Keys, doors and windows

Unlocking

The setting can be changed in the

Central locking system

Settings menu in the Info-Display.

Unlocks and locks doors, load

Vehicle personalisation 3 103.

compartment and fuel filler flap.

The setting can be saved for the key

A pull on an interior door handle

being used. Memorised settings

unlocks the respective door. Pulling

3 21.

the handle once more opens the door.

Unlocking and opening the boot lid

Notice

3 24.

In the event of an accident in which

airbags or belt pretensioners are

Locking

deployed, the vehicle is

Close doors, load compartment and

automatically unlocked.

fuel filler flap.

Notice

A short time after unlocking with the

Press c.

remote control, the doors are

Two settings are selectable:

relocked automatically if no door has

been opened.

● Press c once briefly to unlock

both doors, load compartment

and fuel filler flap.

Press c again and hold to open

the windows and the soft top

3 31.

● Press c once briefly to unlock

only the driver's door, load

compartment and fuel filler flap.

Press e briefly.

To unlock the entire vehicle,

press c twice.

If the driver's door is not closed

properly, the central locking system

will not work.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Press and hold e again to close the

Fault in radio remote control

Fault in central locking system

soft top and the windows 3 31.

system

Unlocking

Central locking buttons

Unlocking

Manually unlock the driver's door by

turning the key in the lock. The

Locks or unlocks both doors, the load

passenger's door can be opened by

compartment and fuel filler flap from

pulling the interior handle twice. The

the passenger compartment.

load compartment and fuel filler flap

cannot be opened.

To deactivate the anti-theft locking

system, switch on the ignition 3 26.

Locking

Push inside locking knob of

passenger's door. Then close the

driver's door and lock it from the

outside with the key. The fuel filler flap

Manually unlock the driver's door by

and tailgate cannot be locked.

turning the key in the lock. Switch on

the ignition and press the central

Manual closing of the soft top

locking button c to unlock

3 34.

Press e to lock.

passenger's door, load compartment

Press c to unlock.

and fuel filler flap.

Automatic locking

By switching on the ignition, the anti-

This security feature can be

theft locking system is deactivated.

configured to automatically lock the

doors, load compartment and fuel

Locking

filler flap as soon as a certain speed

Manually lock the driver's door by

is exceeded.

turning the key in the lock.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Additionally, it is configurable to

Doors

unlock the driver's door or both doors

after the ignition is switched off and

Load compartment

the ignition key is removed (manual

transmission) or the selector lever is

Boot lid

moved to position P (automatic

transmission).

Opening

Settings can be changed in the

Settings menu in the Info-Display.

Vehicle personalisation 3 103.

The settings can be saved for the key

being used 3 21.

Pressing

opens the boot lid while

the vehicle remains locked.

Central locking system 3 22.

Load compartment 3 71.

Press

on the radio remote control

or push the brand emblem at the

bottom half after unlocking to open

the boot lid.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Closing

Blockage of soft top

Notice

The soft top can only be operated

The installation of certain heavy

when the boot lid is closed.

accessories onto the boot lid may

affect its ability to remain open.

General hints for operating the

boot lid

9 Danger

Do not drive with the boot lid open

or ajar, e.g. when transporting

bulky objects, since toxic exhaust

gases, which cannot be seen or

smelled, could enter the vehicle.

Use the interior handle.

This can cause unconsciousness

Do not touch the brand emblem whilst

and even death.

closing as this could unlock the boot

lid again.

Caution

Central locking system 3 22.

Before opening the boot lid check

Blockage of boot lid

overhead obstructions, such as a

The boot lid can only be opened when

garage door, to avoid damage to

the soft top is completely opened or

the boot lid. Always check the

closed. The soft top lid must be

moving area above and behind the

closed.

boot lid.

Manual closing of the soft top 3 34.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Activating

● vehicle inclination, e.g. if it is

Vehicle security

raised

Anti-theft locking system

● ignition

Activation

9 Warning

● Self-activated 30 seconds after

Do not use the system if there are

locking the vehicle by pressing e

people in the vehicle! The doors

once.

cannot be unlocked from the

● Directly by pressing e twice

inside.

briefly within five seconds. Long

press will activate soft top

The system deadlocks the doors. The

closing.

doors must be closed otherwise the

system cannot be activated.

Notice

Press e on the radio remote control

Changes to the vehicle interior, such

If the ignition was on, the driver's door

twice briefly within 15 seconds. Long

as the use of seat covers and open

must be opened and closed once so

press will activate soft top closing.

windows, could impair the function

that the vehicle can be secured.

of passenger compartment

Unlocking the vehicle disables the

monitoring.

