ELECTRICAL-BODY AND CHASSIS 8-113 Harness side 2. Warning Buzzer Harness Side Connector Circuit Disconnect the warning buzzer connector and check continuity and voltage between the warning buzzer harness side connector terminals. Terminal NO. Wire color Connecting to Check item Connecting terminal Check condition Standard Seat Unfasten Continuity belt Fasten No continuity 3 G/R Tail relay 3-Ground Lighting SW “ON” Approx. 12V Key remind SW Insert Approx. 12V (Starter SW) Remove 0V 6 Y Fuse CB-5 6-Ground Starter SW “ON” Approx. 12V Door SW Open Continuity (FRT-LH) Continuity Close No continuity 2 B Ground 2-Ground - Continuity KEY REMIND SWITCH (STARTER SWITCH) Switch Connections Connector No. C-41 Starter Terminal switch key position No. 5 7 Removed OFF ACC Inserted ON START LOCK 5-Ground Continuity Seat belt SW G/Y 5 Key 4-Ground 4 R/B Voltage FRT door-LH 1-Ground 1 B/W |
