Caterpillar. Dealer service tools catalog (2018)

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Safety Glasses

Warranty: Caterpillar ^®Six Months

Meets or exceeds all ANSI and CUL

• Anti-scratch hard-coated lenses

specifications

• 99.9% UVA and UVB protection

• 5-position ratchet and 4-position telescoping

• Ventilation between lens and frame

temples

• Soft non-slip rubber nosepiece

Part No.

Lens Type

Package Quantity

249-7265

Clear (packaged for industrial;)

Safety Glasses

Warranty: Caterpillar ^®Six Months

Meets ANSI Z87.1 + standards and protects

• Gel nosepiece allows for all day comfort

against 99% harmful UVrays

• 4 - position telescoping temples for superior

• 9.75 base lens provide excellent optics and

fit

protection

• All lens are hard coated for scratch resistance

Part No.

Lens Tint

Package Quantity

Industrial Packaging

307-3013

Clear

12 per package

307-3014

Smoke

12 per package

307-3015

Indoor/Outdoor Use

12 per package

Safety Glasses

Warranty: Caterpillar ^®Six Months

Meets ANSI Z87.1 + standards and protects

• 5 position ratchet plus 4-position telescoping

against 99% harmful UVrays

temples for superior fit

• Ventilation channel between lens and frame

helps reduce fogging

Part No.

Lens Tint

Package Quantity

309-4932

Polarized (IndustrialPackaging)

12 per package

control

Soft rubber nosepiece

•

• Tough polycarbonate lens provides superior

protection

Safety Glasses

Warranty: Caterpillar ^®Six Months

Meets ANSI Z87.1+ and CUL standards and

protects against 99% of harmful UV Rays

• Rubber tipped temples for comfortable fit

Part No.

Lens Tint

Package Quantity

307-3017

Clear (Industrial Packaging)

12 per package

JULY 2018 Shop Supplies

18-131

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Safety Glasses

Warranty: Caterpillar ^®Six Months

Meets ANSI Z87.1 + standards and protects

• Soft, rubber temples provide superior comfort

against 99% harmful UVrays

• Rubber nosepiece allows for all day comfort

• Comes standard with neck cord

Part No.

Packaging

Lens Type

308-6384

Clamshell (packaged for retail)

Clear

Safety Glasses, Bi Focal

Warranty: Caterpillar ^®Six Months

Meets ANSI Z87.1 + standards and protects

• Magnification diopter molded into lens

against 99% harmful UVrays

• Soft, rubber nosepiece

• Bi Focal Safety Glass

• Cushioned, non-slip rubber temple pads

Part No.

Package Quantity

Lens Type

Industrial Packaging

308-6391

12 Per Package

Clear 1.0

308-6393

12 Per Package

Clear 1.5

309-2454

12 Per Package

Clear 2.0

309-2456

12 Per Package

Clear 2.5

309-2458

12 Per Package

Clear 3.0

Retail Packaging (Clamshell)

309-2455

Clamshell

Clear 2.0

Safety Glasses

Warranty: Caterpillar ^®Six Months

Meets ANSI Z87.1 + standards and protects

• High gloss painted frame

against 99% harmful UVrays

• Comes standard with neck cord

• Sleek, sporty, lightweight wraparound frame

• Cushioned, non-slip rubber temple pads

• Gel nosepiece allows for all day comfort

Part No.

Packaging

Lens Type

307-3025

12 Per Package ( industrial packaging)

Smoke

Safety Goggles

Warranty: Caterpillar ^®Six Months

• Provides excellent ventilation and indirect

• Clear optical-grade polycarbonate lens

protection

• Adjustable headband

• Fits over most prescription eyewear

• Meets or exceeds all ANSI specifications

Part No.

Description

Package Quantity

233-8584

Safety Goggles

OnePair

18-132 JULY 2018 Shop Supplies

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Goggles, Welding

Warranty: Caterpillar ^®Six Months

• Features a shade 10 lens but in a larger size -

• Has ratcheting head gear

114 x 133 mm (4 1/2 x 5 1/4 in)

• Made of sturdy nylon material

Part No.

Lens Type

1U-8103

Welding Goggles

Goggles, Welding with Lift Front Lens

Warranty: Caterpillar ^®Six Months

• Feature the shade 5 lens with a hinged front-

lift door

Part No.

Lens Type

1U-8104

Welding Goggles with Lift Front Lens

Safety Goggles, Vented

Warranty: Caterpillar ^®Six Months

CEMarked, ANSI 287.1, CUL, EN166

• Fits over most prescription eyewear

• Perforated goggle with excellent ventilation

• Clear optical-grade polycarbonate lens

and protection

• Adjustable headband

Part No.

Description

Package Quantity

233-8583

Vented Safety Goggles

OnePair

Safety Glasses Lanyard

Warranty: Caterpillar ^®Six Months

CEMarked, ANSI 287.1, CUL, EN166

• Rubber tips slip right onto your safety glasses

• Universal lanyard to help you keep track of

• Cat^®branded slider adjusts to help keep your

your safety glasses when moving into and out

glasses snug

of the shop.

Part No.

Description

435-4062

Cat^®Lanyard

JULY 2018 Shop Supplies

18-133

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Wipers, All-purpose

Warranty: Caterpillar ^®Six Months

• Cleaning tissues for safety glasses

• Pop-up style box

Part No.

Description

Qty.

Size

263-0867

All-purpose Wipers

300 tissues per box, 60 boxes per case

127 x 203 mm (5 x 8 in)

Headgear, Heavy-Duty

Warranty: Caterpillar ^®Six Months

European Union Compliant, CE marked

• Polycarbonate for heavy-duty impact

protection against flying particles

• Headgear has precision ratchet head size

adjustment for a comfortable snug fit

• Provide excellent general face and eye

protection

• Floating window suspension distributes

weight and reduces shock of impact

• Windows can be replaced in seconds

• Five position pinlock crown band provides

• Windows mount inside crown protector for

additional adjustment for proper support and

greater splash protection

a firm fit

• Spring loaded pivot assemblies maintain

• Crown protector made of a new high-

proper friction and prevent annoying window

performance thermoplastic offers excellent

drop

impact resistance over a wide range of

• Blue color and matte finish resist smudges

temperatures

and show less daily grime

• Soft vinyl headband to cushion the forehead

• Packaged in quantities of 10

• Packaged individually. Headgear and windows

4C-8095: Heavy Duty Headgear

must be ordered separately.

Accessories

4C-8096 and 4C-8097 Features

• 4C-8096: Window, Clear Polycarbonate

• 229 mm x 368 mm x 2.0 mm (9 in x 14 1/2 in x

0.080 in) thickness

• 4C-8097: Window, Dark Green for Glare

Reduction

• Good heat resistance

18-134 JULY 2018 Shop Supplies

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Face Shield

Warranty: Caterpillar ^®Six Months

• Clear 203 mm x 305 mm x 1 mm (8 in x 12 in x

• Provide excellent general face and eye

.040 in) window

protection

Part No.

Description

1U-8095

Face Shield

Replacement Windows for 1U-8095 Face Shield (Also fit Glendale 5000, Huntsman K, K3, K4 and K10,

• Comfortable and

Norton 6300 and Jackson J-10 face shields)

1U-8096

Clear replacement window

4C-4404

Green replacement window

durable

• Smooth surface to repel dirt

• Excellent protection at NRR29

Ear Plugs, Disposable

Warranty: Caterpillar ^®Six Months

European Union Compliant, CE marked

• Tapered disposable plug for excellent fit

• Light comfortable foam

Part No.

Package Quantity

239-1090

Ear Plugs

Warranty: Caterpillar ^®defects in material and

AS/NZS 1270:2002

• Soft PU foam for comfort

workmanship to first user

• Box of 200 pairs of uncorded ear plugs

• Hi-vis color to identify wearer compliance

• Available in Australia/New Zealand region

• Individually packaged pairs

• Class 5, SLC80 29db

• Complies with AS/NZS 1270:2002

• NRR 32

Part No.

Description

Dimensions (L x W x H)

Weight

536-3576

Ear Plugs

185 x 100 x 210 mm (7.3 x 3.9 x 8.3 in)

0.04 kg (0.09 lb)

JULY 2018 Shop Supplies

18-135

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Ear Plugs, Disposable Foam

Warranty: Caterpillar ^®Six Months

European Union Compliant, CE marked

• Noise reduction rating: 33dB

• Bell-shaped polyurethane foam for maximum

• NRR33, Canada Class A(L), SNR 37,

comfort

SLL{80}26, Class 5, CA 14.114, EN352

• Smooth soil-resistant skin

• Color: neon

Part No.

Description

Qty.

260-4783

Uncorded Disposable Plugs

10 pc

260-4785

Corded DisposablePlugs

25 pc

Ear Muffs

Warranty: Caterpillar ^®defects in material and

AS/NZS 1270:2002

• Padded headband for comfort

workmanship to first user

• Quality Frontier Egard Tradie Ear Muff offer

• 3 position headband for top of head, behind

trade quality hearing protection for general

head or under chin use

purpose use.

• Can be used with hard hat, respirator or visor

• Available in Australia/New Zealand region

• Simple, adjustable cup positioning

• Class 4/SLC80 25 db

• Complies with AS/NZS 1270:2002

Part No.

Description

Dimensions (L x W x H)

Weight

536-3574

Ear Muffs

180 x 90 x 180 mm (7.1 x 3.5 x 7.1 in)

0.25 kg (0.6 lb)

Ear Muffs

Warranty: Caterpillar ^®defects in material and

AS/NZS 1270:2002

• High quality robust hearing protection for high

workmanship to first user

noise use

• Quality FrontierEgardPro5 Ear Muff 30dB

offers high quality robust hearing protection.

• Padded headband for comfort

• Available in Australia/New Zealand region

• Stainless steel wire headband construction

for durability

• Class 5 / SLC80 30db

• Complies with AS/NZS 1270:2002

• Hi Vis color for increased visibility

Part No.

Description

Dimensions (L x W x H)

Weight

536-3575

Ear Muffs

180 x 90 x 180 mm (7.1 x 3.5 x 7.1 in)

0.25 kg (0.6 lb)

JULY 2018 Shop Supplies

18-137

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Ear Muffs, Silencer

Warranty: Caterpillar ^®Six Months

European Union Compliant, CE marked

• Rugged and lightweight

• Comfortable adjustable padded headband

• Dielectric

• Soft foam padded ear cups-comfortable

• Excellent protection at NRR26

whenwearing with glasses

Part No.

Description

233-8587

Silencer Ear Muffs

Ear Muffs, Multipositional

Warranty: Caterpillar ^®One Year

• Foam filled ear cushions with a soft

• Adjustable steel headband

breathable surface

• NRP 26

• Meets ANSI S3.19 - 1974 Standard

Part No.

Package Qty.

Description

543-2135

Multipositional Ear Muffs

Ear Muffs

Warranty: Caterpillar ^®Six Months

European Union Compliant, CE marked

• Recommendedfor moderately high noise

situations (up to 95 dBA TWA)

• Hard hat-mounted ear muffs feature large,

lightweight ear cups that attach to a variety of

• Noise reduction rating: 23 dB

hard hats for convenience

Part No.

Package Qty.

Description

4C-6581

2 Pair

Ear Muffs

18-138 JULY 2018 Shop Supplies

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Hard Hat, Cat^®Ratcheting

Warranty: Caterpillar ^®Six Months

Meets CE0086 EN397:2012+A1:2012 and ANSI

• Ratcheting adjustable suspension assures a

Z89.1 - 2014

snug fit.

• Adjustable/removable chin strap

Part No.

Description

Color

Size

Weight

517-1312

Cat^®Ratcheting Hard Hat

White

One size fits all

0.5 kg (1.1 lb)

517-1313

Cat^®Ratcheting Hard Hat

Yellow

One size fits all

0.5 kg (1.1 lb)

• Impact-absorbent, polypropylene shell

Hard Hats

Warranty: Caterpillar ^®Six Months

• High-density polyethylene

• Attachment points for accessories like:

earmuffs, face shields, flashlights, etc.

• Self-sizing, four-point suspension with brow

pad

• Meets or exceeds ANSI/ISEA Z89.1-2009,

Type 1, Class E and G, CSA Z94.1-2005, Type

• Rain trough brim provides extra protection

1, Class E and G, EN 397

against snow, rain, dust, and dirt

Part No.

Description

437-1415

Yellow Hard Hat

437-1416

White Hard Hat

Hard Hats, Cat^®Branded

Warranty: Caterpillar ^®Six Months, First User

ANSI & CE Certified

• Ratcheting adjustable suspension assures a

Against Defects in Material & Workmanship

snug fit

• Impact absorbent polypropylene shell

• Adjustable/removable chin strap

Part No.

Description

539-2765

Cat^®Hard Hat, White

539-2766

Cat^®Hard Hat, Yellow

JULY 2018 Shop Supplies

18-139

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Hard Hat Winter Liner

Warranty: Caterpillar ^®Six Months

European Union Compliant, CE marked

• Dark blue cotton twill with fleece lining

• Wear with 239-4964, 239-4965, 239-4966,

• Comes with a hook and loop chin strap

fastener

• Will work with other similar hard hats

Part No.

Description

1U-8091

HardHatWinter Liner

and 239-4967 Hard Hats

Helmet, Welding

Warranty: Caterpillar ^®Six Months

• 51 x 108 mm (2 x 4 1/4 in), "shade 10" lens

• Ratcheting headgear adjusts to fit any head

size

• Nylon material is lightweight and durable

Part No.

Description

1U-8097

Welding Helmet

Helmet, Welding

Warranty: Caterpillar ^®Six Months

• Features a shade 10 lens but in a larger size -

• Has ratcheting head gear

114 x 133 mm (4 1/2 x 5 1/4 in)

• Made of sturdy nylon material

Part No.

Lens Type

Lens Use For:

1U-8100

Welding Helmet

Replacement Lens for 1U-8097 and 1U-8100 Welding Helmets

Plastic Cover Plates

1U-8099

1U-8097

(Two needed, one inside and one outside of your tinted glass lens)

Shade 10 Tinted Glass

1U-8101

1U-8100

(Shade 10 lens used for welding with manual weld electrodes)

Shade 10 Tinted Glass

1U-8209

1U-8097

(Shade 10 lens used for welding with manual weld electrodes)

Helmets, Cat^®Welding

Warranty: Manufacturer’s Three Years

ANSI Z87.1+, CSA Z94.3, CE, AS. /NZS

• X-Mode electromagnetically senses the

weld to eliminate sunlight interference,

For warranties, contact helmet@millerwelds.com

• Exclusive Cat^®graphics

continuously detecting the arc even when

• Aluminum heat shield for enhanced protection

sensors are blocked.

487-6612 Miller Elite Series-

• Redesigned headgear features additional

Cat^®- 1st Edition

adjustability settings and enhanced support

for better fit and comfort.

• Large digital controls allow user to easily

adjust mode and settings

• Aluminum heat shield protects lens in high

• Four operating modes: weld, cut, grind and

amperage applications.

487-6612

X-Mode provide ultimate versatility.

• 9.22 sq. in. viewing area

Part No.

Description

Dimensions

Weight

487-6612

Cat^®Welding Helmet

311 x 260 x 254 mm (12.25 x 10.25 x 10in)

1.37 kg (3.02 lb)

18-140 JULY 2018 Shop Supplies

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Protective Shell Insert for Baseball Cap

Warranty: Cat^®1st User Warranty Against

• Turns any baseball cap into a piece of

• One size fits all

Defects in Material and Workmanship

protective headgear offering a mild form of

head protection

Part No.

