Vauxhall Zafira (2016 year). Manual - part 15





-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle care
243
No. Circuit
No. Circuit
Instrument panel fuse box
33
Adaptive forward lighting/Auto-
49
Fuel pump
matic light control
50
Headlamp levelling/Adaptive
34
Exhaust gas recirculation
forward lighting
35
Exterior mirror/Rain sensor
51
Air shutter
36
Climate control
52
Auxiliary heater/Diesel engine
37
Canister vent solenoid
53
Transmission control module/
Engine control module
38
Vacuum pump
54
Vacuum pump/Instrument
39
Central control module
panel cluster/Heating ventila-
40
Windscreen washer/Rear
tion/Air conditioning system
In left-hand drive vehicles, the fuse
window washer system
box is behind the storage
After having changed defective fuses,
41
Right high beam (Halogen)
close the fuse box cover and press
compartment in the instrument panel.
until it engages.
Open the compartment and push it to
42
Radiator fan
the left to unlock. Fold the
If the fuse box cover is not closed
43
Windscreen wiper
compartment down and remove it.
correctly, malfunctions may occur.
44
Windscreen wiper
45
Radiator fan
46
-
47
Horn
48
Radiator fan

-------------------------------------------------------------------------------------------------------------------------------------------------------------

244
Vehicle care
No. Circuit
No. Circuit
1
Cruise control/Speed limiter/
15
Airbag
Adaptive cruise control/Steering
16
Power outlet
wheel controls
17
Air conditioning system
2
Exterior lights/Body control
module
18
Logistics
3
Exterior lights/Body control
19
Body control module
module
20
Body control module
4
Infotainment system
21
Instrument panel cluster/Anti-
5
Infotainment system/Instrument
In right-hand drive vehicles, the fuse
theft alarm system
box is located behind a cover in the
6
Power outlet/Cigarette lighter
22
Ignition sensor
glovebox. Open the glovebox, then
open the cover and fold it down.
7
Power outlet
23
Body control module
8
Left low beam/Body control
24
Body control module
module
25
-
9
Right low beam/Body control
module/Airbag module
26
-
10
Door locks/Body control module
Load compartment fuse box
11
Interior fan
The fuse box is on the left side of the
12
-
load compartment behind a cover.
13
-
14
Diagnostic connector

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle care
245
Fuse assignments
No. Circuit
1
-
2
Trailer outlet
3
Parking assist
4
Selective catalytic reduction
system
5
-
6
-
Remove the cover.
7
Power seat
8
-
9
Selective catalytic reduction
system
10
Nitrogen oxide sensor
11
Trailer module/Trailer socket
12
Trailer module
13
Trailer outlet
14
-
15
-
If equipped with tyre repair kit,
remove the complete box.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

246
Vehicle care
No. Circuit
No. Circuit
Vehicle tools
16
Interior mirror/Rear view
31
-
Tools
camera
32
Active damping system/Lane
17
Power outlet
departure warning
18
-
19
Steering wheel heating
20
Sunblind
21
Heated front seats
22
-
23
-
24
Selective catalytic reduction
system
Some tools, the towing eye and (only
on vehicles with spare wheel) the
25
-
vehicle jacking equipment are placed
26
-
in the rear storage in the load
compartment floor.
27
-
Open the cover in front of the tailgate.
28
-
29
-
30
-

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle care
247
R
: belt type: Radial
Wheels and tyres
Tyre pressure
RF : type: RunFlat
Check the pressure of cold tyres at
16
: wheel diameter, inches
least every 14 days and before any
Tyre condition, wheel condition
95
: load index e.g. 95 is equivalent
long journey. Do not forget the spare
to 690 kg
Drive over edges slowly and at right
wheel. This also applies to vehicles
H
: speed code letter
angles if possible. Driving over sharp
with tyre pressure monitoring system.
edges can cause tyre and wheel
Speed code letter:
Unscrew the valve cap.
damage. Do not trap tyres on the kerb
Q : up to 100 mph
when parking.
S : up to 112 mph
Regularly check the wheels for
T
: up to 118 mph
damage. Seek the assistance of a
H : up to 130 mph
workshop in the event of damage or
V : up to 150 mph
unusual wear.
W : up to 168 mph
Choose a tyre appropriate for the
Winter tyres
maximum speed of your vehicle.
Winter tyres improve driving safety at
The maximum speed is achievable at
temperatures below 7 °C and should
kerb weight with driver (75 kg) plus
therefore be fitted on all wheels.
125 kg payload. Optional equipment
In accordance with country-specific
could reduce the maximum speed of
regulations, affix the speed sticker in
the vehicle.
Tyre pressure 3 288.
the driver's field of view.
Performance 3 281.
The tyre pressure information label
on the front left or right door frame
Directional tyres
Tyre designations
indicates the original equipment tyres
Fit directional tyres such that they roll
and the correspondent tyre
E.g. 215/60 R 16 95 H
in the direction of travel. The rolling
pressures.
215 : tyre width, mm
direction is indicated by a symbol
60
: cross-section ratio (tyre height
(e.g. an arrow) on the sidewall.
to tyre width), %

