The Engine Start/Stop button must
be in the ON position to be able to
raise or lower the windows. Each
door has a Power Window switch to
control that door's window. The driv-
er has a Power Window Lock switch
which can block the operation of pas-
senger windows. The power windows
will operate for approximately 30
seconds after the Engine Start/Stop
button is placed in the ACC or OFF
position. However, if the front doors
are opened, the Power Windows
cannot be operated even within the
30 second period.

Information

• In cold and wet climates, power win-

dows may not work properly due to
freezing conditions.

• While driving with the rear windows

down or with the sunroof (if equipped)
opened (or partially opened), your
vehicle may demonstrate a wind buf-
feting or pulsation noise. This noise is
normal and can be reduced or elimi-
nated by taking the following actions.
If the noise occurs with one or both of
the rear windows down, partially
lower both front windows approxi-
mately one inch. If you experience the
noise with the sunroof open, slightly
close the sunroof.

Window opening and closing

To open:
Press the window switch down to the
first detent position (5). Release the
switch when you want the window to
stop.

To close:
Pull the window switch up to the first
detent position (5). Release the win-
dow switch when you want the win-
dow to stop.

Auto up/down window

Pressing or pulling up the power win-
dow switch momentarily to the sec-
ond detent position (6) completely
lowers or lifts the window even when
the switch is released. To stop the
window at the desired position while
the window is in operation, pull up or
press down and release the switch.

i

3-24

Convenient features of your vehicle

To avoid serious injury or death,
do not extend your head, arms
or body outside the windows
while driving.

WARNING

OHI046029

To reset the power windows

If the power windows do not operate
normally, the automatic power win-
dow system must be reset as follows:
1. Place the Engine Start/Stop button

to the ON position.

2. Close the window and continue

pulling up on the power window
switch for at least one second.

If the power windows do not operate
properly after resetting, it is recom-
mended that the system be checked
by an authorized retailer of Genesis
Branded products.

Automatic reversal

If a window senses any obstacle
while it is closing automatically, it will
stop and lower approximately 30 cm
(12 inches) to allow the object to be
cleared.
If the window detects the resistance
while the power window switch is
pulled up continuously, the window
will stop upward movement then
lower approximately 2.5 cm (1 inch).
If the power window switch is pulled
up continuously again within 5 sec-
onds after the window is lowered by
the automatic window reversal fea-
ture, the automatic window reversal
will not operate.

Information

The automatic reverse feature is only
active when the “Auto Up” feature is
used by fully pulling up the switch to
the second detent.

i

3-25

03

OHI046030

Make sure body parts or other
objects are safely out of the way
before closing the windows to
avoid injuries or vehicle damage.
Objects less than 4 mm (0.16
inch) in diameter caught between
the window glass and the upper
window channel may not be
detected by the automatic reverse
window and the window will not
stop and reverse direction.

WARNING

3-26

Convenient features of your vehicle

Power window lock switch

The driver can disable the power
window switches on the rear passen-
gers' doors by pressing the power
window lock switch. The indicator will
be illuminated.
When the power window lock switch
is pressed:
• The driver's master control can

operate the front passenger's power
window but cannot operate the rear
passengers' power windows.

• The front passenger's control can

operate the front passenger's
power window.

• The rear passenger's control can-

not operate the rear passengers'
power window.

• To prevent possible damage to

the power window system, do
not open or close two windows
or more at the same time. This
will also ensure the longevity of
the fuse.

• Never try to operate the main

switch on the driver's door and
the individual door window
switch in opposite directions at
the same time. If this is done, the
window will stop and cannot be
opened or closed.

NOTICE

OHI046031

Do not allow children to play
with the power windows. Keep
the driver’s door power window
lock switch in the LOCK posi-
tion. Serious injury or death can
result from unintentional win-
dow operation by a child.

WARNING

Remote window opening/
closing function

You can still control the window
movement with the engine turned off
by pressing the door lock button (1)
for more than 3 seconds. The window
moves (up or down), as long as you
press the door lock button. The win-
dow movement stops, when you
release the door lock button. The
hazard warning lights blink 3 times,
when the window is completely
closed.

