Seat Exeo ST. Service Manual

-------------------------------------------------------------------------------------------------------------------------------------------------------------

246

Wheels and tyres

Wear indicators

Wheel balance

The original tyres on your vehicle have 1.6 mm high “tread wear indicators”

The wheels on new vehicles are balanced. However, various factors encoun-

⇒ page 245, fig. 189, running across the tread. Depending on the make,

tered in normal driving can cause them to become unbalanced, which results

there will be six to eight of them evenly spaced around the tyre. Markings on

in steering vibration.

the tyre sidewall (for instance the letters “TWI” or other symbols) indicate the

Unbalanced wheels should be rebalanced, as they otherwise cause excessive

positions of the tread wear indicators. The minimum tread depth required by

wear on steering, suspension and tyres. A wheel must also be rebalanced

law is 1.6 mm (measured in the tread grooves next to the tread wear indica-

when a new tyre is fitted.

tors). Worn tyres must be replaced. Different figures may apply in export

countries ⇒

Incorrect wheel alignment

Tyre pressure

Incorrect wheel alignment causes excessive tyre wear, impairing the safety of

the vehicle. If tyres show excessive wear, you should have the wheel align-

Under-inflation or over-inflation will reduce the life of the tyres considerably

ment checked by an Authorised Service Centre.

and also impair the car's handling. The inflation pressures are listed on a

sticker on the inside of the fuel tank flap.

Correct inflation pressures are very important, especially at high speeds. The

WARNING

pressure should therefore be checked at least once a month and before

There is a serious danger of accidents if a tyre bursts during driving!

starting any long journey.

• The tyres must be replaced at the latest when the tread is worn down to

Tyre pressure monitoring (RKA+)*

the tread wear indicators. Failure to do so could result in an accident. Worn

tyres do not grip well at high speeds on wet roads. There is also a greater

Monitoring of the tyre pressures is based on the tyre pressures you have

risk of “aquaplaning”

stored. The tyre pressure monitoring system cannot function as intended if

you store tyre pressure settings for a normal load, but then drive with the

• At continuously high speeds, a tyre with insufficient pressure flexes

vehicle fully laden. The tyre pressure must be adapted to the actual load and

more. This causes it to overheat. This can cause tread separation and tyre

stored accordingly in the tyre pressure monitoring system ⇒ page 244.

blow-out. Risk of accident. Always observe the recommended tyre pres-

sures.

Driving style

• If tyres show excessive wear, you should have the running gear checked

Fast cornering, heavy acceleration and hard braking all increase tyre wear.

by an Authorised Service Centre.

• Keep chemicals such as oil, fuel and brake fluid away from tyres.

Changing wheels around

If the front tyres are worn considerably more than the rear ones it is advisable

• Damaged wheels and tyres must be replaced immediately!

to change them around as shown ⇒ page 245, fig. 190. All the tyres will then

last for about the same time.

For the sake of the environment

Under-inflated tyres will increase fuel consumption.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Wheels and tyres

247

Anti-puncture tyres*

necessary. We recommend you contact Technical Service. If more than one

tyre is being used under emergency conditions, this reduces the distance

Anti-puncture tyres allow you to continue driving even with a

which can be travelled.

punctured tyre, in the majority of cases.

Starting driving in emergency conditions

Vehicles equipped with anti-puncture⁴⁾ tyres from the factory indi-

When loss in tyre pressure is displayed on the instrument panel, this means

that at least one tyre is being driven in emergency conditions ⇒

cate the loss of tyre pressure on the instrument panel.

End of emergency operation

Driving with anti-puncture tyres (emergency gear)

Do not drive on if:

- Leave the ESP/TCS (electronic stabilisation programme)

• smoke is coming from one of the tyres,

switched on, or switch on ⇒ page 68.

•

there is a smell of rubber,

- Continue driving carefully and slowly (80 km/h maximum).

• the vehicle vibrates,

• there is a rattling noise.

- Avoid sudden manoeuvres and sharp turns.

When is it no longer possible to continue driving even using anti-puncture

- Avoid driving over obstacles (for example kerbs) or potholes.

tyres?

