294
Technical data
Diesel engine 2.0l 103 kW (140 bhp)
General engine data
Power output in kW (bhp)
rpm
103 (140)/ 4000
Maximum torque
in Nm at rpm
320/ 1750 - 2500
No. of cylinders, capacity
in cm 3
4/ 1968
Compression ratio
18,5 ± 0,5
Fuel
Min. 51 CZ
Performance figures
Maximum speed
in km/h
201
Acceleration from 0-80 km/h
in sec.
7,0
Acceleration from 0-100 km/h
in sec.
10,0
Weights
Gross vehicle weight
in kg
2089
Weight in working order (with driver)
in kg
1544
Gross axle weight, front
in kg
1082
Gross axle weight, rear
in kg
1024
Permitted roof load
in kg
75
Trailer weights
With no brakes, gradients up to 12%
750
With brakes, gradients up to 12%
1400

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data
295
Engine oil capacity
Approximate engine oil capacity with oil filter change
4.3 litres
Diesel engine 2.0l 103 kW (140 bhp). Freetrack
General engine data
Power output in kW (bhp)
rpm
103 (140)/ 4000
Maximum torque
in Nm at rpm
320/ 1750 - 2500
No. of cylinders, capacity
in cm 3
4/ 1968
Compression ratio
18,5 ± 0,5
Fuel
Min. 51 CZ
Performance figures26)
26) Front-wheel drive
Maximum speed
in km/h
196
Acceleration from 0-80 km/h
in sec.
7,1
Acceleration from 0-100 km/h
in sec.
10,2
Safety First
Operating instructions
Tips and Maintenance
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

296
Technical data
Weights27)
27) Front-wheel drive
Gross vehicle weight
in kg
2124
Weight in working order (with driver)
in kg
1579
Gross axle weight, front
in kg
1096
Gross axle weight, rear
in kg
1041
Permitted roof load
in kg
75
Trailer weights
With no brakes, gradients up to 12%
750
With brakes, gradients up to 12%
1400
Engine oil capacity
Approximate engine oil capacity with oil filter change
4.3 litres
Diesel engine 2.0l 103 kW (140 bhp). Automatic
General engine data
Power output in kW (bhp)
rpm
103 (140)/ 4000
Maximum torque
in Nm at rpm
320/ 1750 - 2500
No. of cylinders, capacity
in cm 3
4/ 1968
Compression ratio
18,5 ± 0,5
Fuel
Min. 51 CZ

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data
297
Performance figures
Maximum speed
in km/h
201
Acceleration from 0-80 km/h
in sec.
6,7
Acceleration from 0-100 km/h
in sec.
10,0
Weights
Gross vehicle weight
in kg
2124
Weight in working order (with driver)
in kg
1579
Gross axle weight, front
in kg
1112
Gross axle weight, rear
in kg
1029
Permitted roof load
in kg
75
Trailer weights
With no brakes, gradients up to 12%
750
With brakes, gradients up to 12%
1400
Engine oil capacity
Approximate engine oil capacity with oil filter change
4.3 litres
Safety First
Operating instructions
Tips and Maintenance
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

298
Technical data
Diesel engine 2.0l 100 kW (136 bhp)
General engine data
Power output in kW (bhp)
rpm
100 (136)/ 4000
Maximum torque
in Nm at rpm
320/ 1750 - 2500
No. of cylinders, capacity
in cm 3
4/ 1968
Compression ratio
18,5 ± 0,5
Fuel
Min. 51 CZ
Performance figures
Maximum speed
in km/h
199
Acceleration from 0-80 km/h
in sec.
710
Acceleration from 0-100 km/h
in sec.
10,1
Weights
Gross vehicle weight
in kg
2089
Weight in working order (with driver)
in kg
1544
Gross axle weight, front
in kg
1082
Gross axle weight, rear
in kg
1024
Permitted roof load
in kg
75
Trailer weights
With no brakes, gradients up to 12%
750
With brakes, gradients up to 12%
1400

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data
299
Engine oil capacity
Approximate engine oil capacity with oil filter change
4.3 litres
Diesel engine 2.0l 100 kW (136 bhp). Automatic
General engine data
Power output in kW (bhp)
rpm
100 (136)/ 4000
Maximum torque
in Nm at rpm
320/ 1750 - 2500
No. of cylinders, capacity
in cm 3
4/ 1968
Compression ratio
18,5 ± 0,5
Fuel
Min. 51 CZ
Performance figures
Maximum speed
in km/h
199
Acceleration from 0-80 km/h
in sec.
7,1
Acceleration from 0-100 km/h
in sec.
10,1
Weights
Gross vehicle weight
in kg
2124
Weight in working order (with driver)
in kg
1579
Gross axle weight, front
in kg
1112
Gross axle weight, rear
in kg
1029
Permitted roof load
in kg
75
Safety First
Operating instructions
Tips and Maintenance
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

