MINI 3 door (2016 year). Manual - part 6





-------------------------------------------------------------------------------------------------------------------------------------------------------------

Lights
CONTROLS
The indicator lamp in the instrument
Fog lights
cluster is illuminated, when the low
beams are switched on.
Front fog lights
The high beams are switched on and off auto-
The low beams must be switched on.
matically.
Press button. The green indicator lamp
The blue indicator lamp in the instru-
lights up.
ment cluster lights up when the system
If the automatic headlight control, refer to
switches on the high beams.
page 99, is activated, the low beams will come
on automatically when you switch on the front
Deactivating
fog lights.
The High-beam Assistant is deactivated when
When the high beams or headlight flasher are
manually switching the high beams on and off,
activated, the front fog lights are not switched
refer to page 70.
on.
To reactivate the High-beam Assistant, press
the button on the turn signal lever.
Rear fog lights
The low beams or front fog lights must be
System limits
switched on.
The High-beam Assistant cannot serve as a
Press button. The yellow indicator
substitute for the driver's personal judgment of
lamp lights up.
when to use the high beams. Therefore, man-
ually switch off the high beams in situations
If the automatic headlight control, refer to
where required to avoid a safety risk.
page 99, is activated, the low beams will come
The system is not fully functional in the follow-
on automatically when you switch on the rear
ing situations, and driver intervention may be
fog lights.
necessary:
In very unfavorable weather conditions,
such as fog or heavy precipitation.
Instrument lighting
When detecting poorly-lit road users such
Adjusting
as pedestrians, cyclists, horseback riders
and wagons; when driving close to train or
The parking lights or low beams
ship traffic; and at animal crossings.
must be switched on to adjust
In tight curves, on hilltops or in depressions,
the brightness.
in cross traffic or half-obscured oncoming
Adjust the brightness with the
traffic on highways.
thumbwheel.
In poorly-lit towns and cities and in the
presence of highly reflective signs.
When the windshield behind the interior
mirror is fogged over, dirty or covered with
stickers, etc.
101

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Lights
Activating/deactivating
Interior lights
On the Control Display:
General information
1.
"Settings"
Depending on the equipment, the interior
2. "Lighting"
lights, footwell lights, entry lamps, and courtesy
3. "Ambient:"
lamps are controlled automatically.
Settings are stored for the profile currently
Thumb wheel for the instrument lighting con-
used.
trols brightness of some of these features.
Changing color
Overview
Push the switch forward or back:
manual color change.
Push and hold the switch forward or
back: automatic color change. Push
the switch again to end color changes.
Setting the brightness
Depending on the equipment, the brightness of
1
Interior lights
the ambient light can be adjusted via the
thumbwheel for the instrument lighting or on
2
Reading lights
the Control Display.
3
Ambient light
On the Control Display:
1.
"Settings"
Switching the interior lights on and off
2. "Lighting"
Press button.
3. "Brightness:"
To switch off permanently: press the button for
4. Adjust the brightness.
approx. 3 seconds.
Switch back on: press button.
Switching the reading lamps on and off
manually
Press button.
Reading lights are located in the front next to
the interior light.
Ambient light
Depending on your optional features lighting
can be adjusted for some lights in the interior.
102

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety
CONTROLS
Safety
necessarily available in your vehicle, e. g., due
Vehicle features and op-
to the selected options or country versions. This
tions
also applies to safety-related functions and sys-
tems. When using these functions and systems,
This chapter describes all standard, country-
the applicable country provisions must be ob-
specific and optional features offered with the
served.
series. It also describes features that are not
Airbags
1
Front airbag, driver
4
Side airbag
2
Front airbag, front passenger
5
Knee airbag
3
Head airbag
Front airbags
Side airbag
Front airbags help protect the driver and front
In a lateral impact, the side airbag supports the
passenger by responding to frontal impacts in
side of the body in the chest and lap area.
which safety belts alone would not provide ad-
equate restraint.
Head airbag
In a lateral impact, the head airbag supports
the head.
103

