178

Driving and operation

Starting off

Depress the footbrake, release the

handbrake and move the selector lever

to A,

+

or

-

. Easytronic is in automatic

mode and first gear is engaged (second

gear if the Winter programme is active).

"A1" appears in the transmission display

("A2" if the Winter programme is active).
The vehicle begins to "creep" when the

footbrake is released.

It is also possible to start off without

depressing the footbrake if the accelerator

pedal is operated directly after movement

of the selector lever. If there is no

immediate acceleration or the footbrake is

not depressed, no gear is engaged and "A"

flashes. After a few seconds, the display

resumes showing "N". Start off by

repeating the previously described

procedure.
In Automatic mode, selection of other

gears is automatic irrespective of driving

conditions.
Move selector lever toward A

Switch between Automatic and Manual

mode.
Manual gear shifting is possible in manual

mode. "M" and the currently engaged gear

appear in the transmission display.
If the engine speed is too low the Easytronic

will automatically shift to a lower gear even

in Manual mode. This prevents the engine

from stalling.

Move selector lever toward + or -

If a higher gear is selected when the

running speed is too low, or a lower gear

when the speed is too high, no shift is

effected. This prevents the engine from

running at too low or too high revs.
Gears can be skipped by moving the

selector lever repeatedly at short intervals.

+

Shift to a higher gear

-

Shift to a lower gear

179

Driving and operation

If the vehicle is in automatic mode, on

movement of the selector lever to

+

or

-



Easytronic shifts to manual mode and

changes up or down. "M" and the currently

engaged gear appear in the transmission

display.
Move selector lever toward R

Reverse gear. Engage only when vehicle is

stationary.
Depress the footbrake, release the

handbrake and move the selector lever to

R. Reverse gear is engaged. "R" appears in

the transmission display.
The vehicle begins to "creep" when the

footbrake is released.
It is also possible to start off in reverse

without depressing the footbrake if the

accelerator pedal is operated directly after

movement of the selector lever. If there is

no immediate acceleration or the

footbrake is not depressed, no gear is

engaged and "R" flashes. After a few

seconds, the display resumes showing "N".

Start off by repeating the previously

described procedure.

Electronically controlled driving

programmes

z By means of delayed gear changing

(higher engine speeds) following a cold

start, the operating temperature

programme in automatic mode quickly

and automatically brings the catalytic

converter to the temperature required

for optimum pollutant reduction.

z Adaptive programmes automatically

adapt gear shifting in automatic mode

to suit the driving conditions, such as if

the vehicle is towing a caravan/trailer,

has a high payload, or is being driven on

inclines.

z When SPORT mode is engaged, shift

times are reduced and the transmission

shifts at higher engine speeds (unless

cruise control is on). SPORT mode, see

page 212.

z Winter programme: Press button T, see

next page.

180

Driving and operation

Winter programme T

In the event of difficulties starting off

on slippery roads, press button T

("A", currently engaged gear and T

appear in the transmission display).

Easytronic switches to automatic mode

and the vehicle sets off in second gear.
The winter program is switched off by:

z pressing button T again,

z turning off the ignition.
In order to protect the Easytronic the winter

programme automatically switches itself

off at extremely high clutch temperatures.

If the Winter programme is activated,

SPORT mode is deactivated.
If the vehicle is switched to manual mode

while the winter programme is active, the

winter programme is interrupted. The

winter programme resumes upon return to

automatic mode.

Kickdown

Accelerator pedal pressed past the

pressure point: below certain speeds, the

transmission shifts down into a lower gear.

Full engine power is available for

acceleration.
During kickdown no manual gear shifting is

possible.

181

Driving and operation

When the engine speed approaches its

upper limit, the transmission shifts to a

higher gear during kickdown even in

Manual mode.
Without kickdown this automatic shift is

not effected in Manual mode.
If SPORT mode is engaged, the drive

wheels may spin slightly when starting off

with kickdown. This allows for maximum

acceleration of the vehicle.
Engine braking

Automatic mode:

When driving downhill, Easytronic does not

shift into higher gears until a fairly high

engine speed has been reached. When

braking, Easytronic shifts down in good

time.
Manual mode:

To utilise the engine braking effect, select a

lower gear in good time when driving

downhill.

"Rocking the car"

If it becomes necessary to rock the vehicle

to free it from sand, mud, snow or a hole,

move the selector lever between R and A

(or + or -) in a repeat pattern while applying

light pressure to the accelerator pedal. Do

not race the engine and avoid sudden

acceleration.
This applies only to the exceptional

circumstances mentioned above.

Manoeuvring the vehicle

To manoeuvre the vehicle back and forth

during attempts to park or in garage

entrances the creeping movement can be

utilised by releasing the footbrake.
Never actuate accelerator and brake

pedals simultaneously.
To prevent damage, Easytronic

disengages the "creep function" when the

temperature of the automatic clutch is

high.

