9-128
SHOCK ABSORBER USAGE GUIDE
Below is a list of shock absorbers used on the front and rear suspensions of many Arctic Cat snowmobiles.
Specifications given for each shock absorber include collapsed and extended length, stroke, and both rebound and
compression valving ratings.
When using the shock absorber guide, always select a shock absorber with the same length, both collapsed and
extended. Shock valving selection will depend on personal preference.
P/N
Collapsed
Length
Extended
Length
Stroke
0603-555
9.410”
13.540”
4.13”
0604-599
7.060”
10.100”
3.04”
1604-101
7.670”
11.420”
3.75”
0603-117
7.060”
10.030”
2.97”
1603-253
10.840”
16.300”
5.46”
1604-455
9.560”
15.010”
5.45”
1604-369
8.420”
12.490”
4.07”
0703-997
11.470”
17.990”
6.52”
0703-996
11.470”
17.990”
6.52”
0703-929
11.470”
17.990”
6.52”
0703-825
11.470”
17.990”
6.52”
0703-824
11.470”
17.990”
—
0703-810
11.470”
16.900”
5.43”
0703-756
10.300”
15.300”
5.00”
0703-753
11.470”
17.990”
6.52”
0704-760
10.050”
14.450”
4.40”
0704-758
8.070”
11.270”
3.20”
0704-743
9.890”
14.490”
4.60”
0704-738
7.970”
11.220”
3.25”
0704-712
7.990”
11.650”
3.66”
0704-635
7.340”
10.860”
3.52”
0704-617
7.970”
11.220”
3.25”
0704-530
9.880”
14.350”
4.47”
0704-529
9.880”
14.350”
4.47”
0704-519
8.070”
11.270”
3.20”
0704-518
10.050”
14.450”
4.40”
0704-512
9.890”
14.490”
4.60”
1703-199
12.600”
19.300”
6.71”
0704-903
7.970”
11.220”
3.25”
0704-906
9.890”
14.530”
4.64”
1703-208
12.660”
18.860”
6.15”
1703-209
12.660”
18.860”
6.15”
0704-930
7.980”
11.630”
3.60”