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Safety
Ejection Mitigation
Do not apply adhesive materials to the air-
bag cover panels, do not cover them or
The head airbag system is designed as an ejec-
modify them in any way.
tion mitigation countermeasure to reduce the
likelihood of ejections of vehicle occupants
Dashboard and windshield on the front
through side windows during rollovers or side
passenger side must stay clear - do not at-
impact events.
tach adhesive labels or coverings and do
not attach brackets or cables, for instance
Knee airbag
for GPS devices or mobile phones.
The knee airbag supports the legs in a frontal
Do not use the cover of the front airbag on
impact.
the front passenger side as a storage area.
Do not place slip covers, seat cushions or
Protective action
other objects on the front passenger seat
Airbags are not triggered in every impact situa-
that are not specifically suited for seats with
tion, e.g., in less severe accidents or rear-end
integrated side airbags.
collisions.
Do not hang pieces of clothing, such as
jackets, over the backrests.
Information on optimum effect of the
Never modify either the individual compo-
airbags
nents or the wiring in the airbag system.
WARNING
This also applies to steering wheel covers,
If the seat position is incorrect or the de-
the dashboard, and the seats.
ployment area of the airbags is impaired, the
Do not remove the airbag system.
airbag system cannot protect as intended or
Even when you follow all instructions very
may cause additional injuries due to triggering.
closely, injury from contact with the airbags
There is a risk of injuries or danger to life. Fol-
cannot be fully ruled out in certain situations.
low the information on optimum protective ef-
The ignition and inflation noise may lead to
fect of the airbag system.
short-term and, in most cases, temporary hear-
Keep a distance from the airbags.
ing impairment in sensitive occupants.
Make sure that occupants keep their heads
Vehicle modifications for a person with disabili-
away from the side airbag.
ties may affect the air bag system; therefore,
Always grasp the steering wheel on the
contact MINI Customer Relations or your au-
steering wheel rim. Hold your hands at the
thorized MINI service center.
3 o'clock and 9 o'clock positions, to keep
Warnings and information on the airbags are
the risk of injury to your hands or arms as
also found on the sun visors.
low as possible when the airbag is trig-
gered.
Make sure that the front passenger is sitting
correctly, i.e., keeps his or her feet and legs
in the floor area and does not support them
on the dashboard.
There should be no additional persons, ani-
mals or objects between an airbag and a
person.
104

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety
CONTROLS
Functional readiness of the airbag
Front, knee and side airbag on the front pas-
system
senger's side are either activated or deacti-
vated.
Safety information
General information
WARNING
Before transporting a child on the front passen-
Individual components can be hot after
ger seat, refer to the safety notes and instruc-
triggering of the airbag system. There is a risk
tions for children on the front passenger seat,
of injury. Do not touch individual compo-
see Children.
nents.
WARNING
Safety information
Improperly executed work can lead to
WARNING
failure, malfunction or unintentional triggering
To ensure the front-seat passenger airbag
of the airbag system. In the case of a malfunc-
function, the system must be able to detect
tion, the airbag system might not trigger as in-
whether a person is sitting in the front passen-
tended in the event of an accident despite re-
ger seat. The entire seat cushion area must be
spective accident severity. There is a risk of
used for this purpose. There is a risk of injuries
injuries or danger to life. Have the airbag sys-
or danger to life. Make sure that the front pas-
tem checked, repaired, dismantled and scrap-
senger keeps his or her feet in the floor area.
ped by a dealer’s service center or another
qualified service center or repair shop.
Malfunction of the automatic
deactivation system
Correct function
When transporting older children and adults,
When the ignition is switched on, the
the front-seat passenger airbags may be deac-
warning lamp in the instrument cluster
tivated in certain sitting positions. In this case,
lights up briefly and thereby indicates
the indicator lamp for the front-seat passenger
the operational readiness of the entire airbag
airbags lights up.
system and the belt tensioner.
In this case, change the sitting position so that
the front-seat passenger airbags are activated
Airbag system malfunctioning
and the indicator lamp goes out.
Warning lamp does not come on when the
If it is not possible to activate the airbags, have
ignition is turned on.
the person sit in the rear.
The warning lamp lights up continuously.
To enable correct recognition of the occupied
seat cushion.
Automatic deactivation of the front-
Do not attach covers, cushions, ball mats or
seat passenger airbags
other items to the front passenger seat un-
less they are specifically determined to be
The concept
safe for use on the front passenger seat.
The system reads if the front passenger seat is
Do not place any electronic devices on the
occupied by measuring the human body's re-
passenger seat if a child restraint system is
sistance.
to be installed on it.
Do not place objects under the seat that
could press against the seat from below.
105

