194

Driving and operation

To deactivate

The winter program is switched off by:
z pressing button T again,

z changing to manual mode,

z turning off the ignition.
In order to prevent damage, the winter

program switches off automatically at high

transmission oil temperatures.

Kickdown

Depressing the accelerator pedal past the

pressure point: depending on the engine

speed the transmission shifts to a lower

gear. Full engine power is available for

accelerating.
For safety reasons kickdown is available in

both automatic and manual mode.

Engine braking

The automatic transmission automatically

selects the driving programs with the best

possible braking effect.
If necessary, lower gears can also be

selected in manual mode to increase the

braking effect. 1st gear has the greatest

braking effect.

195

Driving and operation

"Rocking the car"

If it becomes necessary to rock the vehicle

to free it from sand, mud, snow or a hole,

move the selector lever from D to R in a

repeat pattern while simultaneously

applying light pressure to the accelerator

pedal. Do not race the engine and avoid

sudden acceleration.
This applies only to the exceptional

circumstances mentioned above.

Manoeuvring the vehicle

To manoeuvre the vehicle back and forth

during attempts to park or in garage

entrances, the vehicle’s creeping

movement can be utilised by releasing the

brake pedal.
Never actuate accelerator and brake

pedals simultaneously.

Stopping the vehicle

The selector lever can be left in the chosen

gear with the engine running.
When stopping on gradients engage

handbrake or depress brake pedal. To

prevent overheating of the transmission,

do not increase engine revolutions to

ensure smooth idling while standing if a

gear has been selected.
Switch off engine if stopping for a lengthy

period, e.g. in traffic jams or at level

crossings.
Before leaving the vehicle, first apply the

handbrake. Then select P. Remove the

ignition key or, with Open&Start system,

remove the electronic key 3 from the

vehicle. Lock the vehicle. Otherwise the

battery may become discharged if the

vehicle is parked up for long periods.

196

Driving and operation

The ignition key can only be removed when

the selector lever is in position P.
If the selector lever is not in position P when

the ignition is switched off, control

indicator

j

 and P flash in the selector lever

indicator strip, see Fig. S 12103 on

page 191. Move the selector lever to

position P.
With the Open&Start system 3, "P" flashes

in the transmission display for 10 seconds

when the ignition is switched off if P has not

been engaged or the handbrake has not

been applied.

Fault

If there is a problem with the automatic

transmission, control indicator A

illuminates. The transmission no longer

shifts automatically. The vehicle can

continue to be driven.
Illumination of control indicator A may

also indicate a problem with the engine

electronics, see page 206.
For diesel engines

1)

  Z 19 DT  and  Z 19 DTH,

illumination of control indicator A could

also indicate that the diesel fuel filter must

be drained of water - see page 300.
Have the cause of the fault eliminated by a

workshop.

2nd gear and the highest gear can be

selected in manual mode. Depending on

the nature of the problem, only the highest

gear may be available.
Only the highest gear is available in D in

automatic mode.

1)

Sales designation, see page 310 and 311.

197

Driving and operation

Interruption of power supply

If the vehicle battery is flat, the selector

lever cannot be moved out of position P

or N.
If the battery is flat, start the vehicle using

jump leads, see page 243.
If the battery is not the cause of the fault,

release selector lever:
1. Apply handbrake.
2. Remove the ashtray insert 3 or the

rubber covering on the bottom of the

stowage compartment 3 - see page 108.

3. To open, push the yellow catch down

with a screwdriver and move the selector

lever out of P or N.

4. Refit the ashtray insert 3 or rubber

covering on the bottom of the stowage

compartment 3 - see page 108.

Reselecting P or N causes locking again.

Have a workshop eliminate the cause of

the power loss.

