MC Acadia Owner (2023 year). Manual in english

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

161

Navigation destinations can be made in a
single command using keywords. A few
examples are:

“

I want directions to an

address,

” “

I need to find a place of

interest or (POI),

”

“

Find contact.

”

The system responds by requesting more
details. For other POIs, say the name of a
category like

“

Restaurants,

” “

Shopping

Malls,

”

“

Hospitals.

”

Navigating to a destination outside of the
current country takes more than one
command. The first command is to tell
the system where the navigation will take
place, such as an Address, Intersection,
POI, or Contact. If Address or Intersection
is selected, the second command is to
say,

“

Change Country.

”

Once the system

responds, say the country before saying
the rest of the address and/or
intersection.
If POI is asked for, say

“

Change Location,

”

then

“

Change Country.

”

Direct commands might be more clearly
understood by the system. An example of a
direct command would be

“

Call <number>.

”

Examples of these direct commands are
displayed on most of the screens while a
voice session is active. If

“

Phone

”

“

Phone

Commands,

”

is spoken, the system

understands that a phone call is requested
and will respond with questions until
enough details are gathered to make a call.

If a cell phone number has been saved with
a name and a place, the direct command
should include both, for example

“

Call

<name> at work.

”

Using Voice Recognition for List Options

When a list is displayed, a voice prompt will
ask to confirm or select an option from
that list.

When a display contains a list, there may be
options that are available but not displayed.
The list on a voice recognition screen
functions the same as a list on other
displays. Scrolling or flinging can be used to
help display other entries from the list.

Manually scrolling or paging the list on a
display during a voice recognition session
suspends the current voice recognition event
and plays the prompt

“

Please select

manually or touch the Back icon on the
infotainment display to try again.

”

If manual selection takes more than
15 seconds, the session terminates and
prompts that it has timed out. The display
returns to the display where voice
recognition was initiated.

The Back Command

Say

“

Back

”

or touch the Back icon on the

infotainment display to go to the
previous menu.

If in voice recognition, and

“

Back

”

is spoken

all the way back to the starting display, and
then

“

Back

”

is spoken one more time, the

voice recognition session will cancel.

Help

Say

“

Help

”

on any voice recognition display

and the help prompt for the display is
played.

Voice Recognition for the Radio

If browsing the audio sources when voice is
touched, the voice recognition commands
for AM, FM, and SiriusXM (if equipped) are
available.

“

Switch to AM

”

Switch bands to AM and

tune to the last AM radio station.

“

Switch to FM

”

Switch bands to FM and

tune to the last FM radio station.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

162

Infotainment System

“

Switch to SXM

”

Switch bands to SiriusXM

and tune to the last SiriusXM channel.

“

Tune to <AM frequency> AM

”

Tune to

the radio station whose frequency is
identified in the command (like

“

nine fifty

”

“

Tune to <FM frequency> FM

”

Tune to the

radio station whose frequency is identified
in the command (like

“

one oh one

point one

”

“

Tune to <AM frequency> AM HD

”

Tune

to the HD Radio station (if equipped) whose
frequency is identified in the command.

“

Tune to <FM frequency> FM HD

”

Tune to

the HD Radio station (if equipped) whose
frequency is identified in the command.

“

Tune to <FM frequency> FM HD <HD

channel number>

”

Tune to the HD Radio

station (if equipped) whose frequency and
HD channel are identified in the command.

“

Tune to SXM <SXM channel number>

”

Tune to the SiriusXM radio station whose
channel number is identified in the
command.

“

Tune to SXM <SXM channel name>

”

Tune

to the SiriusXM radio station whose channel
name is identified in the command.

Voice Recognition for Audio MyMedia

The available voice recognition commands
for [browsing] MyMedia are:

“

Play Artist

”

Begin a dialog to enter a

specific artist name.

“

Play Artist <artist name>

”

Begin playback

of a specific artist.

“

Play Album

”

Begin a dialog to enter a

specific album name.

“

Play Album <album name>

”

Begin

playback of a specific album.

“

Play Song

”

Begin a dialog to enter a

specific song name.

“

Play Song <song name>

”

Begin playback

of a specific song, if available.

“

Play Genre

”

Begin a dialog to enter a

specific genre.

“

Play Genre <genre name>

”

Begin

playback of a specific genre.

“

Play Playlist

”

Begin a dialog to enter a

specific playlist name.

“

Play Playlist <playlist name>

”

Begin

playback of a specific playlist.

“

Play <device name>

”

Play music from a

specific device identified by name. The
device name is the name displayed on the
display when the device is first selected as
an audio source.

“

Play Chapter

”

Begin a dialog to enter a

specific name.

“

Play Chapter <chapter name>

”

Begin

playback of a specific chapter.

“

Play Audiobook

”

Begin a dialog to enter

a specific audiobook.

“

Play Audiobook <audiobook name>

”

Begin playback of a specific audiobook.

“

Play Episode

”

Begin a dialog to enter a

specific name.

“

Play Episode <episode name>

”

Begin

playback of a specific episode.

“

Play Podcast

”

Begin a dialog to enter a

specific podcast.

“

Play Podcast <podcast name>

”

Begin

playback of a specific podcast.

“

My Media

”

Begin a dialog to enter the

desired media content.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

163

Handling Large Amounts of Media Content

It is expected that large amounts of media
content will be brought into the vehicle.
It may be necessary to handle large
amounts of media content in a different
way than smaller amounts of media. The
system may limit the options of voice
recognition by not allowing selection of files
by voice at the highest level if the number
of files exceeds the maximum limit.

Changes to voice commands due to media
content limits are:

Files including other individual files of all
media types such as songs, audiobook
chapters, podcast episodes, and videos.

Album type folders including types such
as albums and audiobooks.

There are no restrictions if the number of
files and albums is fewer than 12,000. When
the number of files connected to the system
is between 12,000 and 24,000, the content
cannot be accessed directly with one
command like

“

Play <song name>.

”

The restriction is that the command

“

Play

Song

”

must be spoken first; the system will

then ask for the song name. The reply
command would be to say the name of the
song to play.

Similar limits exist for album content.
If there are more than 12,000 albums, but
fewer than 24,000, the content cannot be
accessed directly with one command like,

“

Play <album name>.

”

The command

“

Play

Album

”

must first be spoken; the system

will then ask for the album name. The reply
would be to say the name of the album
to play.

Once the number of files has exceeded
approximately 24,000, there is no support
for accessing the songs directly through
voice commands. There will still be access to
the media content by using commands for
playlists, artists, and genres.

The access commands for playlists, artists,
and genres are prohibited after the number
of this type of media exceeds 12,000.

The system will provide feedback the first
time voice recognition is initiated if it has
become apparent that any of these limits
are reached during a device initializing
process.

Voice recognition performance will degrade
to some extent based on many factors when
adding large amounts of data to recognize.
If this is the case, perhaps accessing songs
through playlists or artist name would work
better.

Voice Recognition for Navigation (If
Equipped)

“

Navigation

”

Begin a dialog to enter

specific destination information.

“

Navigation Commands

”

Begin a dialog to

enter specific destination information.

“

Address

”

Begin a dialog to enter a

specific destination address, which includes
the entire address consisting of the house
number, street name, city, state/province,
and country. Do not include the ZIP code.

“

Place of Interest

”

Begin a dialog to enter

a destination Place of Interest category or
major brand name.

The name must be precisely spoken.
Nicknames or short names for the
businesses will not likely be found. Lesser
known businesses might have to be located
by category, such as fast food, hotels,
or banks.

“

Navigate to Contact

”

Begin a dialog to

enter a specific destination contact name.

“

Cancel Route

”

End route guidance.

“

Take Me Home

”

Create a route to a

stored home location.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

164

Infotainment System

Voice Recognition for the Phone

“

Call <contact name>

”

Initiate a call to a

stored contact. The command may include
location if the contact has location numbers
stored.

“

Call <contact> At Home,

” “

At Work,

” “

Mobile,

”

“

On Other

”

Initiate a call to a

stored contact and location at home, at
work, on mobile device, or on another
phone.

“

Call <cell phone number>

”

Initiate a call

to a cell phone number of seven digits, 10
digits, or three digit emergency numbers.

