Oras Electra
6110 Washbasin faucet, 230 V
Touchless washbasin faucet for pre-mixed
Colour: Chrome
water. Fixed electrical connection 230 V.
155
75
Recognition range can be adjusted from
Electrical Connection: 230 VAC
the faucet. The faucet is equipped with a
Pressure loss with flow (0.1 l/s): 170 kPa
litter filter.
Working pressure: 50 - 1000 kPa
ø 28-35
120
25
Flow-rate at 300 kPa (with flow controller):
~230 V
(Pg 11)
0.11 l/s
l = 600
Max. flow period: 2 min (1 - 255 s)
G 3/8
Hot water supply: max. +80°C
EMC Directive: 89/336/EEC
Recognition range: 0 - 40 cm
Protection class: IP 67
Noise class: I (ISO 3822)
Afterflow period: 1 s (0 - 255 s)
.4ADA50-adffce.
6 414150 035524
6114 Washbasin faucet, 230 V
Touchless washbasin faucet with a mixing
Colour: Chrome
155
75
valve. Fixed electrical connection 230 V.
Recognition range can be adjusted at the
Electrical Connection: 230 VAC
faucet. The faucet is equipped with litter
Pressure loss with flow (0.1 l/s): 170 kPa
filters and non-return valves.
ø 28-35
120
Working pressure: 50 - 1000 kPa
~230 V
Flow-rate at 300 kPa (with flow controller):
(Pg 11)
0.11 l/s
Max. flow period: 2 min (1 - 255 s)
l = 600
Hot water supply: max. +80°C
G 3/8
EMC Directive: 89/336/EEC
Recognition range: 0 - 40 cm
Protection class: IP 67
Noise class: I (ISO 3822)
Afterflow period: 1 s (0 - 255 s)
.4ADA50-adffdb.
6 414150 035531
6134 Washbasin faucet, 230/12 V
Touchless washbasin faucet with a
Colour: Chrome
155
75
mixing valve. Plug transformer 230/12 V.
Recognition range can be adjusted at the
Electrical Connection: 230 / 12 VAC
faucet. The faucet is equipped with litter
Pressure loss with flow (0.1 l/s): 170 kPa
filters and non-return valves.
Working pressure: 50 - 1000 kPa
ø 28-35
120
~230 V
Flow-rate at 300 kPa (with flow controller):
(Pg 11)
3, 6 and 9 meters photocell cables
0.11 l/s
available:
Oras No.
Max. flow period: 2 min (1 - 255 s)
l
= 600
6134/3
Hot water supply: max. +80°C
G 3/8
6134/6
EMC Directive: 89/336/EEC
6134/9
Recognition range: 0 - 40 cm
Protection class: IP 67 / transformer IP 40
Noise class: I (ISO 3822)
Afterflow period: 1 s (0 - 255 s)
.4ADA50-achcga.
6 414150 027260
48
Oras Electra
6120F Washbasin faucet, 12 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle (as
factory default). The faucet can be easily
Electrical Connection: 12 VDC
modified for preset temperature or
Pressure loss with flow (0.1 l/s): 200 kPa
premixed water. The faucet is equipped
Working pressure: 100 - 1000 kPa
ø 34 -37
with litter filters, non-return valves and
96
Flow-rate at 300 kPa (with flow controller):
flexible pipes.
0.1 l/s
No adjustments are needed at installation
Max. flow period: 2 min
because an advanced Autofocus sensor
Hot water supply: max. +70°C
is used. Flow controller (6 l/min) enables
Sensor cable: 0.5 m
G 3/8
low water consumption (0.5 l / instance
Intelligent afterflow period: 2 s ± 1 s
of use).
EMC Directive: 2004/108/EY
Recognition range: optimally preset
Electrical connection 12 V via a separate
Protection class: IP 55
power supply (e.g. Oras No. 199275).
Noise class: I (ISO 3822)
EN standard: EN 15091
.4ADA50-afihid.
6 414150 058783
6120FT Washbasin faucet, 230/12 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle (as
factory default). The faucet can be easily
Electrical Connection: 12 VDC
modified for preset temperature or
Pressure loss with flow (0.1 l/s): 200 kPa
premixed water. The faucet is equipped
Working pressure: 100 - 1000 kPa
with litter filters, non-return valves and
ø 34 -37
96
Flow-rate at 300 kPa (with flow controller):
flexible pipes. Electrical connection with a
0.1 l/s
plug transformer 230/12 V.
Max. flow period: 2 min
Alternative: concealed power supply
Hot water supply: max. +70°C
199275. A maximum five of these items
Intelligent afterflow period: 2 s ± 1 s
can be connected to the power supply at
EMC Directive: 2004/108/EY
G 3/8
a time.
Recognition range: optimally preset
Protection class: IP 55 / transformer IP 40
No adjustments are needed at installation
Noise class: I (ISO 3822)
because an advanced Autofocus sensor
is used. Flow controller (6 l/min) enables
low water consumption (0.5 l / instance
of use).
.4ADA50-ahgaai.
6 414150 076008
6121F Washbasin faucet, 12 V
155
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. The
faucet is equipped with litter filters,
Electrical Connection: 12 VDC
non-return valves and flexible pipes. No
Pressure loss with flow (0.1 l/s): 200 kPa
adjustments are needed at installation
110
Working pressure: 100 - 1000 kPa
because an advanced Autofocus sensor
ø 34 -37
Flow-rate at 300 kPa (with flow controller):
is used. Flow controller (6 l/min) enables
0.1 l/s
low water consumption (0.5 l / instance
of use).
Max. flow period: 2 min
Hot water supply: max. +70°C
Electrical connection 12 V via a separate
Intelligent afterflow period: 2 s ± 1 s
power supply (e.g. Oras No. 199275).
EMC Directive: 2014/30/EU
G 3/8
Recognition range: optimally preset
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO 3822)
.4ADA50-aiajfb.
6 414150 080951
49
Oras Electra
6125F Washbasin faucet, 12 V
168
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. The
faucet is equipped with litter filters,
Electrical Connection: 12 VDC
non-return valves and flexible pipes. No
Pressure loss with flow (0.1 l/s): 200 kPa
adjustments are needed at installation
126
Working pressure: 100 - 1000 kPa
because an advanced Autofocus sensor
ø 34 -37
Flow-rate at 300 kPa (with flow controller):
is used. Flow controller (6 l/min) enables
0.1 l/s
low water consumption (0.5 l / instance
of use).
Max. flow period: 2 min
Hot water supply: max. +70°C
Electrical connection 12 V via a separate
Intelligent afterflow period: 2 s ± 1 s
power supply (e.g. Oras No. 199275).
EMC Directive: 2014/30/EU
G 3/8
Recognition range: optimally preset
Protection class: IP 55 / transformer IP 40
Noise class: I(ISO 3822)
.4ADA50-aiajgi.
6 414150 080968
6222F Washbasin faucet, 12 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle (as
factory default). The faucet can be
Electrical Connection: 12 VDC
easily modified for preset temperature
Pressure loss with flow (0.1 l/s): 200 kPa
or premixed water. The faucet can be
Working pressure: 100 - 1000 kPa
taken out of operation, e.g. for cleaning
ø 34 - 37
Flow-rate at 300 kPa (with flow controller):
115
the basin, by placing a cleaning cover
0.1 l/s
over the sensor. The faucet is equipped
with litter filters, non-return valves and
Max. flow period: 2 min
flexible pipes. No adjustments need to be
Hot water supply: max. +70°C
made at installation because an advanced
Sensor cable: 0.5 m
Autofocus sensor is used. Flow controller
Intelligent afterflow period: 2 s ± 1 s
G 3/8
(6 l/min.) enables low water consumption
Min. current consumption: 0 A
(0.5 l / instance of use).
