Saturn Outlook (2010 year). Manual

Keys, Doors and Windows

2-21

2. Press and continue to hold the

window switch until the window
is fully open.

3. Pull up and hold the window

switch to close the window.
Continue to hold it briefly after
the window is fully closed.

4. Repeat for each window that has

the express-up feature.

Anti-Pinch Feature

The anti-pinch feature is on
windows with the express-up
feature. If an object is in the way of
the window as it is express-closing,
or in certain weather conditions like
severe icing, the window will stop
and open to a factory preset
position. The window functions
normally once the obstruction is
removed.

Window Lockout

o (Window Lockout): The window
lockout switch is located with the
power window switches on the
driver door armrest. This feature
prevents the rear windows from
being operated, except from the
driver position. Press the switch to
turn the lockout feature on or off. An
indicator light will come on to show
the lockout feature is on.

Sun Visors

Pull the sun visor down to block
glare. Detach the sun visor from the
center mount and slide it along the
rod from side-to-side to cover the
driver or passenger side of the front
window. Swing the sun visor to the
side to cover the side window. It can
be moved along the rod from
side-to-side in this position also.

Lighted Visor Vanity Mirror

The vehicle has lighted visor vanity
mirrors on both the driver and
passenger sun visors. Pull the sun
visor down and lift the mirror cover
to turn the lamps on.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-22

Keys, Doors and Windows

Roof

Sunroof

The ignition must be in ON/RUN or
ACC/ACCESSORY to operate the
sunroof and power sunshade. See
Retained Accessory Power (RAP)
on page 9‑17

The vehicle may have a sunroof
over the front seats and a rear
sunroof over the second row seats.
The rear sunroof does not open.
The switch to operate the front
sunroof is on the headliner above
the rearview mirror.

Vent: From the closed position,
press and hold the front of the
switch to vent the sunroof. Press
and hold the rear of the switch to
close the sunroof.

Express-open/Express-close:
From the closed position, press and
release the rear of the switch to
express-open the sunroof. Press
and release the front of the switch to
express-close the sunroof.

The front sunshade must be opened
and closed manually. Push up on
the sunshade handle to open the
sunshade.

Manual Sunshades

On a vehicle with only manual
sunshades, press the button on the
sunshade handle to release it and
guide it back. Pull the sunshade
forward until it latches to close it.

Rear Power Sunshade

On vehicles with a rear power
sunshade, the switch is on the
headliner above the rearview mirror.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Keys, Doors and Windows

2-23

Notice: The rear sunshade could
be damaged if you attempt to
open or close it manually. Do not
manually open or close the rear
sunshade.

To open the rear sunshade, located
over the second row seats, press
and release the rear of the switch.
Press and release the front of the
switch to close the sunshade.

Do not keep the sunroof open for
long periods of time while the
vehicle is not in use. Debris can
collect in the tracks, damage the
sunroof operation and plug the
water draining system.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-2

Seats and Restraints

Head Restraints

The vehicle's front seats have
adjustable head restraints in the
outboard seating positions.

{

WARNING

With head restraints that are not
installed and adjusted properly,
there is a greater chance that
occupants will suffer a neck/
spinal injury in a crash. Do not
drive until the head restraints for
all occupants are installed and
adjusted properly.

Adjust the head restraint so that the
top of the restraint is at the same
height as the top of the occupant's
head. This position reduces the
chance of a neck injury in a crash.

1. Pull the head restraint up to

raise it. To lower the head
restraint, press the release
button, located on the head
restraint post on the top of the
seatback, while you push the
head restraint down.

2. Push down on the head restraint

after the button is released to
make sure that it is locked in
place.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and Restraints

3-3

Front Seats

Seat Adjustment

{

WARNING

You can lose control of the
vehicle if you try to adjust a
manual driver's seat while the
vehicle is moving. The sudden
movement could startle and
confuse you, or make you push a
pedal when you do not want to.
Adjust the driver's seat only when
the vehicle is not moving.

A. Manual Seat Adjustment Handle

B. Driver Seat Height Adjuster.

C. See Reclining Seatbacks on

page 3‑6.

To adjust a manual seat:

1. Lift the handle (A) under the seat

to unlock it.

2. Slide the seat and release the

handle.

Try to move the seat to be sure it is
locked in place.

