7A2-12  DIAGNOSIS









F0: Diagnostic Trouble Code

F0: Read DTC Infor As Stored By ECU
F1: Clear DTC Information



F1: Data Display

F2: Snapshot

F3: Miscellaneous Test

F0: Lamp

F0: Power Lamp Test
F1: 3rd Start Lamp Test
F2: AT Oil Temperature Lamp Test
F3: Transmission Check Light Test

F1: Solenoids

F0: Low & Reverse Brake Solenoid
F1: 2-4 Brake Solenoid
F2: High Clutch Solenoid
F3: Low Clutch Solenoid
F4: Line Pressure Solenoid

F5: Lock Up Duty Solenoid







F0: Diagnostic Trouble Code

The purpose of the "Diagnostic Trouble Codes" mode is
to display stored trouble code in the TCM.
When "Clear DTC Information" is selected, a "Clear DTC
Information", warning screen appears. This screen
informs you that by cleaning DTC's "all stored DTC
information in the TCM will be erased".
After clearing codes, confirm system operation by test
driving the vehicle.


F1: Data Display

The purpose of the "Data Display" mode is to continuously
monitor data parameters.
The current actual values of all important sensors and
signals in the system are display through F1mode.
See the "Typical Scan Data" section.


F2: Snapshot

"Snapshot" allows you to focus on making the condition
occur, rather than trying to view all of the data in
anticipation of the fault. The snapshot will collect
parameter information around a trigger point that you
select.


F3: Miscellaneous Test:

The purpose of "Miscellaneous Test" mode is to check for
correct operation of electronic system actuators.



DIAGNOSIS  7A2-13





7A2-14  DIAGNOSIS



Miscellaneous Test

The state of each circuit can be tested by using miscellaneous test menus. Especially when DTC cannot be
deteced, a faulty circuit can be diagnosed by testing each circuit by means of these menus.
Even DTC has been detected, the circuit tests using these menus could help discriminate between a mecanical
trouble and an electrical trouble.

Connect Tech 2 and select "Powertrain", "JR 405E" & "Miscellaneous Test".
F0: Lamps



The circuit is normal if the warning light in the meter panel comes on and goes out in accordance with Tech 2
instruction.







Lamps



F0: Power Lamp Test

F1: 3rd Start Lamp Test

F2: AT Oil Tempeature Lamp Test

F3: Transmission Check Light Test











F0: Power Lamp Test







Power Lamp Test



Power Lamp

Off











  Press "Active" key.



Then, "POWER DRIVE" indicator lamp is turned on in the

meter panel.

  Press "Inactive" key.

  Then, "POWER DRIVE" indicator lamp is turned off in the

meter panel.

  Press "Quit" Key to cancel the test.

F1: 3rd Start Lamp Test



F2: AT Oil Temperature Lamp Test



F3: Transmisstion Check Light Test





Test procedure is same as "F0: Power Lamp Test".



The circuit is normal if the warning light in the meter panel
comes on and goes out in accordance with Tech 2 instruction.


F1: Solenoids



The circuit is normal if clicking sound is generated in accordance with Tech 2 instruction.







Solenoids

F0: Low & Reverse Brake Solenoid

F1: 2-4 Brake Solenoid

F2: High Clutch Solenoid

F3: Low Clutch Solenoid

F4: Line Pressure Solenoid

F5: Lock Up Duty Solenoid











DIAGNOSIS  7A2-15



F0: Low & Reverse Brake Solenoid







Low & Reverse Brake Solenoid


Low & Reverse Brake Duty

0%









  Press "Active" key.

  Then, duty datio is indicated 100 % and "clicking sound" is

generated from the transmission control valve.

  Press "Inactive" key.

  Then, duty datio is indicated 0 % and "clicking sound" is

generated from the transmission control valve.

  Press "Quit" Key to cancel the test.


F0: Low & Reverse Brake Solenoid
F1: 2-4 Brake Solenoid
F2: High Clutch Brake Solenoid
F3: Low Clutch Solenoid
F4: Line Pressure Solenoid
F5: Lock Up Duty Solenoid






Test procedure is same as "F0: Low & Revese Brake
Solenoid"



The circuit is normal if clicking sound is generated in
accordance with Tech 2 instruction.