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Safety
No moisture in or on the seat.
Strength of the driver's and front-seat
passenger airbag
Indicator lamp for the front-seat
The explosive power that activates driver's/
passenger airbags
front passenger's airbags very much depends
on the positions of the driver's/front passeng-
er's seat.
To maintain the accuracy of this function over
the long-term, calibrate the front seats as soon
as a relevant Check Control message is dis-
played. A message also appears on the Control
Display.
Calibrating the front seats
The indicator lamp for the front-seat passenger
WARNING
airbags indicates the operating state of the
There is a risk of jamming when moving
front-seat passenger airbags.
the seats. There is a risk of injury or risk of
The lamp indicates whether the airbags are ei-
property damage. Make sure that the area of
ther activated or deactivated.
movement of the seat is clear prior to any ad-
justment.
The indicator lamp lights up
when a child is properly
An appropriate Check Control message is dis-
seated in a child restraint fix-
played.
ing system or when the seat
1. Move the respective seat all the way for-
is empty. The airbags on the
ward.
front passenger side are not
activated.
2. Move the respective seat forward again. It
moves forward briefly.
The indicator lamp does not light up when,
for example, a correctly seated person of
3. Readjust the seat to the desired position.
sufficient size is detected on the seat. The
The calibration procedure is completed when
airbags on the front passenger side are ac-
the Check Control message disappears.
tivated.
If the message continues to be displayed, re-
peat the calibration.
Detected child seats
If the message does not disappear after a re-
The system generally detects children seated in
peat calibration, have the system checked as
a child seat, particularly in child seats required
soon as possible.
by NHTSA when the vehicle was manufactured.
After installing a child seat, make sure that the
indicator lamp for the front-seat passenger air-
Tire Pressure Monitor
bags lights up. This indicates that the child seat
has been detected and the front-seat passen-
TPM
ger airbags are not activated.
The concept
The system monitors tire inflation pressure in
the four mounted tires. The system warns you if
106

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety
CONTROLS
there is a significant loss of pressure in one or
All wheels are yellow
more tires. For this purpose, sensors in the tire
A flat tire or major drop in inflation pressure in
valves measure the tire inflation pressure.
several tires.
General information
Wheels, gray
With use of the system observe further infor-
The system cannot detect a flat tire due to a
mation found under Tire inflation pressure, re-
malfunction.
fer to page 186.
Status information
Functional requirements
The status control display additionally shows
The system must have been reset with the cor-
the current tire inflation pressures. It shows the
rect tire inflation pressure; otherwise, reliable
actual values read; they may vary depending
signaling of tire pressure loss is not assured.
on driving style or weather conditions.
Reset the system after each adjustment of the
tire inflation pressure and after every tire or
Reset the system
wheel change.
Reset the system after each adjustment of the
Always use wheels with TPM electronics to en-
tire inflation pressure and after every tire or
sure that the system will operate properly.
wheel change.
On the Control Display and on the vehicle:
Status display
1.
"Vehicle info"
The current status of the Tire Pressure Monitor
TPM can be displayed on the Control Display,
2. "Vehicle status"
e.g., whether or not the TPM is active.
3.
"Perform reset"
On the Control Display:
4. Start the engine but do not drive off.
1.
"Vehicle info"
5. Reset the tire inflation pressure using
"Perform reset".
2. "Vehicle status"
6. Drive away.
3.
"Tire Pressure Monitor (TPM)"
The tires are shown in gray and the status is
The status is displayed.
displayed.
After driving faster than 19 mph/30 km/h for a
Status control display
short period, the set tire inflation pressures are
Tire and system status are indicated by the
accepted as reference values. The resetting
color of the tires and a SMS text message on
process is completed automatically while driv-
the Control Display.
ing. After successful completion of the reset,
the tires appear in green on the Control Display
All wheels green
and "Tire Pressure Monitor (TPM) active" is dis-
System is active and will issue a warning based
played.
on the tire inflation pressures stored during the
The progress of the reset is displayed.
last reset.
You may interrupt this trip at any time. When
you continue the reset resumes automatically.
One wheel is yellow
A flat tire or major drop in inflation pressure in
the indicated tire.
107

