spindle)

ALM

772

SPINDLE-3 MODE CHANGE ER-

Same as alarm No. 752 (for the third spindle)

ROR

774

SPINDLE-3 ABNORMAL TORQUE

Same as alarm No. 754 (for the third spindle)

ALM

1204

B-63534EN/02

APPENDIX

G. ALARM LIST

Number

Message

Contents

782

SPINDLE-4 MODE CHANGE ER-

Same as alarm number 752 (for the fourth spindle)

ROR

784

SPINDLE-4 ABNORMAL TORQUE

Same as alarm number 754 (for the fourth spindle)

ALM

D The details of spindle

alarm No.750

1st and 2nd spindles

409

SPE

S2E

S1E

SHE

#3 (SPE)

0 :

In the spindle serial control, the serial spindle parameters fulfill the

spindle unit startup conditions.

1 :

In the spindle serial control, the serial spindle parameters do not fulfill

the spindle unit startup conditions.

#2 (S2E)

0 :

The second spindle is normal during the spindle serial control startup.

1 :

The second spindle was detected to have a fault during the spindle

serial control startup.

#1 (S1E)

0 :

The first spindle is normal during the spindle serial control startup.

1 :

The first spindle was detected to have a fault during the spindle axis

serial control startup.

#0 (SHE)

0 :

The serial communications module in the CNC is normal.

1 :

The serial communications module in the CNC was detected to have a

fault.

3rd and 4th spindles

The details of spindle alarm No. 750 are displayed in the diagnosis display

(No. 409) as shown below.

409

SPE

S4E

S3E

SHE

#3 (SPE)

0 : In the spindle serial control, the serial spindle parameters fulfill the

spindle unit startup conditions.

1 : In the spindle serial control, the serial spindle parameters do not fulfill

the spindle unit startup conditions.

#2 (S2E)

0 : The fourth spindle is normal during the spindle serial control startup.

1 : The fourth spindle was detected to have a fault during the spindle

serial control startup.

#1 (S1E)

0 : The third spindle is normal during the spindle serial control startup.

1 : The third spindle was detected to have a fault during the spindle axis

serial control startup.

#0 (SHE)

0 : The serial communications module in the CNC is normal.

1 : The serial communications module in the CNC was detected to have a

fault.

1205

G. ALARM LIST

APPENDIX

B-63534EN/02

Alarm List (Serial Spindle)

When a serial spindle alarm occurs, the following number is displayed on

the CNC. n is a number corresponding to the spindle on which an alarm

occurs.

(n = 1: First spindle; n = 2: Second spindle; etc.)

NOTE*1

Note that the meanings of the SPM indications differ

depending on which LED, the red or yellow LED, is on.

When the red LED is on, the SPM indicates a 2-digit alarm

number. When the yellow LED is on, the SPM indicates an

error number that designates a sequence problem (for

example, when a rotation command is entered with the

emergency stop state not released).

³ See Appendix A.4, “Error Codes (Serial Spindle).”

Alarm Numbers and Alarms Displayed on the αi Series Spindle Amplifier

SPM in-

No.

Message

dica-

Faulty location and remedy

Description

tion(*1)

(750)

SPINDLE SERIAL LINK

Replace the ROM on the SPM

The program does not start normally.

ERROR

control printed circuit board.

ROM series error or hardware ab-

Replace the SPM control printed

normality on the SPM control printed

circuit board.

circuit board

(749)

S-SPINDLE LSI ERROR

Replace the SPM control printed cir-

An abnormality was detected in the

cuit board.

CPU peripheral circuit of the SPM

control circuit.

7n01

SPN_n_ : MOTOR OVER-

Check and correct the peripheral

The thermostat embedded in the mo-

HEAT

temperature and load status.

tor winding operated.

If the cooling fan stops, replace it.

The internal temperature of the motor

exceeds the specified level.

The motor is used in excess of the

continuous rating, or the cooling com-

ponent is abnormal.

7n02

SPN_n_ : EX SPEED ER-

Check and correct the cutting

The motor speed cannot follow a spe-

ROR

conditions to decrease the load.

cified speed.

Correct parameter No. 4082.

An excessive motor load torque is de-

tected.

The acceleration/deceleration time in

parameter No. 4082 is insufficient.

7n03

SPN_n_ : FUSE ON DC

Replace the SPM unit.

