Chapter 5 Function Code Table
If PP-00 is set to a non-zero number, parameter protection is enabled. You must enter the correct user
password to enter the menu.
To cancel the password protection function, enter with password and set PP-00 to 0.
Group P and Group A are standard function parameters. Group C includes the monitoring function
parameters.
The symbols in the function code table are described as follows:
"☆": The parameter can be modified when the AC drive is in either stop or running state.
"★": The parameter cannot be modified when the AC drive is in the running state.
"●": The parameter is the actually measured value and cannot be modified.
"*": The parameter is factory parameter and can be set only by the manufacturer.
5.1 Standard Function Parameters
Function
Parameter Name
Setting Range
Default
Property
Code
Group P0: Standard Function Parameters
1: G type (constant torque load)
Model
P0-00
GP type display
●
2: P type (variable torque load)
dependent
0: Sensorless flux vector control (SFVC)
P0-01
Motor 1 control mode
2
★
2: Voltage/Frequency (V/F) control
0: Operation panel control (LED off)
P0-02
Command source selection
1: Terminal control (LED on)
0
☆
2: Communication control (LED blinking)
0: Digital setting (non-retentive at power
failure)
1: Digital setting (retentive at power failure)
2: AI1
Main frequency source X
3: AI2
P0-03
0
★
4: AI3
selection
5: Pulse setting (X5)
6: Multi-reference
7: Simple PLC
8: PID
31
Function
Parameter Name
Setting Range
Default
Property
Code
Auxiliary frequency source Y
The same as P0-03 (Main
P0-04
0
★
selection
frequency source X selection)
Range of auxiliary frequency
0: Relative to maximum
P0-05
0
☆
Y for X and Y operation
frequency
Range of auxiliary frequency
P0-06
0% ～ 150%
100%
☆
Y for X and Y operation
Unit's digit (Frequency source
selection)
0: Main frequency source X
1: X and Y operation
(operation relationship
determined by ten's digit)
2: Switchover between X and Y
P0-07
Frequency source selection
3: Switchover between X and "X
00
☆
and Y operation"
4: Switchover between Y and "X
and Y operation"
Ten's digit (X and Y operation
relationship)
0: X+Y 1: X-Y
2: Maximum
3: Minimum
0.00 to maximum frequency
P0-08
Preset frequency
(valid when frequency source is
50.00Hz
☆
digital setting)
0: Same direction
P0-09
Rotation direction
0
☆
1: Reverse direction
P0-10
Maximum frequency
50.00Hz ～ 320.00Hz
50.00Hz
★
0: Set by F0-12
1: VS 1
2: AS
3: VS2
P0-11
Source of frequency upper limit
0
★
4: Pulse setting
5: Communication setting
Frequency lower limit (P0-14) to
P0-12
Frequency upper limit
50.00Hz
☆
maximum frequency (P0-10)
0.00 Hz to maximum frequency
P0-13
Frequency upper limit offset
0.00Hz
☆
(P0-10)
0.00 Hz to frequency upper limit
P0-14
Frequency lower limit
0.00Hz
☆
(P0-12)
32
Function
Parameter Name
Setting Range
Default
Property
Code
Model
P0-15
Carrier frequency
0.5kHz ～ 16.0kHz
☆
dependent
Carrier frequency
0: No
P0-16
1
☆
adjustment with temperature
1: Yes
Model
P0-17
Acceleration time 1
0s ～ 65000s
☆
dependent
Model
P0-18
Deceleration time 1
0s ～ 65000s
☆
dependent
0:1s
Acceleration/Deceleration time
P0-19
1: 0.1s
1
★
unit
2: 0.01s
Frequency offset of auxiliary
0.00 Hz to maximum frequency
P0-21
frequency source for X and
0.00Hz
☆
P0-10)
Y operation
1: 0.1Hz
P0-22
Frequency reference resolution
2
★
2: 0.01Hz
Retentive of digital setting
0: Not retentive
P0-23
0
☆
frequency upon power failure
1: Retentive
0: Motor parameter group 1
1: Motor parameter group 2
P0-24
Motor parameter group selection
0
★
2: Motor parameter group 3
3: Motor parameter group 4
0: Maximum frequency (P0-10)
Acceleration/
P0-25
1: Set frequency
0
★
Deceleration time base frequency
2: 100 Hz
Base frequency for UP/ DOWN
0: Running frequency
P0-26
modification during
0
★
1: Set frequency
running
33
Function
Parameter Name
Setting Range
Default
Property
Code
Unit's digit (Binding operation
panel command to frequency
source)
0: No binding
1: Frequency source by digital
setting
2: AI1
3: AI2
4: AI3
5: Pulse setting (X 5)
Binding command source to
P0-27
6: Multi-reference
0000
frequency source
☆
7: Simple PLC
8: PID
9: Communication setting
Ten's digit (Binding terminal
command to frequency source)
0-9, same as unit's digit
Hundred's digit (Binding
communication command to
frequency source)
0-9, same as unit's digit
0: Modbus protocol
P0-28
Serial communication protocol
1: Profibus-DP bridge
0
☆
2: CANopen bridge
Group P1: Motor 1 Parameters
0: Common asynchronous motor
1: Variable frequency
P1-00
Motor type selection
0
★
asynchronous motor
2: Permanent magnetic
synchronous motor
Model
P1-01
Rated motor power
0.1kW ～ 1000.0kW
★
dependent
Model
P1-02
Rated motor voltage
1V ～ 2000V
★
dependent
0.01-655.35 A (AC drive power ≤ 55 kW)Model
P1-03
Rated motor current
★
0.1-6553.5 A (AC drive power > 55 kW)
dependent
34
Function
Parameter Name
Setting Range
Default
Property
Code
Model
P1-04
Rated motor frequency
0.01 Hz to maximum frequency
★
dependent
Model
P1-05
Rated motor rotational speed
1rpm ～ 65535rpm
★
dependent
0.001-65.535 Ω (AC drive power ≤ 55
Stator resistance
kW)
Tuned
P1-06
★
(asynchronous motor)
0.0001-6.5535 Ω (AC drive power > 55
parameters
kW)
0.001-65.535 Ω (AC drive power ≤ 55
Rotor resistance
Tuned
kW)
P1-07
★
(asynchronous motor)
0.0001-6.5535 Ω (AC drive power > 55
parameters
kW)
0.01-655.35 mH (AC drive power ≤ 55
Leakage inductive reactance
kW)
Tuned
P1-08
★
(asynchronous motor)
0.001-65.535 mH (AC drive power >
parameters
55 kW)
0.1-6553.5 mH (AC drive power ≤ 55
Mutual inductive reactance
Tuned
kW)
P1-09
★
(asynchronous motor)
0.01--655.35 mH (AC drive power > 55
parameters
kW)
No-load current
0.01 to P1-03 (AC drive power ≤ 55 kW) Tuned
P1-10
★
(asynchronous motor)
0.1 to P1-03 (AC drive power > 55 kW)
parameters
0.001-65.535 Ω (AC drive power ≤ 55
Stator resistance
Tuned
kW)
P1-16
★
(synchronous motor)
0.0001-6.5535 Ω (AC drive power > 55
parameters
kW)
0.01-655.35 mH (AC drive power ≤ 55
Shaft D inductance
Tuned
kW)
P1-17
★
(synchronous motor)
0.001-65.535 mH (AC drive power >
parameters
55 kW)
0.01-655.35 mH (AC drive power ≤ 55
Shaft Q inductance
Tuned
kW)
P1-18
★
(synchronous motor)
0.001-65.535 mH (AC drive power >
parameters
55 kW)
35
Function
Parameter Name
Setting Range
Default
Property
Code
Back EMF (synchronous
Tuned
P1-20
0.1V ～ 6553.5V
★
motor)
parameters
P1-27
Encoder pulses per revolution
1 ～ 65535
1024
★
0: ABZ incremental encoder
1: UVW incremental encoder
P1-28
Encoder type
2: Resolver
0
★
3: SIN/COS encoder
4: Wire-saving UVW encoder
A/B phase sequence of ABZ
P1-30
0: Forward
1: Reserve
0
★
incremental encoder
P1-31
Encoder installation angle
0.0 ～ 359.9°
0.0°
★
U, V, W phase sequence of
P1-32
0: Forward
1: Reverse
0
★
UVW encoder
P1-33
UVW encoder angle offset
0.0 ～ 359.9°
0.0°
★
P1-34
Number of pole pairs of resolver
1 ～ 65535
1
★
Encoder wire-break fault
0.0s: No action
P1-36
0.0
★
detection time
0.1-10.0s
0: No auto-tuning
1: Asynchronous motor static
auto-tuning
2: Asynchronous motor complete
P1-37
Auto-tuning selection
auto-tuning
0
★
11: Synchronous motor with-load
auto-tuning
12: Synchronous motor no-load
auto-tuning
Group P2: Vector Control Parameters
P2-00
Speed loop proportional gain 1
1 ～ 100
30
☆
P2-01
Speed loop integral time 1
0.01s ～ 10.00s
0.50s
☆
P2-02
Switchover frequency 1
0.00 ～ P2-05
5.00Hz
☆
P2-03
Speed loop proportional gain 2
1 ～ 100
20
☆
P2-04
Speed loop integral time 2
0.01s ～ 10.00s
1.00s
☆
P2-05
Switchover frequency 2
P2-02 to maximum output
10.00Hz
☆
P2-06
Vector control slip gain
50% ～ 200%
100%
☆
Time constant of speed loop
P2-07
0.000s ～ 0.100s
0.000s
☆
filter
36
Function
Parameter Name
Setting Range
Default
Property
Code
Vector control over excitation
P2-08
0 ～ 200
64
☆
gain
0:Function Code P2-10 Setting
1: VS
2: AS
3: VS2
Torque upper limit source in
4: Pulse setting
P2-09
0
☆
speed control mode
5: Communication setting
6: MIN(VS,AS)
7: MAX(VS,AS)
1-7 option full scale correspond
P2-10
Digital setting of torque upper
P2-10
0.0% ～ 200.0%
150.0%
☆
limit in speed control mode
Excitation adjustment
P2-13
0 ～ 20000
2000
☆
proportional gain
