Repair Section
2-116
7
Check the Exhaust Gas Recirculation (EGR)
Repair or replace the EGR system.
NG
system. (Refer to the EGR system check proce-
dure issued by the vehicle manufacturer.)
OK
8
Perform the accelerator pedal position sensor
Repair or replace the accelerator position sen-
NG
function check. (Refer to the accelerator posi-
sor and/or the corresponding circuit.
tion pedal sensor check procedure issued by
the vehicle manufacturer.)
OK
9
Check the boost pressure sensor and the corre-
Repair or replace the boost pressure sensor
NG
sponding circuit. (Refer to the boost pressure
and/or the corresponding circuit.
sensor check procedure issued by the vehicle
manufacturer.)
OK
10
Check the supply pump and the supply pump
Repair or replace the supply pump and drive cir-
NG
drive circuit. (Refer to the supply pump drive cir-
cuit.
cuit diagram issued by the vehicle manufac-
turer.)
OK
Troubleshooting complete
Repair Section
2-117
(10) Knocking, abnormal noise
Description
Abnormal combustion occurs, and a knocking sound is generated.
Possible Cause
• Engine
• Injector
• Glow control system
• Crankshaft position sensor
Clogged air cleaner element
1
Repair the glow control system. (Refer to the
Repair the glow control system.
NG
glow control system check procedure issued by
the vehicle manufacturer.)
OK
2
Check the crankshaft position sensor. (Refer to
Repair or replace the crankshaft position sensor
NG
the crankshaft position sensor check procedure
and/or the corresponding circuit.
issued by the vehicle manufacturer.)
OK
3
Check each injector. (Refer to the injector check
Repair or replace the injector and/or the corre-
NG
procedure issued by the vehicle manufacturer.)
sponding circuit.
OK
4
Check engine parts that may be a source of
Repair the engine.
NG
abnormal combustion.
OK
Troubleshooting complete
Repair Section
2-118
(11) Poor fuel economy
Description
More fuel than normal is being consumed.
Possible Cause
• Engine
• Injector
• Supply pump
Clogged air cleaner element
1
Check each injector. (Refer to the injector check
Repair or replace the injector and/or the corre-
NG
procedure issued by the vehicle manufacturer.)
sponding circuit.
OK
2
Check the supply pump and the supply pump
Repair or replace the supply pump and drive cir-
NG
drive circuit. (Refer to the supply pump drive cir-
cuit.
cuit diagram issued by the vehicle manufac-
turer.)
OK
3
Check parts that may be a source of poor fuel
Repair the engine.
NG
economy.
OK
Troubleshooting complete
R
e
p a
r
S
e
c
t i o
n
2-119
(12) Black Smoke
Description
Black smoke is being exhausted.
Possible Cause
• Injector
• Supply pump
• EGR system
• Engine ECU
• Electronic control throttle
• Rail pressure sensor
• Mass Air Flow (MAF) meter
• Boost pressure sensor
Clogged air cleaner element
1
Check for air cleaner clogging and/or damage.
Replace the air cleaner or repair the air duct.
NG
OK
2
Check the electronic control throttle and the cor-
Repair or replace the electronic control throttle
NG
responding circuit. (Refer to the electronic con-
and/or the corresponding circuit.
trol throttle check procedure issued by the
vehicle manufacturer.)
OK
3
Check the MAF meter and the corresponding
Repair or replace the MAF meter and/or the cor-
NG
circuit.
(Refer to the MAF meter check proce-
responding circuit.
dure issued by the vehicle manufacturer.)
OK
4
Check the Exhaust Gas Recirculation (EGR)
Repair or replace the EGR system.
NG
system. (Refer to the EGR system check proce-
dure issued by the vehicle manufacturer.)
OK
5
Check the boost pressure sensor and the corre-
Repair or replace the boost pressure sensor
NG
sponding circuit. (Refer to the boost pressure
and/or the corresponding circuit.
sensor check procedure issued by the vehicle
manufacturer.)
