ELECTRICAL-BODY AND CHASSIS  8-303

  INSPECTION AND REPAIR








Power Window Relay

Check continuity between the relay terminals.

1

-

5

.........................No continuity

(When battery voltage is applied between

2

 and

4

)

1

-

5

.........................Continuity



Harness side






Driver Seat Side Power Window & Door Lock

Switch

1.  Harness Side Connector Circuit
  Disconnect the switch connector, and check voltage and

continuity between the harness side connector terminals as
shown in the following table.





Terminal

No.

Wire

color

Connecting to

Check item

Connectin

g terminal

Check condition

Standard

2 G/R

Power window
relay

Voltage

2-Ground

Starter SW “ON”

Approx.

12V

1 L/R

Power window









10 L/W

motor









5 B

Ground  Continuity

5-Ground  -  Continuity




Harness side






Front Passenger’s Power Window & Door Lock

Switch

1.  Harness Side Connector Circuit
  Disconnect the switch connector, and check voltage and

continuity between the harness side connector terminals as
shown in the following table.





Continuity

-

1-10

Continuity

8-304  ELECTRICAL-BODY AND CHASSIS

Terminal

No.

Wire

color

Connecting to

Check item

Connectin

g terminal

Check condition

Standard

9 G/R

Power window
relay

Voltage

9-Ground

Starter SW “ON”

Approx.

12V

6 L/R

Power window









10 L/W

motor









5 B

Ground  Continuity

5-Ground

-  Continuity




Harness side






Rear Power Window Switch-LH & RH

1.  Harness Side Connector Circuit
  Disconnect the switch connector, and check voltage and

continuity between the harness side connector terminals as
shown in the following tables.





D-12

 (RR-LH)

Terminal

No.

Wire

color

Connecting to

Check item

Connectin

g terminal

Check condition

Standard

4 G/R

Power window
relay

Voltage

4-Ground

Starter SW “ON”

Approx.

12V

5 L/R

Power window









6 BR/W

motor









3 B

Ground  Continuity

3-Ground

-  Continuity

D-16

 (RR-RH)

Terminal

No.

Wire

color

Connecting to

Check item

Connectin

g terminal

Check condition

Standard

4 G/R

Power window
relay

Voltage

4-Ground

Starter SW “ON”

Approx.

12V

5 L/R

Power window









6 BR/W

motor









3 B











1 B













Continuity

-

6-10

Continuity

Continuity

Continuity

6-10

-

Continuity

Continuity

6-10

-

Ground Continuity

3-1

Continuity

-

ELECTRICAL-BODY AND CHASSIS  8-305

Harness side



Driver Seat Side Power Window Motor

1. Driver Seat Side Power Window & Door Lock Switch

Connector Circuit

  Disconnect the switch connector, apply the battery voltage

(12V) to the harness side connector terminals and check
operation.

Connecting terminals

Operation

1 (L/R)

10 (L/W)

direction

-

+

DOWN

+

-

UP






2. Driver Seat Side Power Window Motor Connector

Circuit

  Disconnect the switch connector, apply the battery voltage

(12V) to the motor side connector terminals and check
operation.

Connecting terminals

Operation

1

2

direction

+

-

DOWN

-

+

UP



8-306  ELECTRICAL-BODY AND CHASSIS

Harness side



Front Passenger’s Power Window Motor

1.  Front Passenger’s Power Window Switch & Door Lock

Switch Connector Circuit

  Disconnect the motor connector, apply the battery voltage

(12V) to the harness side connector terminals and check
operation.

Connecting terminals

Operation

6 (L/R)

10 (L/W)

direction

-

+

DOWN

+

-

UP






2. Front Passenger’s Power Window Motor Connector

Circuit

  Disconnect the switch connector, apply the battery voltage

(12V) to the motor side connector terminals and check
operation.

Connecting terminals

Operation

1

2

direction

+

-

DOWN

-

+

UP
