SLIDE RAIL SUSPENSION

10. Install:

• Stopper band 1

NOTE:

• Install the stopper band with

a toward the front

pivot arm and

b toward the shaft.

• Install the stopper band with

c toward the rear

pivot arm and

d toward the rear pivot arm

bracket.

È FX10/FX10RT/FX10RTR/FX10RTRA (front side)
É FX10/FX10RT/FX10RTR/FX10RTRA (rear side)
Ê FX10MT/FX10MTR/FX10MTRA

T



R

.

.

Stopper band nut:

4 Nm (0.4 m · kg, 2.9 ft · lb)

a

b

1

È

c

d

1

É

a

1

b

Ê

4-66

POWR

TR

SLIDE RAIL SUSPENSION

INSTALLATION

1. Adjust:

• Track tension

Refer to “TRACK TENSION ADJUSTMENT”
in CHAPTER 2.

Control rod part numbers
(FX10MT/FX10MTR/FX10MTRA)

Ó Standard position Ô Metal washer(s) Õ Plastic washer(s)

È Control rod 1

É Length a mm (in)

Ê Length b mm (in)

Ë Length c mm (in)

FX10MT/FX10MTR/

FX10MTRA

238.3 (9.38)

199.7 (7.86)

2.5P

× 2 = 5

(0.098P

× 2 = 0.197)

Ì Control rod 1

part number

Í Control rod stopper

part number

ΠWasher part numbers

Ï Washer thickness mm (in)

РUpper

Ò Q’ty

Ñ Lower

Ò Q’ty

8HA-4745A-00

(FX10MT/FX10MTR/

FX10MTRA)

8ES-4745D-00

90202-25001

2.0 (0.079)

1

90202-25001

2.0 (0.079)

1

90201-24015

2.0 (0.079)

1

c

a

b

Ï

Ï

Ð

Í

Ì

Ó

Ñ

Ô

Õ

4-67

POWR

TR

FRONT AXLE AND TRACK

FRONT AXLE AND TRACK

Order

Job name/Part name

Q’ty

Remarks

Front axle and track removal

Remove the parts in the order listed below.

Drive chain

Refer to “DRIVE CHAIN”.

Slide rail suspension

Refer to “SLIDE RAIL SUSPENSION”.

Secondary sheave

Refer to “SECONDARY SHEAVE”.

1

Speed sensor

1

2

Bearing housing

1

3

Gear unit

1

4

Set bolt

2

5

Bearing

1

6

Bearing housing

1

7

Bearing housing

1

8

Circlip

1

9

Bearing

1

10

Front axle assembly

1

11

Spacer

1

12

Track

1

For installation, reverse the removal proce-
dure.

1

2

3

5

6

11

10

4

4

7

9

8

12

Ë

É

É

Ê

Ê

É

(3)

New

New

New

È

È

LT

LT

FX10MT/
FX10MTR/
FX10MTRA

9 Nm (0.9 m

•

 kg, 6.5 ft

•

 lb)

È:

40 Nm (4.0 m

•

 kg, 29 ft

•

 lb)

Ë:

24 Nm (2.4 m

•

 kg, 17 ft

•

 lb)

É:

30 Nm (3.0 m

•

 kg, 22 ft

•

 lb)

Ê:

4-68

POWR

TR

FRONT AXLE AND TRACK

INSPECTION

1. Inspect:

• Track 1
• Slide metal 2

Wear/cracks/damage

→ Replace.

1

2

2. Inspect:

• Sprocket wheels 1

Wear/break/damage

→ Replace.

• Front axle 2

Bends/scratches (excessive)/damage

→

Replace.

È FX10/FX10RT/FX10RTR/FX10RTRA
É FX10MT/FX10MTR/FX10MTRA

3. Inspect:

• Bearing

Pitting/damage

→ Replace.

1

2

È

1

2

É

INSTALLATION

1. Install:

• Oil seal 1

NOTE:

Press the oil seal onto the bearing housing as
shown.

È 2.5 ~ 3.5 mm (0.10 ~ 0.14 in)

1

È