-------------------------------------------------------------------------------------------------------------------------------------------------------------

248
Vehicle care
The tyre pressure data refers to cold
The driver is responsible for correct
Temperature dependency
tyres. It applies to summer and winter
adjustment of tyre pressure.
The tyre pressure depends on the
tyres.
temperature of the tyre. During
Always inflate the spare tyre to the
9 Warning
driving, tyre temperature and
pressure specified for full load.
pressure increase. Tyre pressure
If the pressure is too low, this can
The ECO tyre pressure serves to
values provided on the tyre
result in considerable tyre warm-
achieve the smallest amount of fuel
information label and tyre pressure
up and internal damage, leading to
consumption possible.
chart are valid for cold tyres, which
tread separation and even to tyre
Incorrect tyre pressures will impair
means at 20 °C.
blow-out at high speeds.
safety, vehicle handling, comfort and
The pressure increases by nearly
fuel economy and will increase tyre
1.5 psi for a 10 °C temperature
wear.
9 Warning
increase. This must be considered
Tyre pressures differ depending on
when warm tyres are checked.
For specific tyres the
various options. For the correct tyre
The tyre pressure value displayed in
recommended tyre pressure as
pressure value, follow the procedure
the Driver Information Centre shows
shown in the tyre pressure table
below:
the real tyre pressure. A cooled down
may exceed the maximum tyre
1. Identify the engine identifier code.
tyre will show a decreased value,
pressure as indicated on the tyre.
Engine data 3 277.
which does not indicate an air leak.
Never exceed the maximum tyre
2. Identify the respective tyre.
pressure as indicated on the tyre.
Tyre pressure monitoring
The tyre pressure tables show all
If the tyre pressure must be reduced
possible tyre combinations 3 288.
system
or increased on a vehicle with tyre
For the tyres approved for your
The tyre pressure monitoring system
pressure monitoring system, switch
vehicle, refer to the EEC Certificate of
(TPMS) checks the pressure of all
off ignition. After adjusting tyre
Conformity provided with your vehicle
four tyres once a minute when vehicle
pressure, switch on ignition and
or other national registration
speed exceeds a certain limit.
select the appropriate setting on the
documents.
page Tyre load in the Driver
Information Centre, 3 116.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle care
249
System status and pressure warnings
Caution
are displayed by a message with the
corresponding tyre flashing in the
Tyre pressure monitoring system
Driver Information Centre.
warns only about low tyre pressure
The system considers the tyre
condition and does not replace
temperature for the warnings.
regular tyre maintenance by the
driver.
All wheels must be equipped with
pressure sensors and the tyres must
have the prescribed pressure.
Notice
Press MENU to select the Vehicle
In countries where the tyre pressure
Information Menu
X
monitoring system is legally
required, the use of wheels without
pressure sensors will invalidate the
vehicle type approval.
The current tyre pressures can be
shown in the Vehicle Information
A detected low tyre pressure
Menu in the Driver Information
condition is indicated by control
Centre.
indicator w 3 114.
The menu can be selected by the
If w illuminates, stop as soon as
buttons on the turn signal lever.
possible and inflate the tyres as
recommended 3 288.
If w flashes for 60-90 seconds and
then illuminates continuously, there is
Turn the adjuster wheel to select the
a fault in the system. Consult a
tyre pressure monitoring system.
workshop.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