The PSM becomes ready (00 is indi-

LINK BLOWN

Check the motor insulation status.

cated), but the DC link voltage is too

Replace the interface cable.

low in the SPM.

The fuse in the DC link section in the

SPM is blown. (The power device is

damaged or the motor is ground-

fault.)

The JX1A/JX1B connection cable is

abnormal.

7n06

SPN_n_ : THERMAL

Check and correct the parameter.

The temperature sensor of the motor

SENSOR DIS-

Replace the feedback cable.

is disconnected.

CONNECT

1206

B-63534EN/02

APPENDIX

G. ALARM LIST

SPM in-

No.

Message

dica-

Faulty location and remedy

Description

tion(*1)

7n07

SPN_n_ : OVERSPEED

Check for a sequence error. (For ex-

The motor speed has exceeded

ample, check whether spindle syn-

115% of its rated speed.

chronization was specified when the

When the spindle axis was in position

spindle could not be turned.)

control mode, positional deviations

were accumulated excessively (SFR

and SRV were turned off during

spindle synchronization.)

7n09

SPN_n_ : OVERHEAT

Improve the heat sink cooling sta-

Abnormal temperature rise of the

MAIN CIRCUIT

tus.

power transistor radiator

If the heat sink cooling fan stops,

replace the SPM unit.

7n11

SPN_n_ : OVERVOLT

Check the selected PSM.

Overvoltage of the DC link section of

POW CIRCUIT

Check the input power voltage and

the PSM was detected. (PSM alarm

change in power during motor de-

indication: 7)

celeration. If the voltage exceeds

PSM selection error. (The maximum

253 VAC (for the 200-V system) or

output specification of the PSM is ex-

530 VAC (for the 400-V system),

ceeded.)

improve the power supply imped-

ance.

7n12

SPN_n_ : OVERCUR-

Check the motor insulation status.

The motor output current is abnormal-

RENT POW

Check the spindle parameters.

ly high.

CIRCUIT

Replace the SPM unit.

A motor-specific parameter does not

match the motor model.

Poor motor insulation

7n15

SPN_n_ : SP SWITCH

Check and correct the ladder se-

The switch sequence in spindle

CONTROL

quence.

switch/output switch operation is ab-

ALARM

Replace the switching MC.

normal.

The switching MC contact status

check signal and command do not

match.

7n16

SPN_n_ : RAM FAULT

Replace the SPM control printed cir-

Abnormality in an SPM control circuit

cuit board.

component is detected. (RAM for ex-

ternal data is abnormal.)

7n18

SPN_n_ : SUMCHECK

Replace the SPM control printed cir-

Abnormality in an SPM control circuit

ERROR PGM

cuit board.

component is detected.

(Program

DATA

ROM data is abnormal.)

7n19

SPN_n_ : EX OFFSET

Replace the SPM unit.

Abnormality in an SPM component is

CURRENT U

detected. (The initial value for the U

phase current detection circuit is ab-

normal.)

7n20

SPN_n_ : EX OFFSET

Replace the SPM unit.

Abnormality in an SPM component is

CURRENT V

detected.

(The initial value of the V

phase current detection circuit is ab-

normal.)

7n21

SPN_n_ : POS SENSOR

Check and correct the parameters.

The polarity parameter setting of the

POLARITY

(No. 4000#0, 4001#4)

position sensor is wrong.

ERROR

1207

G. ALARM LIST

APPENDIX

B-63534EN/02

SPM in-

No.

Message

dica-

Faulty location and remedy

Description

tion(*1)

7n24

SPN_n_ : SERIAL

Place the CNC-to-spindle cable

The CNC power is turned off (normal

TRANSFER

away from the power cable.

power-off or broken cable).

ERROR

Replace the cable.

An error is detected in communica-

tion data transferred to the CNC.

7n26

SPN_n_ : DISCONNECT

Replace the cable.

The signal amplitude of the detection

C-VELO DE-

Re-adjust the pre-amplifier.

signal (connector JY2) on the Cs con-

TECT

tour control motor side is abnormal.

(Unconnected cable, adjustment er-

ror, etc.)

7n27

SPN_n_ : DISCONNECT

Replace the cable.

The spindle position coder (con-

POS-CODER

Re-adjust the BZ sensor signal.

nector JY4) signal is abnormal.

The signal amplitude (connector

JY2) of the MZ or BZ sensor is ab-

normal.

(Unconnected cable, adjustment

error, etc.)