“

Pair Phone

”

Begin the Bluetooth pairing

process. Follow the instructions on the
infotainment display.

“

Redial

”

Initiate a call to the last dialed

number.

“

Switch Phone

”

Select a different

connected cell phone for outgoing calls.

“

Voice Keypad

”

Begin a dialog to enter

special numbers like international numbers.
The numbers can be entered in groups of
digits with each group of digits being
repeated back by the system. If the group
of digits is not correct, the command

“

Delete

”

will remove the last group of digits

and allow them to be re-entered. Once the
entire number has been entered, the
command

“

Call

”

will start dialing the

number.

Phone Assistant Voice Recognition

Press and hold

on the steering wheel

controls to pass through and launch Google
phone assistant or Siri.

For the low radio, whether connected by
Bluetooth or phone projection, the only
available voice recognition is either Siri
(iPhone) or the Google Assistant (Android).

Phone

Bluetooth (Overview)

The Bluetooth-capable system can be paired
with up to 10 Bluetooth devices and two
active Bluetooth devices, allowing:

Placement and receipt of calls in a
hands-free mode.

Sharing of the device

’

s address book or

contact list with the vehicle.

To minimize driver distraction, before
driving, and with the vehicle parked:

Become familiar with the features of the
mobile device. Organize the phone book
and contact lists clearly and delete
duplicate or rarely used entries.
If possible, program speed dial or other
shortcuts.

Review the controls and operation of the
infotainment system.

Pair mobile device(s) to the vehicle. The
system may not work with all mobile
devices. See

“

Pairing

”

later in this section.

Vehicles with a Bluetooth system can use a
Bluetooth-capable mobile device with a
Hands-Free Profile to make and receive
phone calls. The infotainment system and
voice recognition are used to control the
system. The system can be used while the
ignition is on or in accessory mode. The
range of the Bluetooth system can be up to
9.1 m (30 ft). Not all mobile devices support
all functions and not all mobile devices work
with the Bluetooth system. Visit your brand
website for more information about
compatible mobile devices. See

Online

Account

353

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

165

Controls

Use the controls on the center stack and the
steering wheel to operate the Bluetooth
system.

Steering Wheel Controls

Press to answer incoming calls and start

voice recognition on your connected
Bluetooth mobile device.

Press to end a call, decline a call,

or cancel an operation. Press to mute or
unmute the infotainment system when not
on a call.

Infotainment System Controls

For information about how to navigate the
menu system using the infotainment
controls, see

Overview

136

Audio System

When using the Bluetooth mobile device
system, sound comes through the vehicle's
front audio system speakers and overrides
the audio system. The volume level while on
a mobile device call can be adjusted by
pressing the steering wheel controls or the
volume control on the center stack. The

adjusted volume level remains in memory
for later calls. The volume cannot be
lowered beyond a certain level.

Bluetooth (Pairing and Using a
Phone)

Pairing

A Bluetooth-enabled mobile device must be
paired to the Bluetooth system and then
connected to the vehicle before it can be
used. See the mobile device manufacturer's
user guide for Bluetooth functions before
pairing the device.

Pairing Information

If no mobile device has been connected,
the Phone main page on the infotainment
display will show the Connect Phone
option. Touch this option to connect.
Another way to connect is to touch the
Phones tab at the top right of the display
and then touch Add Phone.

A Bluetooth smartphone with music
capability can be paired to the vehicle as
a smartphone and a music player at the
same time.

Up to 10 devices can be paired to the
Bluetooth system.

The pairing process is disabled when the
vehicle is moving.

Pairing only needs to be completed once,
unless the pairing information on the cell
phone changes or the cell phone is
deleted from the system.

If multiple paired cell phones are within
range of the system, the system connects
to the paired cell phone that is set to
First to Connect. If there is no cell phone
set to First to Connect, it will link to the
cell phone which was used last. To link to
a different paired cell phone, see

“

Linking

to a Different Phone

”

later in this section.

Pairing a Phone

1. Make sure Bluetooth has been enabled

on the cell phone before the pairing
process is started.

2. Touch the Phone icon on the Home Page

or the phone icon on the shortcut tray
near the bottom of the display.

3. Touch Phones at the top of the

infotainment display. There is also a
Connect Phones option in the middle of
the Phone display which will shortcut to
the Phone List menu.

4. Touch Add Phone.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

166

Infotainment System

5. Select the vehicle name shown on the

infotainment display from your cell
phone

’

s Bluetooth Settings list.

6. Follow the instructions on the cell phone

to confirm the six-digit code showing on
the infotainment display and touch Pair.
The code on the cell phone and
infotainment display will need to be
acknowledged for a successful pair.

7. Start the pairing process on the cell

phone to be paired to the vehicle. See
the cell phone manufacturer's user guide
for information on this process. Once the
cell phone is paired, it will show under
Connected.

8. If the vehicle name does not appear on

your cell phone, there are a few ways to
start the pairing process over:

Turn the cell phone off and then
back on.

Go back to the beginning of the
Phone menus on the infotainment
display and restart the pairing
process.

Reset the cell phone, but this step
should be done as a last effort.

9. If the cell phone prompts to accept

connection or allow phone book
download, touch Always Accept and
Allow. The phone book may not be
available if not accepted.

10. Repeat Steps 1

−

8 to pair additional cell

phones.

First to Connect Paired Phones

If multiple paired cell phones are within
range of the system, the system connects to
the paired cell phone that is set as First to
Connect. To enable a paired cell phone as
the First to Connect phone:

1. Make sure the cell phone is turned on.
2. Touch Settings, then touch System.
3. Touch Phones to access all paired and all

connected cell phones and mobile
devices.

4. Touch the information icon or pencil icon

to the right of the cell phone to open
the cell phone

’

s settings menu.

5. Touch the First to Connect option, to

enable the setting for that device.

Cell phones and mobile devices can be
added, removed, connected, and
disconnected. A sub-menu will display
whenever a request is made to add or
manage cell phones and mobile devices.

Secondary Phone

A cell phone can be enabled as a Secondary
Phone by touching the information icon to
the right of the paired cell phone name to
open the phone settings menu. If a cell
phone is enabled as a Secondary Phone, it
can connect simultaneously alongside
another Bluetooth mobile device. In doing
so, the Secondary Phone will be labeled as
Incoming Calls. This means the mobile
device can only receive calls. The Address
Book of a Secondary Phone will not be
available and hands-free outgoing calls
cannot be placed using this cell phone.

If needed, touch the Secondary Phone while
in the Phones list to swap it into the
Outgoing and Incoming role. This role makes
it possible to place outgoing calls from the
Contacts and Recents list.

Listing All Paired and Connected Phones

1. Touch the Phone icon on the Home Page

or the phone icon on the shortcut tray
near the bottom of the display.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

167

2. Touch Phones.

Disconnecting a Connected Phone

1. Touch the Phone icon on the Home Page.
2. Touch Phones.
3. Touch the information icon or the pencil

icon next to the connected cell phone or
mobile device to show the cell phone

’

or mobile device

’

s information display.

4. Touch Disconnect.

Deleting a Paired Phone

1. Touch the Phone icon on the Home Page

or the phone icon on the shortcut tray
near the bottom of the display.

2. Touch Phones.
3. Touch the information icon or the pencil

icon next to the connected cell phone to
display the cell phone

’

s or mobile

device

’

s information display.

4. Touch Forget Device.

Linking to a Different Phone

To link to a different cell phone, the new
cell phone must be in the vehicle and paired
to the Bluetooth system.

1. Touch the Phone icon on the Home Page

or the phone icon on the shortcut tray
near the bottom of the display.

2. Touch Phones.
3. Touch the new cell phone to link to from

the not connected phone list. See

“

First

to Connect Paired Phones

”

and

“

Secondary Phone

”

previously in this

section.

Switching to Handset or
Handsfree Mode

To switch between handset or
handsfree mode:

While the active call is hands-free, touch
the Handset option to switch to the
handset mode.
The mute icon will not be available or
functional while Handset mode is active.

While the active call is on the handset,
touch the Handset option to switch to the
hands-free mode.

Making a Call Using Contacts and Recent
Calls

Calls can be made through the Bluetooth
system using personal cell phone contact
information for all cell phones that support
the Phone Book feature. Become familiar
with the cell phone settings and operation.
Verify the cell phone supports this feature.

The Contacts menu accesses the phone book
stored in the cell phone.

The Recents menu accesses the recents call
list from your cell phone.

To make a call using the Contacts menu:

1. Touch the Phone icon on the Home Page.
2. Touch Contacts.
3. The Contacts list can be searched by

using the first character. Touch A-Z on
the infotainment display to scroll
through the list of names.
Touch the name to call.

4. Touch the desired contact number to call.

To make a call using the Recents menu:

1. Touch Phone on the Home Page.
2. Touch Recents.
3. Touch the name or number to call.

Making a Call Using the Keypad

To make a call by dialing the numbers:

1. Touch the Phone icon on the Home Page.
2. Touch Keypad and enter a phone

number.

3. Touch

on the infotainment display to

start dialing the number.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

168

Infotainment System

Searching Contacts Using the Keypad

To search for contacts using the keypad:

1. Touch the Phone icon on the Home Page.
2. Touch Keypad and enter partial phone

numbers or contact names using the
digits on the keypad to search.
Results will show on the right side of the
display. Touch one to place a call.

Accepting or Declining a Call

When an incoming call is received, the
infotainment system mutes and a ring tone
is heard in the vehicle.

Accepting a Call

There are two ways to accept a call:

Press

on the steering wheel controls.

Touch Answer on the infotainment
display.

Declining a Call

There are two ways to decline a call:

Press

on the steering wheel controls.

Touch Ignore on the infotainment display.

Call Waiting

Call waiting must be supported on the
Bluetooth cell phone and enabled by the
wireless service carrier to work.

Accepting a Call

Press

to answer, then touch Switch on

the infotainment display.

Declining a Call

Press

to decline, then touch Ignore on

the infotainment display

Switching Between Calls (Call Waiting
Calls Only)

To switch between calls, touch Phone on the
Home Page to display Call View. While in
Call View, touch the call information of the
call on hold to change calls.

Three-Way Calling

Three-way calling must be supported on the
Bluetooth cell phone and enabled by the
wireless service carrier to work.

To start a three-way call while in a
current call:

1. In the Call View, touch Add Call to add

another call.

2. Initiate the second call by selecting from

Recents, Contacts, or Keypad.

3. When the second call is active, touch the

merge icon to conference the three-way
call together.

Ending a Call

Press

on the steering wheel controls.

Touch

on the infotainment display,

next to a call, to end only that call.

Dual Tone Multi-Frequency (DTMF) Tones

The in-vehicle Bluetooth system can send
numbers during a call. This is used when
calling a menu-driven phone system. Use the
Keypad to enter the number.

Apple CarPlay and Android Auto

If equipped, Android Auto and/or Apple
CarPlay capability may be available through
a compatible smartphone. If available, the
Android Auto and Apple CarPlay icons will
change from gray to color on the Home
Page of the infotainment display.

To use Android Auto and/or Apple CarPlay:

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

169

For Wired Phone Projection

1. Download the Android Auto app to your

smartphone from the Google Play store.
There is no app required for Apple
CarPlay.

2. Connect your Android phone or Apple

iPhone by using the factory-provided
phone USB cable and plugging into a
USB data port. For best performance, it is
highly recommended to use the device

’

factory-provided USB cable, which should
be replaced after significant wear to
maintain connection quality. Aftermarket
or third-party cables may not work.

3. When the phone is first connected to

activate Apple CarPlay or Android Auto,
accept the terms and conditions on both
the infotainment system and the phone.

4. Follow the instructions on the phone.

The Android Auto and Apple CarPlay icons
on the Home Page will illuminate depending
on the smartphone. Android Auto and/or
Apple CarPlay may automatically launch
upon USB connection. If not, touch the
Android Auto or Apple CarPlay icon on the
Home Page to launch.

Press

{

on the center stack to return to the

Home Page.

For Wireless Phone Projection

If equipped, verify your phone is wireless
compatible by visiting the Google Android
Auto or Apple CarPlay support page.

1. Download the Android Auto app to your

smartphone from the Google Play store.
There is no app required for Apple
CarPlay.

2. For first time connection, there are two

ways to set up wireless projection:

Connect your Android phone or Apple
iPhone by using the factory-provided
phone USB cable and plugging into a
USB data port. For best performance,
it is highly recommended to use the
device

’

s factory-provided USB cable,

which should be replaced after
significant wear to maintain
connection quality. Aftermarket or
third-party cables may not work.

Connecting the phone over Bluetooth.
See

Bluetooth (Pairing and Using a

Phone)

165

Bluetooth (Overview)

164

3. Make sure wireless is turned on the

phone for wireless projection to work.

4. When the phone is first connected to

activate Apple CarPlay or Android Auto,
agree to the terms and conditions on
both the infotainment system and the
phone.

5. Follow the instructions on the phone.

The Android Auto and Apple CarPlay icons
on the Home Page will illuminate depending
on the smartphone. Android Auto and/or
Apple CarPlay may automatically launch
upon wireless connection. If not, touch the
Android Auto or Apple CarPlay icon on the
Home Page to launch.

Wireless Carplay and/or Wireless Android
Auto may experience occasional service
disruption due to outside Wi-Fi interference.

To disconnect the phones wireless
projection:

1. Select Settings from the Home Page.
2. Select Phones

3. Touch

or the pencil icon next to the

phone to be disconnected.

4. Turn off Apple CarPlay or Android Auto.

Press

{

on the center stack to return to the

Home Page.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

170

Infotainment System

Features are subject to change. For further
information on how to set up Android Auto
and Apple CarPlay in the vehicle, visit your
brand website. See

Online Account

353

for

details.

Android Auto is provided by Google and is
subject to Google

’

s terms and privacy policy.

Apple CarPlay is provided by Apple and is
subject to Apple

’

s terms and privacy policy.

Data plan rates apply. For Android Auto
support and to see if your phone is
compatible, see https://support.google.com/
androidauto. For Apple CarPlay support and
to see if your phone is compatible, see
www.apple.com/ios/carplay/. Apple or
Google may change or suspend availability
at any time. Android Auto, Android, Google,
Google Play, and other marks are
trademarks of Google Inc.; Apple CarPlay is a
trademark of Apple Inc.

Press

{

on the center stack to exit Android

Auto or Apple CarPlay. To enter back into
Android Auto or Apple CarPlay, press and
hold

{

on the center stack.

Apple CarPlay and Android Auto can be
disabled from the infotainment system. To
do this, touch Home, Settings, and then

touch the Apps tab along the top of the
display. Use the On/Off toggled to turn off
Apple CarPlay or Android Auto.

Settings

Certain settings can be managed in the
Online Account sites when an account is
established, and may be modified if other
users have accessed the vehicle or created
accounts. This may result in changes to the
security or functionality of the infotainment
system. Some settings may also be
transferred to a new vehicle, if equipped. For
instructions, visit your brand website.

Refer to the User Terms and Privacy
Statement for important details. To view,
touch the Settings icon on the Home Page
of the infotainment display.

The settings menu may be organized into
four categories. Select the desired category
by touching System, Apps, Vehicle,
or Personal.

To access the personalization menus:

1. Touch Settings on the Home Page on the

infotainment display.

2. Touch the desired category to display a

list of available options.

3. Touch to select the desired feature

setting.

4. Touch the options on the infotainment

display to disable or enable a feature.

5. Touch

to go to the top level of the

Settings menu.

System

The menu may contain the following:

Time / Date

Allows setting of the clock.

Language

Sets the display language used on the
infotainment display. It may also use the
selected language for voice recognition and
audio feedback.

Phones

Allows connecting to a different cell phone
or mobile device source, disconnect a cell
phone or media device, or delete a cell
phone or media device.

Wi-Fi Networks

Shows connected and available Wi-Fi
networks.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

171

If a 4G LTE data package is not active on the
vehicle, the infotainment system can be
connected to an external protected Wi-Fi
network, such as a mobile device or home
hotspot, to utilize connected services.

Wi-Fi Hotspot

Allows adjustment of different Wi-Fi
features.

Privacy

Allows adjustment of the infotainment
privacy settings.

Display

Allows adjustment of the infotainment
display.

