Driving
CONTROLS
Manual transmission:
The engine is not yet at operating tempera-
ture.
Neutral is engaged and the clutch pedal is
not pressed.
The wheels are at a sharp angle or the
steering wheel is being turned.
The driver's safety belt is buckled or the
driver's door is closed.
After driving in reverse.
Steptronic transmission:
Fogging of the windows when the auto-
matic climate control is switched on.
The selector lever is in selector lever posi-
tion D.
The vehicle battery charge is very low.
Brake pedal remains depressed while the
At higher elevations.
vehicle is stopped.
The engine compartment lid is unlocked.
The driver's safety belt is buckled or the
The parking assistant is activated.
driver's door is closed.
Stop-and-go traffic.
In order to be able to release the brake pedal,
Selector lever in selector lever position R, N
engage lever in position P. The engine remains
or M/S.
off.
To continue driving depress the brake pedal.
Starting the engine
When a gear is engaged, the engine starts au-
The engine starts automatically under the fol-
tomatically.
lowing conditions:
The air flow from the air conditioner is reduced
Manual transmission: clutch pedal is
when the engine is switched off.
pressed.
Steptronic transmission: by releasing the
Displays in the instrument cluster
brake pedal.
The display indicates that the
After the engine starts, accelerate as usual.
Auto Start/Stop function is ready
for an Automatic engine start.
Safety mode
After the engine switches off automatically, it
will not start again automatically if any one of
The display indicates that the
the following conditions are met:
conditions for an automatic en-
The driver's safety belt is unbuckled and
gine stop have not been met.
the driver's door is open.
The hood was unlocked.
Some indicator lights light up for a varied
Functional limitations
length of time.
The engine is not switched off automatically in
The engine can only be started via the Start/
the following situations:
Stop button.
External temperature too low.
The external temperature is high and auto-
Functional limitations
matic climate control is running.
Even if driving off was not intended, the deacti-
The car's interior has not yet been heated
vated engine starts up automatically in the fol-
or cooled to the required level.
lowing situations:
67

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
Excessive warming of the car's interior
Switching off the vehicle during an
when the cooling function is switched on.
automatic engine stop
The steering wheel is turned.
During an automatic engine stop, the vehicle
can be switched off permanently, e.g., when
Steptronic transmission: change from selec-
leaving it.
tor lever position D to R, N or M/S.
Steptronic transmission:
Steptronic transmission: change from selec-
tor lever position P to R, N, D or M/S.
1. Engage selector lever position P.
The vehicle begins rolling.
2. Press the Start/Stop button. The ignition is
Fogging of the windows when the auto-
switched off. The Auto Start/Stop function is
matic climate control is switched on.
deactivated.
The vehicle battery charge is very low.
3. Set the parking brake.
Excessive cooling of the car's interior when
Manual transmission:
the heating is switched on.
1. Press the Start/Stop button. The ignition is
Manual transmission: low brake vacuum
switched off. The Auto Start/Stop function is
pressure; this can occur, for example, if the
deactivated.
brake pedal is depressed a number of times
2. Shift into first gear or reverse.
in succession.
3. Set the parking brake.
Switching the system on/off
Engine start as usual via Start/Stop button.
Using the button
Automatic deactivation
In certain situations, the Auto Start/Stop func-
tion is deactivated automatically for safety rea-
sons, as it is detected that no driver is present.
Malfunction
The Auto Start/Stop function no longer switches
off the engine automatically. A Check Control
message is displayed. It is possible to continue
driving. Have the system checked by a dealer’s
service center or another qualified service cen-
Press button.
ter or repair shop.
LED comes on: Auto Start/Stop function is
deactivated.
Parking brake
The engine is started during an automatic
engine stop.
Safety information
The engine can only be stopped or started
WARNING
via the Start/Stop button.
An unsecured vehicle can begin to move
LED goes out: Auto Start/Stop function is
and possibly roll away. There is a risk of an acci-
activated.
dent. Before exiting, secure the vehicle against
rolling.
68