Information

• The remote window opening/ clos-

ing function may abruptly stop,
when you move away from your
vehicle during the operation. Stay in
close proximity of your vehicle,
while monitoring the window move-
ment.

• One of the windows may stop oper-

ating, when the window is interrupt-
ed by certain force. However, the
other windows will keep operating.
Thus, you should make sure that all
windows are closed, and that the
hazard warning lights blink 3 times.

i

3-27

03

OHI046001L

If your vehicle is equipped with a
sunroof, you can slide or tilt your sun-
roof with the sunroof control lever
located on the overhead console.

The sunroof can only be opened,
closed, or tilted when the Engine Start/
Stop button is in the ON position.

Information

• In cold and wet climates, the sun-

roof may not work properly due to
freezing conditions.

• After washing the car or after there

is rain, be sure to wipe off any water
that is on the sunroof before operat-
ing it.

Do not continue to move the sun-
roof control lever after the sunroof
is fully open, closed, or tilt.
Damage to the motor or system
components could occur.

Information

The sunroof cannot slide when it is in
the tilt position nor can it be tilted
while in an open or slide position.

Sliding the sunroof

Pressing the sunroof control lever
backward or forward momentarily to
the second detent position completely
opens or closes the sunroof even
when the switch is released. To stop
the sunroof at the desired position
while the sunroof is in operation, press
the sunroof control lever backward or
forward and release the switch.
The sunroof can also be opened or
closed by pressing the sunroof con-
trol lever backward or forward to the
first detent position. But the sunroof
opens or closes only when you press
the sunroof control lever.

i

NOTICE

i

S

SU

UN

NR

RO

OO

OF

F  ((IIF

F  E

EQ

QU

UIIP

PP

PE

ED

D))

3-28

Convenient features of your vehicle

OHI046037

Never adjust the sunroof or sun-
shade while driving. This could
result in loss of control and an
accident that may cause death,
serious injury, or property dam-
age.

WARNING

OHI046038

Automatic reversal

If an object or part of the body is
detected while the sunroof is closing
automatically, it will reverse direction,
and then stop.
The auto reverse function does not
work if a tiny obstacle is between the
sliding glass and the sunroof sash.
You should always check that all pas-
sengers and objects are away from
the sunroof before closing it.

Tilting the sunroof

To open the sunroof, push the sun-
roof control lever upward to the sec-
ond detent. The sunroof will tilt all the
way open.
To stop the sunroof tilting at any
point, operate the control lever.

To close the sunroof, push the sunroof
control lever forward until the sunroof
moves to the desired position.

• Periodically remove dirt accu-

mulation over the sunroof guide
rails or between the sunroof and
roof panel, which may cause a
noise.

• Do not attempt to open the sun-

roof, when a temperature is
below the freezing point, or when
the sunroof is covered with snow
or ice. Otherwise, the motor may
be damaged. In a cold and wet
temperature, the sunroof may not
properly operate.

• To prevent damage to the sun-

roof and the motor, do not con-
tinuously press the sunroof con-
trol lever, after it is fully opened,
closed or tilted.

NOTICE

3-29

03

OHI046039

OHI046040

• Make sure heads, other body

parts or other objects are
safely out of the way before
closing the sunroof to avoid
injuries or vehicle damage.

• Never adjust the sunroof or

sunshade while driving. This
may cause loss of vehicle con-
trol resulting in an accident.

• To avoid serious injury or

death, do not extend your
head, arms or body outside the
sunroof while driving.

WARNING

3-30

Convenient features of your vehicle

Sunshade

The sunshade will automatically open
with the glass panel when the glass
panel moves. Close it manually if you
want it closed.

Resetting the sunroof

Sunroof needs to be reset if (in the
followings)
- Battery is discharged or disconnect-

ed or the related fuse has been
replaced or disconnected.

- The one-touch sliding function of the

sunroof does not normally operate.

1.Turn the Engine Start/Stop button

to the ON position and close the
sunroof completely.

2.Release the control lever.
3.Pull and hold the control lever for-

ward until the sunroof tilts and
slightly moves up and down. Then,
release the lever.