OK
6
Check the rail pressure sensor and the corre-
Repair or replace the rail pressure sensor and
NG
sponding circuit. (Refer to the rail pressure sen-
the corresponding circuit.
sor check procedure issued by the vehicle
manufacturer.)
Repair Section
2-120
OK
7
Check each injector. (Refer to the injector check
Repair or replace the injector and/or the corre-
NG
procedure issued by the vehicle manufacturer.)
sponding circuit.
OK
8
Check the engine ECU power supply. (Refer to
Repair the engine ECU power supply.
NG
the engine ECU power supply circuit diagram
issued by the vehicle manufacturer.)
OK
9
Check the supply pump and the supply pump
Repair or replace the supply pump and drive cir-
NG
drive circuit. (Refer to the supply pump drive cir-
cuit.
cuit diagram issued by the vehicle manufac-
turer.)
OK
Troubleshooting complete
Repair Section
2-121
(13) White smoke
Description
White smoke is being exhausted.
Possible Cause
• Fuel filter
• Injector
• Supply pump
• EGR system
• Engine ECU
• Electronic control throttle
• Rail pressure sensor
Clogged air cleaner element
1
Check the fuel filter.
Replace the fuel filter.
NG
OK
2
Check each injector. (Refer to the injector check
Repair or replace the injector and/or the corre-
NG
procedure issued by the vehicle manufacturer.)
sponding circuit.
OK
3
Check the Exhaust Gas Recirculation (EGR)
Repair or replace the EGR system.
NG
system. (Refer to the EGR system check proce-
dure issued by the vehicle manufacturer.)
OK
4
Check the supply pump and the supply pump
Repair or replace the supply pump and drive cir-
drive circuit. (Refer to the supply pump drive cir-
NG
cuit.
cuit diagram issued by the vehicle manufac-
turer.)
OK
5
Check the rail pressure sensor and the corre-
Repair or replace the rail pressure sensor and
sponding circuit. (Refer to the rail pressure sen-
NG
the corresponding circuit.
sor check procedure issued by the vehicle
manufacturer.)
OK
6
Check the electronic control throttle and the cor-
Repair or replace the electronic control throttle
NG
responding circuit. (Refer to the electronic con-
and/or the corresponding circuit.
trol throttle check procedure issued by the
vehicle manufacturer.)
OK
Troubleshooting complete
Repair Section
2-122
5.2 Other Malfunction Symptoms
Malfunctions caused by components other than the CRS
z There are occasions when a malfunction that appears to be generated by the CRS is actually caused by a different com-
ponent or system. For instance, engine mechanical parts and the fuel system may cause malfunction symptoms iden-
tical to symptoms generated by the CRS. When troubleshooting, do not simply assume that the source of a malfunction
is the CRS. Consider all causes should be exhaustively considered while verifying the list below.
Malfunction
Faulty Item
Cause
Action
Symptom
Intake system
Clogged air cleaner element
Clean or replace the air cleaner element.
Air mixed with the fuel system
Perform fuel system air bleeding.
Faulty fuel filter
Replace the filter.
Fuel system
Insufficient fuel
Add fuel and perform fuel system air
Insufficient
bleeding.
Power
Improper fuel
Switch to the correct fuel.
Compression pressure abnormality
Refer to the engine repair manual.
Engine
Piston, cylinder liner and/or piston ring
Other
Overheat
Intake system
Clogged air cleaner element
Clean or replace the air cleaner element.
Insufficient fuel
Add fuel and perform fuel system air
bleeding.
Improper fuel
Replace the filter.
Fuel system clog
Clean the fuel system.
Fuel system
Air introduction through fuel system con-
Tighten all connections.
Faulty starting
nection points
Fuel filter clog
Replace the fuel filter.
Loose injection piping connections
Tighten connecting nuts.
Faulty battery
Check the battery.
Electrical sys-
Faulty starter wiring
Replace the starter wiring.
tem
Loose battery cables
Tighten the battery terminal connections,
or replace the cables.
Electrical sys-
Faulty starter operation
Replace the starter assembly.
tem
Faulty glow plug system
Replace the glow plugs.