- Look out for the ESP/TCS intervening often, smoke coming from

• If the Electronic Stabilisation Program (ESP) is out of operation.

the tyres or the smell of rubber, the vehicle vibrating or a clat-

• If the tyre pressure monitoring system is out of operation.

tering noise. If any of these occur, stop the vehicle.

• If one of the tyres has been severely damaged in an accident, etc. If a tyre

has been badly damaged there is a risk that parts of the tread can be thrown

The anti-puncture tyres have a tag on the side of the tyre, with the description:

off and cause damage to the fuel lines, brake pipes or fuel filler.

“DSST”, “Eufonia”, “RFT”, “ROF”, “RSC”, “SSR” or “ZP”.

• It is also advisable to stop driving if severe vibrations occur, or if the wheel

starts overheating and gives off smoke.

The sides of this type of tyre are reinforced. When the tyres lose air they are

supported on the sides (emergency driving).

The loss of pressure in the tyre is shown on the instrument panel. You can

WARNING

then drive a maximum of 80 km and if the circumstances are favourable (for

When driving in emergency conditions, the driving quality of the vehicle is

example, low load), even more.

considerably impaired.

The damaged tyre should be changed as soon as possible. The rim should be

• The maximum permitted speed of 80 km/h is subject to road and

checked in a specialist workshop to detect possible damage and replace it if

weather conditions. Please observe legal requirements when doing so.

• Avoid sharp turns and rapid manoeuvres, and brake earlier than usual.

⁴⁾ Depending upon version and country.

Safety First

Controls and equipment

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

248

Wheels and tyres

Rim diameter in inches

WARNING (continued)

Load rating code

• Avoid driving over obstacles (for example kerbs) or potholes.

Speed rating

• If one or more tyres is being driven in emergency conditions, the driving

The tyres could also have the following information:

quality of the vehicle is impaired and there is a risk of accident.

• A direction of rotation symbol

•

“Reinforced” denotes heavy-duty tyres.

Note

• The anti-puncture tyres do not “deflate” on losing pressure because they

The manufacturing date is also indicated on the tyre sidewall (possibly only

are supported on the reinforced sides. Therefore defects in the tyre can not be

on the inner side of the wheel).

detected with a visual inspection.

“DOT ... 1103...” means, for example, that the tyre was produced in the 11th

• Snow chains must not be used on front tyres used in emergency

week of 2003.

conditions.

We recommend that work on tyres and wheels is carried out by an Authorised

Service Centre. They are familiar with the procedure and have the necessary

special tools and spare parts as well as the proper facilities for disposing of

New tyres and wheels

the old tyres.

Any Authorised Service Centre has full information on the technical require-

New tyres and wheels have to be run-in.

ments when installing or changing tyres, wheels or wheel trims.

The tyres and wheel rims are an essential part of the vehicle's design. The

tyres and rims approved by SEAT are specially matched to the characteristics

WARNING

of the vehicle and make a major contribution to good road holding and safe

• We recommend that you use only wheels and tyres which have been

handling ⇒

approved by SEAT for your model. Failure to do so could impair vehicle

Tyres should be replaced at least in pairs and not individually (i.e. both front

handling. Risk of accident.

tyres or both rear tyres together). A knowledge of tyre designations makes it

• Avoid running the vehicle on tyres that are more than six years old. If

easier to choose the correct tyres. Radial tyres have the tyre designations

you have no alternative, you should drive slowly and with extra care at all

marked on the sidewall, for example:

times.

195/65 R15 91T

• Never use old tyres or those with an unknown “history of use”.

This contains the following information:

• If wheel trims are retrofitted, you must ensure that the flow of air to the

brakes is not restricted. This could cause them to overheat.

195 Tyre width in mm

• All four wheels must be fitted with radial tyres of the same type, size

Height/width ratio in %

(rolling circumference) and the same tread pattern.

Tyre construction: Radial

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Wheels and tyres

249

For the sake of the environment

WARNING

Old tyres must be disposed of according to the laws in the country concerned.

If the wheel bolts are not tightened correctly, the wheel could become

loose while driving. Risk of accident.