Description

Dimensions

Weight

539-8085

Protective Shell Insert for Baseball Cap

196 x 152 x 102 mm (7.7 x 6 x 4 in)

0.06 kg (0.13 lb)

Bump Caps, Cat^®Branded

Warranty: Caterpillar ^®Six Months, First User

European Union Compliant, CE marked

• Adjustable suspension and chin strap for a

Against Defects in Material & Workmanship

secure fit

• High-density polyethylene shell

• Side ventilation holes for added comfort in

high temperatures

Part No.

Description

539-2767

Cat^®Bump Cap, Yellow

539-2768

Cat^®Bump Cap, White

Hard Hat

Warranty: Caterpillar ^®defects in material and

AS/NZS 1801:1997

• AS/NZS 1801:1997 certified

workmanship to first user

• White Frontier Tuffgard Hard Hat

• Industrial Strength

• Available in Australia/New Zealand region

• Lightweight

• Non Vented 6 Point Web Suspension

Part No.

Description

Dimensions (L x W x H)

Weight

536-3582

HardHat

280 x 220 x 190 mm (11 x 8.7 x 7.5 in)

0.4 kg (0.9 lb)

JULY 2018 Shop Supplies

18-141

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Blanket,Welding

Warranty: Caterpillar ^®Six Months

• Made of a fiberglass textile material

• Hemmed and seamed with Kevlar thread

• Light gold neoprene coating on one side to

• Retains heat

reduce fraying

• Protects welding area

Part No.

Description

Dimensions

4C-9616

Blanket

183 cm x 183 cm (6 ft x 6 ft)

4C-9617

Blanket

183 cm x 244 cm (6 ft x 8 ft)

4C-9618

Blanket

183 cm x 305 cm (6 ft x 10 ft)

Respirator, Particulate

Warranty: Caterpillar ^®Six Months

• Replaces 4C-8761 Dust/Mist Respirator

• Individually packaged to help prevent

contamination

• 193-0766 and 193-0071 meet NOISH 42 CFR

84 N95 requirements. TC-84A2668 and TC-

• 193-0071 features the Cool Flow™ exhalation

84A2669

valve for easy exhalation and cool dry comfort

• Three-panel respirator with innovative design

• Suggested applications: grinding, sanding,

allows better visibility and conforms to a wide

sweeping, bagging, general maintenance,

range of face sizes

dusty operations and operations involving

liquid or non-oil based particle from sprays

• Soft cover web on inner panel is comfortable

that do not emit harmful vapors

against face and helps provide a custom fit

and secure seal

Part No.

Description

Qty.

193-0071

Particulate Respirator

10 respirators per box

Respirator, Welding

Warranty: Caterpillar ^®Six Months

• Meets NOISH 42 CFR 84 N95 requirements.

• Economical all-filter design with no spare

TC-84A0454

parts to clean

• Cool flow exhalation valve promotes worker

• Suggested applications: welding, brazing,

comfort by offering easy exhalation for cooler,

soldering, torch cutting, metal pouring,

dry comfort

grinding, sanding, sweeping, bagging, general

maintenance and operations involving liquid

• Contours easily to provide a comfortable,

or non-oil based particle from sprays that do

good seal

not emit harmful vapors

Part No.

Description

Qty.

237-5181

Welding Respirator

10 respirators per box

Mask, Reusable Polyester Dust

Warranty: Caterpillar ^®Six Months

• Adjustable metal nose bridge, single strap,

• Non-irritating to the skin

and contour-fit design to ensure best coverage

• Not NIOSH approved

• Lightweight and disposable

• Material: polyester

Part No.

Description

Qty.

262-4866

Reusable Polyester Dust Mask

50 masks per box

18-142 JULY 2018 Shop Supplies

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

Dust Mask

Warranty: Caterpillar ^®defects in material and

AS/NZS 1270:2002

• Clear vision

workmanship to first user

• Box of 50 DM1, high filtration, polyester

• Maintenance free

nuisance particle masks

• Elastic headband

• Available in Australia/New Zealand region

• Adjustable nose bridge and single strap

• Industrial Quality

allows snug fit to most faces

• Lightweight

• For non-toxic nuisance dusts

Part No.

Description

Dimensions (L x W x H)

Weight

536-3580

Dust Mask

120 x 120 x 150 mm (4.7 x 4.7 x 5.9 in)

0.03 kg (0.07 lb)

Dust Mask

Warranty: Caterpillar ^®defects in material and

AS/NZS 1716:2012

• Fast Flow Valve for easy breathing

workmanship to first user

• Box of 10 disposable, P2, 1/2 mask respirators

• Industrial quality grade materials

with fast flow valve

• Lightweight, disposable, single use

• Available in Australia/New Zealand region

• Twin elastic headbands for comfort

• P2 Valved Respirator

• Full face seal

• AS/NZS 1716:2012 Certified

• Adjustable nose bridge allows snug fit to

most faces

Part No.

Description

Dimensions (L x W x H)

Weight

536-3581

Dust Mask

140 x 140 x 160 mm (5.5 x 5.5 x 6.3 in)

0.02 kg (0.04 lb)

JULY 2018 Shop Supplies

18-143

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

First Aid Kit, Personal

Warranty: Caterpillar ^®Six Months

• Small, portable kit for service trucks, tool

• Uses “Book Style” construction with zippered

boxes, or for personal use in family home, car,

internal compartments (makes it easy to

camper, or boat

access items)

• Softshell case made of water resistant nylon

Part No.

Description

150-1578

Personal First Aid Kit

150-1578 consists of:

Description

Size

Quantity

Water resistant nylon container

190.5 x 38.1 x 107.95 mm(7.5 x 1.5 x 4.25in)

Scissors

102mm (4.0in)

Tweezers

76.2 mm (3 in)

First aid booklet

Bandaids

19.05 x 76.2 mm(.75 x 3in)

Alcohol swabs

Wet wipes

Antiseptic swabs

Adhesive tape

2.3 m x 12.7 mm (2.5 yd x.5in)

Sterile gauze pads

50.8 x 50.8 mm (2 x 2 in)

Sterile gauze pads

101.6 x 101.6 mm (4 x 4in)

Sterile abdominal pad

127 x 228.6 mm (5 x 9 in)

Sterile pressure bandage

50.8 mm (2 in)

Conform gauze roll

4.57 m x 50.8 mm (5 yd x 2 in)

Triangular bandage

Safety pins

Vinyl gloves

1 pair

Acetaminophen

1 (2 per pack)

18-144 JULY 2018 Shop Supplies

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

First Aid Kit, Portable

Warranty: Caterpillar ^®Six Months

• Small, portable kit for service trucks, tool

• Softshell case made of water resistant nylon

boxes, or for personal use in family home, car,

• Uses "Book Style" construction with zippered

camper, or boat

internal compartments (makes it easy to

access items)

Part No.

Description

150-1579

Portable First Aid Kit

150-1579 consists of:

Description

Size

Quantity

Water resistant nylon container

228.6 x 76.2 x 127 mm (9 x 3 x 5 in)

Scissors

152.4mm (6in)

Stainless steel splinter forceps

114mm (4.5in)

First aid booklet

Cloth bandaids

22.2 x 76.2 mm (.87 x 3in)

Finger tip bandaids

Knuckle bandaids

Alcohol swabs

Wet wipes

Antiseptic swabs

Adhesive tape

4.6 m x 25.4 mm (5 yd x 1 in)

Sterile gauze pads

50.8 x 50.8 mm ( 2 x 2 in)

Sterile gauze pads

101.6 x 101.6 mm (4 x 4in)

Sterile abdominal pad

127 x 228.6 mm (5 x 9 in)

Sterile pressure bandage

101.6mm (4in)

Conform gauze roll

4.57 m x 50.8 mm (5 yd x 2 in)

Triangular bandage

Safety pins

Vinyl gloves

1 pair

Multi-purpose pad

431.8 x 609.6 mm (17 x 24 in)

Tensor bandage

50.8 mm (2 in)

Instant cold pack (in box)

1016 x 152.4 mm (4 x 6in)

Emergency mylar blanket

JULY 2018 Shop Supplies

18-145

Shop Supplies

PERSONAL PROTECTIVE EQUIPMENT

First Aid Kit, Worksite (25- and 50-person)

Warranty: Caterpillar ^®Six Months

• Kits for your safety and first aid requirements

• 163-0798 contains supplies for 25 people;

163-0799 contains supplies for 50 people

• Comply with OSHA 1910.151 for industry, and

OSHA 1926.50 for construction

• Soft shell case

Part No.

Description

163-0798

Small Worksite First Aid Kit (25-Person)

163-0799

Large Worksite First Aid Kit (50-Person)

163-0798

163-0799

Contents

25-person

50-person

Adhesive Strips, 3/4 in x 3 in

100

Adhesive Tape Roll, 1/2in x 5 yd

Alcohol Wipes

Ammonia Inhalants

InstantCold Pack

Combine Pad, 5 in x 9 in

Sterile Cotton, 1/2 oz roll

Disposable Gloves

1 pr

2 pr

Eye Irrigate Solution, 1 oz bottle

Eye Pads, oval, 1.75 in x 2.5 in

Gauze Pads, 4 in

Gauze Pads, 3 in

First Aid Cream, 7/8 oz

Triangular Bandage

Gauze Bandage, 2 in x 5 yd

Gauze Bandage, 4 in x 5 yd

Elastic Bandage, 2 in

Scissors

Tweezers

First Aid Kit

Warranty: Caterpillar ^®Six Months

• Worksite first aid kit

• Designed to meet DIN 13164

• Metal Box

Part No.

Description

389-2195

First Aid Kit

389-2195 consists of:

Certi-Tape

2-inch Stretch Gauze Roll

3-inch Stretch Gauze Roll

Rescue Blanket

Bandage Scissors

First Aid Fact Sheet

Safety Flag

ANSI Z308.1.2009 Triangular Bandages

ANSI Z308.1.2009 Nitrile Gloves

Certi-Gauze Pads

Certi-Gauze Bandage Compresses in various sizes

Extra Large Plastic Certi-Strips

18-146 JULY 2018 Shop Supplies

Shop Supplies

COVERS

Cover for Engines

Warranty: Manufacturer's

• Protects engine from dirt and debris

• Affordable and disposable

• Can be used as drop cloth or dust cover

• 50 sheets per case

Part No.

Description

Dimensions

1U-7427

Engine Cover

122 x 183 cm (48 x 72 in)

Covers for Seats

Warranty: Caterpillar ^®Six Months

• These seat covers drape over the seats and

• These covers are made of a clear non-slip

are disposable when the job is finished

surface on both sides that helps hold it in

place while providing safe usage.

• They are produced from a specially formulated

resin that has a built-in stretch to help prevent

tool punctures and rips.

Part No.

Description

274-7454

Roll of 250 seat covers

274-7455

Case of 250 seat covers

Dispenser, Wall-Mount for Seat Covers

Warranty: Caterpillar ^®Six Months

• Space saver wall dispenser mounts with ease

• This dispenser will help keep your interior

to accommodate seat cover rolls

protection products clean and easy to reach

Part No.

Description

274-7458

Wall-Mount Seat Cover Dispenser

Covers, Floor

Warranty: Caterpillar ^®Six Months

• Interior service soils are the single most

• These covers have a high absorption paper

frequent complaint by service customers.

on top and a plastic bottom that won't soak

through

• Help keep the inside clean with these floor

covers that stay in place.

Part No.

Description

274-7456

Case of 500 Floor Covers

18-147 JULY 2018 Shop Supplies

JULY 2018 Shop Supplies

18-147

Shop Supplies

COVERS

Covers for Steering Wheels

Warranty: Caterpillar ^®Six Months

• The see-thru steering wheel cover protects

• Impervious to grease, these afford maximum

your customer's steering wheel from oily

protection for the wheel.

prints.

• It is elasticized on both sides providing

protection for the wheel and the customer's

hands.

Part No.

Description

274-7457

Case of 500 covers

Dust Cap for 55 Gallon Drum

Warranty: Caterpillar ^®Six Months

• Excellent for covering open drum containers

• Prevents contamination and evaporation

• Ideal for most industrial, food, chemical, and

• Elastic around entire opening helps keep

pharmaceutical applications

cover in place

• Low cost protection from dirt, dust, and

• Provides easy access to contents

moisture

• Fits a 208.2 L (55 gal) drum

Part No.

Diameter

Description

270-5347

863.6mm (34in)

100 per box

Cover for Barrels

Warranty: Caterpillar ^®Six Months

• Used to cover open or closed top drums -

• Keeps drum top clean and contents ready for

cover snaps onto top of drum

use

• Supportsthe Caterpillar contamination control

• Made of long lasting, low density

efforts

polyethylene - resistant to petroleum-based

fluids and ultraviolet rays

• Protects drum contents from water induction

when stored outside

• 10 covers per package

Part No.

Material Thickness

I.D.

Color

1U-6156

1.5mm (0.06in)

571mm(22.48in)

Yellow

Bags, Zipper-Top and Clear for Contamination Control

Warranty: Caterpillar ^®Six Months

• Exceptional strength

• Material: linear low density polyethylene

(LLDPE)

• Plastic slider top for easy opening and closing

Part No.

Size

Thickness

Qty.

270-5341

203 x 178 mm (8 x 7 in)

3.0 mm

250 bags/carton

270-5342

229 x 305 mm (9 x 12 in)

3.0 mm

250 bags/carton

18-148 JULY 2018 Shop Supplies

Shop Supplies

FLUID SAMPLING

Fluid Sampling Extraction Tools for Pressurized Compartments

Warranty: Caterpillar ^®Six Months

• Valve locations provide oil sample

7373 bottle assembly (which must be ordered

confidence and continuity-comparative

separately). (The cap requires that the bottles

data of pressurized oil samples is more

have a 38 M thread).

reliable because the sample is taken from a

169-7373 Bottle Assembly (Package Qty. -

continuous flow of oil at a known location.

200)

• A probe is provided that allows the valve

• This smaller bottle assembly (169-7373)

to be quickly flushed prior to taking the oil

can be used with the 177-9343 Probe and

sample

Cap Group and reduces mailing expense by

• The sample bottle group is packaged, and

approximately one-half for dealers whose

sealed in a plastic bag to insure cleanliness

oil sample labs can provide effective full

• Pressurized oil sampling is a fast, economical

service analysis with 71 g (21/2 oz) or less

and clean method of obtaining oil samples

of oil. These bottles can be used for engine

from pressurized systems

samples since particle count is not used for

enginesamples. This bottle can also be used

• Better represents oil condition because the oil

with the 1U-5718 Vacuum Pump used for non-

is continually mixed and circulated

pressurized oil sampling.

• 10 to 20 times faster than sampling oil from

8T-9208 Probe Assembly (package Qty. - 1)

non-pressurized systems

• The 8T-9208 Probe Assembly can be attached

• Mailing container is available so the oil

to a 6.35 mm (1/4 in) I.D. rubber hose (6K-

sample can be conveniently mailed to the

0713 Hose - 228.6 mm (9 in) long or any

testing laboratory

desired length cut from bulk 5P-6442 hose

• This bottle group is sealed in a plastic

or equivalent 100R6 type high temperature

bag with sampling instructions included.