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving
CONTROLS
In order to ensure that the vehicle is secured
Turn signal, high beams,
against rolling away, observe the following:
headlight flasher
Set the parking brake.
On uphill grades or on a downhill slope,
Turn signal
turn the front wheels in the direction of the
curb.
Using turn signals
On uphill grades or on a downhill slope,
also secure the vehicle, e.g., with a wheel
chock.
Applying
The lever automatically engages after being
pulled up.
The indicator lamp lights up red. The
parking brake is set.
Lower lamp: indicator lamp in Canadian
Press the lever past the resistance point.
models
The lever returns into its starting position after
actuation.
If for once use during driving is required, en-
To switch off manually, slightly tap the lever to
gage the parking brake slightly and hold the
the resistance point.
button down.
To prevent corrosion and one-sided brake ac-
Triple turn signal activation
tion, lightly apply the parking brake periodically
Lightly tap the lever up or down.
while coasting, if traffic conditions permit.
The turn signal flashes three times.
The brake lights will not light up if the parking
brake is set.
The function can be activated or deactivated.
On the Control Display:
Releasing
1.
"Settings"
2. "Lighting"
3. "Triple turn signal"
Settings are stored for the driver profile cur-
rently used.
Signaling briefly
Press the lever to the resistance point and hold
it there for as long as you want the turn signal
Raise lever slightly, press the button and guide
to flash.
the lever down.
Malfunction
Unusually rapid flashing of the indicator lamp
indicates that a turn signal bulb has failed.
69

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
High beams, headlight flasher
Switching on
Push the lever forward or pull it backward.
Tap up the lever or press it past the resistance
point.
High beams, arrow 1.
Normal wiper speed: tap up once.
Headlight flasher, arrow 2.
The wipers switch to intermittent operation
when the vehicle is stationary.
Fast wiper speed: tap up twice or tap once
Washer/wiper system
beyond the resistance point.
Wipers change to normal speed when vehi-
General information
cle comes to standstill.
Do not use the wipers if the windshield is dry,
The lever automatically returns to its initial po-
as this may damage the wiper blades or cause
sition when released.
them to become worn more quickly.
Safety information
Switching off and brief wipe
WARNING
If the wipers start moving in the folded
away state, body parts can be jammed or dam-
age may occur to parts of the vehicle. There is a
risk of injury or risk of property damage. Make
sure that the vehicle is switched off when the
wipers are in the folded away state and the
wipers are folded in when switching on.
NOTE
Press the lever down.
If the wipers are frozen to the windshield,
To switch off from fast wiper speed: press
the wiper blades can be torn off and the wiper
down twice.
motor can overheat when switching on. There
To switch off from normal wiper speed:
is a risk of property damage. Defrost the wind-
press down once.
shield prior to switching the wipers on.
Single wipe: press down once.
The lever automatically returns to its initial po-
sition when released.
70

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving
CONTROLS
Interval mode or rain sensor
Setting the frequency or sensitivity of
the rain sensor
Concept
The rain sensor automatically controls the time
between wipes depending on the intensity of
the rainfall.
General information
The sensor is located on the windshield, directly
in front of the interior mirror. Without the rain
sensor, the frequency of the wiper operation is
preset.
Turn the thumbwheel to adjust the frequency
or sensitivity of the rain sensor.
Safety information
Up: short interval or high sensitivity of the rain
NOTE
sensor.
If the rain sensor is activated, the wipers
Down: long interval or low sensitivity of the rain
can accidentally start moving in vehicle washes.
sensor.
There is a risk of property damage. Deactivate
the rain sensor in vehicle washes.
Windshield washer system
Activating/deactivating
Safety information
WARNING
The washer fluid can freeze onto the win-
dow at low temperatures and obstruct the
view. There is a risk of an accident. Only use the
washer systems, if the washer fluid cannot
freeze. Use antifreeze, if needed.
NOTE
When the washer fluid reservoir is empty,
Press button on the wiper lever.
the wash pump cannot work as intended.
Wiping is started.
There is a risk of property damage. Do not use
the washer system when the washer fluid res-
If the vehicle is equipped with a rain sensor:
ervoir is empty.
LED in wiper lever lights up.
If wipers are frozen to windshield, wiper opera-
tion is deactivated.
During trip interruption with the rain sensor
switched on: if the trip is resumed within ap-
prox. 15 minutes, the rain sensor is automati-
cally activated again.
71