7n28

SPN_n_ : DISCONNECT

Replace the cable

The position detection signal (con-

C-POS DE-

Re-adjust the pre-amplifier.

nector JY5) for Cs contour control is

TECT

abnormal.

(Unconnected cable, adjustment er-

ror, etc.)

7n29

SPN_n_ : SHORTTIME

Check and correct the load status.

Excessive load has been applied

OVERLOAD

continuously for a certain period of

time. (This alarm is issued also when

the motor shaft has been locked in the

excitation state.)

7n30

SPN_n_ : OVERCUR-

Check and correct the power supply

Overcurrent is detected in PSM main

RENT POW

voltage.

circuit input.

(PSM alarm indication:

CIRCUIT

Unbalanced power supply.

PSM selection error (The maximum

PSM output specification is exceed-

ed.)

7n31

SPN_n_ : MOTOR LOCK

Check and correct the load status.

The motor cannot rotate at a specified

OR V-SIG LOS

Replace the motor sensor cable

speed.

(A level not exceeding the

(JY2 or JY5).

SST level for the rotation command

has existed continuously.)

Abnormality in the speed detection

signal.

7n32

SPN_n_ : RAM FAULT

Replace the SPM control printed cir-

Abnormality in an SPM control circuit

SERIAL LSI

cuit board.

component is detected. (The LSI de-

vice for serial transfer is abnormal.)

7n33

SPN_n_ : SHORTAGE

Check and correct the power sup-

Charging of direct current power sup-

POWER

ply voltage.

ply voltage in the power circuit section

CHARGE

Replace the PSM unit.

is insufficient when the magnetic con-

tractor in the amplifier is turned on

(such as open phase and defective

charging resistor).

1208

B-63534EN/02

APPENDIX

G. ALARM LIST

SPM in-

No.

Message

dica-

Faulty location and remedy

Description

tion(*1)

7n34

SPN_n_ : PARAMETER

Correct a parameter value according

Parameter data exceeding the allow-

SETTING ER-

to the manual.

able limit is set.

ROR

If the parameter number is unknown,

connect the spindle check board, and

check the indicated parameter.

7n35

SPN_n_ : EX SETTING

Correct the value according to the pa-

Gear ratio data exceeding the allow-

GEAR RATIO

rameter manual.

able limit is set.

7n36

SPN_n_ : OVERFLOW

Check whether the position gain val-

An error counter overflow occurred.

ERROR

ue is too large, and correct the value.

COUNTER

7n37

SPN_n_ : SPEED DE-

Correct the value according to the pa-

The setting of the parameter for the

TECT PAR. ER-

rameter manual.

number of pulses in the speed detec-

ROR

tor is incorrect.

7n39

SPN_n_ :

1-ROT Cs SIG-

Adjust the 1-rotation signal in the

An incorrect relationship between the

NAL ERROR

pre-amplifier.

1-rotation signal and the number of

Check the cable shield status.

AB phase pulses was detected dur-

Replace the cable.

ing Cs contour control.

7n40

SPN_n_ : NO 1-ROT Cs

Adjust the 1-rotation signal in the

The 1-rotation signal is not gener-

SIGNAL DE-

pre-amplifier.

ated during Cs contour control.

TECT

Check the cable shield status.

Replace the cable.

7n41

SPN_n_ :

1-ROT POS-

Check and correct the parameter.

The

1-rotation signal of the

CODER ER-

Replace the cable.

spindle position coder (connector

ROR

Re-adjust the BZ sensor signal.

JY4) is abnormal.

The 1-rotation signal (connector

JY2) of the MZ or BZ sensor is ab-

normal.

Parameter setting error

7n42

SPN_n_ : NO 1-ROT.

Replace the cable.

The

1-rotation signal of the

POS-CODER

Re-adjust the BZ sensor signal.

spindle position coder (connector

DETECT

JY4) is disconnected.

The 1-rotation signal (connector

JY2) of the MZ or BZ sensor is dis-

connected.

7n43

SPN_n_ : DISCON. PC

Replace the cable.

The differential speed position coder

FOR DIF. SP.

signal (connector JY8) in SPM type 3

MODE

is abnormal.

7n44

SPN_n_ : CONTROL

Replace the SPM control printed cir-

Abnormality in an SPM control circuit

CIRCUIT(AD)

cuit board.

component was detected (A/D con-

ERROR

verter abnormality).

7n46

SPN_n_ : SCREW

Check and correct the parameter.

An abnormality equivalent to alarm

1-ROT POS-

Replace the cable.

41 was detected during thread cutting

COD. ALARM

Re-adjust the BZ sensor signal.

operation.

1209

G. ALARM LIST

APPENDIX

B-63534EN/02

SPM in-

No.

Message

dica-

Faulty location and remedy

Description

tion(*1)

7n47

SPN_n_ : POS-CODER

Replace the cable.

The A/B phase signal of the

SIGNAL AB-

Re-adjust the BZ sensor signal.

spindle position coder (connector

NORMAL

Correct the cable layout (vicinity of

JY4) is abnormal.

the power line).

The A/B phase signal (connector

JY2) of the MZ or BZ sensor is ab-

normal.

The relationship between the A/B

phase and 1-rotation signal is incor-

rect (Pulse interval mismatch).

7n49

SPN_n_ : HIGH CONV.

Check whether the calculated differ-

In differential speed mode, the speed

DIF. SPEED

ential speed value exceeds the maxi-

of the other spindle converted to the

mum motor speed.

speed of the local spindle has ex-

ceeded the allowable limit (the differ-

ential speed is calculated by multiply-

ing the speed of the other spindle by

the gear ratio).

7n50

SPN_n_ : SPNDL CON-

Check whether the calculated value

In spindle synchronization, the speed

TROL OVER-

exceeds the maximum motor speed.

command calculation value exceed-

SPEED

ed the allowable limit

(the motor

speed is calculated by multiplying the

specified spindle speed by the gear

ratio).

7n51

SPN_n_ : LOW VOLT DC

Check and correct the power sup-

Input voltage drop was detected.

LINK

ply voltage.

(PSM alarm indication: 4) (Momen-

Replace the MC.

tary power failure or poor MC contact)

7n52

SPN_n_ : ITP SIGNAL

Replace the SPM control printed

NC interface abnormality was de-

ABNORMAL I

circuit board.

tected (the ITP signal stopped).

Replace the spindle interface

printed circuit board in the CNC.

7n53

SPN_n_ : ITP SIGNAL

Replace the SPM control printed

NC interface abnormality was de-

ABNORMAL II

circuit board.

tected (the ITP signal stopped).

Replace the spindle interface

printed circuit board in the CNC.

7n54

SPN_n_ : OVERLOAD

Review the load state.

An overload current was detected.

CURRENT

7n55

SPN_n_ : POWER LINE

Replace the magnetic contactor.

The power line state signal of the

SWITCH ER-

Check and correct the sequence.

magnetic contactor for selecting a

ROR

spindle or output is abnormal.

7n56

SPN_n_ : INNER COOL-

Replace the SPM unit.

The cooling fan in the SPM control cir-

ING FAN STOP

cuit stopped.

7n57

SPN_n_ : EX DECEL-

Decrease the acceleration/decel-

An overload was detected in the re-

ERATION

eration duty.

generative resistance. (PSMR alarm

POWER

Check the cooling condition (pe-

indication: 8)

ripheral temperature).

Thermostat operation or short-time

If the cooling fan stops, replace the

overload was detected.

resistor.

The regenerative resistor was dis-

If the resistance is abnormal, re-

connected, or an abnormal resis-

place the resistor.

tance was detected.

1210

B-63534EN/02

APPENDIX

G. ALARM LIST

SPM in-

No.

Message

dica-

Faulty location and remedy

Description

tion(*1)

7n58

SPN_n_ : OVERLOAD IN

Check the PSM cooling status.

The temperature of the radiator of the

PSM

Replace the PSM unit.

PSM has increased abnormally.

(PSM alarm indication: 3)

7n59

SPN_n_ : COOLING FAN

Replace the SPM unit.

The cooling fan in the PSM stopped.

STOP IN PSM

(PSM alarm indication: 2)

7n62

SPN_n_ : MOTOR VCMD

Check and correct the parameters.

The specified motor speed is too

OVERLOWED

(No. 4021, 4056 to 4059)

large.

7n66

SPN_n_ : AMP MODULE

Replace the cable.

An error was found in communication

COMMUNICA-

Check and correct the connection.

between amplifiers.

TION

7n73

SPN_n_ : MOTOR SEN-

Replace the feedback cable.

The motor sensor feedback signal is

SOR DISCON-

Check the shield processing.

not present.

NECTED

Check and correct the connection.

Adjust the sensor.

