8-304  ELECTRICAL-BODY AND CHASSIS

Terminal

No.

Wire

color

Connecting to

Check item

Connecting

terminal

Check condition

Standard

9

G/R

Power window

relay

Voltage

9-Ground

Starter SW “ON”

Approx.

12V

6

L/R

Power window

10

L/W

motor

5

B

Ground

Continuity

5-Ground

-

Continuity

Harness side

Rear Power Window Switch-LH & RH

1.Harness Side Connector Circuit

Disconnect  the  switch  connector,  and  check  voltage  and

continuity between the harness side connector terminals as

shown in the following tables.

D-12

 (RR-LH)

Terminal

No.

Wire

color

Connecting to

Check item

Connecting

terminal

Check condition

Standard

4

G/R

Power window

relay

Voltage

4-Ground

Starter SW “ON”

Approx.

12V

5

L/R

Power window

6

BR/W

motor

3

B

Ground

Continuity

3-Ground

-

Continuity

D-16

 (RR-RH)

Terminal

No.

Wire

color

Connecting to

Check item

Connecting

terminal

Check condition

Standard

4

G/R

Power window

relay

Voltage

4-Ground

Starter SW “ON”

Approx.

12V

5

L/R

Power window

6

BR/W

motor

3

B

1

B

Continuity

-

6-10

Continuity

Continuity

Continuity

6-10

-

Continuity

Continuity

6-10

-

Ground

Continuity

3-1

Continuity

-

ELECTRICAL-BODY AND CHASSIS  8-305

Harness side

Driver Seat Side Power Window Motor

1.Driver  Seat  Side  Power  Window  &  Door  Lock  Switch

Connector Circuit

Disconnect  the  switch  connector,  apply  the  battery  voltage

(12V)  to  the  harness  side  connector  terminals  and  check

operation.

Connecting terminals

Operation

1 (L/R)

10 (L/W)

direction

-

+

DOWN

+

-

UP

2.Driver  Seat  Side  Power  Window  Motor  Connector

Circuit

Disconnect  the  switch  connector,  apply  the  battery  voltage

(12V)  to  the  motor  side  connector  terminals  and  check

operation.

Connecting terminals

Operation

1

2

direction

+

-

DOWN

-

+

UP

8-306  ELECTRICAL-BODY AND CHASSIS

Harness side

Front Passenger’s Power Window Motor

1.Front  Passenger’s  Power  Window  Switch  &  Door  Lock

Switch Connector Circuit

Disconnect  the  motor  connector,  apply  the  battery  voltage

(12V)  to  the  harness  side  connector  terminals  and  check

operation.

Connecting terminals

Operation

6 (L/R)

10 (L/W)

direction

-

+

DOWN

+

-

UP

2.Front  Passenger’s  Power  Window  Motor  Connector

Circuit

Disconnect  the  switch  connector,  apply  the  battery  voltage

(12V)  to  the  motor  side  connector  terminals  and  check

operation.

Connecting terminals

Operation

1

2

direction

+

-

DOWN

-

+

UP

ELECTRICAL-BODY AND CHASSIS  8-307

Harness side

Rear Passenger’s Power Window Motor-LH

1.Rear Power Window Switch-LH Connector Circuit

Disconnect  the  motor  connector,  apply  the  battery  voltage

(12V)  to  the  harness  side  connector  terminals  and  check

operation.

Connecting terminals

Operation

5 (L/R)

6 (BR/W)

direction

-

+

DOWN

+

-

UP

2.Rear Power Window Motor-LH Connector Circuit

Disconnect  the  switch  connector,  apply  the  battery  voltage

(12V)  to  the  motor  side  connector  terminals  and  check

operation.

Connecting terminals

Operation

1

2

direction

+

-

DOWN

-

+

UP