Excitation adjustment integral
P2-14
0 ～ 20000
1300
☆
gain
P2-15
Torque adjustment proportional0 ～ 20000
2000
☆
Torque adjustment integral
P2-16
0 ～ 20000
1300
☆
gain
Unit's digit: integral separation
P2-17
Speed loop integral property
0
☆
0: Disabled 1: Enabled
0: No field weakening
Field weakening mode of
P2-18
1: Direct calculation
1
☆
synchronous motor
2: Automatic adjustment
Field weakening depth of
P2-19
50% ～ 500%
100%
☆
synchronous motor
37
Function
Parameter Name
Setting Range
Default
Property
Code
Maximum field weakening
P2-20
1% ～ 300%
50%
☆
current
Field weakening automatic
P2-21
10% ～ 500%
100%
☆
adjustment gain
Field weakening integral
P2-22
2 ～ 10
2
☆
multiple
Group P3: V/F Control Parameters
0: Linear V/F
1: Multi-point V/F
2: Square V/F
3: 1.2-power V/F
4: 1.4-power V/F
P3-00
V/F curve setting
0
★
6: 1.6-power V/F
8: 1.8-power V/F
9: Reserved
10: V/F complete separation
11: V/F half separation
0.0% (fixed torque boost)
Model
P3-01
Torque boost
☆
0.1%-30.0%
dependent
Cut-off frequency of torque
0.00 Hz to maximum output
P3-02
50.00Hz
★
boost
frequency
Multi-point V/F frequency 1
P3-03
0.00Hz ～ P3-05
10.00Hz
★
Multi-point V/F voltage 1
P3-04
0.0% ～ 100.0%
28.0%
★
Multi-point V/F frequency 2
P3-05
P3-03 ～ P3-07
25.00Hz
★
Multi-point V/F voltage 2
P3-06
0.0% ～ 100.0%
55.0%
★
Multi-point V/F frequency 3
P3-05 to rated motor frequency
P3-07
37.00Hz
★
(P1-04)
38
Function Code
Parameter Name
Setting Range
Default
Property
P3-08
Multi-point V/F voltage 3
0.0% ～ 100.0%
78.0%
★
P3-09
V/F slip compensation gain
0.0% ～ 200.0%
0.0%
☆
P3-10
V/F over-excitation gain
0 ～ 200
64
☆
V/F oscillation suppression
Model
P3-11
0 ～ 100
☆
gain
dependent
0: Digital setting (P3-14)
1: AI1
2: AI2
3: AI3
4: Pulse setting (X5)
Voltage source for V/F
P3-13
5: Multi-reference
0
☆
separation
6: Simple PLC
7: PID
8: Communication setting
100.0% corresponds to the rated
motor voltage
Voltage digital setting for V/F
P3-14
0 V to rated motor voltage
0V
☆
separation
0.0-1000.0s
Voltage rise time of V/F
It indicates the time for the
P3-15
0.0s
☆
separation
voltage rising from 0 V to rated
motor voltage.
Overcurrent stall prevention
100 to 200 (% inverter rated
P3-18
170
☆
current limit (for VF mode)
current)
Over current stall prevention
P3-19
0: Disable; 1: Enable
1
☆
enable
Over current stall prevention
P3-20
0 to 100
20
☆
gain
39
Function Code
Parameter Name
Setting Range
Default
Property
Group P4 Input terminal
0: No function
1: Forward RUN (FWD)
X1 function selection
2: Reverse RUN (REV)
P4-00
(Standard on-board)
3: Three-line control
1
★
4: Forward JOG (FJOG)
5: Reverse JOG (RJOG)
6: Terminal UP
7: Terminal DOWN
8: IGBT enable
X2 function selection
9: Fault reset (RESET)
P4-01
(Standard on-board)
10: RUN pause
2
★
11: Normally open (NO) input of
external fault
12: Multi-reference terminal 1
13: Multi-reference terminal 2
14: Multi-reference terminal 3
X3 function selection
15: Multi-reference terminal 4
P4-02
(Standard on-board)
16: Terminal 1 for acceleration/
12
★
deceleration time selection
17: Terminal 2 for acceleration/
deceleration time selection
18: Frequency source switchover
19: UP and DOWN setting clear
X4 function selection
(terminal, operation panel)
P4-03
(Standard on-board)
20: Command source switchover
13
★
terminal 1
21: Acceleration/Deceleration
prohibited
40
22: PID pause
23: PLC status reset
X5 function selection
24: Swing pause
P4-04
(Standard on-board)
25: Counter input
14
★
26: Counter reset
27: Length count input
28: Length reset
29: Torque control prohibited
30: Pulse input (enabled only for
DI5)
X6 function selection
P4-05
31: Reserved
0
★
(On-board expansion card)
32: Immediate DC braking
33: Normally closed (NC) input of
external fault
34: Frequency modification
forbidden
35: Reverse PID action direction
X7 function selection
P4-06
36: External STOP terminal 1
0
★
(On-board expansion card)
37: Command source switchover
terminal 2
38: PID integral pause
39: Switchover between main
frequency source
X and preset frequency
X8 function selection
P4-07
40: Switchover between auxiliary
