Figure 17
48984
POWER TAKE-OFF APPLICATION DIAGRAM
POWER TAKE-OFF
225
S
TRALIS
AT/AD
SPECIFICATIONS AND DATA
ZF POWER TAKE-OFF
For transmissions:
- EuroTronic Automated 12 AS 2301 D.D./O.D.
TYPE
N AS/10 N AS/10 N AS/10
N AS/10b+c
Order No.
8866613
8866614
8866615
8866617
MOTION OUTPUT I
Drive ratio
2.56
2.35
1.85
1.85
PTO output rev ratio / PTO input rev ratio:
1.95
1.79
1.41
1.41
Rated torque at PTO output with 1500 rev/min
Nm
300
330
430
330
Transmission detectable torque
Nm
769
776
795
776
MOTION OUTPUT 2
Drive ratio
-
-
-
0.93
PTO output rev ratio / PTO input rev ratio:
1.12
1.12
1.12
1.12
Rated torque at PTO output with 1500 rev/min
Nm
-
-
-
670
Transmission detectable torque
Nm
-
-
-
993
Expected duration with rated torque and 1500 rev/min at output hours
500
Rotation direction
engine direction
Type of motion output (vehicle travelling direction)
rear with flange
flange attachment
and with pump
attachment
Control
pneumatic
Weight applied on barycenter
N
206
225
Application
To secondary shaft on transmission rear side
Oil quantity to be added to gearbox
dm
3
-
PTO = POWER TAKEOFF
