IL BAGNO ALESSI One by Oras
8516F Washbasin faucet, 6 V
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle, a Bidetta
hand shower and a rapid pop-up waste.
Pressure loss with flow (0.1 l/s): 250 kPa
The faucet is equipped with litter filters
Working pressure: 100 - 1000 kPa
and non-return valves. No adjustments
Flow-rate at 300 kPa (with flow controller):
are needed at installation because of an
90
0.1 l/s
ø 34 -37
ø 63
advanced Autofocus sensor. The impulse-
Max. flow period: 2 min
controlled solenoid valve gives the battery
G 1/2
a long operating life. Flow controller (6 l/
Hot water supply: max. +70°C
min) enables low water consumption.
Intelligent afterflow period: 2 s ± 1 s
G 1 1/4
EMC Directive: 2004/108/EY
G 3/8
F = with flexible pipes
Recognition range: optimally preset
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-agefjd.
6 414150 064593
8500 Washbasin faucet
Washbasin faucet with pop-up waste,
Colour: Chrome
fixed spout and aerator.
Design: Stefano Giovannoni
Pressure loss with flow (0.1 l/s): 75 kPa
Working pressure: 50 - 1000 kPa
104
Flow-rate at 300 kPa: 0.2 l/s
ø 33 - 35
ø 63
Hot water supply: max. +80°C
Noise class: II (ISO 3822)
ø 10
G 1 1/4
.4ADA50-aefafj.
6 414150 045059
8500F Washbasin faucet
Washbasin faucet with pop-up waste,
Colour: Chrome
fixed spout and aerator.
Design: Stefano Giovannoni
Working pressure: 50 - 1000 kPa
Flow-rate at 300 kPa: 0.18 l/s
F = with flexible pipes
104
Hot water supply: max. +80°C
ø 33 - 35
ø 63
Noise class: II (ISO 3822)
G 3/8
G 1 1/4
.4ADA50-aefagg.
6 414150 045066
28
IL BAGNO ALESSI One by Oras
8502 Washbasin faucet
Washbasin faucet with fixed spout and
Colour: Chrome
aerator. Bidetta hand shower, shower
hose, wall bracket and pop-up waste are
Pressure loss with flow (0.1 l/s): 200 kPa
included.
Working pressure: 200 - 1000 kPa
Design: Stefano Giovannoni
Flow-rate at 300 kPa: 0.13 l/s
Hot water supply: max. +80°C
104
ø 33 - 35
ø 63
Noise class: l (ISO 3822)
ø 10
G 1 1/4
.4ADA50-aeijag.
6 414150 048906
8502F Washbasin faucet
Washbasin faucet with fixed spout and
Colour: Chrome
aerator. Bidetta hand shower, shower
hose, wall bracket and pop-up waste are
Working pressure: 200 - 1000 kPa
included.
Flow-rate at 300 kPa: 0.11 l/s
Design: Stefano Giovannoni
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
104
F = with flexible pipes
ø 33 - 35
ø 63
G 3/8
G 1 1/4
.4ADA50-aeijca.
6 414150 048920
8510 Washbasin faucet
Wall-mounted washbasin faucet. Fixed
Colour: Chrome
spout, aerator and cover plate are
included.
Pressure loss with flow (0.1 l/s): 75 kPa
Body part (Oras 258088) has to be
Working pressure: 50 - 1000 kPa
ordered separately.
Flow-rate at 300 kPa: 0.2 l/s
Design: Stefano Giovannoni
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
max 200
.4ADA50-aefajh.
6 414150 045097
29
IL BAGNO ALESSI One by Oras
8518 Bidet faucet
Bidet faucet with pop-up waste, fixed
Colour: Chrome
spout and aerator.
Design: Stefano Giovannoni
Pressure loss with flow (0.1 l/s): 75 kPa
Working pressure: 50 - 1000 kPa
119
Flow-rate at 300 kPa: 0.2 l/s
ø 33 - 35
Hot water supply: max. +80°C
ø 63
Noise class: II (ISO 3822)
ø 10
G 1 1/4
.4ADA50-aefahd.
6 414150 045073
8518F Bidet faucet
Bidet faucet with pop-up waste, fixed
Colour: Chrome
spout and aerator.
Design: Stefano Giovannoni
Working pressure: 50 - 1000 kPa
Flow-rate at 300 kPa: 0.18 l/s
F = with flexible pipes
119
Hot water supply: max. +80°C
ø 33 - 35
Noise class: II (ISO 3822)
ø 63
G 3/8
G 1 1/4
.4ADA50-aefaia.