0
★
(On-board expansion card)
frequency
source Y and preset frequency
41: Motor selection terminal 1
41
42: Motor selection terminal 2
43: PID parameter switchover
44: User defined fault 1
X9 function selection
P4-08
45: User defined fault 2
0
★
(On-board expansion card)
46: Speed control/Torque control
switchover
47: Emergency stop
48: External STOP terminal 2
49: Deceleration DC braking
50: Clear the current running
time
51: Switchover between two-line
X10 function selection
P4-09
mode and
0
★
(On-board expansion card)
three line mode
53: UPS mode enable
54: Single/Two phase UPS
enable
55-59: Reserved
P4-10
X filter time
0．000s～1.000s
0.010
★
42
Function
Parameter Name
Setting Range
Default
Property
Code
0: Two-line mode 1
1: Two-line mode 2
P4-11
Terminal command mode
0
★
2: Three-line mode 1
3: Three-line mode 2
P4-12
Terminal UP/DOWN rate
0.001Hz/s ～ 65.535Hz/s
1.00Hz/s
☆
P4-13
VS curve 1 minimum input
0.00V ～ P4-15
0.00V
☆
Corresponding setting of VS
P4-14
-100.0% ～ +100.0%
0.0%
☆
curve 1 minimum input
P4-15
VS curve 1 maximum input
P4-13 ～ +10.00V
10.00V
☆
Corresponding setting of VS
P4-16
-100.0% ～ +100.0%
100.0%
☆
curve 1 maximum input
P4-17
VS filter time
0.00s ～ 10.00s
0.10s
☆
P4-18
VS curve 2 minimum input
0.00V ～ P4-20
0.00V
☆
Corresponding setting of VS
P4-19
-100.0% ～ +100.0%
0.0%
☆
curve 2 minimum input
P4-20
VS curve 2 maximum input
P4-18 ～ +10.00V
10.00V
☆
Corresponding setting of VS
P4-21
-100.0% ～ +100.0%
100.0%
☆
curve 2 maximum input
P4-22
AS filter time
0.00s ～ 10.00s
0.10s
☆
P4-23
VS curve 3 minimum input
-10.00V ～ P4-25
-10.00V
☆
VS Corresponding setting of VS
P4-24
-100.0% ～ +100.0%
-100.0%
☆
curve 3 minimum input
P4-25
VS curve 3 maximum input
P4-23 ～ +10.00V
10.00V
☆
Corresponding setting of VS
P4-26
-100.0% ～ +100.0%
100.0%
☆
curve 3 maximum input
P4-27
VS2 filter time
0.00s ～ 10.00s
0.10s
☆
P4-28
PULSE minimum input
0.00kHz ～ P4-30
0.00kHz
☆
Corresponding setting of
P4-29
-100.0% ～ 100.0%
0.0%
☆
pulse minimum input
43
Function
Parameter Name
Setting Range
Default
Property
Code
P4-30
PULSE maximum input
P4-28 ～ 100.00kHz
50.00kHz
☆
Corresponding setting of
P4-31
-100.0% ～ 100.0%
100.0%
☆
pulse maximum input
P4-32
PULSE filter time
0.00s ～ 10.00s
0.10s
☆
Curve 1 (2 points, see P4-13 to
P4-16)
Curve 2 (2 points, see P4-18 to
P4-21)
Curve 3 (2 points, see P4-23 to
P4-26)
Curve 4 (4 points, see A6-00 to
P4-33
VS curve selection
321
☆
A6-07)
Curve 5 (4 points, see A6-08 to
A6-15)
Ten's digit
AS curve selection (same as VS)
Hundred's digit
VS2 curve selection (same as
Unit's digit (Setting for VS less
than minimum input)
0: Minimum value
1: 0.0%
Setting for VS less than
Ten's digit (Setting for AS less
P4-34
000
☆
minimum input
than minimum input)0, 1 (same
as VS)
Hundred's digit (Setting for VS2
less than minimum input)0, 1
(same as VS)
44
Function
Parameter Name
Setting Range
Default
Property
Code
P4-35
X1 delay time
0.0s ～ 3600.0s
0.0s
★
P4-36
X2 delay time
0.0s ～ 3600.0s
0.0s
★
P4-37
X3 delay time
0.0s ～ 3600.0s
0.0s
★
0: High level valid
1: Low level valid
Unit's digit: X1
Ten's digit: X2
P4-38
X valid mode selection 1
00000
★
Hundred's digit: X3
Thousand's digit: X4
Ten thousand's digit: X5
0: High level valid
1: Low level valid
Unit's digit: X6
Ten's digit: X7
P4-39
X valid mode selection 2
00000
★
Hundred's digit: X8
Thousand's digit: X9
Ten thousand's digit: X10
0: Voltage signal
1: Current signal
P4-40
AS input signal selection
0
★
45
Function
Parameter Name
Setting Range
Default
Property
Code
Group P5: Output Terminals
0: Pulse output (Y2P)
P5-00
Y2 terminal output mode
1
☆
1: Pulse output (Y2R)
0: No output
1: AC drive running
2: Fault output (stop)
3: Frequency-level detection
PDT1 output
4: Frequency reached
5: Zero-speed running (no output
at stop)
6: Motor overload pre-warning
7: AC drive overload pre-warning
Y2R function (open collector
8: Set count value reached
output terminal)
9: Designated count value
Attention!
reached
P5-01
2
☆
Set P5-00 = 1 when used as
10: Length reached
11: PLC cycle complete
MC or Brake output.
