7A-232 AUTOMATIC TRANSMISSION (AW30-40LE)
MAIN DATA AND SPECIFICATIONS
GENERAL SPECIFICATIONS
Remaks
Model AW30-40LE
Engine 4JG2-T
Electronic control planetary gear type
Type
3-element 1-stage 2-phase type
(with lock-up mechanism)
1st 2.804
2nd 1.532
3rd 1.000
4th (O/D)
0.705
Gear ratio
Reverse 2.394
Name BESCO
ATF
Ⅲ
Oil used
Q’ty (l)
8
Torque converter
2400±150
Stall speed (rpm)
Forward clutch
C-1
5
Direct clutch
C-2
4
OD direct clutch
C-0
2
Number of discs
Second coast brake
B-1
40 mm
Band width or
Number of discs
Second brake
B-2
5
First and reverse brake
B-3
6
F
ric
tion el
ement
Overdrive brake
B-0
4
Number of discs
One-way clutch No.1
F-1
22
One-way clutch No.2
F-2
28
Cl
ut
ch
OD one-way clutch
F-0
24
Number of sprage
Sun gear
42
Pinion gear
19
Front planetary
Ring gear
79
Sun gear
33
Pinion gear
23
Rear planetary
Ring gear
79
Sun gear
33
Pinion gear
23
P
lan
et
ar
y ge
ar
O/D planetary
Ring gear
79
Number of teeth