EMC Directive: 2004/108/EY
Recognition range: optimally preset
Electrical connection 12 V via a separate
Protection class: IP 55
power supply (e.g. Oras No. 199275).
Noise class: I (ISO 3822)
.4ADA50-agfhji.
6 414150 065798
6222FZ Washbasin faucet, 9/12 V, Bluetooth
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle (as
factory default). The faucet can be
Electrical Connection: 9 / 12 VDC
easily modified for preset temperature
Working pressure: 100 - 1000 kPa
or premixed water. The faucet can be
Max. flow period: 2 min
taken out of operation, e.g. for cleaning
ø 34 - 37
Hot water supply: max. +70°C
115
the basin, by placing a cleaning cover
Intelligent afterflow period: 2 s ± 1 s
over the sensor. The faucet is equipped
with litter filters, non-return valves and
EMC Directive: 2014/30/EU
flexible pipes. No adjustments need to be
Recognition range: optimally preset
made at installation because an advanced
Protection class: IP 55
Autofocus sensor is used. Bluetooth
G 3/8
connection enables easy monitoring and
adjustments of the faucet. Flow controller
(6 l/min.) enables low water consumption
(0.5 l / instance of use).
Electrical connection 9 V or 12 V via a
separate power supply (e.g. Oras No.
199275).
.4ADA50-aifihb.
6 414150 085871
The Bluetooth® trademark and logos are property of Bluetooth SIG, Inc.,
and their usage is licensend for Orasgroup. Other brands and trade names
are property of the respective owners.
50
Oras Electra
6221FZ Washbasin faucet, low pressure, 12 V, Bluetooth
ø60
166
Low pressure model. Touchless washbasin
Colour: Chrome
faucet with a temperature adjustment
handle. The faucet can be taken out of
Electrical Connection: 9 / 12 VDC
operation, e.g. for cleaning the basin,
Working pressure: 100 - 1000 kPa
ø33.5
by placing a cleaning cover over the
Max. flow period: 2 min
sensor. The faucet is equipped with litter
Hot water supply: max. +70°C
filters, non-return valves and flexible
pipes. No adjustments need to be made
Intelligent afterflow period: 2 s ± 1 s
115
at installation because an advanced
EMC Directive: 2014/30/EU
Autofocus sensor is used. Bluetooth
Recognition range: optimally preset
G 3/8
connection enables easy monitoring and
Protection class: IP 55
adjustments of the faucet.
G 3/8
Electrical connection 9 V or 12 V via a
separate power supply (e.g. Oras No.
199275).
.4ADA50-aifiii.
6 414150 085888
6334FT Washbasin faucet, 230/12 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. Length
of spout 120 mm. The faucet is equipped
Electrical Connection: 230 / 12 V
with litter filters, non-return valves
Pressure loss with flow (0.1 l/s): 200 kPa
and Autofocus sensor which enables
Working pressure: 100 - 1000 kPa
installation without adjustments. The
Flow-rate at 300 kPa (with flow controller):
adjustment values can be changed
0.1 l/s
120
according to the conditions in the place
ø 34 -37
Max. flow period: 2 min
of use with pre-programmed parameters.
Flow controller (6 l/min) enables low
Hot water supply: max. +70°C
water consumption. Electrical connection
Intelligent afterflow period: 2 s ± 1 s
with a plug transformer 230/12 V.
EMC Directive: 2004/108/EY
G 3/8
Recognition range: optimally preset
Alternative: concealed power supply
Protection class: IP 55 / transformer IP 40
199275. A maximum five of these items
Noise class: I (ISO 3822)
can be connected to the power supply at
a time.
.4ADA50-ahgedf.
6 414150 076435
6335FT Washbasin faucet, 230/12 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. Length
of spout 170 mm. The faucet is equipped
Electrical Connection: 230 / 12 V
with litter filters, non-return valves
Pressure loss with flow (0.1 l/s): 200 kPa
and Autofocus sensor which enables
Working pressure: 100 - 1000 kPa
installation without adjustments. The
Flow-rate at 300 kPa (with flow controller):
adjustment values can be changed
0.1 l/s
170
according to the conditions in the place
ø 34 -37
Max. flow period: 2 min
of use with pre-programmed parameters.
Flow controller (6 l/min) enables low
Hot water supply: max. +70°C
water consumption. Electrical connection
Intelligent afterflow period: 2 s ± 1 s
with a plug transformer 230/12 V.
EMC Directive: 2004/108/EY
G 3/8
Recognition range: optimally preset
Alternative: concealed power supply
Protection class: IP 55 / transformer IP 40
199275. A maximum five of these items
Noise class: I (ISO 3822)
can be connected to the power supply at
a time.
.4ADA50-ahgfde.
6 414150 076534
The Bluetooth® trademark and logos are property of Bluetooth SIG,
Inc., and their usage is licensend for Orasgroup. Other brands and trade
names are property of the respective owners.
51
Oras Electra
6336FT Washbasin faucet, 230/12 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle and
Bidetta hand shower. Lenght of spout 120
Electrical Connection: 230 / 12 V
mm. The faucet is equipped with litter
Pressure loss with flow (0.1 l/s): 200 kPa
filters, non-return valves and Autofocus
Working pressure: 100 - 1000 kPa
sensor which enables installation without
Flow-rate at 300 kPa (with flow controller):
adjustments. The adjustment values can
0.1 l/s
120
be changed according to the conditions
ø 34 -37
Max. flow period: 2 min
in the place of use with pre-programmed
parameters. Flow controller (6 l/min)
Hot water supply: max. +70°C
G 1/2
enables low water consumption. Electrical
Intelligent afterflow period: 2 s ± 1 s
connection with a plug transformer
EMC Directive: 2004/108/EY
G 3/8
230/12 V.
Recognition range: optimally preset
Protection class: IP 55 / transformer IP 40
Alternative: concealed power supply
Noise class: I (ISO 3822)
199275. A maximum five of these items
can be connected to the power supply at
a time.
.4ADA50-ahgeec.
6 414150 076442
6337FT Washbasin faucet, 230/12 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle and
Bidetta hand shower. Lenght of spout 170
Electrical Connection: 230 / 12 V
mm. The faucet is equipped with litter
Pressure loss with flow (0.1 l/s): 200 kPa
filters, non-return valves and Autofocus
Working pressure: 100 - 1000 kPa
sensor which enables installation without
Flow-rate at 300 kPa (with flow controller):
adjustments. The adjustment values can
0.1 l/s
170
be changed according to the conditions
ø 34 -37
in the place of use with pre-programmed
Max. flow period: 2 min
parameters. Flow controller (6 l/min)
Hot water supply: max. +70°C
G 1/2
enables low water consumption. Electrical
Intelligent afterflow period: 2 s ± 1 s
connection with a plug transformer
EMC Directive: 2004/108/EY
G 3/8
230/12 V.
Recognition range: optimally preset
Protection class: IP 55 / transformer IP 40
Alternative: concealed power supply
Noise class: I (ISO 3822)
199275. A maximum five of these items
can be connected to the power supply at
a time.
.4ADA50-ahgefj.
6 414150 076459
6330F Washbasin faucet, 6 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. Battery-
operated 6 V. Length of spout 120 mm.
Pressure loss with flow (0.1 l/s): 200 kPa
The faucet is equipped with litter filters,
Working pressure: 100 - 1000 kPa
non-return valves and Autofocus sensor
Flow-rate at 300 kPa (with flow controller):
which enables installation without
0.1 l/s
adjustments. The adjustment values can
120
Max. flow period: 2 min
ø 34 -37
be changed according to the conditions
in the place of use with pre-programmed
Hot water supply: max. +70°C
parameters. The impulse-controlled
Intelligent afterflow period: 2 s ± 1 s
solenoid valve gives the battery a long
EMC Directive: 2004/108/EY
G 3/8
operating life. Flow controller (6 l/min)
Recognition range: optimally preset
enables low water consumption.
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-agffid.
6 414150 065583
52
Oras Electra
6331F Washbasin faucet, 6 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. Battery-
operated 6 V. Length of spout 170 mm.
Pressure loss with flow (0.1 l/s): 200 kPa
The faucet is equipped with litter filters,
Working pressure: 100 - 1000 kPa
non-return valves and Autofocus sensor
Flow-rate at 300 kPa (with flow controller):
which enables installation without
0.1 l/s
adjustments. The adjustment values can
170
Max. flow period: 2 min
ø 34 -37
be changed according to the conditions
in the place of use with pre-programmed
Hot water supply: max. +70°C
parameters. The impulse-controlled
Intelligent afterflow period: 2 s ± 1 s
solenoid valve gives the battery a long
EMC Directive: 2004/108/EY
G 3/8
operating life. Flow controller (6 l/min)
Recognition range: optimally preset
enables low water consumption.
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-agffja.
6 414150 065590
6332F Washbasin faucet, 6 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle and
Bidetta hand shower. Lenght of spout 120
Pressure loss with flow (0.1 l/s): 200 kPa
mm. The faucet is equipped with litter
Working pressure: 100 - 1000 kPa
filters, non-return valves and Autofocus
Flow-rate at 300 kPa (with flow controller):
sensor which enables installation without
0.1 l/s
adjustments. The adjustment values can
120
Max. flow period: 2 min
ø 34 -37
be changed according to the conditions
in the place of use with pre-programmed
Hot water supply: max. +70°C
G 1/2
parameters. The impulse-controlled
Intelligent afterflow period: 2 s ± 1 s
solenoid valve gives the battery a long
EMC Directive: 2004/108/EY
G 3/8
operating life. Flow controller (6 l/min)
Recognition range: optimally preset
enables low water consumption.
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-agfghf.
6 414150 065675
6333F Washbasin faucet, 6 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle and
Bidetta hand shower. Lenght of spout 170
Pressure loss with flow (0.1 l/s): 200 kPa
mm. The faucet is equipped with litter
Working pressure: 100 - 1000 kPa
filters, non-return valves and Autofocus
Flow-rate at 300 kPa (with flow controller):
sensor which enables installation without
0.1 l/s
adjustments. The adjustment values can
Max. flow period: 2 min
170
be changed according to the conditions
ø 34 -37
Hot water supply: max. +70°C
in the place of use with pre-programmed
parameters. The impulse-controlled
Intelligent afterflow period: 2 s ± 1 s
G 1/2
solenoid valve gives the battery a long
EMC Directive: 2004/108/EY
operating life. Flow controller (6 l/min)
Recognition range: optimally preset
G 3/8
enables low water consumption.
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-agfgfb.
6 414150 065651
53
Oras Electra
6150F Washbasin faucet, 6 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle (as
factory default). The faucet can be easily
Pressure loss with flow (0.1 l/s): 200 kPa
modified for preset temperature or
Working pressure: 100 - 1000 kPa
premixed water. Battery-operated 6 V. The
Flow-rate at 300 kPa (with flow controller):
ø 34 -37
96
faucet is equipped with litter filters, non-
0.1 l/s
return valves and flexible pipes.
Max. flow period: 2 min
No adjustments need to be made
Hot water supply: max. +70°C
at installation because an advanced
Intelligent afterflow period: 2 s ± 1 s
Autofocus sensor is used. The impulse-
EMC Directive: 89/336/EEC
G 3/8
controlled solenoid valve gives the battery
Recognition range: optimally preset
a long operating life. Flow controller
Protection class: IP 55
(6 l/min.) enables low water consumption
Noise class: I (ISO 3822)
(0.5 l / instance of use).
Battery: Lithium 2CR5 6 V
.4ADA50-afbcad.
6 414150 051203
6151F Washbasin faucet, 6 V
155
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. Battery-
operated 6 V. The faucet is equipped with
Pressure loss with flow (0.1 l/s): 200 kPa
litter filters, non-return valves and flexible
Working pressure: 100 - 1000 kPa
pipes.
110
Flow-rate at 300 kPa (with flow controller):
No adjustments need to be made
ø 34 -37
0.1 l/s
at installation because an advanced
Max. flow period: 2 min
Autofocus sensor is used. The impulse-
controlled solenoid valve gives the battery
Hot water supply: max. +70°C
a long operating life. Flow controller (6 l/
Intelligent afterflow period: 2 s ± 1 s
min.) enables low water consumption (0.5
EMC Directive: 2014/30/EU
G 3/8
l / instance of use).
Recognition range: optimally preset
Protection class: IP 55
Noise class: I(ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-ahjhcg.
6 414150 079726
6155F Washbasin faucet, 6 V
168
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. Battery-
operated 6 V. The faucet is equipped with
Pressure loss with flow (0.1 l/s): 200 kPa
litter filters, non-return valves and flexible
Working pressure: 100 - 1000 kPa
pipes.
126
Flow-rate at 300 kPa (with flow controller):
No adjustments need to be made
ø 34 -37
0.1 l/s
at installation because an advanced
Max. flow period: 2 min
Autofocus sensor is used. The impulse-
controlled solenoid valve gives the battery
Hot water supply: max. +70°C
a long operating life. Flow controller (6 l/
Intelligent afterflow period: 2 s ± 1 s
min.) enables low water consumption (0.5
EMC Directive: 2014/30/EU
l / instance of use).
Recognition range: optimally preset
G 3/8
Protection class: IP 55
Noise class: I(ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-ahjhea.
6 414150 079740
54
Oras Electra
6250F Washbasin faucet, 6 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle (as
factory default). The faucet can be easily
Pressure loss with flow (0.1 l/s): 200 kPa
modified for preset temperature or
Working pressure: 100 - 1000 kPa
premixed water. Battery-operated 6 V.
Flow-rate at 300 kPa (with flow controller):
The faucet can be taken out of operation,
ø 34 - 37
0.1 l/s
115
e.g. for cleaning the basin, by placing a
Max. flow period: 2 min
cleaning cover over the sensor. The faucet
is equipped with litter filters, non-return
Hot water supply: max. +70°C
valves and flexible pipes. No adjustments
Intelligent afterflow period: 2 s ± 1 s
need to be made at installation because
EMC Directive: 2004/108/EY
an advanced Autofocus sensor is used.
Recognition range: optimally preset
G 3/8
The impulse-controlled solenoid valve
Protection class: IP 55
gives the battery a long operating life.
Noise class: I (ISO 3822)
Flow controller (6 l/min.) enables low
Battery: Lithium 2CR5 6 V
water consumption (0.5 l / instance of
use).
.4ADA50-aecbea.
6 414150 042140
6250FZ Washbasin faucet, 6 V, Bluetooth
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle (as
factory default). The faucet can be easily
Working pressure: 100 - 1000 kPa
modified for preset temperature or
Max. flow period: 2 min
premixed water. Battery-operated 6 V.
Hot water supply: max. +70°C
The faucet can be taken out of operation,
ø 34 - 37
Intelligent afterflow period: 2 s ± 1 s
115
e.g. for cleaning the basin, by placing a
EMC Directive: 2014/30/EU
cleaning cover over the sensor. The faucet
is equipped with litter filters, non-return
Recognition range: optimally preset
valves and flexible pipes. No adjustments
Protection class: IP 55
need to be made at installation because
Battery: Lithium 2CR5 6 V
an advanced Autofocus sensor is used.
G 3/8
Bluetooth connection enables easy
monitoring and adjustments of the faucet.
The impulse-controlled solenoid valve
gives the battery a long operating life.
Flow controller (6 l/min.) enables low
water consumption (0.5 l/instance of use).
.4ADA50-aifige.
6 414150 085864
6159F Washbasin faucet, 6 V
Compact touchless washbasin faucet with
Colour: Chrome
one inlet pipe for premixed or cold water.
Battery-operated. The faucet is equipped
Working pressure: 100 - 1000 kPa
with litter filters and flexible pipes.
Flow-rate at 300 kPa (with flow controller):
0.09 l/s
No adjustments are needed at installation
ø 34 -37
96
Max. flow period: 2 min
because an advanced Autofocus sensor is
Hot water supply: max. +70°C
used. The impulse-controlled pilot valve
gives the battery a long operating life.
Intelligent afterflow period: 2 s ± 1 s
EMC Directive: 2004/108/EY
Recognition range: optimally preset
Protection class: IP 55
G 3/8
Noise class: I (ISO 3822) Oras lab.
Battery: Lithium 2CR5 6 V
.4ADA50-ahfbig.
6 414150 075186
The Bluetooth® trademark and logos are property of Bluetooth SIG,
Inc., and their usage is licensend for Orasgroup. Other brands and trade
names are property of the respective owners.
55
Oras Electra
6188 Washbasin faucet, 3 V
Touchless washbasin faucet for cold or
Colour: Chrome
pre-mixed water. Battery-operated 3 V.
Spout length 175 mm. laminar flow. The
Pressure loss with flow (0.1 l/s): 200 kPa
faucet is equipped with litter filter, non-
Working pressure: 100 - 1000 kPa
return valve, shut-off valve and with G1/2”
Flow-rate at 300 kPa (with flow controller):
external connection thread.
0.1 l/s
Max. flow period: 120 s (10/30/60/120/300 s)
Hot water supply: max. +70°C
30
175
Automatic flush period: 30 s
203
(10/30/60/120/180/240/300/600 s)
Intelligent afterflow period: 2 s ± 1 s (1/2/3/4/8
s)
EMC Directive: 2014/30/EU
Recognition range: ~15 cm (~10/15/17/20 cm)
Protection class: IP 55
Noise class: I (ISO 3822) Oras lab.
Battery: AA 1.5 V Lithium x 2
Automatic flush: off (off/12/24/48/72 h)
.4ADA50-ahfbei.
6 414150 075148
6189 Washbasin faucet, 3 V
Touchless washbasin faucet for cold or
Colour: Chrome
pre-mixed water. Battery-operated 3 V.
Spout length 225 mm. laminar flow. The
Pressure loss with flow (0.1 l/s): 200 kPa
faucet is equipped with litter filter, non-
Working pressure: 100 - 1000 kPa
return valve, shut-off valve and with G1/2”
Flow-rate at 300 kPa (with flow controller):
external connection thread.
0.1 l/s
Max. flow period: 120 s (10/30/60/120/300 s)
Hot water supply: max. +70°C
30
225
Automatic flush period: 30 s
253
(10/30/60/120/180/240/300/600 s)
Intelligent afterflow period: 2 s ± 1 s (1/2/3/4/8
s)
EMC Directive: 2014/30/EU
Recognition range: ~15 cm (~10/15/17/20 cm)
Protection class: IP 55
Battery: AA 1.5 V Lithium x 2
Automatic flush: off (off/12/24/48/72 h)
.4ADA50-ahfbff.
6 414150 075155
6172 Washbasin faucet, 6 V
Touchless washbasin faucet with a
Colour: Chrome
swivel spout, aerator with a 6 l/min flow
150±3
controller and temperature adjustment
Pressure loss with flow (0.1 l/s): 200 kPa
knob. Battery-operated 6 V. The
Working pressure: 100 - 1000 kPa
temperature adjustment handle is
Flow-rate at 300 kPa (with flow controller):
equipped with a temperature limiter
0.1 l/s
which can be bypassed by pushing a
Max. flow period: 2 min
button. The faucet is equipped with litter
filters and non-return valves.
Hot water supply: max. +70°C
50
100
Opening range: 0 - 5 cm
Intelligent afterflow period: 3 s ± 2 s
EMC Directive: 89/336/EEC
Recognition range: 40 cm (40 / 50 cm)
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-agaeba.
6 414150 060410
56
Oras Electra
6179 Washbasin faucet, 6 V
Touchless washbasin faucet with
Colour: Chrome
a swivel spout, aerator with a 6 l/
150±3
min flow controller and temperature
Pressure loss with flow (0.1 l/s): 200 kPa
adjustment knob. Battery-operated 6
Working pressure: 100 - 1000 kPa
V. The temperature adjustment handle
Flow-rate at 300 kPa (with flow controller):
is equipped with a temperature limiter
0.1 l/s
which can be bypassed by pushing a
Max. flow period: 2 min
button. The faucet is equipped with litter
filters and non-return valves.
Hot water supply: max. +70°C
50
200
Opening range: 0 - 5 cm
Intelligent afterflow period: 3 s ± 2 s
EMC Directive: 89/336/EEC
Recognition range: 40 cm (40 / 50 cm)
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-afceie.
6 414150 052484
6567 Urinal flusher, 6 V
81
60
Touchless urinal flusher with a concealed
Colour: Chrome
inlet pipe. Battery-operated 6 V. The
device is equipped with a shut-off valve,
Pressure loss with flow (0.2 l/s): 40 kPa
a litter filter and a flusher pipe with a
Working pressure: 50 - 1000 kPa
cable gland. The adjustment values can
Flow-rate at 300 kPa: 0.56 l/s
be changed according to the conditions
Hot water supply: max. +70°C
in the place of use with pre-programmed
EMC Directive: 89/336/EEC
parameters.
50
Recognition range: 40 cm (30 / 40 cm)
Protection class: IP 55
Pre-flush period: 2 s ON (ON / OFF)
Battery: Lithium 2CR5 6 V
Automatic flush: 24 h ON (ON / OFF)
Afterflush period: 6 s (3 / 6 / 10 s)
.4ADA50-aeadfb.
6 414150 040351
6568 Urinal flusher, 6 V
60
Touchless urinal flusher with a visible
Colour: Chrome
inlet pipe. Battery-operated 6 V. The
device is equipped with a litter filter, and
Pressure loss with flow (0.2 l/s): 40 kPa
has a flusher pipe with a cable gland.
Working pressure: 50 - 1000 kPa
The adjustment values can be changed
Flow-rate at 300 kPa: 0.58 l/s
according to the conditions in the place
Hot water supply: max. +70°C
of use with pre-programmed parameters.
EMC Directive: 89/336/EEC
30
Recognition range: 40 cm (30 / 40 cm)
Protection class: IP 55
25
Pre-flush period: 2 s ON (ON / OFF)
Battery: Lithium 2CR5 6 V
Automatic flush: 24 h ON (ON / OFF)
Afterflush period: 6 s (3 / 6 / 10 s)
.4ADA50-aebcec.
6 414150 041242
57
Oras Electra
6575 Flusher for urinal channel, 230 V
75
Touchless urinal flusher with an infrared
sensor. Fixed electrical connection 230
Electrical Connection: 230 VAC
155
25
V. When a person enters the recognition
Pressure loss with flow (0.2 l/s): 140 kPa
range, the infrared sensor reacts and the
Working pressure: 150 - 1000 kPa
flushing will start after a preset period.
Flow-rate at 300 kPa (with flow controller):
Flow-rate limitation at 0.2 l/s can be
0.2 l/s
removed to increase the flow-rate. The
Hot water supply: max. +70°C
faucet is equipped with a litter filter.
Sensor cable: 6 m
EMC Directive: 89/336/EEC
~230 V
Recognition range: max. 15 m
(Pg 11)
Protection class: IP 67 / transformer IP 40
Flush period: 10 s (1 - 30 s)
Flush delay: 60 s (0 - 255 s)
Automatic flush: 24 h (0 - 255 h)
.4ADA50-adjhbd.
6 414150 039713
6180 Shower faucet, 6 V
Touchless shower faucet that reacts
Colour: Chrome
quickly and precisely to the changes
150±3
of water pressure and keeps the water
Pressure loss with flow (0.2 l/s): 300 kPa
temperature as selected. Suited to
Working pressure: 100 - 1000 kPa
places where there are several water
Flow-rate at 300 kPa: 0.2 l/s
outlets and the network always contains
Max. flow period: 5 min
plenty of hot water. Battery-operated 6
Hot water supply: max. +70°C
V. The temperature adjustment handle
is equipped with a temperature limiter
Opening range: 0 - 5 cm
G 3/4
50
which can be bypassed by pushing a
EMC Directive: 89/336/EEC
button. The faucet is equipped with litter
Recognition range: 60 cm (50 / 60 cm)
filters and non-return valves.
Protection class: IP 55
Noise class: II (ISO 3822) Oras lab.
Not recommended for a one-family
Battery: Lithium 2CR5 6 V
house.
Afterflow period: 5 s
.4ADA50-afcejb.
6 414150 052491
6195 Shower faucet, 6 V
Touchless shower faucet that reacts
Colour: Chrome
quickly and precisely to the changes
150±3
of water pressure and keeps the water
Pressure loss with flow (0.2 l/s): 300 kPa
temperature as selected. Suited to
Working pressure: 100 - 1000 kPa
places where there are several water
Flow-rate at 300 kPa: 0.2 l/s
outlets and the network always contains
Max. flow period: 5 min
plenty of hot water. Battery-operated 6
Hot water supply: max. +70°C
V. The temperature adjustment handle
is equipped with a temperature limiter
Opening range: 0 - 5 cm
G 3/4
50
which can be bypassed by pushing a
EMC Directive: 89/336/EEC
button.
Recognition range: 60 cm (60 / 50 cm)
Protection class: IP 55
Not recommended for a one-family
Noise class: II (ISO 3822) Oras lab.
house.
Battery: Lithium 2CR5 6 V
Afterflow period: 5 s
.4ADA50-afidcf.
6 414150 058325
58
Oras Electra
6661F Shower panel, 6 V
Touchless shower panel for pre-mixed
Colour: Aluminum/Chrome
water. Battery-operated 6 V. The shower is
switched on by placing a hand in front of
Pressure loss 0.2 l/s (without flow controller):
the sensor within the recognition range.
250 kPa
Water will flow for as long as the person
Working pressure: 100 - 1000 kPa
is standing under the shower. When the
Flow-rate at 300 kPa (with flow controller):
user exits the recognition range the water
0.195 l/s
flow will stop automatically. The shower
Flow-rate at 300 kPa: 0.22 l/s
panel is equipped with a litter filter and a
Max. flow period: 5 min
flow limiter.
Hot water supply: max. +70°C
The following accessories are sold
Opening range: 0 - 5 cm
separately: soap holder (Oras No. 199880)
EMC Directive: 89/336/EEC
and grab bar (Oras No. 199881).
Recognition range: 60 cm (50 / 60 cm)
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
Afterflow period: 5 s
.4ADA50-aehdbc.
6 414150 047312
6661FTW Shower panel, 12 V
257
Touchless shower panel for pre-mixed
Colour: Aluminum/Chrome
150
water. Electrical connection 12V via a
separate transformer Oras 199275 (max
Electrical Connection: 12 VDC
4 shower panels to one transformer).
Pressure loss 0.2 l/s (without flow controller):
The shower is switched on by placing
250 kPa
a hand in front of the sensor within the
Working pressure: 100 - 1000 kPa
recognition range. Water will flow for
Flow-rate at 300 kPa (with flow controller):
as long as the person is standing under
0.195 l/s
the shower. When the user exits the
Flow-rate at 300 kPa: 0.22 l/s
recognition range the water flow will
stop automatically. The shower panel is
Max. flow period: 5 min
equipped with litter filters, non-return
Hot water supply: max. +70°C
150
valves, flow limiter and 10m power cable
Opening range: 0 - 5 cm
for transformer. Parameters are changed
EMC Directive: 89/336/EEC
with a magnetic key included in the
Recognition range: 60 cm (50 / 60 cm)
package. The following accessories are
Protection class: IP 55
sold separately: soap holder (Oras No.
Noise class: I (ISO 3822)
199880) and grab bar (Oras No. 199881).
Afterflow period: 5 s
.4ADA50-ahhegd.
6 414150 077463
6661FTX Shower panel, 12 V
Touchless shower panel for pre-mixed
Colour: Aluminum/Chrome
257
150
water. Electrical connection 12 V via
a separate bus transformer (Oras No.
Electrical Connection: 12 VDC
199501 or 199502). The shower is
Pressure loss 0.2 l/s (without flow controller):
switched on by placing a hand in front of
250 kPa
the sensor within the recognition range.
Working pressure: 100 - 1000 kPa
Water will flow for as long as the person
Flow-rate at 300 kPa (with flow controller):
is standing under the shower. When the
0.195 l/s
user exits the recognition range the water
Flow-rate at 300 kPa: 0.22 l/s
flow will stop automatically. The shower
panel is equipped with a litter filter and a
Max. flow period: 5 min
flow limiter.
Hot water supply: max. +70°C
150
Opening range: 0 - 5 cm
The following accessories are sold
EMC Directive: 2004/108/EY
separately: soap holder (Oras No. 199880)
Recognition range: 60 cm (50 / 60 cm)
and grab bar (Oras No. 199881).
Protection class: IP 55
Noise class: I (ISO 3822)
Afterflow period: 5 s
.4ADA50-ahcjcf.
6 414150 072925
59
Oras Electra
6662F Shower panel, 6 V
257
150
Touchless thermostatic shower panel
Colour: Aluminum/Chrome
with hand shower and a temperature
adjustment handle. Battery-operated 6 V.