300
Technical data
Trailer weights
With no brakes, gradients up to 12%
750
With brakes, gradients up to 12%
1400
Engine oil capacity
Engine oil capacity with oil filter change.
4.3 litres
Diesel engine 2.0l 125 kW (170 bhp)
General engine data
Power output in kW (bhp)
rpm
125 (1170)/ 4200
Maximum torque
in Nm at rpm
350/ 1750 - 2500
No. of cylinders, capacity
in cm 3
4/ 1968
Compression ratio
18,5 ± 0,5
Fuel
Min. 51 CZ
Performance figures
Maximum speed
in km/h
211
Acceleration from 0-80 km/h
in sec.
6,2
Acceleration from 0-100 km/h
in sec.
8,7

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data
301
Weights
Gross vehicle weight
in kg
2089
Weight in working order (with driver)
in kg
1544
Gross axle weight, front
in kg
1082
Gross axle weight, rear
in kg
1024
Permitted roof load
in kg
75
Trailer weights
With no brakes, gradients up to 12%
750
With brakes, gradients up to 12%
1400
Engine oil capacity
Engine oil capacity with oil filter change.
4.3 litres
Diesel engine 2.0l 125 kW (170 bhp). Freetrack
General engine data
Power output in kW (bhp)
rpm
125 (1170)/ 4200
Maximum torque
in Nm at rpm
350/ 1750 - 2500
No. of cylinders, capacity
in cm 3
4/ 1968
Compression ratio
18,5 ± 0,5
Fuel
Min. 51 CZ
Safety First
Operating instructions
Tips and Maintenance
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

302
Technical data
Performance figures28)
28) Four-wheel drive
Maximum speed
in km/h
204
Acceleration from 0-80 km/h
in sec.
5,9
Acceleration from 0-100 km/h
in sec.
8,7
Weights29)
29) Four-wheel drive
Gross vehicle weight
in kg
2168
Weight in working order (with driver)
in kg
1643
Gross axle weight, front
in kg
1115
Gross axle weight, rear
in kg
1086
Permitted roof load
in kg
75
Trailer weights
With no brakes, gradients up to 12%
750
With brakes, gradients up to 12%
1400
Engine oil capacity
Engine oil capacity with oil filter change.
4.3 litres

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Technical data
303
Dimensions and capacities
Dimensions
Length, width
4,467 mm/ 1,768 mm
Height at kerb weight
1,575 mm
Front and rear projection
913 mm/ 976 mm
Wheelbase
2,578 mm
Turning circle
10.7 m
Front
Rear
Track widtha)
1,527 mm
1,506 mm
1,535 mm
1,514 mm
Capacities
Fuel tank
55 litres, reserve 7 litres
Windscreen washer fluid container with headlight washer
3 l/ 5.5 l
Tyre pressure
Summer-grade tyres:
The correct tyre pressure can be seen on the sticker on the inside of the tank flap.
Winter tyres:
The pressure of these tyres is the same as the summer tyre pressure plus 0.2 bar.
a) This data will change depending on the type of wheel rim.
Safety First
Operating instructions
Tips and Maintenance
Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