Note

• The wheel bolts must be clean and turn easily. Never apply grease or oil

to them.

• For technical reasons, it is not generally possible to use the wheels from

other vehicles. This can also apply to wheels of the same model. The use of

• Use only wheel bolts which belong to the wheel.

wheels or tyres which have not been approved by SEAT for use with your

• If the torque of the wheel bolts is too low, they could loosen whilst the

model may invalidate the vehicle's type approval for use on public roads.

vehicle is in motion. Risk of accident! If the tightening torque is too high,

• If the spare tyre is not the same as the tyres that are mounted on the

the wheel bolts and threads can be damaged.

vehicle - for example with winter tyres - you should only use the spare tyre for

a short period of time and drive with extra care. Refit the normal road wheel

Caution

as soon as possible.

The prescribed torque for wheel bolts for steel and alloy wheels is 120 Nm.

Wheel bolts

Winter tyres

Wheel bolts must be tightened to the correct torque.

Winter tyres will improve the vehicles handling on snow and

The design of wheel bolts is matched to the rims. If different wheel rims are

ice.

fitted, the correct wheel bolts with the right length and correctly shaped bolt

heads must be used. This ensures that wheels are fitted securely and that the

In winter conditions winter tyres will considerably improve the vehicles

brake system functions correctly.

handling. The design of summer tyres (width, rubber compound, tread

pattern) gives less grip on ice and snow.

In certain circumstances, you may not use wheel bolts from a different car -

even if it is the same model ⇒ page 220.

Winter tyres must be inflated to a pressure 0.2 bar higher than the pressures

specified for summer tyres (see sticker on tank flap).

After the wheels have been changed, the tightening torque of the wheel bolts

should be checked as soon as possible with a torque wrench ⇒ . The tight-

Winter tyres must be fitted on all four wheels.

ening torque for steel and alloy wheels is 120 Nm.

Information on permitted winter tyre sizes can be found in the vehicle's regis-

tration documents. Use only radial winter tyres. All tyre sizes listed in the

vehicle documentation also apply to winter tyres.

Safety First

Controls and equipment

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

250

Wheels and tyres

Winter tyres lose their effectiveness when the tread is worn down to a depth

Snow chains

of 4 mm.

The speed rating code ⇒ page 248, “New tyres and wheels” determines the

Snow chains may be fitted only to the front wheels, and only to certain tyre

following speed limits for winter tyres: ⇒

sizes ⇒ page 294.

Q max. 160 km/h

205/55 R16

15 mm chains

S max. 180 km/h

T max. 190 km/h

225/45 R17

9 mm chains

H max. 210 km/h

225/40 R18

7 mm chains

In some countries, vehicles which can exceed the speed rating of the fitted

Remove wheel hub covers and trim rings before fitting snow chains. For safety

tyre must have an appropriate sticker in the driver's field of view. These

reasons cover caps, available in any Authorised Service Centre, must then be

stickers are available from your Authorised Service Centre. The legal require-

fitted over the wheel bolts.

ments of each country must be followed.

Do not have winter tyres fitted for unnecessarily long periods. Vehicles with

summer tyres handle better when the roads are free of snow and ice.

WARNING

Observe the fitting instructions provided by the snow chain manufacturer.

If you have a flat tyre, please refer to the notes on the spare wheel

⇒ page 248, “New tyres and wheels”.

Caution

WARNING

You must remove the snow chains to drive on roads which are free of snow.

Otherwise they will impair handling, damage the tyres and wear out very

The maximum speed for the winter tyres must not be exceeded. Otherwise,

quickly.

this could lead to tyre damage and thus, an accident risk.

Note

For the sake of the environment

• In some countries, the speed limit for using snow chains is 50 km/h. The

Fit your summer tyres in good time. They are quieter, do not wear so quickly

legal requirements of the country should be followed.

and reduce fuel consumption.

• We recommend that you ask your Approved Service Centre for information

about appropriate wheel, tyre and snow chain size.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If and when

251

If and when

Tools, tyre repair kit and spare wheel

Tools

The tools and jack are stored under the floor panel in the

luggage compartment.

Fig. 192 Toolbox and jack

The tools

and jack

⇒ fig. 192 for vehicles with a spare wheel

and for vehicles with the tyre repair kit are stored under the floor

panel in the luggage compartment.

- Take hold of handle

and fold back the floor panel in the

Fig. 191 Access to the

luggage compartment ⇒ fig. 191.

toolbox and jack

- Unscrew the attachment screw from cover

⇒ fig. 191.

– Remove cover.

- Release the toolbox by pulling up the handle on the box (vehicles

equipped with spare wheel).

- Take out the tools or jack.

The tool kit includes:

Safety First

Controls and equipment

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

252

If and when

• A hook for removing wheel covers* or hub caps

Tyre mobility system

• Box spanner for wheel bolts

The tyre mobility system is stored under the floor panel in the

• A screwdriver with reversible blade

luggage compartment.

• Towing eye

• An adapter for the anti-theft wheel bolts*

Before replacing the jack in the storage bin, wind down the arm of the jack as

far as it will go.

Some of the tools listed are only provided in certain models or are optional

extras.

WARNING

• Do not use the hexagonal socket in the screwdriver handle to tighten

the wheel bolts, as with this it is not possible to tighten the bolts to the

required torque. Risk of accident.

Fig. 193 Tyre Mobility

System under floor panel

• The jack supplied by the factory is only designed for changing wheels

in luggage compartment

on this model. On no account attempt to use it for lifting heavier vehicles

or other loads. Risk of injury.

- Take hold of the handle and fold back the floor panel in the

• Never start the engine when the vehicle is raised. Failure to do so could

result in an accident.

luggage compartment.

• If work is to be carried out underneath the vehicle, this must be secured

- Take out the tyre mobility system.

by suitable stands. Otherwise, there is a risk of injury.

Your vehicle is equipped with a Tyre Mobility System in case of a puncture.

The tyre mobility system consists of a container with sealing compound and

a compressor to generate the required tyre pressure.

Instructions for using the sealant compound and the compressor are

included with the sealant can.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If and when

253

Spare steel rim wheel

Your vehicle can be equipped with a steel spare wheel at the factory. The

spare wheel does not usually meet the same performance standards as the

The spare steel rim wheel is carried in the wheel well under

wheels fitted on the vehicle because of the wheel/tyre dimensions, rubber

the floor panel in the luggage compartment. It is only

composition, tread pattern, etc. Therefore, note the following restrictions:

intended for temporary use over short distances.

• The spare steel rim wheel is designed only for your vehicle model. Do not

attempt to mount the wheel on any vehicle but your own.

• Your vehicle will have different driving characteristics when the spare

steel rim wheel is mounted ⇒

• The spare wheel is only intended for temporary use after having a flat tyre.

Replace the spare wheel with a normal wheel that has the proper tyre dimen-

sions as soon as possible.

• If the size of the spare steel rim wheel is different to that of the other

wheels, it is unlikely that snow chains suitable for the other wheels will fit it.

WARNING

• After mounting the spare steel rim wheel, the tyre pressure must be

Fig. 194 Spare steel rim

checked and corrected as soon as possible. The inflating pressure must

wheel

adapt to the vehicle load (consult the table containing the inflation pres-

sures). Otherwise there is danger of causing an accident. Use the highest

Taking out the spare wheel

tyre pressure as indicated in the table.

- Turn the plastic knob ⇒ fig. 194 anti-clockwise.

• Do not drive faster than 80 km/h, as higher speeds can cause an acci-

dent.

- Take out the spare wheel.

• Avoid heavy acceleration, hard braking and fast cornering, as this could

cause an accident.

Securing the defective wheel in the spare wheel well

- Place wheel in spare wheel well in the luggage compartment.

- Secure wheel by turning plastic knob clockwise.

– Replace the floor panel before closing the boot lid.

Safety First

Controls and equipment

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

254

If and when

Changing a wheel

Note

Please observe legal requirements when doing so.

Preparation work

What you must do before changing a wheel.

Changing a wheel

- If you have a flat tyre or puncture, park the car as far away from

the flow of traffic as possible. Choose a location that is as level

Change the wheel as described below.

as possible.