- low pressure hose).The 8T-9208 Probe

The bottle group is ready to use when it is

and hose connected to a locally obtained

removed from the bag after the valve has

waste container provide a method to purge

been purged and the sample is ready to be

or flush the 8C-3446, 8C-3345, or 7X-3387

taken. The bottle included in this group (169-

sample values prior to obtaining the desired

7372) has the capacity to provide a 114 g (4

oil sample using either the 169-7373 Bottle

oz) sample. The 169-7372 can also be ordered

Group or 177-9343 Probe and Cap Group with

by itself, 200 per case.

the desired bottle. Approximately 14.8 cm

• After the sample is obtained, the probe and

to 29.6 cm (1/2 to 1 ounce) of expelled fluid

tube are removed from the bottle cap and

purges the valves.

holder, and discarded, and the cap-cover seals

• Pressurized systems on many Cat products

the bottle. Labels for identifying the sample

are equipped with sampling values to

(obtained locally) can then be attached to

quickly extract oil samples with the above

send the oil for identification purposes. The

tools. Special Instruction SEHS9043 details

4C-4600 mail tube is available to send the oil

retrofitting some earlier models with oil

sample to the laboratory. The laboratory also

sampling valves, as well as pointing out the

provides a mailing label.

respective valve locations on models currently

factory equipped with the oil sample valves.

169-8373 Bottle Group (Package Qty. - 300)

Impervious to grease, these afford maximum

• 177-9343 Probe and Cap Group (package

protection for the wheel.

Qty. - 500)

321-0659 8oz (240ml) Bottle and Cap

• The probe and cap group provides the same

(package Qty. - 1)

probe and cap that are used in the 169-8373

Bottle Group, however, without the bottle.

• The 321-0659 Bottle and Cap can be used

This group is also sealed in a plastic bag with

with the 293-8413 Hydac Contamination

sampling instructions included. This group

Monitor and the 202-2301 Portable

allows the dealer the flexibility to use other

• Contamination Instrumental Kit.

bottles such as the smaller 71 g (21/2 oz) 169-

18-149 JULY 2018 Shop Supplies

JULY 2018 Shop Supplies

18-149

Shop Supplies

FLUID SAMPLING

Item

Part Number

Description

Package Quantity

169-8373

Bottle Group, 300 per box

300 per box

162-8873

Probe, Holder

177-9343

Probe and Cap Group, 500 per box

500 per box

4C-4600

Mailer Container - reusable Tube - 30.5 m (100 ft) rolls

1U-8757

6.35 mm OD x 30.5 m rolls (1/4 in OD x 100 ft) 5 rolls per box

5 rolls per box

4C-4056

7.9 mm ODx30.5 m rolls (5/16in OD x 100 ft) 5 rolls per box, not pictured

5 rolls per box

169-7373

Clear Bottle, 71 g (2.5 oz), 200 per box

200 per box

169-7372

Clear Bottle, 114 g (4 oz), 200 per box

200 per box

1U-5718

Vacuum Pump

8T-9208

Purging Probe(1)

6V-0852

Dust Cap (Blank) (not pictured)

1U-7648

Tube Cutter

3J-7354

Seal - O-ring - STOR for 8C-3446 (not pictured)

–

1U-5719

Seal Kit for 1U-5718 Pump (not pictured)

–

7X-3387

S·O·S Sampling Valve

–

8C-3345

Oil Sampling Valve (M10x1—extthd)

–

8C-3445

Dust Cap (Engine)

–

8C-3446

Oil Sampling Valve (7/16 in-20 - ext. thd)

–

8C-3447

Dust Cap (Transmission) (not pictured)

–

8C-3451

Dust Cap (not pictured)

–

8C-8456

Sealed Cap

–

8T-7876

O-ring Seal for 8C-3345 (not pictured)

Not shown

321-0659

Bottle and Cap (8oz/240ml)

–

4C-4055

6.35 mm OD x 2.1 m (1/4 in OD x 7 ft), 250 pieces per box

250 per box

–

4C-4057

7.9 mm OD x 2.1 m (5/16 in OD x 7 ft), 240 pieces per box

250 per box

Oil Sampling Valves and O-Ring Seals

3J-7354

Seal - O-ring - STOR for 8C-3446 (not pictured)

–

7X-3387

S·O·S Sampling Valve

–

8C-3345

Oil Sampling Valve (M10x1—extthd)

–

8C-3446

Oil Sampling Valve (7/16 in-20 - ext. thd)

–

8T-7876

O-ring Seal for 8C-3345 (not pictured)

Protective Dust Caps for Oil Sampling Valves (These are rubber caps with embossed symbols to indicate system being sampled.)

6V-0852

Dust Cap (Blank) (not pictured)

–

8C-3445

Dust Cap (Engine)

–

8C-3447

Dust Cap (Transmission) (not pictured)

–

8C-3451

Dust Cap (not pictured)

–

8C-8456

Sealed Cap

Miscellaneous fittings and adapters commonly used for oil sampling valve retrofit installations

3J-5390

Plug - NPTF (Ext Hex) 3/8 in-18 NPTF external to 1/8 in-27 NPTF internal

3B-7722

Bushing-Pipe-Reducing 3/8 in-18 NPTF to 1/4 in-18 NPTF

2S-4078

O-ring Seal for 9T-6865 Adapter Plug

7M-8489

Adapter Assembly, 90° elbow 9/16 in-18 SAE external to 1/4 in-18 internal

6V-3966

Pressure Test Valve, 1/4 in-18 NPTF external

(not shown)

7J-8611

Elbow-90°-Pipe 1/4 in-18 NPTF

–

3J-1907

O-ring Seal for 5P-9617 Adapter

–

3L-6521

Adapter Tee, 1/4 in-18 NPT (2 internal and 1 external)

–

5P-3413

Pipe Sealant, 47.25 g (1 2/3 oz) tube

–

5P-3501

Adapter, 9/16 in-18 SAE external to 1/4 in-18 NPTF internal

–

5P-9617

Adapter Reducer, 9/16 in-18 SAE external to 7/16 in-20 SAE internal

–

6V-7529

Adapter, 1/8 in-27 NPTF external to 7/16 in-20 SAE internal

–

8C-6427

Adapter, 1/4 in-18 NPTF external to 7/16 in-20 SAE internal

–

9T-6865

Adapter Plug, 5/8 in-12 SAE external to 7/16 in-20 SAE internal

18-150 JULY 2018 Shop Supplies

Shop Supplies

FLUID SAMPLING

Fluid Sampling Extraction Tools for Non-Pressurized Compartments

Warranty: Caterpillar ^®Six Months

• Fluid sampling extraction tools are used to

• Labels identifying the fluid are obtained

obtain fluid samples from non-pressurized

locally. The label is processed locally and

vehicle compartments such as final drives,

attached to the sample bottle.

differential compartments, transfer cases,

• The 169-7373 bottle is the same as the 169-

axle housings, etc.

7372 bottle except the capacity is 71 g (21/2

• The 1U-5718 Vacuum Pump is capable of

oz) rather than 114 g (4 oz).

pulling 25 inch (7.62 mm) Mercury (vacuum).

• Clear high performance plastic rated at 91° C.

The pump is compact and accepts the

• 1U-8757 Tubing consists of five 30.5 m (100 ft)

169-7372, 114 g (4 oz), and 169-7373 Bottle

rolls of 6.35 mm (1/4 inch) O.D. plastic tubing.

Assembly, 71 g (2 1/2 oz), bottles, or any 38

Random lengths of tubing can be easily

M threaded plastic bottle, and 6.35 mm (1/4

dispensed from the tubing package. This

inch) O.D. and/or 7.9 mm (5/16 inch) O.D.

tubing permits extraction of heavier oils when

plastic tube.

using the vacuum pump.

• The 1U-5719 Kit provides replacement seals

• Both tubing sizes are also available in pre-cut

for the vacuum pump.

2.1 m (7 ft) lengths that are packaged 250

• The 169-7372 bottle has 4 oz (114 g) capacity.

pieces per box. This eliminates cutting the

The bottle is marked showing fluid full range

tube for each sample.

at 3/4 capacity. The fill range provides a

• 4C-4055 tubing contains 250 pieces of 6.35

reminder to not overfill the bottle. Partially

mm (1/4 inch) O.D. tubing each 2.1 m (7 ft).

filling the bottle satisfies both mailing and lag

requirements.

• 1U-7648 tube cutter is a convenient tool that

easily cuts the desirable length of 6.35 mm

• Full bottles expand because of temperature

(1/4 inch) or 7.9 mm (5/8 inch) plastic tubing.

changes and can possibly rupture within the

Cutter can cut the tubing at 90° or at a bias.

mailing container.

• The partially filled bottle also allows the lab

The following summarizes various sampling

to shake fluid sample prior to extracting fluid

tools available through the Caterpillar Parts

for testing.

Distribution System:

Part No.

Description

169-7372

Clear Bottle, 114 g (4 oz), 200 per box

169-7373

Clear Bottle, 71 g (2.5 oz), 200 per box

169-8373

Bottle Group, 300 per box

177-9343

Probe and Cap Group, 500 per box

1U-5718

Vacuum Pump

1U-5719

Seal Kit for 1U-5718 Pump (not pictured)

1U-7648

Tube Cutter

1U-8757

6.35 mm OD x 30.5 m rolls (1/4 in OD x 100 ft) 5 rolls per box

3J-7354

Seal - O-ring - STOR for 8C-3446 (not pictured)

4C-4055

6.35 mm OD x 2.1 m (1/4 in OD x 7 ft), 250 pieces per box

4C-4056

7.9 mm ODx30.5 m rolls (5/16in OD x 100 ft) 5 rolls per box, not pictured

4C-4057

7.9 mm OD x 2.1 m (5/16 in OD x 7 ft), 240 pieces per box

4C-4600

Mailer Container— reusable Tube—30.5 m (100 ft) rolls

6V-0852

Dust Cap (Blank) (not pictured)

7X-3387

S·O·S Sampling Valve

8C-3345

Oil Sampling Valve (M10x1—extthd)

8C-3445

Dust Cap (Engine)

8C-3446

Oil Sampling Valve (7/16 in-20 - ext. thd)

8C-3447

Dust Cap (Transmission) (not pictured)

8C-3451

Dust Cap (not pictured)

8C-8456

Sealed Cap

8T-7876

O-ring Seal for 8C-3345 (not pictured)

8T-9208

Purging Probe (Warranty: Manufacturer’s, 30-Day)

JULY 2018 Shop Supplies

18-151

Shop Supplies

FLUID SAMPLING

Containers, Oil Safe

Warranty: Caterpillar ^®Six Months

• Prevents oil contamination

• Expedites filling and refilling

• Speeds up lubrication jobs

• Leads to an organized workspace

• Dispenses easily to awkward points

• Pump fits 10L drum when coupled with a

Utility Lid

• Reduces spills and resulting accidents

Part No.

Description

310-5744

Contamination Prevention Kit

310-5744 Consists of:

Drum (3 l)

–

Drum (10 l)

–

Pump

–

Stretch Hose Extension

310-5715

Stumpy Spout Lid (Yellow)

Stretch Spout Lid (Blue)

–

Utility Lid (Red)

Accessories

310-5713

Stumpy Spout Lid (Red)

310-5716

Stumpy Spout Lid (Lt. Green)

Wipers, DRC Quarter-Fold

Warranty: Caterpillar ^®Six Months

• Highly absorbent material-cleans up oil,

• Offers a low-lint alternative

grease, water, and other messy fluids

• Economical alternative to shop rags or towels

• Strong and abrasion-resistant-resists

• Soft cloth-like feel

tearing even when wet

Part No.

Size

Color

Qty.

288-4209

31.75 x 33.02 cm (12.5 x 13 in)

White

56 wipers per bundle, 18 bundles per case

18-152 JULY 2018 Shop Supplies

Shop Supplies

TOWELS AND WIPES

Towels, DRC Pop-Up Shop

Warranty: Caterpillar ^®Six Months

• Highly absorbent material-cleans up oil,

• Strong and abrasion-resistant-resists

grease, water, and other messy fluids

tearing even when wet

• Soft cloth-like feel

• Offers a low-lint alternative in a handy pop-up

container

Part No.

Size

Color

Qty.

288-4210

24.13 x 41.91 cm (9.5 x 16.5 in)

White

100 towels per box, 9 boxes per case

288-4211

24.13 x 41.91 cm (9.5 x 16.5 in)

Blue

100 towels per box, 9 boxes per case

Towels, DRC Center-Pull Roll Dry Shop

Warranty: Caterpillar ^®Six Months

• Highly absorbent material-ideal for use on

• Center-pull wiper wrapped in clear plastic film

grease, oils, and other messy fluids

with re-closeable top tab for easy dispensing

• Strong and abrasion-resistant-resists

tearing even when wet

Part No.

Size

Color

Qty.

288-4212

22.86 x 33.02 cm (9.0 x 13.0 in)

White

300 towels per roll, 1 roll per pack

Bucket Dispenser, Cat^®Red Dry Shop Towels

Warranty: Caterpillar ^®materials and

• Handy dispenser bucket keeps towels clean

• Each bucket dispenser includes wall mount

workmanship to first user

and dry indoors and out.

hardwareand comes filledwith a roll of

303-9339 Cat^®Red Dry Shop Towels. Bucket

Ideal for heavy-duty wiping and cleanup

•

can be mounted in an upright or upside down

applications

position.

• DRC technology provides excellent wet

strength and durability while maintaining

Reference

great absorbency.

• Refill with 303-9339 Cat Red Dry Shop Towels

• Durable storage container is perfect for shop

or field.

Part No.

Description

Dimensions

Weight

Cat^®Red Dry ShopTowels

550-0937

254 x 305 mm (10 x 12in)

1.6 kg (3.5 lb)

Bucket Dispenser

Towels, DRC Center - Pull Shop

Warranty: Caterpillar ^®Six Months

• Economical alternative to shop cloths, without

• Made with the strongest and heaviest DRC

the mess

material on the market

• Works like cloth but at a faction of the cost

• New center pull design allows for one towel

to come out at a time

• Packaging keeps your shop towels clean and

dry until needed

• Center-pull design holds until the last three

towels

• Won't color bleed and no thread gaps

• Absorbs fluids on contact and lint free

Part No.

Description

Size

Qty.

303-9339

DRC Red Shop Towels

30.7 x 42.7 cm (12.1 x 16.8 in)

140 per roll

18-153 JULY 2018 Shop Supplies

JULY 2018 Shop Supplies

18-153

Shop Supplies

ABSORBENT PRODUCTS

Towels, DRC Jumbo Roll Shop

Warranty: Caterpillar ^®Six Months

• Highly absorbent material-cleans up oil,

• Strong and abrasion-resistant-resists

grease, water, and other messy fluids

tearing even when wet

• Soft cloth-like feel

Part No.

Description

Size

Color

Qty.

31.75 x 33.02 cm

692 towels per roll,

301-9696

DRC Jumbo Roll Shop Towels

White

(12.5 x 13in)

1 roll per case

311-3136

Holder for 301-9696

Wipers, All Purpose

Warranty: Manufacturer's

• Highly absorbent-cleans up oil, grease,

• Pliable for reaching into tight places

water and other messy fluids

• Soft for personal cleaning

• Strong and abrasion resistant-great wet-

• Lowlint and won't leave a residue

strength for scrubbing

• Economical alternative to shop rags or towels

Part No.

Size

Color

Qty.

265-2255

30.5 x 33 cm (12 x 13 in) quarter-folded

Blue

56 wipers per pack, 18 packs per case

Wipers

Warranty: Caterpillar ^®Six Months

• Designed to outperform rags with Hydroknit

• Leaves no residue

technology in lightweight wiper

• Good on grease and oil, adhesive cleaning

• Reinforced for extra scrubbing and cleaning

and cable lubricant removal

power

• Good for applying thinners and solvents

Part No.

Size

Color

Qty.

254-3422

23.1 x 42.7 cm (9.1 x 16.8 in)

White

126 wipers per box, 10 boxes per case

Wipers, Low Lint Task

Warranty: Caterpillar ^®Six Months

• For lab environments where clean rooms

• Continuous filament rayon/polyester spun-like

require low lint

blend for cloth-like feel

• Excellent for surface wiping in clean

• Excellent absorption rate and capacity

manufacturing environments-fuel systems,

• Solvent resistant

hydraulics, diagnostic equipment and

• Double wrapped in anti-stat packaging

precision instruments

Part No.