To manually raise or lower the seat,
move the lever (B) repeatedly
upward or downward.

Power Seat Adjustment

Driver Seat with Power Seat

Control, Power Recline,

and Power Lumbar shown

A. Power Seat Adjustment Control

B. Reclining Seatbacks on

page 3‑6.

C. Lumbar Adjustment on

page 3‑5.

On vehicles with power seats, the
controls are located on the outboard
side of the seats.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-4

Seats and Restraints

Move the seat forward or rearward
by sliding the power seat
adjustment control (A) forward or
rearward.

The vehicle may have additional
features to adjust the power seat:

Raise or lower the entire seat by
moving the power seat
adjustment control (A) up
or down.

Raise or lower the front part of
the seat cushion by moving the
front of the control up or down.

Raise or lower the rear part of
the seat cushion by moving the
rear of the control up or down.

Memory Seat and Mirrors

On vehicles with the memory
package, the controls for this
feature are located on the driver
door panel. The controls are used to
program and recall memory settings
for the driver seat and outside
mirrors.

To save positions in memory:

1. Adjust the driver seat, including

the seatback recliner and both
outside mirrors to a comfortable
position.

See Power Mirrors on
page 2‑16 for more information.

Not all mirrors will have the
ability to save and recall the
mirror positions.

2. Press and hold button 1 until two

beeps let you know that the
position has been stored.

A second seating and mirror
position can be programmed by
repeating the above steps and
pressing button 2.

To recall the memory positions, the
vehicle must be in P (Park). Press
and release either button 1 or
button 2 corresponding to the
desired driving position. The seat
and outside mirrors will move to the
position previously stored. You will
hear a single beep.

Using the Remote Keyless
Entry (RKE) transmitter to enter the
vehicle, with the remote recall
memory feature on, causes
automatic seat and mirror
adjustment.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and Restraints

3-5

There is no adjustment when the
position has not been changed by
another seating position or the easy
exit feature. See “MEMORY SEAT
RECALL” under Vehicle
Personalization (With DIC Buttons)
on page 5‑42 for more information.

To stop recall movement of the
memory feature at any time, press
one of the power seat controls,
memory buttons, or power mirror
buttons.

If something has blocked the driver
seat while recalling a memory
position, the driver seat recall may
stop working. If this happens, press
the appropriate control for the area
that is not recalling for two seconds,
after the obstruction is removed.
Then try recalling the memory
position again by pressing the
appropriate memory button. If the
memory position is still not being
recalled, see your dealer/retailer for
service.

Easy Exit Seat

The control for this feature is
located on the driver door panel
between buttons 1 and 2.

With the vehicle in P (Park), the exit
position can be recalled by pressing
the exit button. You will hear a
single beep. The driver seat will
move back.

If the easy exit seat feature is on in
the Driver Information Center (DIC),
automatic seat movement will occur
when the key is removed from the
ignition. See “EASY EXIT SEAT”
under Vehicle Personalization (With
DIC Buttons) on page 5‑42 for
more information.

Further programming for the
memory seat feature can be done
using the DIC. You can select or
cancel the following:

The automatic easy exit seat
feature.

The remote memory seat recall
feature.

For programming information, see
Vehicle Personalization (With DIC
Buttons) on page 5‑42.

Lumbar Adjustment

Manual Lumbar

On vehicles with this feature, the
handle is located on the inboard
side of the seatback.

Move the handle forward or
rearward to increase or decrease
lumbar support.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-6

Seats and Restraints

Power Lumbar

On vehicles with power lumbar, the
control is located on the outboard
side of the seat. See “Power
Lumbar” under Power Seat
Adjustment on page 3‑3 for more
information.

To increase or decrease lumbar
support, press and hold the front or
rear of the control (C).

Release the control when the
seatback reaches the desired level
of lumbar support.

Reclining Seatbacks

Manual Reclining Seatbacks

{

WARNING

{

WARNING

If either seatback is not locked, it
could move forward in a sudden
stop or crash. That could cause
injury to the person sitting there.
Always push and pull on the
seatbacks to be sure they are
locked.

In vehicles with seats that have
manual reclining seatbacks, the
lever used to operate them is
located on the outboard side of the
seat. See Seat Adjustment on
page 3‑3.

