Iveco Daily. Manual - part 214





85918

85919

85917

5

TH

- 6

TH

GEAR SYNCHRONISERS

A. synchronization reserve 6

th

-5

th

gear: 1

÷1,4 mm

B. 5

th

-6

th

release clearance: 0,3

÷0,7 mm

3

TH

/4

TH

GEAR SYNCHRONISERS

A. synchronization reserve 1

st

-2

nd

gear: 1

÷1,4 mm

B. 1

st

-2

nd

release clearance: 0,3

÷0,7 mm

2

ND

-1

ST

GEAR SYNCHRONISERS

A. synchronization reserve 2

nd-1st

gear: 1,6

÷2,0 mm

B. 1

st

-2

nd

release clearance: 0,9

÷1,5 mm

REVERSE GEAR SYNCHRONISER

A. Synchronization reserve: 0.9

÷1,4 mm

B. release clearance: 0,35

÷0,85 mm

1. Hub - 2. 5

th

gear - 3. Synchronizer ring - 4. Sliding sleeve - 5. 6

th

gear cog-wheel - 6. 3

rd

gear cog-wheel -

7. 4

th

gear cog-wheel - 8. 2

nd

gear cog-wheel - 9. 1

st

gear cog-wheel - 10. Middle ring - 11. Ring - 12. Reverse gear -

13. Reverse gear ring

Figure 79

Figure 80

Figure 81

Figure 82

90220

112

6 S 380 O.D. TRANSMISSION

D

AILY

Base - May 2004

51966

51968

51967

51969

51970

51971

Figure 83

Figure 84

Figure 85

Figure 86

Figure 87

Figure 88

Clamp the transmission shaft (1) in a vice and position the half
roller bearings (2) on it.

Mount the 4th gear (2) and position the synchronizer ring (1)
on this.

Heat the hub (2) to a temperature of 110

° ÷ 150°C and

mount it on the transmission shaft (1), taking care that the
protrusions (3) of the synchronizer ring are positioned
correctly in their seats in the hub (2).

Mount the retaining ring (1) whose thickness produces null
end float in its seat.

Check the end float of the 4th gear (2). It should be
0.15

÷ 0.40 mm.

Mount the sliding sleeve (1) on the hub (2). Put the springs (5),
plugs (3) and balls (4) into the seats in the hub (2), settling
them under the sliding sleeve (1).

Position the synchronizer ring (2) on the hub (3) so that its
protrusions enter the seats in the hub (3). Mount the roller
bearing (1).

1

1

1

1

1

1

6 S 380 O.D. TRANSMISSION

113

D

AILY

Base - May 2004

Heat the internal rings (1-3) of the tapered roller bearings to
a temperature of approx. 80

°C and, with a suitable punch (1),

mount them on the transmission shaft (2).

51974

51975

51973

Figure 89

Figure 90

Figure 91

Figure 92

Figure 93

Figure 94

Mount the 3rd gear (1).

With a hydraulic press, mount the 6

th

gear (1) pre-heated to

approx. 170

°C.

Check the end float of the 3

rd

gear (2). It should be 0.15

÷0.40

mm.

With a hydraulic press, mount the 5

th

gear (1) pre-heated to

approx. 170

°C.

Mount the retaining ring (1) whose thickness produces null
end float in its seat.

Tighten the main shaft (1) and position the roller bearing (2)
on it.

Mounting the main shaft

Mount the synchronizer rings on their respective gears
according to the marks made during disassembly or
when checking in the case of replacement.

1

1

NOTE

90221

90222

90223

114

6 S 380 O.D. TRANSMISSION

D

AILY

Base - May 2004

51980

51981

51982

51983

51984

Figure 95

Figure 96

Figure 97

Figure 98

Figure 99

Mount the 2nd gear (4) and position the ring (3), middle ring
(2) and synchronizer ring (1) on it, taking care that the tongues
(

→) of the middle ring (2) enter the slots (→) in the gear (4).

Heat the hub (2) to a temperature of 80

° ÷ 110°C and mount

it on the main shaft (1), taking care that the projections (3) of
the synchronizer ring and the tongues (

→) of the ring (3,

Figure 95) are positioned correctly in the seats in the hub (2).

Check the end float of the gear (4). It should be
0.25

÷ 0.5 mm.

Mount the sliding sleeve (2) on the hub (1). Put the springs (5),
plugs (4) and balls (3) into the seats in the hub (1), settling
them under the sliding sleeve (2).

Position the synchronizer ring (3), middle ring (2) and ring (1)
on the hub (4), taking care that the tongues (

→) of the ring

(1) and the projections (

→) of the ring (3) enter the seats in

the hub (4).

Position the roller bearing (2). Mount the 1st gear (1) taking
care that the tongues (3) of the middle ring enter the slots in
the gear (1).

6 S 380 O.D. TRANSMISSION

115

D

AILY

Base - May 2004