198

Driving and operation

Driving hints

The first 600 miles (1000 km)

Drive your vehicle at various speeds. Do

not use full throttle. Never allow the engine

to labour at low revs.
Make good use of all gears. Depress the

accelerator pedal a maximum of around

three quarters of the available pedal travel

in all gears.
Do not drive faster than three quarters of

maximum speed.
Do not brake unnecessarily hard for the

first 125 miles (200 km).
Never coast with engine not running

Many units will not function in this situation

(e.g. brake servo unit, electro-hydraulic

power steering). Driving in this manner is a

danger to yourself and others.
Brake servo unit

When the engine is not running, the brake

servo unit is no longer effective once the

brake pedal has been depressed once or

twice. Braking effect is not reduced, but

significantly greater force is required for

braking.

Electro-hydraulic power assisted steering

If the power-assisted steering fails when

being towed with the engine switched off,

the vehicle can still be steered, but

considerably more force is required.
Driving in mountainous terrain or with a

trailer/caravan

The cooling fan is electrically operated. Its

cooling power is therefore independent of

the engine speed.
Since a considerable amount of heat is

generated at high engine speeds and less

at slower speeds, do not shift down when

climbing hills whilst the vehicle is still coping

with the gradient in the higher gear.
Driving with a roof load

Do not exceed the permissible roof load -

see pages 232, 325. For reasons of safety,

distribute the load evenly and secure it

properly with retaining straps. Adjust the

tyre pressure to the load conditions. Do not

drive faster than 75 mph (120 km/h). Check

and retighten the straps frequently.

Observe country-specific regulations. Roof

loads are not permitted on the Astra

TwinTop.

Switching off the engine

When you switch off, fans in the engine

compartment may continue running for a

time to cool the engine.
If the engine temperature is very high, e.g.

after driving in mountainous terrain: allow

the engine to idle for approximately two

minutes in order to prevent heat

accumulation.
Vehicles with turbocharged engine 3

After running at high engine speeds or high

engine loads, operate the engine briefly at

a low load or run in neutral for approx.

30 seconds before switching off in order to

protect the turbocharger.
Save energy – more miles

Please observe the running-in hints on this

page and the tips for saving energy on the

following pages.
Good, technically correct and economical

driving ensures maximum durability and

performance for your vehicle.

199

Driving and operation

Overrun

The fuel supply is automatically shut off

during overrun, e.g. when the vehicle is

being driven down long gradients or when

braking. To enable the overrun cut-off to

take effect, do not accelerate during

overrun and, if in manual transmission

mode, do not de-clutch. To prevent

damage to the catalytic converter, overrun

cut-off is temporarily deactivated when the

catalytic converter temperature is high.
Vehicles with turbocharged engine 3

Flow-generated noises may be audible if

the accelerator is released quickly on

account of air flow in the turbocharger.
Engine speed

Drive in a low engine speed range for each

gear as much as possible.
Warming up

After a cold start, the automatic

transmission 3 or Easytronic 3 in

automatic mode shifts into higher gears at

higher rpm. This allows the catalytic

converter to quickly reach the temperature

required for optimum pollutant reduction.

Correct gear selection

Engine in neutral and without revving in the

lower gears. Stop-and-go traffic and

driving at a speed too high for the selected

gear or transmission ratio increases wear

and fuel consumption.
Change down

When decreasing speed, shift down into

the next lowest gear. Do not slip the clutch

with a high-revving engine. This is

especially important when hill climbing.
Clutch operation

Always depress the clutch pedal hard to

the floor to prevent shifting difficulties and

transmission damage.
When driving do not use the pedal as a

footrest; this will cause substantial clutch

wear.

Cooling fan

The cooling fan is controlled via a

thermoswitch and therefore only runs if

necessary.
The cooling fan automatically switches on

when the diesel particle filter is being

cleaned 3 depending on the engine.
Pedals

Do not place any objects in the footwell

which could slip under the pedals and

inhibit the pedal travel.
To ensure the pedal travel is uninhibited,

there must be no mats in the area of the

pedals.
Battery care

When driving slowly or when the vehicle is

stationary, e.g. in slow urban traffic,

stop-and-go traffic or traffic jams, turn off

all unnecessary electrical loads where

possible (e.g. heated rear window, heated

seats).
De-clutch when starting in order to relieve

the strain on the starter and the battery.