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Safety
Messages
3. Reset the system.
Required tire inflation pressure check
Message in case of sharp tire inflation
message
pressure loss
A Check Control message is displayed.
The yellow warning lamp lights up.
The system has detected a wheel
A symbol with the affected tires will be
change, but no reset was done.
displayed in the Check Control mes-
sage.
No reset was performed for the system. The
system issues a warning based on the tire
There is a flat tire or a major loss in tire in-
inflation pressures stored during the last re-
flation pressure.
set.
No reset was performed for the system. The
Inflation was not carried out according to
system issues a warning based on the tire
specifications.
inflation pressures stored during the last re-
set.
A Check Control message is displayed.
In these cases:
The tire inflation pressure has fallen be-
low the level of the last reset.
1. Reduce your speed and stop cautiously.
Avoid sudden braking and steering maneu-
In these cases:
vers.
1. Check the tire pressure and correct as
2. Check whether the vehicle is fitted with
needed.
normal tires or run-flat tires.
2. Reset the system.
Run-flat tires, refer to page 196, are la-
beled with a circular symbol containing the
Message in case of low tire pressure
letters RSC marked on the tire's sidewall.
The yellow warning lamp lights up.
WARNING
A damaged regular tire with low or miss-
ing tire inflation pressure impacts handling,
A Check Control message is displayed.
such as steering and braking response. Run-flat
tires can maintain limited stability. There is a
risk of an accident. Do not continue driving if
There is a tire inflation pressure loss.
the vehicle is not equipped with run-flat tires.
No reset was performed for the system. The
Follow the information on run-flat tires and
system issues a warning based on the tire
continued driving with these tires.
inflation pressures stored during the last re-
A low tire inflation pressure might turn on DSC
set.
Dynamic Stability Control.
In these cases:
1. Reduce your speed and drive moderately.
Actions in the event of a flat tire
Do not exceed a speed of
80 mph/130 km/h.
Normal tires
2. At the next opportunity, e.g., gas station,
1. Identify the damaged tire.
check and correct the tire inflation pressure
in all four tires, if necessary.
108

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety
CONTROLS
Check the air pressure in all four tires, e.g.
A vehicle with an average load has a possible
using the tire pressure gage of a tire repair
driving range of approx. 50 miles/80 km.
kit.
A vehicle with a damaged tire reacts differently,
If the tire inflation pressure in all four tires is
e.g., it has reduced lane stability during brak-
correct, the Tire Pressure Monitor may not
ing, a longer braking distance and different
have been initialized. In this case, initialize
self-steering properties. Adjust your driving
the system.
style accordingly. Avoid abrupt steering ma-
neuvers or driving over obstacles, e.g., curbs,
If identification of flat tire damage is not
potholes, etc.
possible, please contact a dealer’s service
center or another qualified service center or
Because the possible driving distance depends
repair shop.
on how the vehicle is used during the trip, the
actual distance may be shorter or longer de-
2. Repair the flat tire, e.g. with a tire repair kit
pending on the driving speed, road conditions,
or by changing the tire.
external temperature, cargo load, etc.
Use of tire sealant, for example, the Mobility
System, may damage the TPM wheel electron-
WARNING
ics. In this case, have the electronics checked at
Your vehicle handles differently when a
the next opportunity and have them replaced if
run-flat tire is damaged and has low or missing
needed.
tire inflation pressure, e.g., your lane stability is
reduced when braking, braking distances are
Run-flat tires
longer and the self-steering properties will
change. There is a risk of an accident.
Maximum speed
Drive moderately and do not exceed a speed of
You may continue driving with a damaged tire
50 mph/80 km/h.
at speeds up to 50 mph/80 km/h.
Final tire failure
Continued driving with a flat tire
Vibrations or loud noises while driving can indi-
If continuing to drive with a damaged tire:
cate the final failure of a tire.
1. Avoid sudden braking and steering maneu-
Reduce speed and stop; otherwise, pieces of
vers.
the tire could come loose and cause an acci-
2. Do not exceed a speed of 50 mph/80 km/h.
dent.
3. Check the air pressure in all four tires at the
Do not continue driving. Contact a dealer’s
next opportunity.
service center or another qualified service cen-
ter or repair shop.
If the tire inflation pressure in all four tires is
shown to be correct, it is possible that the
System limits
Tire Pressure Monitor did not perform a re-
set. Then perform the reset.
The system does not function properly if a reset
has not been carried out, e.g., a flat tire is re-
Possible driving distance with complete loss of
ported though tire inflation pressures are cor-
tire inflation pressure:
rect.
The possible driving distance after a loss of tire
The tire inflation pressure depends on the tire's
inflation pressure depends on cargo load, driv-
temperature. Driving or exposure to the sun
ing style and road conditions.
will increase the tire's temperature, thus in-
creasing the tire inflation pressure. The tire in-
109

