Section 04 FUEL SYSTEM Pilot Jet Use narrow screwdriver from carburetor tool kit Throttle Slide WARNING It is critical to the free operation of the throttle Do not disassemble throttle slide no. 17 needless- CAUTION: After throttle slide reassembly, pro- Disassemble both carburetors at the same time. Remove carburetor cover. Loosen needle retainer screw no. 8. Fully open throttle and hold in this position for the Move aside needle retainer no. 9. 1 A32C6TA 1. Needle retainer moved aside Turn dual carburetor assembly upside down to 1 A32C3RA 1. Plastic washer Unscrew throttle slide cover screws no. 13. Open throttle 3/4 wide and keep that opening. Lift throttle slide covers bottom first until they are 2 A32C2OA 1 1. Lift bottom first Remove circlip no. 14 retaining throttle slide. 188 mmr2005-077 |