Working pressure: 100 - 1000 kPa
The shower is switched on by placing
Flow-rate at 300 kPa (with flow controller):
a hand in front of the sensor within the
0.17 l/s
recognition range. Water will flow for
Flow-rate at 300 kPa: 0.18 l/s
as long as the person is standing under
Max. flow period: 5 min
the shower. When the user exits the
recognition range the water flow will
Hot water supply: max. +70°C
stop automatically. The shower panel is
Opening range: 0 - 5 cm
equipped with litter filters, non-return
EMC Directive: 89/336/EEC
valves and a flow limiter.
Recognition range: 60 cm (50 / 60 cm)
150
Protection class: IP 55
The following accessories are sold
Noise class: I (ISO 3822)
separately: soap holder (Oras No. 199880)
Battery: Lithium 2CR5 6 V
and grab bar (Oras No. 199881).
Afterflow period: 5 s
.4ADA50-aehdaf.
6 414150 047305
6662FTW Shower panel, 12 V
257
Touchless thermostatic shower panel
Colour: Aluminum/Chrome
150
with hand shower and a temperature
adjustment handle. Electrical connection
Electrical Connection: 12 VDC
12 V via a separate transformer Oras
Working pressure: 100 - 1000 kPa
199275 (max 4 shower panels to one
Flow-rate at 300 kPa (with flow controller):
transformer). The shower is switched on
0.17 l/s
by placing a hand in front of the sensor
Flow-rate at 300 kPa: 0.18 l/s
within the recognition range. Water will
flow for as long as the person is standing
Max. flow period: 5 min
under the shower. When the user exits
Hot water supply: max. +70°C
the recognition range the water flow will
Opening range: 0 - 5 cm
150
stop automatically. The shower panel is
EMC Directive: 2004/108/EY
equipped with litter filters, non-return
Recognition range: 60 cm (50 / 60 cm)
valves, flow limiter and 10m power cable
Protection class: IP 55
for transformer. Parameters are changed
Noise class: I (ISO 3822)
with a magnetic key included in the
Afterflow period: 5 s
package.
The following accessories are sold
separately: soap holder (Oras No. 199880)
& grab bar (Oras No. 199881).
.4ADA50-ahheha.
6 414150 077470
6662FTX Shower panel, 12 V
Touchless thermostatic shower panel
Colour: Aluminum/Chrome
257
150
with hand shower and a temperature
adjustment handle. Electrical connection
Electrical Connection: 12 VDC
12 V via a separate bus transformer
Working pressure: 100 - 1000 kPa
(Oras No. 199501 or 199502). The
Flow-rate at 300 kPa (with flow controller):
shower is switched on by placing a
0.17 l/s
hand in front of the sensor within the
Flow-rate at 300 kPa: 0.18 l/s
recognition range. Water will flow for
as long as the person is standing under
Max. flow period: 5 min
the shower. When the user exits the
Hot water supply: max. +70°C
recognition range the water flow will
Opening range: 0 - 5 cm
150
stop automatically. The shower panel is
EMC Directive: 2004/108/EY
equipped with litter filters, non-return
Recognition range: 60 cm (50 / 60 cm)
valves and a flow limiter.
Protection class: IP 55
Noise class: I (ISO 3822)
The following accessories are sold
Afterflow period: 5 s
separately: soap holder (Oras No. 199880)
& grab bar (Oras No. 199881).
.4ADA50-ahcjdc.
6 414150 072932
60
Oras Electra
6664F Shower panel, 6 V
Touchless thermostatic shower panel
Colour: Aluminum/Chrome
with a temperature adjustment handle.
Battery-operated 6 V. The shower is
Working pressure: 100 - 1000 kPa
switched on by placing a hand in front of
Flow-rate at 300 kPa (with flow controller):
the sensor within the recognition range.
0.18 l/s
Water will flow for as long as the person is
Flow-rate at 300 kPa: 0.195 l/s
standing under the shower. When the user
Max. flow period: 5 min
exits the recognition range the water flow
will stop automatically. The shower panel
Hot water supply: max. +70°C
is equipped with litter filters, non-return
Opening range: 0 - 5 cm
valves and a flow limiter.
EMC Directive: 89/336/EEC
Recognition range: 60 cm (50 / 60 cm)
The following accessories are sold
Protection class: IP 55
separately: soap holder (Oras No. 199880)
Noise class: I (ISO 3822)
& grab bar (Oras No. 199881).
Battery: Lithium 2CR5 6 V
Afterflow period: 5 s
.4ADA50-aehdcj.
6 414150 047329
6664FTW Shower panel, 12 V
257
Touchless thermostatic shower panel
Colour: Aluminum/Chrome
150
with a temperature adjustment handle.
Electrical connection 12V via a separate
Electrical Connection: 12 VDC
transformer Oras 199275 (max 4 shower
Working pressure: 100 - 1000 kPa
panels to one transformer). The shower is
Flow-rate at 300 kPa (with flow controller):
switched on by placing a hand in front of
0.18 l/s
the sensor within the recognition range.
Flow-rate at 300 kPa: 0.195 l/s
Water will flow for as long as the person
is standing under the shower. When the
Max. flow period: 5 min
user exits the recognition range the water
Hot water supply: max. +70°C
flow will stop automatically. The shower
Opening range: 0 - 5 cm
panel is equipped with litter filters, non-
EMC Directive: 89/336/EEC
150
return valves, flow limiter and 10m power
Recognition range: 60 cm (50 / 60 cm)
cable for transformer. Parameters are
Protection class: IP 55
changed with a magnetic key included in
Noise class: I (ISO 3822)
the package.
Afterflow period: 5 s
The following accessories are sold
separately: soap holder (Oras No. 199880)
& grab bar (Oras No. 199881).
.4ADA50-ahhefg.
6 414150 077456
6664FTX Shower panel, 12 V
Touchless thermostatic shower panel
Colour: Aluminum/Chrome
257
150
with a temperature adjustment handle.
Electrical connection 12 V via a separate
Electrical Connection: 12 VDC
bus transformer (Oras No. 199501 or
Working pressure: 50 - 1000 kPa
199502). The shower is switched on
Flow-rate at 300 kPa (with flow controller):
by placing a hand in front of the sensor
0.18 l/s
within the recognition range. Water will
Flow-rate at 300 kPa: 0.195 l/s
flow for as long as the person is standing
under the shower. When the user exits
Max. flow period: 5 min
the recognition range the water flow will
Hot water supply: max. +70°C
stop automatically. The shower panel is
Opening range: 0 - 5 cm
equipped with litter filters, non-return
EMC Directive: 2004/108/EY
150
valves and a flow limiter.
Recognition range: 60 cm (50 / 60 cm)
Protection class: IP 55
The following accessories are sold
Noise class: I (ISO 3822)
separately: soap holder (Oras No. 199880)
Afterflow period: 5 s
& grab bar (Oras No. 199881).
.4ADA50-ahcjej.
6 414150 072949
61
Oras Electra
6207C Cover part for washbasin faucet, 12 V
160
Touchless wall-mounted washbasin
Colour: Chrome
faucet with a temperature limiter.
Electrical connection 12 V via a separate
Electrical Connection: 12 VDC
power supply (Oras No. 199275). Body
Pressure loss with flow (0.1 l/s): 200 kPa
part (Oras No. 6227A) has to be ordered
Working pressure: 100 - 1000 kPa
separately.
Flow-rate at 300 kPa (with flow controller):
Parameters are changed with a magnetic
0.1 l/s
key included in the package.
