Scion xB. Service Manual - part 13

195

3-5. Other interior features

3

Interior features

Scion_xB_OM_OM12F03U_(U)

Outside temperature display

■

The outside temperature is displayed when

The engine switch is in the “ON” position.

■

Display

In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change:

●

When the vehicle is stopped, or moving at low speeds (less than 16 mph
[25 km/h])

●

When the outside temperature has changed suddenly (at the entrance/
exit of a garage, tunnel, etc.)

■

When “- -” is displayed

The system may be malfunctioning. Take your vehicle to your Scion dealer.

The temperature display shows temperatures within the ranges of

-40 °F (-40 °C) and 122 °F (50 °C).

196

3-5. Other interior features

Scion_xB_OM_OM12F03U_(U)

Power outlet

■

The power outlet can be used when

The engine switch is in the “ACC” or “ON” position.

NOTICE

■

To avoid damaging the power outlet

Close the power outlet lid when the power outlet is not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir-
cuit.

■

To prevent blown fuse

Do not use an accessory that uses more than 12 V 10 A.

■

To prevent battery discharge

Do not use the power outlet longer than necessary when the engine is not
running.

The power outlet can be used for 12 V accessories that run on less

than 10 A.

197

3-5. Other interior features

3

Interior features

Scion_xB_OM_OM12F03U_(U)

Coat hooks

CAUTION

■

Items that cannot be hung on the coat hook

Do not hang coat hangers or other hard or sharp objects on the hook. If the
SRS curtain shield airbags deploy, these items may become projectiles,
causing death or serious injury.

The coat hooks are provided
with the rear assist grips.

198

3-5. Other interior features

Scion_xB_OM_OM12F03U_(U)

Assist grips

CAUTION

■

Assist grip

Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.

NOTICE

■

To prevent damage to the assist grip

Do not hang any heavy object or put a heavy load on the assist grip.

An assist grip installed on the ceiling can be used to support your

body while sitting on the seat.

199

3-5. Other interior features

3

Interior features

Scion_xB_OM_OM12F03U_(U)

Floor mat

Use only floor mats designed specifically for vehicles of the same

model and model year as your vehicle. Fix them securely in place

onto the carpet.

Insert the retaining hooks
(clips) into the floor mat eye-
lets.

Turn the upper knob of each
retaining hook (clip) to secure
the floor mats in place.

*

: Always align the

 marks.

The shape of the retaining hooks (clips) may differ from that shown
in the illustration.

STEP

1

STEP

2

*

200

3-5. Other interior features

Scion_xB_OM_OM12F03U_(U)

CAUTION

Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering
with the pedals while driving. An unexpectedly high speed may result or it may
become difficult to stop the vehicle. This could lead to an accident, resulting in
death or serious injury.

■

When installing the driver’s floor mat

●

Do not use floor mats designed for other models or different model year
vehicles, even if they are Scion Genuine floor mats.

●

Only use floor mats designed for the driver’s seat.

●

Always install the floor mat securely using the retaining hooks (clips) pro-
vided.

●

Do not use two or more floor mats on top of each other.

●

Do not place the floor mat bottom-side up or upside-down.

■

Before driving

●

Check that the floor mat is securely
fixed in the correct place with all the
provided retaining hooks (clips). Be
especially careful to perform this check
after cleaning the floor.

●

With the engine stopped and the shift
lever in P (automatic transmission) or N
(manual transmission), fully depress
each pedal to the floor to make sure it
does not interfere with the floor mat.

201

3-5. Other interior features

3

Interior features

Scion_xB_OM_OM12F03U_(U)

Luggage compartment features

■

Auxiliary boxes

Type A

Type B

Lift the luggage mat up to use
the boxes.

■

Cargo hooks

Raise the hook to use.

The cargo hooks are provided
for securing loose items.

202

3-5. Other interior features

Scion_xB_OM_OM12F03U_(U)

CAUTION

■

When the cargo hooks are not in use

To avoid injury, always return the cargo hooks to their stowed positions.

Maintenance and care

4

203

Scion_xB_OM_OM12F03U_(U)

4-1. Maintenance and care

Cleaning and protecting

the vehicle exterior.........  204

Cleaning and protecting

the vehicle interior..........  207

4-2. Maintenance

Maintenance

requirements..................  210

General maintenance.......  212

Emission inspection

and maintenance (I/M)
programs........................  216

4-3. Do-it-yourself maintenance

Do-it-yourself service

precautions ....................  217

Hood ................................  220

Positioning a floor jack .....  222

Engine compartment........  224

Tires .................................  238

Tire inflation pressure ......  246

Wheels .............................  250

Air conditioning filter.........  253

Wireless remote control

battery ............................  256

Checking and replacing

fuses ..............................  258

Light bulbs........................  268

204

Scion_xB_OM_OM12F03U_(U)

4-1. Maintenance and care

Cleaning and protecting the vehicle exterior

■

Automatic car washes

●

Fold the mirrors and remove the antenna before washing the vehicle.
Start washing from the front of the vehicle. Make sure to re-install the
antenna and extend the mirrors before driving.

●

Brushes used in automatic car washes may scratch the vehicle surface
and harm your vehicle’s paint.

■

High pressure car washes

●

Do not allow the nozzles of the car wash to come within close proximity
of the windows.

●

Before using the car wash, check that the fuel filler door on your vehicle
is closed properly.