6 414150 045080
8545 Bath and shower faucet
Bath and shower faucet with turnable
Colour: Chrome
spout, aerator and diverter. Hand shower,
shower hose, eccentric unions and cover
Pressure loss with flow (0.3 l/s): 340 kPa
plates are included.
Pressure loss with flow (0.2 l/s): 180 kPa
Design: Stefano Giovannoni
Working pressure: 50 - 1000 kPa
Flow-rate at 300 kPa: 0.28 / 0.26 l/s
Please note! The faucet is not suitable for
Hot water supply: max. +80°C
connecting to exposed water pipes.
Noise class: II (ISO 3822)
205 - 65
150±15
.4ADA50-aeffeh.
6 414150 045547
30
IL BAGNO ALESSI One by Oras
8560 Shower faucet
Shower faucet with hand shower and
Colour: Chrome
shower hose. Eccentric unions and cover
plates are included.
Pressure loss with flow (0.2 l/s): 210 kPa
Design: Stefano Giovannoni
Working pressure: 50 - 1000 kPa
Flow-rate at 300 kPa: 0.24 l/s
Please note! The faucet is not suitable for
Hot water supply: max. +80°C
connecting to exposed water pipes.
Noise class: II (ISO 3822)
150±15
.4ADA50-aeffgb.
6 414150 045561
8575U Bath and shower faucet
Thermostatic shower faucet that reacts
Colour: Chrome
quickly and precisely to the changes of
150±15
incoming water temperature and keeps
Pressure loss with flow (0.3 l/s): 285 kPa
the water temperature as selected.
Working pressure: 100 - 1000 kPa
Temperature adjustment handle equipped
Flow-rate at 300 kPa: 0.31 / 0.23 l/s
with temperature limiter and button
Hot water supply: max. +80°C
for bypassing the limiter (preset at ca.
Noise class: I (ISO 3822)
G 1/2
38°C). Aerator and push-down diverter
are integrated into the spout. Eccentric
161
unions, cover plates, non-return valves
and litter filters are included.
Design: Stefano Giovannoni
.4ADA50-afbdbj.
6 414150 051319
8570U Shower faucet
Thermostatic shower faucet that reacts
Colour: Chrome
quickly and precisely to the changes of
incoming water temperature and keeps
Pressure loss with flow (0.2 l/s): 145 kPa
150±15
the water temperature as selected.
Working pressure: 100 - 1000 kPa
Temperature adjustment handle is
Flow-rate at 300 kPa: 0.29 l/s
equipped with temperature limiter an
Hot water supply: max. +80°C
button for bypassing the limiter (preset at
Noise class: I (ISO 3822)
ca. 38°C). Eccentric unions, cover plates,
78
G 1/2
non-return valves and litter filters are
included.
Design: Stefano Giovannoni
.4ADA50-afbcij.
6 414150 051289
31
IL BAGNO ALESSI One by Oras
8540 Bath faucet
Bath faucet (4 holes) with fixed diverter
Colour: Chrome
spout, aerator and separate control
handles for hot and cold water. Hand
Pressure loss with flow (0.3 l/s): 190 kPa
180
shower and shower hose are included.
ø 22-24
ø34-37
ø 28-30
Working pressure: 50 - 1000 kPa
Design: Stefano Giovannoni
Flow-rate at 300 kPa: 0.38 l/s
l = 2000
Hot water supply: max. +80°C
G 1/2
G 1/2
Noise class: II (ISO 3822)
l= 600
l = 600
.4ADA50-aefdab.
6 414150 045301
8550 Bath faucet, floor mounting
Floor standing bath faucet with fixed
Colour: Chrome
diverter spout and aerator. Hand shower
225
and shower hose are included.
Pressure loss with flow (0.3 l/s): 265 kPa
Design: Stefano Giovannoni
Working pressure: 50 - 1000 kPa
Flow-rate at 300 kPa: 0.32 l/s
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
.4ADA50-aefffe.
6 414150 045554
8586 Body for shower faucet
85 max
Concealed universal shower faucet body
G 1/2
35 min
for cover parts Oras No. 8597 and 8598.
Pressure loss with flow (0.2 l/s): 210 kPa
Working pressure: 50 - 1000 kPa
Flow-rate at 300 kPa: 0.24 l/s
4
Hot water supply: max. +80°C
Noise class: l (ISO 3822)
G 1/2
130
.4ADA50-aeggib.
6 414150 046681
32
IL BAGNO ALESSI One by Oras
7127 Body for shower faucet
88 max
Concealed thermostatic shower faucet
185
58 min
body for Oras No. 2887, 7187, 8577 and
Pressure loss with flow (0.2 l/s): 165 kPa
G 1/2
28
8687. Non-return valves and litter filters
Working pressure: 100 - 1000 kPa
are included.
Flow-rate at 300 kPa: 0.27 l/s
Hot water supply: max. +80°C
Noise class: II (ISO 3822)
G 1/2
G 1/2
50
80
.4ADA50-afafch.
6 414150 050527
7128 Body for bath and shower faucet
88 max
Concealed thermostatic bath and shower
185
58 min
faucet body for Oras No. 2888, 7188,
Pressure loss with flow (0.3 l/s): 250 kPa
G 1/2
28
8578 and 8688. Non-return valves and
Working pressure: 100 - 1000 kPa
litter filters are included.
Flow-rate at 300 kPa: 0.33 l/s
Hot water supply: max. +80°C
Noise class: II (ISO 3822)
G 1/2
G 1/2
50
80
.4ADA50-afafde.
6 414150 050534
33
IL BAGNO ALESSI One by Oras
Oras No. 8577
Oras No. 258080
IL BAGNO ALESSI One by Oras
IL BAGNO ALESSI One by Oras
cover part for concealed
Shower rail
thermostatic shower faucet
for Oras No. 7127
.4ADA50-agffhg.
.4ADA50-aefgai.
6 414150 065576
6 414150 045608
Oras No. 8578
Oras No. 8590
IL BAGNO ALESSI One by Oras
IL BAGNO ALESSI One by Oras
cover part for concealed
Shower set
thermostatic bath and shower
including hand shower, shower
faucet
hose and shower rail.
for Oras No. 7128
.4ADA50-agffgj.
.4ADA50-aeffif.
6 414150 065569
6 414150 045585
Oras No. 8597
Oras No. 248080
IL BAGNO ALESSI One by Oras
IL BAGNO ALESSI One by Oras
cover part for concealed shower
Hand shower
faucet
for Oras No. 8586
195
.4ADA50-aeggji.
.4ADA50-aeffjc.
6 414150 046698
6 414150 045592
Oras No. 8598
Oras No. 8592
IL BAGNO ALESSI One by Oras
IL BAGNO ALESSI One by Oras
cover part for concealed shower
Shower bar for shower cabin
faucet
for Oras No. 8586
.4ADA50-aeghae.
.4ADA50-agfiae.
6 414150 046704
6 414150 065804
Oras No. 238080
Oras No. 8595
IL BAGNO ALESSI One by Oras
IL BAGNO ALESSI One by Oras
Head shower
WC-armatur
2 flush function
(9/6 and 3 liters)
To be used with TECE frame only.
75
.4ADA50-aegifi.
.4ADA50-afagge.
6 414150 046858
6 414150 050664
Oras No. 248090
IL BAGNO ALESSI One by Oras
Concealed shower angle
G 1/2
.4ADA50-aeghbb.
6 414150 046711
34
Oras Signa
Oras Signa - form and function
Oras Signa is an organically inspired faucet for kitchens and bathrooms long-
ing for beautiful design, available as both hybrid function and manually oper-
ated single-lever models for variable uses and purposes in everyday life. The
faucets an innovative 360-degree visual design, with a different look from
every perspective, allowing you to fall in love with it over and over again, 365
days a year.
Oras Signa is designed not only for aesthetics, but for everyday ease of use,
though, as it also hides a variety of features designed to make your life eas-
ier. The hybrid version can be operated manually, or alternatively using the
touchless function for enhanced hygiene and convenience. The pull-out
spout with flexible 150-degree operation radius (standard feature for kitchen
and optional for wash basin faucet) provides you a new level of user-friend-
liness in your kitchen every single day. The Smart Bidetta hand shower avail-
able for wash basin faucet adds also practicality for maximized user conveni-
ence.
35
Oras Signa
2220F Kitchen faucet
140
268
Kitchen faucet with swivel pull-out spout
Colour: Chrome
and aerator. Spout’s swing angle is factory
preset at 150° (can be limited to 70°)
Working pressure: 50 - 1000 kPa
F = with flexible pipes
Flow-rate at 300 kPa: 0.15 l/s
Hot water supply: max. +80°C
223
ø33.5
Noise class: I (ISO 3822) Oras lab.
EN standard: EN 817
G3/8
M15x1
.4ADA50-ahhdjf.