4.Pull and hold the control lever for-

ward until the sunroof is operated
as follows;

TILT DOWN

→

SLIDE OPEN

→

SLIDE CLOSE

Then, release the control lever.

If you do not reset the sunroof
when the vehicle battery is dis-
connected or discharged, or relat-
ed fuse is blown, the sunroof may
operate improperly.

NOTICE

OHI046041

Opening the hood

1. Park the vehicle and set the park-

ing brake.

2. Pull the release lever to unlatch

the hood. The hood should pop
open slightly.

3. Raise the hood slightly, push the

secondary latch up (1)  inside of
the hood center and lift the hood
(2). After it has been raised about
halfway, it will raise completely by
itself.

Closing the hood

1. Before closing the hood, check the

following:

• All filler caps in engine compart-

ment must be correctly installed.

• Gloves, rags or any other com-

bustible material must be removed
from the engine compartment.

2. Lower the hood halfway (lifted

approximately 30cm from the
closed position) and push down to
securely lock in place. Then dou-
ble check to be sure the hood is
secure.

H

HO

OO

OD

D

3-31

03

OHI046032

OHI046033

• Before closing the hood,

ensure all obstructions are
removed from around hood
opening.

• Always double check to be

sure that the hood is firmly
latched before driving away.
Check there is no hood open
warning light or message dis-
played on the instrument clus-
ter. Driving with the hood
opened may cause a total loss
of visibility, which might result
in an accident.

• Do not move the vehicle with

the hood in the raised posi-
tion, as vision is obstructed,
which might result in an acci-
dent, and the hood could fall
or be damaged.

WARNING

T

TR

RU

UN

NK

K

3-32

Convenient features of your vehicle

Non-Powered trunk
(if equipped)

To open:
1. Do one of the following :

- Press the smart key Trunk Unlock

button for more than one second.

- Press the button on the trunk

itself with the Smart Key in your
possession.

- Use the mechanical key.

- Use the trunk release button.

2. Lift the trunk lid up.

To close:
Lower the trunk lid and press down
until it locks.

To prevent damage to the trunk lift
cylinders and the attached hard-
ware, always close the trunk
before driving.

Information

In cold and wet climates, trunk lock
and trunk mechanisms may not work
properly due to freezing conditions.

i

NOTICE

OHI046016

■ Outside

OHI046017

■ Inside

Always keep the trunk lid com-
pletely closed while the vehicle is
in motion. If it is left open or ajar,
poisonous exhaust gases con-
taining carbon monoxide (CO)
may enter the vehicle and seri-
ous illness or death may result.

WARNING

The trunk swings upward. Make
sure no objects or people are
near the rear of the vehicle
when opening the trunk.

WARNING

3-33

03

Power trunk (if equipped)

(1) Power Trunk Main Control button

(2) Power Trunk Open button

(3) Power Trunk Close button

(4) Power Trunk Lock button

To open:
Do one of the following :
- Press the smart key Trunk Unlock

button for more than one second.

- Press the Open button (2) on the

trunk. You need the smart key in
your possession, when all doors
are locked.

- Press the Power Trunk Main

Control button (1).

To close:
Do one of the following:
- Press the Power Trunk Main

Control button (1) until the Power
Trunk is closed securely.

- Press the Close button (3) on the

trunk.

- Press the Lock button (4) on the

trunk while carrying the smart key
with all the vehicle’s doors closed.
All doors will lock and arm the theft
alarm system.

If you push a button or switch while
the trunk is opening or closing, it
could stop moving. Press any button
to operate the Power Trunk again.

OHI046018

OHI046019

OHI046020N

OHI046021N

3-34

Convenient features of your vehicle

Information

The Power Trunk Lock button will
not work if you press the button when:
- Any door is open.
- The Engine Start/Stop button is not

in the OFF position.

- The Smart Key is in the vehicle.

• Do not close or open the Power

Trunk manually. This may cause
damage to the Power Trunk. If it
is necessary to close or open the
Power Trunk manually when the
battery is drained or disconnect-
ed, do not apply excessive force.

• Do not leave the Power Trunk

open for a long period of time.
This may drain the battery.

• To prevent damage to the trunk

lift cylinders and the attached
hardware, always close the trunk
before driving.