Sounds

Allows adjustment of the infotainment
system sounds.

Voice

Allows adjustment of the infotainment voice
recognition features.

Favorites

Allows adjustment of the infotainment
favorite settings.

Updates

If equipped, the vehicle can download and
install select software updates over a
wireless connection. The system will prompt
for certain updates to be downloaded and
installed. There is also an option to check
for updates manually.

To manually check for updates, touch
Settings on the Home Page and select the
System tab. Go to the Vehicle Software
section and touch Updates. Follow the
on-screen prompts. The steps to check for,
download, and install updates may vary by
vehicle.

The vehicle can be used normally during the
software download. Once the download is
complete, there may be a prompt to accept
the installation of the update upon the next
ignition cycle or the next time the vehicle is
shifted into P (Park). For most updates, the
vehicle will be disabled and cannot be driven
during the installation. The system will
deliver messages indicating success or error
during and after the download and
installation processes.

Downloading Over-the-Air vehicle software
updates requires Internet connectivity, which
can be accessed through the vehicle

’

built-in 4G LTE connection, if equipped and

active. If required, data plans are provided
by a third party. Optionally, a secure Wi-Fi
hotspot such as a compatible mobile device
hotspot, home hotspot, or public hotspot
can be used. Applicable data rates may
apply.

To connect the infotainment system to a
secured mobile device hotspot, home
hotspot, or public hotspot, touch Settings on
the Home Page, select the System tab,
followed by Wi-Fi Networks. Select the
appropriate Wi-Fi network, and follow the
on-screen prompts. Download speeds
may vary.

On most compatible mobile devices,
activation of the Wi-Fi hotspot is in the
Settings menu under Mobile Network
Sharing, Personal Hotspot, Mobile Hotspot,
or similar.

Availability of Over-the-Air software updates
varies by vehicle and country. Features are
subject to change. For more information on
this feature, see

Online Account

353

for

details.

Preferences

Allows the infotainment system to disable
or enable the download of new updates in
the background.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

172

Infotainment System

About

Shows the infotainment system software
information.

Running Applications

Shows a complete list of applications that
are currently running on the infotainment
system.

Return to Factory Settings

Allows resetting the infotainment system
settings in the vehicle.

Apps

The menu may contain the following:

Android Auto

Allows interacting directly with a mobile
device on the infotainment display. See

Apple CarPlay and Android Auto

168

Apple CarPlay

This feature allows you to interact directly
with your mobile device on the infotainment
display. See

Apple CarPlay and Android Auto

168

Apps

Shows app settings and information.

Audio

Adjusts different audio settings.

Climate

Adjusts different climate settings.

Navigation

Adjusts different navigation settings.

See

Using the Navigation System

148

Phone

Adjusts different phone settings.

Vehicle

The menu may contain the following:

Rear Seat Reminder

Allows for a chime and a message when the
rear door has been opened before or during
operation of the vehicle.

Climate and Air Quality

Adjusts different climate settings.

Collision/Detection Systems

Adjusts different driver assistance system
settings.

Comfort and Convenience

Adjusts different comfort and convenience
settings.

Lighting

Adjusts different lighting settings.

Power Door Locks

Adjusts different door lock settings.

Remote Lock, Unlock, and Start

Adjusts different remote lock settings.

Seating Position

Adjusts different seat settings.

Teen Driver

See

Teen Driver

173

Valet Mode

This will lock the infotainment system and
steering wheel controls. It may also limit
access to vehicle storage locations,
if equipped.

To enable valet mode:

1. Enter a four-digit code on the keypad.
2. Select Enter to go to the confirmation

screen.

3. Re-enter the four-digit code.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

173

Touch Lock or Unlock to lock or unlock the
system. Touch Back to go back to the
previous menu.

Personal

If equipped, this menu allows adjustment of
different user profile settings. See

“

Users

”

Using the System

138

for information on

setting up user profiles.

The menu may contain the following:

Name

Touch to edit your user name that will be
displayed in the vehicle.

Vehicle Account Information

Touch to view the vehicle account
information and to change the account
password.

“

unverified user account

”

pop-up will

display until the account information
verification process has been completed on
the Internet. Check your registered e-mail
account for an activation e-mail to complete
the verification process.

Profile Picture

Touch to choose or change your profile
picture.

Profile Identifiers

Touch to have the vehicle recognize the
identifier you choose.

Touch Vehicle Key 1 and/or Vehicle Key 2.

If the remote key is lost or stolen, see your
dealer.

Security

Touch to have your profile secured with
a PIN.

Touch No or Yes.

Vehicle Name

Touch to edit your vehicle name.

Vehicle Account

Touch to view the vehicle account
information and to change the account
password.

Delete Profile

Touch to remove the profile from the
vehicle.

Touch Remove or Cancel.

Teen Driver

If equipped, this allows multiple keys to be
registered for beginner drivers to encourage
safe driving habits. When the vehicle is
started with a Teen Driver key, it will
automatically activate certain safety
systems, allow setting of some features, and
limit the use of others. The Report Card will
record vehicle data about driving behavior
that can be viewed later. When the vehicle
is started with a registered key, the Driver
Information Center (DIC) displays a message
that Teen Driver is active.

To access:

1. Touch Settings on the Home Page, then

touch Vehicle, and then Teen Driver.

2. Create a Personal Identification Number

(PIN) by choosing a four-digit PIN.
Re-enter the PIN to confirm. To change
the PIN, touch Change PIN.

The PIN is required to:

Set up/Add or remove keys.

Change Teen Driver settings.

Change or clear the Teen Driver PIN.

Access or delete Report Card data.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

174

Infotainment System

Set up/Add keys to activate Teen Driver and
assign restrictions to the key:

Any vehicle key can be registered, up to a
maximum of eight keys. Label the key to
tell it apart from the other keys.

For a pushbutton start system:

1. Start the vehicle.
2. For automatic transmissions, the vehicle

must be in P (Park). For manual
transmissions, the vehicle must be
stopped with the parking brake set.

3. From the Settings menu, touch Vehicle

and then Teen Driver.

4. Enter the PIN.
5. Place the remote key you wish to

Remote Key

Operation

for transmitter pocket

location.

6. From the Teen Driver menu, touch Setup

Keys or Add/Remove Teen Driver Keys.

If the remote key has not previously
been registered, the option to add
the key displays. Touch Add and a
confirmation message displays. Teen

Driver restrictions will be applied
whenever this remote key is used to
operate the vehicle.

If the remote key has already been
registered, the option to remove the
key displays. If Remove is touched,
the remote key is no longer
registered. A confirmation message
displays, and Teen Driver restrictions
will not be applied if this remote key
is used to operate the vehicle.

In vehicles with a pushbutton start system,
if a Teen Driver and a non-Teen Driver key
are both present at start up, the vehicle will
recognize the non-Teen Driver key to start
the vehicle. The Teen Driver settings will not
be active.

For a keyed ignition system:

1. Start the vehicle.
2. For automatic transmissions, the vehicle

must be in P (Park). For manual
transmissions, the vehicle must be
stopped with the parking brake set.

3. From the Settings menu, touch Vehicle

and then Teen Driver.

4. Enter the PIN.

5. Touch Setup Keys or Add/Remove Teen

Driver Keys. The system displays
instructions for registering or
unregistering a key. A confirmation
message displays.

Manage Settings or Teen Driver Settings

Depending on the options of your vehicle,
the following menu items may be displayed:

Buckle to Drive :

When turned ON, Buckle to

Drive prevents the driver from shifting out
of P (Park) for a period of time after the
brake pedal is pressed if the driver, or on
some vehicles the detected passenger, has
not buckled their seat belt. On some
vehicles, Buckle to Drive is always ON when
Teen Driver is active and is not configurable.

Audio Volume Limit :

Allows a maximum

audio volume to be set. Turn the audio
volume limit on or off. Use the arrows to
choose the maximum allowable level for the
audio volume. On some infotainment
systems, touch Set Audio Volume Limit to
choose the maximum allowable audio
volume level.

Set Audio Volume Limit :

Use the arrows to

choose the maximum allowable level for the
audio volume.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

175

Teen Driver Speed Limiter :

Limits the

maximum speed of the vehicle. When the
speed limiter is turned on and the vehicle is
started with a Teen Driver key, the DIC
displays a message that the top speed is
limited.