Size

Color

Qty.

265-2256

20.3 x 20.3 cm (8 x 8 in)

white

100 wipers per pack, 5 packs per case

18-154 JULY 2018 Shop Supplies

Shop Supplies

ABSORBENT PRODUCTS

Rags, Manufactured

Warranty: Caterpillar ^®Six Months

• HydroKnit fast-absorbing material-highly

• Pound for pound absorbs more oil and water

absorbent

than shop rags

• Cleans up oil, grime, and solvents

• Use with 1U-5432 Paper Wiper Dispenser

• Good for applying thinner and solvents

Part No.

Size

Color

Qty.

267-6532

31.8 x 36.6 cm (12.5 x 14.4 in)

white

76 wipers per bundle, 12 bundles per case

Rags, Manufactured Pop-up

Warranty: Caterpillar ^®Six Months

• HydroKnit fast-absorbing material-highly

• Good for applying thinner and solvents

absorbent

• Pound for pound absorbs more oil and water

• Reinforced for heavy maintenance cleaning

than shop rags

and long-lasting performance that also

• Packaged in sturdy corrugated pop-up

reduces waste

dispenser cartons

• Cleans up oil, grime, and solvents

• Can also use with 269-3368 Dispenser

Part No.

Wiper Size

Color

Qty.

267-6535

23.1 x 42.7 cm (9.1 x 16.8 in)

white

100 rags per carton, 10 cartons per case

267-6536

23.1 x 42.7 cm (9.1 x 16.8 in)

blue

100 rags per carton, 10 cartons per case

Dispenser, for Manufactured Rags and Paper Wipers

Warranty: Caterpillar ^®Six Months

Part No.

Description

Usage

1U-5432

Paper Wiper Dispenser, Plastic

use for 267-6532 Manufactured Rags

269-3368

Dispenser, White Metal

use for 267-6535 and 267-6536 ManufacturedRags

Towels, Hard Roll

Warranty: Caterpillar ^®Six Months

• Towels compressed on roll so more towels fit

• Material: paper

in same space - no sacrifice in performance,

Part No.

Description

Size

Color

Package Quantity

change roll less often

263-0892

Hard Roll Towels

20.3 cm x 304.8 m (8 in x 1000 ft) roll

White

12 rolls

• Good for cleaning and disinfecting surface

Towels, Shop

• Stands up well to spirits and solvents

Warranty: Caterpillar ^®Six Months

• Excellent absorbency

• Perfect to use on grease or oil

• Low-lint, 100% polypropylene construction

Part No.

Description

Size

Package Quantity

162-5791

Shop Towel

30.7 x 42.7 cm (12.1 x 16.8 in)

180 per box

JULY 2018 Shop Supplies

18-155

Shop Supplies

ABSORBENT PRODUCTS

Pads, Oil-Absorbent

Warranty: Caterpillar ^®Six Months

• Sonic-bonded Mats

• A lofty layer of randomly laid out melt-blow

fibers enables the mat to absorb a large

• Mats keep shape even when saturated

amount of oil

• Low lint

Part No.

Size

Quantity

Absorbency

467-9234

15 in x 19 in (38 cm x 48 cm)

14 gallons (55 L)

Socks, Absorbent

Warranty: Manufacturer's

Meets OSHA regulation 29 CFR 1910.22(a)(2) for

• Fine-grade vermiculite filler (non-

dry and clean workplace floors

biodegradable) quickly soaks up leaks and

drips

• Tubular absorbent socks absorb and contain

leaks and spills around machinery (hydraulic

• Durable, stitch-bonded polypropylene skin

oil, coolants, non-aggressive fluids, water,

improves strength

and even hazardous fluids, such as PCB oils

• Self-contained, no messy cleanup (no loose

and solvents)

absorbents to spread, sweep, scatter, shovel,

• Superior diking and damming capability

or track around)

(hugs the floor, creating an effective barrier

• Reusable for water spills only

or dike that holds back fluids, in emergency

• Material Safety Data Sheets (MSDS)available

situations, even after total absorption)

• Supplier-branded product

• Used primarily for everyday housekeeping

around machines that leak, seep, or spill fluids

Reference

• Fits snugly against machine bases and wrap-

• NELG5036

around corners, keeping work area safe and

dry

Shipping

Part No.

Quantity/ Box

Absorption/ Box

Absorption/ Sock

Size

Weight

8 cm x 122 cm

23 kg

235-0844

113 L (30 gal)

2.8 L (.7 gal)

(3in x 48 in)

(50.71 lb)

75 mm (3 in)

11 kg

254-3969

57 L (15 gal)

6.8 L (1.8 gal)

diameter x 3 m

(24.25 lb)

(10 ft) long

Pillows, Absorbent

Warranty: Manufacturer's

• Absorbent pillow soaks up small to medium-

• Strong, polypropylene cover will not tear

size spills of oil and other non-aggressive

when handling

fluids (works best once a spill has been

• Easy cleanup (simply pick up and place into

contained)

proper disposal container)

• Fast, effective way to control leaks

• Meets OSHA regulation 29 CFR 1910.22(a)(2)

• Use only as many as required (pillow's large

for dry and clean workplace floors

surface area and superior wicking ability

• Material Safety Data Sheets (MSDS)available

speeds cleanup time)

• Supplier-branded product

• High absorption/fast-wicking cellulose fibers

begin to work when pillow contacts liquid and

Reference

continue until fully saturated

• NELG5036

Part No.

Size

Quantity

Absorption/Sock

Absorbency

Shipping Weight

25 x 25 x 5 cm

235-0845

1.9 L (64 oz)

76 L (20 gal)

10kg(23lbs)

(10 x 10 x 2in)

18-156 JULY 2018 Shop Supplies

Shop Supplies

ABSORBENT PRODUCTS

Heavyweight Absorbent Material for Most Oil, Water-Based Fluids and Chemicals

Warranty: Manufacturer’s

• Absorbs the following fluids and chemicals:

keep floors and walk areas safer by absorbing

Acetone, Acetonitrile, Aluminum Salts,

leaks, spills, drips, and overspray

Ammonium, Hydroxide, Barium Salts,

• Dark gray color hides dirt and grime of foot

Benzyl Alcohol, Boric Acid, Butanol,

traffic

Calcium Chlorite, Carbon Disulfide,

• Thin profile slides into hard-to-reach areas

Carbon Tetrachloride, Chloroform, Cupric

Chloride, Cyclohexanone, Dichloromethane,

• Made from flame-resistant material which

Diethylamine, Dimethylformamide, Ethyl

can be used around spark-prone areas, such

Acetate, Formaldehyde, Gasoline, Glycol

as welding or grinding equipment

Ether, Hexane, Hydrazine, Anhydrous,

• Material will not degrade or have a chemical

Hydrochloric Acid (37%), Hydrogen Peroxide

reaction to a wide variety of chemicals and

(30%), Hydrofluoric Acid (48%), Isopropanol,

strong solvents

Jet Fuel (JP-5), Kerosene, Methanol, Methyl

Ethyl, Ketone, Mineral Oil, Mineral Spirits,

• Absorbs 10 times its weight, reducing

Naphtha, Nitric Acid (70%), Nitric Acid fuming

material purchase and disposal costs

(90%), Nitrobenzene, Perchloroethylene,

• Dimple design helps absorb more liquid in

Phenol, Potassium Hydroxide 50%, Propylene

less time (material retains liquid, even when

Glycol, Sodium Hydroxide (50%), Styrene,

fully saturated)

Sulfuric Acid (50%), Sulfuric Acid (98%),

• Roll material cuts easily with scissors or razor

Tetrachloroethylene, Tetrahydrofuran, Thionyl

knife - easily shaped to fit virtually any area

Chloride, Toluene, 1, 1, 1-Trichloroethane,

Trichloroethylene, Triethylamine, Turpentine,

• Material: 100% polypropylene

Water

• Multiple layers are held together with

• Heavyweight, gray, absorbent material

thermal bond points for added strength and

designed to absorb chemicals, solvents, oils,

durability-will not fall apart or leave behind

coolants, petroleum products, water, water-

residue, even when fully saturated

based fluids, and even acids and bases

• Meets OSHA regulation 29 CFR 1910.22(a)(2)

• Multiple uses in maintenance, repair, and

for dry and clean workplace floors

operating (MRO) areas; cover areas prone to

• Material Safety Data Sheets (MSDS)available

overspray and spills, leaving a cleaner, safer

• Supplier-branded product unless otherwise

work area; ideal for heavy, concentrated

indicated

machine leaks and large, spreading spills;

Quantity/

Absorption/

Shipping

Part No.

Description

Size

Ply

Box

Box/ Roll

Pad

Weight

235-0847

Roll

1 roll

155 L (41 gal)

76 cm (30 in) wide 46 m (150 ft) long, perforated to 25 x 38 cm (10x15 in)

14 kg (30.86lb)

261-0114

Mat

1 roll

53.06 L (14 gal)

76.2 cm (30 in) wide 15.25 m (50 ft) long

5 kg (11.02 lb)

307-9919

Pad

100 pads

80 L (21 gal)

798 ml (27 oz)

38 x 48 cm (15 x 19 in)

8 kg (17.64 lb)

307-9920

Pad

100 pads

91 L (24 gal)

917 ml (31 oz)

38 x 51 cm (15 x 20 in)

9 kg (19.84 lb)

307-9922

Pad

100 pads

80 L (21 gal)

798ml ( 27oz)

38 x 48 cm (15 x 19 in)

8 kg (17.64 lb)

76 cm (30 in) wide 46 m (150 ft) long

307-9925

Roll

1 roll

163 L (43 gal)

15 kg (33.07lb)

perforated every 25 cm (10in)

307-9927

Roll

1 roll

163 L (43 gal)

76 cm (30 in) wide 46 m (150 ft) long

15 kg (33.07lb)

Rugs, Absorbent

Warranty: Caterpillar ^®Six Months

• Keep shop floors cleaner and safer

• Durable enough to withstand heavy traffic

• Absorb most shop fluids and oils

• Coated rug has a poly-backed coating to

provide extra protection to shop floors

• Tough and tear resistant-won't break down

Part No.

Description

Size

Absorbent Capacity

159-5155

Rug

91 cm x 91.5 m (36 in x 300 ft)

121 L (32 gal) per roll

159-5160

Rug (Coated)

91 cm x 30 m (36 in x 100 ft)

40 L (10.5 gal) per roll

JULY 2018 Shop Supplies

18-157

Shop Supplies

ABSORBENT PRODUCTS

Pads and Rolls, Oil-Only Absorbent

Warranty: Manufacturer's

• Heavyweight, white, absorbent material used

• Dimple design helps absorb more liquid in

for spill cleanup and everyday maintenance

less time (material retains liquid even when

absorption of non-flammable petroleum

fully saturated)

products and petroleumbased fluids, such as

• Roll material cuts easily with scissors or razor

oil, gasoline, kerosene, diesel fuel, solvents,

knife - easily shaped to fit virtually any area

etc.

• Material: 100% polypropylene

• Absorbs petroleum-based fluids only-ideal

• Multiple layers are held together with

for situations where water absorption is not

thermal bond points for added strength and

necessary

durability-will not fall apart or leave behind

• Roll material works great for factory floors

residue, even when fully saturated

saturated with oils or other petroleumbased

• Material can be incinerated with less than

fluids

0.1% ash while producing 21,000 Btu/lb

• Less expensive than a universal absorbent

• Meets OSHA regulation 29 CFR 1910.22(a)(2)

(ideal for oil-only spills or drips)

for dry and clean workplace floors

• Material will not degrade or have a chemical

• Material Safety Data Sheets (MSDS)available

reaction to petroleum-based fluids

• Supplier-branded product unless otherwise

• Absorbs 10 times its weight, reducing

indicated

material purchase and disposal costs

Shipping

Part No.

Description

Quantity/ Box

Absorption/ Box/Roll

Absorption/ Pad

Size

Ply

Color

Weight

76 cm (30 in) wide 46 m

235-0850

Roll

1 roll

155 L (41 gal)

14 kg (30.86lb)

White

(150 ft)long

307-9921

Pad

50 pads

45 L (12 gal)

917 ml (31 oz)

38 x 51 cm (15 x 20 in)

4 kg (8.82 lb)

White

307-9923

Pad

100 pads

76 L (20 gal)

739 ml (25 oz)

38 x 48 cm (15 x 19 in)

8 kg (17.64 lb)

White

76 cm (30 in) wide 46 m

307-9924

Roll

1 roll

151 L (40 gal)

15 kg (33.07lb)

White

(150 ft)long

76 cm (30 in) wide 46 m

307-9926

Roll

1 roll

151 L (40 gal)

15 kg (33.07lb)

White

(150 ft)long

307-9928

Pad

100 pads

76 L (20 gal)

739 ml (25 oz)

38 x 48 cm (15 x 19 in)

8 kg (17.64 lb)

White

Roll, Lightweight Absorbent

Warranty: Manufacturer's

• Lightweight, gray, absorbent mat designed

• Works well in narrow walkways

to cover areas prone to overspray and spills,

• Multiple layers are held together with

leaving a cleaner, safer work area

thermal bond points for added strength and

• Ideal for light machine overspray and small,

durability-will not fall apart or leave behind

annoying leaks of oils, coolants, solvents, and

residue

water

• Dark gray color hides dirt and grime

• Great for day-to-day housekeeping and repair

• Dimple design absorbs more liquid in less

work

time and greater liquid retention holds liquid

• Cross roll perforations— easily and quickly

even when roll is saturated

tear to any size sheet, as small as 25 x 61 cm

• Meets OSHA regulation 29 CFR 1910.22(a)(2)

(10 x 24 in)

for dry and clean workplace floors

• Absorbs 10 times its weight, reducing

• Material Safety Data Sheets (MSDS)available

purchase and disposal costs

• Supplier-branded productx

Quantity/

Part No.

Absorption/Box

Size

Material

Ply

Shipping Weight

Box

235-0849

1 roll

125 L (33 gal)

61 cm (24 in) wide by 91 M (300 ft) long

100% polypropylene

11 kg (24.25lb)

18-158 JULY 2018 Shop Supplies

JULY 2018 Shop Supplies

18-158

Shop Supplies

ABSORBENT PRODUCTS

Mat, Rip & Fit Absorbent

Warranty: Manufacturer's

• Absorbs large amounts of coolant, oil,

• 60’ L x 15” W fitted into dispenser box

solvents, and water, 7.8 gallons (29.5 L)

• Dark gray, flame-resistant material

• Heavy-weight and durable

• 50% recycled material

• Perforations every 10” lengthwise and every

• Refill item for Spill Response Kit, 254-3770

3.75”widthwise to help you easily fit themat

into the shape of your workspace

Shipping

Part No.

Description

Absorption

Dimensions

Weight

Absorbent Roll with length -

15 in (38 cm) wide

385-5560

29.5 L (7.8 gal)

6.9 lbs (3.1 kg)

and widthwise perforations

x 60 ft (18 cm) long

Mat, High-Visibility Absorbent

Warranty: Manufacturer's

• Absorbs oils, coolants, solvents and water

• Flame-resistant - safe for spark-prone areas

such as welding robots

• Ideal for any leak-, spill-, or drip-prone areas

• Comeswith a variety of socks and pillows

• Absorbs a wide range of chemicals without

along with a roll of universal mat

degrading or causing a dangerous chemical

reaction

• Low profile - slides into hard-to-reach areas

• High-visibility yellow color alerts workers to

• Supplier-branded product

potential dangers where work or repairs are

taking place

Absorbent

Part No.