Anti-theft alarm system

mechanical anti-theft locking system.

This is not possible with the central

The anti-theft alarm system is

locking button.

combined with the central locking

system.

It monitors:

● doors, boot lid, bonnet

● passenger compartment

including adjoining load

compartment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Activation without monitoring of

3. Close doors.

Status LED is integrated in the sensor

passenger compartment and

4. Activate the anti-theft alarm

on top of the instrument panel.

vehicle inclination

system.

Status during the first 30 seconds of

anti-theft alarm system activation:

To prevent false alarms passenger

compartment monitoring is

LED illuminates : test, arming delay

deactivated if the soft top is open. The

LED flashes

: doors, boot lid, soft

LED in the button

does not

quickly

top or bonnet not

illuminate.

completely closed,

or system fault

If only the windows are open,

passenger compartment monitoring

Status after system is armed:

operates restricted and the LED in the

LED flashes

: system is armed

button

illuminates.

slowly

Status message is displayed in the

Driver Information Centre.

Seek the assistance of a workshop in

the event of faults.

Status LED

Switch off the monitoring of

Deactivation

passenger compartment and vehicle

inclination when animals are being

Unlocking the vehicle by pressing c

left in the vehicle, because of high

deactivates the anti-theft alarm

volume ultrasonic signals or

system. Long press will activate soft

movements triggering the alarm. Also

top opening.

switch off when the vehicle is on a

The system is not deactivated when

ferry or train.

unlocking the driver's door with the

1. Close boot lid, bonnet, windows

key or by pressing the central locking

and soft top.

button in the passenger

2. Press

o. LED in the button

compartment.

illuminates for a maximum of

10 minutes.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Alarm

ignition on then off, then disconnect

Control indicator d 3 93.

the vehicle's battery within

When triggered, the alarm horn

15 seconds.

sounds and the hazard warning lights

flash simultaneously. The number

and duration of alarm signals are

Immobiliser

stipulated by legislation.

The system is part of the ignition

The alarm can be silenced by

switch and checks whether the

pressing any button on the radio

vehicle is allowed to be started with

remote control or by switching on the

the key being used.

ignition.

The immobiliser is activated

The anti-theft alarm system can be

automatically after the key has been

deactivated only by pressing c or by

removed from the ignition switch.

switching on the ignition.

If the control indicator d flashes when

A triggered alarm, which has not been

the ignition is on, there is a fault in the

interrupted by the driver, will be

system; the engine cannot be started.

indicated by the hazard warning

Switch off the ignition and repeat the

lights. They will flash quickly three

start attempt.

times the next time the vehicle is

If the control indicator continues

unlocked with the radio remote

flashing, attempt to start the engine

control. Additionally a warning

using the spare key and seek the

message is displayed in the Driver

assistance of a workshop.

Information Centre after switching on

Notice

the ignition.

The immobiliser does not lock the

Vehicle messages 3 101.

doors. You should always lock the

If the vehicle's battery is to be

vehicle after leaving it.

disconnected (e.g. for maintenance

Switch on the anti-theft alarm

work), the alarm siren must be

system 3 22, 3 26.

deactivated as follows: switch the

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

In position 0 no mirror is selected.

Electric folding

Exterior mirrors

Convex shape

Folding mirrors

The convex exterior mirror contains

an aspherical area and reduces blind

spots. The shape of the mirror makes

objects appear smaller, which will

affect the ability to estimate

distances.

Electric adjustment

Turn control to 0, then push the

control down. Both exterior mirrors

will fold.

For pedestrian safety, the exterior

mirrors will swing out of their normal

Push the control down again - both

mounting position if they are struck

exterior mirrors return to their original

with sufficient force. Reposition the

position.

mirror by applying slight pressure to

If an electrically folded mirror is

the mirror housing.

manually extended, pressing down

the control will only electrically extend

the other mirror.

Select the relevant exterior mirror by

turning the control to left (L) or right

(R). Then swivel the control to adjust

the mirror.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Heated mirrors

Interior mirrors

Automatic anti-dazzle

Manual anti-dazzle

Operated by pressing Ü.

Dazzle from following vehicles at

night is automatically reduced.

The LED in the button indicates

activation.

To reduce dazzle, adjust the lever on

the underside of the mirror housing.