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Safety
flation pressure is reduced when the tire tem-
cantly under-inflated. Accordingly, when the
perature falls again. These circumstances may
low tire pressure telltale illuminates, you should
cause a warning when temperatures fall very
stop and check your tires as soon as possible,
sharply.
and inflate them to the proper pressure. Driving
on a significantly under-inflated tire causes the
The system cannot indicate sudden serious tire
tire to overheat and can lead to tire failure. Un-
damage caused by external circumstances.
der-inflation also reduces fuel efficiency and
tire tread life, and may affect the vehicle's han-
Malfunction
dling and stopping ability. Please note that the
The yellow warning lamp flashes and
TPMS is not a substitute for proper tire mainte-
then lights up continuously. A Check
nance, and it is the driver's responsibility to
Control message is displayed. No flat
maintain correct tire pressure, even if under-in-
tire or loss of tire pressure can be detected.
flation has not reached the level to trigger illu-
Examples and recommendations in the follow-
mination of the TPMS low tire pressure telltale.
ing situations:
Your vehicle has also been equipped with a
A wheel without TPM electronics, for exam-
TPMS malfunction indicator to indicate when
ple an emergency wheel, is mounted: Have
the system is not operating properly. The TPMS
it checked by a dealer’s service center or
malfunction indicator is combined with the low
another qualified service center or repair
tire pressure telltale. When the system detects
shop as needed.
a malfunction, the telltale will flash for approxi-
mately one minute and then remain continu-
Malfunction: Have system checked by a
ously illuminated. This sequence will continue
dealer’s service center or another qualified
upon subsequent vehicle start-ups as long as
service center or repair shop.
the malfunction exists. When the malfunction
TPM was unable to complete the reset. Re-
indicator is illuminated, the system may not be
set the system again.
able to detect or signal low tire pressure as in-
Interference through systems or devices
tended. TPMS malfunctions may occur for a va-
with the same radio frequency: After leav-
riety of reasons, including the installation of re-
ing the area of the interference, the system
placement or alternate tires or wheels on the
automatically becomes active again.
vehicle that prevent the TPMS from functioning
properly. Always check the TPMS malfunction
Declaration according to NHTSA/FMVSS
telltale after replacing one or more tires or
138 Tire Pressure Monitoring System
wheels on your vehicle to ensure that the re-
Each tire, including the spare (if provided)
placement or alternate tires and wheels allow
should be checked monthly when cold and in-
the TPMS to continue to function properly.
flated to the inflation pressure recommended
by the vehicle manufacturer on the vehicle
placard or tire inflation pressure label. (If your
FTM Flat Tire Monitor
vehicle has tires of a different size than the size
indicated on the vehicle placard or tire inflation
The concept
pressure label, you should determine the
The system does not measure the actual infla-
proper tire inflation pressure for those tires.) As
tion pressure in the tires.
an added safety feature, your vehicle has been
It detects a tire inflation pressure loss by com-
equipped with a tire pressure monitoring sys-
paring the rotational speeds of the individual
tem (TPMS) that illuminates a low tire pressure
wheels while moving.
telltale when one or more of your tires is signifi-
110

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety
CONTROLS
In the event of a tire inflation pressure loss, the
Indication of a flat tire
diameter and therefore the rotational speed of
The yellow warning lamp lights up. A
the corresponding wheel changes. This will be
Check Control message is displayed.
detected and reported as a flat tire.
There is a flat tire or a major loss in tire
inflation pressure.
Functional requirements
The system must have been initialized when
1. Reduce your speed and stop cautiously.
the tire inflation pressure was correct; other-
Avoid sudden braking and steering maneu-
wise, reliable flagging of a flat tire is not as-
vers.
sured. Initialize the system after each correc-
2. Check whether the vehicle is fitted with
tion of the tire inflation pressure and after
normal tires or run-flat tires.
every tire or wheel change.
Run-flat tires, refer to page 196, are la-
beled with a circular symbol containing the
Status display
letters RSC marked on the tire's sidewall.
The current status of the Flat Tire Monitor can
be displayed on the Control Display, e.g.,
WARNING
whether or not the FTM is active.
A damaged regular tire with low or miss-
On the Control Display:
ing tire inflation pressure impacts handling,
such as steering and braking response. Run-flat
1.
"Vehicle info"
tires can maintain limited stability. There is a
2. "Vehicle status"
risk of an accident. Do not continue driving if
3.
"Flat Tire Monitor (FTM)"
the vehicle is not equipped with run-flat tires.
Follow the information on run-flat tires and
The status is displayed.
continued driving with these tires.
Initialization
When a flat tire is indicated, DSC Dynamic Sta-
When initializing, the set tire inflation pressures
bility Control is switched on if needed.
serve as reference values in order to detect a
flat tire. Initialization is started by confirming
System limits
the inflation pressures.
A natural, even tire inflation pressure loss in all
Do not initialize the system when driving with
four tires will not be recognized. Therefore,
snow chains.
check the tire inflation pressure regularly.
On the Control Display:
Sudden serious tire damage caused by external
circumstances cannot be recognized in ad-
1.
"Vehicle info"
vance.
2. "Vehicle status"
The system could be delayed or malfunction in
3.
"Perform reset"
the following situations:
4. Start the engine but do not drive off.
When the system has not been initialized.
5. Start the initialization with "Perform reset".
When driving on a snowy or slippery road
surface.
6. Drive away.
Sporty driving style: spinning traction
The initialization is completed while driving,
wheels, high lateral acceleration (drifting).
which can be interrupted at any time.
When driving with snow chains.
The initialization automatically continues when
driving resumes.
111

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Safety
Actions in the event of a flat tire
A vehicle with a damaged tire reacts differently,
e.g., it has reduced lane stability during brak-
Normal tires
ing, a longer braking distance and different
self-steering properties. Adjust your driving
1. Identify the damaged tire.
style accordingly. Avoid abrupt steering ma-
Check the air pressure in all four tires, e.g.
neuvers or driving over obstacles, e.g., curbs,
using the tire pressure gage of a tire repair
potholes, etc.
kit.
Because the possible driving distance depends
If the tire inflation pressure in all four tires is
on how the vehicle is used during the trip, the
correct, the Flat Tire Monitor may not have
actual distance may be shorter or longer de-
been initialized. In this case, initialize the
pending on the driving speed, road conditions,
system.
external temperature, cargo load, etc.
If identification of flat tire damage is not
WARNING
possible, please contact a dealer’s service
center or another qualified service center or
Your vehicle handles differently when a
repair shop.
run-flat tire is damaged and has low or missing
tire inflation pressure, e.g., your lane stability is
2. Repair the flat tire, e.g. with a tire repair kit
reduced when braking, braking distances are
or by changing the tire.
longer and the self-steering properties will
change. There is a risk of an accident.
Run-flat tires
Drive moderately and do not exceed a speed of
Maximum speed
50 mph/80 km/h.
You may continue driving with a damaged tire
at speeds up to 50 mph/80 km/h.
Final tire failure
Vibrations or loud noises while driving can indi-
Continued driving with a flat tire
cate the final failure of a tire.
If continuing to drive with a damaged tire:
Reduce speed and stop; otherwise, pieces of
the tire could come loose and cause an acci-
1. Avoid sudden braking and steering maneu-
dent.
vers.
Do not continue driving. Contact a dealer’s
2. Do not exceed a speed of 50 mph/80 km/h.
service center or another qualified service cen-
3. Check the air pressure in all four tires at the
ter or repair shop.
next opportunity.
If the tire inflation pressure in all four tires is
correct, the Flat Tire Monitor may not have
Intelligent Safety
been initialized. In this case, initialize the
system.
The concept
Possible driving distance with complete loss of
Intelligent Safety enables central operation of
tire inflation pressure:
the driver assistance system.
The possible driving distance after a loss of tire
The intelligent safety systems can help prevent
inflation pressure depends on cargo load, driv-
an imminent collision.
ing style and road conditions.
Front-end collision warning with City Brak-
A vehicle with an average load has a possible
ing function, refer to page 113.
driving range of approx. 50 miles/80 km.
112