Length

Width

Weight

Material

Ply

Capacity

125 L (33 gal)

46m

261-0115

61 cm (24 in)

11 kg (24 lb)

100% polypropylene

per bag

(151 ft)

Spill Kits, Sorbent

Warranty: Caterpillar ^®Six Months

• Most versatile spill kit on today's market

170-8604 Spill Kit, 5 Gallon

• Chemical Sorbent Folded Spill Kit is a non-

• Absorb 5 gallons of petroleum-based fluid

selective sorbent which will "sorb" most

• Roll of folded sorbent, 13 x 66 cm (5 x 26 in);

aggressive chemicals

fully opened 48 x 66 cm (19 x 26 in);

• 170-8604 fits into small places where

• Qty 1

accessibility is important; unique construction

• Disposal bag and tie, Qty 1

and compressibility allows storage behind or

under seats and/or lab benches where other

170-8605 Spill Kit, 31 Gallon

spill kits will not fit

• Absorb 31 gallons of petroleum-based fluid

• 170-8605 is packaged in a 20 gallon drum and

• 20 gallon drum with lid and plastic closure

can be placed in key locations throughout a

ring, Qty 1

facility

• Roll of folded sorbent, 13 x 127 cm (5 x 50 in);

• Most complete spill kit in a roll (material can

fully opened, 48 x 127 cm (19 x 50 in), Qty 2

be used as a pillow, pad, roll, or boom)

• Sorbent pads, 43 x 48 cm (17 x 19 in), Qty 30

• Scrim coating on one side increases strength

and eliminates linting

• Disposal bags and ties, Qty 3Cleans spills

with no residue

• Each kit contains a containment bag and tie

• Molded handles makes transportation easier

Part No.

Size

170-8604

5gal

170-8605

31 gal

18-159 JULY 2018 Shop Supplies

JULY 2018 Shop Supplies

18-159

Shop Supplies

ABSORBENT PRODUCTS

Pig Original SpillBlocker Dike

Warranty: Caterpillar ^®Six Months

• Non-weight bearing, temporary/removable

• Fast protection when a spill is heading right

barrier for smooth surfaces

for your drain; just place dike in front of spill

to contain liquid.

• Exclusive new pig formulation features a tear-

resistant top layer and a flexible, tacky bottom

• Confines and diverts fluids without absorbing

layer that seals tight to smooth surfaces and

them, making cleanup or reclamation simpler

blocks liquids.

• Polyurethane material resists water, oils and

• Other dikes may look similar, but only PIG

many chemicals

SpillBlocker Dikes have two-layer construction

• Reusable dike cleans easily with soap and

for superior performance.

water

• 2.25 in height is great for containing smaller

spills

Part No.

Description

Dimensions (W x L x H)

Weight

102 mmx3mx57mm

520-0205

Pig Original SpillBlocker Dike

13.6 kg (30 lb)

(4 in x 10 feet x 2.25 in)

Spill Response Cart, Small

Warranty: Manufacturer’s

• Absorbs oils, coolant, solvents, and water

• Cleanup instructions on cart door

• Ideal for spill-prone areas

• Cart can be locked for security

• Comeswith a variety of socks, mat pads,

• Helps to comply with 40 CFR 112.7(c) (1) (vii)

pillows, and wipers

where absorbents can be used to control oil

discharges

• Products in cart can absorb up to 59 liters

(15.5 gallons)

• Material Safety Data Sheets (MSDS)available

• Eight-inch rubber wheels and handles on both

• Supplier-branded product

top and bottom for carrying

Part No.

Description

Weight

267-6532

Small Spill Response Cart

29.5 kg (65.04lb)

Consists of:

Qty.

Reorder Part No.

Absorbent sock, 8 cm x 122 cm (3in x48 in)

235-0844

Absorbent sock, 8 cm x 250 cm (3in x10 ft)

254-3969

Universal mat pads, 38 cmx 22 cm (15in x 8.5in)

307-9919

Absorbent pillows, 25 cm x 25 cm (10in x 10 in)

235-0845

Wipers, 33 cm x 30 cm (13 in x 12 in)

Disposal bags and ties

Nitrile gloves

4C-5522, 4C-5523, or 4C-5526

Safety goggles

233-8583

Disposable boots

Repair putty, 178 mm (7 in) tube

Emergency response guidebook

Instruction Manual

18-160 JULY 2018 Shop Supplies

Shop Supplies

ABSORBENT PRODUCTS

Spill Response Cart, Small

Warranty: Manufacturer’s

• Absorbs oils, coolant, solvents, and water

• Shelves and compartments inside cart for

easy organization

• Ideal for spill-prone areas

• Cart can be locked for security

• Comeswith a variety of socks and pillows

along with a roll of universal mat

• Helps to comply with 40 CFR 112.7(c) (1) (vii)

where absorbents can be used to control oil

• Products in cart can absorb up to 53 liters (14

discharges

gallons)

• Material Safety Data Sheets (MSDS)available

• Eight-inch rubber wheels on board and

handles on both top and bottom

• Supplier-branded product

• Cleanup instructions on cart door

Part No.

Description

Weight

254-3770

Small Spill Response Cart

18 kg (39.68lb)

Consists of:

Qty.

Reorder Part No.

Absorbent socks, 8 cm x 122 cm (3 in x 48 in)

235-0844

Universal mat pads, 38 cm x 18 m (15 in x 60 ft)

Absorbent pillows, 25 cm x 25 cm (10in x 10 in)

235-0845

Disposable bags and ties

Nitrile gloves

4C-5522, 4C-5523, or 4C-5526

Safety goggles

233-8583

Repair putty, 178 mm (7 in) tube

"When the Spill Strikes" poster

Spill Response Kit, Large

Warranty: Manufacturer’s

• Absorbs oils, coolants, solvents, and water

• Equipped with eight-inch rubber wheels and

built-in handles for easy mobility in tight

• Comeswith a variety of socks, mats,pillows,

spaces

and loose absorbents

• Helps to comply with 40 CFR 112.7(c) (1) (vii)

• Products in cart can absorb up to 144 liters

where absorbents can be used to control oil

(38 gallons)

discharges

• Polyethylene container with hinged lid stores

• Material Safety Data Sheets (MSDS)available

and protects absorbents from moisture, dirt,

and damage

• Supplier-branded product

Part No.

Description

Weight

254-3769

Large Spill Response Cart

48.5

Consists of:

Qty.

Reorder Part No.

Absorbent sock, 8 cm x 122 cm (3in x48 in)

235-0844

Absorbent sock, 8 cm x 250 cm (3in x10 ft)

254-3969

235-0845

Absorbent pillows, 53 cm x 43 cm (21in x 17 in)

(Equivalent - not an exact replacement)

Universal mat pads, 51 cm x 41 cm (20in x 16in)

Disposal bags and ties

Shop floor sweep material

Loose absorbent material

Tamper-proof labels

Instructions

JULY 2018 Shop Supplies

18-161

Shop Supplies

FLOOR MATS

Floor Mat, WorkSafe

Warranty: Caterpillar ^®Six Months

• Holes trap dirt and small debris and are easy

• Border can be removed and reattached after

to clean

cutting mat to any size

• Black with orange beveled border

• 7/8 in (22.2 mm) thick

Part No.

Absorbent Capacity

4C-8099

2 ft x 3 ft (61 cm x 91 cm)

4C-8101

3 ft x 5 ft (91 cm x 152 cm)

Floor Mat, Rejuvenator Connect Modular

Warranty: Caterpillar ^®Six Months

• Interlocks on all four sides

• Border ramps are yellow for safety

• Customizable down to 3 x 3 ft (0.914 x 0.914

• Urethane sponge material with tough outer

m)squares

skin

• Resists a wide variety of chemicals of fluids

• 5/8” in (1.59 cm) thick

Part No.

Description

Size

384-8706

Center Segment

36 in x 36 in (91.4 cm x 91.4 cm)

385-8474

Male Ramp

2 in x 39 in (5.1 cm x 99 cm)

Floor Mat, Weldsafe

Warranty: Caterpillar ^®Six Months

• Designed specifically for welding/grinding

• Beveled edges

stations

• Black

• Top surface has melting point of over 500°F

• 9/16 in (1.4 cm)

(260°C)

Part No.

Size

385-8475

36 in x 60 in (91 cm x 152 cm)

Pig^®Grippy^®Absorbent Mat

Warranty: Caterpillar ^®Six Months

• Absorbs and retains water, oils, grease,

• Liquid proof barrier layer prevents seepage

coolants, solvents, etc., while preventing dirt,

through the mat

sand, and liquids from being tracked off onto

• Dark color hides grime allowing longer use

clean floors

• Absorbs up to 13 gal (49 L)

• Demonstrated to reduce slips and falls by as

much as 90%

Specifications

• Grippy^®backing holds mat in place but peels

• Dimensions: 36 in x 100 ft (914 mm x 30 m)

up easily without residue

• Weight: 24 pounds (11 kg)

• Heat-fuse and needle-punched for durability

• Holds up to heavy traffic, including power

trucks

Part Number

Description

473-6461

Pig^®Grippy^®Absorbent Mat

18-162 JULY 2018 Shop Supplies

Shop Supplies

FLOOR MATS

Floor Mat, Clean Walk

Warranty: Caterpillar ^®Six Months

SMCS Code 7951-580

• Removes dirt/contamination from shoes,

wheels, and other passing objects - keeps

• 30 peelable layers, providing a fresh cleaning

dirt/grease from being tracked into office area

surface with each exposed layer

• Inexpensive way to keep carpets and office

• Low profile - only 0.055 in (1.4 mm) thick

areas clean

Part No.

Size

138-3856

635 mmx1143 mm(25in x 45in)

Floor Protection

Warranty: Manufacturer’s One Year

Track Mat

Dozer Blade Mat

• Provides the protection needed against the

• 506-1260 polyurethane motor grader/dozer

Send warranty-related questions to:

potential damage caused by dozers and

blade rest pads and 506-1261 ripper pads

sales@ameintl.net .

excavators driving on concrete workshop

assist in protecting the concrete surface of

floors

workshop floors.

• Polyurethane dovetail sheets

506-1258

• Use with 506-1259 stainless steel trolley,

which holds 12 pads at a time and can be

maneuvered safely and packed away neatly

when not in use.

Part No.

Description

Dimensions

Weight

506-1258

Track Mat

1000 x 800 x18 mm (39 x 31 x 0.71 in)

18 kg (40 lb)

506-1259

Track Mat Carriage

1111.3 x 750 x 965 mm ( 44 x 30 x 38 in)

22 kg (49 lb)

506-1260

Dozer Blade Mat

600 x 200 x 50 mm (23.5 x 8 x 2 in)

18 kg (40 lb)

506-1261

Ripper Mat

400 x 465 x 40 mm ( 16 x 18.3 x 2 in)

11 kg (24.3 lb)

506-1260

506-1261

JULY 2018 Shop Supplies

18-163

Shop Supplies

TAPES AND FILMS

Tape, General Purpose Masking

Warranty: Caterpillar ^®Six Months

• Can be used for holding, bundling, sealing,

tabbing non-critical masking and many

other miscellaneous applications where an

economical grade of paper tape is needed

Part No.

Size in 55 m (60 Yd) Rolls

Rolls/Case

4C-6571

25.4 mm (1 in)

4C-6572

50.8 mm (2 in)

4C-6573

76.2 mm (3 in)

Tape, Masking

Warranty: Caterpillar ^®Six Months

• Six sizes available-13 mm (1/2 in) to 76.2

• Sharp paint edge-thin, smooth backing gives

mm(3in) wide, 60 yd. roll

superior, straight paint line w/o jagged edges

• Clean removal-less adhesive transfer

• One-piece removal-balancedconstruction

reduces residue which can stick to work

allows for one-piece removal

surface

• Heat resistant-will generally function well

in conditions up to 93° C (200° F)

Part No.

Size in 55 m (60 Yd) Rolls

Rolls/Case

1U-6705

12.7 mm (1/2 in)

1U-6709

63.5mm (2 1/2in)

Tape, 3M High Performance Green Masking Tape 401+

Warranty: Caterpillar ^®Six Months

• 3M™High Performance GreenMasking Tape

• Remains in place around corners, over

401+ delivers sharp paint lines where surface

contours and irregular surfaces

temperatures can reach up to 250°F/ 121°C

• Resists paint bleed-through to help create

for 30 minutes. This green crepe paper tape

sharp paint lines

is ideal for critical paint masking applications

• Green backing improves visibility and accuracy

in automotive, specialty vehicle and industrial

during paint masking

markets where strong holding and high temp

performance is required.

• Withstands surface temperatures up to 250

degrees F/ 121 degrees C for 30 minutes in

• 55 meter rolls

paint bake operations

• Adhesive formula removes cleanly in one

piece with no adhesive residue

Part No.

Width

Rolls Per Case

1U-6706

18 mm

485-8533

24 mm

485-8534

48 mm

485-8535

72 mm

Tape, Label Protection

Warranty: Caterpillar ^®Six Months

• Used for covering address labels, packing

• Adhesion to steel: 17.9 N/cm (16 oz/in)

lists, and sales slips when protection against

• Tensile strength: 0.32 kg/mm (18 lb/in)

rough handling is needed

• Thickness: 0.04 mm (1.6 mils)

• Aggressive water-based acrylic adhesive

• Material: polypropylene

• Resistant to UV light and chemicals

Part No.

Size

Rolls/ Case

263-0881

96.01 mm x 659.9 m (3.78 in x 216.5 feet) roll

JULY 2018 Shop Supplies

18-165

Shop Supplies

TAPES AND FILMS

Tape, Filament

Warranty: Caterpillar ^®Six Months

• Stain resistant and transparent with

• Used for closure and reinforcement of

reinforced continuous glass yarn filaments

corrugated fiberboard boxes and performs

well in holding, reinforcing, combining,

bundling, and unitizing applications

Part No.

Size

Rolls/ Case

4C-4094

19mm(3/4in)x55m (60yd)roll

Tape, Filament

Warranty: Caterpillar ^®Six Months

• Fiberglass reinforced tape excellent for

• Elongation: 8%

light-duty applications such as strapping,

• Tack: 12.7 cm (5 in)

palletizing, and packaging

• Tensile strength: 1.71 kg/mm (95.6 lb/in)

• Adhesion to steel: 8.5 g/mm (78 oz/in)

• Thickness: 0.099 mm (3.9 mils)

Part No.

Size

Rolls/ Case

263-0883

51 mm x 22.9 m (2 in x 25 yards) roll

Tape, Transparent

Warranty: Caterpillar ^®Six Months

• Good for general purpose packaging needs

• Has very good resistance to edge tear and

splitting due to shock from impact

• Was developed primarily for single strip

closure of regular slotted containers

• Adhesive sticks at a touch to fiberboard

Part No.

Size

Rolls/ Case

4C-4095

48mm(2in) x 100 m

Tape, Double-faced

Warranty: Caterpillar ^®Six Months

• Multipurpose tape for general mounting and

• Peels clean leaving minimum residue

holding

• Adhesion to steel: 44 g/mm (40 oz/in)

• Can be used to reattach interior cab material

• Tack: 5.1 cm (2 in)

or head liners, sound proofing material, etc.

• Tensile strength: 0.36 kg/mm (20 lb/in)

• Extremely aggressive adhesive

• Thickness: 0.28 mm (11 mils)

• Silicone-coated polyethylene release liner

makes unwinding easy

Part No.