Information

In cold and wet climates, trunk lock
and trunk mechanisms may not work
properly due to freezing conditions.

Power trunk non-opening or
closing conditions:

• The Power Trunk will not open or

close automatically, when the vehi-
cle is moving more than 3 km/h (1.8
mph).

• The Power Trunk can be operated

when the engine is not running.
However, the Power Trunk operation
consumes large amounts of vehicle
electric power. To prevent the bat-
tery from draining, do not operate it
excessively (e.g., more than
approximately 10 times repeatedly.)

• Do not modify or repair any part of

the Power Trunk by yourself. This
must be done by an authorized
retailer of Genesis Branded prod-
ucts.

• Before jacking up the vehicle to

change a tire or repair the vehicle,
open the Power Trunk. Do not oper-
ate the Power Trunk when the vehi-
cle is raised or this could cause the
Power Trunk to operate improperly.

i

NOTICE

i

Never leave children or animals
unattended in your vehicle.
Children or animals might oper-
ate the power trunk that could
result in injury to themselves or
others, or damage to the vehicle.

WARNING

Always keep the trunk lid com-
pletely closed while the vehicle is
in motion. If it is left open or ajar,
poisonous exhaust gases con-
taining carbon monoxide (CO)
may enter the vehicle and seri-
ous illness or death may result.

WARNING

Make sure there are no people
or objects around the trunk
before opening or closing the
Power Trunk. Wait until the trunk
is open fully and stopped
before loading or unloading
cargo from the vehicle.

WARNING

• If there are obstacles such as snow

on the Power Trunk, it may not open
automatically. After removing the
obstacle, try to open it again.

Automatic stop and reverse

If, during power opening or closing,
the trunk is blocked by an object or
part of someone’s body, the power
trunk will detect the resistance and it
will stop movement or move to the
full open position to allow the object
to be cleared.
However, if the resistance is weak
such as from an object that is thin or
soft, or the trunk is near the latched
position, the automatic stop and
reversal may not detect the resist-
ance and the closing operation will
continue. Also, if the Power Trunk is
forced by a strong impact, the auto-
matic stop and reversal may operate.
If the automatic stop and reverse fea-
ture operates more than twice during
one opening or closing operation, the
Power Trunk may stop at that posi-
tion. If this occurs, close the trunk
manually and operate the trunk auto-
matically again.

To reset the power trunk

If the battery has been discharged or
disconnected, or if the related fuse
has been replaced or disconnected,
reset the Power Trunk as follows:
1. Move the shift lever to the P (Park)

position.

2. Close the trunk manually.
If the Power Trunk doesn't work prop-
erly after performing the above pro-
cedure, have the system checked by
an authorized retailer of Genesis
Branded products.

3-35

03

OHI046022N

To prevent serious injury and
damage take the following pre-
cautions when operating the
power trunk:
- Keep all faces, hands, arms,

body parts and other objects
away from the path of the
power trunk.

- Do not intentionally place any

body parts or objects in the
path of the power trunk to
make sure the automatic stop
and reversal operates.

- Do not allow children to play

with the power trunk.

WARNING

Trunk lid control button

When the trunk lid control button is in
the UNLOCK (button not pressed)
position, the power trunk can be con-
trolled with the power trunk main
control button, power trunk open,
close button, and the smart key.
When this trunk lid control button is in
the LOCK (button pressed) position,
the power trunk can be controlled
using the mechanical key of the
smart key only.
The smart trunk does not operate,
when the trunk lid control button is
pressed to the LOCK position.
Even though the trunk lid control but-
ton is in the LOCK (button pressed)
position, the trunk will still be pro-
pelled upward by mechanical force if
the trunk is manually opened more
than 10 degrees beyond the fully
closed position. In addition, if the
trunk is manually closed to the sec-
ondary latch position, the trunk will
be electrically moved to the fully
latched position.

Close the trunk, and keep the
trunk lid control button in the
LOCK (button pressed) position
before washing the vehicle in an
automatic car wash.