12: Accumulative running time
reached
13: Frequency limited
14: Torque limited
15: Ready for RUN
16: VS>AS
17: Frequency upper limit
reached
18: Frequency lower limit
reached
(no output at stop)
19: Under voltage state output
20: Communication setting
P5-02
Relay function (T/A-T/B-T/C)
21: Reserved
43
☆
22: Reserved
23: Zero-speed running 2 (having
output at stop)
Extension card relay function
24: Accumulative power-on time
P5-03
42
☆
( P/A-P/B-P/C )
reached
46
25: Frequency level detection
Y1 function selection (open
FDT2 output
P5-04
0
☆
collector output terminal)
26: Frequency 1 reached
27: Frequency 2 reached
28 : Current 1 reached
29 : Current 2 reached
30 : Timing reached
31 : AI-1 input limit exceeded
32 : Load becoming 0
33 : Reverse running
34 : Zero current state
35 : Module temperature reached
36 : Software current limit
exceeded
37 : Frequency lower limit
reached
(having output at stop)
P5-05
38 : Alarm output
Extension card Y2
Extension card DO2 function
0
☆
39 : Motor overheat warning
function
40 : Current running time
reached
41 : Fault output
(There is no output if it is the
coast-to-stop fault and
under-voltage
occurs)
42 : Brake output
43 : MC (Magnetic contactor)
output
47
Function
Parameter Name
Setting Range
Default
Property
Code
0 : Running frequency
P5-06
Y2P function selection
0
☆
1: Set frequency
P5-07
AO1 function selection
3
☆
2: Output current
3: Output torque (absolute value)
4: Output power
5: Output voltage
6: Pulse input
7: VS
8: AS
9: VS2
Expansion cards AO2 function
P5-08
10: Length
1
☆
selection
11: Count value
12: Communication setting
13: Motor rotational speed
14: Output current (100.0%
correspond 1000.0A)
15: Output voltage ( 100.0%
correspond 1000.0V )
16: Output torque (actual value)
Maximum YPY output
P5-09
0.01kHz～100.00 kHz
50.00kHz
☆
frequency
P5-10
AO1 offset coefficient
-100.00%～+100.00%
0.0%
☆
P5-11
A01gain
-10.00～+10.00
1.00
☆
P5-12
AO2 offset coefficient
-100.00%～+100.00%
0.00%
☆
P5-13
AO2 gain
-10.00～+10.00
1.00
☆
P5-17
Y2P output delay time
0.00S～3600.0S
0.0s
☆
P5-18
RELAY1 output delay time
0.00S～3600.0S
0.0s
☆
P5-19
RELAY2output delay time
0.00S～3600.0S
0.0s
☆
P5-20
Y1 output delay time
0.00S～3600.0S
0.0s
☆
P5-21
DO2 output delay time
0.00S～3600.0S
0.0s
☆
48
Function
Parameter Name
Setting Range
Default
Property
Code
0: Positive logic
1: Negative logic
Unit's digit: Y2R
P5-22
DO valid mode selection
Ten's digit: RELAY1
0.0s
☆
Hundred's digit: RELAY2
Thousand's digit: Y1
Ten thousand's digit: Y2
Group P6: Start/Stop Control
0: Direct start
1: Rotational speed tracking
P6.00
Start mode
restart
0
☆
2: Pre-excited start
(asynchronous motor)
Rotational speed tracking
0: From frequency at stop
P6.01
0
★
mode
1: From zero speed
Rotational speed tracking
P6.02
1～100
20
☆
speed
P6.03
Startup frequency
0.00Hz～10.00Hz
1.00Hz
☆
P6.04
Startup frequency holding time
0.0s～100.0s
0.3s
★
Startup DC braking current/
P6-05
0% ～ 100%
0%
★
Pre-excited current
Startup DC braking time/
P6-06
0.0s ～ 100.0s
0.0s
★
Pre-excited time
0: Linear
Acceleration/Deceleration
acceleration/deceleration
P6-07
3
mode
3: S-curve acceleration/
★
deceleration C
49
Function
Parameter Name
Setting Range
Default
Property
Code
Time proportion of S-curve
P6-08
0.0% ～ (100.0%-P6-09)
80.0%
★
start segment
Time proportion of S-curve
P6-09
0.0% ～ (100.0%-P6-08)
10.0%
★
end segment
0: Decelerate to stop
P6-10
Stop mode
0
☆
1: Coast to stop
Initial frequency of stop DC
P6-11
0.00 Hz to maximum frequency
0.00Hz
☆
braking
Waiting time of stop DC
P6-12
0.0s ～ 100.0s
0.0s
☆
braking
P6-13
Stop DC braking current
0% ～ 100%
30%
☆
P6-14
Stop DC braking time
0.0s ～ 5.0s
0.5s
☆
P6-15
Stop DC braking time
0% ～ 100%
100%
☆
P6-26
Time proportion of S-curve at