On certain vehicles, when the Speed Limiter
is turned ON, the vehicle

’

s maximum

acceleration will be limited. The DIC will
display a message that the acceleration is
limited.

Teen Driver Speed Warning :

Displays a

warning in the DIC when exceeding a
selectable speed. Turn the speed warning on
or off and choose the desired speed warning
level. The speed warning does not limit the
speed of the vehicle. On some infotainment
systems, touch Set Teen Driver Speed
Warning to set the warning speed.

Set Teen Driver Speed Warning :

Choose the

desired speed warning level. The speed
warning does not limit the speed of the
vehicle.

SiriusXM Explicit Content Filter :

Allows the

SiriusXM Explicit Content Filter to be turned
ON or OFF. When ON, the teen driver will
not be able to listen to SiriusXM stations

that contain explicit content, and the Explicit
Content Filter selection in the Audio Settings
will be unavailable for change.

When Teen Driver is Active:

If equipped, the radio will mute when the
driver seat belt, and in some vehicles the
front passenger seat belt, is not buckled.
The audio from any device paired to the
vehicle will also be muted.

An object placed on the front passenger
seat, such as a briefcase, handbag,
grocery bag, laptop, or other electronic
device, could cause the passenger sensing
system to falsely sense an unbuckled
front passenger and mute the radio.
If this happens, remove the object from
the seat. See

Passenger Sensing System

Some safety systems, such as Automatic
Emergency Braking, if equipped, cannot
be turned off.

The gap setting for Adaptive Cruise
Control and alert timing for Forward
Collision Alert, if equipped, cannot be
changed.

When trying to change a safety feature
that is not configurable in Teen Driver,
the feature may be grayed out or
removed from the infotainment menu,

or the DIC will display a message
indicating that Teen Driver is active and
the action is not available.

Super Cruise, if equipped, is not available.

Enhanced Low Fuel Warning (if equipped)

–

When the vehicle is low on fuel, the

low fuel light on the instrument cluster
flashes and the DIC low fuel warning
cannot be dismissed.

Do not tow a trailer if equipped with
Automatic Emergency Braking.

Report Card

The vehicle owner must secure the driver

’

consent to record certain vehicle data when
the vehicle is driven with a registered Teen
Driver key. There is one Report Card per
vehicle. Data is only recorded when a
registered Teen Driver key is used to
operate the vehicle.

The Report Card data is collected from the
time Teen Driver is activated or the last
time the Report Card was reset. The
following items may be recorded:

Distance Driven

–

the total distance

driven.

Maximum Speed

–

the maximum vehicle

speed detected.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

176

Infotainment System

Overspeed Warnings

–

the number of

times the speed warning setting was
exceeded.

Wide Open Throttle

–

the number of

times the accelerator pedal was pressed
nearly all the way down.

Forward Collision Alerts (if equipped)

–

the number of times the driver was
notified when approaching a vehicle
ahead too quickly and at potential risk for
a crash.

Forward Automatic Braking, also called
Automatic Emergency Braking (if
equipped)

–

the number of times the

vehicle detected that a forward collision
was imminent and applied the brakes.

Reverse Automatic Braking (if equipped)

–

the number of times the vehicle detected
that a rearward collision was imminent
and applied the brakes.

Traction Control

–

the number of times

the Traction Control System activated to
reduce wheel spin or loss of traction.

Stability Control

–

the number of events

which required the use of electronic
stability control.

Antilock Braking System Active

–

The

number of Antilock Brake System
activations.

Tailgating Alerts (if equipped)

–

the

number of times the driver was alerted
for following a vehicle ahead too closely.

Report Card Data

Cumulative Data is saved for all trips until
the Report Card is reset or until the
maximum count is exceeded. If the
maximum count is exceeded for a Report
Card line item, that item will no longer be
updated in the Report Card until it is reset.
Each item will report a maximum of
1,000 counts. The distance driven will report
a maximum of 64 374 km (40,000 mi).

To delete Report Card data, do one of the
following:

From the Report Card display, touch
Reset.

Touch Clear PIN and All Teen Driver Keys
from the Teen Driver menu. This will also
unregister any Teen Driver keys and
delete the PIN.

Forgotten PIN

See your dealer to reset the PIN.

Trademarks and License
Agreements

FCC Information

See

Radio Frequency Statement

359

Radio Frequency Statement

359

"Made for iPhone," means that an electronic
accessory has been designed to connect
specifically to iPhone, and has been certified
by the developer to meet Apple
performance standards. Apple is not
responsible for the operation of this device
or its compliance with safety and regulatory
standards. Please note that the use of this
accessory with iPhone may affect wireless
performance. iPhone are trademarks of
Apple Inc., registered in the U.S. and other
countries.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

177

If you decide to continue service after your
trial, your selected subscription plan will
automatically renew thereafter. You will be
charged at then-current rates. Fees and taxes
apply. Please see the SiriusXM Customer
Agreement at siriusxm.com for complete
terms and how to cancel, which includes
calling SiriusXM at 1-866-635-2349. All fees
and programming are subject to change.

Fees and Taxes: Subscription fee, taxes, one
time activation fee, and other fees may
apply. Subscription fee is consumer only. All
fees and programming subject to change.
Subscriptions subject to Customer
Agreement available at www.siriusxm.com.
SiriusXM service is only available in the
48 contiguous United States and Canada.

In Canada: Some deterioration of service
may occur in extreme northern latitudes.
This is beyond the control of SiriusXM
Satellite Radio.

Explicit Language Notice: Channels with
frequent explicit language are indicated with
an

“

”

preceding the channel name.

Channel blocking is available for SiriusXM
Satellite Radio receivers by notifying
SiriusXM:

USA Customers

—

See www.siriusxm.com

or call 1-888-601

–

6296.

Canada Customers

—

See

www.siriusxm.ca or call 1-877-438-9677.

It is prohibited to copy, decompile,
disassemble, reverse engineer, hack,
manipulate, or otherwise make available any
technology or software incorporated in
receivers compatible with the SiriusXM
Satellite Radio System or that support the
SiriusXM website, the Online Service or any
of its content. Furthermore, the AMBER voice
compression software included in this
product is protected by intellectual property
rights including patent rights, copyrights,
and trade secrets of Digital Voice
Systems, Inc.

General Requirements:

1. A License Agreement from SiriusXM is

required for any product that
incorporates SiriusXM Technology and/or
for use of any of the SiriusXM marks to

be manufactured, distributed,
or marketed in the SiriusXM
Service Area.

2. For products to be distributed, marketed,

and/or sold in Canada, a separate
agreement is required with Canadian
Satellite Radio Inc. (operating as SiriusXM
Canada).

TouchSense Technology and TouchSense
System 1000 Series Licensed from
Immersion Corporation. TouchSense System
1000 protected under one or more of the
U.S. Patents at the following address
www.immersion.com/patent-marking.html
and other patents pending.

Bose

Bose AudioPilot and Bose Centerpoint
surround are registered trademarks of Bose
Corporation in the U.S. and other countries.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

178

Infotainment System

Bluetooth

The Bluetooth word mark and logos are
owned by the Bluetooth SIG, Inc. and any
use of such marks by General Motors is
under license. Other trademarks and trade
names are those of their respective owners.

Java

Java is a registered trademark of Oracle
and/or its affiliates.

MPEG4

–

AVC (H.264)

THIS PRODUCT IS LICENSED UNDER THE AVC
PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A
CONSUMER TO (i) ENCODE VIDEO IN
COMPLIANCE WITH THE AVC STANDARD
(

“

AVC VIDEO

”

) AND/OR (ii) DECODE AVC

VIDEO THAT WAS ENCODED BY A
CONSUMER ENGAGED IN A PERSONAL AND
NON-COMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER
LICENSED TO PROVIDE AVC VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED
FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM
MPEG LA, LLC. SEE
HTTPS://WWW.MPEGLA.COM.