200

Driving and operation

Saving fuel, protecting the

environment

Trend-setting technology

In the development and manufacture of

your vehicle, environmentally-friendly and

in the main recyclable materials were used.

The production methods used to make

your vehicle are likewise environmentally-

friendly.
Recycling of production wastes keeps the

circulation of material closed. Reduction of

energy and water requirements also helps

to conserve natural resources.
A highly advanced design means that your

vehicle can be easily disassembled at the

end of its working life, and the individual

materials separated for subsequent re-use.
Materials such as asbestos and cadmium

are not used. The refrigerant in the air

conditioning system 3 is CFC-free.
New painting techniques employ water as

a solvent.

End-of-life vehicle recovery

For detailed information on Vauxhall’ s

ongoing commitment to achieving an

environmentally sustainable future,

including; design for recycling, take back of

End-of-Life Vehicle (ELVs) and the

recycling of ELVs, view

www.Vauxhall.co.uk/recycling for details

.

Energy and environment-conscious

driving

z High noise levels and exhaust emissions

are often a result of driving without due

attention to saving energy and

protecting the environment.

z You should therefore drive with energy in

mind – "more miles with less fuel".
Reduce the noise level and exhaust

emissions by adopting an environment-

conscious driving style. This is extremely

worthwhile and improves the quality of

life.
Fuel consumption depends to a great

extent on your own personal driving

style. The following hints are intended to

help you consume fuel at a rate that is as

close as possible to the specified levels,

see page 316.
Check your vehicle’s fuel consumption

every time you refuel. This facilitates

early detection of any irregularities

causing increased fuel consumption.

Warming up

z Full throttle and warming up at idle

speed increase wear, fuel consumption,

exhaust emission, the amount of

pollutant in the exhaust and the amount

of noise.

z Drive off as soon as possible after

starting.

Uniform speed

z Hectic driving significantly increases fuel

consumption, the exhaust emissions, the

proportion of pollutant in the exhaust

gas and the noise level.

z Do not accelerate and brake

unnecessarily. Drive at uniform speed,

watching the road.
Avoid frequent starting off and stopping

e.g. at traffic lights, in short distance

traffic and in queues of traffic by means

of clever planning. Select roads with

good traffic flow.

Idling

z The engine also consumes fuel when

idling.

z If you have to wait for more than one

minute, it is worthwhile switching off the

engine. Five minutes of idling

corresponds to approximately 0.6 miles

(1 km) of driving.

201

Driving and operation

Overrun

z The fuel supply is automatically shut off

during overrun, e.g. when the vehicle is

being driven down long gradients or

when braking, see page 199.

z To enable the overrun cut-off to come

into action and save fuel, do not

accelerate or de-clutch during overrun.

Correct gear selection

z High revs increase engine wear and fuel

consumption.

z Do not race your engine. Avoid driving at

high engine speeds.
Making use of the tachometer helps to

save fuel. Drive in a low engine speed

range for each gear as much as possible

with uniform engine speeds. Drive as

often as possible in top gear, select the

next higher gear as soon as possible,

and only change down when the engine

is no longer running perfectly smoothly.

High speed

z The higher the speed, the higher the

consumption and the noise level. At top

speed, you consume a great deal of fuel

and produce excessive noise and

exhaust emissions.

z Slightly releasing the accelerator pedal

results in distinct fuel savings with no

major loss of speed.
Drive at no more than around three

quarters of maximum speed and you will

use up to 50% less fuel, without losing a

great deal of time.