250
Vehicle care
After inflating, some driving may be
Operating electronic devices or being
required to update the tyre pressure
close to facilities using similar wave
values in the Driver Information
frequencies could disrupt the tyre
Centre. During this time w may
pressure monitoring system.
illuminate.
Each time the tyres are replaced, tyre
If w illuminates at lower temperatures
pressure monitoring system sensors
and extinguishes after some driving,
must be dismounted and serviced.
this could be an indicator for
For the screwed sensor: replace
approaching a low tyre pressure
valve core and sealing ring. For
condition. Check tyre pressure.
clipped sensor: replace complete
valve stem.
Vehicle messages 3 122.
If the tyre pressure must be reduced
Vehicle loading status
Select:
or increased, switch off ignition.
Adjust tyre pressure to load condition
● Light for comfort pressure up to
Only mount wheels with pressure
according to the tyre information label
3 people.
sensors, otherwise the tyre pressure
or tyre pressure chart 3 288, and
will not be displayed and w
● Eco for Eco pressure up to
select the appropriate setting in the
illuminates continuously.
3 people.
Tyre load menu in the Driver
A temporary spare wheel is not
Information Centre 3 116. This
● Max for full load.
equipped with pressure sensors. The
setting is the reference for the tyre
Tyre pressure sensor matching
tyre pressure monitoring system is
pressure warnings.
not operational for these wheels.
process
The menu Tyre Load only appears if
Control indicator w illuminates. For
the vehicle is at a standstill and the
Each tyre pressure sensor has a
the further three wheels the system
parking brake is applied. On vehicles
unique identification code. The
remains operational.
with automatic transmission the
identification code must be matched
The use of commercially available
selector lever must be in position P.
to a new wheel position after rotating
liquid tyre repair kits can impair the
the wheels or exchanging the
function of the system. Factory-
complete wheel set and if one or more
approved repair kits can be used.
tyre pressure sensors were replaced.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle care
251
The tyre pressure sensor matching
3. On vehicles with automatic
10. Proceed to the right side front
process should also be performed
transmission: set the selector
wheel, and repeat the procedure
after replacing a spare wheel with a
lever to P.
in Step 9.
road wheel containing the tyre
On vehicles with manual
11. Proceed to the right side rear
pressure sensor.
transmission: select neutral.
wheel, and repeat the procedure
The malfunction light w and the
in Step 9.
4. Press MENU on the turn signal
warning message or code should go
lever to select the Vehicle
12. Proceed to the left side rear
off at the next ignition cycle. The
Information Menu in the Driver
wheel, and repeat the procedure
sensors are matched to the wheel
Information Centre.
in Step 9. The horn sounds twice
positions, using a relearn tool, in the
to indicate the sensor
5. Turn the adjuster wheel to scroll to
following order: left side front wheel,
identification code has been
the tyre pressure menu.
right side front wheel, right side rear
matched to the left side rear tyre,
wheel and left side rear wheel. The
6. Press SET/CLR to begin the
and the tyre pressure sensor
turn signal light at the current active
sensor matching process. A
matching process is no longer
position is illuminated until sensor is
message requesting acceptance
active.
matched.
of the process should be
13. Turn off the ignition.
displayed.
Consult your workshop for service or
14. Set all four tyres to the
to purchase a relearn tool. There are
7. Press SET/CLR again to confirm
recommended air pressure level
two minutes to match the first wheel
the selection. The horn sounds
as indicated on the tyre pressure
position, and five minutes overall to
twice to indicate the receiver is in
label.
match all four wheel positions. If it
relearn mode.
takes longer, the matching process
15. Ensure the tyre loading status is
8. Start with the left side front wheel.
stops and must be restarted.
set according to the selected
9. Place the relearn tool against the
pressure 3 116.
The tyre pressure sensor matching
tyre sidewall, near the valve stem.
process is:
Then press the button to activate
1. Apply the parking brake.
the tyre pressure sensor. A horn
Tread depth
chirp confirms that the sensor
Check tread depth at regular
2. Turn the ignition on.
identification code has been
intervals.
matched to this wheel position.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