To recline the seatback:

1. Lift the recline lever (C).

2. Move the seatback to the

desired position, then release
the lever to lock the seatback in
place.

3. Push and pull on the seatback to

make sure it is locked.

To return the seatback to an upright
position, do the following:

1. Lift the lever fully without

applying pressure to the
seatback and the seatback will
return to the upright position.

2. Push and pull on the seatback to

make sure it is locked.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and Restraints

3-7

Power Reclining Seatbacks

In vehicles with seats that have
power reclining seatbacks, the
control used to recline them is
located on the outboard side of the
seat. See Power Seat Adjustment
on page 3‑3 for more information.

To recline the seatback:

Tilt the top of the control (B)
rearward.

To bring the seatback forward,
tilt the top of the control forward.

{

WARNING

Sitting in a reclined position when
the vehicle is in motion can be
dangerous. Even when buckled
up, the safety belts cannot do
their job when reclined like this.

The shoulder belt cannot do its
job because it will not be against
your body. Instead, it will be in
front of you. In a crash, you could
go into it, receiving neck or other
injuries.

The lap belt cannot do its job
either. In a crash, the belt could
go up over your abdomen. The
belt forces would be there, not at
your pelvic bones. This could
cause serious internal injuries.

For proper protection when the
vehicle is in motion, have the
seatback upright. Then sit well
back in the seat and wear the
safety belt properly.

Do not have a seatback reclined if
your vehicle is moving.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-8

Seats and Restraints

Heated Front Seats

{

WARNING

If you cannot feel temperature
change or pain to the skin, the
seat heater may cause burns
even at low temperatures. To
reduce the risk of burns, people
with such a condition should use
care when using the seat heater,
especially for long periods of
time. Do not place anything on
the seat that insulates against
heat, such as a blanket, cushion,
cover or similar item. This may
cause the seat heater to
overheat. An overheated seat
heater may cause a burn or may
damage the seat.

On vehicles with heated front seats,
the controls are located on the
center console. To operate the
heated seats the engine must be
running.

I (Heated Seatback): Press to
turn on the heated seatback.

J (Heated Seat and Seatback):
Press to turn on or off the heated
seat and seatback.

The light on the button will come on
to indicate that the feature is on.
Each time the button is pressed, the
temperature settings change from
high, to medium, to low, to off.
Indicator lights above the button will
show the level of heat selected:
three for high, two for medium, and
one for low.

The passenger seat may take
longer to heat up.

If the vehicle has remote vehicle
start and is started using the RKE
transmitter, the front heated seats
will be turned on to the high setting
if it is cold outside. See “Remote
Vehicle Start” under Remote
Keyless Entry (RKE) System
Operation on page 2‑3. When the
ignition is turned on, the heated seat

feature will turn off. To turn the
heated seat feature back on, press
the desired button.

Heated and Ventilated
Front Seats

{

WARNING

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and Restraints

3-9

On vehicles with the heated and
ventilated seat feature, the controls
are located on the front doors near
the door handle.

(Ventilated Seat): Press to

ventilate the entire seat.

This symbol appears on the climate
control display to indicate that the
feature is on.

(Heated Seat and Seatback):

Press to heat the entire seat.

This symbol appears on the climate
control display to indicate that the
feature is on.

For either feature press the button
once for the highest setting. With
each press of the switch, the seat
changes to the next lower setting,
and then the off setting. The lights
indicate three for the highest setting
and one for the lowest.

The heated and ventilated seats are
canceled after the ignition is turned
off. To use the heated and ventilated
seat feature after the vehicle is
started, you will need to press the
appropriate seat button again.

Rear Seats

A. Seat Adjustment Handle

B. Reclining Seatback Strap

C. Sliding Seat Lever

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-10

Seats and Restraints

Entering and Exiting the
Third Row

{

WARNING

Using the third row seating
position while the second row is
folded, or folded and tumbled,
could cause injury in a sudden
stop or crash. Be sure to return
the seat to the passenger seating
position. Push and pull on the
seat to make sure it is locked into
place.

Notice: Folding a rear seat with
the safety belts still fastened may
cause damage to the seat or the
safety belts. Always unbuckle the
safety belts and return them to
their normal stowed position
before folding a rear seat.

