179

3

Interior features

Scion_xB_OM_OM12F03U_(U)

3-2. Using the audio system

Using the AUX port/USB port

This port can be used to connect a portable audio device and listen

to it through the vehicle’s speakers.

For more information, please refer to the “SCION Audio System

Owner’s Manual” or “SCION Navigation System Owner’s Manual”.

Remove the tray.

Open the cover and connect
the portable audio device.

STEP

1

STEP

2

180

3-2. Using the audio system

Scion_xB_OM_OM12F03U_(U)

Using the steering wheel audio switches

CAUTION

■

To reduce the risk of an accident

Exercise care when operating the audio switches on the steering wheel.

Some audio features (audio volume control, radio, CD player etc.)

can be controlled using the switches on the steering wheel.

For more information, please refer to the “SCION Audio System

Owner’s Manual” or “SCION Navigation System Owner’s Manual”.

181

3-2. Using the audio system

3

Interior features

Scion_xB_OM_OM12F03U_(U)

Using the microphone

The microphone can be used for the voice command in the

Bluetooth

®

 audio system or the hands-free phone system.

For more information, please refer to the “SCION Audio System

Owner’s Manual” or “SCION Navigation System Owner’s Manual”.

182

Scion_xB_OM_OM12F03U_(U)

3-3. Using the interior lights

Interior lights list

Personal lights (

P. 183)

Interior light (

P. 183)

183

3-3. Using the interior lights

3

Interior features

Scion_xB_OM_OM12F03U_(U)

Interior light

Turns the lights on

Turns the lights off

Turns the door position on

Personal lights

Turns the lights on/off

Interior light and personal lights

184

3-3. Using the interior lights

Scion_xB_OM_OM12F03U_(U)

■

Illuminated entry system

The lights automatically turn on/off according to the engine switch position,
whether the doors are locked/unlocked, and whether the doors are open/
closed.

■

To prevent the battery discharged

The following lights will go off automatically after 20 minutes:

●

Interior light

●

Personal light

●

Luggage compartment light (

P. 37)

■

Customization that can be configured at Scion dealer

Settings (e.g. The time elapsed before lights turn off) can be changed.
(Customizable features:

P. 358)

Personal lights

185

3

Interior features

Scion_xB_OM_OM12F03U_(U)

3-4. Using the storage features

List of storage features

CAUTION

■

Items that should not be left in the storage spaces

Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:

●

Glasses may be deformed by heat or cracked if they come into contact
with other stored items.

●

Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.

Auxiliary box

Glove box

Bottle holders

Cup holders

Console box

186

3-4. Using the storage features

Scion_xB_OM_OM12F03U_(U)

Glove box

Pull up the lever to open the
glove box.

CAUTION

■

Caution while driving

Keep the glove box closed when not in use. In the event of sudden braking
or sudden swerving, an accident may occur due to an occupant being struck
by the open glove box or the items stored inside.

Glove box

187

3-4. Using the storage features

3

Interior features

Scion_xB_OM_OM12F03U_(U)

Console box

Lift the lid while pulling up the
knob to release the lock.

■

When using the console box lid as an armrest

CAUTION

■

Caution while driving

Keep the console box closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by the
open console box or the items stored inside.

Slide the console box lid forward as
needed. Pull the lid forward by holding
the front of the lid.

Console box

188

3-4. Using the storage features

Scion_xB_OM_OM12F03U_(U)

Cup holders

Front

Rear

Pull the lid to open.

Cup holders

189

3-4. Using the storage features

3

Interior features

Scion_xB_OM_OM12F03U_(U)

CAUTION

■

Items unsuitable for the cup holder

Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident,
sudden braking or sudden swerving, causing injury. If possible, cover hot
drinks to prevent burns.

■

When not in use (rear cup holders only)

Keep the cup holders closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by the
open cup holders or the items stored inside.

NOTICE

■

To prevent damage to the rear cup holders

Be careful not to subject the cup holders to an impact.
Failure to do so may unfix the cup holders. Reattach them if they are
unfixed.

Cup holders

190

3-4. Using the storage features

Scion_xB_OM_OM12F03U_(U)

Auxiliary box

Type A

Type B

Type C

Auxiliary box

191

3-4. Using the storage features

3

Interior features

Scion_xB_OM_OM12F03U_(U)

Bottle holders

■

When using the holder as a bottle holder

●

When storing a bottle, close the cap.

●

The bottle may not be stored depending on its size or shape.

NOTICE

■

Items that should not be stowed in the bottle holders

Do not place open bottles in the bottle holders, or glasses and paper cups
containing liquid. The contents may spill and glasses may break.

Bottle holders

192

Scion_xB_OM_OM12F03U_(U)

3-5. Other interior features

Sun visors

To set the visor in the for-
ward position, flip it down.

To set the visor in the side
position, flip down, unhook,
and swing it to the side.

193

3-5. Other interior features

3

Interior features

Scion_xB_OM_OM12F03U_(U)

Vanity mirrors

Slide the cover to open.

194

3-5. Other interior features

Scion_xB_OM_OM12F03U_(U)

Clock

■

The clock is displayed when

The engine switch is in the “ON” position.

■

When disconnecting and reconnecting battery terminals

The time display will automatically be set to 1:00.

Press and hold the “CLOCK”
button to enter adjustment
mode for the clock.

Press the “CLOCK” button to adjust the minutes.

After adjusting the minutes, wait 5 seconds to allow the minutes to
be automatically input.

Press the “CLOCK” button to adjust the hours.

After adjusting the hours, wait 5 seconds to allow the hours to be
automatically input.

STEP

1

STEP

2

STEP

3