Lubrication
Excessive engine oil viscosity
Replace with oil of appropriate viscosity.
system
Burnt pistons
Replace the piston, piston ring and cylin-
Faulty starting
der liner.
Engine
Burnt bearings
Replace the bearing and crankshaft.
Low compression pressure
Overhaul the engine.
Ring gear damage
Replace the ring gear and/or starter pin-
Other
ion gear.
Repair Section
2-123
Malfunction
Faulty Item
Cause
Action
Symptom
Poor valve clearance
Adjust the valve clearance or replace the
bearing.
Poor valve seat contact
Break in, or replace the valve and valve
Faulty idling
Engine
seat.
Low coolant temperature
Perform warm-up operation.
Large difference in cylinder-to-cylinder
Overhaul the engine.
compression pressure
Repair Section
2-124
6. DIAGNOSIS CODES (DTC)
6.1 DTC Chart (Example)
DTC Structure
z P####: Powertrain-related (engine, drive system)
z U####: Network-related (vehicle communication)
DTC Assignment
z PO###: Determined by SAE/ISO
z P1###: Determined by manufacturer
z P2###: Determined by manufacturer
z P3###: Mixture of items determined by SAE/ISO and items determined by the vehicle manufacturer.
DTC Chart (example for HINO and TOYOTA vehicles)
z DTC codes that apply to the CRS are listed below (compatible with the DST-2.)
DTC
DTC Description
P0006
Fuel shutoff valve "A" control circuit low voltage
P0007
Fuel shutoff valve "A" control circuit high voltage
P0016
Crankshaft position sensor, cylinder recognition sensor correlation
P0030
A/F sensor heater control circuit
P0031
A/F sensor heater control circuit low voltage
P0032
A/F sensor heater control circuit high voltage
P0036
A/F sensor heater control circuit
P0037
A/F sensor heater control circuit low voltage
P0045
Turbo/supercharger control solenoid open circuit
P0049
Turbo/supercharger overspeed
P0087
Fuel/rail pressure too low
P0088
Fuel/rail pressure too high
P0093
Fuel system leak maximum quantity detection
P0095
Intake air temperature sensor 2, circuit related
P0097
Intake air temperature sensor 2 circuit low voltage
P0098
Intake air temperature sensor 2 circuit high voltage
P0100
Mass Air Flow (MAF) meter, circuit related
P0101
MAF meter circuit range/performance
P0102
MAF meter circuit low input
P0103
MAF meter circuit high input
P0105
Boost pressure sensor, circuit related
P0107
Boost pressure sensor circuit low input
P0108
Boost pressure sensor circuit high input
P0112
Boost pressure sensor 1 circuit low voltage
P0113
Boost pressure sensor 1 circuit high voltage
P0115
Coolant temperature sensor, circuit related
P0117
Coolant temperature sensor circuit low voltage
Repair Section
2-125
DTC
DTC Description
P0118
Coolant temperature sensor circuit high voltage
P0119
Coolant temperature sensor circuit intermittent operation
P0120
Accelerator position sensor, switch "A" circuit related
P0121
Accelerator position sensor switch "A" circuit range/performance
P0122
Accelerator position sensor switch "A" circuit low voltage
P0123
Accelerator position sensor switch "A" circuit high voltage
P0124
Accelerator position sensor switch "A" circuit intermittent operation
P0168
Fuel temperature too high
P0180
Fuel temperature sensor, "A" circuit related
P0181
Fuel temperature sensor "A" circuit range/performance
P0182
Fuel temperature sensor "A" circuit low voltage
P0183
Fuel temperature sensor "A" circuit high voltage
P0184
Fuel temperature sensor "A" circuit intermittent operation
P0185
Fuel temperature sensor, "B" circuit related
P0186
Fuel temperature sensor "B" circuit range/performance
P0187
Fuel temperature sensor "B" circuit low voltage
P0188
Fuel temperature sensor "B" circuit high voltage
P0189
Fuel temperature sensor, "B" circuit intermittent operation