0.0% to Min[(100.0% - F6-27),
20%
☆
P6-27
Time proportion of S-curve at
0.0% to Min[(100.0% - F6-26),
30%
☆
Group P7: Operation Panel and Display
0: MF.K key disabled
1：Switchover between
operation panel control and
remote command control
P7-01
MF Key function selection
0
★
(terminal or communication)
2：Positive & negative switching
3: Forward JOG
4: Reverse JOG
0: STOP/RESET key enabled
only in operation panel control
P7-02
STOP/RESET key function
1
☆
1: STOP/RESET key enabled in
any operation mode
50
Function
Parameter Name
Setting Range
DefaultProperty
Code
0000-FFFF
Bit00: Running frequency 1 (Hz)
Bit01: Set frequency (Hz)
Bit02: Bus voltage (V)
Bit03: Output voltage (V)
Bit04: Output current (A)
Bit05: Output power (kW)
Bit06: Output torque (%)
P7-03
LED display running parameters 1
Bit07: X input status
1F
☆
Bit08: DO output status
Bit09: VS voltage (V)
Bit10: AS voltage (V)
Bit11: VS2 voltage (V)
Bit12: Count value
Bit13: Length value
Bit14: Load speed display
Bit15: PID setting
51
0000-FFFF
Bit00: PID feedback
Bit01: PLC stage
Bit02: Pulse setting frequency(kHz)
Bit03: Running frequency 2 (Hz)
Bit04: Remaining running time
Bit05: VS voltage before correction (V)
Bit06: AS voltage before correction (V)
P7-04
LED display running parameters 2
Bit07: VS2 voltage before correction (V)0
☆
Bit08: Linear speed
Bit09: Current power-on time(Hour)
Bit10: Current running time (Min)
Bit11: Pulse setting frequency(Hz)
Bit12: Communication setting value
Bit13: Encoder feedback speed(Hz)
Bit14: Main frequency X display(Hz)
Bit15: Auxiliary frequency Y display (Hz)
Function
Parameter Name
Setting Range
DefaultProperty
Code
0000-FFFF
Bit00: Set frequency (Hz)
Bit01: Bus voltage (V)
Bit02: X input status
Bit03: DO output status
Bit04: VS voltage (V)
Bit05: AS voltage (V)
P7-05
LED display stop parameters
33
☆
Bit06: VS2 voltage (V)
Bit07: Count value
Bit08: Length value
Bit09: PLC stage
Bit10: Load speed
Bit11: PID setting
Bit12: Pulse setting frequency (kHz)
P7-06
Load speed display
0.0001 ～ 6.5000
1.0000
☆
52
P7-07
Heatsink temperature of inverter module0.0℃～ 100.0℃
-
●
P7-08
Temporary software version
-
-
●
P7-09
Accumulative running time
0h ～ 65535h
-
●
P7-10
Product number
-
-
●
P7-11
Software version
-
-
●
0: 0 decimal place
Number of decimal places
P7-12
1: 1 decimal place
1
☆
for load speed display
2: 2 decimal places
P7-13
Accumulative power-on time
0 ～ 65535 h
-
●
P7-14
Accumulative power consumption
0 ～ 65535 kwh
-
●
Performance software
P7-15
NA
0
●
temporary version
Functional software
P7-16
NA
0
●
temporary version
Group P8: Auxiliary Functions
P8-00
JOG running frequency
0.00 Hz to maximum frequency
2.00Hz☆
P8-01
JOG acceleration time
0.0s ～ 6500.0s
20.0s
☆
P8-02
JOG deceleration time
0.0s ～ 6500.0s
20.0s
☆
53
Function
Parameter Name
Setting Range
Default
Property
Code
Model
P8-03
Acceleration time 2
0.0s ～ 6500.0s
☆
dependent
Model
P8-04
Deceleration time 2
0.0s ～ 6500.0s
☆
dependent
Model
P8-05
Acceleration time 3
0.0s ～ 6500.0s
☆
dependent
Model
P8-06
Deceleration time 3
0.0s ～ 6500.0s
☆
dependent
Model
P8-07
Acceleration time 4
0.0s ～ 6500.0s
☆
dependent
Model
P8-08
Deceleration time 4
0.0s ～ 6500.0s
☆
dependent
P8-09
Jump frequency 1
0.00Hz to maximum frequency
0.00Hz
☆
P8-10
Jump frequency 2
0.00Hz to maximum frequency
0.00Hz
☆
P8-11
Frequency jump amplitude
0.00Hz to maximum frequency
0.01Hz
☆
Forward/Reverse rotation
P8-12
0.0s ～ 3000.0s
0.0s
☆
dead-zone time
P8-13
Reverse control
0: Enabled 1: Disabled
0
☆
Running mode when set
0: Run at frequency lower limit
P8-14
frequency lower than frequency
1: Stop
0
☆
lower limit
2: Run at zero speed
P8-15
Droop control
0.00Hz ～ 10.00Hz
0.00Hz
☆
Accumulative power-on time