7n74

SPN_n_ : CPU TEST ER-

Replace the SPM control printed-cir-

An error was detected in a CPU test.

ROR

cuit board.

7n75

SPN_n_ : CRC ERROR

Replace the SPM control printed-cir-

An error was detected in a CRC test.

cuit board.

7n79

SPN_n_ : INITIAL TEST

Replace the SPM control printed-cir-

An error was detected in an initial test

ERROR

cuit board.

operation.

7n81

SPN_n_ :

1-ROT MO-

Check and correct the parameter.

The one-rotation signal of the motor

TOR SENSOR

Replace the feedback cable.

sensor cannot be correctly detected.

ERROR

Adjust the sensor.

7n82

SPN_n_ : NO 1-ROT

Replace the feedback cable.

The one-rotation signal of the motor

MOTOR SEN-

Adjust the sensor.

sensor is not generated.

SOR

7n83

SPN_n_ : MOTOR SEN-

Replace the feedback cable.

An irregularity was detected in a mo-

SOR SIGNAL

Adjust the sensor.

tor sensor feedback signal.

ERROR

7n84

SPN_n_ : SPNDL SEN-

Replace the feedback cable.

The spindle sensor feedback signal is

SOR DISCON-

Check the shield processing.

not present.

NECTED

Check and correct the connection.

Check and correct the parameter.

Adjust the sensor.

7n85

SPN_n_ :

1-ROT SPNDL

Check and correct the parameter.

The one-rotation signal of the spindle

SENSOR ER-

Replace the feedback cable.

sensor cannot be correctly detected.

ROR

Adjust the sensor.

7n87

SPN_n_ : SPNDL SEN-

The one-rotation signal of the spindle

An irregularity was detected in a

SOR SIGNAL

sensor is not generated.

spindle sensor feedback signal.

ERROR

7n88

SPN_n_ : COOLING RA-

Replace the SPM external cooling

The external cooling fan stopped.

DIFAN FAIL-

fan.

URE

1211

G. ALARM LIST

APPENDIX

B-63534EN/02

SPM in-

No.

Message

dica-

Faulty location and remedy

Description

tion(*1)

7n97

SPN_n_ : OTHER

Replace the SPM.

Another irregularity was detected.

SPINDLE

ALARM

7n98

SPN_n_ : OTHER CON-

Check the PSM alarm display.

A PSM alarm was detected.

VERTER

ALARM

9n01

SPN_n_ : MOTOR OVER-

Check and correct the peripheral

The thermostat embedded in the mo-

HEAT

temperature and load status.

tor winding operated.

If the cooling fan stops, replace it.

The internal temperature of the motor

exceeds the specified level.

The motor is used in excess of the

continuous rating, or the cooling com-

ponent is abnormal.

9n02

SPN_n_ : EX SPEED ER-

Check and correct the cutting

The motor speed cannot follow a spe-

ROR

conditions to decrease the load.

cified speed.

Correct parameter No. 4082.

An excessive motor load torque is de-

tected.

The acceleration/deceleration time in

parameter No. 4082 is insufficient.

9n03

SPN_n_ : FUSE ON DC

Replace the SPM unit.

The PSM becomes ready (00 is indi-

LINK BLOWN

Check the motor insulation status.

cated), but the DC link voltage is too

Replace the interface cable.

low in the SPM.

The fuse in the DC link section in the

SPM is blown. (The power device is

damaged or the motor is ground-

fault.)

The JX1A/JX1B connection cable is

abnormal.

9n06

SPN_n_ : TERMAL

Check and correct the parameter.

The temperature sensor of the motor

SENSOR DIS-

Replace the feedback cable.

is disconnected.

CONNECT

9n07

SPN_n_ : OVERSPEED

Check for a sequence error. (For ex-

The motor speed has exceeded

ample, check whether spindle syn-

115% of its rated speed.

chronization was specified when the

When the spindle axis was in position

spindle could not be turned.)

control mode, positional deviations

were accumulated excessively (SFR

and SRV were turned off during

spindle synchronization.)

9n09

SPN_n_ : OVERHEAT

Improve the heat sink cooling sta-

Abnormal temperature rise of the

MAIN CIRCUIT

tus.

power transistor radiator

If the heat sink cooling fan stops,

replace the SPM unit.

1212

FANUC Series 16i/160i/160is-MB, Series 18i/180i/180is-MB5, Series 18i/180i/180is-MB. Operator's Manual - page 41