VC-1

THIS PRODUCT IS LICENSED UNDER THE VC-1
PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A
CONSUMER TO (i) ENCODE VIDEO IN
COMPLIANCE WITH THE VC-1 STANDARD
(

“

VC-1 VIDEO

”

) AND/OR (ii) DECODE VC-1

VIDEO THAT WAS ENCODED BY A
CONSUMER ENGAGED IN A PERSONAL AND
NON-COMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER
LICENSED TO PROVIDE VC-1 VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED
FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM
MPEG LA, LLC. SEE
HTTPS://WWW.MPEGLA.COM.

MPEG4

–

Visual

USE OF THIS PRODUCT IN ANY MANNER
THAT COMPLIES WITH THE MPEG-4 VISUAL
STANDARD IS PROHIBITED, EXCEPT FOR USE
BY A CONSUMER ENGAGING IN PERSONAL
AND NON-COMMERCIAL ACTIVITIES.

MP3

MPEG Layer-3 audio coding technology
licensed from Fraunhofer IIS and Thomson.

WMV/WMA

This product includes technology owned by
Microsoft Corporation and under a license
from Microsoft Licensing, GP. Use or
distribution of such technology outside of
this product is prohibited without a license
from Microsoft Corporation and/or Microsoft
Licensing, GP as applicable.

Map End User License Agreement

END USER TERMS

The Map Data SD card (

“

Data

”

) is provided

for your personal, internal use only and not
for resale. It is protected by copyright, and
is subject to the following terms (this

“

End

User License Agreement

”

) and conditions

which are agreed to by you, on the one
hand, and HERE North America, LLC (

“

HERE

”

)

and its licensors (including their licensors
and suppliers) on the other hand.

The Data for areas of Canada includes
information taken with permission from
Canadian authorities, including: © Her
Majesty the Queen in Right of Canada, ©
Queen's Printer for Ontario, © Canada Post
Corporation, GeoBase

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

179

HERE holds a nonexclusive license from the
United States Postal Service

to publish and

sell ZIP+4

information.

© United States Postal Service 2013. Prices
are not established, controlled, or approved
by the United States Postal Service. The
following trademarks and registrations are
owned by the USPS: United States Postal
Service, USPS, and ZIP+4.

TERMS AND CONDITIONS

Personal Use Only: You agree to use this
Data for the solely personal, noncommercial
purposes for which you were licensed, and
not for service bureau, timesharing or other
similar purposes. Except as otherwise set
forth herein, you agree not to otherwise
reproduce, copy, modify, decompile,
disassemble or reverse engineer any portion
of this Data, and may not transfer or
distribute it in any form, for any purpose,
except to the extent permitted by
mandatory laws. You may transfer the Data
and all accompanying materials on a
permanent basis if you retain no copies and
the recipient agrees to the terms of this End
User License Agreement. Multi-disc sets may
only be transferred or sold as a complete
set as provided to you and not as a subset
thereof.

Restrictions

Except where you have been specifically
licensed to do so by HERE and without
limiting the preceding paragraph, you may
not (a) use this Data with any products,
systems, or applications installed or
otherwise connected to or in communication
with vehicles capable of vehicle navigation,
positioning, dispatch, real time route
guidance, fleet management or similar
applications; or (b) with, or in
communication with, including without
limitation, cellular phones, palmtop and
handheld computers, pagers, and personal
digital assistants or PDAs.

Warning

This Data may contain inaccurate or
incomplete information due to the passage
of time, changing circumstances, sources
used, and the nature of collecting
comprehensive geographic data, any of
which may lead to incorrect results.

No Warranty

This Data is provided to you

“

as is,

”

and you

agree to use it at your own risk. HERE and
its licensors (and their licensors and
suppliers) make no guarantees,
representations, or warranties of any kind,

express or implied, arising by law or
otherwise, including but not limited to,
content, quality, accuracy, completeness,
effectiveness, reliability, fitness for a
particular purpose, usefulness, use or results
to be obtained from this Data, or that the
Data or server will be uninterrupted or
error free.

Disclaimer of Warranty

THE DATABASE IS PROVIDED ON AN

“

AS IS

”

AND

“

WITH ALL FAULTS BASIS

”

AND

HARMAN (AND THEIR LICENSORS AND
SUPPLIERS) EXPRESSLY DISCLAIM ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF
NON-INFRINGEMENT, MERCHANTABILITY,
SATISFACTORY QUALITY, ACCURACY, TITLE
AND FITNESS FOR A PARTICULAR PURPOSE.
NO ORAL OR WRITTEN ADVICE OR
INFORMATION PROVIDED BY HARMAN (OR
ANY OF THEIR LICENSORS, AGENTS,
EMPLOYEES, OR THIRD PARTY PROVIDERS)
SHALL CREATE A WARRANTY, AND YOU ARE
NOT ENTITLED TO RELY ON ANY SUCH
ADVICE OR INFORMATION. THIS DISCLAIMER
OF WARRANTIES IS AN ESSENTIAL CONDITION
OF THIS AGREEMENT.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

180

Infotainment System

Disclaimer of Liability

HERE AND ITS LICENSORS (INCLUDING THEIR
LICENSORS AND SUPPLIERS) SHALL NOT BE
LIABLE TO YOU IN RESPECT OF ANY CLAIM,
DEMAND OR ACTION, IRRESPECTIVE OF THE
NATURE OF THE CAUSE OF THE CLAIM,
DEMAND OR ACTION ALLEGING ANY LOSS,
INJURY OR DAMAGES, DIRECT OR INDIRECT,
WHICH MAY RESULT FROM THE USE OR
POSSESSION OF THIS DATA; OR FOR ANY
LOSS OF PROFIT, REVENUE, CONTRACTS OR
SAVINGS, OR ANY OTHER DIRECT, INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES ARISING OUT OF YOUR USE OF OR
INABILITY TO USE THIS DATA, ANY DEFECT IN
THIS DATA, OR THE BREACH OF THESE
TERMS OR CONDITIONS, WHETHER IN AN
ACTION IN CONTRACT OR TORT OR BASED
ON A WARRANTY, EVEN IF HERE OR ITS
LICENSORS HAVE BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. Some
States, Territories, and Countries do not
allow certain liability exclusions or damages
limitations, so to that extent the above may
not apply to you.

Export Control

You agree not to export from anywhere any
part of the Data provided to you or any
direct product thereof except in compliance

with, and with all licenses and approvals
required under, applicable export laws, rules
and regulations. Entire Agreement: These
terms and conditions constitute the entire
agreement between HERE (and its licensors,
including their licensors and suppliers) and
you pertaining to the subject matter hereof,
and supersedes in their entirety any and all
written or oral agreements previously
existing between us with respect to such
subject matter.

Governing Law

The above terms and conditions shall be
governed by the laws of the State of Illinois,
without giving effect to (i) its conflict of
laws provisions, or (ii) the United Nations
Convention for Contracts for the
International Sale of Goods, which is
explicitly excluded. You agree to submit to
the jurisdiction of the State of Illinois for
any and all disputes, claims, and actions
arising from or in connection with the Data
provided to you hereunder.

Government End Users

If the Data is being acquired by or on behalf
of the United States government or any
other entity seeking or applying rights
similar to those customarily claimed by the
United States government, this Data is a

“

commercial item

”

as that term is defined at

48 C.F.R. (

“

FAR

”

) 2.101, is licensed in

accordance with this End User License
Agreement, and each copy of Data delivered
or otherwise furnished shall be marked and
embedded as appropriate with the following

“

Notice of Use,

”

and be treated in

accordance with such Notice:

NOTICE OF USE

CONTRACTOR (MANUFACTURER/ SUPPLIER)

NAME:

HERE North America, LLC

CONTRACTOR (MANUFACTURER/SUPPLIER)

ADDRESS:

425 West Randolph Street, Chicago, IL
60606.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Infotainment System

181

This Data is a commercial item as defined in
FAR 2.101 and is subject to the End User
License Agreement under which this Data
was provided.

If the Contracting Officer, federal
government agency, or any federal official
refuses to use the legend provided herein,
the Contracting Officer, federal government
agency, or any federal official must notify
HERE prior to seeking additional or
alternative rights in the Data.

Unicode

Free Type Project

Open Source SW

Further information concerning the OSS
licenses is shown in the infotainment
display.