Max. flow period: 2 min
Hot water supply: max. +70°C
Opening range: 0 - 5 cm
185±15
Intelligent afterflow period: 3 s ± 2 s
Min. current consumption: 0 A
EMC Directive: 2004/108/EY
Recognition range: 40 cm (40 / 50 cm)
Protection class: IP 55
Noise class: I (ISO 3822)
.4ADA50-agaabe.
6 414150 060014
6208C Cover part for washbasin faucet, 12 V
Touchless wall-mounted washbasin
Colour: Chrome
160
faucet with a temperature limiter.
Electrical connection 12 V via a separate
Electrical Connection: 12 VDC
power supply (Oras No. 199275). Body
Pressure loss with flow (0.1 l/s): 200 kPa
part (Oras No. 6227A) has to be ordered
Working pressure: 100 - 1000 kPa
separately.
Flow-rate at 300 kPa (with flow controller):
Parameters are changed with a magnetic
0.1 l/s
key included in the package.
Max. flow period: 2 min
Hot water supply: max. +70°C
250±15
Opening range: 0 - 5 cm
Intelligent afterflow period: 3 s ± 2 s
Min. current consumption: 0 A
EMC Directive: 2004/108/EY
Recognition range: 40 cm (40 / 50 cm)
Protection class: IP 55
Noise class: I (ISO 3822)
.4ADA50-agbeff.
6 414150 061455
6257C Cover part for washbasin faucet, 6 V
160
Touchless wall-mounted washbasin
Colour: Chrome
faucet with a temperature limiter. Battery
operated 6 V (2CR5). Body part (Oras No.
Pressure loss with flow (0.1 l/s): 200 kPa
6227A) has to be ordered separately.
Working pressure: 100 - 1000 kPa
Parameters are changed with a magnetic
Flow-rate at 300 kPa (with flow controller):
key included in the package.
0.1 l/s
Max. flow period: 2 min
Hot water supply: max. +70°C
Opening range: 0 - 5 cm
Intelligent afterflow period: 3 s ± 2 s
185±15
EMC Directive: 2004/108/EY
Recognition range: 40 cm (40 / 50 cm)
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-agaaah.
6 414150 060007
62
Oras Electra
6607C Cover part for shower faucet, 12 V
160
Touchless wall-mounted shower faucet
Colour: Chrome
with a temperature limiter. Electrical
connection 12 V via a separate power
Electrical Connection: 12 VDC
supply (Oras No. 199275). Body part
Pressure loss with flow (0.2 l/s): 300 kPa
(Oras No. 6227A) has to be ordered
Working pressure: 100 - 1000 kPa
separately.
Flow-rate at 300 kPa: 0.2 l/s
Parameters are changed with a magnetic
key included in the package.
Max. flow period: 5 min
Hot water supply: max. +70°C
Opening range: 0 - 5 cm
Min. current consumption: 0 A
EMC Directive: 2004/108/EY
Recognition range: 60 cm (50 / 60 cm)
Protection class: IP 55
Noise class: I (ISO 3822)
Afterflow period: 5 s
.4ADA50-afjjjf.
6 414150 059995
6610C Cover part for washbasin faucet, 3 V
Touchless wall-mounted washbasin
Colour: Chrome
ø170
185
faucet for cold or pre-mixed water.
14
Battery-operated 3 V (AA 1.5 V Lithium x
Working pressure: 100 - 1000 kPa
2). Spout lenght 170mm. Body part Oras
Flow-rate at 300 kPa (with flow controller):
Bluebox (No. 2081 or 2080) has to be
0.08 l/s
ordered separately. Parameters can be
Max. flow period: 60 s (10/30/60/90/120/150/1
changed with a magnetic key, included in
80/210/240/300 s)
the package.
Hot water supply: max. +70°C
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
170
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Battery: AA 1.5 V Lithium x 2
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
.4ADA50-aiaceb.
6 414150 080241
6611C Cover part for washbasin faucet, 3 V
Touchless wall-mounted washbasin
Colour: Chrome
faucet for cold or pre-mixed water.
ø170
260
14
Battery-operated 3 V (AA 1.5 V Lithium x
Working pressure: 100 - 1000 kPa
2). Spout lenght 245mm. Body part Oras
Flow-rate at 300 kPa (with flow controller):
Bluebox (No. 2081 or 2080) has to be
0.08 l/s
ordered separately. Parameters can be
Max. flow period: 60 s (10/30/60/90/120/150/1
changed with a magnetic key, included in
80/210/240/300 s)
the package.
Hot water supply: max. +70°C
Automatic flush period: 30 s (30/60/90/120/18
245
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Battery: AA 1.5 V Lithium x 2
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
.4ADA50-aiacgf.
6 414150 080265
63
Oras Electra
6612C Cover part for washbasin faucet, 3 V
Touchless wall-mounted washbasin
Colour: Chrome
faucet for cold or pre-mixed water.
ø170
325
14
Battery-operated 3 V (AA 1.5 V Lithium x
Working pressure: 100 - 1000 kPa
2). Spout lenght 310mm. Body part Oras
Flow-rate at 300 kPa (with flow controller):
Bluebox (No. 2081 or 2080) has to be
0.08 l/s
ordered separately. Parameters can be
Max. flow period: 60 s (10/30/60/90/120/150/1
changed with a magnetic key, included in
80/210/240/300 s)
the package.
Hot water supply: max. +70°C
Automatic flush period: 30 s (30/60/90/120/18
310
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Battery: AA 1.5 V Lithium x 2
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
.4ADA50-aiachc.
6 414150 080272
6613C Cover part for washbasin faucet, 3 V
ø170
185
Touchless wall-mounted washbasin
Colour: Chrome
40
faucet with temperature adjustment
14
handle. Battery-operated 3 V (AA 1.5 V
Working pressure: 100 - 1000 kPa
Lithium x 2). Spout lenght 170mm. Body
Flow-rate at 300 kPa (with flow controller):
part Oras Bluebox (No. 2081 or 2080) has
0.08 l/s
to be ordered separately. Parameters can
Max. flow period: 60 s (10/30/60/90/120/150/1
be changed with a magnetic key, included
80/210/240/300 s)
in the package.
Hot water supply: max. +70°C
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
170
Recognition range: optimally preset
Protection class: IP 55
Battery: AA 1.5 V Lithium x 2
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
.4ADA50-aiacij.
6 414150 080289
6614C Cover part for washbasin faucet, 3 V
Touchless wall-mounted washbasin
Colour: Chrome
ø170
260
faucet with temperature adjustment
40
14
handle. Battery-operated 3 V (AA 1.5 V
Working pressure: 100 - 1000 kPa
Lithium x 2). Spout lenght 245mm. Body
Flow-rate at 300 kPa (with flow controller):
part Oras Bluebox (No. 2081 or 2080) has
0.08 l/s
to be ordered separately. Parameters can
Max. flow period: 60 s (10/30/60/90/120/150/1
be changed with a magnetic key, included
80/210/240/300 s)
in the package.
Hot water supply: max. +70°C
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
245
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Battery: AA 1.5 V Lithium x 2
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
.4ADA50-aiadac.