- Remove the wheel cover.

- All passengers should leave the vehicle. They should wait in a

- Loosen the wheel bolts ⇒ page 255.

safe place (e.g. behind the roadside crash barrier).

- Raise the car with the jack ⇒ page 256.

- Apply the handbrake firmly.

- Take off the wheel with the flat tyre and then put on the spare

- Engage 1st gear.

wheel ⇒ page 257.

- When towing a trailer: Unhitch the trailer from your vehicle.

- Lower the vehicle.

- Take the tools and the spare wheel ⇒ page 251 out of the

- Tighten the wheel bolts firmly in diagonal sequence with the box

luggage compartment.

spanner ⇒ page 255.

- Replace the cover.

WARNING

If you have a puncture in heavy traffic, switch on the hazard warning lights

and place the warning triangle in a visible location. This is for your own

safety and also warns other road users.

After changing a wheel

After changing the wheel, there are still tasks to complete.

Caution

- Place the wheel with the defective tyre in the spare wheel well

If you have to change the tyre on a gradient, block the wheel opposite the

wheel being changed by placing a stone or similar object under it to prevent

and secure it.

the vehicle from rolling away.

- Put the tools and jack back in the luggage compartment.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If and when

255

– The inflation pressure of the newly fitted spare tyre must be

Loosening and tightening the wheel bolts

checked as soon as possible.

The wheel bolts must be loosened before raising the vehicle.

- Have the tightening torque of the wheel bolts checked as soon

as possible with a torque wrench. It must be 120 Nm (always

when cold)

- Have the flat tyre replaced as quickly as possible.

Note

• If you notice that the wheel bolts are rusty and difficult to turn when

changing a wheel, they must be replaced before having the tightening torque

checked.

• For your safety, drive at moderate speeds until the wheel bolt torque has

Fig. 195 Changing the

been checked.

wheel: Loosen the wheel

bolts

Loosening

- Fit the box spanner as far as it will go over the wheel bolt ⁵⁾.

- Grip the box spanner as close to the end as possible and turn the

wheel bolts about one turn anti-clockwise ⇒ fig. 195 -arrow-.

Tightening

- Fit the box spanner as far as it will go over the wheel bolt⁵⁾.

- Grip the box spanner as close to the end as possible and tighten

the bolt firmly by turning clockwise.

⁵⁾ An adapter is required to unscrew or tighten the anti-theft wheel bolts* ⇒ page 258.

Safety First

Controls and equipment

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

256

If and when

WARNING

Loosen the wheel bolts only about one turn before raising the vehicle with

the jack. Failure to do so could result in an accident.

Note

• Do not use the hexagonal socket in the screwdriver handle to loosen or

tighten the wheel bolts.

• If the wheel bolt does not come loose, it may be possible to release it by

pushing down the end of the spanner carefully with your foot. Hold on to the

vehicle for support and take care not to slip.

Fig. 197 Changing the

wheel: Jack

- Position the vehicle jack under the door sill at the jacking point

Raising the vehicle

closest to the wheel being changed ⇒ fig. 196 -arrows-.

In order to remove the wheel, the vehicle must be raised with

- Wind up the jack under the jacking point until the claw of the jack

a jack.

is directly below the vertical rib under the door sill.

- Align the jack so that the arm of the jack fits on the rib under the

door sill ⇒ fig. 197

and the movable base plate of the jack

is flat on the ground.

- Raise the vehicle until the defective wheel is just clear of the

ground.

Recesses at the front and rear of the door sills mark the jacking points

⇒ fig. 196 -arrows-. There is only one jacking point for each wheel. Do not fit

the jack anywhere else.

The distance from the jacking points to the wheel arches is approximately 15

Fig. 196 Changing the

cm at the front and 25 cm at the rear.

wheel: The jacking points

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If and when

257

An unstable surface under the jack may cause the vehicle to slip off the jack.

After loosening the wheel bolts and raising the vehicle with the jack,

Therefore, the jack must be fitted on solid ground offering good support. Use

change the wheel as described below:

a large, stable base if necessary. On a hard, slippery surface (such as tiles)

use a rubber mat or similar to prevent the jack from slipping.