Heating works with the engine

running and is switched off

automatically after a short time.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Windows

Windscreen stickers

Power windows

Do not attach stickers such as toll

Windscreen

9 Warning

road stickers or similar on the

windscreen in the area of the interior

Heat-reflecting windscreen

Take care when operating the

mirror. Otherwise the detection zone

power windows. Risk of injury,

The heat-reflecting windscreen has a

of the sensor and the view area of the

particularly to children.

coating which reflects solar radiation.

camera in the mirror housing could be

Also data signals, e.g. from toll

restricted.

Keep a close watch on the

stations, might be reflected.

windows when closing them.

Windscreen replacement

Ensure that nothing becomes

trapped in them as they move.

Caution

Operable with ignition switch in

If the vehicle has a front-looking

position 1 or 2 (ignition on) 3 137.

camera sensor for the driver

Retained power off 3 137.

assistance systems, it is very

important that any windscreen

replacement is performed

accurately according to Vauxhall

specifications. Otherwise, these

systems may not work properly

and there is a risk of unexpected

behaviour and/or messages from

The marked areas on the windscreen

these systems.

are not covered with the coating.

Devices for electronic data recording

and fee payment must be attached in

these areas. Otherwise data

recording malfunctions may occur.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Operate the switch for the respective

Push switch , briefly to open all

window by pushing to open or pulling

windows automatically.

to close.

Pull switch , briefly to close all

Pushing or pulling gently to the first

windows automatically.

detent: window moves up or down as

long as the switch is operated.

Safety function

Pushing or pulling firmly to the second

If the window glass encounters

detent then releasing: window moves

resistance above the middle of the

up or down automatically with safety

window during automatic closing, it is

function enabled. To stop movement,

immediately stopped and opened

operate the switch once more in the

again.

same direction.

Override safety function

Opening

Central switch ,

In the event of closing difficulties due

● Press c once briefly: the doors

to frost or the like, switch on the

are unlocked.

ignition, then pull the switch to the first

● Press c once more for two

detent and hold. The window moves

seconds: the windows move

up with safety function disabled. To

down automatically. Press c

stop movement, release the switch.

longer: the soft top will be

opened. Press and hold c until

Comfort operating with the

soft top is completely opened.

remote control

Release c during opening the soft

The windows and the soft top can be

top: movement stops for 10 seconds;

operated remotely from outside the

pressing c once more continues

vehicle.

opening.

Switch in the centre console to

Closing

operate all windows.

● Press e once briefly: the doors

are locked.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

● Press e once more longer: the

Initialising the power windows

Heated rear window

soft top and the windows will be

If the windows cannot be closed

closed. Press and hold e until soft

automatically (e.g. after

top is completely closed.

disconnecting the vehicle battery), a

Release e during closing the soft

warning message is displayed in the

top: movement stops for

Driver Information Centre.

10 seconds; pressing e once

Vehicle messages 3 101.

more continues closing.

Activate the window electronics for

● If the soft top is already closed

each window, beginning with the rear

but windows are opened:

windows, as following:

pressing e for two seconds will

close the windows.

1. Soft top must be closed.

2. Close doors.

Confirmation

3. Switch on ignition.

Complete opening or closing of the

Operated by pressing Ü.

soft top is confirmed by the hazard

4. Pull switch to the second detent

The LED in the button indicates

warning flashers.

until the window starts to close,

activation.

and hold pulled for an additional

Overload

Heating works with the engine

4 seconds.

running and is switched off

If the windows are repeatedly

5. Push switch to the second detent

automatically after a short time.

operated within short intervals, the

until the window starts to open

Heated rear window is deactivated

window operation is disabled for

automatically.

when the soft top is opened.

some time.

6. Repeat for each window.

Sun visors

The sun visors can be folded down or

swivelled to the side to prevent

dazzling.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

If the sun visors have integral mirrors,

Operation with the switch in the

Roof

the mirror covers should be closed

centre console

when driving.

Soft top

Operable with ignition switch in

A ticket holder is located on the

position 1 or 2 (ignition on) 3 137.

backside of the sun visor.

9 Warning

The soft top can be opened and

closed while driving up to a speed of

Take care when operating the soft

31 mph.

top. Risk of injury. Monitor the

action zone above, to the side and

Open soft top

to the rear of the vehicle during

operation.

Make sure that no body parts or

objects could get pinched. Make

sure that people stay clear of the

action zone of the soft top or soft

top lid. Risk of injury.

Check the height, length and width

of the available space before

operating the soft top, e.g. in a

garage, parking garage or when a

bicycle rack is fitted.

