3-18

CHAS

SKI

INSPECTION

The following procedure applies of all of the skis
and related components.

1. Inspect:

• Ski
• Ski runner
• Ski stopper
• Ski handle

Wear/cracks/damage

→ Replace.

• Mounting bolt
• Collars

Wear/damage

→ Replace.

3-19

CHAS

FRONT SUSPENSION

FRONT SUSPENSION

FX10/FX10RT/FX10RTR/FX10RTRA

Order

Job name/Part name

Q’ty

Remarks

Front suspension removal

Remove the parts in the order listed below.

The following procedure applies to both of the
front suspension.

Lower cover/Front bumper

Refer to “COVERS”.

Ski

Refer to “SKI”.

1

Shock absorber

1

FX10

2

Shock absorber

1

FX10RT/FX10RTR/FX10RTRA

3

Collar

1

FX10

4

Tie rod

1

Disconnect.

5

Steering knuckle

1

6

Upper arm ball joint

1

7

Upper arm

1

8

Collar

1

9

Bushing

2

10

Pivot arm cover

1

11

Stabilizer holder

1

12

Bushing

1

Ê

Ë

Ë

É

É

11

1

2

3

8

9

7

12

9

13

18

14

17

15

Ê

Ê

É

6

È

Ë

5

Ê

Ì

Ê

4

17

16

16

10

New

New

LT

90 Nm (9.0 m

•

 kg, 65 ft

•

 lb)

Ì:

65 Nm (6.5 m

•

 kg, 47 ft

•

 lb)

Ë:

45 Nm (4.5 m

•

 kg, 32 ft

•

 lb)

Ê:

34 Nm (3.4 m

•

 kg, 24 ft

•

 lb)

É:

28 Nm (2.8 m

•

 kg, 20 ft

•

 lb)

È:

3-20

CHAS

FRONT SUSPENSION

Order

Job name/Part name

Q’ty

Remarks

13

Stabilizer joint

1

14

Stabilizer

1

15

Lower arm

1

16

Collar

2

17

Bushing

4

18

Lower arm ball joint

1

For installation, reverse the removal proce-
dure.

Ê

Ë

Ë

É

É

11

1

2

3

8

9

7

12

9

13

18

14

17

15

Ê

Ê

É

6

È

Ë

5

Ê

Ì

Ê

4

17

16

16

10

New

New

LT

90 Nm (9.0 m

•

 kg, 65 ft

•

 lb)

Ì:

65 Nm (6.5 m

•

 kg, 47 ft

•

 lb)

Ë:

45 Nm (4.5 m

•

 kg, 32 ft

•

 lb)

Ê:

34 Nm (3.4 m

•

 kg, 24 ft

•

 lb)

É:

28 Nm (2.8 m

•

 kg, 20 ft

•

 lb)

È:

3-21

CHAS

FRONT SUSPENSION

FX10MT/FX10MTR/FX10MTRA

Order

Job name/Part name

Q’ty

Remarks

Front suspension removal

Remove the parts in the order listed below.

The following procedure applies to both of the
front suspension.

Lower cover/Front bumper

Refer to “COVERS”.

Ski

Refer to “SKI”.

1

Shock absorber

1

2

Collar

1

3

Tie rod

1

Disconnect.

4

Steering knuckle

1

5

Upper arm ball joint

1

6

Upper arm

1

7

Collar

1

8

Bushing

2

9

Pivot arm cover

1

10

Stabilizer holder

1

11

Bushing

1

Ê

Ë

Ë

É

1

2

7

8

6

8

12

17

13

16

14

Ê

Ê

É

5

È

Ë

4

Ì

Ê

3

16

15

15

9

New

New

LT

Ê

É

10

11

90 Nm (9.0 m

•

 kg, 65 ft

•

 lb)

Ì:

65 Nm (6.5 m

•

 kg, 47 ft

•

 lb)

Ë:

45 Nm (4.5 m

•

 kg, 32 ft

•

 lb)

Ê:

34 Nm (3.4 m

•

 kg, 24 ft

•

 lb)

É:

28 Nm (2.8 m

•

 kg, 20 ft

•

 lb)

È:
