Shop Supplies
VISES
Jaw Caps
Warranty: Manufacturer's Lifetime
• Designed to avoid marring the surface of
• Polished faces and pliable copper extensions
softer metals and to protect jaw faces
for a sure-grip fit on any make vise
Part No.
Description
Width
• Ma4C-3747an
y sizJaw C
ap
6in
4C-3748
Jaw Cap
5in
4C-3749
Jaw Cap
4 1/2 in
4C-3750
Jaw Cap
4in
• Capable of holding small transmissions,
Holding Fixture
differentials, hydraulic pumps, water pumps
and electrical components
Warranty: Caterpillar ®Six Months
• Mounts on workbench
• Use to secure components during assembly
and disassembly
Part No.
Description
Capacity
2P-8338
Holding Fixture
250lb
Vise, Yoke Pipe
Warranty: Caterpillar ®Six Months
• Used to brace pipe for cutting and machining
• Used for pipe from 10 through 102 mm (1/8
through 3 1/2 in)
Part No.
Description
Weight
127-1909
Yoke Pipe Vise
7.4 kg (16.23lb)
Clamps, Regular Duty, Standard Throat C-Clamps
Warranty: Manufacturer's Lifetime
• Recommended for regular-duty work not
• Equipped with Wilton Permapads® and
requiring unusual throat depth
lifetime lubricated spindles of through
hardened steel
• Drop forged from specially selected steels
• Finished in grey enamel
• Light enough for production line use
Part No.
Capacity
Throat Depth
Spindle Diameter
Minimum Proof Test
Weight
4C-3755
0 - 2 in
1 13/16
9/16
2.00
1 3/8 lb
4C-3756
0 - 3 in
1 15/16
9/16
3.00
143/64lb
4C-3757
0 - 4 in
2 5/16
5/8
3.00
2 3/4 lb
4C-3758
0 - 6 in
2 15/16
5/8
4.00
3 3/4 lb
4C-3759
2 in - 8 in
3 7/16
3/4
5.00
7lb
4C-3760
1 1/2 in - 10in
3 3/4
3/4
6.00
8 3/8 lb
4C-3761
1 1/8 in - 12in
3 7/8
3/4
8.00
12 lb
18-86 JULY 2018 Shop Supplies
Shop Supplies
BATTERIES AND EQUIPMENT
Battery Tester, Cat®
Warranty: Manufacturer's One Year
• 1000 Amp Load Tester is ideal for battery
• High resolution carbon pile assembly ensures
distributors, high volume testing and fleet
maximum contact, reduces hot spots,
use.
prevents edge burning and provides smoother
operation and longer life.
• High rpm fan cools for continuous battery
testing
Part No.
Load
Ammeter
Voltmeter
Leads
Clamps
Weight
Shipping Dimensions
0 - 19.99 V DC
5 ft -
Vinyl insulated steel with flexi-
34 lb
16 in x 15 in x 15 in
4C-4911
1000A
0 - 1999 Amps (Digital)
(Digital)
2 AWG
spring and copperjaw
(15.4 kg)
(0.40 m x 0.38 m x 0.38m)
Bus Bar Set
Warranty: Manufacturer's One year on parts/
• Bus Bar Set for parallel charging
• Comeswith (3 ft) 4 AWG cables to connect to
labor, five years on transformer/rectifier
charger or additional batteries
• Ten Battery Capacity
• Can be mounted on wall or bench
• Use one or combine additional bars for
additional capacity
• Ensures convenient way to hook up to 10
batteries in parallel
• Insulated fiberglass backboard with 10 pairs
of DC Charging leads, 4 AWG (36 in) long with
300 Amp insulated safety clamps
Part No.
Capacity
Leads
Clamp
Material
Weight
Dimension
Connections
10 sets - 4 AWG,
Insulated Fiberglass
4C-4917
300 Amp Insulated Safety
11 kg (24 lb)
31.25 in x 15.25 in x 5.25 in
for 10 Batteries
(36in) long
Backboard
18-87 JULY 2018 Shop Supplies
JULY 2018 Shop Supplies
18-87
Shop Supplies
BATTERIES AND EQUIPMENT
Chargers, Multi-Battery Parallel
Warranty: Manufacturer's One Year
4C-4913
Additional accessories available:
• Charges 1 - 10, 12 Volt Batteries, in parallel,
• 4C-4917 Bus Bar ensures convenient way to
in less than 24 hours
hook up to 10 batteries in parallel.
• 16 charge rates offer precise charging
• Bus Bar includes 10 pairs of DC Charging
leads (48” long, 8.5 AWG with 300 Amp
• Alternate model 4C-4914 charges 1 - 36, 12
insulated clamps) and insulated fiberglass
Volt batteries in parallel
backboard
• Can be mounted on wall or bench
9U-5784 Charging Rack Battery charging rack
•
• UL Listed; RoHS Compliant
stores up to 15 Batteries on threeshelf acid
• Patented multi-diode rectifier with deep
resistant, insulated rack
reserve capacity
4C-9799
Additional accessories available:
• Charges 1 - 10, 12 Volt Batteries, in parallel,
• 4C-4917 Buss Bar ensures convenient way to
in less than 24 hours
hook up 10 batteries in parallel.
• Designed for 230 VAC 50/60Hz electrical
• Buss Bar includes 10 pairs of leads with
environments
insulated fiberglass backboard, with 300 Amp
• Includes a patented multi-diode rectifier with
insulated safety clamps.
a deep reserve capacity
• 9U-5784 Charging Rack that stores up to 15
• Circuit breaker protection and isolated
batteries
transformer provides added safety
4C-4914
• Can be mounted on a wall or bench
• Charges 1 - 36, 12 Volt Batteries, in parallel,
Additional accessories available:
in less than 24 hours
4C-4917 Bus Bar ensures convenient way to
•
• Designed for 190 - 262 Vac 50/60Hz electrical
hook up to 10 batteries in parallel.
environments
Bus Bar includes 10 pairs of DC Charging
•
• Includes a patented multi-diode rectifier with
leads (48” long, 8.5 AWG with 300 Amp
a deep reserve capacity
insulated clamps) and insulated fiberglass
• Circuit breaker protection and isolated
backboard
transformer provides added safety
• 9U-5784 Charging Rack Battery charging rack
• Can be mounted on a wall or bench
stores up to 15 Batteries on threeshelf acid
resistant, insulated rack
• UL Listed
Battery
Charge
Digital
Digital
Part No.
DC Output
AC Input
DC Leads
AC Cord
Weight
Shipping Dimensions
Capacity
Rates
Voltmeter
Ammeter
30Amps,
108-132/ VAC,
Up to 10, 12
0 - 50
1.8 m (6 ft)
16 in x 19 in x
4C-4913
16
11 - 17 Volts
6.5 ft 16-3
18 kg (40 lb)
14.9 Volts
7.5A 60 Hz
Volt Batteries
Amps
6.5AWG
16 in
No AC cord,
110 Amps,
190-262/ VAC,
Up to 36, 12
0 - 19.99
0 - 199
1.5 m (5 ft)
26 in x 17 in x
4C-4914
16
must be hard
38 kg (83 lb)
15.5 Volts
13.8A50/60 Hz
Volt Batteries
Volts (Digital)
Amps
1 AWG
14 in
wired
30Amps,
14.9 Volts
16A, 2m
210 - 250/ VAC,
Up to 10, 12
11 - 17 Volts
0 - 50
m (6.5 ft) 6
16.5 in x 19 in x
4C-9799
(Warranty:
16
length (No
18 kg (40 lb)
4A, 50/ 60 Hz
Volt Batteries
(Digital)
Amps
1/2 AWG
16.5 in
Caterpillar,
Plug)"
6 Months)
18-88 JULY 2018 Shop Supplies
Shop Supplies
BATTERIES AND EQUIPMENT
Battery Charging Rack
Warranty: Caterpillar ®Six Months
• Stores up to 15 batteries
• Three-shelf, acid resistant, insulated steel
rack
• Includes 10 pairs of charging leads
Part No.
Description
9U-5784
Battery Charging Rack
Chargers, Heavy-Duty Commercial Fast
Warranty: Manufacturer's One year on parts/
4C-4920
• Fan cooling prevents overheating enhancing
labor, five years on transformer/rectifier
unit’s life span significantly
• Highest performance fast chargers on the
market
• 500 Amp, fully insulated, “Flexi-Spring”
clamps
• 16 rates of charge and 75 amps
• UL and CSA listed with “Safe in Any
• 75 amps of continuous charge with 375 amps
Weather” operation
crank assist at 12 Volts
• Patented “Stop / Go” Light
• Fan cooling prevents overheating enhancing
unit’s life span significantly
• Automatic reset AC and DC circuit breakers
• UL and CSA listed with “Safe in Any
• Automatic timer
Weather” Operation
4C-4910
• Patented “Stop / Go” Light
Charges all standard & maintenance free
•
• Automatic reset AC and DC circuit breakers
6/12/24 V batteries
• Automatic timer
• High Output 220VAC Charger
4C-4921
• Cranking assist rating of 325 amps at 6 Volts
• The highest performance fleet charger on the
• Fan cooling mechanism prevents overheating
market
enhancing the unit’s life span significantly
• 33% more engine start than the previous
• Certified for outdoor use, safe in any weather
model
• Cautions against incorrect polarity with
• 80 amp continuous charge with 400 amp
patented “stop-go-light” technology
crank assist at 12 Volts
• CE Approved
Electrical
Battery
UL Continuous
UL Cranking
MFGS Boost
Clamp
Shipping
Part No.
Weight
AC Cord
DC Leads
Timer
Requirements
Voltage
Rating
Assist Rate
Rating
Rating
Dimensions
4C-4920 Specifications
120 VAC, 14.8A,
25 kg
3m(10 ft)
2.4 m (8 ft)
4C-4920
6/12 Volt
100/75 Amp
375 Amp
625 Amp
500 Amp
26 x 16 x 14in
-
50 Hz
(55 lb)
14 - 3
4 AWG
4C-4921 Specifications
120 VAC, 15A,
6/12/18/24
31 kg
3m(10 ft)
2.4 m (8 ft)
4C-4921
-
400 Amp
725 Amp
500 Amp
26 x 16 x 14in
-
60 Hz
Volt
(68 lb)
14 - 3
4 AWG
4C-4910 Specifications
4C-4910
2.4m (7.9
90
Warranty:
230 VAC;
6/12/24
34 kg
325/270/180
300/500/700
3 m (9.8 ft)
90/75/55 Amp
ft) 16A Euro
500 Amp
26 x 16 x 14in
minute
Caterpillar,
50/60 Hz
Volt
(75 lb)
Amp
Amp
4 AWG
plug
auto
Six Months
JULY 2018 Shop Supplies
18-89
Shop Supplies
BATTERIES AND EQUIPMENT
Charger, Portable
Warranty: One Year Limited
• Electrical Stability System (ESS™) technology
• batteriesPatented diagnostics indicate weak
turns 9425 into a stable power supply for
or defective battery
extended service procedures or re-flashes.