Size

Rolls/ Case

263-0877

51 mm x 22.9 m (2 in x 25 yards) roll

18-166 JULY 2018 Shop Supplies

Shop Supplies

TAPES AND FILMS

Tape,White Filament

Warranty: Caterpillar ^®Six Months

• Multipurpose non-adhesive thread seal tape

• Easy to assemble and disassemble threaded

used for many maintenance applications

joints when tape is applied

• Polytetraflouroethylene (PTFE) self lubricates

• Thickness: 0.09 mm (3.5 mils)

joints for a leak-proof seal

• Material: polytetraflouroethylene

• White color

Part No.

Size

Rolls/ Case

263-0879

13 mm x 76.2 m (0.5 in x 250 feet) roll

200

Tape, Duct

Warranty: Caterpillar ^®Six Months

• Use this silver, polyethylene-coated, cloth

• Has an extremely tough rubber adhesive

tape for sealing and/or waterproofing

Part No.

Size

Qty.

190-9792

51 mm (2 in) wide and 55 m (60 yds) long

applications

• Rubber adhesive adheres securely

Tape, High Performance Duct

• Thickness: 12 mils

• Tensile strength: 42 lbs per inch

Warranty: Caterpillar ^®Six Months

• Use this olive drab, polyethylene-coated,

cloth tape for sealing and/or waterproofing

applications

• Conforms to mil spec PPP-T-60D

Part No.

Size

Qty.

9U-5922

51 mm wide x 55 mm long (2 in wide x 60 yd long)

Tape, Electrical

Warranty: Caterpillar ^®Six Months

• Premium quality vinyl tape with many

electrical insulation applications

Part No.

Size

Qty.

1P-0810

19 mm x 20.12 m long (3/4 in wide x 66 ft long)

JULY 2018 Shop Supplies

18-167

Shop Supplies

TAPES AND FILMS

Tape, Electrical

Warranty: Caterpillar ^®Six Months

• Quality, black, vinyl tape with excellent

electrical insulation properties

Part No.

Size

Qty.

235-8598

19 mm x 18.3 m long (3/4 in wide x 60 ft long)

Tape, Aluminum

Warranty: Caterpillar ^®Six Months

• A variety of sizes of aluminum tape that can

• 3.5Mil thick

be used for a number of applications in the

• Tough and flexible

• Hi-tack

• Waterproof

Part No.

Description

Size

9U-6910

Aluminum Tape

63.5 mm x 45.7 m (2 1/2in x 50 yds)

9U-6911

Aluminum Tape

101.6 mm x 45.7 m (4 in x 50 yds)

9U-6912

Aluminum Tape

152.4 mm x 45.7 m (6 in x 50 yds)

9U-7042

Aluminum Tape

304.8 mm x 45.7 m (12in x 50 yds)

• Hand-held and portable-excellent on center

seam sealing of regular slotted boxes

Tape Dispenser, Box Sealing

• Sturdy, durable, easy to load and operate;

Warranty: Caterpillar ^®Six Months

• Provides quick, easy method for dispensing

handles tape widths from 38 mm (1 1/2 in) to

4C-4095 Transparent Tape, or any other film-

51 mm (2 in)

backed box sealing tape directly from the roll

Part No.

Description

Qty.

4C-4099

Box Sealing Tape Dispenser

• High impact plastic and one piece

construction makes the dispenser very durable

Tape Dispenser, Filament

• Handles filament tapes up to 19 mm (3/4 in)

Warranty: Caterpillar ^®Six Months

• Fast and economical clips of 4C-4094 Filament

wide

Tape can be applied

• Dispenser cuts and buffs tape with one-hand

motion

• Features hand brake in the core that allows

operator to adjust tension for tighter box

reinforcement and bundling applications

Part No.

Description

Qty.

4C-4100

Filament Tape Dispenser

JULY 2018 Shop Supplies

18-169

Shop Supplies

TAPES AND FILMS

Heavy-Duty Mounting Tape

Warranty: Caterpillar ^®Six Months

• High strength and durable

• Conformable, double-sided, pressure-

sensitive, closed-cell acrylic foam tape

• Clean appearance

• Ideal for re-mounting Cat^®Telematics

• Bonds high, medium and medium/low surface

PL131/141 cellular and satellite locators to

energy substrates.

new surfaces/assets.

• Provides handling convenience, cushioning,

• Black color

damping, and impact resistance.

Part No.

Description

Dimensions

Weight

497-8355

3M VHB Heavy-Duty Mounting Tape 5952

1 in x 36 yards x 5 mil

1 kg (2.2 lb)

Tape, Rubber Mastic

Warranty: Caterpillar ^®Six Months

• Great for quick buildup for moisture seal, for

• Molds easily around irregular surfaces

insulation, and for cushion on cable harness

while holding its position through a range of

and wires

temperatures

• Sticks fast, seals fast and stays tight

Part No.

Size

Qty.

4C-6392

51 mm(2in) wide X 1.7 mm (.065in) thick by 3 m (10 ft)long rolls

Band-it Tool, Adjustable Stretch

Warranty: Caterpillar ^®Six Months

• Fully mechanical

• Nospare parts-no parts toreplace or wear

out

• Adjustable stretch control

• Use with 4C-4880 Film

Part No.

Description

4C-4779

Adjustable Stretch Band-it Tool

Band-it Tool, Stretch

Warranty: Caterpillar ^®Six Months

• "Hand Squeeze" control

• No assembly, no maintenance, no additional

adhesives

• Use with 4C-4880 Film

Part No.

Description

4C-4780

Stretch Band-it Tool

JULY 2018 Shop Supplies

18-169

Shop Supplies

TAPES AND FILMS

Handwrappers

Warranty: Caterpillar ^®Six Months

• Full rolls to 558.8 mm (22 in) wide

• Adjustable tension

• Fits 76.2 mm (3 in) core

• Ring rotates freely

• Heavy duty mast

• Foamgrip

• Ball bearings

Part No.

Use

4C-4776

all 279 mm (11 in), 400 mm (15.75 in), 457 mm (18 in) films with 76 mm (3 in) cores

all 279 mm (11 in), 692 mm (27.25 in), 457 m (18 in) films with 57 mm

4C-4777

(2.25 in) and 76 mm (3 in) cores

Band-it Tool Stand for Stretch

Warranty: Caterpillar ^®Six Months

• Portable

• Adjustable zinc-plated support

• Mounts on any table surface

• Allows wrapping of smaller items using

4C-4880 Film and 4C-4779 or 4C-4780 Stretch

• Accommodates up to 16 kg (35 lbs)

Band-it Tools

Part No.

Description

4C-4781

Stretch Band-it Stand

Film, Heavy-Duty Master Wrap

Warranty: Caterpillar ^®Six Months

• Holds anything, any shape, anywhere

• Applicator packed in all cases

Part No.

Rolls/Case

Film Gauge

Film Width

Roll Length

Film Color

4C-4880

135

127 mm (5 in)

198 m (649.60 ft)

Blue

Film, Stretch

Warranty: Caterpillar ^®Six Months

• Revolutionary performance standard-one of

• Has highest holding-force-to-load possible

the strongest films in the industry

without breaks

• Cast formula

• Visually able to see through to wrapped

product

• Stiff high force

• No neck-down films

Part No.

Rolls/Case

Film Width

Roll Length

Film Color

291-6710

457.2mm (18in)

457 m (1,499.34 ft)

Clear

291-6711

279.4mm (11in)

457 m (1,499.34 ft)

Clear

18-170 JULY 2018 Shop Supplies

Shop Supplies

PACKING SUPPLIES

Film, Hand Wrap Standard-Duty Stretch

Warranty: Caterpillar ^®Six Months

• Convenient stretch film system

• Extra wide-508 mm (20 in) compared to

457.2 mm (18 in)

• Standard-duty gauge

Part No.

Rolls/Case

Film Width

Roll Length

Film Color

293-2978

508 mm (20in)

305 m (1,000.65 ft)

Clear

Heat Shrink Bags

Warranty: Caterpillar ^®Six Months

• Strong durable plastic excellent for pallet

• To determine the size of opening for gusseted

unitization and load retention

bags, add the width and depth

• Ensures product will arrive at destination

• UVI protection will protect bag from sun

clean and undamaged

damage in outdoor storage.

Part No.

Width x Depth x Height

Thickness

Qty.

Gusseted Heat Shrink Bag

270-5329

800 x 495 x 710 mm (31.5 x 19.5 x 28 in)

5 mil

135 bags/roll

270-5331

1257 x 495 x 1370 mm (49.5 x 19.5 x 54in)

5 mil

65 bags/roll

Flat Heat Shrink Bag

270-5332

2438 x 1829 mm (96 x 72 in)

5 mil

35 bags/roll

270-5333

3810 x 2970 mm (150 x 117 in)

5 mil

15 bags/roll

Heat Shrink Sheeting

Warranty: Caterpillar ^®Six Months

• Strong durable plastic excellent for pallet

• 5% UVI protection will protect bag from sun

unitization and load retention

damage in outdoor storage

• Ensures product will arrive at destination

clean and undamaged

Part No.

Roll Size

Thickness

Color

Qty.

270-5334

5.5 x 61 m (18 x 200 ft)

7 mil

white

1 roll

270-5335

914 mm x 198 m (36 in x 650 ft)

5 mil

clear

1 roll

270-5336

1.37 x 198 m (54 in x 650 ft)

5 mil

clear

1 roll

Cardboard Boxes with Cat^®Logo

Warranty: Caterpillar ^®Six Months

• Material: corrugated paper

Part No.

Length x Width x Depth

Edge Crush Number (ECT)

Qty.

270-5348

213 x 213 x 210 mm (8.4 x 8.4 x 8.3 in)

32 lb

25 per package

270-5349

254 x 203 x 170.8 mm (10 x 8 x 7 in)

32 lb

25 per package

270-5350

300 x 300 x 190 mm (11.8 x 11.8 x 7.5 in)

32 lb

20 per package

270-5351

318 x 315 x 224 mm (12.5 x 12.4 x 8.8 in)

32 lb

25 per package

270-5352

356 x 356 x 229 mm (14 x 14 x 9 in)

32 lb

10 per package

270-5353

648 x 648 x 503 mm (25.5 x 25.5 x 19.8 in)

5 per package

JULY 2018 Shop Supplies

18-171

Shop Supplies

PACKING SUPPLIES

Maintenance Products Box

Warranty: Caterpillar ^®Six Months

• The Maintenance Products box preventive

• Made of recyclable heavy duty cardboard

maintenance items, such as filters and grease,

• Practical handle for easy transport

for machine service intervals. Designed

• Includes blank lines for recording box contents

to support dealer promotional campaigns

and over-the-counter part sales; the carton

• Simple assembly

assembles easily and has a convenient

carrying handle.

Part No.

Size

Qty.

390-3319

483 X 457 X 381 mm (19 X 18 X 15 in)

10 per bundle

332-1471

406 X 356 X 305 mm (16 X 14 X 12 in)

20 per bundle

Bags with Cat Logo (Plastic)

Warranty: Caterpillar ^®Six Months

• Two-color Cat logo on front, clear on the back

• Exceptional strength

• Great for parts storage and shipping

• Material: linear low density polyethylene

(LLDPE)

• Thickness: 1.75 ml

Part No.

Size

Qty.

270-5337

30.48 cm x 45.72 cm (12 x 18 in)

1000 bags/carton

270-5338

45.72 cm x 61 cm (18 x 24in)

500 bags/carton

18-172 JULY 2018 Shop Supplies

Shop Supplies

PACKING SUPPLIES

Shrinkfast Shrink Gun

Warranty: Caterpillar ^®Six Months

• Portable - 3.5 lbs

• Versatile - the shrink gun can be used on

machinery, bagged products, boxes, pallets,

• Fast— shrinkwrap a 1016 mm x 1219.2 mm

construction materials, chemicals, petroleum

x 1524 mm (40 in x 48 in x 60 in) pallet in less

containers, metals cabinets, and shelving

than two minutes

• Safe - operates with a safety latch trigger

• UL listed

to prevent unintentional firing and shuts off

• Fast shrinkwrapping - the shrink gun is

automatically when put down

faster and holds more securely than either

• Product support - repair parts are available

stretch-wrapping or banding

through the Caterpillar Parts Distribution

system

Heat

Operating

Part No.

Description

Propane Usage

Air Consumption

Capacity

Pressure

4C-4515

Shrinkfast Shrink Gun

2.6 kg/hr (5.71lb/hr)

22.00 psi

21 CFM

Repair Parts (Warranty: Six Months)

4C-4512

ValveAssembly

4C-4513

Hose Adapter

4C-4514

Spark Plug

4C-4516

Regulator Assembly

4C-4517

Gauge (Pressure)

4C-4518

U.L. Guard

Paper, Poly Coat

Warranty: Caterpillar ^®Six Months

• Used for protecting metal parts and tools,

• Heavy duty protection from water, grease,

metal sheeting interleaving, protecting goods

and oil

on pallets from moisture and debris

• Fits standard dispenser - 3-inch core with

• Fifty pound virgin kraft paper with 10 pound

plugs that reduce it to 1 inch

polycoating

Part No.

Description

Size

263-0891

Poly Coat Paper

914.4mmx274.3m (36inx900 feet) roll

Paper, Masking

Warranty: Caterpillar ^®Six Months

• Specially formulated, high density masking

• Its unique, virtually "pinhole-free" construction

paper that helps reduce labor cost, decreases

delivers exceptional paint and solvent

rework, and minimizes cleanup

resistance to help eliminate bleed-through

• The paper's balanced construction offers

• For protection, each roll is individually

conformability, strength, and easy handling

wrapped

Part No.

Size

Rolls/ Case

1U-9732

304.8 mm x 304.8 m (12 in x 1000 ft)

1U-9733

609.6 mm x 304.8 m (24 in x 1000 ft)

1U-9734

914.4 mm x 304.8 m (36 in x 1000 ft)

JULY 2018 Shop Supplies

18-173

Shop Supplies

PACKING SUPPLIES

Cable Ties and Applicators

Warranty: Caterpillar ^®Six Months

• Used to secure wires, cables, tubes, etc.

Item

Installer Part No.

For Part No. (below)

1U-5228

1S-9593, 8L-8413, 3S-2093, 6K-0806

1U-5227

7K-1181

Bundle Diameter

Item

Part No.

Strap Width

Package Quantity

Installer

Range

1.5mmto 15.7mm

1S-9593

2.5mm (0.10in)

100

1U-5228

(.06in to .62 in)

1.5mmto 28.4mm

8L-8413

3.8mm (0.15in)

200

1U-5228

(.06in to 1.12in)

1.5mmto 44.5mm (.06

3S-2093

4.9mm (0.19in)

500

1U-5228

in to 1.75in)

1.5 mm to 101.6 mm

6K-0806

4.9mm (0.19in)

250

1U-5228

(.06in to 4.00in)

1.5mmto 203 mm (.06

034-1432

in to 8.00in)

4.8 mm to 101.6 mm

7K-1181

7.9mm (0.31in)

100

1U-5227

(.19in to 4.00in)

44.5 mm to 120.6 mm

5P-5148

12.7mm (0.50in)

100

(1.75 in to 4.75 in)

44.5mmto305mm

6V-7555

12.7mm (0.50in)

(1.75 in to 12.00 in)

Not

12.7 mm to 79.4 mm

240-1678

4.8mm (0.19in)

1000

shown

(0.5 in to 3.125 in)

Strapping, High Performance Steel

Warranty: Caterpillar ^®Six Months

• Great for stabilizing heavy loads during

• Break strength: 972.2 kg (2150 lbs)

transportation

Part No.

