167

Maintenance

7

Section 7

Maintenance

168

Maintenance

RECOMMENDATIONS BEFORE YOU SERVICE

 [4.1.h]

WARNING:  Before  servicing,  carefully  read
the instructions in this section. There is a risk
of injury or death if servicing is not carried
out  or  if  the  following  instructions  are  not
followed correctly. If you do not understand
a service or adjustment procedure, see your
dealer.
Before any adjustments are made carry out
the following:
1. Park the tractor on hard level ground and

apply the parking brake.

2. Stop the engine and remove the key.
3. Put blocks in front of and behind the front

and rear wheels.

WARNING:Do not carry out inspections, main-
tenance work or adjustments on the tractor
whilst  the  engine  is  running,  except  when
specifically  requested.  Wait  for  all  moving
parts to come to a complete stop.
- If the maintenance operation must be car-
ried  out  while  the  engine  is  hot  (e.g.  when
changing engine oil), start the engine and let
it idle for the required time, then turn it off
before the maintenance operation.
- If you need to open the bonnet, follow the
procedure  indicated  under  “How  to  open
the bonnet”. In this case beware the risk of
burning and shearing.
- Always use specific personal safety devices
for each service operation.

WARNING:  When  handling  lubricants  (oil,
grease  etc.)  and  other  chemical  products,
always  follow  instructions  for  their  proper
use.  Use  proper  containers  to  collect  fluid.
Dispose of fluids and filters responsibly and
in accordance with the law. DO NOT smoke
or use an open flame during the service pro-
cedure. Use eye protection.

- Read the safety decals and information decals on this
tractor. Read the operator's manual. Understand the op-
eration of the tractor before you start servicing.

- Use the correct safety clothing and safety equipment.
If you wear clothing that is too loose or do not use the
correct safety equipment for your job, you can be injured.
Always wear clothing that will not catch on objects. Extra
safety equipment that can be required includes hard hat,
safety shoes, ear protection, eye or face protection, heavy
gloves and reflector clothing.
- Establish where your nearest first aid kit and fire extin-
guisher are located. Undertake suitable training to make
sure you know how the fire extinguisher works.

- Put a warning tag, as shown below, on or near the key
switch before carrying out servicing or repairs to the trac-
tor. Warning tags are available from your dealer.

Environment

NOTE: Always dispose of replaced parts or substances
(filters, oil, battery etc.) according to rules and laws. Re-
fer to the manufacturer’s specifications on the Material
Safety Data Sheet.

Before you service this machine and before you dispose
of  the  old  fluids,  lubricants  and  filters  always  consider
the environment.

DO NOT pour oil or fluids in the ground, down drains or
into containers that can leak.

Dispose of all old fluids, lubricants and filters in accord-
ance with local regulations.

Check with your local environmental recycling center or
your dealer for correct information.

Plastic And Resin Parts

Avoid  using  petrol,  paraffin,  paint  thinner,  etc.,  when
cleaning plastic, e.g. console, instrument cluster, moni-
tors and gauges etc.

Use ONLY water, mild soap and a soft cloth when you
clean these parts.

Using petrol, paraffin, paint thinner etc., will cause crack-
ing or deformation of the part being cleaned.

169

Maintenance

7

SERVICE ACCESS

Access for inspection and mainte-
nance

WARNING: In particular cases it may be re-
quired that an operation is carried out with
open  bonnet  and  running  engine.  In  such
cases, pay special attention to moving and
hot parts, wear the required personal safety
devices  and  work  only  with  the  minimum
number of persons strictly required for the
operation.

WARNING: All the surfaces inside the bonnet
are hot. High burning danger. Be extremely
careful  and  wait  for  the  surfaces  to  cool
down before operating inside the bonnet to
avoid burns.

WARNING:  Danger  of  shearing.  Open  the
bonnet and remove the side panel only with
engine off and rotating parts completely at
standstill.

WARNING: A gas ram controls opening and
closing of the bonnet. Replace the gas ram if
not properly operating to avoid accidental
fall of the bonnet.

WARNING: If the tractor is equipped with front
hitch and power take-off, before opening the
bonnet  lower  the  links  completely,  whether
there are implements or not.

How to open the bonnet

Park the tractor on hard, level ground, engage the first
gear, engage the parking brake, turn the engine off and
remove the ignition key.

- To open the bonnet, insert the tool (1) in the front slit
and hook up the bonnet closure device.
- Release the locking mechanism.
- Release the bonnet (2) and push the front upward kee-
ping clear until the hood is fully raised. The gas strut will
hold the bonnet in the upright position.

IMPORTANT: When opening the bonnet in windy condi-
tions, put the front of the tractor towards the wind with
the back of the tractors against the wind direction.

- To close, pull the cable and push the front down hard
to close.
- Remove the tool.

WARNING: Replace all covers or guards remo-
ved, close the bonnet and close any service
access doors after servicing or cleaning this
machine.  NEVER  operate  the  machine  with
any  covers  or  guards  removed  or  with  the
bonnet or service door open.

170

Maintenance

TOOL BOX

The tool box (if equipped) is located in front of the front
part of the cab.

The tool box can be removed by removing the retaining
pin, located at the centre back of the tool box. Lift the
tool box from the bottom outwards and upwards.

The tool box position may vary according to tractor model.