Tyre pressure

z Inadequate tyre pressure, leading to

higher road resistance, costs money in

two ways: for more fuel and increased

tyre wear.

z Regular checks (every 14 days) pay off.
Electrical loads

z The power consumption of electrical

equipment increases fuel consumption.

z Switch off all auxiliary electrical loads

(e.g. air conditioning 3, heated rear

window) when not needed.

Roof racks, ski-holders

z Due to air resistance, a roof load can

increase fuel consumption by approx.

3.5 gal./1000 miles (1 l/100 km).

z Remove them if they are not being used.

Repair and maintenance

z Improper repairs or adjustment and

maintenance work can increase fuel

consumption. Do not carry out work on

the engine yourself.
You may out of ignorance infringe

environmental laws by not disposing of

materials properly.
Appropriate parts might not be recycled.
Contact with some of the materials

involved may pose a health hazard.

z We recommend that repair and

maintenance be entrusted to your

Vauxhall Authorised Repairer.

Extreme driving conditions

z Going up steep slopes, cornering, driving

on poor roads and winter driving all

increase fuel consumption.
Fuel consumption increases dramatically

in urban traffic and at winter

temperatures, especially on short trips

when the engine operating temperature

is not reached.

z Follow the hints given above to keep

consumption to a minimum under such

conditions.

202

Driving and operation

Fuels, refuelling

Fuel consumption

Fuel consumption is determined under

specific driving conditions, see page 316.
Special equipment increases the weight of

the vehicle. As a result, they can increase

fuel consumption and reduce the specified

maximum speed.
For the first few thousand miles, friction

between the engine and transmission

components is higher. This increases fuel

consumption.

Fuel for petrol engines

Normal commercial high-quality fuels with

a maximum ethanol content of 5% in

accordance with DIN EN 228 are suitable

(for catalytic converter see page 204, for

octane numbers see pages 310, 311). The

quality thereof has considerable effect on

the performance, running and service life

of the engine. The additives mixed with the

fuel are extremely important. For this

reason you must only refuel with high-

quality fuels containing additives.
Fuels with ethanol content greater than 5%

do not comply with DIN EN 228 and must

not be used unless the vehicle has been

specifically developed and approved for

these fuels.
Fuel with too low an octane number can

cause pinking. No liability can be accepted

for resulting damage.
Petrol with a higher octane number can

always be used.
The ignition timing adjusts automatically

to the grade of fuel used (octane number),

see pages 310, 311.
Use of petrol with an octane rating of 95

will ensure economical driving.
For vehicles with Z20 LEH

1)

 engine, use of

95 RON fuel reduces performance and

torque.

Fuel for diesel engines

Diesel engines must be operated only on

commercially available diesel fuel meeting

the specifications of DIN EN 590.
Since January 2004, some oil companies

have mixed their diesel fuel with upto 5%

Bio fuel (FAME = Fatty Acid Methyl Esters)

like RME (Rape-Oil Methyl Ester). This is in

accordance with the current DIN EN 590

and does not harm the fuel/injection

system. The characteristics of a diesel fuel

mixed up with 5% Bio fuel (FAME) do not

differ from conventional diesel fuel and do

not influence the vehicle’s driveability.
Important: Diesel fuel mixed with 5% FAME

according to DIN EN 590 must not be

confused with 100% Bio Diesel, which is not

to be used in Vauxhall engines.
The flow and filterability of diesel fuel are

temperature-dependent.
Diesel fuels with improved low temperature

properties are therefore available on the

market during the winter months. Make

sure that you fill the tank with winter fuel

before the start of the cold weather

season.
Additives can be used with diesel fuels with

winter properties that are guaranteed by

the manufacturer and when using diesel

fuel filters that are heated depending on

the outside temperature.
Diesel fuels must not be diluted with fuels

that are intended for petrol engines.

1)

Sales designation, see pages 310 and 311.

203

Driving and operation

Fuel filler cap

If replacing the fuel filler cap, be sure to use

a genuine fuel filler cap for your model to

ensure full functionality. Diesel-engined

vehicles have special fuel filler caps.

