Section 04 FUEL SYSTEM Air Screw Adjustment Completely close the air screw no. 6 (until a slight A02C09B 1 1. Air screw NOTE: Turning screw in clockwise enriches mix- CARBURETOR AIR SCREW VM-30 213 (377 engine) 2.0 turns VM-34–617 (552 engine) 2.0 turns Throttle Slide Height Hook throttle cable into the needle retainer plate. NOTE: Do not obstruct hole in throttle slide when A00C1TA 1 2 3 CENTER POST TYPE Make sure the nylon packing no. 4 is installed on CAUTION: Serious engine damage can occur if 2 3 4 5 1 A00C3MA CENTER POST TYPE Using a drill bit, adjust throttle slide height (see Throttle slide height is measured on outlet side of NOTE: Make sure that throttle cable does not hold 180 mmr2005-077 |