182

Driving and operation

Stopping the vehicle

In Automatic or Manual mode, when the

vehicle has stopped first gear (with Winter

mode engaged, second gear) is engaged

automatically and the clutch released. In R

reverse remains engaged.
A warning buzzer sounds when the driver’s

door is opened if the engine is running, a

gear is engaged and the footbrake is not

depressed. The vehicle creeps if the

handbrake is not engaged. Move the

selector lever to N and apply the

handbrake.
When stopping on gradients, engage the

handbrake or depress the brake pedal. To

prevent overheating of the clutch, do not

increase engine speed to ensure smooth

idling when in gear.
To prevent damage to the Easytronic, the

clutch is closed automatically at high

clutch temperatures.
Switch off engine if stopping for a lengthy

period, e.g. in traffic jams or at level

crossings.

Vehicle storage

Before leaving the vehicle:

z Engage handbrake.

z Remove the ignition key or, with the

Open&Start system 3, remove the

electronic key from the vehicle.

The most recently engaged gear (indicator

in transmission display) remains engaged.

With N, no gear is engaged.
When the ignition is switched off the

Easytronic no longer responds to

movement of the selector lever.
Lock the vehicle. Otherwise the battery

may become discharged if the vehicle is

parked for long periods.
If the handbrake has not been applied, the

control indicator R flashes for a few

seconds after the ignition is switched off.
With the engine off and the handbrake not

applied, when the driver’s door is opened a

warning buzzer sounds and the control

indicator R flashes; switch on ignition,

engage gear, switch off ignition and apply

handbrake.

Fault

Control indicator A illuminates in the

event of a fault in the Easytronic system. In

the event of serious faults, "F" also appears

in the transmission display.
It is possible to continue driving if only

control indicator A illuminates. Manual

mode can then no longer be selected.
If "F" appears in the transmission display,

continued driving is not possible.
Have the cause of the fault eliminated by a

workshop. The self-diagnosis integrated

into the system facilitates rapid fault

identification.

183

Driving and operation

Interruption of power supply

The clutch is not disengaged if the vehicle

battery is discharged and a gear has been

selected. The vehicle cannot move.
If the battery is flat, start the vehicle using

jump leads, see page 243.

If the cause of the power failure is not a

discharged battery, contact a workshop. If

the vehicle must be removed from flowing

traffic, release the clutch on vehicles with

5-speed Easytronic. On vehicles with

6-speed Easytronic, the clutch cannot be

released 3; if the vehicle must be moved,

raise vehicle at the front to tow.
To disengage the clutch (only on vehicles

with 5-speed Easytronic)

1. Apply handbrake and switch off ignition.
2. Prop bonnet open, see page 241.

3. Clean Easytronic around the cap (see

figure) so that no dirt can get into the

opening when the cap is removed.

4. Rotate cap to slacken and remove by

lifting upwards, see figure.

5. Turn the adjusting screw clockwise using

a flat-head screwdriver (vehicle tools 3,

see page 251) until clear resistance can

be felt. The clutch has now been

disengaged.
Do not turn beyond the resistance, since

this can damage the Easytronic.

6. Fit cleaned cap again. The cap must be

in full contact with the housing.

Towing the vehicle and starting the engine

is not permitted when the clutch has been

released in this way, although the vehicle

can be moved a short distance.
Contact a workshop immediately for

assistance.

184

Driving and operation

Automatic transmission

3



The automatic transmission 3 allows

automatic selection.
The engine can only be started when the

gear selector is in position P or N. When

starting in position N, depress the

footbrake or apply the handbrake. After

starting the engine, depress the brake

before selecting a gear. Do not accelerate

whilst selecting a gear. If a gear has been

selected and the brake is released, the

vehicle will "creep". Never operate the

accelerator and the brake pedal

simultaneously. The selected gear is

displayed in the transmission display.

Only select 3, 2 or 1 to prevent automatic

upshifting or as an aid in engine braking.

Transmission display

Display of mode or selected gear in left

position of transmission display. The gear

that has been selected by the transmission

appears in the right position of the

transmission display.

Selector lever positions P, R, N and D

9

 Warning

Disregard of these instructions may lead

to injuries or endanger life.

P

Park position

R

Reverse gear

N

Neutral

D

Drive position

3, 2, 1

Selected gear 3

P

Park position. Front wheels locked.

Only engage when the vehicle is

stationary and the handbrake is

applied. "P" appears on the

transmission display.

R

Reverse gear. Only engage when the

vehicle is stationary. "R" appears on

the transmission display.

N

Neutral or idle. "N" appears on the

transmission display.

D

Drive position for normal driving in

1st gear to highest gear. "D" and the

current gear appear in the

transmission display.