Vehicle passengers should be

Hold switch pulled until the soft top is

informed accordingly.

completely opened and the soft top lid

Before leaving the vehicle, remove

is closed. All windows will be opened

the ignition key in order to prevent

during this operation.

unauthorised operation of the

To close all windows pull switch ,.

windows and the soft top.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Close soft top

Operation with remote control

Close soft top

Open soft top

Hold switch pushed until the soft top

Press and hold e until the soft top, the

and the soft top lid are completely

soft top lid and the windows are

closed. All windows will be opened

Press and hold c until the soft top is

completely closed. All windows will be

during this operation.

opened completely and the soft top lid

opened at first during this operation.

is closed. All windows will be opened

Pull switch , briefly to close all

during this operation.

Confirmation of operation

windows.

Complete opening or closing of the

Confirmation of operation

soft top with the remote control is

confirmed by the hazard warning

Complete opening or closing of the

flashers.

soft top with the switch in the centre

console is confirmed by the sound of

an acoustic signal.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

Safety stop

The button on the remote control or

the switch in the centre console must

be actuated until the soft top is in its

respective end position. Releasing

the button or the switch during

operation stops soft top movement

immediately. The soft top remains in

intermediate position only for a

certain time. After this time a warning

chime sounds, the hydraulic pressure

in the system decreases and the soft

If any of these requirements are

top can start to move by itself.

●

Load compartment partition is

not fulfilled, a warning chime

Actuating button or switch once more

folded out, pass-through flap is

sounds and a message appears

continues operation.

closed 3 71.

in the Driver Information Centre

●

Soft top lid is engaged in closed

when the switch is actuated and

Requirements for operation

position.

the soft top will not open or close.

● Vehicle is stationary or driving

●

Boot lid is completely closed.

●

There must be no objects in front

with a speed up to 31 mph.

●

Outside temperature is not lower

of the rear window or in the pivot

than -7 °C for opening and

area of the soft top and the soft

-10 °C for closing.

top lid.

●

Vehicle battery voltage is

If the automatic drive is not

sufficient.

operational when the soft top is open,

execute a manual closing process,

●

The system is not overloaded by

see the following instructions in

repeated operation (max. 5

"Manual closing in the event of a

complete cycles in succession).

system fault".

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

General hints

Manual closing in the event of a

Manual operation of the soft top is

system fault

permitted only for closing.

Notice

●

Always actuate the operation

In case of malfunction of the electro-

Read the following description

switch until the acoustic signal

hydraulic actuation, the opened soft

completely before starting to

sounds or the hazard warning

top can be closed manually.

operate.

flashers illuminate, to ensure that

Do not perform the manual closing

the soft top is completely opened

with the vehicle parked on

or closed.

downhill gradient or inclines.

●

The soft top can be held in an

Remove the large wind deflector

intermediate position to facilitate

before starting to operate.

cleaning of hood spaces and

After closing, have the soft top

gaskets. Release the switch in

repaired by a workshop.

the centre console during

operation to stop soft top

Prepare the following tools which are

movement in intermediate

required for manual operation:

position for a maximum of

7 minutes when ignition is on.

After this time a warning chime

sounds, the hydraulic pressure in

A warning chime sounds and a

the system decreases and the

message appears in the Driver

soft top can start to move by

Information Centre.

itself.

●

Do not open the soft top if it is wet,

Caution

frozen or dirty.

We strongly advise performing

●

Activating the soft top on uneven

manual closing of the soft top with

ground can lead to malfunctions

two persons.

and damage.

●

Vehicle care 3 229.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, doors and windows

●

allen key with 4 mm hexagon on

3. On the inside of the upper load

5. Lift up soft top lid from both sides

the long side and 6 mm hexagon

compartment edge is a lever for

simultaneously up to approx. the

on the short side, located in the

releasing the soft top lid. Locate

half raised position.

glovebox

the lever and unlatch by swivelling

the lever downwards.

●

two strings, located in the

glovebox

Notice

●

screwdriver, located in the tool

The boot lid cannot be opened from

box in the load compartment

next step on.

3 209

Remove the screwdriver from the

1. Switch off ignition.

toolbox for further operation. It is

possible that the load compartment

2. Open the boot lid and remove the

cannot be opened until the vehicle is

screwdriver from the tool box.

at a workshop. Therefore remove

any required objects from the load

compartment.

4. Close boot lid.

Vauxhall Cascada (2016 year). Manual - part 2
