BMW AG Motorcycle (K1100LT, K1100RS). Manual - part 14

12.29

Troubleshooting on battery

Battery produces excessive gas.

no

Check battery.
Is battery defective?

yes

Renew battery.

no

Check contact between regulator/alternator
and between alternator/diode carrier.
Is contact poor?

yes

Repair cable connections.

no

Check regulator.
Is regulator defective?

yes

Renew regulator.

Acid level too low.

no

Check level.
Is level below set level?

yes

Top up with distilled water.

no

Check charge status.
Is battery overcharged?

yes

Top up with distilled water.

12.30

Acid density too low.

nein

Check charge status of battery.
Is battery discharged?

yes

Charge battery.

no

Check acid concentration.
Is acid concentration too low?

yes

Adjust acid concentration.

no

Check line network. Is there short-circuit in line
network?

yes

Check electrical system.

no

Check alternator. Alternator does not charge
correctly?

yes

Check generator/regulator; replace if neces-
sary.

Acid leak at plugs.

no

Check acid level.
Is acid level too high?

yes

Adjust acid level.

no

Check charging voltage.
Is charging voltage too high?

yes

Check regulator; replace if necessary.

Excessive drop in terminal voltage
under load.

no

Check voltage at battery.
Is battery discharged?

yes

Charge battery.

no

Check charging voltage.
Is charging voltage too low?

yes

Check regulator; replace if necessary.

12.31

Insufficient power output

no

Check connection terminals.
Are terminals loose/oxidated?

yes

Clean/tighten terminals.

no

Check acid level.
Is level below top edge of plates?

yes

Top up with distilled water.

no

Check charge status.
Is charge too low?

yes

Charge battery/replace defective battery.

Battery constantly overcharged.

no

Check charging system.
Is there a defect in charging system?

yes

Generator/check regulator; replace if neces-
sary.

no

Check cell for short-circuit.
Does a cell have a short-circuit?

yes

Replace battery.

12.32

13.1

Contents

Page

13

Technical data

................................................................................................................................ 3

Adjusting idle speed

...................................................................................................................5

Checking start speed increase (choke), adjusting if necessary

........................6

Checking start speed increase

 .................................................................................................6

Adjusting start speed increase

 .................................................................................................6

Adjusting CO value

......................................................................................................................7

Removing/installing and checking/adjusting throttle position sensor

...........8

Removing and installing throttle position sensor

 ..............................................................8

Checking trottle position sensor

 ..............................................................................................8

Adjusting throttle position sensor

 ............................................................................................8

Removing and installing air cleaner insert

.....................................................................9

Removing and installing air cleaner housing

..............................................................10

Removing and installing throttle rail

................................................................................12

Removing and installing injectors

 ..........................................................................................13

Removing and installing intake stub pipe

 ..........................................................................13

Removing and installing Motronic control unit

.........................................................14

13 Fuel preparation and control

13.2

13.3

13

Technical data

K 1100 LS

K 1100 RS

Inside ø of

throttle stub pipe

mm (in) 35 (1.37795)

CO value

% by vol.

1,5 ± 0,5

Idle speed

rpm 950 ± 50

13.4