Removing a wheel

- Unscrew the bolts using the hexagonal tool in the handle of the

WARNING

screwdriver (vehicle tool) and place them on a clean surface

⇒ fig. 198.

• Take all precautions so that the base of the jack does not slip. Failure to

do so could result in an accident.

Fitting a wheel

• The vehicle can be damaged if the jack is not applied at the correct

jacking points. There is also a risk of injury since the jack can slip off

- Screw in the wheel bolts and tighten them lightly using the

suddenly if it is not properly engaged.

hexagonal socket in the screwdriver handle.

The wheel bolts should be clean and easily screwed. Before fitting the spare

wheel, inspect the wheel condition and hub mounting surfaces. These

Removing and fitting the wheel

surfaces must be clean before fitting the wheel.

For removal and fitting the wheel, the following tasks must be

The hexagonal socket in the screwdriver handle makes it easier to turn the

completed.

wheel bolts. The reversible screwdriver blade should be removed when the

tool is used for this purpose.

If tyres with a specific direction of rotation are fitted, note the direction of

rotation.

Note

Do not use the hexagonal socket in the screwdriver handle to loosen or

tighten the wheel bolts.

Fig. 198 Changing the

wheel: Hexagonal socket

in screwdriver handle to

turn the wheel bolts

Safety First

Controls and equipment

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

258

If and when

Anti-theft wheel bolts

Tyres with directional tread pattern

A special adapter is required to turn the anti-theft wheel

Tyres with directional tread pattern must be fitted so that they

bolts.

rotate in the correct direction.

A directional tread pattern can be identified by arrows on the sidewall that

point in the direction of rotation. Always note the direction of rotation indi-

cated when fitting the wheel. This is important so that these tyres can give

maximum grip and avoid excessive noise, tread wear and aquaplaning.

If, in an emergency, you have to fit the spare wheel so it rotates in the wrong

direction, you must drive extremely carefully. The tyre will not give optimum

performance. This is particularly important when driving on wet roads.

To benefit from the advantages of tyres with this type of tread pattern, the

defective tyre should be replaced as soon as possible so that all tyres again

rotate in the correct direction.

Fig. 199 Anti-theft wheel

bolt

- Insert the adapter onto the wheel bolt and push it on as far as it

will go ⇒ fig. 199.

- Fit the box spanner as far as it will go over the adapter.

- Loosen or tighten the wheel bolt as appropriate.

Error code

The code number of the anti-theft wheel bolt is stamped onto the front part of

the adaptor.

The code number should be noted and kept in a safe place, as it is only by

using the code number that a duplicate adaptor can be obtained from an

Authorised Service Centre.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If and when

259

The sealing compound must not be used in the following cases:

Tyre repair* (Tyre-Mobility-System)

• On cuts and punctures larger than 4 mm ⇒ fig. 200

• if the wheel rim has been damaged

General information and safety notes

•

if you have been driving with very low pressure or a completely flat tyre

Repaired tyres are only suitable for temporary use over a

How to use the TMS (tyre mobility system) is described in the section

short period.

Repairing a tyre ⇒ page 260 and in the instructions supplied with the tyre

sealant can.

The TMS (tyre mobility system) can be used at outside temperatures down to

-20°C.

WARNING

After repairing a tyre please note the following points:

• Do not drive faster than 80 km/h.

• Avoid heavy acceleration, hard braking and fast cornering.

• Vehicle handling could be impaired.

Fig. 200 The Tyre

Mobility System is not

• Tyres which have been sealed using the Tyre Mobility System are only

suitable for repairing this

suitable for temporary use over a short period.

type of damage to tyres.

• After using the tyre sealant the tyre pressure monitoring system* may

malfunction. Therefore, please drive carefully to the next available quali-

Your vehicle is equipped with a tyre repair kit: the Tyre Mobility System.

fied workshop.

• The Tyre Mobility System must NOT be used,

In the event of a puncture you will find the TMS, which consists of a sealing

compound and a compressor, located under the floor panel in the luggage

− on cuts and punctures larger than 4 mm

compartment.

