8-280 ELECTRICAL-BODY AND CHASSIS 1. All the doors do not lock and unlock CheckpointTrouble Cause Count ermeasure Reinstall or replace the fuse No. CB-15 (20A) Poor fuse contact or blown NG Repair grounding point ( B-28 ) contact Grounding point ( B-28 ) Poor grounding point contact Repair open circuit or connector contact Voltage between the driver’s side power window & door lock SW harness side connector terminal 9 D-5 and the ground (Should be battery voltage present) Open circuit or poor connector contact NG NG OK OK OK Fuse No. CB-15 (20A, Fuse box) Repair open circuit or connector contact Open circuit or poor connector contact NG Replace the driver’s side power window & door lock SW. Driver’s side power window & door lock SW. function SW. malfunction NG OK Continuity between 5 D-5 and B-28 2. All the doors do not get locked (or unlocked) Repair open circuit or connector contact Open circuit or poor connector contact NG Replace the driver’s side power window & door lock SW. Driver’s side power window & door lock SW. function SW. malfunction NG OK Continuity between the driver’s D-5 and 8 D-5 |
