6F – 10 EXHAUST SYSTEM
Important Operations – Installation
Follow the removal procedure in the reverse order to
perform the installation procedure. Pay careful attention to
the important points during the installation procedure.
8. Front Pipe With Gasket
Connect the front pipe to the exhaust manifold.
Torque kg
⋅m(lb⋅ft/N⋅m)
6.8
± 0.5 (49 ± 3.6/67 ± 5)
6. Front Pipe BRKT
Tighten the fixing bolt to the specified torque.
Torque kg
⋅m(lb⋅ft/N⋅m)
Front pipe side 2.4
± 0.5 (17 ± 3.6/23 ± 5)
Transmission side 4.1
± 1.0 (30 ± 7/40 ± 1)
5. Oxidizing Catalytic Converter With Gasket (4JA1TC)
Center Pipe With Gasket (4JH1TC)
Tighten the fixing nuts to the specified torque.
Torque kg
⋅m(lb⋅ft/N⋅m)
4.4
± 1.3 (32 ± 9.4/43 ± 13)
3. Silencer With Gasket
Tighten the fixing nuts to the specified torque.
Torque kg
⋅m(lb⋅ft/N⋅m)
4.4
± 1.3 (32 ± 9.4/43 ± 13)
2. Tail Pipe With Gasket
Tighten the fixing nuts to the specified torque.
Torque kg
⋅m(lb⋅ft/N⋅m)
4.4
± 1.3 (32 ± 9.4/43 ± 13)
• Connect battery ground cable.
• After assembling each part, start the engine to check
for any leakage of gas at each connection.