• Charges all types of 12 volt batteries.
Nominal 13.7V DC Output
• Designed for AGM, Gel Cell, Sealed, and
• Program for deep discharge recovery of
Standard Flooded batteries including Spiral
flooded batteries
Cell, Orbital, or Optima batteries
• Display: 3 LED display indicating charge
• MADE IN USA
status
NOTE: Cannot be sold in all regions. Sales are
• Battery Types: 12 Volt Flooded, AGM, and Gel
restricted in some countries. Limited availability.
Cell batteries - including Spiral Cell, Orbital,
or Optima
Part No.
Model
DC Output
DC Leads
ClampRating
Shipping Dimensions
Weight
AC Cord Voltage
DC Leads
510-5236
9425
20Amps
6.5' AWG
300 A
14”x12”x12”
21 lb
6’ 18-3 / 120VAC 60 Hz
7 ft 4/AWG
Heavy-Duty Portable Battery Charger
Warranty: Manufacturer’s Five Years
• Model 6010B Associated Heavy-Duty
• Patented multi-diode rectifiers, fan-cooled
6/12/24V Portable Battery Charger
• Patented “Stop/Go-light” technology with 500
• Powerful performance in a smaller package
amp insulated clamps. Made in USA.
• Charges all standard and maintenance-free
• Compliant for Bahamas, Belize, Canada,
6/12/24 v batteries with 4 charging positions
Colombia, Dominican Republic, Ecuador, El
Salvador, Guatemala, Haiti, Honduras, Liberia,
• Fully portable 60/60/30A charger with 230
Mexico, Nicaragua, Panama, Peru, Philippines,
amp crank assist
Puerto Rico, Surinam, Tahiti, Taiwan, Trinidad,
• Vacuum-impregnated heavy-duty transformer
USA, Venezuela and Virgin Islands
Part No.
Description
Dimensions
Weight
Associated Heavy-Duty 6/12/24V
356 x 407 x 330 mm
481-5978
18 kg (40 lb)
Portable Battery Charger
(14 x 16 x 13 in)
18-90 JULY 2018 Shop Supplies
Shop Supplies
BATTERIES AND EQUIPMENT
Battery Charging Station, Cat® Advanced
Model Usage: All Models
European Union Compliant, RoHs, CE
• Bite Rite Clampstm
Warranty: Manufacturer’s One Year
• Fully automatic 80 amp charger
• Uses standard 15-amp outlet
• All-Lead Acid Batteries
• Series or parallel charging options
• Charges 6v, 12v and 24v
• Field-replaceable leads in four minutes
• Temperature sensor runs before and during
• Language Capabilities: English, Spanish,
charge cycle
French, Portuguese, German, Italian
• Custom Cat® Input Menus as well as non-Cat
Specifications
battery compatible
• Dimensions: 508 x 508 x 508 mm
• Presets come loaded for all Cat battery part
(20 x 20 x 20 in)
numbers which automatically set up correct
• Weight: 16.8 kg (37 lb)
charge
• Optional setting for regular manual input
REPAIR
• Displays charging status and time remaining
Manufacturer guarantees these products to be free of
• Fully charges most batteries in < 30 minutes
workmanship and material defects prior to purchase for 12
months. For warranty and repair needs, contact Auto Meter
• Deep discharge recovery
at 866-248-6356
• USBports for easy upgrade and data log
download
Part No.
Description
Power
485-9464
Battery Charging Station
60 Hz, 110 VAC
485-9465
Battery Charging Station
50 Hz, 220 VAC
Replacement Parts
485-9466
CableSet, 8’ (includes clamps)
485-9467
CableSet, 20’ (includesclamps)
485-9472
USB Cable
485-9744
Temperature Sensor and Stand Kit
JULY 2018 Shop Supplies
18-91
Shop Supplies
BATTERIES AND EQUIPMENT
Starting System, Extra Heavy-Duty Plug-In
Warranty: Caterpillar ®Six Months
• More truck starting power than 8hp gas
• Polarity protection
starter
• 30 foot of tangle-free cables
• Extra heavy duty plug-in starting system ideal
• Stainless steel receptacle mounts onto a truck
for volume car starting in extremely cold
bumper and connects directly to a battery
climates
• Reaches stalled vehicles from front, back, or
• Heavier 1 AWG cable has half the voltage
side
drop as Model 4C-4929 (6139)
• Solid copper jaw, with patented insulated
• Anti-spark delay timer protection for safety
clamps with “flexi-spring” cable guard
during hook-up
• Patented “stop-go safety light”
• Circuit breaker protection
Cir. Mil.
Side
Total
Vehicle Connection
SAE
Shipping
Part No.
Description
Gauge
Copper,
Amp Clamp
Terminal
Weight
Length
Length
Rating
Dimensions
Jacket
Adapters
Super
Extra Heavy-Duty Plug-In
9 in x 12 in x
4C-4930
30ft
5 ft
1 AWG
83,600 T-94
800 A
No
Heavy-
26 lb
Starting System
12 in
Duty
Service Part
4C-9917
Power Socket with Battery Cable
Starting System, Heavy-Duty Plug-In
Warranty: Caterpillar ®Six Months
• Stainless Steel receptacle mounts onto a
• Solid copper jaw, with patented insulated
truck bumper and connects directly to a
clamps with “flexi-spring” cable guard
battery
• Patented “stop-go safety light”
• Reaches stalled vehicles from front, back or
• 30 ft of tangle-free cables
side
• For the flush mount version, combine with
• Polarized LEXAN plug won’t break in coldest
4C-4931 (6125)
weather
Cir. Mil.
Side
Total
Vehicle Connection
SAE
Shipping
Part No.
Description
Gauge
Copper,
Amp Clamp
Terminal
Weight
Length
Length
Rating
Dimensions
Jacket
Adapters
Heavy-Duty Plug-In
Heavy-
6 in x 12 in x
4C-4929
30ft
5 ft
4 AWG
41,300 T-94
500 A
Yes
17 lb
Starting System
Duty
12 in
Service Parts
Power Socket with
4C-4943
-
-
-
-
-
-
-
-
-
battery cable
Plug-in Cable (in-
4C-4944
-
-
-
-
-
-
-
-
-
cludes clamps)
Polarized Lexan®
4C-4946
-
-
-
-
-
-
-
-
-
Plug, .45 kg (1 lb)
18-92 JULY 2018 Shop Supplies
Shop Supplies
BATTERIES AND EQUIPMENT
Jump Start Plug Assembly
Warranty: Caterpillar ®Six Months
• Used with jump start receptacle on M Series
• 4.7 meter (15.5 feet long)
Motor Graders and other similar receptacles
• 8S-2632 has receptacle on one end and
• Used for receptacle-to-receptacle on machine-
battery terminals on the other
to-machine applications
9S-3664
Part No.
Description
8S-2632
9S-3664
Jump Start Plug Assembly
Power Socket, Flush Mount
Warranty: Caterpillar ®Six Months
• Alternative to cabinet style socket -
• For a complete starting system, order 4C-4931
stainless steel plate mounts flush on service
and 4C-4944 Plug-In Cables
Part No.
Description
vehicle
4C-4931
Flush Mount Power Socket
Cables, Booster
Warranty: Caterpillar ®Six Months
• Professional quality
• Designed for convenience and safety
• Ensure quick and efficient connections
• Replacement clamps available
Gauge
Side
Approx.
Clamp
Part No.
Length
Gauge
(circular
Jacket
Terminal
Ind.
Rating
mil)
Adapters
Weight
Heavy Duty and Super Heavy Duty Cables
4C-4934
(Equipped with stop/go
T-94 (T-94:
3.6 kg (7.94
light - red L.E.D.s warn
4 m (12 ft)
5 AWG
32,900
flexible to 4° C
500 A
Yes
lb)
operator if polarity is
(-40° F))
reversed)
T-94 (T-94:
7.3 kg
4C-4938
5 m (15 ft)
1/0 AWG
106,400
flexible to 4° C
800 A
No
(16.09 lb)
(-40° F))
Booster Cables
6.4 kg
300-5899
6 m (20 ft)
2 AWG
62,450
T-94
600A
No
(14.11 lb)
T-94 (T-94:
2.7 kg (5.95
4C-4933
4 m (12 ft)
4 AWG
37,360
flexible to 4° C
500E
No
lb)
(-40° F))
T-94 (T-94:
3.6 kg (7.94
4C-4935
5 m (16 ft)
4 AWG
37,360
flexible to 4° C
500E
No
lb)
(-40° F))
T-94 (T-94:
4.1 kg (9.04
4C-4936
6 m (20 ft)
4 AWG
37,360
flexible to 4° C
500E
No
lb)
(-40° F))
Clamps, Replacement
Warranty: Caterpillar ®Six Months
• Designed to grip securely to side terminal
• Color coded (Red/Black) for safety and visual
and/or post terminal batteries for maximum
appeal
current carrying capacity
Clamp
Part No.
Description
Jaws
Insulation
Weight/Master
Rating
Replacement clamp for use
4C-4940
500A
Copper
Bonded Vinyl
4 kg (8.82 lb)
with 3, 4, and 6 ga cable
Batteries and Battery
Heavy Gauge
4C-4942
600A
Bonded Vinyl
4.5 kg (9.92 lb)
Chargers
Copper
JULY 2018 Shop Supplies
18-93
Shop Supplies
BATTERIES AND EQUIPMENT
Battery Post Set
Warranty: Caterpillar ®Six Months
• Alternative to cabinet style socket -
• For a complete starting system, order 4C-4931
stainless steel plate mounts flush on service
and 4C-4944 Plug-In Cables
vehicle
4C-5637
Part No.
Description
4C-5637
10 mm (3/8 in) Female for Stud Type Batteries
4C-5638
10mm(3/8in)MaleforSideTerminal Batteries
4C-5638
Cables
Warranty: Caterpillar ®Six Months
• Polarized plug on both ends
• Mates with either 4C-9917 or 4C-4943 Power
Socket
Part No.
Description
Mateswith
4C-9801
3.66 m (12 ft) 4 AWG
4C-4943 Power Socket
4C-9802
3.66 m (12 ft) 1 AWG
4C-9917 Power Socket
Battery Cable Repair Kit
Warranty: Caterpillar ®Six Months
• Fabricate or repair 8 through 4/0 gauge
• Cable Cutter - can cut up to 500 MCM copper
electrical cables
or aluminum cable
• Install splices or terminals
Reference
• Crimping tool comes with multiple dies for
• Special Instruction SMHS7677, Use of Battery
various cable sizes (AWG No. 8, 6, 4, 2, 1/0,
Cable Repair Kit
2/0, 3/0, 4/0)
Part No.
Description
Qty.
6V-3025
Battery Cable Repair Kit
-
Battery Cable Repair Kit includes:
6V-3017
00 Butt Splice
4
6V-3018
0 Butt Splice
3
6V-3019
000 Butt Splice
3
6V-3020
0000 Butt Splice
2
6V-3021
Crimping Tool
-
6V-3022
Cable Cutter
-
6V-3023
Box
-
Replacement Dies for 6V-3021
1U-6659
Left-Hand
-
1U-6660
Right-Hand
-
18-94 JULY 2018 Shop Supplies
Shop Supplies
LIGHTING AND ELECTRICAL
Flashlight, Mini-Maglite
Warranty: Lifetime
• For people on-the-go, can be carried on the
• Includes two AA batteries
hip in its own nylon belt holster
Part No.
Description
Length
9U-7231
Mini-Maglite Flashlite
5 3/4 inches
4C-9463
Replacement Lamps
-
Flashlight, Cat® Heavy-Duty Professional
Warranty: Lifetime
• High quality
• Extra long lamp life, equivalent of 3 or 4 sets
of batteries
• Designed and manufactured in the U.S.A.
• Approximately 5 to 6 hours operating time per
• Precision machined, high strength aluminum
set of batteries
exterior components
• Ambient candle mode for hands free
• Anodized internally and externally for
operation
optimum corrosion resistance
• Spare lamp in tail cap
• Water resistant O-ring seals throughout
protecting an internal self-actuating switch
• All flashlights have Cat® logo
• Hi-impact, scratch resistant Lexan® lens
• Fast action Linear-Focusing™ flood-to-spot
beam with a twist of the wrist
Item
Part No.
Description
Length
Batteries
1
1U-7321
Flashlight
254 mm (10in)
2 D cell batteries
2
1U-7322
Flashlight
310 mm(12 3/16in)
3 D cell batteries
3
4C-9442
Flashlight
375mm(143/4in)
4 D cell batteries
Accessories (Warranty: Six Months)
4C-9448
Mounting Clamp kit for
(Warranty:
4
all D cell flash- lights, 2
-
-
Caterpillar,
clamps and screws
Six Months)
Flashlight, Heavy-Duty
Warranty: Caterpillar ®Six Months
• Water-resistant, made of high impact plastic,
• Battery barrier protects bulb and head
with corrosion resistant contact parts and a
contacts from impact force
belt ring to prevent loss
• Comes with spare bulb
• Batteries not included
Part No.
Length
Batteries
Switch
Comeswith
1U-7319
210 mm (8 1/4in)
2 D cell batteries
-
-
JULY 2018 Shop Supplies
18-95
Shop Supplies
LIGHTING AND ELECTRICAL
Flashlight, Continuity Tester
Warranty: Caterpillar ®Lifetime
• Made of high impact plastic
• Uses 2 D cell batteries (not included)
• Can be used as a flashlight or continuity
• 1.82 m (72 in) length continuity wires shipped
tester
inside flashlight
• Yellow with black cap
• Magnet allows your hands to be free for
testing
Part No.
Description
Length
1U-7318
Continuity Tester / Flashlight
210 mm (8 1/4in)
Service Part
1U-9532
D-Cell Alkaline Battery
-
Flashlights, Cat® Branded
Warranty: Manufacturers Limited Lifetime
ANSI and CE marked
• Uses 2 D cell batteries (not included)
(Return defective product postage prepaid to the
• Lighting for use during service work
• 1.82 m (72 in) length continuity wires shipped
EZ Red Co, 8 Leonard Way, Deposit, NY 13754
inside flashlight
607-467-2866)
• Magnet allows your hands to be free for
testing
Part No.
Description
Weight
473-3336
Flashlight
0.109 kg
473-3337
Flashlight
0.186 kg
473-3338
Flashlight
0 .091 kg
473-3339
Flashlight
0 .136 kg
18-96 JULY 2018 Shop Supplies
Shop Supplies
LIGHTING AND ELECTRICAL
Slim Light, Cat® Rechargeable
Warranty: Caterpillar ®One Year
CE/REACH/ROHS/PAHS
Features
• Nospot is too tight for the CT1205
• Micro USB rechargeable (cable included) High
Rechargeable Slim Light. Generating 175
power LED/COB
lumens of flood light and 100 lumens of beam
• Dual light: flood & beam
light, it’s proof that good things come in small
• Magnetic pocket clip
packages.
• Protected charge port
• Slim design ensures that storage won’t be a
problem.
• Charge indicator
• With a run time of 3 hours on flood and 4
Specifications
hours on beam, this light delivers a long-
• 100 lumen beam output
lasting punch.
• 175 lumen flood light
• The magnetic pocket clip offers easy, hands-
free use.
• Water and impact resistant
Part No.
Description
Dimensions (H x W x D)
Weight
540-3913
Cat® RechargeableSlimLight
165 x 32 x 19 mm (6.5 x 1.25 x 0.75 in)
0.08 kg (0.17 lb)
Work Light, E-Z Red COB Extreme Light - Rechargeable
Warranty: Caterpillar ®One Year
CE/ROHS
• USB charging port (includes USB charge cord)
• 3W COB LED
• Over-charge protection
• 3.7V 4400 mAh Li-ion rechargeable battery
• Dimmable
• 500 lumens high, 150 lumens low
• Impact protection, ergonomic grip handle and
bumper
• Up to 4 hours high / 7 hours low continuous
use
• Easy operating soft-touch switch
• Approximately 6 hours of charging time
• 360 degree rotating hook for easy
maneuverability
Part No.
Description
Dimensions (H x W x D)
Weight
E-Z Red COB Extreme Light -
540-3914
305 x 51 x 38 mm (12 x 2 x 1.5 in)
0.31 kg (0.7 lb)
Rechargeable Work Light
Light, Inspection
Warranty: Manufacturer's Lifetime
• Lightweight, super compact light source
• Shock proof, corrosion proof
• White beam to penetrate smoke, fog and
• Economical, 30-hour long life lamp module
water
• Handy shirt clip
• Water-tight to 609.6 m (2000 ft)
• Includes two AA batteries
• Includes 90° light bender
Part No.
Description
141-1655
Inspection Light
Service Part
4C-6741
LampModule (Qty. 12) (Warranty: Manufacturer’s, Lifetime)
JULY 2018 Shop Supplies
18-97
Shop Supplies
LIGHTING AND ELECTRICAL
Light, Pen
Warranty: Manufacturer's, 120 Day
European Union Compliant, CE marked
• Handy shirt clip
• Madefrom temperedaircraft aluminum
• Push end of pen light to momentarily
illuminate or twist end clockwise for constant
• 100,000 hour lifetime, hi-intensity light
"on"
emitting diode (LED) bulb
• Waterproof
• Batteries last up to 60 hours
• Includes 3 AAAA batteries
Part No.
Description
238-8244
Pen Light, White LED
269-3123
Pen Light, Blue LED
Replacement Batteries
245-3224
AAAA-Cell Alkaline Battery
Battery, Lantern
Warranty: Caterpillar ®Six Months
• Offers dependable high performance for
• Recommended for all industrial lanterns
portable lighting uses
Part No.
Designation
Package Qty.
1U-9547
Lantern Battery, Spring Terminal, 6 Volt
12
Batteries, Industrial
Warranty: Caterpillar ®Six Months
Alkaline
Heavy-Duty
• Top-of-the-line for maximum service life
• Ideally suited for normal industrial use
• Best for use in high-drain, continuous use
situations
Part No.
Description
Voltage
Package Quantity
1U-9531
C-Cell Alkaline Battery
1.5
72
1U-9532
D-Cell Alkaline Battery
1.5
72
AA Alkaline Battery , non-rechargeable, package qty
1U-9533
1.5
96
96 (5 required to power Indicator III)
1U-9534
Battery - 9V Size (not shown)
9
72
1U-9535
AAA-Cell Alkaline Battery
1.5
96
1U-9536
C-Cell Heavy-Duty Battery
1.5
72
1U-9537
D-Cell Heavy-Duty Battery
1.5
72
1U-9538
AA-Cell Heavy-Duty Battery
1.5
96
1U-9539
9 Volt Heavy-Duty Battery
9
72
AAAA-Cell Alkaline Battery (Warranty: Manufacturer,
245-3224
1.5
6
120 Day)
18-98 JULY 2018 Shop Supplies
Shop Supplies
LIGHTING AND ELECTRICAL
Lights, Portable Fluorescent Work
Warranty: Manufacturer's, One Year
• 13 Watt fluorescent lamp is equivalent in light
• Entire light double insulated for user safety
output to a 60 Watt incandescent, but four
• Oil resistant power cord , UL listed and meets
4C-6479
4C-6378
times more efficient and will last up to 10
OSHA standards
times longer (10,000 hours)
• Durable and shatter resistant butyrate outer
• Built with the Saf-T-Lite design concept which
tube gives long life
places light and all electrical components
• 4C-6478 and 4C-6479 include magnetic
inside a closed chamber for user safety
mounts and vapor clips
• Protected on-off switch can be operated by
depressing domed end of the light
4C-6477
Part No.
Description
Length
Cord Type
Voltage/Watt
Standard Color
Portable Florescent
7.62 m (25 ft)
4C-6477
SJTO 18/2
110V/13 Watt
Yellow
Work Light
Cord
Portable Florescent
15.24 m (50 ft)
4C-6478
SJTO 18/2
110V/13 Watt
Yellow
Work Light
Cord
Portable Florescent
12.19 m (40 ft)
4C-6479
SJT 18/2
110V/13 Watt
Yellow
Work Light
Reel
Portable Florescent
9.5 m (30 ft)
9U-7203
SJTOW-A 18/2
12V/13 Watt
Yellow
Work Light
Cord
Service Parts for 9U-7203
Replacement Lamp,
9U-6712
-
-
-
-
12V, 13 Watt
Light Assembly Accessories
Warranty: Manufacturer's, One Year
Part No.
Description
Material
9U-6009
Fluorescent Lamp, 110V/13 Watt
Twin Tube, cool white light emission
9U-6009
9U-6010
Magnetic Mount 26.3 kg (58 lb) pull
Nickel plated magnet
9U-6010
Light Kit (Fluorescent)
Warranty: Manufacturer's, One Year
• 110V kit which includes 13 Watt lamp,
• Install onto any Saf-T-Lite reel or cordset
outer tube, switch assembly and installation
which was originally equipped with a 110V/13
instructions
Watt "Stubby" light head, such as 4C-6477,
4C-6478 or 4C-6479
Part No.
Description
9U-6710
Fluorescent Light Kit
Replacement Parts
9U-6009
Fluorescent Lamp, 110V/13 Watt
JULY 2018 Shop Supplies
18-99
Shop Supplies
LIGHTING AND ELECTRICAL
Light, Ratchet
Warranty: Caterpillar ®Six Months
UL Approved
• STOWtype cord - used for heavy duty
service and with oil-resistant, thermoplastic
• 120 Volt/60 Hz light made from yellow,
jacket, is weather resistant for outdoor use
unbreakable aerospace plastic with a 10 amp
tool-tap-plug
• Two year warranty on workmanship and
material defects (not including bulb)
• 10,000 hour life, 13 Watt rough-service
fluorescent bulb delivers output of a 60 Watt
• Handy magnetic base so you can position the
incandescent bulb
light where you need it
Part No.