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety
CONTROLS
Person warning with City light braking func-
Press button briefly:
tion, refer to page 116.
The menu for the intelligent safety
system is displayed. The systems
Safety information
are individually switched off ac-
WARNING
cording to their respective settings.
Indicators and warnings do not relieve
LED lights up orange or goes out respective
the driver from personal responsibility. Due to
to their individual settings.
system limits, warnings or reactions of the sys-
Adjust as needed. Individual settings are stored
tem may not be output or they may be output
for the profile currently used.
too late or incorrectly. There is a risk of an acci-
dent. Adjust the driving style to the traffic con-
Press button again:
ditions. Watch traffic closely and actively inter-
All Intelligent Safety systems are
vene in the respective situations.
activated.
WARNING
The LED lights up green.
Due to system limits, individual functions
Hold down button:
can malfunction during tow-starting/towing
All Intelligent Safety systems are
with the Intelligent Safety systems activated,
turned off.
e.g., approach control warning with light brak-
ing function. There is a risk of an accident.
The LED goes out.
Switch all Intelligent Safety systems off prior to
tow-starting/towing.
Front-end collision
Overview
warning with City Brak-
Button in the vehicle
ing function
The concept
The system can help prevent accidents. If an
accident cannot be prevented, the system will
help reduce the collision speed.
The system sounds a warning before an immi-
nent collision and actuates brakes independ-
ently if needed.
The automatic braking intervention is done
Intelligent Safety button
with limited force and duration.
The system is controlled via a camera in the
base of the mirror.
Switching on/off
The front-end collision warning is available
Some Intelligent Safety systems are automati-
even if cruise control has been deactivated.
cally active after every departure. Some Intelli-
With the vehicle approaching another vehicle
gent Safety systems activate according to the
intentionally, the collision warning and braking
last setting.
113

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Safety
are delayed in order to avoid false system reac-
Overview
tions.
Button in the vehicle
General information
The system warns at two levels of an imminent
danger of collision at speeds from approx.
3 mph/5 km/h. Time of warnings may vary with
the current driving situation.
Appropriate braking kicks in at speeds of up to
35 mph/60 km/h.
Detection range
Intelligent Safety button
Camera
It responds to objects if they are detected by
the system.
Safety information
The camera is installed near the interior rear-
WARNING
view mirror.
Indicators and warnings do not relieve
Keep the windshield in the area behind the in-
the driver from personal responsibility. Due to
terior rearview mirror clean and clear.
system limits, warnings or reactions of the sys-
tem may not be output or they may be output
too late or incorrectly. There is a risk of an acci-
Switching on/off
dent. Adjust the driving style to the traffic con-
ditions. Watch traffic closely and actively inter-
Switching on automatically
vene in the respective situations.
The system is automatically active after every
driving-off.
WARNING
Due to system limits, individual functions
Switching on/off manually
can malfunction during tow-starting/towing
Press button briefly:
with the Intelligent Safety systems activated,
e.g., approach control warning with light brak-
The menu for the intelligent safety
ing function. There is a risk of an accident.
system is displayed. The systems
Switch all Intelligent Safety systems off prior to
are individually switched off ac-
tow-starting/towing.
cording to their respective settings.
114

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety
CONTROLS
LED lights up orange or goes out respective
Prewarning
to their individual settings.
This warning is issued, for example, when there
Adjust as needed. Individual settings are stored
is the impending danger of a collision or the
for the profile currently used.
distance to the vehicle ahead is too small.
The driver must intervene actively when there
Press button again:
is a prewarning.
All Intelligent Safety systems are
activated.
Acute warning with braking function
The LED lights up green.
Acute warning in displayed in case of the immi-
nent danger of a collision when the vehicle ap-
Hold down button:
proaches another object at a high differential
All Intelligent Safety systems are
speed.
turned off.
The driver must intervene actively when there
The LED goes out.
is an acute warning. If necessary, the driver is
assisted by a minor automatic braking inter-
vention in a possible risk of collision.
Setting the warning time
Acute warnings can also be triggered without
The warning time can be set via the onboard
previous forewarning.
monitor.
1.
"Settings"
Braking intervention
2. "Frontal Coll. Warning"
The warning prompts the driver himself/herself
to react. During a warning, the maximum brak-
3. Activate the desired warning time on the
ing force is used. Premise for the brake booster
Control Display.
is sufficiently quick and sufficiently hard step-
The selected warning time is stored for the pro-
ping on the brake pedal. The system can assist
file currently used.
with some braking intervention if there is risk of
a collision. At low speeds vehicles may thus
Warning with braking function
come to a complete stop.
Manual transmission: During a braking inter-
Display
vention up to a complete stop, the engine may
If a collision with a recognized vehicle is immi-
be shut down.
nent a warning symbol appears in the instru-
The braking intervention is executed only if ve-
ment cluster and in the Head-Up Display.
hicle stability has not been restricted, e.g. by
Symbol Measure
deactivating the DSC Dynamic Stability Control.
Symbol lights up red: prewarning.
The braking intervention can be interrupted by
Brake and increase distance.
stepping on the accelerator pedal or by actively
moving the steering wheel.
Symbol flashes red and an acoustic
Object detection can be restricted. Limitations
signal sounds: acute warning.
of the detection range and functional restric-
You are requested to intervene by
tions are to be considered.
braking or make an evasive maneu-
ver.
115