Size

Thickness

270-5343

19 mmx624.8 m ( 3/4in x 2050 ft)

0.5mm (0.02in)

Strapping Seals

Warranty: Caterpillar ^®Six Months

• Easy to use strapping buckles

• Used with 270-5345 Nylon Cord Strapping,

12.7 mm (1/2 in) wide

• Holds tension strong for nylon poly strapping

Part No.

Size

Qty.

270-5344

12.7 mm (1/2 in)

1000buckles per carton

18-174 JULY 2018 Shop Supplies

Shop Supplies

PACKING SUPPLIES

Tie Strap Tightener, Electric

Warranty: Manufacturer's

• Tightens cable ties and cuts off excess when

Has a comfortable grip and handle for all hand

preset tension is attained

sizes

• Used with straps, harnesses, and hoses

• Tightens up to 12.7 mm (1/2 in) wide straps

• Weight: 454 g (16 oz)

Part No.

Description

4C-5877

Electric Tie Strap Tightener

Tie Down Straps

Warranty: Manufacturer’s

• Elastic rubber tie down straps with a hook at

• Excellent for general tie down applications

each end

such as tarps and covers

Part No.

Size

262-9304

8 x 12.6 x 381 mm (.31 x .50 x 15 in)

262-9305

10 x 13 x 533 mm (.39 x .50 x 21 in)

• Material: SBR Rubber

Wire, Black

Warranty: Manufacturer’s

• Black annealed mechanics tie wire

• Soft and pliable-makes a perfect tie every

time

Part No.

Size

Material

Qty.

Length

262-9959

18 gauge

Black iron

1 Roll

177 m (580.71 ft)

Strapping, High Performance Nylon Cord

Warranty: Caterpillar ^®Six Months

• Economical alternative to steel strapping

• Used with 270-5344 Strapping Seals, 12.7 mm

(1/2 in)

• Easy to use on a wide range of products

• Breaking strength: 272.1 kg (600 lbs)

Part No.

Size

Color

Qty.

270-5345

12.7 mm x 1188.7 m (1/2 in x 3900 ft)

White

4 rolls per box

JULY 2018 Shop Supplies

18-175

Shop Supplies

PACKING SUPPLIES

Tie Strap Tightener, Electric

Warranty: Manufacturer's

• Tightens cable ties and cuts off excess when

• Has a comfortable grip and handle for all hand

preset tension is attained

sizes

• Used with straps, harnesses, and hoses

• Tightens up to 12.7 mm (1/2 in) wide straps

• Weight: 454 g (16 oz)

Part No.

Description

4C-5877

Electric Tie Strap Tightener

Python Cinch Straps

Warranty: Caterpillar ^®Six Months

• Nylon with heavy duty nickel plated steel

• Easy installation and removal

buckle

• UV and Weather Resistant

• Allows hose expansion and contraction

• Varied lengths from 21 to 29 inches long

without damage

Part No.

Width

Length

391-2683

3.81mm (1.5in)

533 mm (21in)

391-2684

3.81mm (1.5in)

635 mm (25in)

391-2685

3.81mm (1.5in)

737 mm (29in)

Label Maker Kit

Warranty: Caterpillar ^®Six Months

• Create metal labels that stand up to harsh

• Tape advance and rewind control

weather, temperature and corrosion

• Wheel characters-selection window helps

• For tagging hoses, castings, engine

reduce embossing errors

components, pipes, etc.

• Also embosses 12.6 mm (1/2 in) vinyl tape

• Heavy-duty cast aluminum body construction

• 306-9601 tags will fit hose up to 3.25 inches

• Built-in hole punch

in diameter

• Front scissors cut-off-cuts tape exactly

where required

Part No.

Description

Size

Qty.

9U-7918

Label Maker Kit

9U-7918LabelMakerKit

Aluminum Tape Roll,

12.7 mm (1/2 in) x 4.88 m (16 ft) x 0.1524 mm

9U-7920

10 per box

no adhesive

(0.006 in thick)

Optional

12.7 mm (1/2 in) x 279.4 mm (11 in) x .305 mm

306-9601

Aluminum Hose Tag

500 per box

(.012 in) thick

Aluminum Tape Roll,

12.7 mm (1/2 in) x 4.88 m (16 ft) x 0.1524 mm

9U-7920

10 per box

no adhesive

(0.006 in thick)

Aluminum Tape Roll,

12.6 mm (1/2 in) x 3.66 m (12 ft) x 0.33 mm (0.13

9U-7921

10 per box

with adhesive

in thick)

Stainless Steel Tape

12.7 mm (1/2 in) x 6.41 m (21 ft) x 0.127 mm (.005

9U-7922

10 per box

Roll, no adhesive

in thick)

18-176 JULY 2018 Shop Supplies

Shop Supplies

LOCKS

Padlock, Cat^®Branded Combination

Warranty: Manufacturer,s, Two Years

• Cat^®part number engraved on side of padlock

Combination

Lock

Shackle

Horizontal Shackle

Vertical Shackle

Part No.

Width

Type

Mechanism

Diameter

Clearance

50.8 mm

7.9 mm

285-1145

Resettable

4-digit dialing

25.4 mm (1 in)

(2 in)

(5/16 in)

Padlock, Cat^®Branded Combination

Warranty: Manufacturer,s, Two Years

• Cat^®part number engraved on side of padlock

Combination

Lock

Shackle

Horizontal Shackle

Vertical Shackle

Part No.

Width

Type

Mechanism

Diameter

Clearance

47.6 mm (1

7.1 mm

285-1146

fixed

3-digit dialing

20.6 mm (13/16 in)

19.0 mm (3/4 in)

7/8 in)

(9/32 in)

Padlock, Cat^®Branded High Security Brass

Warranty: Manufacturer,s, Two Years

• Lock body and shackle black with Cat^®logo

on both sides of bumper, Cat part number on

Number of

Shackle

Horizontal Shackle

Part No.

Width

Vertical Shackle Clearance

Pin Tumblers

Diameter

Clearance

44.4 mm (1

7.1 mm

285-1147

20.6 mm (13/16 in)

22.3 mm (7/8 in)

3/4 in)

(9/32 in)

side of bum

per

Padlock, Cat^®Branded High Security Brass

Warranty: Manufacturer,s, Two Years

• Lock body and shackle black with Cat^®logo

on both sides of bumper, Cat part number on

side of bumper

Package

Number of

Shackle

Horizontal Shackle

Vertical Shackle

Part No.

Width

Quantity

Pin Tumblers

Diameter

Clearance

44.4 mm

7.1 mm

285-1148

20.6 mm (13/16 in)

22.3 mm (7/8 in)

(1 3/4in)

(9/32 in)

JULY 2018 Shop Supplies

18-177

Shop Supplies

LOCKS

Padlock, Cat^®Branded High Security Brass

Warranty: Manufacturer,s, Two Years

• Lock body and shackle black with Cat^®logo

on both sides of bumper, Cat part number on

Number of

Shackle

Horizontal Shackle

Part No.

Width

Vertical Shackle Clearance

Pin Tumblers

Diameter

Clearance

44.4 mm (1

7.1 mm

285-1149

20.6 mm (13/16 in)

63.5mm (2 1/2in)

3/4 in)

(9/32 in)

side of bum

per

Padlock, Cat^®Branded High Security Brass

Warranty: Manufacturer,s, Two Years

• Lock body and shackle black with Cat^®logo

on both sides of bumper, Cat part number on

side of bumper

Package

Number of

Shackle

Horizontal Shackle

Vertical Shackle

Part No.

Width

Quantity

Pin Tumblers

Diameter

Clearance

44.4 mm (1

7.1 mm

285-1150

20.6 mm (13/16 in)

63.5mm (2 1/2in)

3/4 in)

(9/32 in)

Ladders, Step and Shelf

Warranty: Caterpillar ^®Six Months

Step Ladder

Shelf Ladder

• Fiberglass nonconductive industrial step

• Aluminum industrial shelf ladder for everyday

ladder designed for everyday use

industrial use

• Extra heavy-duty, 136 kg (300 lb) weight rating

• Thick non-marring rubber tread provides a slip

• Steps are level when ladder is set at 72

resistant footing

degrees

• Wide back braces provide maximum stiffness

• Equipped with thick rubber bumpers extending

and discourages unsafe climbing

152 mm (6.0 in) from top of ladder down side

• Full channel fiberglass rails are covered with

rails

a polyester veil for years of service

• Two pair of heavy duty steel gussets support

• Double-rivet step construction with tubular

bottom step

steel rivets for maximum strength

• Angled feet with thick rubber tread on both

• Nonconductivestructural molded top with

legs provide sure footing

tool slots is extremely durable (slots help keep

• Each step is secured with solid aluminum

tools close at hand)

rivets for maximum strength

• Spreader braces are located inside rails to

help protect them from getting hooked or

damaged in transit

• Reinforced bottom back brace provides

additional strength to bottom of ladder

Step

Part No.

Description

Height

Bottom Width

Approx. Spread

Approx. Weight

Size

2.4 m

7.6 cm

38.1 cm (15

263-1022

Shelf Ladder

7.7 kg (16.98lb)

(7.87 ft)

(2.99 in)

1/64 in)

1.2 m

7.6 cm

45.7 cm (18

263-1030

Step Ladder

71 cm (27.95 in)

5.9 kg (13.01lb)

(3.94 ft)

(2.99 in)

1/64 in)

18-178 JULY 2018 Shop Supplies

Shop Supplies

CLEANING EQUIPMENT AND SUPPLIES

Brooms

Warranty: Caterpillar ^®Six Months

Push Broom

Handle

• 100% Select black tampico

• Selected hardwood with clear lacquered

• Clear lacquered half-round hardwood block

finish

• Recommended for dry sweeping semi smooth

• One end rounded and other end equipped with

floors

crimped on metal thread to fit standard floor

• Handle not included

brush blocks

Whisk Broom

• Made of selected fine broom corn

• Sewn twice for strength

• Plated ring cap

Part No.

Description

Size

Qty.

263-0794

Push Broom

609 mm (24 in) wide

263-0796

Broom Handle

23.8 x 1524 mm ( 15/16 x 60 in)

Janitorial Equipment

Warranty: Caterpillar ^®Six Months

Janitorial Bucket

MopHeads

• Side pressure wringer

• Lay-flat style

• Screw-type mount

• 7.6 cm (3 in) casters

Use with 264-4364 Mop Handle

•

• Color: yellow

Mop Handle

• Size: (L x W x H) 33 x 33 x 68.6 cm (13 x 13 x

• Lay-flat style

27 in)

• Screw-type mount

• Metal cap

Part No.

Description

Material

Size

Qty.

264-4361

Rayon Mop Head

4-ply rayon

0.9 kg (32 oz)

264-4363

Cotton Mop Head

4-ply cotton

0.68 kg (24 oz)

264-4364

Mop Handle

Hardwood

152.4 cm (60in) long

Trash Can or Waste Receptacle Liners

Warranty: Caterpillar ^®Six Months

• Plastic, super durable trash can liners with

• Bottom designed for added strength and

superior stretch and tear resistance

greater leak resistance

Quantity/

Part No.

Strength

Capacity

Liner Size

Roll

263-0885

Medium (10-12 micron)

57 L (15 gal)

60.96 cm x 81.28 cm (24in x 32in)

500

263-0886

Heavy (12-14 micron)

125 L (33 gal)

83.82 cm x 99.06 cm (33in x 39in)

250

Extra-Heavy (15-17

263-0887

208 L (55 gal)

91.44 cmx144.78cm(36inx57in)

200

micron)

Garbage Bags, Heavy Duty

Warranty: Caterpillar ^®Six Months

• Madefrom the highest quality raw materials

• Exceptional strength

• Mineral reinforced to enhance physical

• Performance bottom seal resists leakage

properties

• Individually-folded in space-saving packaging

Part No.

Size

Capacity

Color

Qty.

1092 x 1193.8 cm (43 x 47in) 212 L

100 bags/

270-5346

22.7 kg (50.04lb)

HMW-HDPE Gray

(56 gallon)

case

18-180 JULY 2018 Shop Supplies

Shop Supplies

CLEANING EQUIPMENT AND SUPPLIES

Cups, Paper

Warranty: Caterpillar ^®Six Months

• Two-piece construction with tightly rolled rim

• Fully wax coated inside and out with a satin

finish

Part No.

Description

Capacity

Qty.

263-0884

Paper Cups

238.8 ml (8 oz)

2000per case

Eye Loupe

Warranty: Caterpillar ^®Six Months

• 25.4 mm (1 in) depth

• Extremely portable

• 12X power

Part No.

Description

8S-2257

Loupe

Creeper

Warranty: Caterpillar ^®Six Months

• Rugged, one-piece, plastic body construction

• Low profile, gives maximum workspace but

still clears air hoses

• Easy-to-clean surface is resistant to solvents,

greases, and fuels

• Six pop-in urethane wheels resist corrosion

and provide a smooth rid

• Body-fitting design, contoured to provide

optimum comforte

Part No.

Description

Dimensions

Wheel Size

Clearance

965 x 445 x 102 mm

172-0852

Creeper

51 mm (2 in)

22.2mm (0.87in)

(38.0 x 17.5 x 4.0 in)

172-0853

Replacement wheel

51 mm (2 in)

JULY 2018 Shop Supplies

18-181

Shop Supplies

PAINT AND CHEMICALS

Paint, Canada

Contact Information:

• Meets requirements for 2.8 VOC

Global Dealer Solutions Network

Part No.

Description

Size

Parts Technical Support Team

12-Ounce (355 ml) Aerosols (sold by case of twelve)

Toll Free - North America: 1-877-228-2420

479-5400

Standard PerformanceTopcoat -Caterpillar yellow

12 oz (355 ml) Aerosol

International: +1-309-266-4421

479-5395

Standard Performance Primer - Yellow

12 oz (355 ml) Aerosol

479-5399

Standard Performance Topcoat - High Gloss Black

12 oz (355 ml) Aerosol

Email: Tech_Support@Cat.com

479-5398

Standard Performance Topcoat - Medium Gloss Black

12 oz (355 ml) Aerosol

479-5397

Standard Performance Topcoat - Low Gloss Black

12 oz (355 ml) Aerosol

479-5396

Hi-Temp Topcoat - Black

12 oz (355 ml) Aerosol

479-5402

Standard Performance Topcoat - Matterhorn White

12 oz (355 ml) Aerosol

479-5403

Standard Performance Topcoat - Power Module White

12 oz (355 ml) Aerosol

479-5401

Standard Performance Topcoat - Mohave Brown

12 oz (355 ml) Aerosol

479-5404

Standard PerformanceTopcoat -Safety Red

12 oz (355 ml) Aerosol

One-Gallon (3.79 L) Cans (sold by case of four)

458-9626

Standard PerformanceTopcoat -Caterpillar yellow

1GalCan(3.79L)

458-9631

Standard Performance Primer - Yellow

1GalCan(3.79L)

458-9625

Standard Performance Topcoat - High Gloss Black

1GalCan(3.79L)

458-9623

Standard Performance Topcoat - Medium Gloss Black

1GalCan(3.79L)

458-9622

Standard Performance Topcoat - Low Gloss Black

1GalCan(3.79L)

458-9630

Standard Performance Topcoat - Matterhorn White

1GalCan(3.79L)

458-9629

Standard Performance Topcoat - Power Module White

1GalCan(3.79L)

Five-Gallon Pails (19L)

458-9627

Standard PerformanceTopcoat -Caterpillar yellow

5 Gal Pail (19L)

458-9632

Standard Performance Primer - Yellow

5 Gal Pail (19L)

458-9624

Standard Performance Topcoat - Medium Gloss Black

5 Gal Pail (19L)

55-Gallon Drums (208 L)

458-9628

Standard PerformanceTopcoat -Caterpillar yellow

55 Gal Drum (208 L)

Paint, Countries in EUR, AMEC and APD Regions

Contact Information:

Part No.

