Yanmar diesel tractor EF494T. OPERATOR'S MANUAL - part 9

EF494T OM

32

  Clogging or dirt in air filter.








  Tension or damage of cooling fan belt.







Check the radiator grill and engine room for dust.






  Check electrical wiring for wear of sheath and loose

joints.






(4) Sitting on the operator’s seat.


  Effect and play in the brake.


(A) Play 30-40mm







EF494T OM

33

  Play in the steering wheel.


(A): Play 20-50mm



  Effect and play in the clutch pedal.


(A): Play 15-25mm



(5) Start the engine:


  Check for abnormal sound.




  Color of exhaust gas.


(A) What color?



  Function of lamps and meters.








EF494T OM

34

2.

Breaking in the engine (first 50

hours)

The new tractor should be operated carefully for the first
50 hours. This will have a large positive effect on the
lifetime and performance of the tractor throughout its
life. Pay particular attention to the following points:
(1) Refrain from abrupt starts and stops.
(2) Do not use a speed higher than necessary and do

not load the machine more than necessary.

(3) Begin operation only after the engine has warmed

up sufficiently.

(4) Slow down on rough roads or slopes.
(5) Check the tractor thoroughly after breaking it in for

the first 50 hours.





3.

Starting and stopping engine



WARNING

  Before starting the engine, sit in the driver's seat

and make sure the levers and controls are within
the reach for safe operation. Negligence will
cause a serious injury.

  Do not start the engine in a closed room. Start the

engine outdoor where the good ventilation is
available. If you are forced to start the engine in a
confined room, make sure the ventilation is
proper. Gas oxidation can lead to death.



 WARNING

  Before and after operation, never fail to check and

service the machine. Particular check will be
required at the clutch, brake pedals and controls,
and steering devices. Negligence can cause a
serious injury to the operator and/or damage to
the machine.

  Engage the parking brake during the warm-up

operation. Otherwise the tractor may abruptly start
to run.


NOTE:
In cold season, pay a special attention to the warm-up
for adequate operation of the hydraulic system.


Temperature

Warm-up operation

0 ~ -10°C

more than 10 min

-10 ~ -20°C

more than 20 min

< -20°C

more than 30 min









EF494T OM

35

Starting



CAUTION

Do not start the engine if the position control lever is not
in the LOW position. The implement may abruptly raise
causing a damage or injury to the human and machine.

(1) Set the fuel filter and water separator to "O" to open

the fuel cock.



(A) Fuel cock open
(B) Fuel cock close










(2) Put the main and range shift levers, reverse lever

and PTO shift lever in the N position.

(3) Set the position control lever in LOW.




(4) Put the accelerator lever in the TOP position. Fully

depress the clutch pedal and turn the main switch to
START.

(5) After the engine has started, immediately release the

main switch.





IMPORTANT

* The engine cannot be started without putting both the

main and PTO shift levers in the N position.