6 414150 077395
2222F Kitchen faucet, 3 V
Kitchen faucet with hybrid control (both
Colour: Chrome
touchless and single-lever functions),
140
268
l= 300
thermostat with control unit, swivel pull-
Working pressure: 100 - 1000 kPa
out spout and aerator. Spout’s swing
Flow-rate at 300 kPa: 0.15 l/s
angle is factory preset at 150° (can be
Hot water supply: max. +70°C
223
65
29
limited to 70°).The touchless function
ø33.5
Automatic flush period: 30 s
is turned on by taking hands within
153
119
(10/30/60/120/180/240/300/600 s)
the recognition range and water flows
automatically for 6 s but can be stopped
Flow period (touchless function): 6 s
G3/8
(4/6/8/10/20/60 s)
earlier by putting hands back to the
M15x1
recognition area. Battery-operated 3 V.
EMC Directive: 2014/30/EU
F = with flexible pipes
Recognition range: optimally preset
Protection class: IP 55
Noise class: I (ISO 3822) Oras lab.
Battery: AA 1.5 V Lithium x 2
Automatic flush: off (off/12/24/48/72 h)
.4ADA50-ahhecf.
6 414150 077425
2225F Kitchen faucet with dishwasher valve, 230/5 V
Kitchen faucet with swivel pull-out spout,
Colour: Chrome
140
268
aeretor and remote valve for dishwasher.
Spout’s swing angle is factory preset
Electrical Connection: 230 / 5 V
ø 52
at 150° (can be limited to 70°). The
Working pressure: 100 - 1000 kPa
dishwasher valve is opened by pressing
Flow-rate at 300 kPa: 0.15 l/s
223
a switch with signal light, and the valve
ø33.5
Hot water supply: max. +70°C
closes automatically after preset period.
Dishwasher valve open period: 4 h / 12 h
Dishwasher valve closes automatically
230 V/5 V
after 3 or 12 hours (one push opens the
EMC Directive: 2014/30/EU
G3/8
valve for 3 hours, pushing for 5 seconds
Protection class: IP 54 / transformer IP 40
29
65
l=2 m
opens the valve for 12 hours).
Noise class: I (ISO 3822) Oras lab.
M15x1
Electrical connection with a plug
Battery: CR 2450 3 V
transformer 230/5 V.
F = with flexible pipes
.4ADA50-ahhebi.
6 414150 077418
36
Oras Signa
2227F Kitchen faucet with dishwasher valve, 230/5 V
Kitchen faucet with hybrid control (both
Colour: Chrome
touchless and single-lever functions),
140
268
thermostat with control unit, swivel pull-
ø 52
l= 300
Electrical Connection: 230 / 5 V
out spout, aerator and remote valve for
Working pressure: 100 - 1000 kPa
230 V/5 V
dishwasher. Spout’s swing angle is factory
223
Flow-rate at 300 kPa: 0.15 l/s
ø33.5
29
65
preset at 150° (can be limited to 70°). The
l=2 m
Hot water supply: max. +70°C
touchless functions stays on for 6 s but
153
119
can be stopped by putting hands back to
Automatic flush period: 30 s
G3/8
the recognition area. Dishwasher valve
(10/30/60/120/180/240/300/600 s)
M15x1
closes automatically after 3 or 12 hours
Flow period (touchless function): 6 s
(one push opens the valve for 3 hours,
(4/6/8/10/20/60 s)
pushing for 5 seconds opens the valve for
Dishwasher valve open period: 4 h / 12 h
12 hours).
EMC Directive: 2014/30/EU
Electrical connection with a plug
Recognition range: optimally preset
transformer 230/5 V.
Protection class: IP 54 / transformer IP 40
F = with flexible pipes
Noise class: I (ISO 3822) Oras lab.
Battery: AA 1.5 V Lithium x 2, CR 2450 3 V
Automatic flush: off (off/12/24/48/72 h)
.4ADA50-ahhedc.
6 414150 077432
2204F Washbasin faucet
140
214
Washbasin faucet with swivel spout,
Colour: Chrome
aerator and a rapid pop-up waste.
F = with flexible pipes
Pressure loss with flow (0.1 l/s): 220 kPa
Working pressure: 50 - 1000 kPa
168
Flow-rate at 300 kPa: 0.12 l/s
ø 35-37
Hot water supply: max. +80°C
ø 63
Noise class: I (ISO 3822)
EN standard: EN 817
l = 400
G 3/8
G 1 1/4
.4ADA50-ahefeh.
6 414150 074547
2208F Washbasin faucet
Washbasin faucet with swivel spout,
Colour: Chrome
aerator, rapid pop-up waste and Bidetta
140
214
34
hand shower, shower hose and wall
Pressure loss with flow (0.1 l/s): 300 kPa
G3/8
bracket.
Working pressure: 50 - 1000 kPa
F = with flexible pipes
Flow-rate at 300 kPa: 0.1 l/s
168
ø 35-37
G 1/2
Hot water supply: max. +80°C
l
= 1500
Noise class: I (ISO 3822)
ø 63
G 3/8
EN standard: EN 817
G 3/8
l
= 400
G 3/8
G 1 1/4
.4ADA50-ahefgb.
6 414150 074561
37
Oras Signa
2213F Washbasin faucet
Washbasin faucet with hybrid control
Colour: Chrome
(both touchless and single-lever
140
212
154
120
functions), thermostat with control unit,
Pressure loss with flow (0.1 l/s): 300 kPa
l
= 300
swivel pull-out spout, aerator and a rapid
Working pressure: 100 - 1000 kPa
168 - 668
pop-up waste. Battery-operated 3 V.
ø 35 - 37
G 1/2
Flow-rate at 300 kPa: 0.1 l/s
ø 63
32
F = with flexible pipes
G 3/8
3 x
Hot water supply: max. +70°C
l
= 400
l
= 1500
Automatic flush period: 30 s
G 3/8
3 x l = 400
(10/30/60/120/180/240/300/600 s)
G 1 1/4
G 3/8
Flow period (touchless function): 6 s
G 3/8
(4/6/8/10/20/60 s)
EMC Directive: 2004/108/EY
Recognition range: optimally preset
Protection class: IP 55
Noise class: I (ISO 3822)
Battery: AA 1.5 V Lithium x 2
Automatic flush: off (off/12/24/48/72 h)
.4ADA50-ahefif.
6 414150 074585
2216F Washbasin faucet, 3 V
Washbasin faucet with hybrid control
Colour: Chrome
(both touchless and single-lever
154
120
functions) swivel spout, aerator, rapid
140
214
Pressure loss with flow (0.1 l/s): 300 kPa
l
= 300
pop-up waste, thermostat with control
Working pressure: 100 - 1000 kPa
168
G 1/2
G 1/2
unit and remote operated Smart Bidetta
Flow-rate at 300 kPa: 0.1 l/s
ø 35-37
hand shower with shower hose and wall
32
l
= 1600
ø 63
Max. flow period: 2 min Bidetta
bracket. Battery-operated 3 V.
G 1/2
l
= 400
Hot water supply: max. +70°C
G 3/8
G 3/8
3 x
The function of remote operated Smart
G 3/8
Bidetta: when lifting the hand shower
Number of devices connected: 8
G 1 1/4
G 3/8
from the holder water starts to flow
Automatic flush period: 30 s
3 x l = 400
from the faucet. When pressing the hand
(10/30/60/120/180/240/300/600 s)
shower trigger the water supply transfers
Flow period (touchless function): 6 s
from faucet to hand shower. When
(4/6/8/10/20/60 s)
placing the Smart Bidetta hand shower
EMC Directive: 2004/108/EY
back to its holder the faucet closes
Recognition range: optimally preset
automatically.
Protection class: IP 55
F = with flexible pipes
Noise class: I (ISO 3822)
Battery: AA 1.5 V Lithium x 2, CR 2450 3 V
Automatic flush: off (off/12/24/48/72 h)
.4ADA50-ahefjc.
6 414150 074592
2207A Body for washbasin faucet, 230/12 V
150
min. 65
Body part for touchless, concealed
31
thermostatic washbasin faucet. Mains
Working pressure: 50 - 1000 kPa
supply 230/12 V. Cover part no. 2207C is
Hot water supply: max. +70°C
sold separately.
Protection class: IP 55 / transformer IP 40
57
75
93
.4ADA50-ahfcbg.
6 414150 075216
38
Oras Signa
2207C Cover part for washbasin faucet, 230/12 V
Cover part for touchless, concealed
Colour: Chrome
thermostatic washbasin faucet with a
temperature limiter. Mains supply 230/12
Electrical Connection: 230 / 12 V
V. Body part no. 2207A is sold separately.
Pressure loss with flow (0.1 l/s): 250 kPa
Working pressure: 100 - 1000 kPa
Flow-rate at 300 kPa: 0.11
Max. flow period: 120 s (10/30/60/120/300 s)
Hot water supply: max. +70°C
Automatic flush period: 30 s
(10/30/60/120/180/240/300/600 s)
Intelligent afterflow period: 2 s ± 1 s (1/2/3/4/8
s)
EMC Directive: 2004/108/EY
Recognition range: ~15 cm (~10/15/17/20 cm)
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO 3822) Oras lab.
Automatic flush: off (off/12/24/48/72 h)
.4ADA50-ahfehg.
6 414150 075476
2209A Body for bath and shower faucet, 230/12 V
Body part for concealed thermostatic
bath and shower faucet with one outlet.
Working pressure: 50 - 1000 kPa
Mains supply 230/12 V. Cover part no.
Hot water supply: max. +70°C
2209C is sold separately.
Protection class: IP 55 / transformer IP 40
min.
.4ADA50-ahfeja.
6 414150 075490
2209C Cover part for bath and shower faucet, 230/12 V
Cover part for concealed thermostatic
Colour: Chrome
bath and shower faucet with one outlet.
Mains supply 230/12 V. Body part no.
Electrical Connection: 230 / 12 V
2209A is sold separately.
Pressure loss with flow (0.2 l/s): 300 kPa
Working pressure: 100 - 1000 kPa
Flow-rate at 300 kPa: 0.2 l/s
Max. flow period: 8 min
Hot water supply: max. +70°C
EMC Directive: 2004/108/EY
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO3822) Oras lab.
Filling time: 10 min (0 - 20 min)
.4ADA50-ahfchi.
6 414150 075278
39
Oras Signa
2219A Body for bath and shower faucet, 230/12 V
Body part for concealed thermostatic
bath and shower faucet with two outlets.
Working pressure: 50 - 1000 kPa
Mains supply 230/12 V. Cover part no.
Hot water supply: max. +70°C
min.
2219C is sold separately.
Protection class: IP 55 / transformer IP 40
.4ADA50-ahffjj.
6 414150 075599
2219C Cover part for bath and shower faucet, 230/12 V
Cover part for concealed thermostatic
Colour: Chrome
bath and shower faucet with two outlets.
Mains supply 230/12 V. Body part no.
Electrical Connection: 230 / 12 V
2219A is sold separately.
Pressure loss with flow (0.2 l/s): 300 kPa
Working pressure: 100 - 1000 kPa
Flow-rate at 300 kPa: 0.2 l/s
Max. flow period: 8 min
Hot water supply: max. +70°C
EMC Directive: 2004/108/EY
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO3822) Oras lab
Filling time: 10 min (0 - 20 min)
.4ADA50-ahffic.
6 414150 075582
40
Oras Signa
2270 Cover part for rain shower faucet, 230/12 V
75
Cover part for thermostatic rain shower
Colour: Chrome
faucet with dual flow control, round head
shower and shower set including hand
Pressure loss with flow (0.2 l/s): 300 kPa
shower, shower hose, wall connection
ø 250
Working pressure: 100 - 1000 kPa
elbow and shower rail. Mains supply
400
Flow-rate at 300 kPa: 0.2 l/s
230/12 V. Body part no. 2219A and 2 x
Hot water supply: max. +70°C
204220 are sold separately.
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO 3822) Oras lab.
45
275
175
.4ADA50-ahfdjb.
6 414150 075391
2271 Cover part for rain shower faucet, 230/12 V
75
Cover part for thermostatic rain shower
Colour: Chrome
faucet with dual flow control, square head
shower and shower set including hand
Pressure loss with flow (0.2 l/s): 300 kPa
shower, shower hose, wall connection
250
Working pressure: 100 - 1000 kPa
elbow and shower rail. Mains supply
400
Flow-rate at 300 kPa: 0.2 l/s
230/12 V. Body part no. 2219A and 2 x
Max. flow period: 8 min
204220 are sold separately.
Hot water supply: max. +70°C
EMC Directive: 2004/108/EY
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO 3822) Oras lab.
Filling time: 10 min (0 - 20 min)
45
275
175
.4ADA50-ahfeah.
6 414150 075407
41
Oras Signa
2272 Cover part for rain shower faucet, 230/12 V
75
Cover part for thermostatic rain shower
Colour: Chrome
faucet with dual flow control, round
head shower and hand shower set
Electrical Connection: 230 / 12 V
including hand shower, shower hose, wall
ø 250
Pressure loss with flow (0.2 l/s): 300 kPa
connection elbow and shower bracket/
400
Working pressure: 100 - 1000 kPa
holder. Mains supply 230/12 V. Body
Flow-rate at 300 kPa: 0.2 l/s
part no. 2219A and 2 x 204220 are sold
separately.