304
Technical data
Dimensions and capacities. Freetrack
Dimensions
Length, width
4,493 mm/ 1,778 mm
Height at kerb weight
1,615 mm
Front and rear projection
940 mm/ 977 mm
Wheelbase
2,576 mm
Turning circle
10,7
Front
Rear
Track width
1,542 mm
1,527 mm
Capacities
Fuel tank
60 l. Reserve 8l.
Windscreen washer fluid container with headlight washer
3 l/ 5.5 l
Tyre pressure
Summer-grade tyres:
The correct tyre pressure can be seen on the sticker on the inside of the tank flap.
Winter tyres:
The pressure of these tyres is the same as the summer tyre pressure plus 0.2 bar.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Index
305
Index
Airbags
Automatic wiper/wash function for the rear window
A
Care
32
124
ABS
182
Disposal
32
Auxiliary audio connection: AUX-IN
145
Warning lamp
78
Safety notes
32
Accessories
210
Alarm system
B
Acoustic signal
20
Switching off
102
Ball coupling
198
Acoustic warning
163
Alterations to the vehicle
210
BAS
181
Adjusting headlights
Alternator
Battery
driving on the left
191
Warning lamp
79
Changing
231
driving on the right
191
Ambient temperature display
63
Charging
231
Adjusting the seat belt height
27
Anti-freeze
223
Winter conditions
230
Adjustments for Bixenon headlights
Anti-lock brake system
182
Belt tension device
driving on the left
193
Warning lamp
78
Disposal
28
driving on the right
193
Anti-theft alarm system
102
Warning lamp
31
Air conditioner*
Switching off
102
Belt tension devices
28
2C-Climatronic*
156
Anti-theft wheel bolts
245
Biodiesel
214
Air conditioning system
Apple iPod connector
146
Bonnet
217
General notes
160
Aquaplaning
236
Brake assist system
181
Air conditioning*
153
Ashtray*
143
Brake fluid
228
Air recirculation mode
Automatic anti-dazzle interior mirror*
Changing
229
2C-Climatronic
159
Activating the anti-dazzle function
125
Warning lamp
64
Manual air conditioning
155
Deactivating anti-dazzle function
125
Brake pad wear indicator*
Airbag covers
36
Automatic car wash tunnel
202
Indicator
82
Airbag system
30
Automatic gearbox / DSG automatic gearbox . 168
Brake pads
187, 189
Curtain airbags
41
Automatic lighting
112
Front airbags
34
Brake pedal
Automatic mode
Warning lamp
82
Side airbags
37
2C-Climatronic
157
Warning lamp
31
Brake servo
181, 187

-------------------------------------------------------------------------------------------------------------------------------------------------------------

306
Index
Brake system
228
Centre arm rest
135
Safety notes
47
Brake servo
185
Cetane number
214
Securing
51
Brakes
185
Changing gear
Child seats
Warning lamp
77
See Manual gearbox
167
ISOFIX and Toptether systems
52
Brakes
187
Changing the lamps
on the front passenger seat
31
Braking distance
187
Main headlight lamps
260
Cigarette lighter*
143
Bulb changes
rear lights
263
Cleaning alloy wheels
206
general notes
259
Changing the main headlight lamps
Cleaning and caring for your vehicle
201
Bulb defect
dipped beam lights
261
Cleaning chrome
205
warning lamp
77
main beam lights
262
Cleaning cloth seat covers
208
Buzzer
117, 163
Side lights
263
Cleaning dash panel
208
turn signal lamps
261
Cleaning engine compartment
207
C
Changing the rear light lamps
Cleaning fabric trim
208
Position light, fog light and rear light on the
Cleaning leather
208
Car care
tailgate
265
Cleaning plastic parts
208
Exterior
202
Changing the rear lights
Cleaning seat belts
209
Car care products
201
Indicator, side and brake lights on the
bodywork
264
Cleaning steel wheels
206
Catalytic converter
189
luggage compartment lights
266
Cleaning windows
204
CD changer
135
Changing windscreen wiper blades
226
Cleaning wooden trim
208
Central locking
93
Automatic speed dependent locking and un-
Chassis number
276
Climatic*
153
locking system*
95
Checking
231
Climatronic
Emergency unlocking system
95
Checking battery electrolyte level
231
General notes
160
Locking system for involuntary unlocking . . 95
Checking engine oil level
220
Clock
58
Selective unlocking system*
94
Clothes hook
138
Child safety
46
Central locking button
Child seat
48
Cockpit
55
Central locking
97
Categorisation in groups
48
Control
unlocking
97
Group 1
49
Light switches
111
Central locking system
Group 2
49
Control lamps
72
Automatic speed dependent locking and un-
Group 3
49
Control lighting
55
locking system*
95
Groups 0 and 0+
48

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Index
307
Controls
Diesel engine
Driving economically
194
Electric windows
106
Winter driving
215
Driving programmes
169
Convenience closing
Diesel engine particulate filter*
190
Driving safety
8
Sliding/tilting roof
109
Differential lock
184
Driving with an automatic gearbox / DSG automatic
Windows
108
Differential lock fault (EDL)
gearbox*
170
Convenience opening
warning lamp
79
Driving with respect for the environment
194
Windows
108
Digital clock
58
Duplicate keys
99
Coolant
223
Dipped headlights
111
Dust filter
160
Warning lamp
64
Disabling front passenger airbag
Dynamic headlight range control
113
Coolant Level
223
Safety notes
45
Coolant level
Disabling the airbag
E
warning light
75
Disabling front passenger airbag
44
Coolant Loss
223
EDL
184
Display (without warning or information texts) . 59
Coolant temperature
EDS
Displays in the Multi-function display
Display
57
Warning lamp
78
Memory displays
62
Safety instructions
76
Electric steering system
Door lock cylinders
205
Cruise control system
176
warning light
82
Door release lever
55
Warning lamp
77
Electrical sockets
144
Doors
Cruise control*
Electronic differential lock
184
Childproof locks
98
Turning off the cruise control system
178
Warning lamp
78
Warning lamp
82
Curtain airbags
41
Electronic immobiliser
83, 164
Drawer
135
Description
41
warning message
64
Drinks holders at the front
139
Function
42
Electronic stabilisation program
183
Drive wheels traction control system
182
Safety notes
42
Electronic stabilisation programme
81
Driving
Description
162
Driving abroad
190
D
Warning lamp
163
Economically / With Respect for the
Electronic stabilisation programme (ESP)
Environment
194
Danger of fitting a child seat on the front passenger
With a trailer
198
warning lamp
81
seat
31
emergency manual locking
96
Driving abroad
190
Diesel
214
Headlights
191
Emergency opening
Doors
102

