8–296 ELECTRICAL-BODY AND CHASSIS

Rear Power Window Motor-RH

1. Rear Power Window Switch-RH Connector Circuit

Disconnect the motor connector, apply the battery
voltage (12V) to the harness side connector terminals
and check operation.

1

3 4 5 6

2

2. Rear Power Window Motor-RH Connector Circuit

Disconnect the switch connector, apply the battery
voltage (12V) to the motor side connector terminals
and check operation.

1

2

M

DOWN

UP

825RV092

Harness side

Motor side

D-16

D-15

Connecting terminals

Operation direction

5 (L/R)

6 (BR/W)

–

+

DOWN

+

–

UP

Connecting terminals

Operation direction

1

2

+

–

DOWN

–

+

UP

ELECTRICAL-BODY AND CHASSIS 8–297

MEMO

8–298 ELECTRICAL-BODY AND CHASSIS

AUDIO, CLOCK AND CIGARETTE LIGHTER

PARTS LOCATION (LHD)

H-9

H-10

H-13

B-22

B-21

B-20

B-10

D-8

H-7

D-3

B-14

C-41

B-28

H-16

D-17

H-14

D-13

D08RVA54

ELECTRICAL-BODY AND CHASSIS 8–299

PARTS LOCATION (RHD)

H-9

H-13

H-7

H-10

B-21

B-20

B-22

B-10

D-3

D-8

B-14

C-41

B-28

H-16

D-17

H-14

D-13

D08RVA52
