Section 09 REAR SUSPENSION Subsection 01 (SC SUSPENSION) NOTE: If necessary, to ease shock removal, un- Remove rear shock absorber. A33F59B 2 1 TYPICAL REAR SHOCK ABSORBER Installation is the reverse of removal procedure. CAUTION: Take care not to damage grease fit- Respect the following tightening torque specifica- DESCRIPTION TIGHTENING TORQUE Shock upper and lower nut 19.5 N•m (173 lbf•in) FRONT SHOCK ABSORBER Lift rear of vehicle and support it off the ground. Unfasten one end of stopper strap(s) or loosen the A32E19B 1 SUMMIT LIQUID COOLED MODELS Unbolt front shock from the top. Remove the front idler wheels to gain access to Unbolt axle screws and slide out axle to remove A33F5EA 1 2 3 TYPICAL FRONT SHOCK ABSORBER Installation is the reverse of removal procedure. Respect the following tightening torque specifica- mmr2005-094 387 |