Information

If the trunk lid control button is in
LOCK position, the Smart Trunk sys-
tem will also be deactivated.

i

NOTICE

3-36

Convenient features of your vehicle

OHI046009

• Always keep the Trunk Lid

Control Button in the LOCK
(button pressed) position when
not in use. Serious injury or
death can result from uninten-
tional operation by a child.

• Make sure heads, other body

parts or other obstacles are
safely out of the way before
operating the power trunk.

WARNING

Emergency trunk safety
release

Your vehicle is equipped with an
Emergency Trunk Safety Release
lever located inside the trunk. When
someone is inadvertently locked in
the trunk, the trunk can be opened by
moving the lever in the direction of the
arrow and pushing the trunk open.

3-37

03

OHI046023N

• You and your passengers

must be aware of the location
of the Emergency Trunk Safety
Release lever in this vehicle
and how to open the trunk in
case you are accidentally
locked in the trunk.

(Continued)

WARNING

(Continued)
• NEVER allow anyone to occupy

the trunk of the vehicle at any
time. If the trunk is partially or
totally latched and the person
is unable to get out, serious
injury or death could occur due
to lack of ventilation, exhaust
fumes and rapid heat build-up,
or because of exposure to cold
weather conditions. The trunk
is also a highly dangerous loca-
tion in the event of a crash
because it is not a protected
occupant space but is a part of
the vehicle’s crush zone.

• Your vehicle should be kept

locked and the Smart Key
should be kept out of the
reach of children. Parents
should teach their children
about the dangers of playing
in trunks.

• Use the release lever for emer-

gencies only.

S

SM

MA

AR

RT

T  T

TR

RU

UN

NK

K  ((IIF

F  E

EQ

QU

UIIP

PP

PE

ED

D))

3-38

Convenient features of your vehicle

On a vehicle equipped with a smart
key, the trunk can be opened with no-
touch activation using the Smart
Trunk system.

How to use the Smart Trunk

The trunk can be opened with no-
touch activation satisfying all the
conditions below.
• After 15 seconds when all doors

are closed and locked

• Positioned in the detecting area for

more than 3 seconds.

Information

• The Smart Trunk does not operate

when:
- The smart key is detected within

15 seconds after the doors are
closed and locked, and is continu-
ously detected.

- The smart key is detected within

15 seconds after the doors are
closed and locked, and 1.5 m from
the front door handles. (for vehi-
cles equipped with Welcome Light)

- A door is not locked or closed.
- The smart key is in the vehicle.

1. Setting
To activate the Smart Trunk, go to
User Settings mode and select
Smart Trunk on the LCD display.
For more information, refer to "LCD
Display" in this chapter.

2. Detect and Alert
If you are positioned in the detecting
area (50 ~100 cm behind the vehi-
cle) carrying a smart key, the hazard
warning lights will blink and chime
will sound for about 3 seconds to
alert you the smart key has been
detected and the trunk will open.

i

OHI046024N

OHI046025

OHI046195L

Information

Do not approach the detecting area if
you do not want the trunk to open. If
you have unintentionally entered the
detecting area and the hazard warn-
ing lights and chime starts to operate,
leave the detecting area with the smart
key. The trunk will stay closed.

3. Automatic opening
The hazard warning lights will blink
and chime will sound 2 times and
then the trunk will slowly open.
The smart trunk does not operate,
when the trunk lid control button is
pressed to the LOCK position.

How to deactivate the Smart
Trunk function using the smart
key

1. Door lock
2. Door unlock
3. Trunk open

If you press any button of the smart
key during the Detect and Alert
stage, the Smart Trunk function will
be deactivated.
Make sure to be aware of how to
deactivate the Smart Trunk function
for emergency situations.

i

3-39

03

OHI046026

OHI046004L

• Make sure you close the trunk

before driving your vehicle.

• Make sure there are no people

or objects around the trunk
before opening or closing the
trunk.

• Make sure objects in the trunk

do not come out when open-
ing the trunk on a slope. It
may cause serious injury.

(Continued)

(Continued)
• Make sure to deactivate the

Smart Trunk when washing
your vehicle. Otherwise, the
trunk may open inadvertently.

• The key should be kept out of

reach of children. Children
may inadvertently open the
Smart Trunk while playing
around the rear area of the
vehicle.

WARNING