Description
Cord Type
179-7043
Ratchet Light
STOW Type Cord - 7.62 m (25 ft) long, made from 16/3 wire
Extension Cord, Triple-Tap
Warranty: Caterpillar ®Six Months (Two year
UL Approved
• Case is made from shatter resistant ABS
warranty on workmanship and material defects)
plastic
• 120 Volt/60 Hz reel extension cord is 15.2 m
(50 ft) long, made from 16/3 wire with a built-
in 10 amp circuit breaker
Part No.
Description
179-7053
Triple-Tap Extension Cord
18-100 JULY 2018 Shop Supplies
Shop Supplies
LIGHTING AND ELECTRICAL
Electrical Cord Definitions
Abbreviations
U.L.
Underwriters Laboratories
C.U.L.
CanadianUnderwritersLaboratories
O.S.H.A.
Office of Safety and Health Administration
NEMA
National Electrical Manufacturers Association
Cord Designation by Letter
"S"
Hard surface, flexible cord, general use
"J"
300 Volt cord or smaller
"E"
Elastic synthetic rubber, good low temp cord
"W"
Watertight cord
"O"
Oil resistant
"A"
Low-temperature rated
"T"
Thermo-grade plastic
Extension Cords, Cat® Heavy-duty Contractor and Industrial Application
Warranty: Caterpillar ®Six Months
• Designed for heavy-duty use by contractors
• All cords have Cat logo printed on cord
and industrial applications
• All extension cords are UL (Underwriters
• Outer jacket protects against rough handling
Laboratory) listed and meet OSHA (Office
and extreme weather conditions
of Safety and Health Administration)
requirements
• Provides superior resistance to sunlight,
ozone, cracking, oils chemicals, and moisture
• All plugs and outlets are NEMA (National
Electrical Manufacturers Association)
• Materials: all-weather vinyl
designated - 5-15P plug and 5-15R outlet
Rating (S) Hard Surface, Flexible Cord, General Use; (J) 300 Volt cord or smaller;
Voltage
Operating
Part No.
Length
Outlet
Wire Size
(W)Watertight Cord; (O) Oil Resistant; (T) Thermo Grade Plastic)
Rating
Temperature
12 gauge, 3
-35 to 60°C
241-8522
25.00 ft
single
SJTOW
300 volts
conductor
(-31 to 140°F)
12 gauge, 3
-35 to 60°C
241-8529
50.00 ft
single
SJTOW
300 volts
conductor
(-31 to 140°F)
12 gauge, 3
-35 to 60°C
241-8530
100.00 ft
single
SJTOW
300 volts
conductor
(-31 to 140°F)
12 gauge, 3
-35 to 60°C
243-1874
25.00 ft
triple
SJTOW
300 volts
conductor
(-31 to 140°F)
12 gauge, 3
-35 to 60°C
243-1875
50.00 ft
triple
SJTOW
300 volts
conductor
(-31 to 140°F)
12 gauge, 3
-35 to 60°C
243-1876
100.00 ft
triple
SJTOW
300 volts
conductor
(-31 to 140°F)
10 gauge, 3
-35 to 60°C
243-1877
25.00 ft
triple
SJTOW
300 volts
conductor
(-31 to 140°F)
10 gauge, 3
-35 to 60°C
243-1878
50.00 ft
triple
SJTOW
300 volts
conductor
(-31 to 140°F)
10 gauge, 3
-35 to 60°C
243-1879
100.00 ft
triple
SJTOW
300 volts
conductor
(-31 to 140°F)
JULY 2018 Shop Supplies
18-101
Shop Supplies
LIGHTING AND ELECTRICAL
Connectors and Plugs, Heavy-Duty (20-30 Amps) with Insulating Cord Grip
Warranty: Manufacturer's
UL and CSA listed
• For use with tools, motors, grinding machines,
high pressure washers, outdoor lighting
• For use in construction sites, industrial, dusty,
and damp environments
Part No.
Type
Description
Cord Diameter
Yellow High Impact, with
14.27 - 26.97 mm
9U-6374
20 Amp, 125/250V Connector
InsulatingCord Grip
(.562in - 1.062in)
Yellow High Impact, with
15.875 - 28.575mm
9U-6378
30 Amp, 125V Connector
InsulatingCord Grip
(.625in - 1.125in)
Yellow High Impact, with
15.875 - 28.575mm
9U-6379
30Amp, 125VPlug
InsulatingCord Grip
(.625in - 1.125in)
Rubber Splicing Compound
Warranty: Caterpillar ®Six Months
• Linerless rubber tape
• Use for insulating and sealing on electrical
cable installation and repair
Part No.
Description
Size
Qty.
19 mm (3/4 in) wide x 0.8 mm (0.030 in)
4C-6393
Rubber Splicing Compound
1 roll per package
thick x 4.6 m (15 ft) long rolls
Wire Marker Tape Dispenser
Warranty: Caterpillar ®Six Months
• Provides a fast, convenient system for
• Ten refillable compartments with numbers
marking wire or cable
from 0 to 9 let you choose the exact number/
letter combinations needed
• Helps eliminate errors in the disassembly and
assembly of hydraulic lines, wiring harness,
• Easy to use, easy to carry; convenient rolls -
generator sets and panels
easy cutoff, no waste
• Highly resistant to oils and solvents
• Tapes are an epoxy film with an acrylic
adhesive
Part No.
Description
6V-7939
Wire Marker Tape Dispenser
Marker Tape Replacement Rolls (10 rolls per box)
8T-5209
Tape No. 0
8T-5211
Tape No. 1
8T-5212
Tape No. 2
8T-5213
Tape No. 3
8T-5214
Tape No. 4
8T-5215
Tape No. 5
8T-5216
Tape No. 6
8T-5217
Tape No. 7
8T-5218
Tape No. 8
8T-5219
Tape No. 9
18-102 JULY 2018 Shop Supplies
Shop Supplies
LIGHTING AND ELECTRICAL
Crimping Tools
Warranty: Caterpillar ®Six Months
• For insulated and uninsulated ferrules
Part No.
Wire Gauge
139-2788
24-12 AWG
139-2789
10-6 AWG
386-5102
28-24, 24-20, 18-16
Heat Shrinking Tubing
Warranty: Caterpillar ®Six Months
• Madefrompolyolefin
• Easy to install
• Effectively resists abrasion, scoring, cut-
• Use on inline electrical splices to provide
mechanical protection as well as corrosion
and moisture seal
hrough, and t e effects of long t m aging
Part No.
Expanded I.D.
Recovered I.D.
Recovered Length
Package Quantity
4C-6387
10mm (.400in)
3.8mm (0.15in)
152 mm (6 in)
25
4C-6388
20mm (.800in)
5.0mm (0.20in)
152 mm (6 in)
5
4C-6389
28 mm (1.10)
9.4mm (0.37in)
229 mm (9 in)
5
4C-6390
388mm(1.50in)
12.7mm (0.50in)
229 mm (9 in)
5
4C-6391
51mm (2.00in)
16.5mm (0.65in)
229 mm (9 in)
1
• Use on inline electrical splice where moisture
Heat Shrinking Tubing
and corrosion are a concern
Warranty: Caterpillar ®Six Months
• One piece, pre-insulated
• Easy application
Part No.
Wire
Barrel Length
I.D.
Color
Package Quantity
4C-6394
#22to18AWG
0.28
0.062
Red
100
4C-6395
#16to14AWG
0.30
0.095
Blue
100
4C-6396
#12to10AWG
0.38
0.142
Yellow
100
• Resists fungus, acids and alkalies, ozone and
Cold Shrink Insulators
ultra-violet light
Warranty: Caterpillar ®Six Months
• Rubber insulators can be used on cable to
• Easy to install (no flame/torch needed) -
insulate as well as to protect from moisture
unwind the expander core by pulling the
and corrosion while remaining flexible
insulator and tubing will shrink to cable
• When shrunk, connection is water resistant
diameter
• Very portable since no heat source is required
Part No.
Minimum Diameter
Tube Max.
Relaxed Package Length
Qty.
4C-6382
2.5mm (0.10in)
21.6mm (0.85in)
203 mm (8 in)
1
4C-6383
10.6mm (0.42in)
21.6mm (0.85in)
203 mm (8 in)
1
4C-6384
13mm (0.51in)
25.4 mm (1 in)
229 mm (9 in)
1
4C-6385
17.5mm (0.69in)
33mm (1.30in)
304.8mm (12in)
1
4C-6386
24.1mm (0.95in)
48.3mm (1.90in)
304.8mm (12in)
1
JULY 2018 Shop Supplies
18-103
Shop Supplies
LIGHTING AND ELECTRICAL
Wedge Removal Tool
Warranty: Caterpillar ®Six Months
• Use to remove wedges from DT series
Deutsch connectors
Part No.
Description
147-6456
Wedge Removal Tool (included in kit)
Plugs and Connectors, Straight Blade
Warranty: Manufacturer's
UL and CSA listed
• For use in construction sites, industrial, dusty,
and damp environments
• For use with tools, motors, grinding machines,
high pressure washers, outdoor lighting
Part No.
Type
Description
9U-6362
15 Amp, 125V AC Connector
2 Pole, 3 Wire, NEMA 5-15P
9U-6363
15Amp,125VAC Plug
2 Pole, 3 Wire, NEMA 5-15P
9U-6364
15 Amp, 250V AC Connector
2 Pole, 3 Wire, NEMA 6-15P
9U-6366
20 Amp, 125V AC Connector
2 Pole, 3 Wire, NEMA 5-20P
9U-6368
20 Amp, 250V AC Connector
2 Pole, 3 Wire, NEMA 6-20P
9U-6369
20Amp,250VAC Plug
2 Pole, 3 Wire, NEMA 6-20P
18-104 JULY 2018 Shop Supplies
Shop Supplies
LIGHTING AND ELECTRICAL
Sure Seal Series Field Service Kit
Warranty: Caterpillar ®Six Months
• Make or repair custom connectors
• Designed for 14 to 18 gauge wire carrying up
to 15 Amps
• Easy to assemble
• Forms a water, chemical, and grime resistant
Reference
seal
• Special Instruction SMHS7531, Use of Sure
• Wide variety of circuit configurations
Seal Repair Kit
• Tested from -40°C to 105°C (-40°F to 221°F)
Part Number
Qty.