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
Cleaning
Fold-away position of the wipers
Concept
The fold-out position enables the wipers to be
folded away from the windshield.
General information
Helpful when changing the wiper blades or un-
der frosty conditions, e.g.
Pull the lever.
Safety information
The system sprays washer fluid on the wind-
WARNING
shield and activates the wipers briefly.
If the wipers start moving in the folded
away state, body parts can be jammed or dam-
age may occur to parts of the vehicle. There is a
Windshield washer nozzles
risk of injury or risk of property damage. Make
The windshield washer nozzles are automati-
sure that the vehicle is switched off when the
cally heated while the ignition is switched on.
wipers are in the folded away state and the
wipers are folded in when switching on.
Rear window wiper
Folding out the wipers
Switching on the rear window wiper
1. Switch the ignition on and off again.
2. With frosty conditions, make sure that the
blades are not frozen to the windshield
3. Press the wiper lever up beyond the point
of resistance and hold it for approx. 3 sec-
onds, until the wipers remain in a nearly
vertical position
Turn the switch from idle position 0 upward, ar-
row 1: interval mode. When reverse gear is en-
gaged, the system switches to continuous op-
eration.
Clean the rear window
In interval mode: turn the switch further, ar-
row 2. The switch automatically returns to its
4. Lift the wiper all the way off of the wind-
interval position when released.
shield.
In idle position: turn switch downward, arrow 3.
The switch automatically returns to its idle posi-
tion when released.
72

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving
CONTROLS
Folding down the wipers
Next, fully close the lid of the washer fluid res-
ervoir.
After the wipers are folded back down, the
wiper system must be reactivated.
NOTE
1. Switch on the ignition.
Silicon-containing additives in the washer
2. Push wiper lever down. Wipers return to
fluid for the water-repelling effect on the win-
their resting position and are ready again
dows can lead to damage to the washing sys-
for operation.
tem. There is a risk of property damage. Do not
add silicon-containing additives to the washer
fluid.
Washer fluid
NOTE
Mixing different windshield washer con-
General information
centrates or antifreeze agents can damage the
All washer nozzles are supplied from one reser-
washing system. There is a risk of property
voir.
damage. Do not mix different windshield
Use a mixture of tap water, windshield washer
washer concentrates or antifreeze agents. Ob-
concentrate and, if required, antifreeze for the
serve the information and mixing ratios pro-
windshield washer system.
vided on the containers.
Recommended minimum fill quantity:
0.2 US gal/1 liter.
Overview
Safety information
WARNING
Some antifreeze agents can contain
harmful substances and are flammable. There
is a risk of fire and a risk of injury. Observe the
instructions on the containers. Keep antifreeze
away from ignition sources. Do not refill oper-
ating materials into different bottles. Store op-
erating materials out of reach of children.
The washer fluid reservoir is located in the en-
United States: The washer fluid mixture ratio is
gine compartment.
regulated by the U.S. EPA and many individual
states; do not exceed the allowable washer
Malfunction
fluid dilution ratio limits that apply. Follow the
The use of undiluted windshield washer con-
usage instructions on the washer fluid con-
centrate or alcohol-based antifreeze can lead
tainer.
to incorrect readings at temperatures below
Use of BMW’s Windshield Washer Concentrate
+ 5 ℉/- 15 ℃.
or the equivalent is recommended.
WARNING
Washer fluid can ignite and catch fire on
contact with hot engine parts. There is a risk of
injury or risk of property damage. Only add
washer fluid when the engine is cooled down.
73