252
Vehicle care
Tyres should be replaced for safety
If there is more wear at the front than
Wheel covers
reasons at a tread depth of 2-3 mm
the rear, swap round front wheels and
Wheel covers and tyres that are
(4 mm for winter tyres).
rear wheels periodically. Ensure that
factory approved for the respective
the direction of rotation of the wheels
For safety reasons, it is
vehicle and comply with all of the
remains the same.
recommended that the tread depth of
relevant wheel and tyre combination
the tyres on one axle should not vary
Tyres age, even if they are not used.
requirements must be used.
by more than 2 mm.
We recommend tyre replacement
If the wheel covers and tyres used are
every 6 years.
not factory approved, the tyres must
not have a rim protection ridge.
Changing tyre and wheel
Wheel covers must not impair brake
size
cooling.
If tyres of a different size than those
fitted at the factory are used, it may be
9 Warning
necessary to reprogramme the
speedometer as well as the nominal
Use of unsuitable tyres or wheel
tyre pressure and make other vehicle
covers could lead to sudden
modifications.
pressure loss and thereby
accidents.
After converting to a different tyre
size, have the label with tyre
The legally permissible minimum
Vehicles with steel wheels: When
pressures replaced.
tread depth (1.6 mm) has been
using locking wheel nuts, do not
reached when the tread has worn
attach wheel covers.
9 Warning
down as far as one of the tread wear
indicators (TWI). Their position is
Use of unsuitable tyres or wheels
indicated by markings on the
may lead to accidents and will
sidewall.
invalidate the vehicle type
approval.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle care
253
The use of tyre chains is not permitted
Tyre chains
on the temporary spare wheel.
Tyre repair kit
Minor damage to the tyre tread can be
repaired with the tyre repair kit.
Do not remove foreign bodies from
the tyres.
Tyre damage exceeding 4 mm or that
is at the tyre's sidewall cannot be
repaired with the tyre repair kit.
The tyre repair kit is on the left side in
9 Warning
the load compartment behind a cover.
Tyre chains are only permitted on the
1. Take the tyre repair kit from the
front wheels.
Do not drive faster than 50 mph.
compartment.
Always use fine mesh chains that add
Do not use for a lengthy period.
2. Remove the compressor.
no more than 10 mm to the tyre tread
Steering and handling may be
and the inboard sides (including chain
affected.
lock).
If you have a flat tyre:
9 Warning
Apply the parking brake and engage
first gear, reverse gear or P.
Damage may lead to tyre blowout.
Tyre chains are only permitted on
tyres of size 215/60 R16 and
225/50 R17.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

254
Vehicle care
3. Remove the electrical connection
cable and air hose from the
stowage compartments on the
underside of the compressor.
6. Unscrew valve cap from defective
10. Set the rocker switch on the
tyre.
compressor to I. The tyre is filled
with sealant.
7. Screw the filler hose to the tyre
valve.
11. The compressor pressure gauge
4. Screw the compressor air hose to
briefly indicates up to six bar
8. The switch on the compressor
the connection on the sealant
whilst the sealant bottle is
must be set to J.
bottle.
emptying (approx. 30 seconds).
9. Connect the compressor plug to
Then the pressure starts to drop.
5. Fit the sealant bottle into the
the power outlet or cigarette
retainer on the compressor.
12. All of the sealant is pumped into
lighter socket.
the tyre. Then the tyre is inflated.
Set the compressor near the tyre
To avoid discharging the battery,
in such a way that the sealant
13. The prescribed tyre pressure
we recommend running the
bottle is upright.
should be obtained within ten
engine.
minutes. Tyre pressure 3 288.
When the correct pressure is
obtained, switch off the
compressor.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle care
255
14. Detach the tyre repair kit. Push
catch on bracket to remove
sealant bottle from bracket. Screw
the tyre inflation hose to the free
connection of the sealant bottle.
This prevents sealant from
escaping. Stow tyre repair kit in
load compartment.
15. Remove any excess sealant
using a cloth.
16. Take the label indicating
maximum permitted speed from
If the prescribed tyre pressure is
If tyre pressure is more than
the sealant bottle and affix in the
not obtained within ten minutes,
1.3 bar, set it to the correct value.
driver's field of view.
remove the tyre repair kit. Move
Repeat the procedure until there
the vehicle one tyre rotation.
17. Continue driving immediately so
is no more loss of pressure.
Reattach the tyre repair kit and
that sealant is evenly distributed
If the tyre pressure has fallen
continue the filling procedure for
in the tyre. After driving approx.
below 1.3 bar, the vehicle must
ten minutes. If the prescribed tyre
6 miles (but no more than ten
not be used. Seek the assistance
pressure is still not obtained, the
minutes), stop and check tyre
of a workshop.
tyre is too badly damaged. Seek
pressure. Screw compressor air
18. Stow away tyre repair kit in load
the assistance of a workshop.
hose directly onto tyre valve and
compartment.
compressor when doing this.
Drain excess tyre pressure with
the button over the pressure
indicator.
Do not run the compressor longer
than ten minutes.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