Description
Size
6V-3000
1
Sure Seal Field Service Kit
-
Sure Seal Field Service Kit Consists of
6V-3001
1
Sure Seal Crimping Tool
-
6V-3007
1
Divided Box w/ Hinged Lid
6V-3008
1
Insertion Tool
-
7N-7779
100
Socket Connector
14 - 18 AWG
7N-7780
100
Pin Connector
14 - 18 AWG
9G-3695
50
Sealing Plug
1 Connector
7N-7777
3
Socket Housing
-
7N-7778
3
Plug Housing
-
2 Connector
7N-9737
3
Plug Housing
-
7N-9738
3
Socket Housing
-
3 Connector
7N-7781
3
Socket Housing
-
7N-7782
3
Plug Housing
-
4 Connector
7N-8204
3
Socket Housing
-
7N-8205
3
Plug Housing
-
5 Connector
9G-3672
1
Plug Housing
-
9G-3678
1
Socket Housing
-
6 Connector
9G-3671
1
Plug Housing
-
9G-3677
1
Socket Housing
-
7 Connector
9G-3670
-
Plug Housing
-
9G-3676
1
Socket Housing
-
8 Connector
9G-3669
1
Plug Housing
-
9G-3675
1
Socket Housing
-
9 Connector
9G-3668
1
Plug Housing
-
9G-3674
1
Socket Housing
-
10 Connector
9G-3667
1
Plug Housing
-
9G-3673
1
Socket Housing
-
JULY 2018 Shop Supplies
18-105
Shop Supplies
LIGHTING AND ELECTRICAL
Flashlight Kit (UV)
Warranty: Manufacturer's One Year
CE marked
Kit also contains:
Meets ASTM UV-A intensity and wavelength
• One pair UVS-30 absorbing Cat safety glasses
specifications for FPI and MPI
with ANSI,
• OPTI-LUX 365 UV-A LED Inspection Flashlight
• AUS/NZ, CE, CSA certifications
• 10,000 μW/cm2 of UV-A (365 nm) light at 38
• Spare battery
cm (15 in)
• Global charger set
• Instant on at full intensity
- 100-120v
• Each charge provides four hours of continuous
- 230v EU/CE
operation
- 240v AUS/CE
- 230v UK/CE
• 100,000-hour LED service life
• Lanyard
• Rugged anodized aluminum body
• Holster
• Weight 130 g (4.6 oz)
• Storage case
Part No.
Description
459-0184
UV Flashlight Kit
Cat® Power Pocket Light
Warranty: Manufacturer's Limited Lifetime
CE marked
• 2xAA batteries included
• Featuring a slim and compact design, the
• Hand tether
Cat® Power Pocket Light CT12351P features a
• Pocket clip
1-watt CREE® LED, and generates 100 lumens
of light output at a distance of 60meters.
Specifications
• Water and impact resistant, the CT12351P
• 60 meter beam distance
includes a hand tether and pocket clip for
• 100 lumen light output
easy portability.
2-hour runtime
•
Features
• Water and impact resistant
• Aircraft-grade aluminum
• 5.75 L x 0.75 in D (146 mm x 19 mm)
• 1WCREE® LED
• 0.9 lb (0.4 kg)
• Rear tactical switch
Part No.
Description
473-3336
Cat® Power Pocket Light
18-106 JULY 2018 Shop Supplies
Shop Supplies
LIGHTING AND ELECTRICAL
Cat®Tactical Flashlight
Warranty: Manufacturer's Limited Lifetime
CE marked
Features
• This compact and durable tactical flashlight is
• Aircraft-grade aluminum
designed for a lifetime of reliable use.
• 2WCREE® LED
• The Cat® tactical flash CT12352P features a
• Rear tactical 3-position switch
2-watt high-power CREE® LED, and generates
• 3xAAA batteries included
150 lumens of light output at a distance of 80
meters.
• Hand tether
• A rear-mounted weather-resistant switch
Specifications
provides 3 settings including HIGH, LOW, and
• 80 meter beam distance
STROBE.
• 150 lumen light output
• Water and impact resistant, the CT12352P
includes a hand tether for easy portability.
• 3-hour runtime
• Water and impact resistant
• 4.6 L x 1.2 in D (117 mm x 30 mm)
• 0.72 lbs (0.3 kg)
Part No.
Description
473-3337
Cat® Tactical Flashlight
Cat® Pocket COB Light
Warranty: Manufacturer's Limited Lifetime
CE marked
• COB LED technology
• The Cat® Pocket COB Light CT1000 provides
• Magnetic base
175 lumens of light output.
• Rear pocket clip
• Witha rugged,water resistant ABSbody and
Specifications
a flood beam effect, this light can brightly
illuminate a wide area.
• 175 lumen light output
• Upto 7-hour runtime
Features
• Water and impact resistant
• Flood beam effect
• 6 H x 0.55 W x 1.25 D in (152 mm x 14 mm x
• Rugged ABS body
32 mm)
• Water resistant
• 0.15 lb (0.07 kg)
Part No.
Description
473-3338
Cat® Pocket COB Light
JULY 2018 Shop Supplies
18-107
Shop Supplies
LIGHTING AND ELECTRICAL
Cat® LED Headlight
Warranty: Manufacturer's Limited Lifetime
CE marked
Features
• The CT40150P Cat® LED Headlight features
• Aircraft grade aluminum
a 1.5-watt CREE® LED, and generates 120
• 1.5W CREE® LED
lumens of light output at a distance of 60
• Front mount 2 position switch
meters.
• 3x AAA batteries included
• Including a 2-way front-mounted switch, the
CT40150P features a ratcheting light head for
• Ratcheting light adjustment
directing light as desired.
• Adjustable headband
• Water and impact resistant, the CT40150P
Specifications
features an adjustable headband for hands
free use.
• 60 meter beam distance
• 120 Lumen light output
• 3.5 hr runtime
• Water & impact resistant
• 2.0” L x 1.2” D (51 mm x 30 mm)
• .3 LBS (.1 kg)
Part No.
Description
473-3339
Cat® LED Headlight
18-108 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Utility
Warranty: Caterpillar ®Six Months
CE marked, EN388: 2211, AS/NZS2161.2
• Lighter and More Durable than Leather
• Black
• More Breathable than Leather
• Synthetic Leather Palm
• Reinforced Thumb
• Synthetic Leather Fingertips
• Adjustable Wrist Strap
• Spandex Back
Part No.
Size
377-5750
Medium
377-5751
Large
377-5752
Extra Large
Gloves, Utility
Warranty: Caterpillar ®Six Months
• Help protect from heat, cold, nicks, cuts, and
• Tough spandex top material resists snags
bruises
• Snug, comfort fit assures greater dexterity
• Split-palm design ensures long life in high-
• NOT flame-proof or fire retardant
wear areas
• Machine washable, air dry (Do NOT machine
• Hidden seam design eliminates snagging
dry)
Part No.
Size
Qty.
276-0491
Medium
Bulk - 6 pair
276-0492
Large
Bulk - 6 pair
276-0493
Extra Large
Bulk - 6 pair
276-0494
XX Large
Bulk - 6 pair
Gloves, Impact
Warranty: Caterpillar ®Six Months
• Design features improved dexterity and glove
• Split palm design puts 1 mm material in all
life
high wear areas
• Compression-molded Airprene knuckle and
• 3 mm gel palm padding reduces vibrations
index finger protection
• NOT flame-proof or fire retardant
• Seamless index finger for great fingertip
• Machine washable, air dry (do NOT machine
control
dry)
• Streamlined thermal plastic rubber (TPR) hook
and loop fastening on cuff
Part No.
Size
Qty.
276-0499
Medium
Bulk - 6 pair
276-0500
Large
Bulk - 6 pair
276-0501
Extra Large
Bulk - 6 pair
276-0502
XX Large
Bulk - 6 pair
18-109 JULY 2018 Shop Supplies
JULY 2018 Shop Supplies
18-109
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Insulated
Warranty: Caterpillar ®Six Months
• Improved thermal protection
• Compression-molded neoprene knuckle and
index finger protection
• Unique combination of Velboa and micro
fleece layer closest to skin for warmth
• Durable synthetic leather palm
• Neoprene cuff design with streamlined
• NOT flame-proof or fire retardant
thermal plastic rubber (TPR) hook and loop
• Machine washable, air dry (do NOT machine
fastening
dry)
Part No.
Size
Qty.
276-0495
Medium
Bulk - 6 pair
276-0496
Large
Bulk - 6 pair
276-0497
Extra Large
Bulk - 6 pair
276-0498
XX Large
Bulk - 6 pair
Gloves, Fingerless
Warranty: Caterpillar ®Six Months
• Protect hands while having full fingertip
• Snug, comfort fit assures greater dexterity
access
• NOT flame-proof or fire retardant
• Palm padding of 3 mm shock-absorbing gel
• Machine washable, air dry (do NOT machine
• Hidden seam design eliminates snagging
dry)
• Tough spandex top material resists snags
Part No.
Size
Qty.
276-0487
Medium
Bulk - 6 pair
276-0488
Large
Bulk - 6 pair
276-0489
Extra Large
Bulk - 6 pair
276-0490
XX Large
Bulk - 6 pair
Gloves, Padded Utility
Warranty: Caterpillar ®Six Months
CE marked, EN388: 1121, AS/NZS2161.2
• Spandex Back
• Padded Palm
• Yellow and Black
• Breathable Mesh
• Synthetic Leather Palm
• Adjustable Wrist Strap
• Synthetic Leather Fingertips
Part No.
Size
377-5737
Medium
377-5738
Large
377-5739
X Large
377-5740
XX Large
377-5741
XXX Large
18-110 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, High Visibility Padded Utility
Warranty: Caterpillar ®Six Months
CE marked, EN388: 1121, AVS/NZS
• Nylon Black
• High-Visibility Green
• Padded Palm
• Synthetic Leather Palm
• Reflective Tape
• Synthetic Leather Fingertips
• Adjustable Wrist Strap
• Reflective Tape Fingertips and Knuckle Strap
Part No.
Size
377-5734
Medium
377-5735
Large
377-5736
X Large
Gloves, Water-Resistant Utility
Warranty: Caterpillar ®Six Months
CE marked, EN388: 1121, AVS/NZS
• Reinforced Thumb
• Gray
• Silicone Grip Fingers
• Synthetic Leather Palm
• Reflective Piping
• Neoprene Back
• Adjustable Wrist Strap
• Padded Palm
Part No.
Size
377-5753
Medium
377-5754
Large
377-5755
X Large
Gloves, Padded Palm Utility Glove with Adjustable Wrist, Cat® Branded
Warranty: Caterpillar ®Six Months, First User
EN388, EN420
• High visibility reflective piping
Against Defects in Material & Workmanship
• Synthetic leather palm with PVC reinforced
• Wrap-around wrist strap for a secure fit
palm, fingers and knuckles
• EN 388: 2121
• Water-resistant rubber and nylon back
Part No.
Size
Weight
539-2756
Medium
0.2 kg (0.4 lb)
539-2758
Large
0.2 kg (0.4 lb)
539-2759
Jumbo
0.2 kg (0.4 lb)
Gloves, High Impact Synthetic Palm with Silicone Grip, Cat branded
Warranty: Caterpillar ®Six Months
• Synthetic leather palm with silicone grip
• Adjustable wrist closure
• Molded knuckle impact protection
• Meets EN 388: 3131
Part No.
Size
473-4628
Medium
473-4629
Large
473-4629
Jumbo
JULY 2018 Shop Supplies
18-111
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Leather-Driver
Warranty: Caterpillar ®Six Months
CE marked, EN388: 3122, AVS/NZS
• Palm Patch
• Unlined
• Ball and Tape Closure
• Double-Stitched
• Gunn Cut with Keystone Thumb
Part No.