185

Driving and operation

The selector lever can only be moved from

P when the ignition is switched on and the

footbrake depressed (selector lever lock).
To engage P or R, push button on selector

lever.
The engine can only be started with lever in

position P or N. When position N is selected,

press footbrake or engage handbrake

before starting.
Do not accelerate during the selection

procedure.

Gears 3, 2, 1

Press button on selector lever to engage 3

or 1.
The current gear is displayed in the

transmission display.

Electronically controlled driving

programmes

z When SPORT mode is engaged, the

transmission shifts at higher engine revs

(unless cruise control is on). Control

indicator 1 illuminates in the

transmission display, see page 184.
SPORT mode, see page 212.

z Winter programme: Press button T, see

next page.

3, 2, 1 Transmission does not shift above

the selected gear

186

Driving and operation

z Automatic neutral shift function

automatically sets the transmission to N

to reduce fuel consumption, e.g. at

traffic lights.
Automatic neutral is activated when the

following occur simultaneously:

As soon as the brake is released and the

accelerator pedal is depressed, the

vehicle starts off in the usual manner.

z The operating temperature programme

automatically brings the catalytic

converter to the temperature that is

required for optimum emission reduction

after a cold start by selecting an

appropriate gear (increased engine

revs).

z The adaptive programme automatically

tailors gearshifting to the driving

conditions, e.g. greater load or

gradients.

Winter programme T

Press button T if you are having problems

starting off on a slippery road surface.
To activate

The winter programme can be activated in

P, R, N, D and 3 (T illuminates in the

transmission display). The vehicle starts off

in 2nd gear.
To deactivate

The winter program is switched off by:

z pressing button T again,

z shifting to 2 or 1 manually,

z turning off the ignition.
In order to prevent damage, the winter

program switches off automatically at high

transmission oil temperatures.

– The selector lever is in automatic

mode 3,

– The selector lever is in position 3, 2

or 1

– The footbrake is depressed
– The vehicle is stationary
– The accelerator pedal is not

actuated

– The transmission fluid temperature

is greater than 0 °C

187

Driving and operation

Kickdown

Depressing the accelerator pedal past the

pressure point: depending on the engine

speed the transmission shifts to a lower

gear. Full engine power is available for

accelerating.

Engine braking

In order to utilise the engine braking

effect when driving downhill, select drive

range 3, 2 or, if necessary, 1 in good time.
Gear 1 has the greatest braking effect. If

gear 1 is selected at too high a speed, the

transmission remains in second gear until

the shift point for first gear is reached,

e.g. as a result of deceleration.

"Rocking the car"

If it becomes necessary to rock the vehicle

to free it from sand, mud, snow or a hole,

move the selector lever from D to R in a

repeat pattern while simultaneously

applying light pressure to the accelerator

pedal. Do not race the engine and avoid

sudden acceleration.
This applies only to the exceptional

circumstances mentioned above.

188

Driving and operation

Manoeuvring the vehicle

To manoeuvre the vehicle back and forth

during attempts to park or in garage

entrances, the vehicle’s creeping

movement can be utilised by releasing the

brake pedal.
Never actuate accelerator and brake

pedals simultaneously.

Stopping the vehicle

The selector lever can be left in the chosen

gear with the engine running.
When stopping on gradients engage

handbrake or depress brake pedal. To

prevent overheating of the transmission,

do not increase engine revolutions to

ensure smooth idling while standing if a

gear has been selected.
Switch off engine if stopping for a lengthy

period, e.g. in traffic jams or at level

crossings.
Before leaving the vehicle, first apply the

handbrake. Then select P. Remove the

ignition key or, with Open&Start system,

remove the electronic key 3 from the

vehicle. Lock the vehicle. Otherwise the

battery may become discharged if the

vehicle is parked up for long periods.
The ignition key can only be removed when

the selector lever is in position P.
With the Open&Start system 3, "P" flashes

in the transmission display for 10 seconds

when the ignition is switched off if P has not

been engaged or the handbrake has not

been applied.

Fault

If there is a problem with the automatic

transmission, control indicator A

illuminates. The transmission no longer

shifts automatically. The vehicle can

continue to be driven.
Illumination of control indicator A may

also indicate a problem with the engine

electronics, see page 206.
For diesel engines

1)

 Z 19 DT and Z 19 DTH,

illumination of control indicator A could

also indicate that the diesel fuel filter must

be drained of water - see page 300.
Have the cause of the fault eliminated by a

workshop.

1)

Sales designation, see page 310 and 311.

189

Driving and operation

The transmission no longer shifts

automatically. Vehicle can continue to be

driven. Second gear is not available.