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
Manual transmission
Steptronic transmission
Safety information
Safety information
WARNING
WARNING
An unsecured vehicle can begin to move
An unsecured vehicle can begin to move
and possibly roll away. There is a risk of an acci-
and possibly roll away. There is a risk of an acci-
dent. Before exiting, secure the vehicle against
dent. Before exiting, secure the vehicle against
rolling.
rolling.
In order to ensure that the vehicle is secured
In order to ensure that the vehicle is secured
against rolling away, observe the following:
against rolling away, observe the following:
Set the parking brake.
Set the parking brake.
On uphill grades or on a downhill slope,
On uphill grades or on a downhill slope,
turn the front wheels in the direction of the
turn the front wheels in the direction of the
curb.
curb.
On uphill grades or on a downhill slope,
On uphill grades or on a downhill slope,
also secure the vehicle, e.g., with a wheel
also secure the vehicle, e.g., with a wheel
chock.
chock.
NOTE
Selector lever positions
When shifting to a lower gear, excessive
speeds can damage the engine. There is a risk
D Drive
of property damage. When shifting into 5th or
Selector lever position for normal vehicle oper-
6th gear, press the gearshift lever to the right.
ation. All gears for forward travel are activated
automatically.
Shifting
R Reverse
General information
Select only when the vehicle is stationary.
The engine speed during a shifting operation is
adjusted automatically for harmonious and dy-
N Neutral
namic gear shifting.
The vehicle may roll. Use in automatic car
washes, for example.
Reverse gear
Select only when the vehicle is stationary.
P Park
To overcome the resistance push the gearshift
Select only when the vehicle is stationary. The
lever dynamically to the left and engage re-
drive wheels are blocked.
verse gear with a forward shifting movement.
Before exiting the vehicle, make sure that se-
lector lever position P is set. Otherwise, the ve-
hicle may begin to move.
Kickdown
Kickdown is used to achieve maximum driving
performance. Step on the accelerator pedal be-
74

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving
CONTROLS
yond the resistance point at the full throttle po-
Sport program and manual mode M/S
sition.
Activating the sport program
Engaging selector lever positions
General information
To prevent the vehicle from creeping after you
select a gear, maintain pressure on the brake
pedal until you are ready to start.
The selector lever can only be taken out of se-
lector lever position P if the ignition is on or the
engine is running.
With the vehicle stationary, depress the brake
Press the selector lever to the left out of selec-
pedal before shifting out of selector lever posi-
tor lever position D.
tion P or N; otherwise, the shift block will not be
The engaged gear is displayed in the instru-
deactivated and the shift command will not be
ment cluster, for example, S1.
executed.
The sport program of the transmission is acti-
vated.
Releasing the selector lever lock
A lock prevents the inadvertent switching to se-
lector lever position P or R or the inadvertent
Activating the M/S manual mode
change from selector lever position P.
1. Press the selector lever to the left out of se-
lector lever position D.
2. Push the selector lever forward or back-
ward.
Manual mode M/S becomes active and the gear
is changed.
The engaged gear is displayed in the instru-
ment cluster, for example, M1.
If the situation requires, the Steptronic trans-
mission continues to shift automatically.
To release the lock: with the brake pedal de-
Example: once maximum engine speed is at-
pressed, press the button on the front of the
tained, M/S manual mode is automatically up-
selector lever, see arrow.
shifted as needed.
Switching to manual mode
To shift down: press the selector lever for-
ward.
To shift up: pull the selector lever rear-
wards.
Gears will only be shifted at appropriate engine
and road speeds, for example downshifting is
not possible if the engine speed is too high.
75