P0190
Rail pressure sensor, circuit related
P0191
Rail pressure sensor circuit range/performance
P0192
Rail pressure sensor circuit low voltage
P0193
Rail pressure sensor circuit high voltage
P0194
Rail pressure sensor circuit intermittent operation
P0200
Injector open circuit
P0201
Injector open circuit- #1 cylinder
P0202
Injector open circuit- #2 cylinder
P0203
Injector open circuit- #3 cylinder
P0204
Injector open circuit- #4 cylinder
P0205
Injector open circuit- #5 cylinder
P0206
Injector open circuit- #6 cylinder
P0208
Injector open circuit- #8 cylinder
P0217
Engine overheat
P0218
Transmission overheat
P0219
Engine overrun
P0230
Fuel pump, primary circuit related
P0234
Turbo/supercharger overboost
P0237
Boost pressure sensor circuit low voltage
P0263
Cylinder correction quantity error- #1 cylinder
P0266
Cylinder correction quantity error- #2 cylinder
P0269
Cylinder correction quantity error- #3 cylinder
P0272
Cylinder correction quantity error- #4 cylinder
Repair Section
2-126
DTC
DTC Description
P0275
Cylinder correction quantity error- #5 cylinder
P0278
Cylinder correction quantity error- #6 cylinder
P0299
Turbo/supercharger supercharge deficiency
P0335
Crankshaft position sensor, "A" circuit related
P0339
Crankshaft position sensor "A" circuit intermittent operation
P0340
Cylinder recognition sensor, "A" circuit related
P0400
EGR flow volume abnormality
P0404
EGR control circuit range/performance
P0405
EGR sensor "A" circuit low voltage
P0406
EGR sensor "A" circuit high voltage
P0407
EGR sensor "B" circuit low voltage
P0408
EGR sensor "B" circuit high voltage
P0500
Vehicle speed sensor, "A" circuit related
P0501
Vehicle speed sensor "A" circuit range/performance
P0504
Brake switch "A", "B" correlation
P0510
Throttle position switch closed
P0524
Engine oil pressure too low
P0540
Intake air heater "A" circuit
P0544
Exhaust gas temperature sensor, circuit related
P0545
Exhaust gas temperature sensor circuit low voltage
P0546
Exhaust gas temperature sensor circuit high voltage
P0560
Battery voltage
P0605
Engine ECU internal malfunction
P0607
Engine ECU internal malfunction
P0611
EDU malfunction
P0617
Starter relay circuit high voltage
P0627
Fuel pump "A" open control circuit
P0686
Engine ECU power supply relay control circuit low voltage
P0704
Clutch switch input circuit abnormality
P0710
Transmission oil temperature sensor, "A" circuit related
P0715
Turbine speed sensor, "A" circuit related
P0753
Shift solenoid "A" actuation related
P0758
Shift solenoid "B" actuation related
P0850
Parking/neutral switch, input circuit related
P2002
Particulate Matter (PM) capture efficiency at or below specified value
P2031
Exhaust gas temperature sensor, circuit related
P2032
Exhaust gas temperature sensor circuit low voltage
P2033
Exhaust gas temperature sensor circuit high voltage
P2047
Exhaust gas fuel addition valve abnormality
P2120
Accelerator position sensor, switch "D" circuit related
P2121
Accelerator position sensor switch "D" circuit range/performance
Repair Section
2-127
DTC
DTC Description
P2122
Accelerator position sensor, switch "D" circuit low input
P2123
Accelerator position sensor, switch "D" circuit high input
P2125
Accelerator position sensor, switch "E" circuit related
P2127
Accelerator position sensor, switch "E" circuit low input
P2128
Accelerator position sensor, switch "E" circuit high input
P2138
Accelerator position sensor, switch "D"/"E" circuit voltage correlation
P2226
Atmospheric pressure sensor, circuit related
P2228
Atmospheric pressure sensor circuit low voltage
P2229
Atmospheric pressure sensor circuit high voltage















Content      ..     2      3      4