Refuelling

Fuel filler neck at right rear side of vehicle.
The tank flap is locked together with the

doors, see page 40.
Open the tank flap.
Unscrew the fuel filler cap, remove and

suspend from the tank flap.
The fuel tank has a limiting system which

prevents overfilling of the tank.

9

 Warning

Care must be taken when handling fuel.
Before refuelling, switch off the engine

and where applicable any auxiliary

heating with combustion chambers

(see sticker on fuel filler cap). Switch off

mobile phones.

204

Driving and operation

Correct filling depends to a large extent on

proper operation of the fuel dispensing

pump:
1. Fully insert the pump nozzle and switch

it on.

2. After automatic switch off, the specified

tank capacity is reached after continued,

measured filling. Leave the filler nozzle in

place until the stop.

To close, position the fuel filler cap and

rotate past the resistance until the cap

audibly clicks over the retainer.

Close fuel tank cover.
Wipe off any overflowing fuel immediately.

Catalytic converter,

exhaust gases

Catalytic converter for petrol engines

Leaded fuel will damage the catalytic

converter and parts of the electronic

system, rendering them inoperative.
High quality fuels other than those listed on

pages 202, 310, 311 (e.g. LRP

1)

) could

damage the catalytic converter.

9

 Warning

Fuel is flammable and explosive. When

handling fuel or in the immediate vicinity,

avoid naked flames or sparks. Do not

smoke. This also applies where the

presence of fuel is revealed by its

characteristic smell. If fuel odours occur in

the car, have a workshop eliminate the

fault immediately.

1)

LRP

 =

L

ead

R

eplacement

P

etrol.

205

Driving and operation

Damage to the catalytic converter or the

vehicle may result if the following points

are not observed:
z On ignition faults, uneven running after

cold start, a clear drop-off in engine

power or other unusual operating

symptoms which could indicate a fault in

the ignition system, contact a workshop

as soon as possible. Continue driving if

necessary for a short time at low speed

and low revs.
Irregular engine running and a loss of

engine power when the Electronic

Stability Program (ESP®

Plus

 3) comes

into action are the result of operating

conditions and are therefore of no

significance - see page 210.

z If unburned fuel enters the catalytic

converter, this may result in overheating

and irreparable damage to the catalytic

converter.
You should therefore avoid

unnecessarily long use of the starter

when starting off, running the tank dry

(an irregular fuel supply will lead to

overheating) and starting the engine by

pushing or towing.

z If the control indicator Z flashes to

indicate emissions, back off until the

flashing stops and the control indicator

illuminates. Contact a workshop

immediately. Control indicator for

emissions Z, see page 206.

Catalytic converter for diesel engines

Damage to the catalytic converter or the

vehicle may result if the following points

are not observed:
z On uneven running, a clear drop-off in

engine power or other unusual operating

symptoms, contact a workshop as soon

as possible. Continue driving if necessary

for a short time at low speed and low

revs.
Irregular engine running and a loss of

engine power when the Electronic

Stability Program (ESP®

Plus

 3) comes

into action are the result of operating

conditions and are therefore of no

significance - see page 210.

206

Driving and operation

Controlling exhaust emission

Some of the damaging substances

in the exhaust such as carbon

monoxide (CO), hydrocarbons (HC)

and nitrous oxides (NO

x

) are reduced

to a minimum by making structural

changes – mainly in the injection system

and the ignition system in conjunction

with the catalytic converter.

Control indicator Z for exhaust

Illuminates when the ignition is switched on

and during the start attempt. Goes off

shortly after the engine starts running.
Illuminated with the engine running

indicates a fault in the exhaust gas

cleaning system. The permitted emissions

may be exceeded. Contact a workshop

immediately.
Flashing with the engine running indicates

a fault which could lead to catalytic

converter damage. You may continue

driving without damage if you back off

until flashing stops and the control

indicator comes on. Contact a workshop

immediately.