6 414150 080302
64
Oras Electra
6615C Cover part for washbasin faucet, 3 V
Touchless wall-mounted washbasin
Colour: Chrome
ø170
325
faucet with temperature adjustment
40
handle. Battery-operated 3 V (AA 1.5 V
Working pressure: 100 - 1000 kPa
14
Lithium x 2). Spout lenght 310mm. Body
Flow-rate at 300 kPa (with flow controller):
part Oras Bluebox (No. 2081 or 2080) has
0.08 l/s
to be ordered separately. Parameters can
Max. flow period: 60 s (10/30/60/90/120/150/1
be changed with a magnetic key, included
80/210/240/300 s)
in the package.
Hot water supply: max. +70°C
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
310
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Battery: AA 1.5 V Lithium x 2
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
.4ADA50-aiadbj.
6 414150 080319
6616C Cover part for shower faucet, 3 V
ø170
Touchless wall-mounted shower faucet
Colour: Chrome
with a temperature limiter. Battery-
operated 3 V (AA 1.5 V Lithium x 2). Body
Working pressure: 100 - 1000 kPa
part Oras Bluebox (No. 2081 or 2080) has
Flow-rate at 300 kPa: 0.23 l/s
to be ordered separately. Parameters can
Max. flow period: 60 s (10/30/60/90/120/150/1
be changed with a magnetic key, included
80/210/240/300 s)
in the package.
Hot water supply: max. +70°C
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
14
Recognition range: optimally preset
66
Protection class: IP 55
Battery: AA 1.5 V Lithium x 2
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
.4ADA50-aiadcg.
6 414150 080326
6617C Cover part for shower faucet, 3 V
ø170
Push button operated wall-mounted
Colour: Chrome
shower faucet with a temperature limiter.
Battery-operated 3 V (AA 1.5 V Lithium
Working pressure: 100 - 1000 kPa
x 2). Body part Oras Bluebox (No. 2081
Flow-rate at 300 kPa: 0.23 l/s
or 2080) has to be ordered separately.
Max. flow period: 45 s (15/30/45/60/75/90/105
Parameters can be changed
/120/135/150 s)
Hot water supply: max. +70°C
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
14
Protection class: IP 55
66
Battery: AA 1.5 V Lithium x 2
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
.4ADA50-aiadea.
6 414150 080340
65
Oras Electra
6620C Cover part for washbasin faucet, 12 V
Cover part for washbasin faucet with cold
Colour: Chrome
ø170
185
14
or premixed water. Electrical connection
12 V. Spout lenght 170 mm. Body part
Electrical Connection: 12 VDC
Oras Bluebox (No. 2081 or 2080),
Working pressure: 100 - 1000 kPa
transformer (No. 199275) and right cable
Flow-rate at 300 kPa (with flow controller):
length (No. 200510 -200570), has to be
0.08 l/s
ordered separately. Parameters can be
Max. flow period: 60 s (10/30/60/90/120/150/1
changed with a magnetic key, included in
80/210/240/300 s)
the package.
Hot water supply: max. +70°C
Automatic flush period: 30 s (30/60/90/120/18
170
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
EN standard: EN 15091
.4ADA50-aifhij.
6 414150 085789
6621C Cover part for washbasin faucet, 12 V
Cover part for washbasin faucet with cold
Colour: Chrome
or premixed water. Electrical connection
ø170
260
14
12 V. Spout lenght 245 mm. Body part
Electrical Connection: 12 VDC
Oras Bluebox (No. 2081 or 2080),
Working pressure: 100 - 1000 kPa
transformer (No. 199275) and right cable
Flow-rate at 300 kPa (with flow controller):
length (No. 200510 -200570), has to be
0.08 l/s
ordered separately. Parameters can be
Max. flow period: 60 s (10/30/60/90/120/150/1
changed with a magnetic key, included in
80/210/240/300 s)
the package.
Hot water supply: max. +70°C
245
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
EN standard: EN 15091
.4ADA50-aifhjg.
6 414150 085796
6622C Cover part for washbasin faucet, 12 V
Cover part for washbasin faucet with cold
Colour: Chrome
or premixed water. Electrical connection
ø170
324
14
12 V. Spout lenght 310 mm. Body part
Electrical Connection: 12 VDC
Oras Bluebox (No. 2081 or 2080),
Working pressure: 100 - 1000 kPa
transformer (No. 199275) and right cable
Flow-rate at 300 kPa (with flow controller):
length (No. 200510 -200570), has to be
0.08 l/s
ordered separately. Parameters can be
Max. flow period: 60 s (10/30/60/90/120/150/1
changed with a magnetic key, included in
80/210/240/300 s)
the package.
Hot water supply: max. +70°C
310
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
EN standard: EN 15091
.4ADA50-aifiac.
6 414150 085802
66
Oras Electra
6623C Cover part for washbasin faucet, 12 V
ø170
185
Cover part for washbasin faucet
Colour: Chrome
40
with mixed water and a temperature
14
adjustment handle. Electrical connection
Electrical Connection: 12 VDC
12 V. Spout lenght 170 mm. Body part
Working pressure: 100 - 1000 kPa
Oras Bluebox (No. 2081 or 2080),
Flow-rate at 300 kPa (with flow controller):
transformer (No. 199275) and right cable
0.08 l/s
length (No. 200510 -200570), has to be
Max. flow period: 60 s (10/30/60/90/120/150/1
ordered separately. Parameters can be
80/210/240/300 s)
changed with a magnetic key, included in
Hot water supply: max. +70°C
the package.
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
170
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
EN standard: EN 15091
.4ADA50-aifibj.
6 414150 085819
6624C Cover part for washbasin faucet, 12 V
Cover part for washbasin faucet
Colour: Chrome
ø170
260
with mixed water and a temperature
40
14
adjustment handle. Electrical connection
Electrical Connection: 12 VDC
12 V. Spout lenght 245 mm. Body part
Working pressure: 100 - 1000 kPa
Oras Bluebox (No. 2081 or 2080),
Flow-rate at 300 kPa (with flow controller):
transformer (No. 199275) and right cable
0.08 l/s
length (No. 200510 -200570), has to be
Max. flow period: 60 s (10/30/60/90/120/150/1
ordered separately. Parameters can be
80/210/240/300 s)
changed with a magnetic key, included in
Hot water supply: max. +70°C
the package.
Automatic flush period: 30 s (30/60/90/120/18
245
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
EN standard: EN 15091
.4ADA50-aificg.
6 414150 085826
6625C Cover part for washbasin faucet, 12 V
Cover part for washbasin faucet
Colour: Chrome
ø170
325
with mixed water and a temperature
40
adjustment handle. Electrical connection
Electrical Connection: 12 VDC
14
12 V. Spout lenght 310 mm. Body part
Working pressure: 100 - 1000 kPa
Oras Bluebox (No. 2081 or 2080),
Flow-rate at 300 kPa (with flow controller):
transformer (No. 199275) and right cable
0.08 l/s
length (No. 200510 -200570), has to be
Max. flow period: 60 s (10/30/60/90/120/150/1
ordered separately. Parameters can be
80/210/240/300 s)
changed with a magnetic key, included in
Hot water supply: max. +70°C
the package.
310
Automatic flush period: 30 s (30/60/90/120/18
0/240/300/360/480/600 s)
EMC Directive: 2014/30/EU
Recognition range: optimally preset
Protection class: IP 55
Noise class: I (ISO 3822)
Automatic flush: off
(off/6/12/18/24/30/36/48/60/72 h)
Afterflow period: 3 s (1/2/3/4/5/6/7/8/9/10 s)
EN standard: EN 15091
.4ADA50-aifidd.
6 414150 085833
67
