Figure 1 METHODS OF DIAGNOSIS The available diagnosis systems are currently: - PT-01 - SYMPTOMS 1. Connector with 19-pin diagnosis socket - 2. LED signalling communication between the instrument - control unit and correct power supply - 3. USB indicator light - 4. Serial port indicator light - 5. Power supply connector (power only to update SW with serial port). 117696 PT-01 SECTION 3 - INDUSTRIAL APPLICATION 51 F2C CURSOR ENGINES |