To access the third row:

1. Remove objects on the floor in

front of or on the second row
seat, or in the seat tracks on the
floor.

2. Move the front center console

armrest completely forward. See
Center Console Storage on
page 4‑1.

3. Place folding armrests in the

upright position.

4. Ensure that the safety belt is

unfastened and in the stowed
position.

5. Pull the sliding seat lever (C)

forward and move the seatback
forward. The seat cushion will
fold, and the entire seat will slide
forward.

Returning the Seat to the
Seating Position

To return the second row seat to its
normal seating position:

1. Remove objects on the floor

behind the second row seat or in
the seat tracks on the floor.

2. Pull the seatback rearward until

it is locked in place.

3. Slide the seat rearward by

pushing on the seatback until it
is locked into place.

4. Push down on the rear of the

seat cushion until it is locked in
place.

5. Push and pull on the seatback

and seat cushion to make sure
they are locked in place.

6. Check that the safety belt is not

under the seat cushion.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and Restraints

3-11

Reclining the Seatbacks

To recline the seatback:

1. Leaning forward in the seat, pull

the reclining seatback strap (B).

2. Move the seatback to the

desired position, then release
the strap to lock the seatback in
place.

3. Push and pull on the seatback to

make sure it is locked.

Folding the Rear Seat

To fold the second row seats:

1. Remove anything on or under

the seat.

2. Place the armrest in the upright

position, and unfasten the
safety belt.

3. Pull forward on the reclining

seatback strap (B) and push
down on the seatback.

If the headrest touches the front
seat, slide the second row seat
rearward.

To return the seatback to the
seating position, lift the upper corner
of the seatback and push it
rearward until it locks into place.
Push and pull on the seatback to
make sure it is locked.

Adjusting the Seats

To adjust the second row seats, pull
outward on the seat adjustment
handle (A). Slide the seat forward or
rearward to the desired position.
Release the handle and push and
pull on the seat to make sure it is
locked.

Third Row Seats

{

WARNING

Using the third row seating
position while the second row is
folded, or pushed forward in the
entry position, could cause injury
in a sudden stop or crash. Be
sure to return the seat to the
passenger seating position. Push
and pull on the seat to make sure
it is locked into place.

The third row seats can be folded
forward or removed.

To fold the seatback:

1. Remove anything on or under

the seat.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-12

Seats and Restraints

2. Disconnect the rear safety belt

mini-latch, using a key in the slot
on the mini-buckle, let the belt
retract into the headliner. Stow
the mini-latch in the holder
located in the headliner.

3. Pull up on the release lever

located on the back of the seat.
The headrest moves forward
automatically.

4. Push the seatback forward to

lay flat.

To return the seatback to the
seating position:

1. Raise the seatback into place by

using the pullstrap from the rear
of the vehicle, or by pushing it
into place from inside the
vehicle.

2. The headrest must be locked

into place before sitting in
the seat.

{

WARNING

3. Push and pull on the seatback to

make sure it is locked in place.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and Restraints

3-13

{

WARNING

A safety belt that is improperly
routed, not properly attached,
or twisted will not provide the
protection needed in a crash. The
person wearing the belt could be
seriously injured. After raising the
rear seatback, always check to be
sure that the safety belts are
properly routed and attached, and
are not twisted.

4. Reconnect the center safety belt

mini-latch to the mini-buckle. Do
not let it twist.

5. Pull on the safety belt to be sure

the mini-latch is secure.

Removing the Third Row Seats

1. Remove the cargo management

system, if it is in the vehicle. See
Cargo Management System on
page 4‑3.

2. Remove anything on or under

the seat.

3. Fold the seatback down. See

“Folding the Seatback” earlier in
this section.

4. Remove the rear bolts located

on the floor on each side of
the seat.

5. Remove the seat by tilting it

slightly upward, and then pulling
it out of the rear of the vehicle in
one motion.

6. Replace the bolts in the floor

holes for storage.

Installing the Third Row Seats

1. Before installing the seat the

seatback must be folded
forward. See “Folding the
Seatback” earlier in this section.

The seats must be placed in the
proper locations to attach
correctly. The wider seat must
be installed on the driver side
and the narrower seat on the
passenger side. Remove the
bolts from the holes in the floor
before installing the seats.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Saturn Outlook (2010 year). Manual - part 4