Description

Size

12-Ounce (355 ml) Aerosols (sold by case of twelve)

Global Dealer Solutions Network

479-5400

Standard PerformanceTopcoat -Caterpillar yellow

12 oz (355 ml) Aerosol

Parts Technical Support Team

479-5395

Standard Performance Primer - Yellow

12 oz (355 ml) Aerosol

Toll Free - North America: 1-877-228-2420

479-5399

Standard Performance Topcoat - High Gloss Black

12 oz (355 ml) Aerosol

International: +1-309-266-4421

479-5398

Standard Performance Topcoat - Medium Gloss Black

12 oz (355 ml) Aerosol

Email: Tech_Support@Cat.com

479-5397

Standard Performance Topcoat - Low Gloss Black

12 oz (355 ml) Aerosol

479-5396

Hi-Temp Topcoat - Black

12 oz (355 ml) Aerosol

479-5402

Standard Performance Topcoat - Matterhorn White

12 oz (355 ml) Aerosol

479-5403

Standard Performance Topcoat - Power Module White

12 oz (355 ml) Aerosol

479-5404

Standard PerformanceTopcoat -Safety Red

12 oz (355 ml) Aerosol

One-Gallon (3.79 L) Cans (sold by case of four)

479-5392

Standard PerformanceTopcoat -Caterpillar yellow

1GalCan(3.79L)

479-5394

Standard Performance Primer - Yellow

1GalCan(3.79L)

479-5388

Standard Performance Topcoat - High Gloss Black

1GalCan(3.79L)

479-5389

Standard Performance Topcoat - Medium Gloss Black

1GalCan(3.79L)

479-5391

Standard Performance Topcoat - Matterhorn White

1GalCan(3.79L)

Five-Gallon Pails (19L)

479-5393

StandardPerformanceTopcoat-Caterpillar yellow

5 Gal Pail (19L)

JULY 2018 Shop Supplies

18-183

Shop Supplies

PAINT AND CHEMICALS

Paint, America's South and United States (except CA, CT, DE, MD and Box Elder, Cache, Davis,

Salt Lake, Tooele, Utah and Weber Counties, UT)

Contact Information:

Part No.

Description

Size

12-Ounce (355 ml) Aerosols (sold by case of twelve)

Global Dealer Solutions Network

458-9587

Standard PerformanceTopcoat -Caterpillar yellow

12 oz (355 ml) Aerosol

Parts Technical Support Team

458-9582

Standard Performance Primer - Yellow

12 oz (355 ml) Aerosol

Toll Free - North America: 1-877-228-2420

458-9586

Standard Performance Topcoat - High Gloss Black

12 oz (355 ml) Aerosol

International: +1-309-266-4421

458-9585

Standard Performance Topcoat - Medium Gloss Black

12 oz (355 ml) Aerosol

Email: Tech_Support@Cat.com

458-9584

Standard Performance Topcoat - Low Gloss Black

12 oz (355 ml) Aerosol

458-9583

Hi-Temp Topcoat - Black

12 oz (355 ml) Aerosol

458-9589

Standard Performance Topcoat - Matterhorn White

12 oz (355 ml) Aerosol

458-9590

Standard Performance Topcoat - Power Module White

12 oz (355 ml) Aerosol

458-9588

Standard Performance Topcoat - Mohave Brown

12 oz (355 ml) Aerosol

458-9621

Standard PerformanceTopcoat -Safety Red

12 oz (355 ml) Aerosol

One-Gallon (3.79 L) Cans (sold by case of four)

458-9576

Standard PerformanceTopcoat -Caterpillar yellow

1GalCan(3.79L)

458-9579

Standard Performance Primer - Yellow

1GalCan(3.79L)

458-9571

Standard Performance Topcoat - High Gloss Black

1GalCan(3.79L)

458-9572

Standard Performance Topcoat - Medium Gloss Black

1GalCan(3.79L)

458-9570

Standard Performance Topcoat - Low Gloss Black

1GalCan(3.79L)

458-9574

Standard Performance Topcoat - Matterhorn White

1GalCan(3.79L)

458-9581

Standard Performance Topcoat - Dawn Gray

1GalCan(3.79L)

458-9575

Standard Performance Topcoat - Mojave Brown

1GalCan(3.79L)

Five-Gallon Pails (19L)

458-9577

Standard PerformanceTopcoat -Caterpillar yellow

5 Gal Pail (19L)

458-9580

Standard Performance Primer - Yellow

5 Gal Pail (19L)

458-9573

Standard Performance Topcoat - Medium Gloss Black

5 Gal Pail (19L)

55-Gallon Drums (208 L)

458-9578

Standard PerformanceTopcoat -Caterpillar yellow

55 Gal Drum (208 L)

Paint - California, Connecticut, Delaware, Maryland and Box Elder, Cache, Davis, Salt lake, Tooele,

Utah and Weber Counties, Utah

Contact Information:

• Meets requirements for 2.8 VOC

Global Dealer Solutions Network

Part No.

Description

Size

12-Ounce (355 ml) Aerosols (sold in cases of twelve)

Parts Technical Support Team

458-9587

Standard PerformanceTopcoat -Caterpillar yellow

12 oz (355 ml) Aerosol

Toll Free - North America: 1-877-228-2420

458-9582

Standard Performance Primer - Yellow

12 oz (355 ml) Aerosol

International: +1-309-266-4421

458-9586

Standard Performance Topcoat - High Gloss Black

12 oz (355 ml) Aerosol

Email: Tech_Support@Cat.com

458-9585

Standard Performance Topcoat - Medium Gloss Black

12 oz (355 ml) Aerosol

458-9584

Standard Performance Topcoat - Low Gloss Black

12 oz (355 ml) Aerosol

458-9583

Hi-Temp Topcoat - Black

12 oz (355 ml) Aerosol

458-9589

Standard Performance Topcoat - Matterhorn White

12 oz (355 ml) Aerosol

458-9590

Standard Performance Topcoat - Power Module White

12 oz (355 ml) Aerosol

458-9588

Standard Performance Topcoat - Mohave Brown

12 oz (355 ml) Aerosol

458-9621

Standard PerformanceTopcoat -Safety Red

12 oz (355 ml) Aerosol

One-Gallon (3.79 L) Cans (Sold by case of four)

458-9626

Standard PerformanceTopcoat -Caterpillar yellow

1GalCan(3.79L)

458-9631

Standard Performance Primer - Yellow

1GalCan(3.79L)

458-9625

Standard Performance Topcoat - High Gloss Black

1GalCan(3.79L)

458-9623

Standard Performance Topcoat - Medium Gloss Black

1GalCan(3.79L)

458-9622

Standard Performance Topcoat - Low Gloss Black

1GalCan(3.79L)

458-9630

Standard Performance Topcoat - Matterhorn White

1GalCan(3.79L)

458-9629

Standard Performance Topcoat - Power Module White

1GalCan(3.79L)

Five-Gallon Pails (19L)

458-9627

Standard PerformanceTopcoat -Caterpillar yellow

5 Gal Pail (19L)

458-9632

Standard Performance Primer - Yellow

5 Gal Pail (19L)

458-9624

Standard Performance Topcoat - Medium Gloss Black

5 Gal Pail (19L)

55-Gallon Drums (208 L)

458-9628

Standard PerformanceTopcoat -Caterpillar yellow

55 Gal Drum (208 L)

18-184 JULY 2018 Shop Supplies

Shop Supplies

PAINT AND CHEMICALS

Dyes for Leak Detection, UV Visible

Warranty: Manufacturer's

• Detects leaks in light or dark oils, fuels, water

solutions

Part No.

Description

Size

Dosage

To detect oil leaks in engines, transmission, hydraulic systems, etc.

1U-5572

Oil Glo 22 Additive

28.4 g (1 oz) bottle

28.4 g (1 oz) per 7.58 L (2 gal) of oil

1U-5573

Oil Glo 22 Additive

0.47 L (1 pt) bottle

28.4 g (1 oz) per 7.58 L (2 gal) of oil

To detect fuel leaks or suspected fuel dilution

28.4 g (1 oz) per 37.9 L (10 gal) of gasoline or

1U-5574

Gas Glo 32 Additive

28.4 g (1 oz) bottle

diesel fuel

28.4 g (1 oz) per 37.9 L (10 gal) of gasoline or

1U-5575

Gas Glo 32 Additive

0.47 L (1 pt) bottle

diesel fuel

To detect cooling system leaks, use:

1U-5576

Water Glo 23Additive

28.4 g (1 oz) bottle

28.4 g (1 oz) per 151.6 L (40 gal) of water

1U-5577

Water Glo 23Additive

0.47 L (1 pt) bottle

28.4 g (1 oz) per 151.6 L (40 gal) of water

Ether Cylinder

Warranty: Manufacturer's

• Cold weather starting aid

• Easy to install, hand tighten

• Heavy-duty construction

• 7.6 cm (3 in) diameter

• Quick starts from -45.5°C (-50°F)

• For measured shot systems

Part No.

Qty.

Size

7X-1062

21 oz (595 g)

7N-0296

18 oz (510 g)

130-8414

8 oz (226 g)

Sprayers, Reusable, Bulk-Liquid

Warranty: Caterpillar ^®Six Months

• Used to apply oil and water-based bulk

• Canisters pressurized with compressed air

chemicals, such as cleaners, degreasers,

from any standard air compressor

penetrating oils, solvents, or lubricants

• Both sprayers constructed with metal

• Compressed air sprayers provide a cost

canisters (steel or brass), brass nozzles, and

effective, reusable alternative to traditional

corrosion resistant internal parts

spray cans (eliminates both storage and

• Steel canister sprayers are used for oil and

disposal concerns)

solvent-based materials while brass canisters

• Cat compressed air sprayers use a special

can also be used for water-based materials

chemical-resistant internal seal which

• Cannot be used for paint application

virtually eliminates seal replacement

• Capacity: 0.9 I (32 oz)

problems found in standard sprayers

• Eliminate using flammable and/or

environmentally dangerous propellants

Part No.

Description

231-7015

Steel Canister Sprayer

Service Parts

231-7016

Adjustable Tube

231-7017

Seal

231-7018

Nozzle

JULY 2018 Shop Supplies

18-185

Shop Supplies

PAINT AND CHEMICALS

Ultrasonic Couplant, Cat^®

Warranty: Caterpillar ^®Six Months

• Required for use with Cat Ultrasonic Wear

• High viscosity, no-drip formula

Indicator III tool, Ultrasonic Wear Indicator IV

• Operating ranges 10 to 220 degrees F (-12 to

and the Intrinsically Safe Ultrasonic Thickness

104 degrees celcius)

Gauges

• 94 ml (3.2 fl-oz)

Part Number

Description

505-8671

Cat^®Ultrasonic Couplant

Service/Repair Parts

Nicad Battery, rechargeable, package qty 1

1U-7445

(5 required to power Indicator III)

AA Alkaline Battery, non-rechargeable, package qty 96

1U-9533

(5 required to power Indicator III)

4C-5490

Couplant Holder

Optional Items (Sold Separately)

Cable Assembly RS232 - to transfer thickness values

4C-5488

to the CTS program in a PC AT version

Cable Assembly RS232 - to transfer thickness values

4C-5489

to the CTS program in a PC XT version

4C-5897

Modem Cable

9U-6175

Soft Protective Case

Ultrasonic Couplant, VersaSonic High-Temperature, High-Viscosity

Warranty: Manufacturer’s 5-Year Shelf Life and

• An ultrasonic couplant for harsh conditions

• Superior, long-term corrosion inhibition

Performance. Contact 360-671-9121

including rain, snow, mud and all temps

• Compatible with plastics

or sales@echoultrasonics.com.

• 4 oz, biodegradable

• For use with Cat^®Ultrasonic Wear Indicator

• Operating Range: -10 to 750°F /-23 to 398°C

IV and Intrinsically Safe Ultrasonic Thickness

Gauges

Part No.

Description

Weight

VersaSonic High-Temperature, High-Viscosity Ultrasonic

545-8721

0.23 kg (0.5 lb)

Couplant

Nozzle Cleaner

Model Usage: C7, C9, C13 and C15 Engines

• For USA and Canada dealers only

• Increases safety and reduces assembly time

Warranty: Caterpillar ^®Six Months

• Required for cleaning the ARD Nozzle on

• Sold by case only (case contains 12 units)

Cat^®engines equipped with purge air nozzles.

Part No.

Description

Dimensions

Weight

535-8931

Nozzle Cleaner

Package is 2.5 x 4.125 x 2 in

0.058 kg (0.128lb)

18-186 JULY 2018 Shop Supplies

Shop Supplies

PAINT AND CHEMICALS

Kynetx A/C Flushing Solvent

Warranty: Manufacturer’s Six Months

• Kynetx A/C Flushing Solvent is a refrigerant

• Compatible with CFC, HCFC and HFC

Contact #ChemtoolCustomerAssistance@

flushing solution used to flush out old A/C

refrigerants

Chemtool.com or 815-389-0150

refrigerants and contaminants when changing

• Compatible with mineral, ester, and PAG oil

and charging new refrigerant.

lubricants

• Flushes lubricant contaminants and solids

• Available for dealers in America’s North and

from A/C system lines

America’s South regions, except Brazil

Part No.

Description

Dimensions

Weight

190 x 132 x 61 mm

3.8 L (1 gallon)

486-1523

Kynetx A/C Flushing Solvent

(7.5 x 5.2 x 2.4 in)

3.3 kg (7.25 lb)

Kynetx HD Cabinet and Spray Cleaner

Warranty: Manufacturer’s Six Months

• Replaces 174-6854 and 174-6855

• Imperceptible thin film corrosion preventative

Contact #ChemtoolCustomerAssistance@

offers superior rust protection and weldable

• Kynetx HD Cabinet and Spray Cleaner is a

Chemtool.com or 815-389-0150

surface.

concentrated liquid alkaline cleaner used

primarily in industrial applications for in-

• Exceptional hard water stability keeps

process cleaning of ferrous metals.

washers clean.

• Highly effective for rust removal, paint

• Ideal for removal of stearates and rust

stripping and zinc phosphate removal

• Lean concentrations assure low consumption

• Residual films of HD Cabinet and Spray

and cost effectiveness.

Cleaner can provide corrosion protection for

• Contains no phosphates, nitrites or silicones

parts in storage and during shipping.

• Available for dealers in America’s North and

• Extremely low foaming characteristics ideal

America’s South regions, except Brazil

for high-pressure spray and pressure washers

Part No.

Description

Dimensions

Weight

55 Gallon Drum

486-1524

Kynetx HD Cabinet and Spray Cleaner

89 x 58 cm (35 x 23 in)

200 kg (440lb)

Kynetx A/C PAG Oil ISO 100

Warranty: Manufacturer’s Six Months

• Replaces 4C-2959

• Prevents lubrication breakdown

Contact #ChemtoolCustomerAssistance@

• Low viscosity refrigerant oil for R-134a

• Provides hydrodynamic, elasto-hydrodynamic,

Chemtool.com or 815-389-0150

boundaryandextremepressurelubrication

• Provides superior protection against

compressor wear

• Available for dealers in America’s North and

America’s South regions, except Brazil

Part No.

Description

Dimensions

Weight

8 fl oz (240 mL) Can

486-1528

Kynetx A/C PAG Oil ISO 100

95 x 69 mm (3.75 x 2.7)

0.67 kg (1.5 lb)

JULY 2018 Shop Supplies

18-187

Caterpillar. Dealer service tools catalog (2018) - page 27
