(1) Connect SST's red clip to the battery's positive (+) terminal and the black clip to the battery's negative (-) terminal. HINT: Do not connect the yellow connector. The yellow connector is used to connect to the seat belt pretensioner. CAUTION: If the LED illuminates when the activation switch is not being pressed, SST may be malfunctioning. Replace SST with a new (b) Disconnect SST from the battery. (c) Disconnect the pretensioner connector. (1) Disconnect the cable from the negative (-) battery terminal. (2) Remove the front door scuff plate
. (3) Remove the rear door scuff plate
. (4) Remove the front door opening trim weatherstrip
. (5) Remove the rear door opening trim weatherstrip
. (6) Remove the lower center pillar garnish
. (7) Disconnect the pretensioner connector as shown in the illustration. SEAT BELT: FRONT SEAT OUTER BELT ASSEMBLY (for Double Cab... |