QNX

Part C

–

EULA

The product you have purchased ("Product")
contains Software (Runtime Configuration
No. 505962; "Software") which is distributed
by or on behalf of the Product manufacturer
"Manufacturer") under license from Software
Systems Co. ("QSSC"). You may only use the
Software in the Product and in compliance
with the license terms below.

Subject to the terms and conditions of this
License, QSSC hereby grants you a limited,
non-exclusive, non-transferable license to use
the Software in the Product for the purpose
intended by the Manufacturer. If permitted
by the Manufacturer, or by applicable law,
you may make one backup copy of the
Software as part of the Product software.
QSSC and its licensors reserve all license+C31
rights not expressly granted herein, and
retain all right, title and interest in and to
all copies of the Software, including all
intellectual property rights therein. Unless

required by applicable law you may not
reproduce, distribute or transfer,
or de-compile, disassemble or otherwise
attempt to unbundle, reverse engineer,
modify or create derivative works of, the
Software. You agree: (1) not to remove,
cover or alter any proprietary notices, labels
or marks in or on the Software, and to
ensure that all copies bear any notice
contained on the original; and (2) not to
export the Product or the Software in
contravention of applicable export
control laws.

EXCEPT TO THE EXTENT OTHERWISE
REQUIRED BY APPLICABLE LAW, QSSC AND
ITS LICENSORS PROVIDE THE SOFTWARE ON
AN "AS IS" BASIS, WITHOUT WARRANTIES OR
CONDITIONS OF ANY KIND, EITHER EXPRESS
OR IMPLIED INCLUDING, WITHOUT
LIMITATION, ANY WARRANTIES OR
CONDITIONS OF TITLE, NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. ANY WARRANTIES OR
OTHER PROVISIONS OFFERED BY THE
MANUFACTURER OR ITS DISTRIBUTOR(S)
THAT DIFFER FROM THIS LICENSE ARE
OFFERED BY THE MANUFACTURER OR ITS
DISTRIBUTOR(S) ALONE AND NOT BY QSSC,

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

182

Infotainment System

ITS AFFILIATES OR THEIR LICENSORS. YOU
ASSUME ANY RISKS ASSOCIATED WITH YOUR
USE OF THE SOFTWARE UNDER THIS LICENSE.

EXCEPT TO THE EXTENT OTHERWISE
REQUIRED BY APPLICABLE LAW (SUCH AS IN
THE CASE OF DELIBERATE OR GROSSLY
NEGLIGENT ACTS), IN NO EVENT SHALL QSSC,
ITS AFFILIATES OR THEIR LICENSORS BE
LIABLE TO YOU UNDER ANY LEGAL THEORY,
WHETHER IN TORT (INCLUDING NEGLIGENCE),
CONTRACT OR OTHERWISE, FOR DAMAGES,
INCLUDING ANY DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES
OF ANY CHARACTER ARISING AS A RESULT OF
THIS LICENSE OR OUT OF THE USE OR
INABILITY TO USE THE PRODUCT (INCLUDING
BUT NOT LIMITED TO DAMAGES FOR LOSS
OF GOODWILL, WORK STOPPAGE, PRODUCT
FAILURE OR MALFUNCTION, OR ANY AND ALL
OTHER COMMERCIAL DAMAGES OR LOSSES),
EVEN IF QSSC, ITS AFFILIATES OR THEIR
LICENSORS HAVE BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.

WMA

This product is protected by certain
intellectual property rights of Microsoft. Use
or distribution of such technology outside of
this product is prohibited without a license
from Microsoft.

For more information on the Software,
including any open source software license
terms (and available source code) as well as
copyright attributions applicable to the
Runtime Configuration indicated above,
please contact the Manufacturer or contact
QSSC at 175 Terence Matthews Crescent,
Kanata, Ontario, Canada K2M 1W8
(licensing@qnx.com).

Linotype

Helvetica is a trademark of Linotype Corp.
registered in the U.S. Patent and Trademark
Office and may be registered in certain
other jurisdictions in the name of Linotype
Corp. or its licensee Linotype GmbH.

Usage in text form of each of the Licensed
Trademarks is:

The trademark attribution requirements for
the Licensed Trademarks may be viewed at
https://www.linotype.com/2061-19414/
trademarks.html.

END USER NOTICE

The marks of companies displayed by this
product to indicate business locations are
the marks of their respective owners. The
use of such marks in this product does not
imply any sponsorship, approval,
or endorsement by such companies of this
product.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

184

Climate Controls

Climate Control Display

1. Driver and Passenger Temperature

Settings

2. Fan Control
3. Driver and Passenger Temperature

Controls

4. Sync (Synchronized Temperature)
5. Recirculation
6. Air Delivery Mode Controls
7. Auto (Automatic Operation)
8. A/C (Air Conditioning)
9. On/Off (Power)

The fan, air delivery mode, air conditioning,
driver and passenger temperatures, and Sync
settings can be controlled by touching
CLIMATE on the infotainment Home Page or
the climate button in the climate control
display application tray. A selection can then
be made on the front climate control page
displayed.

Climate Control Status Display

The climate control status display appears
briefly when the center stack climate
controls are adjusted.

Automatic Operation

The system automatically controls the
following four functions to heat or cool the
vehicle to the desired temperature:

Fan Speed

Air Delivery Mode

Air Conditioning

Recirculation

When the AUTO indicator light is lit, all four
functions are operating automatically. Each
function can be manually set and the
selected setting will be shown. This cancels
full automatic operation and the AUTO
indicator light turns off. Functions that are
not manually set will continue to be
automatically controlled, although the AUTO
indicator light will not be lit.

To place the system in automatic mode:

1. Press AUTO.
2. Set the driver and passenger

temperature.
To find your comfort setting, start with
22 °C (72 °F) and allow the system time
to stabilize. Then adjust the temperature
as needed for best comfort.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Climate Controls

185

To improve fuel efficiency and to cool the
vehicle faster, recirculation may be
automatically selected in warm weather.

The recirculation light will not come on
when automatically controlled. Press

manually select recirculation; press it again
to select outside air.

Do not cover the solar sensor on the top of
the instrument panel near the windshield.
This sensor regulates air temperature based
on sun load. See

“

Sensors

”

later in this

section.

Manual Operation

Press to turn the climate control system

on or off. When the system is off, outside
air will be prevented from entering the
vehicle. When the system is on, a button is
pressed, or knob is turned, the climate
control system will turn on and deliver
airflow per the current setting.

Turn clockwise or counterclockwise to

increase or decrease the fan speed. Press the
knob to turn the fan off.

Press AUTO to return to automatic
operation.

Driver and Passenger Temperature Control :

The temperature can be adjusted separately
for the driver and passenger.

Turn the knob clockwise or counterclockwise
to increase or decrease the driver or
passenger temperature setting.

SYNC :

Press to link the passenger and rear

climate temperature settings, if equipped, to
the driver setting. The SYNC indicator light
will turn on. When the passenger or rear
climate temperature settings are adjusted,
the SYNC indicator light is off.

The driver side or passenger side
temperature display shows the temperature
setting increasing or decreasing.

Air Delivery Mode Control :

Press

[

, or

to change the direction of the

airflow. An indicator light comes on in the
selected mode button.

Changing the mode cancels the automatic
operation and the system goes into manual
mode. Press AUTO to return to automatic
operation.

Air is directed to the instrument panel

outlets.

Air is divided between the instrument

panel and floor outlets. Some air is directed
toward the windshield and side window
outlets.

[

Air is directed to the floor outlets,

with some to the windshield, side window
outlets, and second row floor outlets.

This mode clears the windows of fog or

moisture. Air is directed to the windshield,
floor outlets, and side window vents. The
system automatically forces outside air into
the vehicle and the air conditioning
compressor will run, unless the outside
temperature is close to freezing.

Press to clear the windshield of fog or

frost more quickly. Air is directed to the
windshield and the side window vents. The
air conditioning compressor also comes on,
unless the outside temperature is below
freezing.

Do not drive the vehicle until all windows
are clear.

See

Air Vents

188

A/C :

Press to turn the air conditioning

system on or off. An indicator light comes
on to show that the air conditioning is
enabled. If the fan is turned off, the air

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

186

Climate Controls

conditioner will not run. The A/C light will
stay on even if the outside temperatures are
below freezing.

