8-62
AL141D
4. Place the console into position and secure with
four screws making sure all wiring harnesses are
positioned under the console.
NOTE: Secure wiring harnesses and cables to
the steering post with cable ties as noted in
removing.
5. Connect the end of the brake cable to the seat of
the brake lever.
AL140D
6. Secure the brake cable to the bracket by tightening
the jam nut.
AF462D
7. Secure the brake lever with the pin, washer, and
retaining ring.
AL138D
AL137D
8. Secure the handlebar pad to the handlebar with the
Phillips-head screws.
9. Apply Handlebar Grip Adhesive (p/n 0636-071) to
the bore of the handlebar grip; then using a rubber
hammer, drive the grip into position.
! WARNING
The handlebar adhesive is extremely flammable.
The product contains acetone and the vapors, when
released, can be easily ignited. Keep away from
heat, sparks, and open flame. Use only in a well-
ventilated area. Avoid prolonged breathing of
vapor. Avoid eye and skin contact. Keep container
closed when not in use.