Size
377-5742
Medium
377-5743
Large
377-5744
X Large
377-5745
XX Large
377-5746
XXX Large
Gloves, High-Visibility Leather Driver
Warranty: Caterpillar ®Six Months
CE marked, EN388: 4122, AVS/NZS
• Gunn Cut with Wing Thumb
• High-Visibility Green
• Elastic Wrist
Part No.
Size
377-5732
Large
Leather
• Gunn Cut with Wing Thumb
Gloves, High-Visibility Leather Palm
• Rubberized Safety Cuff
Warranty: Caterpillar ®Six Months
CE marked, EN388: 4122, AVS/NZS
• Elastic Wrist
• High-Visibility Green
• Grain Pigskin Leather
• Finger Tips and Knuckle Strap
Part No.
Size
377-5733
Large
Gloves, Hi-Visability, High Impact, Cat® Branded
Warranty: Caterpillar ®Six Months, First User
EN388, EN420
• Molded knuckle impact protection
Against Defects in Material & Workmanship
• Synthetic leather palm with PVC dots
• Sewn with cut- and heat-resistant aramid
thread
• Padded with high visibility poly/spandex back
• Laminated neoprene/nylon/polyester cuff
• Reflective knuckle strap
• EN 388: 1121
Part No.
Size
Weight
539-2761
Large
0.24 kg (0.5 lb)
539-2762
Jumbo
0.24 kg (0.5 lb)
539-2763
2X
0.24 kg (0.5 lb)
539-2764
3X
0.24 kg (0.5 lb)
18-112 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Fingerless Leather
Warranty: Caterpillar ®Six Months
CE marked, EN388: 1220, AS/NZS2161.2
• Spandex Black
• Black
• Breathable
• Double-Stitched
•
• Adjustable Wrist Strap
Part No.
Size
377-5756
Medium
Reversed Pigskin Leather Palm
377-5757
Large
377-5758
X Large
Gloves, Unlined Grain Leather Driver's
• Keystone thumb
• Pull-strap closure
Warranty: Caterpillar ®Six Months
CE marked, meets EN388, AVS/NZS
• Package of 12
• For drivers, utility, and warehouse workers
Part No.
Size
• Gunn cut patte
rn
282-9529
Large
282-9530
Extra Large
• Elastic shirred back holds glove securely to
hand
Gloves, Lined Leather Driver's
• Gunn cut pattern
Warranty: Caterpillar ®Six Months
• For drivers, utility and warehouse workers
• Extra warmth
Part No.
Size
Qty.
246-5147
Extra Large
12 Pair with Hang Tags
246-5149
Large
12 Pair with Hang Tags
246-5151
Medium
12 Pair with Hang Tags
JULY 2018 Shop Supplies
18-113
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Split Leather Palm
Warranty: Caterpillar ®Six Months
• For tough rugged jobs
• Gauntlet cuff style
• Full leather index finger
• Elastic on back with knuckle strap
Part No.
Size
Qty.
Large
12 Pair with Hang Tags
•246-5155m
and leather
tips
• Full leather index finger
• Wingthumb
Gloves, Split Cowhide Palm
Warranty: Caterpillar ®Six Months
• For medium- to heavy-duty work
• Gunn cut pattern
Part No.
Size
Qty.
282-9531
Medium
Bulk - 12 Pair
282-9532
Large
Bulk - 12 Pair
282-9533
Extra Large
Bulk - 12 Pair
• Knitwrist cuff
Gloves, Traditional All-purpose
• Plastic dots on inner side and back of index
finger
Warranty: Caterpillar ®Six Months
• For general work
• Cotton blend
Part No.
Size
Qty.
246-5163
Large
Bulk - 12 Pair
• PVC Dotted Palm and Fingers
Gloves, Fleece-Lined Dotted Jersey
• Gunn Cut with Continuous Thumb
• Open Cuff
Warranty: Caterpillar ®Six Months
CE marked, EN388: 0221, AS/NZS2161.2
• Black
• Cotton Jersey
• Fleece Lined
Part No.
Size
377-5747
Large
• Micro-Dotted Palm and Fingers
Gloves, Fleece-Lined Dotted Jersey
• Gunn Cut with Continuous Thumb
• Knit Wrist
Warranty: Caterpillar ®Six Months
CE marked, EN388: 1111, AS/NZS2161.2
• Black
• Cotton Jersey
Part No.
Size
377-5748
Medium
377-5749
Large
18-114 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Jersey
Warranty: Caterpillar ®Six Months
CE marked, EN388
• Soft knit fabric
• For general purpose use
• Stretch to provide excellent fit
Part No.
Size
Qty.
246-5165
Large
12 Pair with Hang Tags
385-5557
Large
Bulk - 144 Pairs
Gloves, Fleeced
Warranty: Caterpillar ®Six Months
• For outside work
• Double layer of fabric
• Knitwrist cuff
• Added warmth
Part No.
Size
Qty.
246-5167
Large
Bulk - 12 Pairs
Gloves, Leather Welding
Warranty: Caterpillar ®Six Months
• One piece back fully welted
• Color: Gold
Part No.
Size
Qty.
247-4447
Large
Single Pair
Gloves, Chemical-resistant Nitrile
Warranty: Caterpillar ®Six Months
• When using gloves as Personal Protection
• Protect against cuts, abrasions, punctures,
Equipment (PPE), always consult the Material
and snags
• Safety Data Sheet (MSDS) for the chemical
• Embossed texture improves grip
that is being handled for the most appropriate
• Will not swell or weaken like rubber or
glove.
neoprene in solvents and fats
Part No.
Size
Thickness
Application
Chemical Resistance
Qty.
SodiumHydroxide, Freon,
Chemical Handling Acids,
Xylene, Hydro-chlor- ic
Solvents, Caustics, Oils, Grease,
Bulk
Acid, Stoddard Solvent,
4C-5522
L
15 mil
Degreasing Machine operations
- 12
Potassium Hydrox- ide,
using cut- ting oil, metal
Pair
Perchloroethylene,
fabrication
Phosphoric Acid
SodiumHydroxide, Freon,
Chemical Handling Acids,
Xylene, Hydro-chlor- ic
Bulk
Solvents, Caustics, Oils, Grease,
Acid, Stoddard Solvent,
4C-5523
XL
22 mil
- 12
Degreasing Better protection than
Potassium Hydrox- ide,
Pair
4C-5522 due to thickness.
Perchloroethylene,
Phosphoric Acid
JULY 2018 Shop Supplies
18-115
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Work Glove,WaterproofThermal-Coated
Warranty: Cat® 1st User Warranty Against
ANSI Cut Level 2, EN388 Cut Level 3
• High-visibility color enhances worker
Defects in Material and Workmanship
protection and compliance.
• For jobs that require handling sharp materials
in cold and wet conditions, the Magid® ROC®
• Color-coded overcast reduces fraying and acts
HV250WWaterproof Thermal-Coated Work
as a visual aid in sizing.
Glove keeps hands dry and warm while also
• Machine washable for longer service life
delivering ANSI level A2 cut protection.
• ANSI Level A2 Cut Resistance under the
• Insulcore™ Extreme Thermal Lining delivers
ANSI/ISEA 105-2016 Standard, ANSILevel
ultimate protection against cold temperatures.
4 Abrasion Resistance and ANSI Level 3
• Aquagard™ Waterproof Membrane is
Puncture Resistance
guaranteed to keep hands dry.
• Rated an ANSI Cut Level 2 under the ANSI/
• NitriX® Grip Technology palm coating delivers
ISEA 105-2011 Standard using the ASTM
rock-solid grip, enhanced abrasion resistance
te
and increases wear life.
Part No.
Description
Size
Weight
539-8084
9
Magid ROC HV250W Waterproof
539-
8095
10
0.12 kg (0.26 lb)
Thermal-Coated Work Glove
539-8096
11
18-116 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Nitrile-coated Knit-lined
Warranty: Caterpillar ®Six Months
CE Cat. 11
• Excellent grip
• For dry and light oil applications
• When using gloves as Personal Protection
Equipment (PPE), always consult the Material
• Resistance to cuts and abrasions
Safety Data Sheet for the chemical that is
• Porous coating is soft and flexible
being handled for themost appropriate glove.
Part No.
Size
Qty.
Application
Chemical
Light to mediumduty, general purpose, fabrica- tion,
12 pair per
4C-5526
Large
assembly, maintenance, shipping, and re- ceiving. Excellent
Oil, Grease
package
grip in light oil applications.
Gloves, Neox with Neoprene Coating
Warranty: Caterpillar ®Six Months
• Resistance to cuts, abrasions, and chemicals
• When using gloves as Personal Protection
Equipment , always consult the Material
• Interlock knit lining enhances puncture and
Safety Data Sheet for the chemical that is
snag resistance
being handled for the most appropriate glove.
• Two-piece lining eliminates irritating seams
Part No.
Size
Qty.
Application
Chemical Resistance
Acids, Solvents,
One size
12 pair per
Resists Heat,Cutting, Usein Plating,
(Ex.:Glycol Ether),
4C-5527
fits most
package
Galvanizing Degreasing, Petrochemicals
Oils, Caustics, Soaps,
Alcohols
Gloves, Neoprene-coated Knit-lined
Warranty: Caterpillar ®Six Months
CE Marked, EN388:3222, EN511:121, EN374,
• Fabric lining enhances puncture and snag
EN374:AKL, EN407:43XXXX
resistance
• For full-arm protection when using chemicals
• When using gloves as Personal Protection
Equipment, always consult the Material
• Broad protection against cuts and abrasions
Safety Data Sheet for the chemical that is
• Resist oils, caustics, acids, alcohol, and
being handled for the most appropriate glove.
solvents
Part No.
Size
Qty.
Application
Chemical Resistance
One size
Single
Resists Heat,Cutting, Usein Plating,
Acids, Solvents, (Ex:Glycol Ether),
4C-5529
fits most
Pair
Galvanizing, Sandblasting Cabinet
Oils, Caustics, Soaps, Alcohols
Gloves, Nitrile Disposable
Warranty: Caterpillar ®Six Months
• EN 374, EN 388, EN 420 & FDA 21 CFR
• Ideal combination of thickness and dexterity
177.2600
Rolled cuff prevents tearing when donning
gloves
• Gloves for any single-use application requiring
lightweight protection from fluids, dirt and
• 5ml thick
chemicals, Magid’s ComfortFlex® COMPLETE
• Industrial grade
BK powder-free, black disposable nitrile
• 9.5” length
gloves are ideal for dirty jobs.
• 100 gloves per dispenser
• Powder-free nitrile eliminates concerns of
airborne contamination
Part No.
