3-14

CHAS

STEERING

• Loosen the steering shaft locknuts 5.
• Adjust the steering shaft 6 by turning so that

the pivot arm point right under.

• Tighten the steering shaft locknuts 5.

• Adjust each angle of right and left skis by turn-

ing the tie rod respectively.

• Measure the ski toe-out.

Refer to “STEERING SYSTEM” in CHAPTER 2.

Turning the steering
shaft in direction

a

Turning the ski in
direction

c

Turning the steering
shaft in direction

b

Turning the ski in
direction

d

T



R

.

.

Steering shaft locknut:

25 Nm (2.5 m · kg, 18 ft · lb)
LOCTITE

®

b

a

5

6

d

c

F

W

D

7. Install:

For FX10RT/FX10RTR/FX10RTRA
• Steering joint 1
• Steering joint holders 2

NOTE:

• Install the steering joint with the shallow cutout

a

facing forward.

• Align the centerline of the steering joint with the

centerline of the steering column 3 as shown in
the illustration.

• The steering joint holders should be installed

with punch marks

b facing forward.

CAUTION:

First, tighten the bolts on the front side of the
steering joint holder, and then on the rear side.

a

1

FWD

2

1

b

3

3-15

CHAS

STEERING

8. Install:

• Handlebar 1
• Handlebar holders 2

NOTE:

• The handlebar holders should be installed with

the punch marks

a facing forward.

• Align the punch mark

b on the handlebar with

the upper surface of the lower handlebar holder.
(FX10)

• Align the punch mark

b on the handlebar with

the upper surface of the steering joint. (FX10RT/
FX10RTR/FX10RTRA/FX10MT/FX10MTR/
FX10MTRA)

CAUTION:

First, tighten the bolts on the front side of the
handlebar holder, and then on the rear side.

9. Install:

For FX10/FX10RT/FX10RTR/FX10RTRA
• Wind deflector bracket holder 1
• Wind deflector bracket 2

NOTE:

Align the end of the wind deflector bracket with the
punch mark

a on the handlebar.

T



R

.

.

Handlebar holder bolt:

23 Nm (2.3 m · kg, 17 ft · lb)

a

b

1

2

2

1

a

10. Install:

• Handlebar protector 1 (FX10/FX10RT/

FX10RTR/FX10RTRA/FX10MTRA)

NOTE:

Install the handlebar cover 1, making sure not to
pinch the cables, leads, etc.

11. Adjust:

• Throttle cable free play
Refer to “THROTTLE CABLE FREE PLAY
ADJUSTMENT”
 in CHAPTER 2.

1

3-16

CHAS

SKI

SKI

FX10/FX10RT/FX10RTR/FX10RTRA

Order

Job name/Part name

Q’ty

Remarks

Ski removal

Remove the parts in the order listed below.

The following procedure applies to both of the
ski.

1

Cotter pin

1

2

Nut

1

3

Bolt

1

4

Collar

1

5

Collar

1

6

Washer

2

7

Collar

1

8

Ski stopper

1

9

Ski

1

For installation, reverse the removal proce-
dure.

8

12 Nm (1.2 m

 kg, 8.7 ft

 lb)

È:

17 Nm (1.7 m

 kg, 12 ft

 lb)

É:

48 Nm (4.8 m

 kg, 35 ft

 lb)

Ë:

19 Nm (1.9 m

 kg, 13 ft

 lb)

Ê:

3-17

CHAS

SKI

FX10MT/FX10MTR/FX10MTRA

Order

Job name/Part name

Q’ty

Remarks

Ski removal

Remove the parts in the order listed below.

The following procedure applies to both of the
ski.

1

Cotter pin

1

2

Nut

1

3

Bolt

1

4

Collar

1

5

Collar

1

6

Washer

2

7

Collar

1

8

Ski stopper

1

9

Ski

1

For installation, reverse the removal proce-
dure.

8

12 Nm (1.2 m

 kg, 8.7 ft

 lb)

È:

17 Nm (1.7 m

 kg, 12 ft

 lb)

É:

48 Nm (4.8 m

 kg, 35 ft

 lb)

Ë:

19 Nm (1.9 m

 kg, 13 ft

 lb)

Ê:
