Electrical system

239

8

WARNING: Always use specific personal safety devices
for each operation.

IMPLEMENT CABLE ACCESS

Access is provided for implement cables in the right hand
corner of the rear window.

To fit cables:

OPERATION 1

Open the rear window and remove the rubber grommet
by pulling upward.

OPERATION 2

Cut the grommet down (1) into the centre of the circle
area and then cut out the centre (2) to fit the cable(s).

OPERATION 3

Fit the grommet over the cable(s) and install the grommet
and cable(s) into the slots in the cab.

OPERATION 4

Close the rear window.

Electrical system

240

Page left intentionally blankf

Technical specifications

241

9

Section 9

Technical specifications

ARGO TRACTORS constantly updates its range of products and
therefore reserves the right to undertake modifications, if appro-
priate ad necessary, without prior notice.
All data and information contained in this publication could be
subject to changes.
Dimensions and weights are only approximate values and the
equipment shown by the pictures could not correspond to stan-
dard models.
Precise data and information about models and equipment are
available at your ARGO TRACTORS Dealer.

Technical specifications

242

APPROXIMATE TRACTOR DIMENSIONS

IMPORTANT: The dimensions shown on the following pages are only approximate. They depend on many factors, such as
tyre size, ballast, amount of fuel, tyre pressure etc.
ALL dimensions are in mm.

The above mentioned dimensions are rough values, as they may change according to tyres.

NOTE: Overall width of the tractor may change according to the type of axle and to the track width settings.

NOTE: (only for EEC Member States): An overall width of 2,500 mm to 3,000 mm (8 to 10 feet) MAY REQUIRE local au-
thorization for use on the highway. An overall width over 3,000 mm (10 feet) a local authorization is MANDATORY.

DIMENSIONS in mm













De Luxe Cab

A - Height at cab roof

2710

Height may change according to tyres

B - Wheelbase

2440

C - Overall length
(Front ballast - Hitch lower links)

4460

D - Ground clearance (max.)

480

under pick-up hitch

345

E - Width
- Min. - max., front

1837-2319

- Min. - max., rear

2092-2492

F - Front and rear track adjustment

See track tables

Approximate weight of tractor:

kg

4200