Max. flow period: 8 min
Hot water supply: max. +70°C
EMC Directive: 2004/108/EY
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO 3822) Oras lab.
Filling time: 10 min (0 - 20 min)
45
275
175
.4ADA50-ahfebe.
6 414150 075414
2273 Cover part for rain shower faucet, 230/12 V
75
Cover part for thermostatic rain shower
Colour: Chrome
faucet with dual flow control, square
head shower and hand shower set
Electrical Connection: 230 / 12 V
including hand shower, shower hose, wall
250
Pressure loss with flow (0.2 l/s): 300 kPa
connection elbow and shower bracket/
400
Working pressure: 100 - 1000 kpa
holder. Mains supply 230/12 V. Body
Flow-rate at 300 kPa: 0.2 l/s
part no. 2219A and 2 x 204220 are sold
Max. flow period: 8 min
separately.
Hot water supply: max. +70°C
EMC Directive: 2004/108/EY
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO 3822) Oras lab.
Filling time: 10 min (0 - 20 min)
275
175
45
.4ADA50-ahfecb.
6 414150 075421
42
Oras Signa
2280 Shower faucet with shower set, 230/12 V
75
Cover part for thermostatic shower faucet
Colour: Chrome
with shower set including hand shower,
shower hose and shower rail. Mains
Electrical Connection: 230 / 12 V
supply 230/12 V. Body part no. 2209A and
Pressure loss with flow (0.2 l/s): 300 kPa
1 x 204220 are sold separately.
Working pressure: 100 - 1000 kPa
Flow-rate at 300 kPa: 0.2 l/s
Max. flow period: 8 min
Hot water supply: max. +70°C
EMC Directive: 2004/108/EY
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO 3822) Oras lab.
45
175
175
.4ADA50-ahfeef.
6 414150 075445
2281 Shower faucet with shower set, 230/12 V
Cover part for thermostatic shower faucet
Colour: Chrome
with shower hose and hand shower, wall
connection elbow and shower holder/
Electrical Connection: 230 / 12 V
bracket. Mains supply 230/12 V. Body
Pressure loss with flow (0.2 l/s): 300 kPa
part no. 2209A and 1 x 204220 are sold
Working pressure: 100 - 1000 kPa
45
separately.
175
175
Flow-rate at 300 kPa: 0.2 l/s
Max. flow period: 8 min
Hot water supply: max. +70°C
EMC Directive: 2004/108/EY
Protection class: IP 55 / transformer IP 40
Noise class: I (ISO 3822) Oras lab.
Filling time: 10 min (0 - 20 min)
.4ADA50-ahfefc.
6 414150 075452
43
Oras Signa
2290 Hand shower set
Hand shower set including wall
Colour: Chrome
60
connection elbow, shower hose 1250
mm, suitable with 204220.
G 1/2
100
45
175
.4ADA50-ahfdeg.
6 414150 075346
2291 Shower set
61
Shower set including shower rail 1100
Colour: Chrome
mm, hand shower and shower hose 1600
ø 18
mm, suitable with 204220.
G 1/2
100
45
175
.4ADA50-ahfdcc.
6 414150 075322
44
Oras Signa
Oras No. 204220
Oras No. 232021
170
Installation unit for wall-mounted
Rain shower with Square shower
93
max 90
80
min 65
hand shower set and head
head for rain shower,
75
10
showers.
250 x 250 mm, shower pipe 400
Possible to use with pipe-in-pipe
mm
if you use the hand shower, not if
you’re using the head shower.
G1/2
31
64
.4ADA50-ahfdga.
.4ADA50-ahfdbf.
6 414150 075360
6 414150 075315
Oras No. 200023
Installation rail, suitable for
204220, 2209A, 2219A.
.4ADA50-ahfdhh.
6 414150 075377
Oras No. 200024
Installation angle set.
Possible to use in combination with
installation rail.
.4ADA50-ahfdie.
6 414150 075384
Oras No. 200020
Installation kit for washbasin
pipe-in-pipe installation box for
washbasin faucet
60
80
300
.4ADA50-ahfccd.
6 414150 075223
Oras No. 200022
Installation kit for double outlet
models
pipe-in-pipe installation box for
two outlets
82
265
253
80
600
.4ADA50-ahfcgb.
6 414150 075261
Oras No. 232020
Rain shower with Round shower
head for rain shower,
solid brass Ø 220 mm, projection:
400 mm
.4ADA50-ahfdai.