Press to turn on recirculation. An

indicator light comes on. Air is recirculated
to quickly cool the inside of the vehicle.
It can also be used to help reduce outside
air and odors that enter the vehicle. The air
conditioning compressor also comes on
when this mode is activated.

Rear Window Defogger

The rear window defogger uses a warming
grid to remove fog from the rear window.

Press to turn the rear window defogger

on or off. An indicator light on the button
comes on to show that the rear window
defogger is on.

The rear window defogger only works when
the ignition is on. The defogger turns off if
the ignition is turned to off or ACC/
ACCESSORY.

Caution

Using a razor blade or sharp object to
clear the inside rear window can damage
the rear window defogger. Repairs would

(Continued)

Caution (Continued)

not be covered by the vehicle warranty.
Do not clear the inside rear window with
sharp objects.

Heated Mirror :

If equipped with heated

outside mirrors, the mirrors heat to help
clear fog or frost from the surface of the
mirror when the rear window defog button
is pressed. See

Heated Mirrors

Remote Start Climate Control Operation :

If equipped with remote start, the climate
control system may run when the vehicle is
started remotely. The rear defog may come
on during remote start based on cold
ambient conditions. The rear defog indicator
light does not come on during a remote
start.

If equipped, the heated seats will turn on if
it is cold outside or the ventilated seats will
turn on if it is hot outside. The heated and
ventilated seat indicator lights may not
come on during a remote start. If equipped,
the heated steering wheel will come on in a
remote start if it is cold outside. The heated
steering wheel indicator light may not
come on.

Sensors

The solar sensor, located in the defrost grille
in the middle of the instrument panel,
monitors the solar heat. Do not cover the
solar sensor or the system will not work
properly.

There is also an exterior temperature sensor
behind the front grille. This sensor reads the
outside air temperature and helps maintain
the temperature inside the vehicle. Any
cover on the front of the vehicle, could
cause a false reading in the displayed
temperature.

The climate control system uses the
information from these sensors to maintain
comfort settings by adjusting the outlet

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

188

Climate Controls

If the air delivery mode or fan speed is
manually adjusted, this cancels full
automatic operation.

Manual Operation

]

Turn the knob clockwise or

counterclockwise to increase or decrease the
airflow to the rear panel outlets.

Temperature Controls :

Turn the knob

clockwise or counterclockwise to adjust the
rear passenger temperature.

Air Delivery Mode Control :

Press to select

the desired air delivery mode. This changes
the direction of the airflow in the rear
seating area.

If the rear floor air delivery mode is
selected, the rear fan speed indicator will
change when adjusted, but the airflow
amount directed to the floor will not. This is
normal operation for the system.

If equipped, press to turn on the driver

side or passenger side rear seat heater.
Press again to lower the temperature.
Indicator lights show the level of heat
activated.

Air Vents

To adjust the center and side air outlets on
the instrument panel, use the slider switch
in the center of the outlet to change the
direction of the airflow and also to shut off
the airflow.

There may be outlets overhead in the rear
passenger area; adjust as needed.

Keep all outlets open whenever possible for
best system performance.

Operation Tips

Clear away any ice, snow, or leaves from
the air inlets at the base of the
windshield that can block the flow of air
into the vehicle.

Clear snow off the hood to improve
visibility and help decrease moisture
drawn into the vehicle.

Use of non-GM approved hood deflectors
can adversely affect the performance of
the system.

Keep the path under all seats clear of
objects to help circulate the air inside the
vehicle more effectively.

If fogging reoccurs while in

modes with mild temperature throughout
the vehicle, turn on the air conditioner to
reduce windshield fogging.

Maintenance

Passenger Compartment Air Filter

The passenger compartment air filter
reduces dust, pollen, and other airborne
irritants from outside air that is pulled into
the vehicle. The filter will need to be
replaced periodically. See

Maintenance

Schedule

339

Using the climate control system without an
air filter installed is not recommended.
Water or other debris could enter the
system and result in leaks or noises. Always
install a new filter when removing the old
filter.

For more information on filter replacement,
see your dealer.

Service

All vehicles have a label underhood that
identifies the refrigerant used in the vehicle.
The refrigerant system should only be
serviced by trained and certified technicians.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/29/22

Driving and Operating

191

Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . . . 252
Towing Equipment . . . . . . . . . . . . . . . . . . . . 255
Trailer Sway Control (TSC) . . . . . . . . . . . . . 258

Conversions and Add-Ons

Add-On Electrical Equipment . . . . . . . . . . . 259

Driving Information

Driving for Better Fuel Economy

Driving habits can affect fuel mileage. Here
are some driving tips to get the best fuel
economy possible.

Set the climate controls to the desired
temperature after the engine is started,
or turn them off when not required.

On AWD vehicles, see

Driver Mode Control

220

Avoid fast starts and accelerate smoothly.

Brake gradually and avoid abrupt stops.

Avoid idling the engine for long periods
of time.

When road and weather conditions are
appropriate, use cruise control.

Always follow posted speed limits or
drive more slowly when conditions
require.

Keep vehicle tires properly inflated.

Combine several trips into a single trip.

Replace the vehicle's tires with the same
TPC Spec number molded into the tire's
sidewall near the size.

Follow recommended scheduled
maintenance.

Distracted Driving

Distraction comes in many forms and can
take your focus from the task of driving.
Exercise good judgment and do not let other
activities divert your attention away from
the road. Many local governments have
enacted laws regarding driver distraction.
Become familiar with the local laws in
your area.

To avoid distracted driving, keep your eyes
on the road, keep your hands on the
steering wheel, and focus your attention on
driving.

Do not use a phone in demanding driving
situations. Use a hands-free method to
place or receive necessary phone calls.

Watch the road. Do not read, take notes,
or look up information on phones or
other electronic devices.

Designate a front seat passenger to
handle potential distractions.

Become familiar with vehicle features
before driving, such as programming
favorite radio stations and adjusting
climate control and seat settings. Program
all trip information into any navigation
device prior to driving.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/29/22

192

Driving and Operating

Wait until the vehicle is parked to
retrieve items that have fallen to the
floor.

Stop or park the vehicle to tend to
children.

Keep pets in an appropriate carrier or
restraint.

Avoid stressful conversations while
driving, whether with a passenger or on a
cell phone.

{

Warning

Taking your eyes off the road too long or
too often could cause a crash resulting in
injury or death. Focus your attention on
driving.

Refer to the infotainment section for more
information on using that system and the
navigation system, if equipped, including
pairing and using a cell phone.

Defensive Driving

Defensive driving means

“

always expect the

unexpected.

”

The first step in driving

defensively is to wear the seat belt. See

Seat Belts

Assume that other road users
(pedestrians, bicyclists, and other drivers)
are going to be careless and make
mistakes. Anticipate what they may do
and be ready.

Allow enough following distance between
you and the driver in front of you.

Focus on the task of driving.

Impaired Driving

Death and injury associated with impaired
driving is a global tragedy.

{

Warning

Drinking alcohol or taking drugs and then
driving is very dangerous. Your reflexes,
perceptions, attentiveness, and judgment
can be affected by even a small amount
of alcohol or drugs. You can have a
serious

—

or even fatal

—

collision if you

drive after drinking or taking drugs.

Do not drive while under the influence of
alcohol or drugs, or ride with a driver
who has been drinking or is impaired by
drugs. Find alternate transportation
home; or if you are with a group,
designate a driver who will remain sober.

Control of a Vehicle

Braking, steering, and accelerating are
important factors in helping to control a
vehicle while driving.

Braking

Braking action involves perception time and
reaction time. Deciding to push the brake
pedal is perception time. Actually doing it is
reaction time.

Average driver reaction time is about
three-quarters of a second. In that time, a
vehicle moving at 100 km/h (60 mph) travels
20 m (66 ft), which could be a lot of
distance in an emergency.

Helpful braking tips to keep in mind include:

Keep enough distance between you and
the vehicle in front of you.

Avoid needless heavy braking.

Keep pace with traffic.

If the engine ever stops while the vehicle is
being driven, brake normally but do not
pump the brakes. Doing so could make the
pedal harder to push down. If the engine
stops, there will be some power brake assist
but it will be used when the brake is

MC Acadia Owner (2023 year). Manual in english - page 6
