106

MAINTENANCE

Track Maintenance

Track Alignment

Periodically check that the track is centered and running evenly on the
slide rails. Misalignment will cause excessive wear to the track and slide
rail.

1. Safely support the rear of the snowmobile with the track off the

ground.

2. Start the engine and apply a small amount of throttle until the track

turns slowly at least five complete revolutions. Stop the engine and
let the track come to a stop (do not apply brakes).

3. Inspect track alignment by

looking through the track
window to make sure the
rails are evenly spaced on
each side. If the track runs
to the left, loosen the idler
shaft bolts, then loosen the
left locknut and tighten the
left adjusting bolt. If the
track runs to the right,
loosen the idler shaft bolts,
then loosen the right lock-
nut and tighten the right
adjusting bolt.

4. After adjustments are com-

plete, tighten the locknuts
and torque idler shaft bolts
to 35 ft. lbs. (47.5 Nm).

5. Repeat steps 2 and 3 to verify proper alignment.

Rail

107

MAINTENANCE

Steering System

Steering Inspection

Each week, or before a long ride, check all steering system fasteners and
tighten if necessary.

x

x

x

x

108

MAINTENANCE

Steering System

Ski Alignment

WARNING! Improper ski alignment or adjustment may cause loss of steering
control, resulting in serious injury or death. Do not attempt to change the ski
alignment or camber adjustment. See your POLARIS dealer.

1. Place the handlebars in a straight-ahead position.
2. With only vehicle weight compressing the suspension, measure

10 inches (25.4 cm) forward from the center of the ski mounting
bolt. See illustration. At this point, measure between the skis. This is
measurement X.

3. Perform the same measurement rearward from the center of the ski

mounting bolt. This is measurement Y.

4. The X measurement should be 1/8-1/4 inch (3-6 mm) greater than

the Y measurement. If the skis are misaligned, see your dealer for
alignment correction as camber adjustment may also be affected.

X

Y

10 in.

(25.4 cm)

10 in.

(25.4 cm)

109

MAINTENANCE

Steering System

Ski Skags

WARNING! Worn skis and/or skags will adversely affect handling. Loss of
vehicle control may result, causing serious injury or death. See your dealer's
studding chart for recommended skags. If you install longer or more aggressive
carbide skags than the original equipment, it may also be necessary to add track
studs to maintain proper vehicle control while turning on hard-packed snow or
ice.

Check skags before each use of the snowmobile to ensure positive steer-
ing characteristics. Skags must be replaced when worn to half their orig-
inal diameter.

TIP: Carbide skags must be replaced if any abnormal wear or chipping is found.

Skag Replacement

1. Raise and support the front of the

snowmobile so the skis are
approximately 6 inches (15.2 cm)
from the ground.

2. Remove the attaching nuts and pry

the skag downward.

3. Remove the front end of the skag.

4. Remove the rear end of the skag.

5. Reverse the steps to install a skag.

Rail Slide Wear

For ease of inspection, all
POLARIS rail slides have
a wear limit indicator
groove to indicate the min-
imum permissible slide
thickness. Replace the rail
slides if they are worn to
the top of the groove at any
point along their length.
Failure to do so may result
in permanent damage to
the track or rails.

Skag

Replace when

worn to top of

groove

Minimum

Thickness