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
The selected gear is briefly displayed in the in-
Shift down: briefly pull left shift paddle.
strument cluster, followed by the currently se-
The lowest possible gear can be selected by
lected gear.
pulling and holding the left shift paddles.
Gears will only be shifted at appropriate engine
Manual mode M/S: prevent automatic
and road speeds, for example downshifting is
upshifting
not possible if the engine speed is too high.
Once a particular engine speed is attained, M/S
The selected gear is briefly displayed in the in-
manual mode is automatically upshifted as
strument cluster, followed by the current gear.
needed.
If the shift paddles on the steering wheel are
For vehicles with Steptronic Sport transmission,
used to shift gears in automatic mode, the
automatic shift operations are not performed if
transmission switches to manual mode tempo-
one of the following conditions is met:
rarily in selector lever position D and perma-
DSC is deactivated.
nently in selector lever position S.
TRACTION is activated.
In selector lever position D, after conservative
In addition, there is no downshifting for kick-
driving for a certain amount of time in manual
down.
mode or if there has been no acceleration or
shifting of the shift paddles within a certain
With the respective transmission version, the
amount of time, the transmission switches back
lowest possible gear can be selected by simul-
to automatic mode.
taneously operating the kickdown and the left
shift paddles. This is not possible, when switch-
It is possible to switch from manual mode into
ing briefly via the shift paddles from selector
the automatic mode at any time:
lever position D to manual mode M/S.
Pull and hold right shift paddle.
Or
Ending the sport program/manual
In addition to the briefly pulled right shift
mode
paddle, briefly pull the left shift paddle.
Push the selector lever to the right.
D is displayed in the instrument cluster.
Displays in the instrument cluster
Shift paddles for Steptronic Sport
The selector lever position is dis-
transmission
played, for example: P.
Manually release the transmission lock
Should the selector lever be blocked in selector
lever position P despite the ignition being
switched on, the brake being depressed and
the button on the selector lever being pressed,
the transmission lock can be canceled man-
The shift paddles on the steering wheel allow
ually:
you to shift gears quickly while keeping both
hands on the steering wheel.
Shift up: briefly pull right shift paddle.
76

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving
CONTROLS
Before unlocking the transmission lock man-
Steptronic Sport transmission: Launch
ually, engage the parking brake forcefully to
Control
prevent the vehicle from rolling away.
Concept
1.
Loosen the selector lever sleeve together
Launch Control enables optimum acceleration
with the lower retaining ring and, if re-
on surfaces with good traction.
quired, the MINI Driving Modes switch from
the center console. To do so, pull the re-
taining ring and, if required, the MINI Driv-
General information
ing Modes switch upward at the rear edge.
The use of Launch Control causes premature
component wear since this function represents
a very heavy load for the vehicle.
Do not use Launch Control during the break-in,
refer to page 164, period.
To increase vehicle stability, activate DSC again
as soon as possible.
An experienced driver may be able to achieve
better acceleration values in DSC OFF mode, re-
fer to page 120.
2.
Lift the sleeve. Unplug the cable connector,
if needed.
Requirements
3.
Using the screwdriver from the onboard ve-
Launch Control is available when the engine is
hicle tool kit, refer to page 215, press the
warmed up, that is, after uninterrupted driving
yellow release lever downward, see arrow.
of at least 6 miles/10 km.
To start with Launch Control do not steer the
steering wheel.
Start with launch control
While the engine is running:
1.
Press button and select SPORT with
the MINI Driving Modes switch, refer to
page 122.
4.
Move the selector lever slightly toward the
The instrument cluster displays TRACTION
rear; to do this press the button on the
in combination with SPORT. The DSC OFF
front of the selector lever.
indicator lamp lights up.
Release the release lever.
2. Engage selector lever position S.
5.
Bring the selector lever into the desired po-
3. With the left foot, forcefully press down on
sition.
the brake.
4. Step on the accelerator pedal beyond the
resistance point at the full throttle position,
kickdown.
77