Size
472-0401
Medium
472-0402
Large
472-0403
Extra Large
472-0404
Extra Extra Large
JULY 2018 Shop Supplies
18-117
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Best Nitrile Disposable
Warranty: Caterpillar ®Six Months
CE marked,Cat 1
• Low allergy risk
• 0.10 mm thick
• Smooth finish
• Powder free
• Box of 100
• Rolled Cuff keeps dirt out
Part No.
Qty.
381-7612
Medium
381-7613
Large
381-7614
X Large
Gloves, Disposable Powder-Free Nitrile
Warranty: Caterpillar ®Six Months
CE Marked, meets EN 388:1994 and EN 374-
• Contains no latex
3:1994
• 5 mil thick
• Superior resistance to abrasives, chemicals,
and punctures
Part No.
Description
Size
Qty.
246-5180
Powder-Free
Large
100 per box
259-7007
Powder-Free
Medium
100 per box
259-7008
Powder-Free
Extra Large
100 per box
Gloves, Disposable Powdered Nitrile
Warranty: Caterpillar ®Six Months
CE Marked, meets EN 388:1994 and EN 374-
• Contains no latex
3:1994
• 5 mil thick
• Superior resistance to abrasives, chemicals,
and punctures
Part No.
Description
Size
Qty.
246-5179
Powdered
Large
100 per box
259-7005
Powdered
Medium
100 per box
259-7006
Powdered
Extra Large
100 per box
Gloves, Disposable Latex
Warranty: Caterpillar ®Six Months
CE Marked, meets EN 388:1994 and EN 374-
• Excellent sensitivity touch
3:1994
• Seamless construction
• For working with chemicals
• Rubber latex
• Extra stretch for best fit
• 5 mil thick, 10 in long
Part No.
Size
Qty.
246-5181
Large
100 per box
260-1779
Extra Large
100 per box
18-118 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Nitrile Coated
Warranty: Caterpillar ®Six Months
CE marked, EN388: 3121, AS/NZS2161.2
• Nitrile-coated Nylon
• Yellow
• Ajustable wrist strap
Part No.
Size
377-5759
Medium
377-5760
Large
377-5761
X Large
Gloves, High-Visibility Nitrile Coated String Knit
Warranty: Caterpillar ®Six Months
CE marked, EN388: 2243, AS/NZS2161.2
• Textured for enhanced grip
• High-Visibility Green
• Cold Resistant
• Latex-Coated String Knit
• Adjustable Wrist Strap
Part No.
Size
377-5762
Medium
377-5763
Large
377-5764
X Large
Gloves, Nitrile Coated Bamboo
Warranty: Caterpillar ®Six Months
CE marked, EN388
• More comfortable and tougher than other
fabrics
• Made of sustainable materials
• Bamboo also breathes better, wicks away
more moisture, and is cooler
Part No.
Size
385-5553
Large
385-5554
X Large
385-5555
XX Large
Gloves, Cut Resistant, Level 2
Warranty: Caterpillar ®Six Months
CE marked, EN388
• Strong and flexible
• Lycra and Kevlar glove with Nitrile coated
• Knit wrist
palm
• ANSI cut level 2 protection
Part No.
Size
381-7607
Medium
381-7608
Large
381-7609
X Large
JULY 2018 Shop Supplies
18-119
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Cut Resistant
Warranty: Caterpillar ® defects in material and
ANSI, CE
• ANSI Cut Level A4, EN388 Cut Level 5
workmanship to first user
• 15 g orange engineered yarn liner
• Improved grip and abrasion resistance
• Black polyurethane palm coating
• Repels liquids from palm of hand
• Reinforced thumb crotch
Part No.
Description
Size
Weight
539-3724
Medium
539-3725
Cut-Resistant Gloves
Large
0.08 kg (0.18 lb)
539-3726
XL
Gloves, Cut Resistant
Warranty: Caterpillar ® defects in material and
ANSI, CE
• ANSI Cut Level A2, EN388 Cut Level 3
workmanship to first user
• Gray basetek innovative fiber technology liner
• Improved grip and abrasion resistance
• Gray polyurethane palm coating
• Repels liquids from palm of hand
Part No.
Description
Size
Weight
539-3712
Medium
539-3713
Cut-Resistant Gloves
Large
0.12 kg (0.26 lb)
539-3714
XL
Gloves, Cut Resistant
Warranty: Caterpillar ® defects in material and
ANSI, CE
• ANSI Cut Level A3, EN388 Cut Level 5
workmanship to first user
• 13 g gray basetek innovative fiber technology
• Improved grip and abrasion resistance
liner
• Repels liquids from palm of hand
• Gray polyurethane palm coating
Part No.
Description
Size
Weight
539-3715
Medium
539-3716
Cut-Resistant Gloves
Large
0.13 kg (0.29 lb)
539-3717
XL
18-120 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, Cut Resistant
Warranty: Caterpillar ® defects in material and
ANSI, CE
• ANSI Cut Level A4, EN388 Cut Level 5
workmanship to first user
• 13 g green basetek innovative fiber
• Improved grip and abrasion resistance
technology liner
• Repels liquids from palm of hand
• Black polyurethane palm coating
Part No.
Description
Size
Weight
539-3718
Medium
539-3719
Cut-Resistant Gloves
Large
0.17 kg (0.37 lb)
539-3720
XL
Gloves, Cut Resistant, Level 4
Warranty: Caterpillar ®Six Months
CE EN 388, EN 407
• Comfortable with excellent feel
• Made of high performance polyethylene
• Breathable
(HPPE), nylong and Spandex with a
• Knit wrist
polyurethane coated palm
• ANSI cut level 4 protection
• Better gripping than nitrile coated gloves
• ANSI abrasion level 5 protection
• Strong and flexible
Part No.
Description
381-7611
Cut Resistant Gloves - Level 4
Gloves, Cut Resistant
Warranty: Caterpillar ® defects in material and
ANSI, CE
• ANSI Cut Level A3, EN388 Cut Level 5
workmanship to first user
• 13 g blue engineered yarn liner
• Improved grip and abrasion resistance
• Black polyurethane palm coating
• Repels liquids from palm of hand
• Reinforced thumb crotch
Part No.
Description
Size
Weight
539-3721
Medium
539-3722
Cut-Resistant Gloves
Large
0.13 kg (0.29 lb)
539-3723
XL
Gloves, Nylon with Nitrile Coating
Warranty: Caterpillar ®Six Months
• For maintenance/assembly and shipping/
• Excellent cut and abrasion resistances
receiving
• Goodalternative to heavy cotton-coated
gloves
Part No.
Size
Qty.
247-6412
Large
12 Pair with Hang Tags
247-6413
Extra-Large
12 Pair with Hang Tags
JULY 2018 Shop Supplies
18-121
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Gloves, General Purpose
Warranty: Caterpillar ® defects in material and
ANSI, CE
• Black hybrid coating technology microfoam
workmanship to first user
nitrile coating
• Great value, general purpose glove
• “All in one”: Fit, Feel, Flexibility, Breathability,
• 15 g, gray nylon liner
Durability, Excellent Wet Grip
Part No.
Description
Size
Weight
539-3706
Medium
539-3707
General Purpose Gloves
Large
0.11 kg (0.23 lb)
539-3708
XL
Gloves, General Purpose
Warranty: Caterpillar ® defects in material and
ANSI, CE
• Black hybrid coating technology microfoam
workmanship to first user
nitrile coating
• Great value, general purpose glove
• “All in one”: Fit, Feel, Flexibility, Breathability,
• 15 g, gray nylon liner
Durability, Excellent Wet Grip
• ¾ nitrile coating provides full-finger coverage
Part No.
Description
Size
Weight
539-3709
Medium
539-3710
General Purpose Gloves
Large
0.16 kg (0.34 lb)
539-3711
XL
Gloves, General Purpose
Warranty: Caterpillar ® defects in material and
ANSI, CE
• Black polyurethane palm coating
workmanship to first user
• 13 g black nylon liner
• For general assembly or inspection purposes
Part No.
Description
Size
Weight
539-4696
Medium
539-4697
General Purpose Gloves
Large
0.06 kg (0.13 lb)
539-4698
XL
Palm-Coated Work Glove
Warranty: Caterpillar ®Six Months
ANSI and EN/CEMarked
• 13-gauge machine HPPE-blended shell
delivers a ground-breaking combination of
• EN388 cut level 5, ANSI cut level 5, ANSI
ultra-lightweight comfort and maximum cut
abrasion resistance level 6, ANSI puncture
protection.
resistance level 4
• Touchscreen-compatible.
• The D-ROC® GPD800 offers superior comfort,
dexterity and grip with the maximum level of
• Grey color hides dirt and grime extending
cut protection around the entire glove.
wear.
• Polyurethane palm coating maintains dexterity
• Sold in packages of 12
while delivering excellent grip.
Part No.
Size
Weight
Description
495-5913
9 Medium
0.79 kg per pair
Palm-Coated Work Glove
495-5914
10Large
0.79 kg per pair
Palm-Coated Work Glove
495-5915
11 XL
0.79 kg per pair
Palm-Coated Work Glove
18-122 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Coveralls, Tyvek
Warranty: Caterpillar ®Six Months
• White coveralls with zipper front
• Strong, whether wet or dry
• For general maintenance work, fiberglass
• Resistant to abrasion, tears, and punctures
handling, spray painting, and sand blasting
• 100%Polyethylene construction
• Offers splash protection against many liquids
• Blocks out 99.9% of all dry particulate down
• Lightweight and soft
to 0.5 microns
Part No.
Size
Qty.
267-8539
Large
25
267-8540
Medium
25
267-8541
Small
25
267-8542
X Large
25
267-8543
XX Large
25
267-8544
XXX Large
25
267-8545
XXXX Large
25
Rain Jackets and Pants
Warranty: Manufacturer’s
• 0.35 mm (.014 in) PVC exterior laminated
• Corduroy collar
to polyester interior [PVC is a synthetic
• Raglan sleeves for maximum mobility (a
thermoplastic elastomer (TPE) which provides
raglan sleeve is attached to a garment body
excellent ozone and weather resistance.]
at a 45 degree angle helping it to stretch from
• Double-lapped heat-welded construction
neckline to underarm)
• Non-conductive hardware
• Take-up snaps at cuff
• Meets California Proposition 65
• Back yoke ventilation
Rain Jacket
Rain Pants
• Yellow rain jacket with a detachable hood and
• Yellow rain pants with fly front overall and
two patch pockets
pockets with flaps
• Full snap front
• Fabric/elastic suspender and elastic waist
band
• Inner storm fly prevents rain and debris from
penetrating front opening
• Take-up snaps at ankle
Part No.
Chest Size
Waist Size
Size
Rain Jacket
311-2983
Medium, 101.6-106.68 cm (40-42 in)
-
-
311-2984
Large, 111.76-116.84 cm (44-46 in)
-
-
311-2985
XLarge, 121.92-127 cm (48-50in)
-
-
Rain Pants
311-2986
-
Medium, 91.44-96.52 cm (36-38 in)
-
311-2987
-
Large, 101.6-106.68 cm (40-42in)
-
311-2988
-
XLarge,111.76-116.84 cm (44-46in)
-
2 Pc Suits
311-2979
-
-
Medium
311-2980
-
-
Large
311-2981
-
-
XLarge
JULY 2018 Shop Supplies
18-123
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Highway Warning Kit, Triangular
Warranty: Caterpillar ®Six Months
• Three reflective triangles in a sturdy plastic
• Complies with Federal Motor Vehicle Safety
case
Standard Number 1
• Compact, fold-flat design
• Great for day or night visibility
• Durable spring steel base
Part No.