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Safety
System limits
Warning sensitivity
The more sensitive the warning settings are,
Safety information
the more warnings are displayed. However,
WARNING
there may also be an excess of false warnings.
The system can react incorrectly or not at
all due to the system limits. There is a risk of ac-
cidents or risk of property damage. Observe the
Person warning with City
information regarding the system limits and ac-
light braking function
tively intervene, if needed.
The concept
Detection range
The system can help prevent accidents with pe-
The system's detection potential is limited.
destrians.
Thus a system reaction might not come or
The system issues a warning in the city driving
might come late.
speed area if there is imminent danger of a col-
lision with pedestrians and includes a braking
E. g. the following situations may not be de-
function.
tected:
A camera at the base of the rearview mirror
Slow moving vehicles when you approach
controls the system.
them at high speed.
Vehicles that suddenly swerve in front of
General information
you, or sharply decelerating vehicles.
With sufficient brightness, the system warns
Vehicles with an unusual rear appearance.
about possible collision danger with pedes-
Two-wheeled vehicles ahead of you.
trians starting at approx. 6 mph/10 km/h to ap-
prox. 35 mph/60 km/h and assists with braking
Functional limitations
before a collision.
The system may not be fully functional in the
Under those circumstances it reacts to people
following situations:
who are within the detection range of the sys-
In heavy fog, rain, sprayed water or snow-
tem.
fall.
Detection range
In tight curves.
If the field of view of the camera or the
front windshield are dirty or covered.
If the driving stability control systems are
deactivated, for example DSC OFF.
Up to 10 seconds after the start of the en-
gine, via the Start/Stop button.
During calibration of the camera immedi-
ately after vehicle delivery.
If there are constant blinding effects be-
The detection area in front of the vehicle is div-
cause of oncoming light, e. g., from the sun
ided into two areas
low in the sky.
116

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety
CONTROLS
Central area, arrow 1, directly in front of the
Intelligent Safety button
vehicle.
Expanded area, arrow 2, to the right and
Camera
left.
A collision is imminent if pedestrians are lo-
cated within the central area. A warning is is-
sued about pedestrians who are located within
the extended area only if they are moving in
the direction of the central area.
Safety information
WARNING
Indicators and warnings do not relieve
The camera is installed near the interior rear-
the driver from personal responsibility. Due to
view mirror.
system limits, warnings or reactions of the sys-
Keep the windshield in the area behind the in-
tem may not be output or they may be output
terior rearview mirror clean and clear.
too late or incorrectly. There is a risk of an acci-
dent. Adjust the driving style to the traffic con-
ditions. Watch traffic closely and actively inter-
Switching on/off
vene in the respective situations.
Switching on automatically
WARNING
The system is automatically active after every
Due to system limits, individual functions
driving-off.
can malfunction during tow-starting/towing
with the Intelligent Safety systems activated,
Switching on/off manually
e.g., approach control warning with light brak-
Press button briefly:
ing function. There is a risk of an accident.
The menu for the intelligent safety
Switch all Intelligent Safety systems off prior to
system is displayed. The systems
tow-starting/towing.
are individually switched off ac-
cording to their respective settings.
Overview
LED lights up orange or goes out respective
to their individual settings.
Button in the vehicle
Adjust as needed. Individual settings are stored
for the profile currently used.
Press button again:
All Intelligent Safety systems are
activated.
The LED lights up green.
Hold down button:
117















Content      ..     4      5      6      7     ..