P8-16
0h ～ 65000h
0h
☆
threshold
Accumulative running time
P8-17
0h ～ 65000h
0h
☆
threshold
P8-18
Startup protection
0: No 1: Yes
0
☆
Frequency detection
P8-19
0.00 Hz to maximum frequency
50.00Hz
☆
value(FDT1)
Frequency detection
P8-20
0.0% ～ 100.0% (FDT1 level)
5.0%
☆
value(FDT1)
54
Function
Parameter Name
Setting Range
Default
Property
Code
Detection range of frequency
P8-21
0.0% ～ 100.0% (maximum frequency)
0.0%
☆
reached
Jump frequency during
P8-22
0: Disabled
1: Enabled
0
☆
acceleration/deceleration
Frequency switchover point
P8-25
between acceleration time 1
0.00 Hz to maximum frequency
0.00Hz
☆
and acceleration time 2
Frequency switchover point
P8-26
between deceleration time 1
0.00 to maximum frequency
0.00Hz
☆
and deceleration time 2
P8-27
Terminal JOG preferred
0: Disabled
1: Enabled
0
☆
Frequency detection value
P8-28
0.00 to maximum frequency
50.00Hz
☆
(PDT2)
Frequency detection
P8-29
0.0%-100.0% (PDT2 level)
5.0%
☆
hysteresis (PDT2)
Any frequency reaching
P8-30
0.00 Hz to maximum frequency
50.00Hz
☆
detection value 1
Any frequency reaching
P8-31
0.0%-100.0% (maximum frequency)
0.0%
☆
detection amplitude 1
Any frequency reaching
P8-32
0.00 Hz to maximum frequency
50.00Hz
☆
detection value 2
Any frequency reaching
P8-33
0.0%-100.0% (maximum frequency)
0.0%
☆
detection amplitude 2
P8-34
Zero current detection level
0.0%-300.0% (rated motor current)
5.0%
☆
Zero current detection delay
P8-35
0.01s ～ 600.00s
0.10s
☆
time
P8-36
0.0% (no detection)
200.0%
☆
Output over current threshold
0.1%-300.0% (rated motor current)）
55
Function
Parameter Name
Setting Range
Default
Property
Code
Output over current detection
P8-37
0.00s ～ 600.00s
0.00s
☆
delay time
P8-38
Any current reaching 1
0.0%-300.0% (rated motor current)
100.0%
☆
Any current reaching 1
P8-39
0.0%-300.0% (rated motor current)
0.0%
☆
amplitude
P8-40
Any current reaching 2
0.0%-300.0% (rated motor current)
100.0%
☆
Any current reaching 2
P8-41
0.0%-300.0% (rated motor current)
0.0%
☆
amplitude
P8-42
Timing function
0: Disabled
1: Enabled
0
☆
0: P8-44
1: AI1
2: AI2
P8-43
Timing duration source
0
☆
3: AI3
(100% of analog input corresponds to the
value of P8-44)
P8-44
Timing duration
0.0Min ～ 6500.0Min
0.0Min
☆
P8-45
VS input voltage lower limit
0.00V ～ P8-46
3.10V
☆
P8-46
VS input voltage upper limit
P8-45 ～ 10.00V
6.80V
☆
P8-47
Module temperature threshold
0℃～ 100℃
75℃
☆
0: Fan working during running
P8-48
Cooling fan control
0
☆
1: Fan working continuously
Dormant frequency (P8-51) to maximum
P8-49
Wakeup frequency
0.00Hz
☆
frequency (P0-10)
P8-50
Wakeup delay time
0.0s ～ 6500.0s
0.0s
☆
P8-51
Dormant frequency
0.00 Hz to wakeup frequency (P8-49)
0.00Hz
☆
P8-52
Dormant delay time
0.0s ～ 6500.0s
0.0s
☆
P8-53
Current running time reached
0.0 ～ 6500.0 min
0.0Min
☆
Output power correction
P8-54
0.00% ～ 200.0%
100.0%
☆
coefficient
Brake release current
P8-55
0.00% ～ 200.0%
5.00%
☆
threshold
56
Brake release frequency
P8-56
0.00 to 25.00Hz
0Hz
☆
threshold
Brake release delay ON set
☆
P8-57
0.0 to 5.0s
0.1s
time
P8-58
Brake apply frequency
☆
0.00 to 25.00Hz
0.50Hz
threshold
P8-59
Brake apply delay OFF set
☆
0.0 to 5.0s
0.2s
time
P8-60
☆
Drive run delay ON set time
0.00 to 10.00s
0.2s
P8-61
MC contactor delay OFF set
☆
0.00 to 10.00s
0.2s
time
P8-62
☆
Current threshold in UPS mode
0 to 200
100%
P8-63
Acceleration time in UPS mode
0.0 to 20.0
3s
P8-64
Deceleration time in UPS mode
0.0 to 20.0
3s
P8-65
Brake apply keep frequency set
0.00 to 10.00
0.50s
time
P8-66
Time proportion of S-curve at
0.00% to Min[(100%-P8.67),80%]
20.0%
stop stage start
P8-67
Time proportion of S-curve at
0.00% to Min[(100%-P8.66),80%]
30.0%
stop stage end
P8-68
0: Three phase UPS
UPS input phase mode select
0