-------------------------------------------------------------------------------------------------------------------------------------------------------------

308
Index
Emission control system
Examples of menu use
Fuel
warning lamp
81
Open the main menu
67
Diesel
214
Engine
Open the winter tyres menu
67
Petrol
213
Running in
189
To close the winter tyres menu
68
Fuel level
Engine compartment
Exterior mirrors
204
Indicator
57
Working in the engine compartment
215
Fuel reserve
75
Engine coolant
223
F
Warning
64
Engine fault
Fuel Tank
Fastening rings
18
Warning lamp
81
Opening the fuel tank flap
212
Fire extinguisher
147
Engine management
Fuel tank
Floor mats
16
Warning lamp
81
See Fuel reserve
75
Engine oil
218
Fog lights
111
Fuel: save
194
folding table*
136
Changing
222
Fuses
252
Checking level
220
Folding the seat backrests down
133
Oil properties
219
Four-wheel drive
185
G
Specifications
218
Freetrack towing eye
274
Topping up
221
Front airbags
34
G 12
223
Engine oil dipstick
220
Description
34
Gear shift pattern
167
Engine oil pressure
Function
35
General overview of the engine compartment
279
Warning lamp
64, 78
Safety notes
37
Glove compartment
134
Environment
194
Front interior light type 1
Glow plug system
166
Environmental friendliness
195
Switching light off
117
Warning lamp
81
Switching light on
117
Environmental tip
Avoiding pollution
213
Front interior light type 2
H
Switching light off
118
ESP
81, 183
Handbrake
173
Switching light on
118
Example of menu use
Warning lamp
77, 173
Front passenger airbag deactivation
44
Open the configuration menu
67
Hazard warning lights
115
Program a speed limit warning
67
Front reading lights
119
To activate and deactivate the speed limit
Front seat adjustment
warning
68
Lumbar support
131

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Index
309
head restraints
Instrument panel menu
Luggage compartment
17, 147
Adjusting
129, 130
Configuration menu
69
See also Luggage compartment
17
adjustment of the head restraint angle . . . 130
Example of menu use
67
Luggage compartment cover
148
Removing
130
Lights and visibility menu
71
Luggage compartment retaining net
138
head restraints, correct adjustment
13
Instrument panel menus
In-use and non-use positions
14
Principal menu
65
M
Headlight flasher
116
Vehicle status menu
69
Headlight range control
113
Instruments
56
Main beam
116
Headlights
111
Interior lights
117
Main beam headlights
Driving abroad
191
Intermittent wipe, windscreen
121
Indicator lamp
76
Fog lights
111
ISOFIX and Toptether systems
52
Main headlight lamps
260
Washer system
125
Manual gearbox
167
Heated front seats
132
Manual mode
J
Heated window
2C-Climatronic
158
2C-Climatronic
157
Jacking points
MFD
61
Sill panel with cover
248
Heating and ventilation
151
Mileage display
60
Jump leads
268
High pressure cleaners
203
Mirrors
Horn
55
Jump-starting
268
Exterior mirrors, electrical
126
Interior mirror
125
K
Make-up mirrors
120
I
Mobile telephone
211
Key tab
99
Identification number
276
Modifications
210
Keys
99
Ignition key
163
Multi-function display
61
Ignition lock
163
Multi-purpose* mobile stowage compartment 141
L
Indicator lights
Closing
141
indication lamp
76
Fitting
140
Lights
111
Information texts in the display
63
Opening
141
Load compartment
Instrument and switch lighting
113
Removal
140
See Luggage compartment
17
Instrument lighting
55
Uses
141
Locks
205
Instrument panel
55















Content      ..     17      18      19