Description
Case Dimensions (L x W x H)
Size
Qty.
262-4862
Triangular Warning Kit
45.7 x 13 x 13 cm (18 x 5 x 5 in)
43 cm (17 in)
3 per case
Safety Vests
Warranty: Caterpillar ®Six Months
262-9301 LimeGreenMeshSafety Vest
262-9176 Orange Mesh Safety Vest
• Non-reflective, lime green color
• Non-reflective, dayglow orange color
• Front hook and loop closure with black cloth
• Front hook and loop closure
binding
• Elastic side straps
• One size fits all
• One size fits all
• Material: 100% polyester mesh
• Material: 100% polyester mesh
Part No.
Description
Color
Material
262-9176
Safety Vest
Orange
Polyester Mesh
262-9301
Safety Vest
Lime Green
Polyester Mesh
18-124 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Safety Vest, Cat® 5-Point Breakaway
Warranty: Manufacturer’s One Year
Meets CSA Z96
• Crossover placket with hook-and-loop closure
Workmanship. Contact JM Industrial supply at
on front shoulders, front placket, and at sides
• 3.2 oz. (110 gsm), 100% polyester mesh
309-346-5796 or wendy@jmindsupply.com.
• Two transparent badge pockets with hook-
• 3M Scotchlite Reflective stripes
and-loop closures on left chest and lower right
Part No.
Color
Size
461-0914
Hi-Vis Yellow
M/L
461-0915
Hi-Vis Yellow
XL/2XL
461-0916
Hi-Vis Orange
M/L
461-0917
Hi-Vis Orange
XL/2XL
Safety Vest, Cat® 5-Point Breakaway
Warranty: Manufacturer’s One Year
Meets ANSI 107 Class 2, ISO EN 20471, AS/
• Crossover placket with hook-and-loop closure
Workmanship. Contact JM Industrial supply at
NZS 4602
on front shoulders, front placket, and at sides
309-346-5796 or wendy@jmindsupply.com.
• 3.2 oz. (110 gsm), 100% polyester mesh
• Two transparent badge pockets with hook-
and-loop closures on left chest and lower right
• 3M Scotchlite Reflective stripes
Part No.
Color
Size
461-0918
Hi-Vis Yellow
M/L
461-0919
Hi-Vis Yellow
XL/2XL
461-0920
Hi-Vis Orange
M/L
461-0921
Hi-Vis Orange
XL/2XL
JULY 2018 Shop Supplies
18-125
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Safety Vest, Cat® Branded
Warranty: Manufacturer’s One Year
Meets CSA Z96
• 3M Scotchlite Reflective stripes
Workmanship. Contact JM Industrial supply at
• 3.5 oz. (120 gsm), 100% polyester tricot
• Crossover placket with hook-and-loop closure
309-346-5796 or wendy@jmindsupply.com.
Part No.
Color
Size
461-0922
Hi-Vis Yellow
M/L
461-0923
Hi-Vis Yellow
XL/2XL
461-0924
Hi-Vis Orange
M/L
461-0925
Hi-Vis Orange
XL/2XL
Safety Vest, Cat® Branded
Warranty: Manufacturer’s One Year
Meets ANSI 107 Class 2, ISO EN 20471, AS/
• 3M Scotchlite Reflective stripes
Workmanship. Contact JM Industrial supply at
NZS 4602
• Crossover placket with hook-and-loop closure
309-346-5796 or wendy@jmindsupply.com.
• 3.5 oz. (120 gsm), 100% polyester tricot
Part No.
Color
Size
461-0926
Hi-Vis Yellow
M/L
461-0927
Hi-Vis Yellow
XL/2XL
461-0928
Hi-Vis Orange
M/L
461-0929
Hi-Vis Orange
XL/2XL
18-126 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
T-Shirt, Cat® Branded Hi-Vis Short Sleeved
Warranty: Manufacturer’s One Year
Meets CSA Z96
• Moisture wicking, 6 oz. (200 gsm), 100%
Workmanship. Contact JM Industrial supply at
polyester jersey
• 3M Scotchlite Reflective stripes
309-346-5796 or wendy@jmindsupply.com.
Part No.
Color
Size
461-0930
Hi-Vis Yellow
M
461-0931
Hi-Vis Yellow
L
461-0932
Hi-Vis Yellow
XL
461-0933
Hi-Vis Yellow
2XL
461-0934
Hi-Vis Orange
M
461-0935
Hi-Vis Orange
L
461-0936
Hi-Vis Orange
XL
461-0937
Hi-Vis Orange
2XL
T-Shirt, Cat® Branded Hi-Vis Short Sleeved
Warranty: Manufacturer’s One Year
Meets ANSI 107 Class 2, ISO EN 20471, AS/
• Moisture wicking, 6 oz. (200 gsm), 100%
Workmanship. Contact JM Industrial supply at
NZS 4602
polyester jersey
309-346-5796 or wendy@jmindsupply.com.
• 3M Scotchlite Reflective stripes
Part No.
Color
Size
461-0938
Hi-Vis Yellow
M
461-0939
Hi-Vis Yellow
L
461-0940
Hi-Vis Yellow
XL
461-0941
Hi-Vis Yellow
2XL
461-0942
Hi-Vis Orange
M
461-0943
Hi-Vis Orange
L
461-0944
Hi-Vis Orange
XL
461-0945
Hi-Vis Orange
2XL
JULY 2018 Shop Supplies
18-127
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Safety Glasses, Cat® Branded, Tread
Warranty: Manufacturer's One Year
ANSI Z87.1:2003, AS/NZS 1337:1992, CE
• Lenses and temples flex for a comfortable fit
marked, EN 166:2001, CSA Z94.3:2007
• Full frames with vented top and bottom
• Lightweight and stylish
• Crystal clear polycarbonate lenses
• Soft, vented nose piece
• Anti-scratch/anti-fog coating
• Cushioned temple arms
• Weight - 1 oz (29 g)
• Three position adjustable temples with a
• Retail Box and Packaging
snap-lock positioning
• Cat® branded
• Wrap lens
Part No.
Lens Type
Package Quantity
396-2013
Clear
10
396-2014
Smoke
10
396-2015
Blue Mirror
10
Safety Glasses, Cat® Branded, Dozer
Warranty: Manufacturer's One Year
ANSI Z87.1:2003, AS/NZS 1337:1992, CE
• Lenses and temples flex for a comfortable fit
marked, EN 166:2001, CSA Z94.3:2007
• 180 degree high wrap around style lens
• Lightweight and stylish
• Crystal clear polycarbonate lenses
• Rubber grip nose piece
• Anti-scratch/anti-fog coating
• Four position adjustable temples with a snap-
• Weight - 0.84 oz (24 g)
lock positioning
• Retail Box and Packaging
• Sides extendable by 0.5 in (12 mm)
• Cat® branded
Part No.
Lens Type
Package Quantity
396-2010
Clear
10
396-2011
Smoke
10
396-2012
Blue Mirror
10
Safety Glasses, Cat® Branded, Shield
Warranty: Manufacturer's One Year
ANSI Z87.1:2003, AS/NZS 1337:1992, CE
• Crystal clear polycarbonate lenses
marked, EN 166:2001, CSA Z94.3:2007
• Anti-scratch/anti-fog coating
• Lightweight
• Weight - 0.811 oz (23 g)
• Lenses and temples flex for a comfortable fit
• Retail Box and Packaging
• 180 degree high wrap around style lens
• Cat® branded
Part No.
Lens Type
Package Quantity
396-2005
Clear
10
396-2006
Smoke
10
18-128 JULY 2018 Shop Supplies
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Safety Glasses, Cat® Branded, Grit
Warranty: Manufacturer's One Year
ANSI Z87.1:2010, AS/NZS 1337:1, CE marked,
• High wrap molded lenses for optimal
CSA Z94.3:2007, EN 166:2011
protection
• Super lightweight, fashion sunglasses styling
• Anti-scratch/anti-fog coating
• Nylon frames with injected rubber temples
• Weight - 1.05 oz (30g)
and nose pad
• Retail Box and Packaging
• 180-degree high wrap around style lens
• Cat® branded
• Crystal clear polycarbonate lenses
Part No.
Lens Type
Package Quantity
435-4061
Smoke
10
Safety Glasses, Cat® Branded, Guard
Warranty: Manufacturer's One Year
ANSI Z87.1:2010, AS/NZS 1337:1, CE marked,
• 100% optical lens clarity
CSA Z94.3 :2007, EN 166:2011
• Anti-scratch/anti-fog coating
• Ultra-lightweight metal frames with spring
• Weight - 1.37 oz (39g)
hinges
• Retail Box and Packaging
• Rubber nose pad and temple tips
• Cat® branded
• 180-degree high wrap around style lens
Part No.
Lens Type
Package Quantity
460-3236
Clear
10
460-3237
Smoke
10
Safety Glasses, Cat® Branded, Torque
Warranty: Manufacturer's One Year
ANSI Z87.1:2010, AS/NZS 1337:1, CE marked,
• 180-degree high wrap around style lens
CSA Z94.3.2007, EN 166:2011
• Crystal clear polycarbonate lenses
• Foam-lined safety glasses for dust proof fit
• Anti-scratch/anti-fog coating
• Light and durable nylon chassis with indirect
• Weight - 1.79 oz (49g)
ventilation
• Retail Box and Packaging
• Detachable temples for use with the included
• Cat® branded
strap
Part No.
Lens Type
Package Quantity
460-3238
Clear
10
Safety Glasses, Wraparound
Warranty: Caterpillar ®Six Months
Meets or exceeds all ANSI, CSA, and CE
• Can be worn over prescription glasses
specifications
• 99.9% UVA and UVB protection
• Visitor disposable safety glasses
Part No.
Lens Type
Package Quantity
239-1085
Clear
1
JULY 2018 Shop Supplies
18-129
Shop Supplies
PERSONAL PROTECTIVE EQUIPMENT
Safety Glasses, Overspec
Warranty: Caterpillar ® defects in material and
AS/NZS 1337.1:2010 SAI Lic: SMKH25509
• Effective and comfortable when worn over
workmanship to first user
prescription glasses or alone
• Keep visitors safe with these frontier clear
lens overspec safety glasses
• 99% UV-resistant
• Available in Australia/New Zealand region
• Anti-scratch and anti-fog lens
Part No.
Description
Dimensions (L x W x H)
Weight
536-3573
Overspec Safety Glasses
150x50 x50mm(2.9x2x2in)
0.03 kg (0.08 lb)
18-130 JULY 2018 Shop Supplies