Forward gears 1, 3 and 4 must be shifted

manually using selector lever:

Interruption of power supply

If the vehicle battery is flat, the selector

lever cannot be moved out of position P.
If the battery is flat, start the vehicle using

jump leads, see page 243.
If the battery is not the cause of the fault,

release selector lever:
1. Apply handbrake.
2. Release selector lever trim from centre

console at rear, fold upwards and rotate

to the left.

3. Push the yellow catch forward with a

screwdriver and move the selector lever

out of P.

4. Mount selector lever trim on centre

console and refit.

Reselecting P causes locking again. Have a

workshop eliminate the cause of the power

loss.

1

= 1st gear

2

= 3rd  gear

3, D = 4th  gear

190

Driving and operation

Automatic transmission with

ActiveSelect

3



This automatic transmission 3 allows

both automatic gearchanges (automatic

mode) and manual gearchanges (manual

mode) 3.
The engine can only be started when the

selector lever is in position P or N. When

starting in position N, depress the

footbrake or apply the handbrake. After

the engine has started, depress the brake

before selecting a gear. Do not accelerate

whilst selecting a gear. If a gear has been

selected and the brake is released, the

vehicle will "creep". Never operate the

accelerator and the brake pedal

simultaneously. The selected gear is

displayed in the transmission display,

see page 184.

Selecting D puts the transmission in

automatic mode.
If the selector lever is moved to the left from

the D position, manual mode is activated.

Gearchanges can then be made manually

by tipping the selector lever toward + or -.

Transmission display

Display of mode or selected gear in left

position of transmission display. The gear

that has been selected by the transmission

appears in the right position of the

transmission display.

9

 Warning

Disregard of these instructions may lead

to injuries or endanger life.

P

Park position

R

Reverse gear

N

Neutral

D

Automatic mode

M

Manual mode with display of

selected gear

191

Driving and operation

Selector lever settings P, R, N and D

(automatic mode)

The selector lever can only be moved out of

position P or N with the ignition switched on

and the footbrake applied (selector lever

lock). In selector lever position N the

selector lever lock is activated after a delay

and only if the vehicle is stationary.

In position P or N, control indicator

j



illuminates red in the selector lever

indicator strip if the selector lever is

blocked.
To engage P or R, push button on selector

lever.
The engine can only be started with lever in

position P or N. When position N is selected,

press footbrake or engage handbrake

before starting.
Do not accelerate during the selection

procedure.

P

Park position. Front wheels locked.

Only engage when the vehicle is

stationary and the handbrake is

applied. "P" appears on the

transmission display.

R

Reverse gear. Only engage when the

vehicle is stationary. "R" appears on

the transmission display.

N

Neutral or idle. "N" appears on the

transmission display.

D

Drive position for normal driving in 1st

gear to highest gear. "D" and the

current gear appear in the

transmission display.

192

Driving and operation

ActiveSelect (manual mode)

Move selector lever out of position D and

then forwards or backwards.

If a higher gear is selected at a speed that

is too slow or a lower gear is selected at a

speed that is too high, the gear will not be

changed. This prevents the revs from being

too low or too high.

If the engine speed is too slow, the

transmission automatically shifts down,

but not if the gear was selected below a

certain speed.
If a higher gear is selected below a certain

speed, the transmission does not shift

back.
No automatic shifting to a higher gear

takes place at high engine revs.
For safety reasons, kickdown is also

available in manual mode, see page 194.
The selected gear is displayed in the

transmission display, see page 184.

Electronically controlled driving

programmes

z When SPORT mode is engaged, the

transmission shifts at higher engine revs

(unless cruise control is on). Control

indicator 1 illuminates in the

transmission display, see page 190.
SPORT mode, see page 212.

z Winter programme: Press button T,

see next page.

+

Shift to a higher gear

-

Shift to a lower gear

193

Driving and operation

z Automatic neutral shift function

automatically sets the transmission to N

to reduce fuel consumption, e.g. at

traffic lights.
Automatic neutral is activated when the

following occur simultaneously:

As soon as the brake is released and the

accelerator pedal is depressed, the

vehicle starts off in the usual manner.

z The operating temperature programme

automatically brings the catalytic

converter to the temperature that is

required for optimum emission reduction

after a cold start by selecting an

appropriate gear (increased engine

revs).

z The adaptive programme automatically

tailors gearshifting to the driving

conditions, e.g. greater load or

gradients.

Winter programme T

Press button T if you are having problems

starting off on a slippery road surface.
To activate

The winter programme can be operated in

automatic mode (T illuminates in

transmission display, see page 190). The

vehicle starts off in 2nd or 3rd gear

depending on the nature of the road

surface.

– The selector lever is in automatic or

manual mode

– The footbrake is depressed
– The vehicle is stationary
– The accelerator pedal is not

actuated

– The transmission fluid temperature

is greater than 0 °C