1: Single/Two phase UPS
P8-69
Single/Two phase UPS under
60.0 to 140.0
60.0 (210V)
voltage point
Function
Parameter Name
Setting Range
Default
Property
Code
Group P9: Fault and Protection
Motor overload protection
0: Disabled
P9-00
1
☆
selection
1: Enabled
57
P9-01
Motor overload protection gain
0.10 ～ 10.00
1.00
☆
Motor overload warning
P9-02
50% ～ 100%
80%
☆
coefficient
P9-03
Overvoltage stall gain
0 ～ 100
0
☆
Overvoltage stall protective
P9-04
120% ～ 150%
130%
☆
voltage
P9-05
Overcurrent stall gain
0 ～ 100
20
☆
Overcurrent stall protective
P9-06
100% ～ 200%
150%
☆
current
Short-circuit to ground upon
0: Disabled
P9-07
1
☆
power-on
1: Enabled
P9-09
Fault auto reset times
0 ～ 20
0
☆
DO action during fault auto
0: Not act
P9-10
0
☆
reset
1: Act
Time interval of fault auto
P9-11
0.1s ～ 100.0s
1.0s
☆
reset
Input phase loss protection/
Unit's digit: Input phase loss protection
P9-12
contactor energizing
Ten's digit: Contactor energizing protection
11
☆
protection selection
0: Disabled1: Enabled
Output phase loss protection
0: Disabled
P9-13
1
☆
selection
1: Enabled
Function
Parameter Name
Setting Range
Default
Property
Code
P9-14
1st fault type
0: No fault
－
●
P9-15
2nd fault type
1: Reserved
－
●
58
2: Over-current during acceleration
3: Over-current during deceleration
4: Over-current at constant speed
5: Overvoltage during acceleration
6: Overvoltage during deceleration
7: Overvoltage at constant speed
8: Buffer resistance overload
9: Under voltage
10: AC drive overload
11: Motor overload
12: Power input phase loss
13: Power output phase loss
-16
3rd (latest) fault type
14: Module overheat
－
●
15: External equipment fault
16: Communication fault
17: Contactor fault
18: Current detection fault
19: Motor auto-tuning fault
20: Encoder / PG card fault
21: EEPROM read-write fault
22: AC drive hardware fault
23: Short circuit to ground
24: Reserved
25: Reserved
26: Accumulative running time reached
27: User-defined fault 1
59
Function
Parameter Name
Setting Range
Default
Property
Code
－
－
●
P9-17
Frequency upon 3rd fault
P9-18
Current upon 3rd fault
－
－
●
－
－
●
P9-19
Bus voltage upon 3rd fault
－
－
●
P9-20
DI status upon 3rd fault
Output terminal status upon
－
－
●
P9-21
3rd fault
－
－
●
P9-22
AC drive status upon 3rd fault
－
－
●
P9-23
Power-on time upon 3rd fault
－
－
●
P9-24
Running time upon 3rd fault
－
－
●
P9-27
Frequency upon 2nd fault
－
－
●
P9-28
Current upon 2nd fault
P9-29
Bus voltage upon 2nd fault
－
－
●
P9-30
DI status upon 2nd fault
－
－
●
Output terminal status upon
P9-31
－
－
●
2nd fault
P9-32
Frequency upon 2nd fault
－
－
●
P9-33
Current upon 2nd fault
－
－
●
P9-34
Bus voltage upon 2nd fault
－
－
●
P9-37
DI status upon 1st fault
－
－
●
Output terminal status upon
P9-38
－
－
●
1st fault
P9-39
Frequency upon 1st fault
－
－
●
60
Function
Parameter Name
Setting Range
Default
Property
Code
P9-40
Current upon 1st fault
－
－
●
P9-41
Bus voltage upon 3rd fault
－
－
●
P9-42
DI status upon 1st fault
－
－
●
Output terminal status upon
P9-43
－
－
●
1st fault
P9-44
Frequency upon 1st fault
－
－
●
Unit's digit (Motor overload, Err11)
0: Coast to stop
1: Stop according to the stop mode
2: Continue to run
Ten's digit (Power input phase loss, Err12)
Fault protection action
P9-47
00000
☆
selection 1
Hundred's digit (Power output phase loss,
Err13)
Thousand's digit (External equipment fault,
Err15)
Ten thousand's digit (Communication fault,
Err16)
Unit's digit (Encoder fault, Err20)
0: Coast to stop
Ten's digit (EEPROM read-write fault,
Err21)
Fault protection action
0: Coast to stop
P9-48
00000
☆
selection 2
1: Stop according to the stop mode
Hundred's digit: reserved
Thousand's digit (Motor overheat, Err25)
Ten thousand's digit (Accumulative running
time reached)
61