− if the wheel rim has been damaged

The Tyre Mobility System will reliably seal tyres damaged by foreign bodies,

− if you have been driving with very low pressure or a completely flat

provided that the cuts or punctures are no larger than approx. 4 mm in diam-

tyre

eter.

• Seek professional assistance if the repair of a tyre puncture is not

possible with the sealing compound.

It is not necessary to remove the foreign body from the tyre.

• Do not allow the sealant to come into contact with your eyes, skin or

clothing.

Safety First

Controls and equipment

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

260

If and when

Repairing a tyre

WARNING (continued)

• If you do come into contact with the sealant immediately rinse the eyes

or skin affected with clean water.

• Change clothing immediately if it becomes soiled with the tyre sealant.

• Make sure you do not breathe in the fumes!

• If any of the tyre sealant is accidentally ingested, immediately rinse the

mouth thoroughly and drink lots of water.

− Do not induce vomiting. Seek medical assistance if needed.

• If any allergic reactions should occur get medical help immediately.

• Keep the sealant away from children.

For the sake of the environment

Fig. 201 Repairing a tyre

Used bottles of sealing compound can be returned to the Technical Service

for disposal.

Preparations

- If you have a flat tyre or puncture, park the car as far away from

Note

the flow of traffic as possible.

• If sealant should leak out, leave it to dry. When it has dried, you can pull

it off like a piece of foil.

- Apply the handbrake firmly to prevent the vehicle from moving

• Observe the expiry date stated on the sealing compound can. Have the

accidentally on slopes.

sealing compound exchanged by a qualified workshop.

- Engage 1st gear.

- Check whether a repair is possible using the Tyre Mobility System

⇒ page 259.

- Ensure that all passengers leave the vehicle and move away from

the danger area ⇒

– Take the tyre sealant can and the compressor out of the luggage

compartment.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If and when

261

– Stick the “max. 80 km/h” adhesive, which is included with the

- If the tyre pressure remains lower than the value specified above

tyre sealant can, onto the instrument panel where the driver will

drive the vehicle approx. 10 metres forwards or backwards, so

see it.

that the sealant can spread evenly in the tyre. If the pressure is

still lower than the specification the tyre is too badly damaged

Filling the tyre

and cannot be repaired using the tyre sealant.

Shake the tyre sealant can well.

Final check

Screw the enclosed filling hose onto the sealant can as far as it

- After about 10 minutes, stop to check the tyre pressure.

will go. This will automatically pierce the foil sealing the can.

- If tyre pressure is less than 1.3 bar, the tyre is too badly

Take the valve cap off the tyre valve and use the enclosed valve

damaged. Do not drive on! You should obtain professional

insert tool to unscrew the valve insert ⇒ page 260, fig. 201.

assistance.

Place the valve insert onto a clean surface.

–

Remove the sealing plug from the filling hose and insert the hose

WARNING

into the tyre valve.

• If you have a puncture in heavy traffic, switch on the hazard warning

lights and place the warning triangle in a visible location. This is for your

Hold the tyre sealant can upside down and fill the complete

own safety and also warns other road users.

contents of the can into the tyre.

•

Make sure your passengers wait in a safe place (for instance behind the

Then disconnect the hose and screw the valve insert firmly back

roadside crash barrier).

into the tyre valve.

• Please observe the manufacturers' safety notes on the compressor and

the instructions supplied with the tyre sealant can.

Inflating the tyre

• If it was not possible to build up a tyre pressure of 2.0 bar within 6

- Screw the compressor filling hose onto the tyre valve and plug

minutes this means that the tyre is too badly damaged. Do not drive on!

the connector into the cigarette lighter.

• Seek professional assistance if the repair of a tyre puncture is not

possible with the sealing compound.

- Pump the tyre up to 2.0 to 2.5 bar and monitor the pressure

• If tyre pressure is less than 1.3 bar after driving about 10 minutes, the

shown on the pressure gauge.

tyre is too badly damaged. Do not drive on! Obtain technical assistance.

Caution

Take special care if you have to repair a tyre on a slope.

Safety First

Controls and equipment

Practical tips

Technical Data

Seat Exeo ST. Service Manual - part 16
