Problems
597
size of the expansion joints that must be built into the
structure.
A copper telephone wire has essentially no sag between
poles 35.0 m apart on a winter day when the temperature
is ! 20.0°C. How much longer is the wire on a summer day
when T
C
#
35.0°C?
10. The concrete sections of a certain superhighway are de-
signed to have a length of 25.0 m. The sections are poured
and cured at 10.0°C. What minimum spacing should the
engineer leave between the sections to eliminate buckling
if the concrete is to reach a temperature of 50.0°C?
11. A pair of eyeglass frames is made of epoxy plastic. At room
temperature (20.0°C), the frames have circular lens holes
2.20 cm in radius. To what temperature must the frames
be heated if lenses 2.21 cm in radius are to be inserted in
them? The average coefficient of linear expansion for
epoxy is 1.30 ) 10
!
4
(°C)
!
1
.
12. Each year thousands of children are badly burned by hot
tap water. Figure P19.12 shows a cross-sectional view of an
antiscalding faucet attachment designed to prevent such
accidents. Within the device, a spring made of material
with a high coefficient of thermal expansion controls a
movable plunger. When the water temperature rises above
a preset safe value, the expansion of the spring causes the
plunger to shut off the water flow. If the initial length L of
the unstressed spring is 2.40 cm and its coefficient of lin-
ear expansion is 22.0 ) 10
!
6
(°C)
!
1
, determine the in-
crease in length of the spring when the water temperature
rises by 30.0°C. (You will find the increase in length to be
small. For this reason actual devices have a more compli-
cated mechanical design, to provide a greater variation in
valve opening for the temperature change anticipated.)
9.
floorboard hold stationary the ends of this section of copper
pipe. Find the magnitude and direction of the displacement
of the pipe elbow when the water flow is turned on, raising
the temperature of the pipe from 18.0°C to 46.5°C.
L
Figure P19.12
The active element of a certain laser is made of a glass
rod 30.0 cm long by 1.50 cm in diameter. If the tempera-
ture of the rod increases by 65.0°C, what is the increase in
(a) its length, (b) its diameter, and (c) its volume? Assume
that the average coefficient of linear expansion of the glass
is 9.00 ) 10
!
6
(°C)
!
1
.
14. Review problem. Inside the wall of a house, an L-shaped
section of hot-water pipe consists of a straight horizontal
piece 28.0 cm long, an elbow, and a straight vertical piece
134 cm long (Figure P19.14). A stud and a second-story
13.
Figure P19.14
15.
A brass ring of diameter 10.00 cm at 20.0°C is heated and
slipped over an aluminum rod of diameter 10.01 cm at
20.0°C. Assuming the average coefficients of linear expan-
sion are constant, (a) to what temperature must this com-
bination be cooled to separate them? Is this attainable?
(b) What If? What if the aluminum rod were 10.02 cm in
diameter?
16. A square hole 8.00 cm along each side is cut in a sheet of
copper. (a) Calculate the change in the area of this hole
if the temperature of the sheet is increased by 50.0 K.
(b) Does this change represent an increase or a decrease
in the area enclosed by the hole?
17.
The average coefficient of volume expansion for carbon
tetrachloride is 5.81 ) 10
!
4
(°C)
!
1
. If a 50.0-gal steel con-
tainer is filled completely with carbon tetrachloride when
the temperature is 10.0°C, how much will spill over when
the temperature rises to 30.0°C?
18.
At 20.0°C, an aluminum ring has an inner diameter of
5.000 0 cm and a brass rod has a diameter of 5.050 0 cm.
(a) If only the ring is heated, what temperature must it
reach so that it will just slip over the rod? (b) What If? If
both are heated together, what temperature must they
both reach so that the ring just slips over the rod? Would
this latter process work?
19.
A volumetric flask made of Pyrex is calibrated at 20.0°C. It
is filled to the 100-mL mark with 35.0°C acetone. (a) What
is the volume of the acetone when it cools to 20.0°C?
(b) How significant is the change in volume of the flask?