■

Bumpers

Do not scrub with abrasive cleaners.

Perform the following to protect the vehicle and maintain it in prime
condition.

● Working from top to bottom, liberally apply water to the vehicle

body, wheel wells and underside of the vehicle to remove any
dirt and dust.

● Wash the vehicle body using a sponge or soft cloth, such as a

chamois.

● For hard-to-remove marks, use car wash soap and rinse thor-

oughly with water.

● Wipe away any water.
● Wax the vehicle when the waterproof coating deteriorates.

If water does not bead on a clean surface, apply wax when the vehi-
cle body is cool.

205

4-1. Maintenance and care

4

Mai

n

tenan

ce and care

Scion_xB_OM_OM12F03U_(U)

CAUTION

■

When washing the vehicle

Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.

■

Precautions regarding the exhaust pipe

Exhaust gasses cause the exhaust pipe to become quite hot.

When washing the vehicle, be careful not to touch the pipe until it has cooled
sufficiently, as touching a hot exhaust pipe can cause burns.

206

4-1. Maintenance and care

Scion_xB_OM_OM12F03U_(U)

NOTICE

■

To prevent paint deterioration and corrosion on the body and compo-
nents (wheels etc.)

●

Wash the vehicle immediately in the following cases:

• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, insect droppings or bird droppings are present on the

paint surface

• After driving in an area contaminated with soot, oily smoke, mine dust,

iron powder or chemical substances

• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface

●

If the paint is chipped or scratched, have it repaired immediately.

●

To prevent the wheels from corroding, remove any dirt and store in a place
with low humidity when storing the wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.

●

Do not apply wax to the surfaces of the lights.
Wax may cause damage to the lenses.

■

Antenna installation and removal precautions

●

Before driving, ensure that the antenna is installed.

●

When the antenna is removed, such as before entering an automatic car
wash, make sure to store it in a suitable place so as not to lose it. Also,
before driving, make sure to reinstall the antenna in its original position.

207

4-1. Maintenance and care

4

Mai

n

tenan

ce and care

Scion_xB_OM_OM12F03U_(U)

Cleaning and protecting the vehicle interior

The following procedures will help protect your vehicle’s interior and

keep it in top condition:

■

Protecting the vehicle interior

Remove dirt and dust using a vacuum cleaner. Wipe dirty sur-
faces with a cloth dampened with lukewarm water.

208

4-1. Maintenance and care

Scion_xB_OM_OM12F03U_(U)

■

Shampooing the carpets

There are several commercial foaming-type cleaners available. Use a
sponge or brush to apply the foam. Rub in overlapping circles. Do not use
water. Wipe dirty surfaces and let them dry. Excellent results are obtained by
keeping the carpet as dry as possible.

■

Seat belts

Clean with mild soap and lukewarm water using a cloth or sponge. Also
check the belts periodically for excessive wear, fraying or cuts.

CAUTION

■

Water in the vehicle

●

Do not splash or spill liquid in the vehicle.
Doing so may cause electrical components etc. to malfunction or catch
fire.

●

Do not get any of the SRS components or wiring in the vehicle interior wet.
(

P. 70)

An electrical malfunction may cause the airbags to deploy or not function
properly, resulting in death or serious injury.

■

Cleaning the interior (especially instrument panel)

Do not use polish wax or polish cleaner. The instrument panel may reflect off
the windshield, obstructing the driver’s view and leading to an accident,
resulting in death or serious injury.

209

4-1. Maintenance and care

4

Mai

n

tenan

ce and care

Scion_xB_OM_OM12F03U_(U)

NOTICE

■

Cleaning detergents

●

Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:

• Non-seat portions: Organic substances such as benzene or gasoline,

alkaline or acidic solutions, dye, and bleach

• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alco-

hol

●

Do not use polish wax or polish cleaner. The instrument panel’s or other
interior part’s painted surface may be damaged.

■

Water on the floor

Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.

■

Cleaning the inside of the rear window

●

Do not use glass cleaner to clean the rear window, as this may cause
damage to the rear window defogger heater wires. Use a cloth dampened
with lukewarm water to gently wipe the window clean. Wipe the window in
strokes running parallel to the heater wires.

●

Be careful not to scratch or damage the heater wires.

210

Scion_xB_OM_OM12F03U_(U)

4-2. Maintenance

Maintenance requirements

■

Repair and replacement

It is recommended that genuine Scion parts be used for repairs to ensure
performance of each system. If non-Scion parts are used in replacement or if
a repair shop other than a Scion dealer performs repairs, confirm the war-
ranty coverage.

To ensure safe and economical driving, day-to-day care and regular

maintenance is essential. It is the owner’s responsibility to perform

regular checks. Scion recommends the following maintenance:

■

General maintenance

General maintenance should be performed on a daily basis.
This can be done by yourself or by a Scion dealer.

■

Scheduled maintenance

Scheduled maintenance should be performed at specified inter-
vals according to the maintenance schedule.

For details about maintenance items and schedules, refer to the
“Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.

■

Do-it-yourself maintenance

You can perform some maintenance procedures by yourself.
Please be aware that do-it-yourself maintenance may affect war-
ranty coverage.

The use of Scion Repair Manuals is recommended.

For details about warranty coverage, see the separate “Owner’s War-
ranty Information Booklet” or “Owner’s Manual Supplement”.