256
Vehicle care
Notice
● No people or animals may be in
Wheel changing
The driving characteristics of the
the vehicle when it is jacked-up.
Some vehicles are equipped with a
repaired tyre are severely affected,
● Never crawl under a jacked-up
tyre repair kit instead of a spare wheel
therefore have this tyre replaced.
vehicle.
3 253.
If unusual noise is heard or the
● Do not start the vehicle when it is
Make the following preparations and
compressor becomes hot, turn
raised on the jack.
observe the following information:
compressor off for at least
● Clean wheel nuts and thread with
30 minutes.
Park the vehicle on a level, firm
a clean cloth before mounting the
and non-skid surface. The front
The built-in safety valve opens at a
wheel.
wheels must be in the straight-
pressure of seven bar (102 psi).
ahead position.
Note the expiry date of the kit. After
9 Warning
Apply the parking brake and
this date its sealing capability is no
engage first gear, reverse gear or
longer guaranteed. Pay attention to
Do not grease wheel bolt, wheel
P.
storage information on sealant
nut and wheel nut cone.
bottle.
Remove the spare wheel 3 258.
1. Disengage wheel nut caps with a
Replace the used sealant bottle.
Never change more than one
screwdriver and remove. Pull off
Dispose of the bottle as prescribed
wheel at once.
the wheel cover. Vehicle tools
by applicable laws.
Use the jack only to change
3 246.
The compressor and sealant can be
wheels in case of puncture, not
Alloy wheels: Disengage wheel
used from approx. -30 °C.
for seasonal winter or summer
nut caps with a screwdriver and
tyre change.
The adapters supplied can be used
remove. To protect the wheel,
to pump up other items e.g.
The jack is maintenance-free.
place a soft cloth between the
footballs, air mattresses, inflatable
If the ground on which the vehicle
screwdriver and the alloy wheel.
dinghies etc. They are located on the
is standing is soft, a solid board
underside of the compressor. To
(max. 1 cm thick) should be
remove, screw on compressor air
placed under the jack.
hose and withdraw adapter.
Take heavy objects out of the
vehicle before jacking up.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle care
257
4. Ensure the jack is correctly
positioned under the relevant
vehicle jacking point.
2. Fold out the wheel wrench and
3. Some versions may have covered
install ensuring that it locates
the vehicle jacking point. Pull out
securely and loosen each wheel
the cover sideways.
nut by half a turn.
5. Set the jack to the necessary
The wheels might be protected by
height. Position it directly below
locking wheel nuts. To loosen
the jacking point in a manner that
these specific nuts first attach the
prevents it from slipping.
adapter onto the head of the nut
before installing the wheel
wrench. The adapter is located in
the glovebox.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

258
Vehicle care
11. Align the valve hole in the wheel
Rear arm position of the lifting
cover with the tyre valve before
platform centrically under the recess
installing.
of the sill.
Install wheel nut caps.
12. Install vehicle jacking point cover.
13. Stow the replaced wheel 3 258,
the vehicle tools 3 246 and the
adapter for the locking wheel nuts
3 66.
14. Check the tyre pressure of the
installed tyre and the wheel nut
Attach wheel wrench and with the
torque as soon as possible.
jack correctly aligned rotate wheel
Have the defective tyre renewed or
wrench until wheel is clear of the
repaired as soon as possible.
ground.
6. Unscrew the wheel nuts.
Jacking position for lifting platform
Front arm position of the lifting
platform at the underbody.
7. Change the wheel. Spare wheel
3 258
Spare wheel
8. Screw on the wheel nuts.
9. Lower vehicle.
Some vehicles are equipped with a
tyre repair kit instead of a spare wheel
10. Install the wheel wrench ensuring
3 253.
that it locates securely and tighten
each nut in a crosswise
If mounting a spare wheel which is
sequence. Tightening torque is
different from the other wheels, this
140 Nm.
wheel might be classified as a
temporary spare wheel and the
corresponding speed limits apply,

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle care
259
even though no label indicates this.
Seek the assistance of a workshop to
check the applicable speed limit.
The spare wheel has a steel rim.
Caution
The use of a spare wheel that is
smaller than the other wheels or in
combination with winter tyres
could affect driveability. Have the
defective tyre replaced as soon as
possible.
3. Fit the wheel wrench on one
5. Lift the spare wheel holder and
hexagon bolt and turn it
unhook both catches.
The spare wheel is located in a holder
anticlockwise until a resistance is
6. Lower the spare wheel holder.
beneath the vehicle floor.
noticeable.
1. Open the storage in the load
4. Proceed with the other hexagon
compartment 3 246.
bolt in the same way.
2. Remove both caps above the
hexagon bolts.
7. Detach the safety cable.















Content      ..     13      14      15      16     ..