6 414150 075308
45
Oras Electra
Sophisticated technology wrapped in design.
The extensive product range covers all the needs for home and public use.
Oras Electra faucets are timeless and modern in design and developed for
comfort and sustainability with increased pleasure of experiencing water.
More than 30 years of experience in electronic faucets truly shows in Oras
Electra, our most widely used and versatile touchless faucet family. Oras in-
troduced the touchless faucets in the public premises already in the 1990s,
and today the electronic faucets are common also in the household use.
With touchless faucets, water consumption can be reduced by half, while
user-friendliness and hygiene rise to a whole new level. The simplistic and ap-
proachable design serves as a beautiful contrast to the sophisticated technol-
ogy inside, instantly telling you how easy Oras Electra is to use - and to keep
clean. The extensive product range covers nearly all the needs for home and
public use.
Now, Oras Electra family is extended not only with new design options but
also with Bluetooth compatible variants that can be easily monitored and ad-
justed using the Oras App.
Use of the Bidetta hand shower
Moving hand briefly (0.5 s) over the faucet sensor opens the faucet (for max 2
min) and the Bidetta hand shower can be used. To turn off the faucet after us-
ing Bidetta, move your hand again briefly over the sensor, or wash your hands
in which case the faucet closes automatically.
46
Oras Electra
6100 Washbasin faucet, 230 V
Touchless washbasin faucet for pre-mixed
Colour: Chrome
water. Fixed electrical connection 230 V.
155
75
Recognition range can be adjusted at the
Electrical Connection: 230 VAC
faucet.
Pressure loss with flow (0.1 l/s): 170 kPa
Working pressure: 50 - 1000 kPa
3, 6 and 9 meters photocell cables
Flow-rate at 300 kPa (with flow controller):
120
available:
ø 28-35
~230 V
25
(Pg 11)
Oras No.
0.11 l/s
l = 600
6100/3
Max. flow period: 2 min (1 - 255 s)
G 3/8
6100/6
Hot water supply: max. +80°C
6100/9
EMC Directive: 89/336/EEC
Recognition range: 0 - 40 cm
Protection class: IP 67
Noise class: I (ISO 3822)
Afterflow period: 1 s (0 - 255 s)
.4ADA50-achccc.
6 414150 027222
6104 Washbasin faucet, 230 V
Touchless washbasin faucet with a mixing
Colour: Chrome
155
75
valve. Fixed electrical connection 230 V.
Recognition range can be adjusted at the
Electrical Connection: 230 VAC
faucet. The faucet is equipped with litter
Pressure loss with flow (0.1 l/s): 170 kPa
filters and non-return valves.
Working pressure: 50 - 1000 kPa
ø 28-35
120
~230 V
Flow-rate at 300 kPa (with flow controller):
(Pg 11)
3, 6 and 9 meters photocell cables
0.11 l/s
available:
Oras No.
Max. flow period: 2 min (1 - 255 s)
l
= 600
6104/3
Hot water supply: max. +80°C
G 3/8
6104/6
EMC Directive: 89/336/EEC
6104/9
Recognition range: 0 - 40 cm
Protection class: IP 67
Noise class: I (ISO 3822)
Afterflow period: 1 s (0 - 255 s)
.4ADA50-achcdj.
6 414150 027239
6105 Washbasin faucet, 230 V
Touchless washbasin faucet with a mixing
Colour: Chrome
155
75
valve and hand shower. Fixed electrical
connection 230 V. Recognition range can
Electrical Connection: 230 VAC
be adjusted at the faucet. The faucet is
Pressure loss with flow (0.1 l/s): 220 kPa
equipped with litter filters and non-return
Working pressure: 50 - 1000 kPa
valves.
120
~230 V
Flow-rate at 300 kPa (with flow controller):
ø 28-35
(Pg 11)
0.11 l/s
Use of the hand shower: Lift the hand
shower from its holder and press the
Max. flow period: 2 min (1 - 255 s)
l
= 600
trigger. The water flow will stop when the
Hot water supply: max. +80°C
G 3/8
hand shower is replaced to the holder.
EMC Directive: 89/336/EEC
Recognition range: 0 - 40 cm
An extension cord in the legth of 2-5
Protection class: IP 67
meters is available for the holder of the
Noise class: I (ISO 3822)
hand shower. (Oras No. 197033/m)
Afterflow period: 1 s (0 - 255 s)
3, 6 and 9 meters photocell cables
available:
Oras No.
6105/3
6105/6
6105/9
.4ADA50-achceg.
6 414150 027246
47