Control indicator A for engine electronics

Illuminates for a few seconds after the

ignition is switched on.
If it illuminates when the engine is running,

there is a fault in engine or transmission

electronics. The electronic system switches

to an emergency running programme. Fuel

consumption may be increased and the

driveability of the vehicle may be impaired.
In some cases, faults can be eliminated by

switching off the engine and restarting. If

the control indicator comes on again when

the engine is running, contact a workshop

to eliminate the cause of the fault.

207

Driving and operation

If it illuminates briefly, but does not recur, it

is of no significance.
Illumination of A can indicate water in the

diesel fuel filter 3, at the same time a

message appears in the service display,

see page 120. Have a workshop check the

fuel filter for possible water residue.
If it flashes after the ignition is switched on,

there is a fault in the immobiliser system.

The engine cannot be started, see page 31.

Exhaust gases

During the first drive smoke may develop

because of wax and oil evaporating on the

exhaust system. Park the vehicle in the

open for a while after the first drive and

avoid inhaling the fumes.

Diesel particle filter 3

The diesel particle filter system removes

polluting soot particles out of the engine

exhaust gases. The system includes a self-

cleaning function that operates

automatically while driving. The filter is

cleaned by burning the trapped soot

particles at a high temperature. There may

be an increase in fuel consumption,

exhaust smell, and engine cooling fan

operation 3 during the self-cleaning

operation.

9

 Warning

Engine exhaust gases contain poisonous

carbon monoxide, which is colourless and

odourless and could be fatal if inhaled.
If exhaust gases penetrate the vehicle

interior, open a window and contact a

workshop.
Avoid driving with an open luggage

compartment. Otherwise, exhaust gases

could penetrate the interior.

208

Driving and operation

Picture no: 18537t.tif

The self-cleaning function can not operate

automatically during certain driving

situations where the engine does not reach

its normal operating temperature. An

example of this would be driving only short

distances in cold weather. If the filter needs

cleaning and recent driving situations did

not allow the function to automatically

operate, then the control indicator

!

 will

flash. If this occurs, then you may continue

to drive the vehicle normally. The vehicle

will not be damaged and does not require

service.

The self-cleaning function will

automatically operate while driving after

the engine has reached its normal

operating temperature. The control

indicator

!

 will continue to flash until the

self-cleaning operation is complete. This

may take up to 20 minutes of driving. The

time will be shorter at higher vehicle

speeds. If the vehicle is not moving for

more than a few minutes, then the self-

cleaning function will not operate.

Operation will continue when driving

resumes.

We recommend that you do not turn the

ignition off until the self-cleaning operation

is complete. If you must turn the ignition off

before the operation is complete, then the

operation will automatically resume when

driving the next time and after the engine

has reached its normal operating

temperature.

209

Driving and operation

The control indicator

!

 goes off as soon as

the self-cleaning operation is complete.

Maintenance

Have all maintenance work carried out at

the intervals specified. We recommend

that you entrust this work to your Vauxhall

Authorised Repairer, who has proper

equipment and trained personnel

available. Electronic testing systems permit

rapid diagnosis and remedy of faults. This

way you can be certain that all

components of the vehicle’s electrical,

injection and ignition systems operate

correctly, that your vehicle has a low level

of pollutant emission and that the catalytic

converter system will have a long service

life.
You are thereby making an important

contribution towards keeping the air clean

and compliance with emissions legislation.
Checking and adjustment of the fuel-

injection and ignition systems is part of the

scope of inspection. For this reason you

should have all maintenance work carried

out at the intervals specified in your Service

Booklet.

Drive Control Systems

Interactive Driving System (= IDS+) 3

IDS+ unites the sensors and control units of

the Electronic Stability Program (ESP®

Plus

),

Anti-lock Brake System (ABS) and

Continuous Damping Control (CDC). This

provides both excellent driving dynamics

and greater safety.