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Driving
A flag symbol is displayed in the instrument
cluster.
5. The starting engine speed adjusts. Within
3 seconds, release the brake.
Before using Launch Control, allow the trans-
mission to cool down for approx. 5 minutes.
78

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Displays
CONTROLS
Displays
necessarily available in your vehicle, e. g., due
Vehicle features and op-
to the selected options or country versions. This
tions
also applies to safety-related functions and sys-
tems. When using these functions and systems,
This chapter describes all standard, country-
the applicable country provisions must be ob-
specific and optional features offered with the
served.
series. It also describes features that are not
Instrument cluster
Overview, instrument cluster
1
Tachometer
84
4
Fuel gauge
84
2
Indicator/warning lights
5
Display/reset miles
84
3
Speedometer
6
Electronic displays
80
79

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Displays
Electronic displays
1
Driver assistance systems
Onboard computer
88
Messages, e.g., Check Control
2
Selector lever position
74
Time
84
Gear shift indicator
86
External temperature
84
3
MINI Driving Modes switch status
122
Selection lists
88
Status
Total miles/trip odometer
84
Red lights
Check Control
Safety belt reminder
Concept
The Check Control system monitors functions in
Indicator lamp flashes or illuminates:
the vehicle and notifies you of malfunctions in
safety belt on the driver or front pas-
the monitored systems.
senger side is not buckled. The safety
belt reminder can also be activated if objects
Indicator/warning lights
are placed on the front passenger seat.
Make sure that the safety belts are positioned
General information
correctly.
The indicator and warning lights can light up in
a variety of combinations and colors.
Airbag system
Several of the lights are checked for proper
Airbag system and belt tensioner are
functioning and light up temporarily when the
not working.
engine is started or the ignition is switched on.
80

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Displays
CONTROLS
Have the vehicle checked immediately by a
Indicator lamp flashes: the conditions are not
dealer’s service center or another qualified
adequate for the system to work.
service center or repair shop.
The system was deactivated but applies the
brakes until you actively resume control by
Parking brake, brake system
pressing on the brake pedal or accelerator
pedal.
The parking brake is set.
For additional information, refer to Re-
Yellow lights
lease parking brake, refer to page 69.
Anti-lock Braking System ABS
Braking force boost may not be work-
Approach control warning
ing. Avoid sudden braking. Stop cau-
tiously. Take the longer braking dis-
Indicator lamp illuminates: advance
tance into account.
warning is issued, e.g., when there is
the impending danger of a collision or
Have the system immediately checked
the distance to the vehicle ahead is too small.
by a dealer’s service center or another qualified
service center or repair shop.
Increase distance.
Indicator lamp flashes: acute warning of the
imminent danger of a collision when the vehi-
DSC Dynamic Stability Control
cle approaches another vehicle at a relatively
The indicator lamp flashes: DSC controls
high differential speed.
the drive and braking forces. The vehi-
Intervention by braking or make an evasive
cle is stabilized. Reduce speed and
maneuver.
adapt driving style to the driving circumstances.
The indicator lamp lights up: DSC has malfunc-
Pedestrian warning
tioned.
Have the system checked by a dealer’s service
If a collision with a person detected in
center or another qualified service center or re-
this way is imminent, the symbol lights
pair shop.
up and a signal sounds.
For additional information, refer to Dynamic
Stability Control DSC, refer to page 120.
Orange lights
Active Cruise Control
DSC Dynamic Stability Control is deactivated
or DTC Dynamic Traction Control is activated
The number bars shows the selected
distance from the vehicle driving ahead.
DSC Dynamic Stability Control is deacti-
vated or DTC Dynamic Traction Control
For more information, see Camera-
is activated.
based cruise control, refer to page 124.
For additional information, refer to Dynamic
Stability Control DSC, refer to page 120, and
Vehicle detection, Active Cruise Control
Dynamic Traction Control DTC, refer to
Indicator lamp illuminates: a vehicle has
page 121.
been detected ahead of you.
81

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTROLS
Displays
Flat Tire Monitor FTM
Engine functions
The Flat Tire Monitor signals a loss of
Engine function impaired.
tire inflation pressure in a tire.
Have the vehicle checked by a dealer’s
Reduce your speed and stop cautiously.
service center or another qualified serv-
Avoid sudden braking and steering maneuvers.
ice center or repair shop.
For additional information, refer to Flat Tire
For additional information, refer to On-board
Monitor, refer to page 110.
Diagnostics socket, refer to page 214.
Tire Pressure Monitor TPM
Rear fog lamp
The indicator lamp illuminates.
Rear fog lights are activated.
The Tire Pressure Monitor signals a low
For additional information, refer to Rear
tire inflation pressure or a flat tire.
fog lights, refer to page 101.
Observe the information in the Check Control
message.
Green lights
The indicator lamp flashes and then illuminates
continuously.
Turn signal
No flat tire or loss of tire inflation pressure can
Turn signal switched on.
be detected.
Unusually rapid flashing of the indicator
Interference caused by systems or devices
lamp indicates that a turn signal bulb
with the same radio frequency: after leav-
has failed.
ing the area of the interference, the system
For additional information, refer to Turn signal,
automatically becomes active again.
refer to page 69.
TPM was unable to complete the reset. Re-
set the system again.
Parking lights, headlight control
A wheel without TPM electronics is
Parking lights or headlights are acti-
mounted: have it checked by a dealer’s
vated.
service center or another qualified service
center or repair shop as needed.
For additional information, refer to
Parking lights/low beams, headlight control, re-
Malfunction: have the system checked by a
fer to page 98.
dealer’s service center or another qualified
service center or repair shop.
For additional information, refer to Tire Pres-
Front fog lights
sure Monitor, refer to page 106.
Front fog lights are activated.
For additional information, refer to
Steering system
Front fog lights, refer to page 101.
Steering system in some cases not
working.
High-beam Assistant
Have the steering system checked by a
High-beam Assistant is switched on.
dealer’s service center or another qualified
service center or repair shop.
82

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Displays
CONTROLS
High beams are activated and off automatically
"Service request"
as a function of the traffic situation.
Contact a dealer’s service center or another
For additional information, refer to High-beam
qualified service center or repair shop.
Assistant, refer to page 100.
"Roadside Assistance"
Contact Roadside Assistance.
Cruise control
Hiding Check Control messages
The system is switched on. It maintains
the speed that was set using the control
elements on the steering wheel.
Blue lights
High beams
High beams are activated.
For additional information, refer to High
beams, refer to page 70.
Press and hold button on turn signal lever.
Some Check Control messages are dis-
General lamps
played continuously and are not cleared
At least one Check Control message is
until the malfunction is eliminated. If sev-
displayed or is stored.
eral malfunctions occur at once, the mes-
sages are displayed consecutively.
These messages can be faded for approx.
Text messages
8 seconds. After this time, they are dis-
Text messages in combination with a symbol in
played again automatically.
the instrument cluster explain a Check Control
message and the meaning of the indicator and
Other Check Control messages are faded
warning lights.
automatically after approx. 20 seconds.
They are stored and can be displayed again
later.
Supplementary text messages
Additional information, such as on the cause of
Displaying stored Check Control
an error or the required action, can be called up
messages
via Check Control.
On the Control Display:
With urgent messages the added text will be
automatically displayed on the Control Display.
1.
"Vehicle info"
2. "Vehicle status"
Symbols
3.
"Check Control"
Within the supplementary text, the following
4. Select the text message.
functions can be selected independent of the
check control message.
Display additional information about
the Check Control message in the
Integrated Owner's Manual.
83















Content      ..     2      3      4      5     ..
